DSR-M800P
FILE NO.
REFERENCE No.SM5310488
L8HAC/XE, UK, UK2
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
(Product Code : 175 810 57)
(Europe)
SERVICE MANUAL
Digital Video Recorder
CONTENTS
NOTES ON HANDLING INTERNAL HARD DISK DRIVE
COMPONENTS ........................................................................ 3
SPECIFICATIONS .................................................................... 4
1. DISASSEMBLY .................................................................... 5
2. RESETTING THE USE TIME ............................................... 5
3. ADJUSTMENT ...................................................................... 6
4. PARTS LIST.......................................................................... 7
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS...........C1
ALARM
REC/STOP
LOCK/REMOTE
USB
POWER
SEARCH
MENU RESET
MENU REVIEW CUE
EXIT/OSD
PLAY/
STOP
STILL
TIMER
FULL
LAN
(LINK/ACT.)
DSR-M800P
(Product Code : 175 810 77)
(U.K.)
DSR-M800P
(Product Code : 175 810 78)
(U.K.)
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
PRODUCT SAFETY NOTICE

−2 −

−3 −
1. Do not subject the unit to shocks or vibration.
If the unit is subjected to shocks or vibration, it may
damage the HDD or cause corruption of the data stored in
the HDD.
• Do not move the unit while the power is turned on.
Always be sure to turn off the power before removing the
unit from or placing it onto the rack.
• When transporting the unit, pack it securely using the
specified packing materials. In addition, use a method of
transportation that minimizes vibration.
• When placing the unit down on a surface such as a floor,
attach the specified feet to the base of the unit and place
it down gently. If the feet are not attached, place the unit
down very carefully so that it does not make any noise.
2. Do not move the unit for 30 seconds after turning
off the power.
After the power is turned off, the disk inside the HDD will
continue to spin for a brief period due to inertia, and the
heads will be in an unstable state.
During this time, the unit is even more susceptible to
shocks and vibration than when power is being supplied.
Make sure that the unit is not subjected to even gentle
vibration for at least 30 seconds after turning off the
power.
3. Do not operate the unit when condensation has
formed.
If the unit is operated when condensation has formed, it
may cause operating problems.
If sudden changes in the ambient temperature occur, wait
for the temperature to stabilize before operating the unit.
Notes on handling internal hard disk drive components
This unit has a built-in hard disk drive (HDD).
Be sure to observe the following points carefully when operating, setting-up and servicing the unit.
4. Notes when replacing the HDD
Be sure to follow the correct replacement procedure when
replacing the HDD.
• HDDs that have been removed from their packaging may
not operate correctly if they are subjected to any shocks
or vibration. It is recommended that you place the HDD
onto a soft, level surface with the printed circuit board
facing upward after unpacking it.
• Be careful not to subject the HDD to shocks or vibration
when removing and tightening screws as part of the HDD
replacement procedure. Make sure that all screws are
tightened securely so that they will not become loose.
• The HDD is sensitive to static electricity, so you should
take proper precautions to prevent static electricity
buildup.
5. Handling the HDD unit by itself
If transporting or storing the HDD unit by itself, always be
sure to pack it in the specified packaging first.
In addition, use a method of transportation that minimizes
vibration.
If the HDD becomes damaged, handle the unit and the
damaged HDD that has been removed in order for it to be
replaced carefully to prevent the problem from being
aggravated until as the nature of the problem can be
checked and analyzed.

−4 −
120 GB or 240 GB
NTSC/PAL color signal standard (Switchable)
NTSC : 720 x 480 (Super/High), 352 x 480 (Standard)
PAL : 720 x 576 (Super/High), 352 x 576 (Standard)
MPEG2 (Video), MPEG1 Layer2 (Audio)
3 Levels (Super, High, Standard)
Frame
1 (NTSC: 30 fps or PAL: 25 fps)
1
Playback, Still, Search, Cue, Review, Frame advance, Slow
Search by time and data
Search by alarm event list
English/ French/ Spanish
Month/ Day/ Year/ Hours/ Minutes/ Seconds
1.0 V p-p 75 Ω, unbalanced, BNC
1.0 V p-p 75 Ω, unbalanced, BNC
-8dBs, 27kΩ, unbalanced, RCA pin jack
-8dBs, 600Ω, unbalanced, RCA pin jack
-60dBs, 10kΩ, unbalanced, 3.5mm mini jack
100BASE-TX/ 10BASE-T RJ-45
For compact flash reader (Front)
3 terminals: A, B, C
External switch connection or VA-RMN01 remote control
Normal 5V, Low level active
Normal 5V, Low level active
Normal open, Low level active
Normal open. Low level active
Normal 5V, Low level active
Open collector (500 mA), Low level active
Open collector (50 mA), Low level active
120 V - 240 V AC, 50/ 60 Hz
460 mA - 280 mA
Temperature: 5 °C to 40 °C, Humidity:10% to 80 %
210 (W) x 96 (H) x 391.5 (D) mm
3.4 kg
SPECIFICATIONS
Hard disk capacity :
Television System :
Picture Resolution :
Compression :
Picture Quality :
Recording Type :
Recording Speed :
Recording Area :
Playback :
Search Mode :
•Time/ Data Search :
•Alarm Search :
Menu Language :
Clock setting :
Video input terminal :
Video output terminal :
Audio input terminal :
Audio output terminal :
Microphone input terminal :
LAN terminal :
USB terminal :
Control connector (Push lock) :
•RS-485 terminal :
•Remote control input treminal :
•Clock adjust output treminal :
•Non REC output treminal :
•Alarm input treminal :
•Alarm reset input treminal :
•Alarm output treminal :
•Warning output treminal :
•Full out warning treminal :
Power :
Current consumption :
Operating environment :
Dimension :
Weight :
Search Mode

−5 −
Fig. 1
1. DISASSEMBLY
1-1. REMOVAL OF CABINET, CIRCUIT BOARD LOCATIONS AND CP-1 BOARD LOCA-
TIONS OF ADJUSTMENT POINTS
NOTE:
1. Please carry out the screw stop
of the attachment to HDD in the
order of the number stamped
on the HDD holder.
2. Please attach the 1st set of an
HDD unit in the backside of a
product.
3. Harness should use the socket
of an end.
CP-1 PWB
OP-1 PWB
TB-1 PWB
PW-1 PWB
HDD Unit
TP301
VR340
2. RESETTING THE USE TIME
1.Press the Vbutton for more than 3 seconds. DISK1 USE
time display reverses.
2.USED TIME display to reset with the Vbutton pressed.
3.Press the MENU RESET button. Time display resets it.
4.Whe it is finished, the EXIT/OSD button is pressed.
< POWER FAILURE >
F A I LURE –––––––: ––
RECOVER –––––––: ––
< USED TI ME >
DISK1 USE : 0 0 0 0 0 H
DISK2 USE : –––––H
POWER
: 0 0 0 0 0 H
FIRMWARE : MAIN / SUB

−6 −
3. ADJUSTMENT
1. AGC VOLTAGE ADJUSTMENT
1. Terminate the VIDEO OUT terminal with a 75 Ωregistor.
2. Connect the color bar generator to the VIDEO IN terminal,
and input color bar signal (100 % white level).
2. Connect the oscilloscope to the TP301.
3. Adjust VR340 so that the level becomes 1.00 ±0.03 Vp-p.
Measuring Point Measuring Equipment Condition
Adj. Value
Oscilloscope
Color bar generator
E-E Mode
Color bar signal
(100% white level)
1.00 ±0.03 V p-p
TP301
(CP-1 board)
VR340 (CP-1 board)
Adj. Location
Fig. 3
1.00 ±
Vp-p
0.03

7
4. PARTS LIST
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
NJ503
NJ503
NJ503
NJ503
5020
5021
NJ503
N.S.P.:Not available as service parts.
NJ503
6035
HDD
NJ610
NJ612
6014 6006
6007
NJ614
6012
6011 NJ602
NJ602
NJ602
CP-1
NJ603
NJ604
NJ601
PW-1
TB-1
6009 6003
NJ608
NJ608
6004
7001
6005
5050
6005
6005
NJ612
6001(N.S.P.)
5106
5103
5102
5108
5101 5104
5105
5107
NJ605
NJ605
NJ605
NJ605
6002(N.S.P.)
OP-1
NJ606
NJ609
NJ606
NJ607 NJ607
NJ609
NJ609
6030
W0001
NJ612
*CH-L8HAC/XE(MS)
5112
NJ611
NJ612
6013
NJ613
6015
ACCESSORIES & PACKING MATERIALS
9102 613 200 1106 INSTRUCTION MANUAL
9203 613 053 6495 FIXER
9212 645 052 1997 CORE,FERRITE
OR 645 060 3778 CORE,FERRITE
9300 645 040 6065 CORD,POWER-1.8MK,
EXCEPT DSR-M800P (Europe)
9300 645 040 6072 CORD,POWER-1.8MK,
DSR-M800P (Europe) ONLY
9001 613 200 1915 CARTON CASE
9002 613 200 3339 CUSHION
9003 613 200 3346 CUSHION,TOP,DSR-M800P (Europe) ONLY
9003 613 200 7849 CUSHION,TOP,EXCEPT DSR-M800P (Europe)
9004 613 200 3353 CUSHION,BACK, BACK
9005 613 200 3360 CUSHION,F/B, FRONT/BACK
9012 613 200 4879 BAG,INNER
CABINET & CHASSIS PARTS
5020 613 199 4683 COVER TOP(3L57)
5021 613 200 0536 LABEL CAUTION HDD
5050 613 200 7689 LABEL RATING
5101 613 199 4812 CABINET FRONT
5102 613 199 4843 DEC FRONT
5103 613 199 4874 DEC INDICATOR
5104 613 199 4799 BUTTON 10P
5105 613 199 4805 BUTTON REC
5106 613 199 4850 DEC WINDOW
5107 613 199 4867 DEC WINDOW
5108 613 199 7912 BUTTON TIMER
5112 613 121 7324 BADGE
6001 CABINET BOTTOM-HALF (N.S.P.)
6002 FRAME FRONT-F2F02 (N.S.P.)
6003 613 199 4690 COVER BACK
6004 613 199 4706 COVER FAN
6005 645 058 0406 STAND(V0)
6006 613 199 4720 HOLDER HDD-1
6007 613 199 4737 HOLDER HDD-2
6009 613 199 6809 COVER,DIP SW
6011 613 200 4268 SPACER
6012 613 096 4021 HOLDER
6013 613 200 7832 EARTH
6014 613 059 4099 SPRING PLATE
6015 613 059 4099 SPRING PLATE
6030 645 002 1121 FIXER
6035 613 198 0150 LABEL GUARANTEE
7001 645 057 2036 MOTOR,FAN DC 1.56W
HDD 613 200 5562 COMPL,HDD (120)
NJ503 411 098 1303 SCR S-TPG BIN 3X6A
NJ601 411 184 5802 SCR S-TPG BIN+OTW 3X6
NJ602 411 184 5802 SCR S-TPG BIN+OTW 3X6
NJ603 411 002 0804 SCR BIN 4X6
NJ604 411 085 3709 WASHER OUT TW 4
NJ605 411 001 1901 SCR S-TPG BIN 3X6
NJ606 411 184 7400 SCR L-TPG PAN 3X10
NJ607 411 184 7400 SCR L-TPG PAN 3X10
NJ608 411 001 5206 SCR S-TPG PAN 4X20
NJ609 411 001 1901 SCR S-TPG BIN 3X6
NJ610 412 062 6102 SPECIAL SCREW-3.5X4.5
NJ611 411 001 1901 SCR S-TPG BIN 3X6
NJ612 411 001 1901 SCR S-TPG BIN 3X6
NJ613 411 001 1901 SCR S-TPG BIN 3X6
NJ614 411 001 1901 SCR S-TPG BIN 3X6
CP-1 613 200 1809 COMPL PWB,CP-1-A
OP-1 613 200 1663 COMPL PWB,OP-1
PW-1 613 200 1687 COMPL PWB,PW-1
TB-1 613 200 1649 COMPL PWB,TB-1
W0001 613 187 7887 ASSY,WIRE ,CN501-INLET

8
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
ELECTRICAL PARTS
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CP-1-A
613 200 1809
(BATTERY)
Z3300 645 008 5765 BATTERY,RECHARGE
(SEMICONDUCTORS)
Q1003 405 002 0308 TR 2SA1037K-R
Q1101 405 090 4905 TR 2SC4452-4
Q1102 405 090 4905 TR 2SC4452-4
Q1103 405 090 4905 TR 2SC4452-4
Q1104 405 090 4905 TR 2SC4452-4
Q3200 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3300 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3301 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3302 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3303 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3304 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3305 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3306 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3307 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3401 405 089 2103 TR 2SC4483-S
OR 405 089 2202 TR 2SC4483-T
Q3403 405 000 5305 TR DTC143TK
OR 405 045 2208 TR 2SC3900
Q3404 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3406 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3407 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
Q3407 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3408 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3409 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3441 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
Q3470 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q3471 405 141 0603 TR 2SA1037AK-R
OR 405 002 0308 TR 2SA1037K-R
OR 405 002 0209 TR 2SA1037K-Q
OR 405 002 0407 TR 2SA1037K-S
(INTEGRATED CIRCUITS)
IC101 409 541 0003 IC SAA7115
IC102 409 541 0102 IC SAA7126H
IC103 409 541 0201 IC PCM1800
IC104 409 541 0300 IC AK4380VT
IC116 409 541 7408 IC PST598IN
IC117 409 228 9206 IC NJM2100M
IC300 409 556 4102 IC V1.00-09 CASINO SUB
IC301 409 482 3002 IC BR24C08F
OR 409 504 7001 IC 24LC08BT/SN
IC303 409 353 4206 IC PST9127N
IC304 409 540 3906 IC MAX3100EEE
IC320 409 540 4101 IC RTL8139C
IC321 409 540 4002 IC AT93C46I18 (N.S.P.)
IC330 409 432 6404 IC MAX3082CSA
IC331 409 544 6606 IC SI-3012KS-TL
IC340 409 306 1009 IC MM1031XM
IC342 409 084 0409 IC LA6458M
IC343 410 439 6908 IC LC74782M-9841-TRM
IC344 409 326 0907 IC LA7152
IC345 409 182 9106 IC AN3916
IC346 409 183 1000 IC NJM2233BM
IC410 409 547 9901 IC CX23415-12 (N.S.P.)
IC411 409 528 7704 IC W986432DH-7
IC412 409 528 7704 IC W986432DH-7
IC421 409 541 4506 IC IT8172G (N.S.P.)
IC441 409 556 6601 IC V05001-1 CDVP-PL2
IC442 409 556 6700 IC V05001-2 CDVP-PL2
IC443 409 528 7803 IC W981216BH-7
IC444 409 528 7803 IC W981216BH-7
IC445 409 368 5809 IC TC7SH08FU
IC451 409 542 9005 IC RM5231A
IC452 409 542 4604 IC ICS9248YF81
IC461 409 505 1602 IC PLL1700E
IC462 409 427 7904 IC TC74VHC02FT

9
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
(DIODES)
D1001 407 133 3104 DIODE RB411D
D1101 407 209 4509 ZENER DIODE UDZS6.8B
D1102 407 209 4509 ZENER DIODE UDZS6.8B
D1103 407 209 4509 ZENER DIODE UDZS6.8B
D1104 407 209 4509 ZENER DIODE UDZS6.8B
D1105 407 133 3104 DIODE RB411D
D1106 407 133 3104 DIODE RB411D
D1107 407 133 3104 DIODE RB411D
D1108 407 133 3104 DIODE RB411D
D3300 407 120 4503 DIODE DA204U-T106
D3302 407 120 4503 DIODE DA204U-T106
D3303 407 120 4503 DIODE DA204U-T106
D3304 407 120 5807 DIODE AK04
OR 407 160 9100 DIODE ERA83-004
D3305 407 120 5807 DIODE AK04
OR 407 160 9100 DIODE ERA83-004
D3401 407 113 5609 DIODE DSH015
D4101 407 133 3104 DIODE RB411D
D4102 407 133 3104 DIODE RB411D
D4601 407 133 3104 DIODE RB411D
(OSCILLATORS)
X1001 645 037 4623 OSC,CRYSTAL 24.576MHZ
X3001 613 109 0972 OSC,CRYSTAL 32KHZ
X3002 645 031 3097 OSC,CERAMIC 10MHZ
X3003 645 056 9869 OSC,CRYSTAL 3.6864MHZ
X3200 645 056 9876 OSC,CRYSTAL 25.000MHZ
X3400 613 122 9020 OSC,CRYSTAL 7.16MHZ
OR 613 135 2766 OSC,CRYSTAL 7.16MHZ
OR 645 000 4636 OSC,CRYSTAL 7159.090KHZ
OR 645 001 7155 OSC,CRYSTAL 7.15909MHZ
X4201 613 109 0972 OSC,CRYSTAL 32KHZ
X4501 645 057 0780 OSC,CRYSTAL 14.31818MHZ
X4601 645 028 0856 OSC,CRYSTAL 27.000MHZ
(VARIABLE RESISTOR)
VR340 636 036 2239 VR,SEMI 22KB
(INDUCTORS)
L1001 645 001 4512 INDUCTOR,10U K
L1002 645 004 1990 INDUCTOR,47U K
L1003 645 004 1990 INDUCTOR,47U K
L1004 645 004 2478 INDUCTOR,10U J
L1005 645 004 2362 INDUCTOR,18U J
L1006 645 004 1990 INDUCTOR,47U K
L1007 645 004 1990 INDUCTOR,47U K
L1008 645 004 1990 INDUCTOR,47U K
L3200 645 006 3602 INDUCTOR,1.1UH
L3203 645 006 3602 INDUCTOR,1.1UH
L3206 645 006 3602 INDUCTOR,1.1UH
L3300 645 006 3602 INDUCTOR,1.1UH
L3301 645 006 3602 INDUCTOR,1.1UH
L3302 645 006 3602 INDUCTOR,1.1UH
L3401 645 020 1912 INDUCTOR,240 OHM
L3402 645 020 1912 INDUCTOR,240 OHM
L3403 645 020 1912 INDUCTOR,240 OHM
L3405 645 020 1912 INDUCTOR,240 OHM
L3406 645 004 2430 INDUCTOR,56U J
L3407 645 004 2409 INDUCTOR,33U J
L3408 645 001 4512 INDUCTOR,10U K
L3409 645 001 4512 INDUCTOR,10U K
L3410 645 001 4512 INDUCTOR,10U K
L3411 645 001 4512 INDUCTOR,10U K
L3412 645 001 4512 INDUCTOR,10U K
L3470 645 001 4512 INDUCTOR,10U K
L3471 645 004 2430 INDUCTOR,56U J
L4101 645 004 1990 INDUCTOR,47U K
L4201 645 004 1990 INDUCTOR,47U K
L4202 645 004 1990 INDUCTOR,47U K
(TRANSFORMER)
T3200 645 057 0179 UNIT,LAN INTERFACE MODULE
(CAPACITORS)
C1004 403 073 1200 CERAMIC 0.033U K 50V
C1005 403 164 0204 CERAMIC 0.1U Z 25V
C1006 403 162 4006 ELECT 22U M 6.3V
C1007 403 162 4006 ELECT 22U M 6.3V
C1008 403 164 0204 CERAMIC 0.1U Z 25V
C1009 403 162 4006 ELECT 22U M 6.3V
C1010 403 163 9802 CERAMIC 0.047U Z 25V
C1011 403 163 9802 CERAMIC 0.047U Z 25V
C1012 403 162 4006 ELECT 22U M 6.3V
C1013 403 164 0204 CERAMIC 0.1U Z 25V
C1014 403 162 4006 ELECT 22U M 6.3V
C1015 403 139 7306 CERAMIC 18P J 50V
C1016 403 139 7306 CERAMIC 18P J 50V
C1017 403 164 0204 CERAMIC 0.1U Z 25V
C1018 403 164 0204 CERAMIC 0.1U Z 25V
C1019 403 162 4006 ELECT 22U M 6.3V
C1020 403 164 0204 CERAMIC 0.1U Z 25V
C1021 403 164 0204 CERAMIC 0.1U Z 25V
C1022 403 162 4006 ELECT 22U M 6.3V
C1023 403 164 0204 CERAMIC 0.1U Z 25V
C1024 403 162 4006 ELECT 22U M 6.3V
C1025 403 139 7108 CERAMIC 12P J 50V
C1026 403 155 1500 CERAMIC 180P J 50V
C1027 403 155 1609 CERAMIC 33P J 50V
C1028 403 157 1607 CERAMIC 6P D 50V
C1029 403 162 4006 ELECT 22U M 6.3V
C1030 403 164 0204 CERAMIC 0.1U Z 25V
C1031 403 164 0204 CERAMIC 0.1U Z 25V
C1032 403 162 4006 ELECT 22U M 6.3V
C1033 403 164 0204 CERAMIC 0.1U Z 25V
C1034 403 162 4006 ELECT 22U M 6.3V
C1035 403 215 1006 CERAMIC 470P J 50V
C1036 403 215 1006 CERAMIC 470P J 50V
C1037 403 162 4006 ELECT 22U M 6.3V
C1038 403 162 4006 ELECT 22U M 6.3V
C1039 403 162 4006 ELECT 22U M 6.3V
C1040 403 162 4006 ELECT 22U M 6.3V
C1041 403 164 0204 CERAMIC 0.1U Z 25V
C1042 403 164 0204 CERAMIC 0.1U Z 25V
C1043 403 162 4006 ELECT 22U M 6.3V
C1045 403 073 1200 CERAMIC 0.033U K 50V
C1101 403 164 0204 CERAMIC 0.1U Z 25V
C1102 403 164 0204 CERAMIC 0.1U Z 25V
C1103 403 164 0204 CERAMIC 0.1U Z 25V
C1104 403 157 3601 CERAMIC 100P J 50V
C1105 403 157 3601 CERAMIC 100P J 50V
C1106 403 164 0204 CERAMIC 0.1U Z 25V
C1107 403 175 0606 ELECT 100U M 6.3V
C1108 403 162 4006 ELECT 22U M 6.3V
C1109 403 164 0204 CERAMIC 0.1U Z 25V
C1110 403 145 9905 CERAMIC 22P J 50V
C1111 403 164 0204 CERAMIC 0.1U Z 25V
C1112 403 215 1006 CERAMIC 470P J 50V
C1113 403 113 3805 CERAMIC 1000P K 50V
C1114 403 162 4006 ELECT 22U M 6.3V
C1115 403 162 4006 ELECT 22U M 6.3V
C1116 403 162 4006 ELECT 22U M 6.3V
C1117 403 215 1006 CERAMIC 470P J 50V
C1118 403 145 9905 CERAMIC 22P J 50V
C1119 403 113 3805 CERAMIC 1000P K 50V
C1120 403 162 4006 ELECT 22U M 6.3V
C1121 403 162 4006 ELECT 22U M 6.3V
C1122 403 157 2901 CERAMIC 47P J 50V
C1123 403 157 2901 CERAMIC 47P J 50V
C1124 403 157 2901 CERAMIC 47P J 50V
C1125 403 157 2901 CERAMIC 47P J 50V
C1126 403 157 1904 CERAMIC 10P D 50V
C1127 403 157 1904 CERAMIC 10P D 50V
C1128 403 157 1904 CERAMIC 10P D 50V
C1129 403 157 1904 CERAMIC 10P D 50V
C1130 403 164 0204 CERAMIC 0.1U Z 25V
C1131 403 164 0204 CERAMIC 0.1U Z 25V
C1132 403 164 0204 CERAMIC 0.1U Z 25V
C1133 403 164 0204 CERAMIC 0.1U Z 25V
C1137 403 164 0204 CERAMIC 0.1U Z 25V
C1169 403 157 3601 CERAMIC 100P J 50V
C3000 403 164 0204 CERAMIC 0.1U Z 25V
C3001 403 162 4709 ELECT 10U M 16V
C3002 403 145 9905 CERAMIC 22P J 50V
C3003 403 145 9905 CERAMIC 22P J 50V
C3004 403 164 0204 CERAMIC 0.1U Z 25V
C3005 403 164 0204 CERAMIC 0.1U Z 25V
C3006 403 164 0204 CERAMIC 0.1U Z 25V
C3007 403 162 4709 ELECT 10U M 16V
C3008 403 155 4204 CERAMIC 15P J 50V
C3009 403 139 7108 CERAMIC 12P J 50V

10
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C3010 403 164 0204 CERAMIC 0.1U Z 25V
C3011 403 162 4709 ELECT 10U M 16V
C3012 403 113 3805 CERAMIC 1000P K 50V
C3013 403 113 3805 CERAMIC 1000P K 50V
C3014 403 113 3805 CERAMIC 1000P K 50V
C3015 403 162 4709 ELECT 10U M 16V
C3016 403 164 0204 CERAMIC 0.1U Z 25V
C3200 403 175 0606 ELECT 100U M 6.3V
C3201 403 164 0204 CERAMIC 0.1U Z 25V
C3202 403 164 0204 CERAMIC 0.1U Z 25V
C3203 403 164 0204 CERAMIC 0.1U Z 25V
C3204 403 164 0204 CERAMIC 0.1U Z 25V
C3205 403 164 0204 CERAMIC 0.1U Z 25V
C3206 403 164 0204 CERAMIC 0.1U Z 25V
C3207 403 164 0204 CERAMIC 0.1U Z 25V
C3208 403 164 0204 CERAMIC 0.1U Z 25V
C3209 403 164 0204 CERAMIC 0.1U Z 25V
C3210 403 164 0204 CERAMIC 0.1U Z 25V
C3211 403 155 4204 CERAMIC 15P J 50V
C3212 403 155 4204 CERAMIC 15P J 50V
C3213 403 164 0204 CERAMIC 0.1U Z 25V
C3214 403 157 1904 CERAMIC 10P D 50V
C3215 403 164 0204 CERAMIC 0.1U Z 25V
C3216 403 164 0204 CERAMIC 0.1U Z 25V
C3217 403 162 4709 ELECT 10U M 16V
C3218 403 145 9905 CERAMIC 22P J 50V
C3219 403 145 9905 CERAMIC 22P J 50V
C3300 403 164 0204 CERAMIC 0.1U Z 25V
C3301 403 113 3805 CERAMIC 1000P K 50V
C3302 403 113 3805 CERAMIC 1000P K 50V
C3303 403 113 3805 CERAMIC 1000P K 50V
C3304 403 175 3300 ELECT 47U M 16V
C3305 403 164 0204 CERAMIC 0.1U Z 25V
C3306 403 175 0606 ELECT 100U M 6.3V
C3307 403 280 0805 ELECT 330U M 6.3V
C3308 403 280 0805 ELECT 330U M 6.3V
C3309 403 175 0606 ELECT 100U M 6.3V
C3310 403 175 0606 ELECT 100U M 6.3V
C3311 403 175 4505 ELECT 47U M 6.3V
C3401 403 175 3300 ELECT 47U M 16V
C3405 403 162 6604 ELECT 2.2U M 50V
C3406 403 157 6909 CERAMIC 820P K 50V
C3407 403 157 3601 CERAMIC 100P J 50V
C3408 403 155 2101 CERAMIC 1500P K 50V
C3409 403 175 4109 ELECT 22U M 16V
C3410 403 175 4109 ELECT 22U M 16V
C3411 403 175 4109 ELECT 22U M 16V
C3413 403 164 0204 CERAMIC 0.1U Z 25V
C3414 403 164 0204 CERAMIC 0.1U Z 25V
C3416 403 218 3106 ELECT 1000U M 16V
C3417 403 162 6604 ELECT 2.2U M 50V
C3418 403 175 3706 ELECT 4.7U M 50V
C3419 403 157 7005 CERAMIC 1800P K 50V
C3420 403 164 0204 CERAMIC 0.1U Z 25V
C3421 403 139 7306 CERAMIC 18P J 50V
C3422 403 139 7306 CERAMIC 18P J 50V
C3423 403 139 7306 CERAMIC 18P J 50V
C3424 403 139 7306 CERAMIC 18P J 50V
C3428 403 175 4505 ELECT 47U M 6.3V
C3429 403 164 0204 CERAMIC 0.1U Z 25V
C3430 403 162 6208 ELECT 1U M 50V
C3431 403 164 0204 CERAMIC 0.1U Z 25V
C3432 403 164 0204 CERAMIC 0.1U Z 25V
C3433 403 164 0204 CERAMIC 0.1U Z 25V
C3434 403 175 3706 ELECT 4.7U M 50V
C3435 403 175 3706 ELECT 4.7U M 50V
C3436 403 162 4709 ELECT 10U M 16V
C3437 403 175 3706 ELECT 4.7U M 50V
C3438 403 205 2808 CERAMIC 0.047U K 25V
C3439 403 155 2200 CERAMIC 3300P K 50V
C3440 403 164 0204 CERAMIC 0.1U Z 25V
C3441 403 175 4505 ELECT 47U M 6.3V
C3442 403 162 4709 ELECT 10U M 16V
C3443 403 175 4505 ELECT 47U M 6.3V
C3444 403 162 4709 ELECT 10U M 16V
C3445 403 162 4709 ELECT 10U M 16V
C3446 403 164 0204 CERAMIC 0.1U Z 25V
C3447 403 164 0204 CERAMIC 0.1U Z 25V
C3448 403 164 0204 CERAMIC 0.1U Z 25V
C3449 403 164 0204 CERAMIC 0.1U Z 25V
C3470 403 162 4709 ELECT 10U M 16V
C3471 403 155 2200 CERAMIC 3300P K 50V
C3472 403 162 6208 ELECT 1U M 50V
C3473 403 205 2808 CERAMIC 0.047U K 25V
C3474 403 157 3106 CERAMIC 56P J 50V
C3475 403 175 4505 ELECT 47U M 6.3V
C3476 403 164 0204 CERAMIC 0.1U Z 25V
C3481 403 162 4709 ELECT 10U M 16V
C3482 403 162 4709 ELECT 10U M 16V
C3483 403 164 0204 CERAMIC 0.1U Z 25V
C3484 403 175 3300 ELECT 47U M 16V
C4101 403 164 0204 CERAMIC 0.1U Z 25V
C4102 403 164 0204 CERAMIC 0.1U Z 25V
C4103 403 164 0204 CERAMIC 0.1U Z 25V
C4104 403 164 0204 CERAMIC 0.1U Z 25V
C4105 403 164 0204 CERAMIC 0.1U Z 25V
C4106 403 164 0204 CERAMIC 0.1U Z 25V
C4107 403 162 4006 ELECT 22U M 6.3V
C4108 403 164 0204 CERAMIC 0.1U Z 25V
C4109 403 162 4006 ELECT 22U M 6.3V
C4110 403 164 0204 CERAMIC 0.1U Z 25V
C4111 403 164 0204 CERAMIC 0.1U Z 25V
C4112 403 164 0204 CERAMIC 0.1U Z 25V
C4113 403 164 0204 CERAMIC 0.1U Z 25V
C4114 403 164 0204 CERAMIC 0.1U Z 25V
C4115 403 164 0204 CERAMIC 0.1U Z 25V
C4116 403 164 0204 CERAMIC 0.1U Z 25V
C4117 403 164 0204 CERAMIC 0.1U Z 25V
C4118 403 164 0204 CERAMIC 0.1U Z 25V
C4119 403 162 4006 ELECT 22U M 6.3V
C4120 403 164 0204 CERAMIC 0.1U Z 25V
C4121 403 164 0204 CERAMIC 0.1U Z 25V
C4122 403 164 0204 CERAMIC 0.1U Z 25V
C4123 403 164 0204 CERAMIC 0.1U Z 25V
C4124 403 164 0204 CERAMIC 0.1U Z 25V
C4125 403 164 0204 CERAMIC 0.1U Z 25V
C4126 403 164 0204 CERAMIC 0.1U Z 25V
C4127 403 164 0204 CERAMIC 0.1U Z 25V
C4128 403 164 0204 CERAMIC 0.1U Z 25V
C4129 403 164 0204 CERAMIC 0.1U Z 25V
C4130 403 164 0204 CERAMIC 0.1U Z 25V
C4131 403 164 0204 CERAMIC 0.1U Z 25V
C4132 403 164 0204 CERAMIC 0.1U Z 25V
C4133 403 164 0204 CERAMIC 0.1U Z 25V
C4134 403 164 0204 CERAMIC 0.1U Z 25V
C4135 403 164 0204 CERAMIC 0.1U Z 25V
C4136 403 164 0204 CERAMIC 0.1U Z 25V
C4137 403 164 0204 CERAMIC 0.1U Z 25V
C4138 403 164 0204 CERAMIC 0.1U Z 25V
C4139 403 164 0204 CERAMIC 0.1U Z 25V
C4140 403 164 0204 CERAMIC 0.1U Z 25V
C4141 403 164 0204 CERAMIC 0.1U Z 25V
C4142 403 164 0204 CERAMIC 0.1U Z 25V
C4143 403 164 0204 CERAMIC 0.1U Z 25V
C4144 403 164 0204 CERAMIC 0.1U Z 25V
C4145 403 164 0204 CERAMIC 0.1U Z 25V
C4146 403 164 0204 CERAMIC 0.1U Z 25V
C4147 403 164 0204 CERAMIC 0.1U Z 25V
C4148 403 164 0204 CERAMIC 0.1U Z 25V
C4149 403 164 0204 CERAMIC 0.1U Z 25V
C4150 403 164 0204 CERAMIC 0.1U Z 25V
C4151 403 164 0204 CERAMIC 0.1U Z 25V
C4152 403 164 0204 CERAMIC 0.1U Z 25V
C4153 403 164 0204 CERAMIC 0.1U Z 25V
C4154 403 162 4006 ELECT 22U M 6.3V
C4155 403 164 0204 CERAMIC 0.1U Z 25V
C4201 403 175 0606 ELECT 100U M 6.3V
C4202 403 164 0204 CERAMIC 0.1U Z 25V
C4203 403 175 0606 ELECT 100U M 6.3V
C4204 403 164 0204 CERAMIC 0.1U Z 25V
C4205 403 164 0204 CERAMIC 0.1U Z 25V
C4206 403 164 0204 CERAMIC 0.1U Z 25V
C4207 403 164 0204 CERAMIC 0.1U Z 25V
C4208 403 164 0204 CERAMIC 0.1U Z 25V
C4209 403 164 0204 CERAMIC 0.1U Z 25V
C4210 403 175 0606 ELECT 100U M 6.3V

11
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C4211 403 164 0204 CERAMIC 0.1U Z 25V
C4212 403 162 4006 ELECT 22U M 6.3V
C4213 403 164 0204 CERAMIC 0.1U Z 25V
C4214 403 164 0204 CERAMIC 0.1U Z 25V
C4215 403 164 0204 CERAMIC 0.1U Z 25V
C4216 403 164 0204 CERAMIC 0.1U Z 25V
C4217 403 164 0204 CERAMIC 0.1U Z 25V
C4218 403 162 4006 ELECT 22U M 6.3V
C4219 403 164 0204 CERAMIC 0.1U Z 25V
C4221 403 164 0204 CERAMIC 0.1U Z 25V
C4401 403 164 0204 CERAMIC 0.1U Z 25V
C4402 403 164 0204 CERAMIC 0.1U Z 25V
C4403 403 164 0204 CERAMIC 0.1U Z 25V
C4404 403 164 0204 CERAMIC 0.1U Z 25V
C4405 403 164 0204 CERAMIC 0.1U Z 25V
C4407 403 164 0204 CERAMIC 0.1U Z 25V
C4408 403 164 0204 CERAMIC 0.1U Z 25V
C4409 403 164 0204 CERAMIC 0.1U Z 25V
C4410 403 164 0204 CERAMIC 0.1U Z 25V
C4411 403 164 0204 CERAMIC 0.1U Z 25V
C4412 403 164 0204 CERAMIC 0.1U Z 25V
C4413 403 164 0204 CERAMIC 0.1U Z 25V
C4414 403 164 0204 CERAMIC 0.1U Z 25V
C4501 403 164 0204 CERAMIC 0.1U Z 25V
C4502 403 164 0204 CERAMIC 0.1U Z 25V
C4503 403 164 0204 CERAMIC 0.1U Z 25V
C4504 403 340 6907 CERAMIC 1U K 16V
C4505 403 164 0204 CERAMIC 0.1U Z 25V
C4506 403 164 0204 CERAMIC 0.1U Z 25V
C4507 403 164 0204 CERAMIC 0.1U Z 25V
C4508 403 164 0204 CERAMIC 0.1U Z 25V
C4509 403 164 0204 CERAMIC 0.1U Z 25V
C4510 403 157 1904 CERAMIC 10P D 50V
C4511 403 164 0204 CERAMIC 0.1U Z 25V
C4512 403 334 3806 CERAMIC 10U K 6.3V
C4513 403 164 0204 CERAMIC 0.1U Z 25V
C4514 403 164 0204 CERAMIC 0.1U Z 25V
C4515 403 164 0204 CERAMIC 0.1U Z 25V
C4516 403 340 6907 CERAMIC 1U K 16V
C4517 403 164 0204 CERAMIC 0.1U Z 25V
C4518 403 164 0204 CERAMIC 0.1U Z 25V
C4519 403 164 0204 CERAMIC 0.1U Z 25V
C4520 403 164 0204 CERAMIC 0.1U Z 25V
C4521 403 340 6907 CERAMIC 1U K 16V
C4522 403 164 0204 CERAMIC 0.1U Z 25V
C4523 403 164 0204 CERAMIC 0.1U Z 25V
C4524 403 164 0204 CERAMIC 0.1U Z 25V
C4525 403 157 1904 CERAMIC 10P D 50V
C4526 403 157 1904 CERAMIC 10P D 50V
C4527 403 164 0204 CERAMIC 0.1U Z 25V
C4528 403 008 7406 CERAMIC 10P D 50V
C4529 403 157 1904 CERAMIC 10P D 50V
C4530 403 157 1508 CERAMIC 3P C 50V
C4531 403 157 1508 CERAMIC 3P C 50V
C4532 403 164 0204 CERAMIC 0.1U Z 25V
C4533 403 157 1904 CERAMIC 10P D 50V
C4534 403 157 1904 CERAMIC 10P D 50V
C4535 403 157 1904 CERAMIC 10P D 50V
C4536 403 164 0204 CERAMIC 0.1U Z 25V
C4537 403 157 1904 CERAMIC 10P D 50V
C4538 403 164 0204 CERAMIC 0.1U Z 25V
C4540 403 334 3806 CERAMIC 10U K 6.3V
C4541 403 334 3806 CERAMIC 10U K 6.3V
C4551 403 162 4006 ELECT 22U M 6.3V
C4552 403 162 4006 ELECT 22U M 6.3V
C4601 403 164 0204 CERAMIC 0.1U Z 25V
C4602 403 162 4006 ELECT 22U M 6.3V
C4603 403 139 7306 CERAMIC 18P J 50V
C4604 403 139 7306 CERAMIC 18P J 50V
C4605 403 164 0204 CERAMIC 0.1U Z 25V
C4606 403 162 4006 ELECT 22U M 6.3V
C4607 403 164 0204 CERAMIC 0.1U Z 25V
C4608 403 162 4006 ELECT 22U M 6.3V
C4609 403 164 0204 CERAMIC 0.1U Z 25V
C4610 403 162 4006 ELECT 22U M 6.3V
(RESISTORS)
R1009 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1011 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1012 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1013 401 105 0504 MT-GLAZE 1K JA 1/16W
R1014 401 105 0504 MT-GLAZE 1K JA 1/16W
R1015 401 105 0504 MT-GLAZE 1K JA 1/16W
R1016 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1017 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1018 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1019 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1020 401 105 2607 MT-GLAZE 22 JA 1/16W
R1021 401 105 2607 MT-GLAZE 22 JA 1/16W
R1024 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1025 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1026 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1027 401 113 5003 MT-GLAZE 240 JA 1/16W
R1028 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1029 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R1030 401 105 5202 MT-GLAZE 470 JA 1/16W
R1031 401 105 2607 MT-GLAZE 22 JA 1/16W
R1032 401 105 0504 MT-GLAZE 1K JA 1/16W
R1033 401 105 0504 MT-GLAZE 1K JA 1/16W
R1034 401 113 6406 MT-GLAZE 5.1K JA 1/16W
R1035 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1036 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1037 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1038 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1039 401 105 5400 MT-GLAZE 47K JA 1/16W
R1040 401 105 5400 MT-GLAZE 47K JA 1/16W
R1041 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1042 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1043 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1044 401 037 5004 MT-GLAZE 0.000 ZA 1/10W
R1048 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1049 401 105 2607 MT-GLAZE 22 JA 1/16W
R1101 401 105 0603 MT-GLAZE 10K JA 1/16W
R1102 401 105 2607 MT-GLAZE 22 JA 1/16W
R1103 401 105 2607 MT-GLAZE 22 JA 1/16W
R1104 401 105 2607 MT-GLAZE 22 JA 1/16W
R1105 401 105 2607 MT-GLAZE 22 JA 1/16W
R1106 401 105 2607 MT-GLAZE 22 JA 1/16W
R1107 401 105 2607 MT-GLAZE 22 JA 1/16W
R1108 401 105 2607 MT-GLAZE 22 JA 1/16W
R1109 401 105 2607 MT-GLAZE 22 JA 1/16W
R1110 401 105 2607 MT-GLAZE 22 JA 1/16W
R1111 401 105 2607 MT-GLAZE 22 JA 1/16W
R1112 401 105 2607 MT-GLAZE 22 JA 1/16W
R1113 401 105 2607 MT-GLAZE 22 JA 1/16W
R1114 401 105 2607 MT-GLAZE 22 JA 1/16W
R1115 401 105 2607 MT-GLAZE 22 JA 1/16W
R1116 401 105 2607 MT-GLAZE 22 JA 1/16W
R1117 401 105 2607 MT-GLAZE 22 JA 1/16W
R1118 401 105 2607 MT-GLAZE 22 JA 1/16W
R1119 401 105 2607 MT-GLAZE 22 JA 1/16W
R1120 401 105 2607 MT-GLAZE 22 JA 1/16W
R1121 401 105 2607 MT-GLAZE 22 JA 1/16W
R1122 401 105 2607 MT-GLAZE 22 JA 1/16W
R1123 401 105 2607 MT-GLAZE 22 JA 1/16W
R1124 401 105 2607 MT-GLAZE 22 JA 1/16W
R1125 401 105 2607 MT-GLAZE 22 JA 1/16W
R1126 401 105 2607 MT-GLAZE 22 JA 1/16W
R1127 401 105 2607 MT-GLAZE 22 JA 1/16W
R1128 401 105 2607 MT-GLAZE 22 JA 1/16W
R1129 401 105 0603 MT-GLAZE 10K JA 1/16W
R1130 401 105 2607 MT-GLAZE 22 JA 1/16W
R1131 401 105 2607 MT-GLAZE 22 JA 1/16W
R1132 401 105 6001 MT-GLAZE 5.6K JA 1/16W
R1133 401 105 1600 MT-GLAZE 15K JA 1/16W
R1134 401 105 1600 MT-GLAZE 15K JA 1/16W
R1135 401 105 0603 MT-GLAZE 10K JA 1/16W
R1136 401 105 0504 MT-GLAZE 1K JA 1/16W
R1138 401 105 0504 MT-GLAZE 1K JA 1/16W
R1139 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R1140 401 113 6604 MT-GLAZE 7.5K JA 1/16W
R1141 401 105 4700 MT-GLAZE 39K JA 1/16W
R1142 401 105 1600 MT-GLAZE 15K JA 1/16W
R1143 401 105 1600 MT-GLAZE 15K JA 1/16W
R1144 401 105 2904 MT-GLAZE 22K JA 1/16W
R1145 401 105 2904 MT-GLAZE 22K JA 1/16W
R1146 401 113 6604 MT-GLAZE 7.5K JA 1/16W

12
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
R1147 401 105 4700 MT-GLAZE 39K JA 1/16W
R1148 401 105 1600 MT-GLAZE 15K JA 1/16W
R1149 401 105 1600 MT-GLAZE 15K JA 1/16W
R1150 401 105 2904 MT-GLAZE 22K JA 1/16W
R1151 401 105 2904 MT-GLAZE 22K JA 1/16W
R1152 401 105 5400 MT-GLAZE 47K JA 1/16W
R1153 401 105 5400 MT-GLAZE 47K JA 1/16W
R1154 401 105 5400 MT-GLAZE 47K JA 1/16W
R1155 401 105 5400 MT-GLAZE 47K JA 1/16W
R1156 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1157 401 105 5400 MT-GLAZE 47K JA 1/16W
R1160 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1161 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1169 401 105 0603 MT-GLAZE 10K JA 1/16W
R3000 401 105 0504 MT-GLAZE 1K JA 1/16W
R3001 401 105 0504 MT-GLAZE 1K JA 1/16W
R3002 401 105 0504 MT-GLAZE 1K JA 1/16W
R3003 401 105 0504 MT-GLAZE 1K JA 1/16W
R3004 401 105 0504 MT-GLAZE 1K JA 1/16W
R3005 401 105 0504 MT-GLAZE 1K JA 1/16W
R3006 401 105 0603 MT-GLAZE 10K JA 1/16W
R3007 401 105 0603 MT-GLAZE 10K JA 1/16W
R3008 401 105 0603 MT-GLAZE 10K JA 1/16W
R3009 401 105 0504 MT-GLAZE 1K JA 1/16W
R3010 401 105 0504 MT-GLAZE 1K JA 1/16W
R3011 401 105 0504 MT-GLAZE 1K JA 1/16W
R3012 401 105 0504 MT-GLAZE 1K JA 1/16W
R3013 401 105 0504 MT-GLAZE 1K JA 1/16W
R3014 401 105 0504 MT-GLAZE 1K JA 1/16W
R3015 401 105 0504 MT-GLAZE 1K JA 1/16W
R3016 401 105 0504 MT-GLAZE 1K JA 1/16W
R3017 401 105 0603 MT-GLAZE 10K JA 1/16W
R3018 401 105 0603 MT-GLAZE 10K JA 1/16W
R3019 401 105 0603 MT-GLAZE 10K JA 1/16W
R3020 401 105 0603 MT-GLAZE 10K JA 1/16W
R3021 401 105 0603 MT-GLAZE 10K JA 1/16W
R3022 401 105 0603 MT-GLAZE 10K JA 1/16W
R3023 401 105 0603 MT-GLAZE 10K JA 1/16W
R3024 401 105 0603 MT-GLAZE 10K JA 1/16W
R3027 401 105 0603 MT-GLAZE 10K JA 1/16W
R3028 401 105 0603 MT-GLAZE 10K JA 1/16W
R3029 401 105 0603 MT-GLAZE 10K JA 1/16W
R3030 401 105 0504 MT-GLAZE 1K JA 1/16W
R3031 401 105 0504 MT-GLAZE 1K JA 1/16W
R3032 401 105 0405 MT-GLAZE 100 JA 1/16W
R3033 401 105 0504 MT-GLAZE 1K JA 1/16W
R3034 401 105 0405 MT-GLAZE 100 JA 1/16W
R3035 401 105 0405 MT-GLAZE 100 JA 1/16W
R3036 401 105 0405 MT-GLAZE 100 JA 1/16W
R3037 401 105 0504 MT-GLAZE 1K JA 1/16W
R3038 401 105 0504 MT-GLAZE 1K JA 1/16W
R3039 401 105 0405 MT-GLAZE 100 JA 1/16W
R3040 401 105 0405 MT-GLAZE 100 JA 1/16W
R3041 401 105 0405 MT-GLAZE 100 JA 1/16W
R3042 401 105 0405 MT-GLAZE 100 JA 1/16W
R3043 401 105 0603 MT-GLAZE 10K JA 1/16W
R3044 401 105 0603 MT-GLAZE 10K JA 1/16W
R3045 401 105 0504 MT-GLAZE 1K JA 1/16W
R3048 401 105 0603 MT-GLAZE 10K JA 1/16W
R3049 401 105 0603 MT-GLAZE 10K JA 1/16W
R3050 401 105 0603 MT-GLAZE 10K JA 1/16W
R3051 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3052 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3053 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3054 401 105 0504 MT-GLAZE 1K JA 1/16W
R3055 401 105 0504 MT-GLAZE 1K JA 1/16W
R3056 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3057 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R3058 401 105 2904 MT-GLAZE 22K JA 1/16W
R3059 401 177 2406 MT-GLAZE 10M JA 1/16W
R3060 401 105 3000 MT-GLAZE 220K JA 1/16W
R3061 401 105 0504 MT-GLAZE 1K JA 1/16W
R3062 401 105 0504 MT-GLAZE 1K JA 1/16W
R3063 401 105 0603 MT-GLAZE 10K JA 1/16W
R3064 401 105 0603 MT-GLAZE 10K JA 1/16W
R3065 401 105 0504 MT-GLAZE 1K JA 1/16W
R3066 401 105 0603 MT-GLAZE 10K JA 1/16W
R3067 401 105 0603 MT-GLAZE 10K JA 1/16W
R3068 401 105 0504 MT-GLAZE 1K JA 1/16W
R3069 401 105 0504 MT-GLAZE 1K JA 1/16W
R3070 401 105 0504 MT-GLAZE 1K JA 1/16W
R3071 401 105 0504 MT-GLAZE 1K JA 1/16W
R3072 401 105 0504 MT-GLAZE 1K JA 1/16W
R3073 401 105 0603 MT-GLAZE 10K JA 1/16W
R3074 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3075 401 105 0603 MT-GLAZE 10K JA 1/16W
R3076 401 105 0504 MT-GLAZE 1K JA 1/16W
R3077 401 105 0504 MT-GLAZE 1K JA 1/16W
R3081 401 105 0603 MT-GLAZE 10K JA 1/16W
R3082 401 105 0603 MT-GLAZE 10K JA 1/16W
R3085 401 105 0504 MT-GLAZE 1K JA 1/16W
R3087 401 105 0603 MT-GLAZE 10K JA 1/16W
R3089 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3249 401 105 0603 MT-GLAZE 10K JA 1/16W
R3250 401 105 2607 MT-GLAZE 22 JA 1/16W
R3251 401 105 8005 MT-GLAZE 1M JA 1/16W
R3252 401 113 4204 MT-GLAZE 51 JA 1/16W
R3253 401 113 4204 MT-GLAZE 51 JA 1/16W
R3254 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R3255 401 113 4204 MT-GLAZE 51 JA 1/16W
R3256 401 113 4204 MT-GLAZE 51 JA 1/16W
R3257 401 105 0504 MT-GLAZE 1K JA 1/16W
R3258 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3259 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3260 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3261 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R3262 401 105 0603 MT-GLAZE 10K JA 1/16W
R3263 401 105 0603 MT-GLAZE 10K JA 1/16W
R3264 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3301 401 105 0603 MT-GLAZE 10K JA 1/16W
R3302 401 105 0603 MT-GLAZE 10K JA 1/16W
R3303 401 105 0504 MT-GLAZE 1K JA 1/16W
R3305 401 105 0603 MT-GLAZE 10K JA 1/16W
R3306 401 105 0603 MT-GLAZE 10K JA 1/16W
R3307 401 105 0504 MT-GLAZE 1K JA 1/16W
R3309 401 105 0603 MT-GLAZE 10K JA 1/16W
R3310 401 105 0603 MT-GLAZE 10K JA 1/16W
R3311 401 105 0504 MT-GLAZE 1K JA 1/16W
R3312 401 146 5100 MT-GLAZE 1K JA 1/4W
R3313 401 146 5100 MT-GLAZE 1K JA 1/4W
R3314 401 105 0603 MT-GLAZE 10K JA 1/16W
R3315 401 105 0603 MT-GLAZE 10K JA 1/16W
R3317 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3318 401 105 0603 MT-GLAZE 10K JA 1/16W
R3319 401 105 0603 MT-GLAZE 10K JA 1/16W
R3321 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3322 401 105 0603 MT-GLAZE 10K JA 1/16W
R3323 401 105 0603 MT-GLAZE 10K JA 1/16W
R3325 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3326 401 105 0603 MT-GLAZE 10K JA 1/16W
R3327 401 105 0603 MT-GLAZE 10K JA 1/16W
R3328 401 105 0603 MT-GLAZE 10K JA 1/16W
R3329 401 105 0603 MT-GLAZE 10K JA 1/16W
R3330 401 105 0603 MT-GLAZE 10K JA 1/16W
R3331 401 105 0603 MT-GLAZE 10K JA 1/16W
R3332 401 188 1108 MT-GLAZE 300 JA 1/4W
R3333 401 188 2907 MT-GLAZE 68 JA 1/4W
R3334 401 188 2907 MT-GLAZE 68 JA 1/4W
R3335 401 166 9904 MT-FILM 6.8K DU 1/16W
R3336 401 166 5906 MT-FILM 120 DU 1/16W
R3337 401 167 1105 MT-FILM 24K DU 1/16W
R3338 401 105 0504 MT-GLAZE 1K JA 1/16W
R3400 401 105 0504 MT-GLAZE 1K JA 1/16W
R3401 401 105 0504 MT-GLAZE 1K JA 1/16W
R3402 401 037 5004 MT-GLAZE 0.000 ZA 1/10W
R3410 401 105 2706 MT-GLAZE 220 JA 1/16W
R3413 401 105 4502 MT-GLAZE 390 JA 1/16W
R3415 401 105 0603 MT-GLAZE 10K JA 1/16W
R3417 401 105 1105 MT-GLAZE 12K JA 1/16W
R3418 401 105 0405 MT-GLAZE 100 JA 1/16W
R3419 401 105 1105 MT-GLAZE 12K JA 1/16W
R3420 401 105 0504 MT-GLAZE 1K JA 1/16W
R3421 401 105 0504 MT-GLAZE 1K JA 1/16W
R3422 401 105 0702 MT-GLAZE 100K JA 1/16W
R3423 401 105 0603 MT-GLAZE 10K JA 1/16W
R3424 401 105 0603 MT-GLAZE 10K JA 1/16W

13
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
R3425 401 105 0603 MT-GLAZE 10K JA 1/16W
R3426 401 105 0504 MT-GLAZE 1K JA 1/16W
R3428 401 105 0504 MT-GLAZE 1K JA 1/16W
R3429 401 105 2003 MT-GLAZE 1.8K JA 1/16W
R3431 401 105 0405 MT-GLAZE 100 JA 1/16W
R3434 401 146 5100 MT-GLAZE 1K JA 1/4W
R3435 401 146 5100 MT-GLAZE 1K JA 1/4W
R3437 401 105 6407 MT-GLAZE 68 JA 1/16W
R3438 401 105 0504 MT-GLAZE 1K JA 1/16W
R3439 401 105 0504 MT-GLAZE 1K JA 1/16W
R3441 401 105 0504 MT-GLAZE 1K JA 1/16W
R3442 401 114 0502 MT-GLAZE 2.2M JA 1/16W
R3443 401 114 0502 MT-GLAZE 2.2M JA 1/16W
R3444 401 105 0603 MT-GLAZE 10K JA 1/16W
R3445 401 105 0603 MT-GLAZE 10K JA 1/16W
R3450 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R3451 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R3452 401 105 0702 MT-GLAZE 100K JA 1/16W
R3453 401 105 2706 MT-GLAZE 220 JA 1/16W
R3454 401 105 7602 MT-GLAZE 820K JA 1/16W
R3455 401 105 0504 MT-GLAZE 1K JA 1/16W
R3456 401 105 0504 MT-GLAZE 1K JA 1/16W
R3457 401 105 0504 MT-GLAZE 1K JA 1/16W
R3458 401 105 0603 MT-GLAZE 10K JA 1/16W
R3459 401 105 0603 MT-GLAZE 10K JA 1/16W
R3460 401 105 0603 MT-GLAZE 10K JA 1/16W
R3470 401 105 8203 MT-GLAZE 68K JA 1/16W
R3471 401 105 0702 MT-GLAZE 100K JA 1/16W
R3472 401 105 0504 MT-GLAZE 1K JA 1/16W
R3473 401 105 2706 MT-GLAZE 220 JA 1/16W
R3474 401 105 3000 MT-GLAZE 220K JA 1/16W
R3475 401 105 0702 MT-GLAZE 100K JA 1/16W
R3476 401 105 5509 MT-GLAZE 470K JA 1/16W
R3477 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R3478 401 105 0504 MT-GLAZE 1K JA 1/16W
R3482 401 105 0504 MT-GLAZE 1K JA 1/16W
R4101 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4102 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4103 401 105 2607 MT-GLAZE 22 JA 1/16W
R4104 401 105 2607 MT-GLAZE 22 JA 1/16W
R4105 401 105 2607 MT-GLAZE 22 JA 1/16W
R4106 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4107 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4108 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4109 401 105 0504 MT-GLAZE 1K JA 1/16W
R4110 401 105 2607 MT-GLAZE 22 JA 1/16W
R4111 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4112 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R4113 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4114 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4115 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4116 401 105 2607 MT-GLAZE 22 JA 1/16W
R4117 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4118 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4119 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4120 401 105 0504 MT-GLAZE 1K JA 1/16W
R4121 401 105 2607 MT-GLAZE 22 JA 1/16W
R4122 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4123 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4124 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4125 401 105 2607 MT-GLAZE 22 JA 1/16W
R4126 401 105 2607 MT-GLAZE 22 JA 1/16W
R4127 401 105 2607 MT-GLAZE 22 JA 1/16W
R4128 401 105 2607 MT-GLAZE 22 JA 1/16W
R4129 401 105 2607 MT-GLAZE 22 JA 1/16W
R4130 401 105 2607 MT-GLAZE 22 JA 1/16W
R4131 401 105 2607 MT-GLAZE 22 JA 1/16W
R4132 401 105 2607 MT-GLAZE 22 JA 1/16W
R4133 401 105 0504 MT-GLAZE 1K JA 1/16W
R4134 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R4135 401 105 0603 MT-GLAZE 10K JA 1/16W
R4136 401 105 0504 MT-GLAZE 1K JA 1/16W
R4137 401 105 0504 MT-GLAZE 1K JA 1/16W
R4138 401 105 0504 MT-GLAZE 1K JA 1/16W
R4139 401 105 0603 MT-GLAZE 10K JA 1/16W
R4140 401 105 0603 MT-GLAZE 10K JA 1/16W
R4141 401 105 2607 MT-GLAZE 22 JA 1/16W
R4142 401 105 2607 MT-GLAZE 22 JA 1/16W
R4143 401 105 2607 MT-GLAZE 22 JA 1/16W
R4201 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4202 401 105 0603 MT-GLAZE 10K JA 1/16W
R4203 401 105 0603 MT-GLAZE 10K JA 1/16W
R4204 401 105 0603 MT-GLAZE 10K JA 1/16W
R4205 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4206 401 105 0603 MT-GLAZE 10K JA 1/16W
R4207 401 105 0504 MT-GLAZE 1K JA 1/16W
R4208 401 105 0603 MT-GLAZE 10K JA 1/16W
R4209 401 105 0603 MT-GLAZE 10K JA 1/16W
R4210 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4211 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4212 401 105 0504 MT-GLAZE 1K JA 1/16W
R4213 401 105 0603 MT-GLAZE 10K JA 1/16W
R4214 401 105 0603 MT-GLAZE 10K JA 1/16W
R4215 401 105 0603 MT-GLAZE 10K JA 1/16W
R4216 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4217 401 105 0504 MT-GLAZE 1K JA 1/16W
R4218 401 105 0603 MT-GLAZE 10K JA 1/16W
R4219 401 105 5400 MT-GLAZE 47K JA 1/16W
R4220 401 105 0603 MT-GLAZE 10K JA 1/16W
R4221 401 105 0603 MT-GLAZE 10K JA 1/16W
R4222 401 105 0603 MT-GLAZE 10K JA 1/16W
R4223 401 105 0306 MT-GLAZE 10 JA 1/16W
R4224 401 105 0603 MT-GLAZE 10K JA 1/16W
R4225 401 105 0603 MT-GLAZE 10K JA 1/16W
R4226 401 105 0603 MT-GLAZE 10K JA 1/16W
R4227 401 105 0603 MT-GLAZE 10K JA 1/16W
R4228 401 105 0603 MT-GLAZE 10K JA 1/16W
R4229 401 105 0603 MT-GLAZE 10K JA 1/16W
R4230 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4231 401 105 0603 MT-GLAZE 10K JA 1/16W
R4232 401 105 0603 MT-GLAZE 10K JA 1/16W
R4233 401 105 0306 MT-GLAZE 10 JA 1/16W
R4234 401 105 0603 MT-GLAZE 10K JA 1/16W
R4235 401 105 0603 MT-GLAZE 10K JA 1/16W
R4236 401 105 0603 MT-GLAZE 10K JA 1/16W
R4237 401 105 0603 MT-GLAZE 10K JA 1/16W
R4238 401 105 0603 MT-GLAZE 10K JA 1/16W
R4239 401 105 0504 MT-GLAZE 1K JA 1/16W
R4240 401 105 0603 MT-GLAZE 10K JA 1/16W
R4241 401 105 0603 MT-GLAZE 10K JA 1/16W
R4242 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4243 401 105 0603 MT-GLAZE 10K JA 1/16W
R4244 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4245 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4246 401 105 0504 MT-GLAZE 1K JA 1/16W
R4247 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4248 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4249 401 105 0504 MT-GLAZE 1K JA 1/16W
R4250 401 105 0504 MT-GLAZE 1K JA 1/16W
R4251 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4252 401 105 0603 MT-GLAZE 10K JA 1/16W
R4253 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4254 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4255 401 105 0603 MT-GLAZE 10K JA 1/16W
R4256 401 105 1600 MT-GLAZE 15K JA 1/16W
R4257 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4258 401 105 0504 MT-GLAZE 1K JA 1/16W
R4259 401 105 0603 MT-GLAZE 10K JA 1/16W
R4260 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4261 401 105 0603 MT-GLAZE 10K JA 1/16W
R4262 401 105 0504 MT-GLAZE 1K JA 1/16W
R4263 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4264 401 105 0603 MT-GLAZE 10K JA 1/16W
R4265 401 105 0603 MT-GLAZE 10K JA 1/16W
R4266 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4267 401 105 5400 MT-GLAZE 47K JA 1/16W
R4268 401 105 0603 MT-GLAZE 10K JA 1/16W
R4269 401 105 0603 MT-GLAZE 10K JA 1/16W
R4270 401 105 0504 MT-GLAZE 1K JA 1/16W
R4271 401 105 0603 MT-GLAZE 10K JA 1/16W
R4272 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4273 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4274 401 105 0603 MT-GLAZE 10K JA 1/16W
R4275 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4276 401 105 0603 MT-GLAZE 10K JA 1/16W
R4277 401 105 5301 MT-GLAZE 4.7K JA 1/16W

14
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
R4278 401 105 0504 MT-GLAZE 1K JA 1/16W
R4279 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4280 401 105 5400 MT-GLAZE 47K JA 1/16W
R4281 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4282 401 105 1600 MT-GLAZE 15K JA 1/16W
R4283 401 105 0504 MT-GLAZE 1K JA 1/16W
R4284 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4285 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4286 401 105 0603 MT-GLAZE 10K JA 1/16W
R4287 401 105 0603 MT-GLAZE 10K JA 1/16W
R4288 401 105 0603 MT-GLAZE 10K JA 1/16W
R4289 401 105 0603 MT-GLAZE 10K JA 1/16W
R4290 401 105 0603 MT-GLAZE 10K JA 1/16W
R4291 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4292 401 105 0504 MT-GLAZE 1K JA 1/16W
R4401 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4402 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4403 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4404 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4405 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4406 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4501 401 105 2607 MT-GLAZE 22 JA 1/16W
R4502 401 105 0603 MT-GLAZE 10K JA 1/16W
R4503 401 105 0603 MT-GLAZE 10K JA 1/16W
R4504 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4505 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4506 401 105 0504 MT-GLAZE 1K JA 1/16W
R4507 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4508 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4509 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4510 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4511 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4512 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4513 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R4514 401 158 4108 MT-GLAZE 4.7 JA 1/16W
R4515 401 105 0603 MT-GLAZE 10K JA 1/16W
R4516 401 105 2607 MT-GLAZE 22 JA 1/16W
R4517 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4518 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4519 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4520 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4521 401 105 0603 MT-GLAZE 10K JA 1/16W
R4522 401 105 0603 MT-GLAZE 10K JA 1/16W
R4523 401 105 0603 MT-GLAZE 10K JA 1/16W
R4524 401 105 0603 MT-GLAZE 10K JA 1/16W
R4525 401 105 2607 MT-GLAZE 22 JA 1/16W
R4526 401 105 2607 MT-GLAZE 22 JA 1/16W
R4527 401 105 0603 MT-GLAZE 10K JA 1/16W
R4528 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4529 401 105 0603 MT-GLAZE 10K JA 1/16W
R4530 401 105 8005 MT-GLAZE 1M JA 1/16W
R4531 401 105 0603 MT-GLAZE 10K JA 1/16W
R4532 401 105 2607 MT-GLAZE 22 JA 1/16W
R4533 401 105 2607 MT-GLAZE 22 JA 1/16W
R4534 401 105 2607 MT-GLAZE 22 JA 1/16W
R4542 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4543 401 105 2607 MT-GLAZE 22 JA 1/16W
R4601 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4602 401 105 2607 MT-GLAZE 22 JA 1/16W
R4603 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R4605 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4606 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4610 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R4611 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
(CONNECTORS)
CN101 645 051 0670 PLUG,PWB 40P (N.S.P)
CN102 645 029 6352 PLUG,7P (N.S.P)
CN301 645 029 6406 PULG,12P (N.S.P)
CN302 645 029 6383 PLUG,10P (N.S.P)
CN303 645 049 3829 SOCKET,FPC 7P (N.S.P)
CN305 645 049 4055 SOCKET,FPC 30P (N.S.P)
CN309 645 029 6321 PLUG,4P (N.S.P)
CN310 645 029 6369 PLUG,8P (N.S.P)
(MISCELLANEOUS)
613 118 4886 HOLDER, Y3001,Y3002
Y3003 645 006 4425 FIXER
Y3004 645 008 8070 FIXER
COMPL PWB,OP-1
613 200 1663
(SEMICONDUCTORS)
Q8801 405 110 4007 TR 2SK1847
Q8861 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q8881 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
(INTEGRATED CIRCUITS)
IC881 409 346 2301 IC BU2090F
IC882 409 495 2009 IC LM3525MX
(DIODES)
D8801 407 229 0901 LED SEL6210S-TH10D-RED
D8802 407 229 0901 LED SEL6210S-TH10D-RED
D8803 407 229 0901 LED SEL6210S-TH10D-RED
D8804 407 230 5100 LED SEL6910ATH10D
D8805 407 229 0901 LED SEL6210S-TH10D-RED
D8806 407 229 0901 LED SEL6210S-TH10D-RED
D8807 407 229 0901 LED SEL6210S-TH10D-RED
D8808 407 229 0901 LED SEL6210S-TH10D-RED
D8809 407 229 0901 LED SEL6210S-TH10D-RED
D8810 407 229 0901 LED SEL6210S-TH10D-RED
D8811 407 230 5100 LED SEL6910ATH10D
(INDUCTORS)
L8851 645 008 7400 CORE,BEAD
L8852 645 008 7400 CORE,BEAD
L8853 645 008 7400 CORE,BEAD
L8861 645 001 4581 INDUCTOR,100U K
OR 645 003 7924 INDUCTOR,100U K
(CAPACITORS)
C8801 403 139 1007 ELECT 47U M 6.3V
C8802 403 164 0204 CERAMIC 0.1U Z 25V
C8851 403 139 1007 ELECT 47U M 6.3V
C8852 403 164 0204 CERAMIC 0.1U Z 25V
C8853 403 164 0204 CERAMIC 0.1U Z 25V
C8854 403 139 1007 ELECT 47U M 6.3V
C8861 403 139 3100 ELECT 4.7U M 50V
C8862 403 164 0204 CERAMIC 0.1U Z 25V
(BUZZER)
BZ861 419 002 7700 PIEZO BUZZER HAS-RP2-14
(RESISTORS)
R8801 401 105 2706 MT-GLAZE 220 JA 1/16W
R8802 401 105 2706 MT-GLAZE 220 JA 1/16W
R8803 401 113 5102 MT-GLAZE 300 JA 1/16W
R8804 401 113 5201 MT-GLAZE 360 JA 1/16W
R8805 401 105 5202 MT-GLAZE 470 JA 1/16W
R8806 401 105 6506 MT-GLAZE 680 JA 1/16W
R8807 401 105 7305 MT-GLAZE 820 JA 1/16W
R8808 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R8809 401 105 2003 MT-GLAZE 1.8K JA 1/16W
R8810 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R8811 401 105 4106 MT-GALZE 3.3K JA 1/16W
R8812 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R8813 401 113 6604 MT-GLAZE 7.5K JA 1/16W
R8814 401 113 6901 MT-GLAZE 13K JA 1/16W
R8821 401 105 4007 MT-GLAZE 330 JA 1/16W
R8822 401 105 4007 MT-GLAZE 330 JA 1/16W
R8823 401 105 4007 MT-GLAZE 330 JA 1/16W
R8824 401 105 4007 MT-GLAZE 330 JA 1/16W
R8825 401 105 4007 MT-GLAZE 330 JA 1/16W
R8826 401 105 4007 MT-GLAZE 330 JA 1/16W
R8827 401 105 4007 MT-GLAZE 330 JA 1/16W
R8828 401 105 4007 MT-GLAZE 330 JA 1/16W
R8829 401 105 4007 MT-GLAZE 330 JA 1/16W
R8830 401 105 4007 MT-GLAZE 330 JA 1/16W
R8831 401 105 4007 MT-GLAZE 330 JA 1/16W
R8832 401 105 5905 MT-GLAZE 560 JA 1/16W
R8833 401 105 5905 MT-GLAZE 560 JA 1/16W
R8851 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R8852 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R8861 401 105 0603 MT-GLAZE 10K JA 1/16W
R8862 401 105 0702 MT-GLAZE 100K JA 1/16W
R8863 401 105 0504 MT-GLAZE 1K JA 1/16W
R8871 401 105 0504 MT-GLAZE 1K JA 1/16W

15
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
R8881 401 105 5400 MT-GLAZE 47K JA 1/16W
R8882 401 105 5400 MT-GLAZE 47K JA 1/16W
(SWITCHES)
S8801 645 008 8049 SWITCH,PUSH 1P-1T
S8802 645 008 8049 SWITCH,PUSH 1P-1T
S8803 645 008 8049 SWITCH,PUSH 1P-1T
S8804 645 008 8049 SWITCH,PUSH 1P-1T
S8805 645 008 8049 SWITCH,PUSH 1P-1T
S8806 645 008 8049 SWITCH,PUSH 1P-1T
S8808 645 008 8049 SWITCH,PUSH 1P-1T
S8809 645 008 8049 SWITCH,PUSH 1P-1T
S8810 645 008 8049 SWITCH,PUSH 1P-1T
S8812 645 008 8049 SWITCH,PUSH 1P-1T
S8813 645 008 8049 SWITCH,PUSH 1P-1T
S8814 645 008 8049 SWITCH,PUSH 1P-1T
(JACK)
JK882 645 056 7377 SOCKET,USB 4P
(CONNECTORS)
CN881 645 049 7872 SOCKET,FPC 7P (N.S.P)
CN883 613 199 6243 ASSY,WIRE (N.S.P)
(MISCELLANEOUS)
Y8801 613 199 4881 HOLDER USB
Y8802 411 021 6207 SCR S-TPG BIN 3X8
645 058 3285 FIXER PWB(H=5)
COMPL PWB,PW-1
613 200 1687
(VARISTORS)
VA501 407 212 9201 VARISTOR ENE471D-14A
OR 407 130 2902 VARISTOR ENC471D-14A
(SEMICONDUCTORS)
Q5010 405 164 9508 TR SPP11N60C2
Q5011 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q5101 405 151 2208 TR FW232
OR 405 167 3503 TR FY7ACH-03A
Q5102 405 151 2208 TR FW232
OR 405 167 3503 TR FY7ACH-03A
Q5104 405 132 3101 TR DTC114EKA
Q5105 405 132 3101 TR DTC114EKA
Q5106 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q5181 405 138 6700 TR DTC144EKA
(INTEGRATED CIRCUITS)
IC501 409 543 4504 IC FA3641N-TE1
IC502 409 067 7203 IC L5431
IC511 409 476 7405 IC LTC1628CG
IC512 409 067 7203 IC L5431
IC513 409 544 6606 IC SI-3012KS-TL
IC515 409 543 8007 IC SI-3033C
(DIODES)
D5001 407 005 5908 DIODE D3SB60
D5011 407 005 8701 DIODE ERA15-02
D5012 407 005 8701 DIODE ERA15-02
D5014 407 190 6902 PHOTO COUPLE PS2561L1-1
OR 407 219 8207 PHOTO COUPLE SFH615AGRX16
D5015 407 211 1404 DIODE D1NL20U
OR 407 100 6909 DIODE AG01
D5016 408 038 0908 ZENER DIODE 1.5KE150A
D5017 407 091 6704 DIODE AP01C
D5018 407 078 2705 DIODE 1SS244
D5019 407 190 6902 PHOTO COUPLE PS2561L1-1
OR 407 219 8207 PHOTO COUPLE SFH615AGRX16
D5021 407 099 6607 ZENER DIODE MTZJ12B
D5023 407 078 2705 DIODE 1SS244
D5025 407 099 7901 ZENER DIODE MTZJ20B
D5101 407 226 2007 DIODE DF30JC10
D5102 408 038 5309 DIODE ERC81-004J11
OR 408 041 9301 DIODE ERC81-004L37
D5103 407 063 9207 ZENER DIODE MTZJ7.5B
D5104 407 160 9100 DIODE ERA83-004
OR 407 120 5807 DIODE AK04
D5105 407 150 7703 DIODE RB441Q
D5106 407 150 7703 DIODE RB441Q
D5107 407 160 9100 DIODE ERA83-004
OR 407 120 5807 DIODE AK04
D5109 407 099 5402 ZENER DIODE MTZJ6.2B
D5110 407 120 6309 ZENER DIODE MTZJ3.3A
D5111 407 078 2705 DIODE 1SS244
D5112 407 169 5707 DIODE RL2Z-LF-C4
(INDUCTORS)
L5001 645 049 9777 LINE FILTER
L5101 645 011 6957 INDUCTOR,10U
L5102 645 006 3602 INDUCTOR,1.1UH
OR 645 024 3417 INDUCTOR,2.0UH
L5103 645 052 2918 INDUCTOR,6.8U M
L5104 645 052 2918 INDUCTOR,6.8U M
L5105 645 006 3602 INDUCTOR,1.1UH
OR 645 024 3417 INDUCTOR,2.0UH
L5106 645 006 3602 INDUCTOR,1.1UH
OR 645 024 3417 INDUCTOR,2.0UH
(TRANSFORMER)
T5001 645 047 7485 TRANS,POWER,PULSE
(CAPACITORS)
C5001 404 083 9903 MT-POLYEST 0.22U M 250V
C5002 404 074 1701 CERAMIC 2200P M 250V
C5003 404 083 9903 MT-POLYEST 0.22U M 250V
C5007 403 164 0204 CERAMIC 0.1U Z 25V
C5008 404 074 1602 CERAMIC 1000P M 250V
C5010 403 370 5000 ELECT 180U M 400V
C5014 403 066 8407 MT-POLYEST 0.1U M 400V
C5016 403 381 3606 ELECT 10U M 63V
C5017 403 374 8007 CERAMIC 3300P K 630V
C5018 403 374 7901 CERAMIC 100P K 1K
C5019 403 057 3107 POLYESTER 0.1U K 50V
C5020 403 057 3107 POLYESTER 0.1U K 50V
C5021 403 164 0204 CERAMIC 0.1U Z 25V
C5022 403 157 3601 CERAMIC 100P J 50V
C5023 404 088 2008 CERAMIC 330P K 250V
C5024 403 164 0204 CERAMIC 0.1U Z 25V
C5025 404 074 1602 CERAMIC 1000P M 250V
C5026 403 304 9005 ELECT 10U M 50V
C5028 403 274 9708 POLYESTER 0.22U K 50V
C5101 403 370 4607 ELECT 820U M 25V
C5102 403 370 4607 ELECT 820U M 25V
C5103 403 360 7601 ELECT 1000U M 10V
C5105 403 370 4607 ELECT 820U M 25V
C5106 403 057 3107 POLYESTER 0.1U K 50V
C5107 403 075 7101 CERAMIC 1000P K 500V
C5108 403 075 7101 CERAMIC 1000P K 500V
C5109 403 164 0204 CERAMIC 0.1U Z 25V
C5110 403 157 2505 CERAMIC 27P J 50V
C5111 403 113 3805 CERAMIC 1000P K 50V
C5112 403 215 2201 CERAMIC 0.01U K 50V
C5113 403 155 1609 CERAMIC 33P J 50V
C5114 403 157 4202 CERAMIC 220P J 50V
C5115 403 155 1609 CERAMIC 33P J 50V
C5116 403 157 4202 CERAMIC 220P J 50V
C5117 403 157 2505 CERAMIC 27P J 50V
C5118 403 113 3805 CERAMIC 1000P K 50V
C5119 403 164 0204 CERAMIC 0.1U Z 25V
C5120 403 057 3107 POLYESTER 0.1U K 50V
C5121 403 057 3107 POLYESTER 0.1U K 50V
C5122 403 370 4607 ELECT 820U M 25V
C5123 403 364 1704 OS-SOLID 470U M 6.3V
C5124 403 364 1704 OS-SOLID 470U M 6.3V
C5126 403 301 1200 ELECT 22U M 50V
C5127 403 057 3107 POLYESTER 0.1U K 50V
C5128 403 164 0204 CERAMIC 0.1U Z 25V
C5129 403 164 0204 CERAMIC 0.1U Z 25V
C5130 403 164 0204 CERAMIC 0.1U Z 25V
C5131 403 359 1405 ELECT 22U M 50V
C5134 403 360 7601 ELECT 1000U M 10V
C5136 403 360 7601 ELECT 1000U M 10V
C5137 403 380 8800 ELECT 100U M 6.3V
C5138 403 313 6606 ELECT 47U M 16V
C5139 403 359 1009 ELECT 470U M 25V
C5140 403 283 6309 CERAMIC 1U Z 10V
C5143 403 215 2201 CERAMIC 0.01U K 50V
C5147 403 359 1009 ELECT 470U M 25V
C5148 403 164 0204 CERAMIC 0.1U Z 25V
C5150 403 164 0204 CERAMIC 0.1U Z 25V
C5151 403 164 0204 CERAMIC 0.1U Z 25V
C5152 403 164 0204 CERAMIC 0.1U Z 25V

16
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C5153 403 164 0204 CERAMIC 0.1U Z 25V
C5155 403 164 0204 CERAMIC 0.1U Z 25V
C5156 403 164 0204 CERAMIC 0.1U Z 25V
C5157 403 359 1009 ELECT 470U M 25V
C5159 403 283 6309 CERAMIC 1U Z 10V
(RESISTORS)
R5001 402 069 0401 SOLID 2.7M KA 1/2W
R5010 401 105 1600 MT-GLAZE 15K JA 1/16W
R5012 401 105 1105 MT-GLAZE 12K JA 1/16W
R5013 401 064 7309 OXIDE-MT 100 JA 2W
R5014 401 064 7309 OXIDE-MT 100 JA 2W
R5015 401 105 3901 MT-GLAZE 33 JA 1/16W
R5016 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R5017 401 113 5003 MT-GLAZE 240 JA 1/16W
R5018 402 088 4701 FUSIBLE RES 0.1K 0.25W
R5019 401 105 1006 MT-GLAZE 1.2K JA 1/16W
R5020 401 105 3000 MT-GLAZE 220K JA 1/16W
R5021 401 105 4700 MT-GLAZE 39K JA 1/16W
R5022 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R5026 401 105 2904 MT-GLAZE 22K JA 1/16W
R5027 401 113 5003 MT-GLAZE 240 JA 1/16W
R5028 401 105 2904 MT-GLAZE 22K JA 1/16W
R5030 401 105 3406 MT-GLAZE 27K JA 1/16W
R5031 401 105 3406 MT-GLAZE 27K JA 1/16W
R5032 401 105 3406 MT-GLAZE 27K JA 1/16W
R5033 401 105 3406 MT-GLAZE 27K JA 1/16W
R5034 401 105 3406 MT-GLAZE 27K JA 1/16W
R5035 401 105 3406 MT-GLAZE 27K JA 1/16W
R5036 401 105 3406 MT-GLAZE 27K JA 1/16W
R5037 401 105 3406 MT-GLAZE 27K JA 1/16W
R5038 401 105 3406 MT-GLAZE 27K JA 1/16W
R5039 401 105 3406 MT-GLAZE 27K JA 1/16W
R5040 401 105 4205 MT-GLAZE 33K JA 1/16W
R5041 401 105 4205 MT-GLAZE 33K JA 1/16W
R5042 401 105 4205 MT-GLAZE 33K JA 1/16W
R5043 401 105 4205 MT-GLAZE 33K JA 1/16W
R5044 401 105 4205 MT-GLAZE 33K JA 1/16W
R5045 401 105 4205 MT-GLAZE 33K JA 1/16W
R5046 401 105 4205 MT-GLAZE 33K JA 1/16W
R5047 401 105 4205 MT-GLAZE 33K JA 1/16W
R5048 401 105 4205 MT-GLAZE 33K JA 1/16W
R5049 401 105 4205 MT-GLAZE 33K JA 1/16W
R5050 401 105 4205 MT-GLAZE 33K JA 1/16W
R5102 401 105 3208 MT-GLAZE 270 JA 1/16W
R5103 401 105 3208 MT-GLAZE 270 JA 1/16W
R5104 401 166 7900 MT-FILM 820 DU 1/16W
R5105 401 167 0108 MT-FILM 8.2K DU 1/16W
R5106 401 105 4106 MT-GALZE 3.3K JA 1/16W
R5107 401 166 8808 MT-FILM 2.2K DU 1/16W
R5108 401 167 2508 MT-FILM 100K DD 1/16W
R5109 401 167 1006 MT-FILM 20K DU 1/16W
R5110 401 105 1600 MT-GLAZE 15K JA 1/16W
R5111 401 105 1600 MT-GLAZE 15K JA 1/16W
R5112 401 167 1006 MT-FILM 20K DU 1/16W
R5113 401 166 3209 MT-FILM 39K DD 1/16W
R5115 401 302 3803 MT-FILM 0.015 JE 1W
R5116 401 105 0306 MT-GLAZE 10 JA 1/16W
R5117 401 302 3803 MT-FILM 0.015 JE 1W
R5123 401 167 0207 MT-FILM 9.1K DU 1/16W
R5125 401 167 2102 MT-FILM 68K DD 1/16W
R5126 401 167 1105 MT-FILM 24K DU 1/16W
R5132 401 166 9904 MT-FILM 6.8K DU 1/16W
R5133 401 166 9607 MT-FILM 5.1K DU 1/16W
R5137 401 105 0603 MT-GLAZE 10K JA 1/16W
R5138 401 105 0603 MT-GLAZE 10K JA 1/16W
R5139 401 105 6506 MT-GLAZE 680 JA 1/16W
R5181 401 105 1600 MT-GLAZE 15K JA 1/16W
(THERMISTOR)
TH501 407 230 1904 THERMISTOR NTPAA5R1LDNB0
(FUSE)
F5001 423 030 2705 FUSE 250V 2A
(CONNECTORS)
CN501 645 005 9315 PLUG,2P
CN510 645 005 7373 PLUG,3P (N.S.P)
CN511 645 003 2882 PLUG,4P (N.S.P)
CN512 613 199 6229 ASSY,WIRE (N.S.P)
CN515 613 199 6236 ASSY,WIRE (N.S.P)
(MISCELLANEOUS)
645 008 7677 HOLDER,FUSE,F5001 ,Y5003,Y5004
OR 645 008 7660 HOLDER,FUSE,F5001 ,Y5003,Y5004
OR 645 016 0479 HOLDER,FUSE,F5001 ,Y5003,Y5004
Y5017 411 046 8507 SCR PAN+SW+W 3X10
Y5025 645 021 3793 SPACER
613 118 4886 HOLDER,Y5021,Y5022,Y5023,Y5024
613 053 8000 FIXER,Y5030,Y5031,Y5032
COMPL PWB,TB-1
613 200 1649
(VARISTORS)
VA852 408 048 7300 VARISTOR DSAA-P0300SA
VA854 408 048 7300 VARISTOR DSAA-P0300SA
VA855 645 045 7449 SURGE-ABSORBER
VA856 645 045 7449 SURGE-ABSORBER
VA857 645 045 7449 SURGE-ABSORBER
VA860 645 045 7449 SURGE-ABSORBER
VA861 645 045 7449 SURGE-ABSORBER
VA863 645 045 7449 SURGE-ABSORBER
(SEMICONDUCTORS)
Q8541 405 080 4601 TR 2SC3808
Q8561 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q8562 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
Q8563 405 014 4400 TR 2SC2412K-Q
OR 405 014 4509 TR 2SC2412K-R
OR 405 014 4608 TR 2SC2412K-S
(INTEGRATED CIRCUIT)
IC852 409 084 0409 IC LA6458M
(DIODES)
D8531 407 099 7000 ZENER DIODE MTZJ15B
OR 407 099 7109 ZENER DIODE MTZJ15C
OR 407 099 6904 ZENER DIODE MTZJ15A
D8565 407 012 4406 DIODE 1SS133
D8566 407 012 4406 DIODE 1SS133
(INDUCTORS)
L8541 645 020 1868 INDUCTOR,750 OHM
L8542 645 006 3602 INDUCTOR,1.1UH
L8543 645 020 1868 INDUCTOR,750 OHM
L8544 645 020 1868 INDUCTOR,750 OHM
L8545 645 020 1868 INDUCTOR,750 OHM
L8546 645 020 1868 INDUCTOR,750 OHM
L8547 645 006 3602 INDUCTOR,1.1UH
L8548 645 020 1868 INDUCTOR,750 OHM
L8549 645 020 1868 INDUCTOR,750 OHM
L8550 645 020 1868 INDUCTOR,750 OHM
L8561 645 006 3602 INDUCTOR,1.1UH
(CAPACITORS)
C8531 403 189 2405 ELECT 10U M 16V
C8532 403 366 7605 CERAMIC 1000P J 25V
C8533 403 157 3601 CERAMIC 100P J 50V
C8534 403 163 7907 ELECT 47U M 6.3V
C8535 403 189 2405 ELECT 10U M 16V
C8536 403 189 2405 ELECT 10U M 16V
C8537 403 164 0204 CERAMIC 0.1U Z 25V
C8539 403 189 2405 ELECT 10U M 16V
C8555 403 298 9609 CERAMIC 0.1U K 16V
C8561 403 189 2405 ELECT 10U M 16V
C8562 403 189 2405 ELECT 10U M 16V
C8565 403 191 8709 ELECT 1U M 50V
C8566 403 189 2405 ELECT 10U M 16V
(RESISTORS)
R8501 401 113 4402 MT-GLAZE 75 JA 1/16W
R8502 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R8521 401 105 3406 MT-GLAZE 27K JA 1/16W
R8531 401 105 0603 MT-GLAZE 10K JA 1/16W
R8532 401 105 0603 MT-GLAZE 10K JA 1/16W
R8533 401 105 0603 MT-GLAZE 10K JA 1/16W
R8534 401 105 0603 MT-GLAZE 10K JA 1/16W
R8535 401 105 0702 MT-GLAZE 100K JA 1/16W
R8536 401 105 0405 MT-GLAZE 100 JA 1/16W

17
LOCATION PARTS NO. DESCRIPTION
R8537 401 105 4700 MT-GLAZE 39K JA 1/16W
R8541 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R8542 401 105 0504 MT-GLAZE 1K JA 1/16W
R8543 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R8544 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R8545 401 105 0504 MT-GLAZE 1K JA 1/16W
R8546 401 105 0504 MT-GLAZE 1K JA 1/16W
R8547 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R8548 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R8549 401 012 5609 CARBON 1K JA 1/4W
R8550 401 013 4106 CARBON 120 JA 1/4W
R8555 401 113 4402 MT-GLAZE 75 JA 1/16W
R8556 401 113 4402 MT-GLAZE 75 JA 1/16W
R8557 401 113 4402 MT-GLAZE 75 JA 1/16W
R8558 401 113 4402 MT-GLAZE 75 JA 1/16W
R8561 401 105 7503 MT-GLAZE 82K JA 1/16W
R8562 401 105 0603 MT-GLAZE 10K JA 1/16W
R8563 401 105 0702 MT-GLAZE 100K JA 1/16W
R8564 401 105 0405 MT-GLAZE 100 JA 1/16W
R8565 401 114 0908 MT-GLAZE 3.3M JA 1/16W
R8566 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R8567 401 105 0405 MT-GLAZE 100 JA 1/16W
R8568 401 105 0405 MT-GLAZE 100 JA 1/16W
R8569 401 114 0908 MT-GLAZE 3.3M JA 1/16W
R8571 401 105 2409 MT-GLAZE 2K JA 1/16W
R8572 401 105 2409 MT-GLAZE 2K JA 1/16W
R8573 401 105 2409 MT-GLAZE 2K JA 1/16W
(SWITCHES)
S8501 645 023 3883 SWITCH,DIP 1P-1TX10
S8502 645 008 8049 SWITCH,PUSH 1P-1T
S8503 645 057 9370 SWITCH,SLIDE 1P-2T
(JACKS)
JK851 645 000 3943 SOCKET,BNC 2P
JK852 645 051 8911 JACK,RCA-2
JK853 645 009 8741 JACK,PHONE D3.6, MIC-JACK
JK854 645 056 1399 TERMINAL 15P
JK855 645 056 1375 JACK,MODULAR 8P
(CONNECTOR)
CN851 645 049 8244 SOCKET,FPC 30P (N.S.P)
(MISCELLANEOUS)
Y8501 613 199 4331 HOLDER,TB-1
FLEXIBLE FLAT CABLE
W0002 613 199 8575 ULTRA ATA CABLE ASSY ,CN101-HDD
W0004 645 058 7757 FLEXIBLE FLAT CABLE ,CN303-CN881
W0005 645 058 7764 FLEXIBLE FLAT CABLE ,CN305-CN851

C1
CIRCUIT DIAGRAMS & PRINTED WIRING BOARDS
TABLE OF CONTENTS
OVERALL WIRING & BLOCK DIAGRAM Page
OVERALL WIRING ................................................................................................................................................ C3
OVERALL BLOCK .................................................................................................................................................. C4
CIRCUIT DIAGRAMS
PW-1 BOARD POWER SUPPLY ......................................................................................................................... C5
CP-1 BOARD (DM-A) MPEG ............................................................................................................................... C6
CP-1 BOARD (DM-B) COMPANION CHIP ........................................................................................................ C11
CP-1 BOARD (DM-C) FLASH MEMORY ........................................................................................................... C16
CP-1 BOARD (DM-D) MIPS CPU ...................................................................................................................... C17
CP-1 BOARD (DM-E) CLOCK GENERATOR .................................................................................................... C18
CP-1 BOARD (DM-F) ENCODER, DECODER .................................................................................................. C19
CP-1 BOARD (DM-G) VCR I/O .......................................................................................................................... C20
CP-1 BOARD (SY-A) SUB UCOM & LAN .......................................................................................................... C21
OP-1 BOARD KEY SWITCH & LED .................................................................................................................. C24
TB-1 BOARD REAR TERMINAL ........................................................................................................................ C25
CIRCUIT WAVEFORMS ..................................................................................................................................... C25
PRINTED WIRING BOARDS (P.W.B.)
CP-1 P.W.B. (SIDE A & B) ................................................................................................................................... C26
PW-1 P.W.B. (SIDE A) ......................................................................................................................................... C31
PW-1 P.W.B. (SIDE B) ......................................................................................................................................... C32
OP-1 P.W.B. ......................................................................................................................................................... C33
TB-1 P.W.B. ......................................................................................................................................................... C34

C2
NOTES:
1. All resistance values in "OHMS" unless otherwise noted.
(K=1,000 ; M=1,000,000)
2. All capacitance values in "µF" unless otherwise noted.
p=pico farad ; µ,u or U=micro farad
3. All inductance values in "µH" unless otherwise noted.
µ,u or U=micro henry ; m=milli henry
PRODUCT SAFETY NOTICE
THE COMPONENTS DESIGNATED BY A SYMBOL ( ) IN THIS
SCHEMATIC DIAGRAM DESIGNATES COMPONENTS WHOSE
VALUE ARE OF SPECIAL SIGNIFICANCE TO PRODUCT SAFETY.
SHOULD ANY COMPONENT DESIGNATED BY A SYMBOL NEED TO
BE REPLACED, USE ONLY THE PART DESIGNATED IN THE PARTS
LIST.
DO NOT DEVIATE FROM THE RESISTANCE, WATTAGE AND VOLT-
AGE RATINGS SHOWN.
PAL-C-EX
EXPLANATORY NOTES (EXAMPLES)
Resistor 10K:1/16J means 10kilo ohm ±5%, 1/16watt max.
1M:1/10K means 1mega ohm ±10%, 1/10watt max.
Capacitor 0.047:F means 0.047micro farad, Ftype.
Electrolytic capacitor
10:16 means 10micro farad, 16volt max.C2C2
Inductor 330:J means 330micro henry ±5%
470:K means 470micro henry ±10%
No description J or K means ±5%

A
B
C
D
E
F
G
H
I
J
K
1 2 3 4 5 6 7 8 9 10111213141516171819
A
B
C
D
E
F
G
H
I
J
K
C3
OVERALL WIRING & BLOCK DIAGRAM OVERALL WIRING
CN101
DM-G
DM-G
SY-A
CN301
CN302CN515
CN512
CN501
CN852
CN883CN102
CN310
CN510
CN305 CN851
CN303 CN881
CN511
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
4040
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
4
3
2
1
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
1010
9
8
7
6
5
4
3
2
1
12
11
10
9
8
7
6
5
4
3
2
1
1
2
1
2
3
4
5
6
7
8
1
2
3
4
5
6
77
6
5
4
3
2
1
8
7
6
5
4
3
2
1
1
2
3
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
7
6
5
4
3
2
1 7
6
5
4
3
2
1
1
2
3
4
RESET
GND
DD7
DD8
DD6
DD9
DD5
DD10
DD4
DD11
DD3
DD12
DD2
DD13
DD1
DD14
DD0
DD15
GND
NC
DMARQ
GND
DI0W
GND
DI0R
GND
IORDY
CSEL
DMACK
GND
INTRQ
OBSOLETE
DA1
PDIAG
DA0
DA2
CS0
CS1
DASP
GNDGND
DASP
CS1
CS0
DA2
DA0
PDIAG
DA1
OBSOLETE
INTRQ
OPTION
GND
DMACK
CSEL
IORDY
GND
DI0R
GND
DI0W
GND
DMARQ
NC
GND
DD15
DD0
DD14
DD1
DD13
DD2
DD12
DD3
DD11
DD4
DD10
DD5
DD9
DD6
DD8
DD7
GND
RESET
AL5V
GND
GND
AL12V
AL12V
AL2.5V
AL2.5V
AL2.5V
GND
GND
GND
GND
AL3.3V
AL3.3V
AL3.3V
AL3.3V
AL5V
AL5V
GND
GND
AL5.4V
AL5.4V
GND
POWER FAIL
GND
FAN INSENSOR
GND
POWER FAIL
GND
AL5.4V
AL5.4V
GND
GND
AL5V
AL5V
AL3.3V
AL3.3V
AL3.3V
AL3.3V
GND
GND
GND
GND
AL2.5V
AL2.5V
AL2.5V
AL12V
AC IN(L)
W5001
AC IN(N)
VIDEO IN
GND
VIDEO OUT
GND
AL 12V
AD IN
GND
AD OUT
AL5V
USBPEN
USBDVR
USBDP+
USBDM-
CRX1
GNDGND
CRX1
USBDM-
USBDP+
USBDVR
USBPEN
AL5V
AD OUT
GND
AD IN
AL 12V
GND
VIDEO OUT
GND
VIDEO IN
OP-1
TB-1
PW-1
HDD1
HDD2
FAN
AC IN
CP-1
ASSY WIRE
LENGTH STYLE SIDE STYLE
FLEXIBLE FLAT CABLE
FLEXIBLE FLAT CABLE
LENGTH STYLE SIDE STYLE
LENGTH STYLE
LENGTH STYLE
(WHITE)
BOARD IN
BOARD IN
FAN12V
SENSOR
GND
GND
1
PAL/NTSC
RESET
DISK FULL OUT
WARNING OUT
ALARM OUT
ALARM RESET
ALARM IN
NON REC OUT
CLK SET OUT
CLK SET IN
REMOTE
RS-485B
RS-485A
SW8
SW7
SW6
SW5
SW4
SW3
SW2
SW1
SW0
GND
RX+
RX-
RXC
CMT
TX-
TX+ TX+
TX-
CMT
RXC
RX-
RX+
GND
SW0
SW1
SW2
SW3
SW4
SW5
SW6
SW7
SW8
RS-485A
RS-485B
REMOTE
CLK SET IN
CLK SET OUT
NON REC OUT
ALARM IN
ALARM RESET
ALARM OUT
WARNING OUT
DISK FULL OUT
RESET
GND
30
PAL/NTSC
KEY 1
KEY 2
LED CLK
LED DATA
AL5V
GND
BUZZER BUZZER
GND
AL5V
LED DATA
LED CLK
KEY IN DATA2
KEY IN DATA1
150mm
150mm
150mm
120mm
250mm
300mm
1AC0W31B64600
1AC0W31B64700
1AC0W31B64800
1AC0W31B64900
1AV4W32H29250
1AV4W32H07120
SIDE STYLE
AL12V
GND
GND
AL5V
LENGTH STYLE
LENGTH STYLE
SY-A
DM-A
DM-B
DM-C
DM-D
DM-E
DM-F
DM-G
W1-81057/L8HAC-XE
SY-A
SY-A
SY-A
SY-A
