INSTRUCTION MANUAL
DVR Utility Software VA-SW814
VA-SW81LITE
    " #$%&'

English 1
CONTENTS
DVR UTILITY SOFTWARE FEATURES . . . . . . . . . . . 2
SOFTWARE VERSION . . . . . . . . . . . . . . . . . . . . . . . . 2
NETWORK CONFIGURATION . . . . . . . . . . . . . . . . . . 3
SYSTEM REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . 5
TCP/IP SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
INSTALLING THE SOFTWARE. . . . . . . . . . . . . . . . . . 7
LOGGING IN/LOGGING OFF/DISPLAY LANGUAGE
SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
■User Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
■Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
■Logging Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
■Display Language Setting . . . . . . . . . . . . . . . . 11
■Display While Communication is in
Progress . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
BASIC WINDOW FLOWCHART . . . . . . . . . . . . . . . . 12
FUNCTIONS OF EACH MAIN WINDOW
(MONITORING, RECORDING AND PLAYBACK
WINDOW) COMPONENT. . . . . . . . . . . . . . . . . . . . . . 13
BASIC NETWORK SETTINGS . . . . . . . . . . . . . . . . . 16
OPERATION OF SETTING BUTTONS . . . . . . . . . . . 19
INITIAL SETUP (SETUP WINDOW) . . . . . . . . . . . . . 20
■SYSTEM SETUP tab . . . . . . . . . . . . . . . . . . . . . 20
■REGISTER DVR tab . . . . . . . . . . . . . . . . . . . . . 22
■ADVANCED SETUP tab . . . . . . . . . . . . . . . . . . 29
■USER ID tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
CLOCK AND SYSTEM UPDATE SETTINGS . . . . . . 34
■CLOCK SET tab . . . . . . . . . . . . . . . . . . . . . . . . 34
■SYSTEM UPDATE tab. . . . . . . . . . . . . . . . . . . . 35
■INFORMATION1 tab . . . . . . . . . . . . . . . . . . . . . 36
■INFORMATION2 tab . . . . . . . . . . . . . . . . . . . . . 38
MENU SETTINGS (MENU WINDOW) . . . . . . . . . . . . 39
■LANGUAGE/D.S.TIME SET tab . . . . . . . . . . . . 39
■REC MODE SET tab . . . . . . . . . . . . . . . . . . . . . 41
■TIMER REC SET tab . . . . . . . . . . . . . . . . . . . . . 44
■HOLIDAY SET tab . . . . . . . . . . . . . . . . . . . . . . . 46
■DISPLAY/BUZZER SET tab . . . . . . . . . . . . . . . 47
■MONITOR SET tab . . . . . . . . . . . . . . . . . . . . . . 49
■TITLE/MOTION SET tab . . . . . . . . . . . . . . . . . . 51
BROADCAST TRANSMISSION SETTINGS
(BROADCAST WINDOW) . . . . . . . . . . . . . . . . . . . . . 52
IMAGE DISPLAY WINDOWS . . . . . . . . . . . . . . . . . . 54
■Display Screen Type . . . . . . . . . . . . . . . . . . . . 54
■Switching Display Windows . . . . . . . . . . . . . . 55
■Sequence Display Function. . . . . . . . . . . . . . . 57
■Title Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
■Zoom Function . . . . . . . . . . . . . . . . . . . . . . . . . 59
■Full Screen Function . . . . . . . . . . . . . . . . . . . . 60
MONITORING LIVE IMAGES . . . . . . . . . . . . . . . . . . 61
■Monitoring in a QUAD/SINGLE Screen. . . . . . 61
■Monitoring with MULTI Screens . . . . . . . . . . . 62
■Disconnecting DVRs . . . . . . . . . . . . . . . . . . . . 63
■Image Audio Output . . . . . . . . . . . . . . . . . . . . . 63
RECORDING IMAGES. . . . . . . . . . . . . . . . . . . . . . . . 64
■Normal Recording . . . . . . . . . . . . . . . . . . . . . . 64
■Timer Recording . . . . . . . . . . . . . . . . . . . . . . . . 66
■Alarm Recording. . . . . . . . . . . . . . . . . . . . . . . . 67
PLAYING BACK RECORDED IMAGES . . . . . . . . . . 68
■Playing Back Recorded Images . . . . . . . . . . . 68
■Functions of Each Playback Control Panel
Component . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
SEARCHING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
■Time/Date Search . . . . . . . . . . . . . . . . . . . . . . . 70
■Alarm Search . . . . . . . . . . . . . . . . . . . . . . . . . . 71
■Alarm Thumbnail Search . . . . . . . . . . . . . . . . . 73
SAVING STILL IMAGES . . . . . . . . . . . . . . . . . . . . . . 74
DOWNLOAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
■Specifying the Image Range . . . . . . . . . . . . . . 75
■Functions of Each Download
Window Element. . . . . . . . . . . . . . . . . . . . . . . . 76
■Basic Downloading Operations
(Individual Download) . . . . . . . . . . . . . . . . . . . 78
■Preset List Operations
(Batch Downloads) . . . . . . . . . . . . . . . . . . . . . . 80
TIMER DOWNLOAD . . . . . . . . . . . . . . . . . . . . . . . . . 81
TAMPER DETECTION. . . . . . . . . . . . . . . . . . . . . . . . 89
MP2 Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
■Main Functions . . . . . . . . . . . . . . . . . . . . . . . . . 90
■Operating Environment . . . . . . . . . . . . . . . . . . 90
■Installation/Saving Location . . . . . . . . . . . . . . 90
■Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
■Window Structure and Functions of
Each Part. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
■Opening (Playing) Files . . . . . . . . . . . . . . . . . . 93
■Saves a Still Image . . . . . . . . . . . . . . . . . . . . . . 97
■Prints Still Images . . . . . . . . . . . . . . . . . . . . . . 97
■Searches for Images . . . . . . . . . . . . . . . . . . . . 98
■Detecting Tampering of Images . . . . . . . . . . . 98
    " #$%&'

2English
DVR UTILITY SOFTWARE FEATURES
This software is a remote monitoring system for digital video recorders (DVR) and computer terminals
that are connected via a network. It includes an extensive range of functions that are designed to make
optimal use of the latest in technology and network features. It can cater to a wide variety of monitoring
needs including ease of operation and system expandability.
●You can build a computerized monitoring network system simply by installing this software
into a computer.
●Up to eight computers can be connected to control up to a maximum of 4000 DVRs in a
single network.
●Menu settings and recording and playback operations are just a few of the DVR operations
that can be controlled across the network by a computer.
●Recording parameters can be set individually for each DVR.
●DVR image monitoring can be switched between a single screen and 4-screen multi screens.
If a 4-channel DVR is connected, images for a maximum of 16 channels can be viewed at
once in a single screen.
●The system is provided with complete security features. Users that have access to the
system are verified by means of a user ID and password, and four different user levels (ID1 to
ID4) are available, with different operating privileges for each level.
SOFTWARE VERSION
Two versions of this software application are available. The descriptions given in this manual apply to
both versions.
VA-SW814 VA-SW81LITE
Sold separately
Standard version with full functionality
Included with this unit (DSR-M800PA/
DSR-M810P/DSR-M804/DSR-M804P/
DSR-M814/DSR-M814P)
Lite version with limited functions
Accessories: Hardware key (USB type) Accessories: None
In order to activate all of the functions of this software, you will need to connect the
hardware key to the USB port. If the hardware key is not connected, the functionality
of the software will be limited. (P.10)
 (   " #$%&'

English 3
NETWORK CONFIGURATION
This system consists of DVRs, monitoring cameras and computer terminals that are used for remote
monitoring. All devices in the system are connected through a dedicated local area network (LAN).
●Applicable models:
DSR-M800/DSR-M800P/DSR-M800PA/DSR-M804/DSR-M804P/DSR-M810/DSR-M810P/
DSR-M814/DSR-M814P
See “http://www.sanyosecurity.com” for models other than the above.
Network configurations can include a combination of different models.
●Number of DVR connections:
Standard 1000 DVRs (Up to 4000 DVRs can be connected depending on the subnet mask
values.)
●Number of computer terminal connections:
Max. 8 computers (1 master computer + 7 slave computers)
●Applicable software:
If using this software (VA-SW814 or VA-SW81LITE) on the master computer, then the slave
computers must also be running the same version of software. Older versions of the software
(VA-SW800/804/814 Ver. 1.0/80LITE) cannot be used with this software.
Slave computers that are running older versions of the software should be upgraded
by installing this software. Once the software upgrade has been carried out, you can
continue to use the same accessory hardware key as before. (P.8)
DVR1 DVR2 DVR3 DVR4
Master computer
Slave computer
Switching Hub
Switching Hub
 )   " #$%&'

4English
NETWORK CONFIGURATION
●Examples of IP address setting ranges:
(When using automatic setting mode and the subnet mask is set to the standard 255.255.252.0)
Computer terminals: DVRs:
192.168.0.251 –254
192.168.1.251 –254
192.168.2.251 –254
192.168.3.251 –254
192.168.0.1 –250
192.168.1.1 –250
192.168.2.1 –250
192.168.3.1 –250
Distinction between “Master” and “Slave”
A master computer is a computer terminal that has operating privileges available for
registering and deleting DVRs that are connected to the network. The default setting is for one
master computer. In contrast, general computer terminals that do not have operating
privileges for registering and deleting DVRs are called slave computers, and a maximum of
seven of them can be connected. (P.20)
•When using the software on a network, carry out the required network settings at the DVRs first.
IP addresses will be assigned automatically, but the “DVR NAME” and “GROUP” settings can
also be changed manually using a computer. (P.22)
•You should make sure that the TCP/IP settings for the operating system (OS) that you are using
match the computers that are connected to the network. (P.6)
•Connect the devices to an independent stand-alone network. Furthermore, check with the
network administrator to make sure that the IP addresses that you set do not conflict with IP
addresses that are already in use by the network.
    " #$%&'

English 5
SYSTEM REQUIREMENTS
The following environment is required for the operation of this system.
*1 If using at a resolution of 1024x768, you will need to select “Auto-hide the taskbar”in the Taskbar Properties menu.
*2 Latest driver with 100% DirectX 9.0b compatibility is required.
*3 If no sound card is available, monitoring of DVR images and audio playback will not be possible when [AUDIO
RECORDING] is set to [ON].
Windows®is a trademark, or registered trademark of Microsoft Corporation in the United States and/or other countries.
Pentium®is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other
countries.
Recommended Single Monitoring
System IBM PC/AT or Compatible
CPU Pentium 4, 3GHz or faster Pentium III 800MHz
Memory 256MB
Interface 100Base TX, USB (1.1)
Display XGA (1024 ×768 pixel), 16-million color or greater*1
AGP graphics card for hardware overlay*2
Sound Sound card that supports 48 kHz stereo playback (PCI connection recommended)*3
OS Windows®XP Professional
Recommended graphics chip
ATI RADEON9000 series or later
nVidia GeForce4 series or later
Quadro4 series or later
Matrox MillenniumP series or later
•If the firewall function of Windows XP or some other firewall software is active, communication
between the computer and the DVRs will be interrupted and the system will not operate
normally. Be sure to turn off any firewall settings when using this software.
Furthermore, the firewall function is
activated as a standard feature for Windows
XP SP2. When this software is run for the
first time, a firewall setting confirmation
window will be displayed. Select [Unblock]
so that communications can be received
from the DVRs.
•If monitoring images that are distorted because of reasons such as an unstable sync signal, the
display may not appear normally even if the PC meets the above specifications.
 *   " #$%&'

6English
TCP/IP SETTINGS
When using the software on a network, you should first change the TCP/IP settings as required in
accordance with the operating systems (OS) of the various computers that on the network that are to be
used. (Operation is only guaranteed under Windows XP Professional.)
1Click the Network Connections icon in
the Control Panel.
The “Network and Internet Connections”
window will be displayed.
2Click “Local Area Connections”.
The “Network Connections”window will be
displayed, and the settings for the LAN card
(Ethernet adapter) being used will appear in
the “LAN or High-Speed Internet”column.
3Right-click on the LAN card (Ethernet
adapter) being used, and then select
“Properties (R)”from the pop-up menu.
The “General”tab window in the “Local Area
Connection Properties”window will be
displayed.
4Check that “Internet Protocol (TCP/IP)”
is selected in the list of components
used by the Ethernet board that appears
in the “This connection uses the
following items: (O)”box.
If “Internet Protocol (TCP/IP)”is not
selected, select it.
5Click [Properties (R)].
The “General”tab window in the “Internet
Protocol (TCP/IP) Properties”window will
be displayed.
6Select “Use the following IP address:”
and then type in the IP address and the
subnet mask.
For standard settings, enter a subnet mask
of “255.255.252.0”as shown in the example
illustration.
7Check the settings, and then click [OK].
The display will return to the “Local Area
Connection Properties”window.
8Click [OK].
This completes the TCP/IP settings.
If you connect any LAN cables or change the TCP/IP settings while this software is
running, communication errors may occur. If you make any such changes after
installing the software, make them while the software is not running.
 +   " #$%&'

English 7
INSTALLING THE SOFTWARE
Install the DVR Utility Software to the computer that is connected to the network. The following
procedure will install the hardware key driver and the MP2 Viewer at the same time.
1Insert the DVR Utility Software CD into
the CD-ROM drive of the computer.
The “Welcome”window appears.
2Click [Next] in the “Welcome”window.
3Click [Yes] in the “License Agreement”
window.
The License Agreement will be displayed.
Be sure to check the terms of the License
Agreement carefully.
4Click [Next] in the “Choose Destination
Location”window.
Normally you should accept the default
location without changing it. If you would
like to change the destination folder for
installing the software, type the path to the
folder directly into the box, or click [Browse]
and select the folder to be used for the
installation.
5Click [Next] in the “Select Program
Folder”window.
This lets you check the program folder
where the program icon will be added.
Normally you should accept the default
folder without changing it. If you would like
to change the program folder, type the
folder name into the box, or select an
existing folder from the list underneath.
 ,   " #$%&'

8English
INSTALLING THE SOFTWARE
6Installation will begin.
Installation of the software will begin, and a
progress bar showing the installation
progress will appear in the “Setup Status”
window.
7Restart the computer.
Click [Finish] in the “InstallShield Wizard
Complete”window to restart the computer
automatically. Once the computer has
restarted, installation is then complete.
8Shortcut icon display
After restarting the computer, a shortcut
icon for the software will appear on the
desktop. Double-click the icon to start the
software.
●Version Updates
When updating the DVR Utility Software
from version VA-SW800/804 to
VA-SW814, you can follow the procedure
given below to reuse the DVR registration
list that was created by the VA-SW800/
804 version.
1Uninstall version VA-SW800/804.
2Install version VA-SW814.
3Display the “SETUP”window, and
open the “REGISTER DVR”tab.
4With the computer connected to the
LAN, select “MANUAL”for “TCP/IP
ADDR.”.
5Click [CREATE LIST].
After a brief period, the DVR
registration list that was created by the
VA-SW800/804 version will be
regenerated and displayed.
6Click [OK].
The list details will be stored on the
computer and applied to the DVRs.
Refer to “INITIAL SETUP (SETUP
WINDOW)”(P.20 –25) for further details
on these operations.
    " #$%&'

English 9
LOGGING IN/LOGGING OFF/DISPLAY
LANGUAGE SETTING
The user level for each user on the network can be set to one of four levels. The user level is verified by
means of the user name and password that are entered when the user logs in.
■User Level
Different operating privileges are set for each user level. The range of operations that are permitted to
be carried out by users depends on their user level. Set the user levels in accordance with the operating
environment.
* VA-SW81LITE has restricted operation for some functions.
Operations marked with Çare limited to the master computer.
Operation limit levels in brackets can be set using the SYSTEM SETUP tab in the “SETUP”window. (P.21)
User Level ID1 ID2 ID3 ID4
Username (Default setting) ID1 ID2 ID3 ID4
Password (Default setting) 1111 2222 3333 4444
Monitoring live images DVR selection, volume adjustment, etc. mmmm
Playback operations mmm
Search operations Time/date search mmm
Alarm search mmm
Alarm thumbnail search mmm
Saving operations Saving still images mmm
Download (m)(m)m
Timer download * (m)(m)m
Recording operations Normal recording mm
Timer recording mm
Initial settings Language, TV system, master computer,
download operation limit, automatic clock
adjustment and sequence interval settings m
Registering and deleting DVRs Ç
Network connection expansion m
User registration, changing and deletion m
Clock and system
update settings Clock settings m
Firmware updates m
System-related information display m
Menu settings DVR monitor language, daylight saving
time, external clock and remote operation
condition settings m
Recording condition setting m
Timer recording m
Holiday settings m
Display information and warning buzzer
settings m
Monitoring window settings m
Motion sensor and camera title settings m
Broadcast transmission
settings * Normal recording, timer recording mm
Menu upload, clock set, system update m
Tamper detection * Checking for image tampering mmm
    " #$%&'

10 English
LOGGING IN/LOGGING OFF/DISPLAY LANGUAGE SETTING
■Logging In
1Hardware key installation
Insert the accessory hardware key into the USB
port of the computer.
If the hardware key is not installed, the software
will operate as the Lite version, and some
functions will be disabled. (P.9, 12)
2Serial No. input
When the software is run for the first time after
installation, the serial number input dialog box will
be displayed. Type in the specified serial number.
If the hardware key is installed, the serial number
dialog box will not be displayed again the next
time the software is run.
However, the serial number must be typed in at
the following times.
•When the hardware key is not installed
•When running VA-SW81LITE (limited function
version)
3Authentication check
When the software is run, the window for entering
the user name and the password will be displayed.
When logging in, type your user name into the
“USER NAME”box and type the password for
verification into the “PASSWORD”box. Then click
[OK] or press the [ENTER] key.
If the number entered does not satisfy the checksum conditions, the input dialog box will be
displayed again. If an incorrect serial number is typed in three times in succession,
“AUTHENTICATION ERROR”will be displayed and the only available operation will be to exit (log
off).
The serial No. is listed on the label that is affixed to the case of the CD-ROM disk.
•The first time the master computer is started up, log in by entering the initial settings for user
level ID4 (username: ID4/password: 4444). (P. 9)
•If the password typed in is incorrect, the window for entering the user name and the password
will be displayed again and you will need to type the password in once more. In addition, if you
click a button to use an operation that is not permitted by the user level that you have logged in
at, the window for entering the user name and the password will be displayed again and you will
be required to type in the user name and password corresponding to the user level for that
operation.
 -   " #$%&'

English 11
LOGGING IN/LOGGING OFF/DISPLAY LANGUAGE SETTING
■Logging Off
Click on the toolbar to close the connection.
Make sure that you carry out this disconnect operation when exiting the software and closing the
program window.
■Display Language Setting
This software uses English as its default display language. However, you can use the SYSTEM SETUP
tab in the “SETUP”window to set the display language to any one of the following five languages. (P.20)
When using the software, first change the display
language setting to the required language.
Available languages:
English, French, Spanish, German, Chinese
After you have changed the setting, restart the
application. The displays will then appear in the newly
selected language.
■Display While Communication is in Progress
When a screen operation has been carried out that
requires the system to wait for a response from the
DVR, the following message box will be displayed and
the green indicator will flash.
The message box will disappear once communication
is complete (or a communication error or other error) is
generated.
To display text in Chinese, select “Install files
for East Asian languages”in “Regional and
Language Options”in the Control Panel.
    " #$%&'

12 English
BASIC WINDOW FLOWCHART
When the software is started and a user has logged in, the main window for live image monitoring and
recording/playback is displayed. The software lets you display a variety of operating windows and
setting windows starting from the main window, as shown in the flowchart diagram below.
B
(P. 17)
CLOCK & SYSTEM window
MENU window
INDIVIDUAL CAMERA window
(DSR-M804/M814 only)
QUAD/SINGLE window
ALARM SEARCH window
BROADCAST window
TIMER DOWNLOAD window
SETUP window
Download window
C
(P. 18)
A
(P. 16)
TAMPER DETECTION window
MULTI window
SEQUENCE window
(DSR-M804/M814 only)
Click to exit the
software and
close the program
window
✱
✱
✱
✱
If the hardware key is not
installed, control buttons
marked with ✱will not be
displayed.
The sample windows shown in this instruction manual
are all examples of windows that appear when using a
4-channel type DVR (DSR-M804/M814).
 (   " #$%&'

English 13
FUNCTIONS OF EACH MAIN WINDOW (MONITORING,
RECORDING AND PLAYBACK WINDOW) COMPONENT
The main window is the initial window that is displayed the first time the software is run. This is the basic
window for carrying out live image monitoring and recording and playback operations, and it can also be
used as the starting place for displaying other setting windows. The toolbar that appears at the top of
the window appears in the same way for all windows, except when the login window is displayed at
startup.
1Toolbar
This lets you use basic functions and open
different setting windows with a single click.
Click the required icon to use a function or
window.
●CLOCK & SYSTEM (P.17, 34)
This displays the “CLOCK & SYSTEM”
window.
Used for clock setting, firmware updating and
checking system-related information.
●MENU (P.18, 39)
This displays the “MENU”window.
This window is used to carry out menu
settings such as setting recording
parameters.
●INDIVIDUAL CAMERA (P.54)
If the DVR is a DSR-M804/M814 (4-channel
type), images from the specified camera are
displayed in a single screen.
●QUAD/SINGLE (P.54)
This is the initial screen that is displayed after
the software is started. Images from all
channels from the specified DVR are
displayed in a single screen. The screen
configuration changes depending on the type
of DVR.
DSR-M804/M814 (4-channel type): Quad
screen
DSR-M800/M810 (1-channel type): Single
screen
2 3
H
J
I
1
54
6
8
F
G
K
7
9
 )   " #$%&'

14 English
FUNCTIONS OF EACH MAIN WINDOW (MONITORING, RECORDING AND
PLAYBACK WINDOW) COMPONENT
●SEQUENCE (P.57)
If the DVR is a DSR-M804/M814 (4-channel
type), all images from the specified camera
are displayed in sequence with automatic
switching.
●MULTI (P.54)
Images from a maximum of four DVRs are
allocated to windows in a 4-screen split
screen, so that images from all connected
cameras are displayed in a single multi
screen. If all of the DVRs are DSR-M804/
M814 models (4-channel type), 16 screens
are displayed.
●ALARM SEARCH (P.71)
This displays the “ALARM SEARCH”or
“ALARM THUMBNAIL SEARCH”window.
This window is used to search for alarm
recordings.
●BROADCAST (P.52)
This displays the “BROADCAST”window.
This window is used for issuing batches of
basic commands such as commands to start
or stop recording to the DVRs that are
connected to the system.
●TIMER DOWNLOAD (P.81)
This displays the “TIMER DOWNLOAD”
window.
Timer reservations can be made for
downloading recorded images.
●TAMPER DETECTION (P.89)
This displays the “TAMPER DETECTION”
window.
This window lets you determine if any
tampering has been carried out on recorded
images.
●SETUP (P.16, 20)
This displays the “SETUP”window.
This window is used to make initial
program settings after the software has
been installed.
2EXIT
Click to exit the software and close the
program window.
3Date and time display
This shows the date and time set by the
computer’s internal clock.
The timer download status is displayed
underneath the date and time. (P.84)
4Message display window
Results for details such as error and alarm
status and setting operations are displayed in
sequential messages.
<DVR registration name, date and time of
occurrence, details of occurrence>
Display example:
DVR-3 11-05-04 15:45:40 LIVE ERROR
BROADCAST 11-05-04 15:50:20 DONE
•The only error messages that are
displayed are system errors such as
communication errors.
•When the software is exited, the
information is discarded from the
display, but it can still be found in the
log file that is saved in the log file
sub-folder of the folder that the software
has been installed into.
(C:\ProgramFiles\SANYO\VA-SW814\log)
    " #$%&'

English 15
FUNCTIONS OF EACH MAIN WINDOW (MONITORING, RECORDING AND
PLAYBACK WINDOW) COMPONENT
5Playback control panel (P.69)
This is used when playing back recorded
images.
6Recording control panel (P.64 –66)
Use when manually recording the monitored
images.
7Disconnect DVR (P.63)
This breaks the connection to a DVR.
8Zoom (P.59)
This enlarges or reduces live or playback
images centering on a specified point in the
screen.
9Full screen (P.60)
This hides the toolbar and control panel so
they do not appear on the screen, and
displays the current image so that it fills the
whole of the screen area.
FSaving control panel (P.74, 75)
Saves still images and downloads recorded
images.
GAudio adjustment panel (P.63)
Audio output items such as volume, channel
selection and muting can be adjusted for both
live and recorded images.
HTime/date search (P.70)
This lets you play back recorded images by
specifying the date and time that they were
recorded.
IBrowse
Click this button to specify files that are saved
on a computer drive. Folders and files can be
viewed in a list, and you can specify a file by
typing its filename into the window.
The only types of file that can be viewed are
files in MP2 format that have been
downloaded from a DSR-M800/M804/M810/
M814 series. Files that have been saved in
JPEG format cannot be viewed.
JTARGET
The DVR names and attribute group names
that are recorded by the computer are
displayed in a tree list in the window. Menu
settings and monitoring, recording and
playback operations can be carried out by
clicking a DVR name in the list to specify a
DVR.
If you click the “+”symbol at the left of a
group, the DVRs that have been registered
in the group will be displayed, and the “+”
will change to a “–”. If you click the “–”
symbol, the list of DVRs will disappear and
the symbol will change back to a “+”.
KTitle bar (P.58)
Image information is displayed on the bar in a
two-level structure for DVRs and for cameras.
When a multi screen is displayed, a window
can be selected by clicking on its title bar.
 *   " #$%&'

16 English
BASIC NETWORK SETTINGS (User Level: ID4)
In order to use a computer to control DVRs that are on the network, you first need to set some basic
network-related system conditions. Click the icons on the toolbar in the main window to display the
respective setting windows, click on the tab indexes to specify a particular setting menu, and use these
setting menus to make the settings.
■Initial Setup: SETUP Window (P.20)
This window contains the following four tabs. They are
used to carry out initial settings relating to the network
configuration and the system environment.
1SYSTEM SETUP tab
•Display language setting
•Setting the TV format (NTSC/PAL) in accordance
with the input signals
•Setting the master computer address
•Download operation limit level setting
•Setting the automatic adjustment function for DVR
clocks
•Sequence screen switching interval setting
2REGISTER DVR tab
(Operation only possible at master computer)
The options in this tab let you add and remove DVRs on
the network from the DVR registration list. In addition, it
can be used to list the properties of each registered
DVR.
3ADVANCED SETUP tab
This lets you expand the network so that 1001 or more
DVRs can be connected to the same network.
4USER ID tab
This is used to register, change and delete users that
can log into the system.
A
1SYSTEM SETUP tab
2REGISTER DVR tab
3ADVANCED SETUP tab
4USER ID tab
 +   " #$%&'

English 17
BASIC NETWORK SETTINGS (User Level: ID4)
■Clock Settings and System Updates:
CLOCK & SYSTEM Window (P.34)
This consists of the following four types of tabs which can
be used for operations such as setting the clock, updating
the firmware and displaying system information.
1CLOCK SET tab
This is used to set the current time for selected DVRs.
2SYSTEM UPDATE tab
This is used to update the firmware for selected DVRs.
3INFORMATION1 tab
This is used to display DVR setting information and
information about the hard disk, and is also used for
hard disk initialization.
4INFORMATION2 tab
This shows information such as the DVR usage time,
power outages and the firmware version.
•With the DSR-M810/M814, the recording start and
stop times are also displayed.
•With the DSR-M800, the firmware version is not
displayed.
B
1CLOCK SET tab
2SYSTEM UPDATE tab
3INFORMATION1 tab
4INFORMATION2 tab
 ,   " #$%&'

18

C
1LANGUAGE/
D.S.TIME SET tab
2REC MODE SET tab
3TIMER REC SET tab
4HOLIDAY SET tab
5DISPLAY/BUZZER SET tab
6MONITOR SET tab7TITLE/MOTION SET tab
BASIC NETWORK SETTINGS (User Level: ID4)
■Menu Settings: MENU Window (P.39)
This window contains the following seven tabs. They are used to
carry out operations such as setting recording conditions and setup
environments for selected DVRs.
If you specify a DVR and then click in the “MENU”
window, or if you double-click the name of a DVR and carry out the
selection operations given in the dialogue box, the information for
the selected DVR will be loaded and the window will become active.
1LANGUAGE/D.S.TIME SET tab
This is used to make settings such as the display language for
the monitor connected to the DVR, daylight saving settings, and
also lets you adjust the time for connected peripheral devices.
(With the DSR-M810, the “REMOTE SET”settings can also be
carried out.)
2REC MODE SET tab
This is used to set the recording conditions for DVRs.
3TIMER REC SET tab
This is used to set timer recording conditions for DVRs.
4HOLIDAY SET tab
This is used to set holiday settings.
5DISPLAY/BUZZER SET tab
This is used to set the display information for the monitor
connected to the DVR, and also lets you make warning buzzer
settings.
6MONITOR SET tab (DSR-M804/M814 only)
This is used for monitor window settings at the DVR.
7TITLE/MOTION SET tab (DSR-M804/M814 only)
This sets the motion sensor and camera title settings for each
DVR channel.
    " #$%&'

English 19
OPERATION OF SETTING BUTTONS
The following operation buttons are displayed in the various setting windows such as the initial setting
and menu setting windows. The basic functions of each button are the same for each window.
Button Button function and related operations
Table setting Tab input data is saved, but it is not sent to the DVR.
•When a button is clicked, the setting data is checked, and if an
error is found, an error message is displayed.
•If the data has been saved correctly, the tab index changes to
yellow and a message will be displayed saying that the unit is
ready to upload to the DVR. (Menu setting)
Cancels input and setting data.
•If [APPLY] has not been clicked yet, the input data will be
canceled.
•If [APPLY] has already been clicked, the original setting values
can be restored by clicking the [CANCEL] button and then using
[IMPORT] or [OPEN] to load the original data.
•If an [IMPORT] or [OPEN] operation has not yet been carried
out, the values in the displayed tab will be returned to the
default settings.
•If the tab index has changed to yellow, use the [CANCEL]
operation to return it to the normal color. (Menu setting)
Saving and
loading
This loads the current menu data from the selected DVR.
•Menu data can also be loaded by double-clicking the DVR
name in the “TARGET”window.
•If the tab index has changed to yellow, use the [IMPORT]
operation to return it to the normal color.
This loads the data that has been saved in the setting file on the
computer’s hard disk.
This uploads the setting data to a DVR.
•For menu settings, the data that will be uploaded is the data for
tabs with indexes that are displayed in yellow.
•After the data is uploaded, the tab indexes will return to their
normal color.
Saves the data being edited onto the hard disk of the computer.
•The “Save as”dialog box will be displayed. Specify the
destination folder and filename and then click [SAVE].
•
File format: DSR-M800, M804, M810, M814 Series Setup File (*.hbc)
•If carrying out a menu upload from the “BROADCAST”window,
save the menu data first.
Clears a DVR or user registration (only displayed for the
REGISTER DVR tab/USER ID tab).
    " #$%&'
