Sanyo Denki SANUPS E11A Series User instructions

User Settings Guide
Uninterruptible Power Supply
M0009096B

Introduction
Thank you for choosing the SANUPS E11A.
SAVE THESE INSTRUCTIONS
This manual describes the functions and setting operations of the user setting menus. To operate
correctly, read this manual when setting or changing the user setting menus of the UPS. Please be sure
to also read the E11A Instruction Manual for details about UPS installation, operation, and
maintenance. Store this manual together with the E11A instruction manual in a safe place for
convenient reference.
UPS is an abbreviation for Uninterruptible Power Supply.
Table of contents
§1. User Settings........................................................................................................... 1
§1.1 Prior to Modifying the User Settings ............................................................ 1
§2. Setup Menu List...................................................................................................... 2
§3. Operation................................................................................................................. 4
§3.1 Setting UPS Operation Mode ....................................................................... 4
§3.2 Setting Output Voltage ................................................................................. 5
§3.3 Setting Output Frequency Sync Range ....................................................... 6
§3.4 Setting Battery Power Startup Frequency ................................................... 7
§3.5 Setting PC Interface ...................................................................................... 8
§3.6 Setting Serial Baud Rate............................................................................... 9
§3.7 Setting UPS Operation Upon Power Recovery ............................................. 10
§3.8 Setting Buzzer Sound .................................................................................... 11
§3.9 Setting UPS Shutdown Operation ................................................................ 12
§3.10 Setting Overload Recovery Operation......................................................... 13
§3.11 Setting UPS Operation at OFF........................................................ 14
§3.12 Setting Low Battery Voltage Warning Timing ........................................... 15
§3.13 Setting Battery Backup Time...................................................................... 16
§3.14 Setting Battery Type.................................................................................... 17
§3.15 Setting Battery Test Schedule..................................................................... 18
§3.16 Resetting Battery Information .................................................................... 19
§3.17 Enabling and Disabling Linked Operation Delay ...................................... 20
§3.18 Setting Linked operation ON delay time.................................................... 21
§3.19 Setting Linked operation OFF delay time .................................................. 22
§3.20 Enabling and Disabling Output line control............................................... 23
§3.21 Setting Outlet box OUTPUT1 ON delay time ............................................ 24
§3.22 Setting Outlet box OUTPUT2 ON delay time ............................................ 25
§3.23 Setting Outlet box OUTPUT1 OFF delay time .......................................... 26
§3.24 Setting Outlet box OUTPUT2 OFF delay time .......................................... 27
§3.25 Setting Outlet box OUTPUT1 power outage output time.......................... 28
§3.26 Setting Outlet box OUTPUT2 power outage output time.......................... 29
§3.27 Setting Operation of Outlet Box OUTPUT0 after stopping of
OUTPUT1 and OUTPUT2 .......................................................................... 30
§3.28 Setting Ring signal....................................................................................... 31
§3.29 Resetting the Setting Value......................................................................... 32
Appendix. UPS Model Name ..................................................................................... 33

1
§
§1 1. . U Us se er r S Se et tt ti in ng gs s
§
§1 1. .1 1 P Pr ri io or r t to o M Mo od di if fy yi in ng g t th he e U Us se er r S Se et tt ti in ng gs s
The UPS has a user settings menu, described in §2 “Setup Menu List”. The factory default setting of the
UPS is indicated by the “ *” mark in the “Default Setting” column. Configure each menu according to your
environment, your applications, and the specifications of the connected load devices. For details of setup
operations of each menu, see §3.1 to §3.29. Whenever you change a menu item setting, we recommend that
you place a check mark in the “Current Setting” column field of the Setup Menu List.
All of the user setting menu items can be selected and set by display LED blinking pattern.
Setup menu list and the blinking pattern of indicators on the control panel are illustrated in the following
figures. The control panel display varies depending on the UPS model. See Appendix “UPS Model name” to
check your UPS Model. The figures on each page show the example of E11A*** model. The setup operations
are also identical for E11A***-T or E11A351.
MenuLED SettingLED
No. Ref.
page Item Menu Menu LED Setting Setting LED Default Setting
Current
Setting
Remarks
Auto
●○○○
*
Double Conversion
○●○○
1 4 3.1
UPS operation
mode
○
●○○○
Economy
●●○○
100V 200V
●○○○
110V 220V
○●○○
115V 230V
●●○○
120V 240V
○○●○
2 5 3.2 Output voltage
(RESTART)
○
○●○○
－ 208V
●○●○
See
remarks
Select the menu by the blinking pattern of 5
LEDs. The blinking pattern changes each time
you press . Pressing this button repeatedly
cycles through the LED blinking patterns.
For the menus indicated by “RESTART” in
this column, restart of the UPS is required.
The factory default
setting.
When you change the setting of the menus indicated by RESTART in the “Menu” column, its changes do not take effect
until you restart the UPS. If a restart is required, be sure to power off the load devices before resetting. See §11.3 “UPS
Shutdown (If Not to Be Used for More Than a Week)” in the
E11A Instruction Manual for information about how to shut
down the UPS, and §11.1 “UPS Startup” in the
E11A Instruction Manual for information about how to start the UPS.
Note
Indicates the section numbers of
sections with reference information
for each item. See the indicated
sections for detailed information.
Select the setting by the blinking pattern of 4
LEDs. The blinking pattern changes each time
you press . Pressing this button repeatedly
cycles through the LED blinking patterns.
Place a check mark when
you change the setting.
E
E1 11 1A A* ** ** *
E
E1 11 1A A* ** ** *- -T T
E
E1 11 1A A3 35 51 1
● : indicates that LED is blinking.
○ : indicates that LED is off.

2
§
§2 2. . S Se et tu up p M Me en nu u L Li is st t
No.
Ref.
page Item Menu Menu LED Setting Setting LED
Default
Setting
Current
Setting
Remarks
Auto
●○○○
*
Switch the UPS operating mode automatically.
Double Conversion
○●○○
Set the UPS operating mode to Double Conversion mode.
1 4 3.1
UPS operation
mode
○
●○○○
Economy
●●○○
Set the UPS operating mode to Economy mode
100V 200V ●○○○
110V 220V ○●○○
115V 230V ●●○○
120V 240V ○○●○
2 5 3.2
Output voltage
(RESTART)
○
○●○○
- 208V ●○●○
See
remarks
Set the rated Output voltage. Same as Input voltage.
Default setting varies depending on UPS Model.
See §12.2 “Setup Menu List” in the E11A Instruction Manual.
1% ●○○○
± 1%
3% ○●○○
*
± 3%
3 6 3.3
Frequency sync
range (RESTART)
○
●●○○
5% ●●○○
± 5%
Output frequency variation range (%
)
50Hz ●○○○
4 7 3.4
Battery power
startup frequency
(RESTART)
○
○○●○
60Hz ○●○○
See
remark
Set the output frequency when UPS starts from the battery
power during AC input power failure. Default setting varies
depending on UPS Model. See §12.2 “Setup Menu List” in the
E11A Instruction Manual.
Standalone ●○○○
Set when using UPS remote ON/OFF or Standard OS UPS
Services. When using 001 model, do not use this setting.
Workstation
○●○○
*
Set when using a power management software, LAN card or
UPS remote ON and One-touch system shutdown.
Serial Login
●●○○
Shutdown by serial login.
5 8 3.5 PC interface
○
●○●○
- ○○●○
Do not use this setting.
9600 ●○○○
*
9600 bps.
4800 ○●○○
4800 bps.
6 9 3.6 Serial baud rate
○
○●●○
2400 ●●○○
2400 bps.
Set the serial baud rate when a
workstation, PC, or optional LAN
card is connected.
Auto ●○○○
*
Auto restart
OFF ○●○○
The UPS stays off.
30% ●●○○
Auto restart when battery
charge reaches 30%.
50% ○○●○
Auto restart when battery
charge reaches 50%.
7 10 3.7
UPS operation upon
power recovery
○
●●●○
80% ●○●○
Auto restart when battery
charge reaches 80%.
Specify when to restart the UPS after
a power outage and shutdown of the
UPS due to final discharge of the
batteries.
All patterns
●○○○
*
All sounds
Pattern 1
○●○○
Emit sounds on serious failure, battery trouble and key click
sounds.
Pattern 2
●●○○
Emit sounds on serious failure and key click sounds.
8 11 3.8 Buzzer sound
○
○○○●
OFF
○○●○
Emit key click sounds only.
1 second
●○○○
*
Turn the UPS off when pressed
for 1 second.
3 seconds
○●○○
Turn the UPS off when pressed
for 3 seconds.
9 12 3.9 Shutdown operation
○
●○○●
Special operation
●●○○
Turn the UPS off on special
operation.
Set the operation for switch to
stop the UPS power supply.
Auto return ●○○○
*
Auto recovery when a certain
period of time has elapsed.
10 13 3.10
Overload recovery
operation
○
○●○●
Bypass ○●○○
Fixed as bypass power supply
on overload.
Set the UPS operation after
switching to the bypass power
supply because of overload.
OFF ●○○○
*
The UPS stays off.
11 14 3.11
UPS operation at
OFF
(RESTART)
○
●●○●
Bypass ○●○○
Bypass power supply
Specify the UPS power supply
conditions when is off.
Battery voltage ●○○○
*
When low battery voltage
level is detected.
2 minutes
○●○○
When remaining battery
duration is 2 minutes.
12 15 3.12
Low battery voltage
warning timing
○
○○●●
3 minutes
●●○○
When remaining battery
duration is 3 minutes.
Set the timing of emitting the low
battery voltage warning alarm
(beep, Red BATT. LOW lit).
6 5 3.5
●○○○
*
20 15
○●○○
30 30
●●○○
40 45
○○●○
60
●○●○
90
○●●○
120
●●●○
13 16 3.13
Battery backup time
(minutes)
○
●○●●
180
○○○●
Set the UPS backup time on power outage. An external battery
must be connected for settings of 20/15 minutes or higher.
Backup time vary according to UPS model.
See §12.2 “Setup Menu List” in the E11A Instruction Manual .
5 years
●○○○
*
5 years lifetime type
10 years
○●○○
10 years lifetime type
14 17 3.14 Battery type
○
○●●●
3 years
●●○○
3 years lifetime type
Set the battery type. Set this when you
replace the battery or connect an
external battery.
180 days
●○○○
*
Test batteries every 180 days.
90 days
○●○○
Test batteries every 90 days.
30 days
●●○○
Test batteries every 30 days.
15 18 3.15
Battery test
schedule
○
●●●●
None
○○●○
No battery check.
Set the interval (number of days) for
the automatic battery check. The
check is carried out automatically
when the specified number of days
has elapsed.
Do not reset
●○○○
*
Do not reset.
16 19 3.16 Reset battery
information
●
○○○○
Reset
○●○○
Reset the battery information when you replace the battery.
● : indicates that LED is blinking.
○ : indicates that LED is off.
When you change the setting of the menus indicated by RESTART in the “Menu” column, its changes do not take effect until you
restart the UPS. If a restart is required, be sure to power off the load devices before resetting. See §11.3 “UPS Shutdown (If Not to Be
Used for More Than a Week)” in the
E11A Instruction Manual for information about how to shut down the UPS, and §11.1 “UPS
Startup” in the
E11A Instruction Manual for information about how to start the UPS.
Note
The available menus in the next page table (No.17-28) vary depending on the UPS model.
See Appendix “UPS Model name” to check your UPS Model.

3
No.
Ref.
page
Item Menu Menu LED Setting Setting
LED
Default
Setting
Current
Setting
Remarks
No delay
●○○○
*
Linked ON/OFF delay disabled
(operate with delay of 0 seconds)
17 20 3.17
Linked delay
operation
●
●○○○
Delay
○●○○
Linked ON/OFF delay enabled
(operate with specified delay)
0 seconds ●○○○ *
10 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
5 minutes ○●●○
10 minutes ●●●○
15 minutes ○○○●
18 21 3.18 Linked operation
ON delay time
●
○●○○
30 minutes ●○○●
0 seconds ●○○○ *
10 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
5 minutes ○●●○
10 minutes ●●●○
15 minutes ○○○●
19 22 3.19
Linked operation
OFF delay time
●
●●○○
30 minutes ●○○●
Set the ON/OFF delay times when
you conduct linked operation.
Delay operation is not enabled
unless item §3.17 “Enabling and
Disabling Linked Operation Delay”
is set to “Delay”.
Set when you connect
a remote switch, or
connect linked
operation cable(s) to
conduct linked
operation.
Disabled ●○○○ * Disable system control
20 23 3.20 Output line control
(Restart)
●
○○●○ Enabled ○●○○ Enable system control
0 seconds ●○○○ *
5 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
5 minutes ●○●○
21 24 3.21
Outlet box
OUTPUT1
ON delay time
●
●○●○
10 minutes ○●●○
0 seconds ●○○○ *
6 seconds ○●○○
35 seconds ●●○○
1 minute
30 seconds
○○●○
5 minutes
30 seconds
●○●○
22 25 3.22
Outlet box
OUTPUT2
ON delay time
●
○●●○
10 minutes
30 seconds
○●●○
Set the ON delay times for the
OUTPUT1 and OUTPUT2 terminals
of the outlet box.
The delay times are not enabled
unless item §3.20 “Enabling and
Disabling Output line Control” is set
to “Enabled”.
0 seconds ●○○○ *
10 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
23 26 3.23
Outlet box
OUTPUT1
OFF delay time
●
●●●○
5 minutes ○●●○
0 seconds ●○○○ *
10 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
24 27 3.24
Outlet box
OUTPUT2
OFF delay time
●
○○○●
5 minutes ○●●○
Set the OFF delay times for the
OUTPUT1 and OUTPUT2 terminals
of the outlet box.
The delay times are not enabled
unless item §3.20 “Enabling and
Disabling Output line Control” is set
to “Enabled”.
Until batteries
exhausted
●○○○ *
0 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
25 28 3.25
Outlet box
OUTPUT1 power
outage output time
●
●○○●
5 minutes ○●●○
Until batteries
exhausted
●○○○ *
0 seconds ○●○○
30 seconds ●●○○
1 minute ○○●○
3 minutes ●○●○
26 29 3.26
Outlet box
OUTPUT2 power
outage output time
●
○●○●
5 minutes ○●●○
Set the power outage output times
for the OUTPUT1 and OUTPUT2
terminals of the outlet box.
The delay times are not enabled
unless item §3.20 “Enabling and
Disabling Output line Control
”
is set
to “Enabled” and item §3.5 “Setting
PC Interface” is set to “Standalone”.
Stop power
supply
●○○○
*
27 30 3.27
Operation of Outlet
box OUTPUT0
after stopping of
OUTPUT1 and 2
●
●●○●
Continue
power supply
○●○○
Set the operation of OUTPUT0 after
output from the OUTPUT1 and 2
terminals has stopped. This setting
is not enabled unless item§3.20
“Enabling and Disabling Output line
Control” is set to “Enabled”.
Set when you connect
an outlet box to
perform output line
control.
Output
●○○○
*
Output a Ring signal when the UPS starts.
29 31 3.28 Ring signal
●
○○●●
Do not output
○●○○ Do not output a Ring signal when the UPS starts.
001, 002 Model: No.17- No.28 Menus are not available. These Menu LED blinking patterns are not displayed.
021 Model: No.17- No.27 Menus are not available. Only No.28 Menu is available.
Although Menu LED blinking patterns of No.17 - No.27 are displayed, do not change the settings of these Menus.
011, 012 Model: No.17- No.28 Menus are available.
See §12.2 “Setup Menu List” in the E11A Instruction Manual to check the available menus when using other model UPS.

4
Two beeps are heard. The setting is saved and the UPS
returns to normal o
p
eration.
§
§3 3. . O Op pe er ra at ti io on n
§
§3 3. .1 1 S Se et tt ti in ng g U UP PS S O Op pe er ra at ti io on n M Mo od de e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Check that the 5 LEDs surrounded by in the following figure are blinking as follows.
④ Quickly press several times (for no more than 3 seconds) to switch to the setting value LED
blinking pattern to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “Economy” setting is selected.
Setting Setting LED Description
Auto ● ○ ○ ○
The UPS switches automatically
between the three operating modes*
depending on the input power state.
Double
Conversion
○ ● ○ ○
The UPS operating mode is set to
Double Conversion mode.
Economy ● ● ○ ○
The UPS operating mode is set to
Economy mode.
However, operation mode might
switch to the “Double Conversion”
mode according to the condition of
the input power or the load devices.
* UPS operation mode
Economy mode: when power conditions are good, UPS supplies
its power to the load devices.
Double Conversion mode: when power conditions fluctuate,
UPS converts to the stable power, and supplies
to the load devices.
Active Filter Mode: when load power fluctuates, suppresses
high frequencies generated by the load devices
and improves power factor.
Default
setting
Set the UPS operation mode.
Select “Auto”, “
Double Conversion” or
“Economy”.
MAIN SW on the back panel set to “ON”. *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT” are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Hold for 3 or 4 sec.
until 2 beeps.
Press
Hold for 3 or 4 sec.
until 2 beeps.

5
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .2 2 S Se et tt ti in ng g O Ou ut tp pu ut t V Vo ol lt ta ag ge e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press several times (within 3 seconds) to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press several times (for no more than 3 seconds) to switch to the setting value LED
blinking pattern to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
⑥ Restart the UPS.
LEDs that blink when the “120 V” or “240V” setting is
selected.
100V Model
Setting Setting LED Description
100V
● ○ ○ ○
110V
○ ● ○ ○
115V
● ● ○ ○
120V
○ ○ ● ○
The default setting varies depending
on the UPS model. Check your UPS
model and see §12.2 “Setup Menu
List” in the
E11A Instruction Manual.
200V Model
Setting Setting LED Description
200V
● ○ ○ ○
220V
○ ● ○ ○
230V
● ● ○ ○
240V
○ ○ ● ○
208V
● ○ ● ○
The default setting varies depending
on the UPS model. Check your UPS
model and see §12.2 “Setup Menu
List” in the
E11A Instruction Manual.
The rated output voltage is the same as the rated input
voltage. Check the input voltage to select the output voltage.
Set the output voltage. Select the output
voltage according to your using environment.
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
If you change other menus, shut down the UPS after changing all
settings. Then restart the UPS. Be sure to power off the load devices
before shutting down the UPS.
Note
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Hold for 3 or 4 sec.
until 2 beeps.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.

6
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .3 3 S Se et tt ti in ng g O Ou ut tp pu ut t F Fr re eq qu ue en nc cy y S Sy yn nc c R Ra an ng ge e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
⑥ Restart the UPS.
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the output frequency variation range (%) in
economy mode and auto mode operation.
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
LEDs that blink when the “5%” setting is selected.
Setting Setting LED Description
1% ● ○ ○ ○
within ±1% of the rated input frequency
3% ○ ● ○ ○
within ±3% of the rated input frequency
5% ● ● ○ ○
within ±5% of the rated input frequency
The UPS switches to Double Conversion mode when the
frequency range is outside the setting. A smaller value provides
better precision, but increases the likelihood of switching to
Double Conversion mode if the input frequency is unstable.
Select “5%” if the UPS system is used with a device such as an
EG (Engine Generator) that has wide frequency fluctuations or
if you give priority to operation efficiency of the UPS.
Default
setting
Hold for 3 or 4 sec.
until 2 beeps.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
If you change other menus, shut down the UPS after changing all
settings. Then restart the UPS. Be sure to power off the load devices
before shutting down the UPS.
Note

7
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .4 4 S Se et tt ti in ng g B Ba at tt te er ry y P Po ow we er r S St ta ar rt tu up p F Fr re eq qu ue en nc cy y
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
⑥ Restart the UPS.
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the output frequency when starting up
the UPS by the procedures of “UPS Battery
Power Startup” in §11.1 “UPS Startup” in
the
E11A Instruction Manual .
LEDs that blink when the “60Hz” setting is selected.
Setting Setting LED Description
50 Hz ● ○ ○ ○
60 Hz ○ ● ○ ○
The default setting varies depending
on the UPS model. Check your UPS
model and see §12.2 “Setup Menu
List” in the
E11A Instruction
Manual.
Set the output frequency when starting the UPS from battery
power. Select according to the environment, or the specification
of load devices. If you select the different output frequency
from AC power frequency, after the UPS operates with battery
power, and when AC power recovers, the output frequency
switches to the same frequency as AC power.
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Hold for 3 or 4 sec.
until 2 beeps.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
If you change other menus, shut down the UPS after changing all
settings. Then restart the UPS. Be sure to power off the load devices
before shutting down the UPS.
Note

8
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .5 5 S Se et tt ti in ng g P PC C I In nt te er rf fa ac ce e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “Standalone” setting is selected.
Setting Setting LED Description
Standalone ● ○ ○ ○
Set when using the following functions
・ Standard OS UPS Services
・ UPS remote ON/OFF
Workstation ○ ● ○ ○
Set when using the following functions
・ The power management software
・ LAN Interface card
・ UPS remote ON and One-touch
system shutdown by remote switch
Serial Login ● ● ○ ○
Shutdown by serial login.
－ ○ ○ ● ○ Do not use this setting
*1. When using 001 model, do not use this setting.
Set the interface mode when using external
interface connector.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Hold for 3 or 4 sec.
until 2 beeps.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
*1

9
Two beeps are heard. The setting is saved and the UPS
returns to normal operation.
§
§3 3. .6 6 S Se et tt ti in ng g S Se er ri ia al l
B
Ba au ud d R Ra at te e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard..
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “4800” setting is selected.
Setting Setting LED Description
9600 ● ○ ○ ○ 9600 bps
4800 ○ ● ○ ○ 4800 bps
2400 ● ● ○ ○ 2400 bps
Select 9600bps when using the LAN interface card.
Set the serial baud rate when a workstation, PC,
or optional LAN Interface card is connected.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Hold for 3 or 4 sec.
until 2 beeps.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.

10
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .7 7
S
Se et tt ti in ng g U UP PS S O Op pe er ra at ti io on n U Up po on n P Po ow we er r R Re ec co ov ve er ry y
When using the supplied power management software or optional power management software, you cannot
set this menu on the control panel of the UPS. Set this menu using the power management software. Refer to
the User Guide of the power management software.
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “30%” setting is selected.
Setting Setting LED Description
Auto ● ○ ○ ○
The UPS restarts automatically when
the utility power recovers.
OFF ○ ● ○ ○
The UPS stays off when the utility power
recovers. However, when “Bypass” is
selected in §3.11, the UPS supplies the
bypass power.
30% ● ● ○ ○
The UPS restarts automatically, when
battery charge reaches 30% after the
utility power recovers.
50% ○ ○ ● ○
The UPS restarts automatically, when
battery charge reaches 50% after the
utility power recovers.
80% ● ○ ● ○
The UPS restarts automatically, when
battery charge reaches 80% after the
utility power recovers.
After changing the setting, shut down the UPS, then restart the UPS.
Be sure to power off the load devices before shutting down the UPS.
Note
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Default
setting
Specify the UPS operation when power
recovers after the UPS stops due to
final discharge of the batteries during a
power outage.
When using the power management software,
the LEDs may blink as shown in the left figure.
You cannot set on the control panel of the UPS.
Change the setting using the power management
software.
MAIN SW on the back panel set to “ON”. *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT” are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.

11
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .8 8 S Se et tt ti in ng g B Bu uz zz ze er r S So ou un nd d
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “Pattern 1” setting is selected.
Setting Setting LED Description
All
patterns
● ○ ○ ○
Emit beeps to power outage, overload,
alarm, serious failure, battery warning,
battery test, battery test result error,
and emit key click sounds.
Pattern 1 ○ ● ○ ○
Emit beeps at serious failure, battery
warning, and emit key click sounds.
Pattern 2 ● ● ○ ○
Emit beeps at alarm, and emit key click
sounds.
OFF ○ ○ ● ○
Emit key click sounds only.
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Default
setting
Select the conditions under which the UPS emits
the buzzer sound.
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.

12
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .9 9 S Se et tt ti in ng g U UP PS S S Sh hu ut td do ow wn n O Op pe er ra at ti io on n
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “3 seconds” setting is selected.
Setting Setting LED Description
1 second
● ○ ○ ○
The UPS stops when pressed for
1 second.
3 seconds
○ ● ○ ○
The UPS stops when pressed for
3 seconds.
Special
operation
● ● ○ ○
Press and hold for
approximately 3 seconds and then
release the button when the buzzer
starts beeping. Pressing for at
least 3 seconds while the buzzer is
beeping shuts down the UPS.
This setting is the function to prevent shutdown of the UPS
by an accidental operation. This setting is available for
shutdown operation only.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the shutdown operation for
switch to stop the UPS. This operation is
only valid for the shutdown operation.
The startup operation cannot be changed.
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT” are not blinking. *2
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.

13
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .1 10 0 S Se et tt ti in ng g O Ov ve er rl lo oa ad d R Re ec co ov ve er ry y O Op pe er ra at ti io on n
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “Bypass” setting is selected.
Setting Setting LED Description
Auto
return
● ○ ○ ○
The UPS returns to UPS power supply
operation automatically after a certain
time has elapsed. *1
Bypass ○ ● ○ ○
The UPS continues bypass power
supply operation when overload
condition persists. Then the UPS
switches to UPS power supply when
the overload is resolved. *2
*1. The UPS switches to UPS power supply operation every 2.5
seconds, and switches back to bypass power supply if the
overload condition still persists. This cycle is repeated.
*2. If the utility power voltage is low and the load current is
below the overload detection threshold when the UPS
switches to bypass power supply, the UPS may continue to
switch between UPS power supply and bypass power
supply.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the conditions for automatic switch back
to the UPS power supply (auto return) after
switching to the bypass power supply
because of overload.
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.

14
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .1 11 1 S Se et tt ti in ng g U UP PS S O Op pe er ra at ti io on n a at t
O
OF FF F
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
⑥ Restart the UPS.
LEDs that blink when the “Bypass” setting is selected.
Setting Setting LED Description
OFF
● ○ ○ ○
When UPS is stopping by , the
UPS stays off and the power is not
supplied.
Bypass
○ ● ○ ○
When UPS is stopping by , the
UPS supplies the bypass power.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Specify the UPS power supply conditions
when the UPS is stopped by the procedure in
§11.2 “UPS Shutdown (Daily)” in the
E11
A
Instruction Manual
.
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT” are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.
If you change other menus, shut down the UPS after changing all
settings. Then restart the UPS. Be sure to power off the load devices
before shutting down the UPS.
Note

15
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .1 12 2 S Se et tt ti in ng g L Lo ow w B Ba at tt te er ry y V Vo ol lt ta ag ge e W Wa ar rn ni in ng g T Ti im mi in ng g
When using the supplied power management software or optional power management software, you cannot
set this menu on the control panel of the UPS. Set this menu using the power management software. Refer to
the
User Guide of the power management software.
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “3 minutes” setting is selected.
Setting Setting LED Description
Battery
voltage
● ○ ○ ○
Warning is emitted (Alarm buzzer
sounds and BATT.LOW lights) when
low battery voltage level is detected.
2 minutes ○ ● ○ ○
Warning is emitted when remaining
battery duration is 2 minutes.
3 minutes ● ● ○ ○
Warning is emitted when remaining
battery duration is 3 minutes.
The buzzer does not sound when “OFF” or “Pattern 2” is selected as the
setting value in §3.8 “Setting Buzzer Sound”.
If you are using the power management software, the above setting is
disabled and the warning is emitted at the timing set for performing
UPS shutdown in the power management software.
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Default
setting
When using the power management
software, the LEDs may blink as shown
in the left figure. You cannot set on the control
panel of the UPS. Change the setting using
the power management software.
Set the timing of emitting the low
battery voltage warning.
MAIN SW on the back panel set to “ON”. *1
The “Green ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.

16
§
§3 3. .1 13 3 S Se et tt ti in ng g B Ba at tt te er ry y B Ba ac ck ku up p T Ti im me e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Perform the steps 3 to 5 in
§3.16 “Resetting Battery Information”.
LEDs that blink when the “20 min.” or “15 min. setting is selected.
Setting (minute)
UPS Model
351
751
102
152
202
302
Setting LED Description
5 6 3.5 ● ○ ○ ○
20 15 ○ ● ○ ○
30 30
● ● ○ ○
40 45 ○ ○ ● ○
60 ● ○ ● ○
90 ○ ● ● ○
120 ● ● ● ○
180 ○ ○ ○ ●
Set the UPS backup time on
power outage. Select settings
of 20/15 minutes or higher
when the external battery box
is connected. Backup time vary
according to the UPS Model.
S ee §12.2 “Setup Menu List” in
the E11A Instruction Manual.
Select the backup time according to the connected external battery box.
When the 20minutes battery box is connected, “ 20 minutes” must be
selected. Even if “40 minutes” is selected, the actual backup time cannot
be extended to 40 minutes.
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Default
setting
Set the UPS backup time when a battery box is
connected.
Proceed to §3.16 “Resetting Battery Information”
⇒ page 19
After changing the setting, perform the steps 3 to 5 in §3.16 “Resetting
Battery Information”. This setting does not take effect until the battery
information is reset. Do not perform the procedure above except in the
battery replacement.
Note
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.

17
§
§3 3. .1 14 4 S Se et tt ti in ng g B Ba at tt te er ry y T Ty yp pe e
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Perform the steps 3 to 5 in §3.16 "Resetting Battery Information”.
LEDs that blink when the “10 years” setting is selected.
Setting Setting LED Description
5 years
● ○ ○ ○
5 years lifetime type
10 years
○ ● ○ ○
10 years lifetime type
3 years
● ● ○ ○
3 years lifetime type
Select the battery type according to the type of the mounted
battery. When the 5 years lifetime type battery is mounted, “5
years” must be selected. Even if “10 years” is selected, the
actual battery service life cannot be extended to 10 years.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the battery type. Set this when you replace
the battery or connect an external battery.
Proceed to §3.16 “Resetting Battery Information” ⇒ page 19
After changing the setting, perform the steps 3 to 5 in §3.16 “Resetting
Battery Information”. This setting does not take effect until the battery
information is reset. Do not perform the procedure above except in the
battery replacement.
Note
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.

18
Two beeps are heard. The setting is saved and the UPS returns
to normal operation.
§
§3 3. .1 15 5 S Se et tt ti in ng g B Ba at tt te er ry y T Te es st t S Sc ch he ed du ul le e
When using the supplied power management software or optional power management software, you cannot
set this menu on the control panel of the UPS. Set this menu using the power management software. Refer to
the User Guide of the power management software.
① Check that the UPS is in the following condition.
② Press and hold for 3 or 4 seconds. Then release it when two beeps are heard.
③ Quickly press (within 3 seconds) several times to set the 5 LEDs surrounded by in the figure
below to a blinking pattern such as the one in the figure.
④ Quickly press (within 3 seconds) several times to switch to the setting value LED blinking pattern
to select for the 4 LEDs surrounded by in the figure below.
⑤ Press and hold for 3 or 4 seconds.
Then release it when two beeps are heard.
LEDs that blink when the “90 days” setting is selected.
Setting Setting LED Description
180 days ● ○ ○ ○
Check batteries every 180 days.
90 days ○ ● ○ ○
Check batteries every 90 days.
30 days ● ● ○ ○
Check batteries every 30 days.
None ○ ○ ● ○
No battery check.
Default
setting
The blinking pattern changes each time you press or .
If you miss the LED blinking pattern you want to select, continue pressing
the button repeatedly until the LED blinking pattern is redisplayed.
Tip
Set the interval (number of days) for the automatic
battery test. The test is carried out automatically
when the specified number of days has elapsed.
MAIN SW on the back panel set to “ON” *1
The “Green INV.ON/STAND BY” and
the “Green OUTPUT are not blinking. *2
*1. Operation is possible regardless of whether
is ON or OFF.
*2. If these LEDs are blinking, Forced Bypass switch
may be set to “Bypass”. Set this switch to “Inverter”,
and restart the UPS.
Tip
The UPS switches to the user setting mode.
Buzzer sounds : 2 beeps
： Either BATT.LOW or 25 blinks,
or both
BATT.LOW and 25 blink.
： INPUT blinks.
：
LED is off.
：
LED is blinking.
Press
Press
Hold for 3 or 4 sec.
until 2 beeps.
Hold for 3 or 4 sec.
until 2 beeps.
