2600 ANSI LUMENS zTRUE WXGA zULTRA SHORT THROW PROJECTOR
Issued 11/09 ©2009 SANYO
PDG-DWL100
WXGA Ultra Short Throw Projector
SHORT THROW PROJECTION FROM ONLY 34 INCHES AWAY
The PDG-DWL100 can project a full wide WXGA (1280 x 800) 80-inch image from a
distance of only 34 inches from the screen.Teachers can project images on the
blackboard right from their desk. This means large images even in relatively small
rooms. The PDG-DWL100 has an HDMI input terminal which is the most popular
connection for wide aspect ratio projector.
FLEXIBILITY WITH D-SUB15 VGA INPUT AND MONITOR OUT
The PDG-DWL100 offers excellent versatility via 2 D-Sub 15 input/output
terminals. Using an optional adapter cable, the D-Sub 15 input can even accept
component video signals. One of them can be connected and used for monitor
output for greater flexibility.
8-WATT SPEAKER PLUS MANY FEATURES FOR EDUCATION USE
Projectors are increasingly used in more media-rich presentations and are becoming
a truly multi-media device. The PDG-DWL100 has a 8-watt speaker, loud enoughfor
an average classroom or business meeting room. This eliminates the need for a
separate speaker system.
NETWORKING CAPABILITY
The PDG-DWL100 is equipped with SANYO’s exclusive PJ Network Interface for
wired networking, a common feature among SANYO’s extensive line of commercial
projectors. Networking allows the monitoring of projector functions and operation
from a long distance via a web browser. Emails can be sent automatically to report
the operating status.
SPACE SAVING DESIGN
The use of a short-throw lens makes it possible to move the projector from the center
of the classroom or meeting room, to a spot closer to the screen. This frees up more
room space, and cuts down on the possibility of viewers blocking the image with their
shadows.
CLOSED CAPTION
Closed captioning provides the audio portion of a television signal as printed words
on the projected screen - helpful for hearing impaired individuals or audio off
situations.
KEYSTONE CORRECTION
To compensate for keystone (trapezoidal) picture distortion, the PDG-DWL100
provides vertical keystone correction with a correction range up to ±15 degrees.
Specifications
Resolution WXGA (1,280x800)
Brightness (typical) 2,600 ANSI
Panel System 0.65" WXGA DMD
Contrast Ratio (Full on / off) 1750:1
Image Size 46” - 338”
Aspect Ratio 16:10
Projection Lamp 225W UHP
Scanning Frequency H:31.35k-79.98kHz V:50-75Hz
Fan Noise 34dBA / 29dBA (Nomal / Eco)
Voltage 100-240V
Power Consumption 320W / 240W (Nomal / Eco)
Input signal compatibility UXGA / WXGA / SXGA / XGA / SVGA / VGA, 480i / 480p / 575i / 575p / 576i / 576p / 720p /
1080i
/
1080p
Color System PAL / SECAM / NTSC / NTSC4.43 / PAL-M /
PAL-N
Projection Lens (inch) F2.6 f=0.28"
Throw Ratio 0.51:1
Throw Distance (feet) 1.65' - 12.13'
Zoom / Focus Fixed / Manual
Zoom Ratio 1:1
Up / Down Ratio 20 : -3
Digital Keystone Correction V +/- 15°
Digital Zoom 4x - 1x
Speaker Output 8W
Weight (lbs.) 8.4lbs.
Dimensions (inch) W,H,D 12.1"x4.7"x9.9"
Replacement Lamp CHSP8EM01GC01
Replacement Remote CH458EL01G001
Lamp Life *
(hours Normal / Eco) Up to 3000h / 4000h (Normal / Eco)
Input
D-sub15 pin x 2 for Input
RCA ：Video
Mini-DIN 4-pin ：S-Video 1-Input
HDMI (v1.3) for Digital signals
D-sub15 pin for Monitor out
Out Put Dsub15 x 1 : MONITOR OUT
Audio Output Mini jack x 1 (VARIABLE)
Control Service port (Mini Din8) x 1
RJ-45 (control)
Other Feature Auto Input Search, Digital Zoom, Freeze,
Closed caption
Included Accessories Owner’s Manual, Power Cord, Computer Cable, Wireless Remote Controller,
AAA type Batteries x 2pcs, Lens Cap & Strap
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a general estimate. The
brightness of a lamp usually decreases over time and use.
DLP® and the DLP logo are registered
trademarks of Texas Instruments.
BrilliantColor™ and DynamicBlack™ are
trademarks of Texas Instruments.
Back Panel
