Sanyo PLC-XC56 - 3100 User manual

EXPAND SERIAL COMMAND
FUNCTIONAL SPECIFICATIONS
PLC-XC56

Ver. 1.00
SANYO Electric Co., Ltd
DS Company
Projector Division

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
1 / 65
- CONTENTS -
1. Overview.........................................................................................................................7
2. Serial Interface Specification .......................................................................................7
2.1Transfer Specification...............................................................................................7
2.2Connection................................................................................................................7
3. Notes for communication.............................................................................................8
4. Name Definition .............................................................................................................8
5. Functional Execution Command Table.......................................................................9
5.1 Image Command Table........................................................................................9
5.2 PC Adjust Control Command Table.....................................................................9
5.3 Input Control Command Table.............................................................................9
5.4 Screen Command Table........................................................................................9
5.5 Lamp Command Table....................................................................................... 10
5.6 Sound Command Table...................................................................................... 10
5.7 Setting Command Table..................................................................................... 10
5.8 Other Command Table....................................................................................... 10
6. Status Read Command Table.................................................................................... 11
6.1 Image Status Read Command Table................................................................ 11
6.2 PC Adjust Status Read Command Table .......................................................... 11
6.3 Video Status Read Command Table................................................................. 11
6.4 Input Status Read Command Table .................................................................. 11
6.5 Screen Status Read Command Table............................................................... 11
6.6 Lamp Status Read Command Table ................................................................. 12
6.7 Sound Status Read Command Table................................................................ 12
6.8 Setting Status Read Command Table ............................................................... 12
6.9 Other Status Read Command............................................................................ 12
7. Error Code Table ......................................................................................................... 13
8. Functional Execution Command.............................................................................. 14
8.1 Format ................................................................................................................... 14
8.2 Transfer Example.................................................................................................. 14
8.3 Operation Requirements..................................................................................... 14
8.4 Image Command................................................................................................ 15
8.4.1 CF_BRIGHT Command ................................................................................. 15
8.4.2 CF_CONT Command.................................................................................... 15
8.4.3 CF_COLOR Command................................................................................. 15
8.4.4 CF_TINT Command....................................................................................... 15
8.4.5 CF_SHARP Command .................................................................................. 16
8.4.6 CF_GAMMA Command............................................................................... 16
8.4.7 CF_WBAL - Command ................................................................................. 16
8.4.8 CF_COLTEMP Command ............................................................................. 17

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
2 / 65
8.4.9 CF_PROGV Command................................................................................. 17
8.4.10 CF_NZRED Command................................................................................... 17
8.4.11 CF_IMAGE Command.................................................................................. 18
8.4.12 CF_IMAGEADJ Command........................................................................... 18
8.5 PC Adjust Control Command............................................................................. 19
8.5.1 CF_FSYNC Command.................................................................................. 19
8.5.2 CF_TDOTS Command................................................................................... 19
8.5.3 CF_CLAMP Command ................................................................................. 19
8.5.4 CF_H – POS Command ................................................................................ 20
8.5.5 CF_V – POS Command ................................................................................ 20
8.5.6 CF_DDOTS Command.................................................................................. 20
8.5.7 CF_DLINE Command.................................................................................... 21
8.5.8 CF_PCSTORE Command .............................................................................. 21
8.5.9 CF_PCMODEFREE Command ...................................................................... 21
8.6 Input Control Command..................................................................................... 22
8.6.1 CF_INPUT Command.................................................................................... 22
8.6.2 CF_SOURCE Command................................................................................ 22
8.6.3 CF_INPUT1 Command.................................................................................. 23
8.6.4 CF_INPUT2 Command.................................................................................. 23
8.6.5 CF_INPUT3 Command.................................................................................. 23
8.6.6 CF_INPUT4 Command.................................................................................. 23
8.6.7 CF_INPUT_%1_%2 Command...................................................................... 23
8.6.8 CF_SYSTEM Command................................................................................. 24
8.7 Screen Control Command................................................................................. 25
8.7.1 CF_SCREEN Command ................................................................................ 25
8.7.2 CF_DZCENT Command ................................................................................ 25
8.7.3 CF_KEYSTONE Command............................................................................ 26
8.7.4 CF_KYSTNMODE Command........................................................................ 26
8.7.5 CF_VSCALE Command................................................................................ 26
8.7.6 CF_VPOS Command.................................................................................... 27
8.7.7 CF_HSCALE Command................................................................................ 27
8.7.8 CF_HPOS Command .................................................................................... 28
8.8 Lamp Command.................................................................................................. 29
8.8.1 CF_LAMPH Command.................................................................................. 29
8.8.2 CF_LAMPMODE Command ......................................................................... 29
8.8.3 CF_LAMPLIFECONTRL Command................................................................ 29
8.9 Sound Command................................................................................................ 30
8.9.1 CF_VOLUME Command............................................................................... 30
8.9.2 CF_MUTE Command..................................................................................... 30
8.10 Setting Command................................................................................................ 31

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
3 / 65
8.10.1 CF_LANG Command.................................................................................... 31
8.10.2 CF_MENUPOSITION Command................................................................... 31
8.10.3 CF_INPUTSEARCH Command...................................................................... 31
8.10.4 CF_AUTOSETUPPCADJ Command .............................................................. 32
8.10.5 CF_AUTOSETUPKEYSTONE Command......................................................... 32
8.10.6 CF_AUTOSETUP Command .......................................................................... 32
8.10.7 CF_BACKGND Command ........................................................................... 32
8.10.8 CF_DISP Command...................................................................................... 33
8.10.9 CF_LOGO Command................................................................................... 33
8.10.10 CF_CEIL Command................................................................................... 34
8.10.11 CF_REAR Command................................................................................. 34
8.10.12 CF_STANDBYMODE Command................................................................ 34
8.10.13 CF_P-MANE Command............................................................................ 34
8.10.14 CF_P-MANETIME Command.................................................................... 35
8.10.15 CF_ON-STA Command............................................................................. 35
8.10.16 CF_RCODE Command.............................................................................. 35
8.10.17 CF_KEYDIS Command.............................................................................. 35
8.10.18 CF_PJPINCODE Command...................................................................... 36
8.10.19 CF_FANMODE Command........................................................................ 36
8.10.20 CF_CCAPTIONDISP Command................................................................ 36
8.10.21 CF_CCAPTIONCOLOR Command........................................................... 37
8.10.22 CF_FILSCRL Command............................................................................. 37
8.10.23 CF_FILCTL Command................................................................................ 37
8.10.24 CF_FILTIMER Command............................................................................ 37
8.10.25 CF_FILH Command................................................................................... 37
8.10.26 CF_FDEFAULT Command.......................................................................... 38
8.11 Other Command.................................................................................................. 39
8.11.1 CF_KEYENU Command ................................................................................ 39
8.11.2 CF_MENU Command ................................................................................... 39
8.11.3 CF_POWER Command ................................................................................. 39
8.11.4 CF_FREEZE Command.................................................................................. 40
8.11.5 CF_VMUTE Command.................................................................................. 40
8.11.6 CF_PTIMER Command.................................................................................. 40
9. Status Read Command.............................................................................................. 41
9.1 Format ................................................................................................................... 41
9.2 Transfer Example.................................................................................................. 41
9.3 Operation Condition ........................................................................................... 41
9.4 Image Status Read Command.......................................................................... 41
9.4.1 CR_BRIGHT Command................................................................................. 41
9.4.2 CR_CONT Command................................................................................... 41

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
4 / 65
9.4.3 CR_COLOR Command................................................................................. 42
9.4.4 CR_TINT Command....................................................................................... 42
9.4.5 CR_SHARP Command.................................................................................. 42
9.4.6 CR_GAMMA Command.............................................................................. 42
9.4.7 CR_WBAL – R Command.............................................................................. 42
9.4.8 CR_WBAL – G Command............................................................................. 42
9.4.9 CR_WBAL – B Command.............................................................................. 43
9.4.10 CR_COLTEMP Command............................................................................. 43
9.4.11 CR_NZRED Command.................................................................................. 43
9.4.12 CR_PROGV Command ................................................................................ 43
9.4.13 CR_IMAGE Command ................................................................................. 44
9.4.14 CR_IMGGMD Command............................................................................. 44
9.5 PC Adjust Status Read Command..................................................................... 45
9.5.1 CR_FSYNC Command.................................................................................. 45
9.5.2 CR_TDOTS Command................................................................................... 45
9.5.3 CR_CLAMP Command................................................................................. 45
9.5.4 CR_H – POS Command................................................................................ 45
9.5.5 CR_V – POS Command................................................................................ 45
9.5.6 CR_DDOTS Command.................................................................................. 46
9.5.7 CR_DLINE Command.................................................................................... 46
9.5.8 CR_PCSTORE Command.............................................................................. 46
9.6 Video Status Read Command ........................................................................... 47
9.6.1 CR_SERSYS Command ................................................................................. 47
9.7 Input Status Read Command............................................................................. 48
9.7.1 CR_INPUT Command.................................................................................... 48
9.7.2 CR_SOURCE Command............................................................................... 48
9.7.3 CR_SRCINP1 Command............................................................................... 48
9.7.4 CR_SRCINP2 Command............................................................................... 48
9.7.5 CR_SRCINP3 Command............................................................................... 48
9.7.6 CR_SRCINP4 Command............................................................................... 49
9.7.7 CR_SYSTEM Command................................................................................. 49
9.7.8 CR_SYSLIST Command ................................................................................. 50
9.7.9 CR_MODELIST Command ............................................................................ 50
9.8 Screen Status Read Command.......................................................................... 51
9.8.1 CR_SCREEN Command................................................................................ 51
9.8.2 CR_ KYSTNMODE Command....................................................................... 51
9.8.3 CR_VSCALE Command................................................................................ 51
9.8.4 CR_VPOS Command.................................................................................... 51
9.8.5 CR_HSCALE Command................................................................................ 51
9.8.6 CR_HPOS Command.................................................................................... 52

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
5 / 65
9.9 Lamp Status Read Command............................................................................ 53
9.9.1 CR_LAMPREPL Command............................................................................ 53
9.9.2 CR_LAMPH Command................................................................................. 53
9.9.3 CR_LAMPCORRESPH Command................................................................. 53
9.9.4 CR_LAMPMODE Command......................................................................... 53
9.9.5 CR_LAMPMSTS Command........................................................................... 54
9.9.6 CR_PROJH Command.................................................................................. 54
9.9.7 CR_HMLAMP Command.............................................................................. 54
9.9.8 CR_LAMPLIFECONTRL Command................................................................ 54
9.10 Sound Status Read Command........................................................................... 55
9.10.1 CR_VOLUME Command............................................................................... 55
9.10.2 CR_MUTE Command .................................................................................... 55
9.11 Setting Status Read Command.......................................................................... 56
9.11.1 CR_LANG Command................................................................................... 56
9.11.2 CR_INPUTSEARCH Command...................................................................... 56
9.11.3 CR_AUTOSETUPPCADJ Command.............................................................. 56
9.11.4 CR_AUTOSETUPKEYSTONE Command ........................................................ 56
9.11.5 CR_BACKGND Command........................................................................... 57
9.11.6 CR_DISP Command...................................................................................... 57
9.11.7 CR_LOGO Command................................................................................... 57
9.11.8 CR_CEIL Command...................................................................................... 57
9.11.9 CR_REAR Command .................................................................................... 57
9.11.10 CR_STANDBYMODE Command............................................................... 58
9.11.11 CR_P-MANE Command............................................................................ 58
9.11.12 CR_P-MANETIME Command.................................................................... 58
9.11.13 CR_ON-STA Command ............................................................................ 58
9.11.14 CR_RCODE Command............................................................................. 58
9.11.15 CR_SECURITY Command.......................................................................... 59
9.11.16 CR_KEYDIS Command.............................................................................. 59
9.11.17 CR_PJLOCKNOW Command................................................................... 59
9.11.18 CR_PJLOCKMENU Command.................................................................. 59
9.11.19 CR_FANMODE Command........................................................................ 59
9.11.20 CR_CCAPTIONDISP Command ............................................................... 60
9.11.21 CF_CCAPTIONCOLOR Command........................................................... 60
9.11.22 CR_FILH Command................................................................................... 60
9.11.23 CR_FILREPL Command.............................................................................. 60
9.11.24 CR_FILTIMER Command ........................................................................... 60
9.11.25 CR_FILCOND Command.......................................................................... 61
9.11.26 CR_FILREMAIN Command........................................................................ 61
9.12 Other Status Read Command............................................................................ 62

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
6 / 65
9.12.1 CR_STATUS Command ................................................................................. 62
9.12.2 CR_SIGNAL Command ................................................................................ 62
9.12.3 CR_VMUTE Command.................................................................................. 62
9.12.4 CR_FREEZE Command.................................................................................. 62
9.12.5 CR_PTIMER Command ................................................................................. 63
9.12.6 CR_TEMPWARN Command.......................................................................... 63
9.12.7 CR_TEMP Command..................................................................................... 64
9.12.8 CR_TEMPFAIL Command ............................................................................. 65

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
7 / 65
1. Overview
1.1 This Functional Specification defines communication functions for PLC-XC56
1.2 Compatible to Firmware Ver. 1.x of the projector.
1.3 Most commands can be used to control projector remotely from PC by RS-232C. Therefore, the
commands are defined as Expand Serial Commands.
2. Serial Interface Specification
2.1Transfer Specification
Item Specification
Synchronous System Asynchronous
Transmission Speed 9600 / 19200
Data Length 8 bit
Parity N/A
Stop Bit 1
Flow Control N/A
Note1) Transmission Speed: initial setting value is 19200
Note2) Transmission Speed can be changed in service mode.
2.2Connection
Dedicated serial cable must be used for a connection to a computer and a projector.
PC     Projector
COM 1    Control Port
(D-Sub 9 Pin) （D-Sub 9 Pin）

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
8 / 65
3. Notes for communication
1. Expand Serial Command is defined as one command / one line that starts with “C” and ends
with carriage return (0x0D)
2. There are two types of commands: Functional Execution Command and Status Read
Command.
- Example of Functional Execution Command:”CF_BRIGHT_032”[CR]
- Example of Status Read Command: “CR_RIGHT”[CR]
Note) ”_” means a space
3. When it takesmore than one second to receive one command, it is not executed.
When it takes more than one second to receive carriage return (0X0D) after the projector
receives the first data “C”, it clears the information of buffer.
4. On command pipelining, wait for the interval of 100ms till sending next command after receiving
a response.
                                 (More than 100ms)
Command
PC →Projector    “CF_BRIGHT_032” CR Next Command
Projector →PC  “000” CR
Response
(A few ms - 5s)
When a computer sends next command before receiving a response, the projector may not
operate properly,except when there is no response for more than 5 seconds.
5. It takes about 5 seconds for internal initialization after plugging in AC power. During this time
commands cannot be processed. Do not issue any command.
4. Name Definition
1. Data from a controller to a projector is represented as COMMAND, and data from a projector to
a controller for the incoming command is represented as RESPONSE.
2. [CR] : Carriage Return Code
Command ends with cartridge return code.
Response also ends with carriage return code.
3. _ : Space Code
Aspace Code is indicated by (_).
4. %1 : Parameter in Command
When there are several parameters, they are defined as %2, %3…
5. %%% : Error code returned from a projector
Acceptable: “000”.
Unacceptable: See [7. Error Code Table].
6. %a : Parameter in Response Command
When there are several parameters, they are defined as %b, %c…

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
9 / 65
5. Functional Execution Command Table
5.1 Image Command Table
Execute command Item
CF_BRIGHT_%1[CR] Set Brightness value
CF_CONT_%1[CR] Set Contrast value
CF_COLOR_%1[CR] Set Color value
CF_TINT_%1[CR] Set Tint value
CF_SHARP_%1[CR] Set Sharpness value
CF_GAMMA_%1[CR] Set Gamma value
CF_WBAL-R_%1[CR] Set White Balance Red value
CF_WBAL-G_%1[CR] Set White Balance Green value
CF_WBAL-B_%1[CR] Set White Balance Blue value
CF_COLTEMP_%1[CR] Set Color Temp. value
CF_PROGV_%1[CR] Set /Cancel Progressive Scan
CF_NZRED_%1[CR] Set/Cancel Noise reduction
CF_IMAGE_%1[CR] Set Image mode
CF_IMAGEADJ_%1[CR] Reset/Store for Image Adjustment
5.2 PC Adjust Control Command Table
Execute command Item
CF_FSYNC_%1[CR] Set Fine Sync value
CF_TDOTS_%1[CR] Set Total Dots value
CF_CLAMP_%1[CR] Set Clamp Value
CF_H-POS_%1[CR] Set Horizontal Position value
CF_V-POS_%1[CR] Set Vertical Position value
CF_DDOTS_%1[CR] Set Display Dots value
CF_DLINE_%1[CR] Set Display Line value
CF_PCSTORE_%1[CR] Store current values of PC Adjust at Mode 1-5
CF_PCMODEFREE_%1[CR] Relese registered values of Mode1-5.
5.3 Input Control Command Table
Execute command Item
CF_INPUT_%1[CR]
Select Input
CF_SOURCE_%1[CR]
Select Input Source
CF_INPUT1
_%1[CR]
Select computer-1 and source selected in %1
CF_INPUT2_%1[CR]
Select computer-2 and source selected in %1
CF_INPUT3_%1[CR]
Select Video and
source
selected in
%1
CF_INPUT
4
_%
1
[CR]
Select
S
-
v
ideo and
source
selected in %1
CF_INPUT_%1_%2[CR]
Select Input and Source
CF_SYSTEM_%1[CR]
Select System
5.4 Screen Command Table
Execut
e command
Item
CF_SCREEN_%1[CR]
Select Screen size
CF_DZCENT_%1[CR]
Cancel Digital Zoom mode
CF_KEYSTONE_%1[CR]
Set Keystone
CF_KYSTNMODE_%1[CR]
Set Keystone Store mode
CF_VSCALE_%1[CR]
Set value of Vertical scale
CF_VPOS_%1[CR]
Set value of Vertical position
CF_HSCALE_%1[CR]
Set value of Horizontal scale
CF_HPOS_%1[CR]
Set value of Horizontal position

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
10 / 65
5.5 Lamp Command Table
Execute command
Item
CF_LAMPH_%1[CR]
Reset total running time of each lamp
CF_LAMPMODE_%1[CR]
Select Lamp mode
CF_LAMPLIFECO
NTRL_%1[CR]
Select Lamp life mode
5.6 Sound Command Table
Execute command
Item
CF_VOLUME_%1[CR]
Set Volume value
CF_MUTE_%1[CR]
Control ON/OFF of Sound Mute
5.7 Setting Command Table
Execute command
Item
CF_LANG_%1[CR]
Select language for OSD
CF_MENUPOS
ITION_%1[CR]
Move menu position.
CF_INPUTSEARCH_%1[CR]
Set up Input search function
CF_AUTOSETUPPCADJ_%1
[CR]
Set Auto PC in Auto Setup
CF_AUTOSETUPKEYSTONE_%1
[CR]
Set Auto Keystone in Auto Setup
CF_AUTOSETUP_%1[CR]
Excute Auto Setup
CF_BACKGND_%1[CR]
Set screen mode for the case of no signal
CF_DISP_%1[CR]
Set Display function
CF_LOGO_%1_%2[CR]
Set Logo function
CF_CEIL_%1[CR]
Set Ceiling function
CF_REAR_%1[CR]
Set Rear function
CF_STANDBYMODE_%1[CR]
Set Standby Mode
CF_P
-
MANE_%1[CR]
Set Power management function
CF_P
-
MANETIME_%1[CR]
Set Power management time
CF_ON
-
STA_%1[CR]
Set Power ON Start function
CF_RCODE_%1[CR]
Select Remote Control Reception Code
CF_KEYDIS_%1[CR]
Disable RC/Projector keys
CF_PJPINCODE_%1[CR]
Input PIN code to release PJ Locj
CF_FANMODE_%1[CR]
Select Fan mode
CF_FANCONTR
O
L_%1[CR]
Select Fan control mode
CF_CCAPTIONDISP_%1[CR]
Set channel of Closed caption
CF_CCAPTIONCOLOR_%1[CR]
Set color of Closed caption
CF_FILSCRL_%1[CR]
Reset projector scroll counter
CF_F
ILCTL_%1[CR]
Scroll projector filter
CF_FILTIMER_%1[CR]
Set time when Filter warning OSD is displayed
CF_FILH_%1[CR]
Reset Filter used time
CF_FDEFAULT_%1[CR]
Set the value to Factory Default
5.8 Other Command Table
Execute command
Item
CF_KEYEMU_%1[CR]
Behave the same as corresponding key of
projector top panel
CF_MENU_%1[CR]
Switch ON/OFF of each Menu.
CF_POWER_%1[CR]
Switch ON/OFF of Power.
CF_FREEZE _%1[CR]
Set Freezefunction.
CF_VMUTE _%1[CR]
Set No show function.
CF_PTIMER _%1[CR]
Set P-Timer function.


PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
11 / 65
6. Status Read Command Table
6.1 Image Status Read Command Table
Status read command
Item
CR_BRIGHT[CR]
Get Brightness value
CR_CONT[CR]
Get Contrast value
CR_COLOR[CR]
Get Color value
CR_TINT[CR]
Get Tint value
CR
_SHARP[CR]
Get Sharpness value
CR_GAMMA[CR]
Get Gamma value
CR_WBAL
-
R[CR]
White Balance Red value
CR_WBAL
-
G[CR]
White Balance Green value
CR_WBAL
-
B[CR]
White Balance Blue value
CR_COLTEMP[CR]
Get setting value of Color temperature
CR_NZRED[CR]
Get setting status of Noise reduction
CR_PROGV[CR]
Get setting status of Progressive scan
CR_IMAGE
[CR]
Get Selected Image status
CR_IMGGMD[CR]
Get setting value of Image Gamma
6.2 PC Adjust Status Read Command Table
Status read command
Item
CR_FSYNC[CR]
Get setting value of Fine Sync
CR_TDOTS[CR]
Get setting value of Total Dots
CR_CLAMP[CR]
Get setting value of Clamp
CR_H
-
POS[CR]
Get setting value of Horizontal Position
CR_V
-
POS[CR]
Get setting value of Vertical Position
CR_DDOTS[CR]
Get setting value of Display Dots
CR_DLINE[CR]
Get setting value of Display Line
CR_PCSTORE[CR]
Get Free or Stored status for PC Adj. mode1
-
5
6.3 Video Status Read Command Table
Status read command
Item
CR_SERSYS[CR]
Get selected current signal. When in Auto mode, it
returns a result by Auto detect.
6.4 Input Status Read Command Table
Status read command
Item
CR_INPUT[CR]
Get selected Input No.
CR_SOURCE[CR]
Get selected source of currently selected Input
CR_SRCINP1[CR]
Get selected source of Computer 1
CR_SRCINP2[CR]
Get selected source of Computer 2
CR_SRCINP3[CR]
Get selected source of Video
CR_SRCINP
4
[CR]
Get selected source of S-video
CR_SYSTEM[CR]
Get selected system status in Input mode
CR_SYSLIST[CR]
Get selectable System table
CR_MODELIST[CR]
Get selectable Mode table 
6.5 Screen Status Read Command Table
Status read command
Item
CR_SCREEN[CR]
Get selected screen size
CR_KYSTNMODE[CR]
Get setting status of Keystone Store mode
CR_VSCALE[CR]
Get setting status of Vertical Scale
CR_VPOS[CR]
Get setting status of Vertical Position
CR_HSCALE[CR]
Get setting status of Horizontal Scale

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
12 / 65
CR_HPOS[CR]
Get setting status of Horizontal Position
6.6 Lamp Status Read Command Table
Status read command
Item
CR_LAMPREPL[CR]
Get the information for Lamp replacement time
C
R_LAMPH[CR]
Get lamp total running time
CR_LAMPCORRESPH
[CR]
Get corresponding lamp use time
CR_LAMPMODE[CR]
Get Lamp Mode status
CR_LAMPSTS[CR]
Get lamp lighting status
CR_PROJH[CR]
Get projector total running time
CR_HMLAMP[CR]
Get lamp number
CR_
LAMPLIFECONTRL[CR]
Get lamp life mode
6.7 Sound Status Read Command Table
Status read command
Item
CR_VOLUME[CR]
Get Volume value
CR_MUTE[CR]
Get Sound Mute setting status
6.8 Setting Status Read Command Table
Status read command
Item
CR_LANG[CR]
Get selected language
CR_AUTOSETUPPCADJ
Get setting status of Auto PC in Auto setup
CR_AUTOSETUPKEYSTONE
Get setting status of Keystone in Auto setup
CR_INPUTSEARCH[CR]
Get setting status of Input search
CR_BACKGND[CR]
Get setting status screenmode for the case of no signal
CR_DISP[CR]
Get setting status of Display
CR_LOGO[CR]
Get setting status of Logo
CR_CEIL [CR]
Get setting status of Ceiling
CR_REAR[CR]
Get setting status of Rear
CR_STANDBYMODE[CR]
Get setting status of Standby Mode
CR_P
-
MANE[CR]
Get setting status of Power management
CR_P
-
MANETIME[CR]
Get setting time for Power management
CR_ON
-
STA[CR]
Get setting status of ON Start
CR_RCODE[CR]
Get selected Remote Control Code
CR_SECURITY[CR]
Get setting status of Security
CR_KEYDIS[CR]
Get RC/KEY disability status
CR_PJLOCKNOW[CR]
Get if PJ Lock is actually in operation
CR_PJLOCKMENU[CR]
Get setting statsus of PJ Lock on Menu
CR_FANMODE[CR]
Get selected Fan mode
CR_CCAPTIONDISP[CR]
Get setting status of
channel of Closed caption
CR_CCAP
TIONCOLOR[CR]
Get setting status of
color of Closed caption
CR_FILH[CR]
Get Filter used time
CR_FILREPL[CR]
Get the information for Filter replacement time
CR_FILTIMER[CR]
Get time when Filter warning OSD is displayed
CR_FILCOND[CR]
Ge
t status of filte
r clogs
CR_FILREMAIN[CR]
Get number of remaining filter
6.9 Other Status Read Command
Status read command
Item
CR_STATUS[CR]
Get setting status of Projector behavior
CR_SIGNAL[CR]
Get Signal Status if there is a signal or not
CR_VMUTE[CR]
Get setting status of No Show
CR_FREEZE[CR]
Get setting status of Freeze
CR_PTIMER[CR]
Get the operating status of Presentation Timer
CR_TEMPWARN[CR]
Get if temperature is close to abnormal temperature
CR_TEMP[CR]
Get current temperature status

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
13 / 65
CR_TEMPFAIL[CR]
Get temperature when sensors detect abnormal temperature
7. Error Code Table
Error Code Contents
? -When the received data cannot be decoded -Parameter determination error (digit number error,
including invalid value, etc.)
101 The function is not available in the selected Mode
102 Selected value is out of range (Not reflected)
103 Command mismatched to Hardware (command for
Optional function which is not installed)
201 When reached upper or lower limit of increasing or
decreasing data
301 Command cannot be executed during capturing
display. Resend the command after a while
302 Command cannot be executed during Auto PC
operation. Resend the command after a while
402 Command cannot be executed during PIN code
operation. Resend the command after a while.
Note) These error codes are applied to Expand Command, not to Basic Command

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
14 / 65
8. Functional Execution Command
8.1 Format
1. PC issues commands in format as below:
Pattern1 : “CF_COMMAND” [CR]
Pattern2 : “CF_COMMAND_”%1 [CR]
CF_: Header
COMMAND : Character line
%1 : Parameter (Character line)
_ : Space (To separate COMMAND and Parameter)
2. The projector decodes the received command and when it is ready to receive the next
command, it returns the response.
“000” [CR] : (0x06, 0x0D) When receiving Functional Execution Command
“nnn” [CR] : Except “000” , when it is unable to execute command by any specific reason.
See Error Code Table for details
3. When the received data cannot be decoded, the projector returns “?” [CR]
8.2 Transfer Example
When setting projector’s total dots to 1344 by Expand Serial Command
PC →PJ: ”CF_TDOTS_1344” [CR]
PC ←PJ: “000”[CR] - - - - - - - - - - - Acceptable
8.3 Operation Requirements
1) Functional Execution Command is limited when the projector status is as below.
However, Status Read Command is effective even under these conditions.
Projector Status
Available Functional Execution Command
Standby Mode
C00: POWER ON
Countdown in process
C00: POWER ON
(Terminates Countdown)
C01: POWER OFF
C02: POWER OFF
(Terminates Countdown)
Cooling down in process
N/A
Cooling down
in process
d
ue to Abnormal
Temperature N/A
Abnormal Temperature
N/A
Power Failure
(For 60 seconds after Power Failure occurred)
N/A
Power Save / Cooling down
in process
N/A
Power Save in process
C00: POWER ON
C01: POWER OFF
Note:) When the projector receives the other command in this above status, it returns
error code to show the status.
When the projector receives the following functional execution commands, OSD
menu is closed except for pop-up menu
2) When Eco mode is selected in Standby mode of Setting menu and projector is in Standby,
Functional Execution Commands are invalid.

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
15 / 65
8.4 Image Command
8.4.1 CF_BRIGHT Command
Command
"CF_BRIGHT_%1”[CR]
%1
"000~063”
---------------
Directly select Brightness setting value
"UP” ----------------------- Current Brightness setting value + 1
"DN” ----------------------- Current Brightness setting value – 1
Details
Set Brightness value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.) This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.2 CF_CONT Command
Command “CF_CONT_％1”[CR]
%1
“000~063”
---------------
Directly select Contrast setting value
“UP” ----------------------- Current Contrast setting value + 1
“DN” ----------------------- Current Contrast setting value – 1
Details
Set Contrast value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.) This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
"Error Code”[CR]
8.4.3 CF_COLOR Command
Command
“CF_COLOR_%1”[CR]
%1
“000~063”
----------------
Directly select Color setting value
“UP” ------------------------ Current Color setting value + 1
“DN” ------------------------ Current Color setting value - 1
Details
Set Color value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.4 CF_TINT Command
Command
“CF_TINT_%1”[CR]
%1
“000~063”
---------------
Directly select Tint setting value
“UP” ----------------------- Current Tint setting value + 1
“DN” ----------------------- Current Tint setting value – 1
Details
Set Tint value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
16 / 65
8.4.5 CF_SHARP Command
Command
“CF_SHARP_%1”[CR]
%1
“000~015”
----------------
Directly select
Sharpness
setting
value
“UP” ------------------------ Current Sharpness setting value + 1
“DN” ------------------------ Current Sharpness setting value - 1
Details
Set Sharpness value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.6 CF_GAMMA Command
Command
“CF_
GAMMA_%1”[CR]
%1
“000~015”
----------------
Directly set
Gamma
setting value
“UP” ------------------------ Current Gamma setting value + 1
“DN” ------------------------ Current Gamma setting value – 1
Details
Set Gamma value of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Una
cceptable
“Error Code”[CR]
8.4.7 CF_WBAL - Command
Command
“CF_WBAL
-
%1_%2”[CR]
%1 “Ｒ” --------------------- Red “Ｇ” --------------------- Green
“Ｂ” --------------------- Blue
%2
“000~063”
-----------
Directly select Color value specified byWhite Balance%1
“UP” ------------------- Current Color value set by White Balance%1 + 1
“DN” ------------------- Current Color value set by White Balance%1 - 1
Details
Set Color value set by White Balance%1
of user control
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
17 / 65
8.4.8 CF_COLTEMP Command
Command
“CF_COLTEMP_%1”[CR]
%1
“000”
------
Xlow
“001” ------ Low
“002” ------ Mid
“003” ------ High
Details
Set Color Temperature. (Available only in the normal Power ON status)
The value set by this command will not be saved to the projector. Therefore, when
turning into Stanby-mode or ALL is OFF, the value returns to original setting. (The
value is held in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.9 CF_PROGV Command
Command
“CF_PROGV_%1”[CR]
%1
“FILM”
--------
Select
Progressive Mode FILM
“L1” ----------- Select Progressive Mode L1
“L2” ----------- Select Progressive Mode L2
“OFF” --------- Cancel Progressive scan
“UP” -----------Switch Progressive mode in positive order
OFF →L1 →L2 →FILM →OFF
“DN” -----------Switch Progressive mode in negative order
OFF →FILM →L2 →L1 →OFF
Details
Set / cancel Progressive scan
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.10 CF_NZRED Command
Command
“CF_NZRED_%1”[CR]
%1
“OFF”
-------
Canc
el Noise Reduction
“L1” --------- Noise Reduction for moving image
“L2” --------- Noise Reduction for still image
“UP” -----------Switch Progressive mode in positive order
OFF →L1 →L2 →FILM →OFF
“DN” -----------Switch Progressive mode in negative order
OFF →FILM →L2 →L1 →OFF
Details
Noise Reduction based on frame correlation
Select L1 or L2 depending on motion detection
L2 is more effective in reducing noise than L1, however, L2 can have a blur in
moving image
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF. (The value is held
in Suspend mode.)
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
18 / 65
8.4.11 CF_IMAGE Command
Command
“CF_IMAGE_%1”[CR]
%1
“DYNAMIC”
------
Dynamic (Fixed value to enable projection with a sharp, powerful
picture tone)
“STAND” ---------- Standard (Image adjust value is set to factory default)
“REAL” ------------ Real (Fixed value to display graphic image with natural tone)
“CINEMA” -------- Cinema (Fixed value to focus on tone reproduction for movie)
“BLACKBOARD” – Blackboard (Fixed value to project image onto green-colored
blackboard)
blackboard)
“COLORBOARD ” – Colorboard(Fixed value to project image onto colored board)
“CUSTOM1” ----- Image1 (the value set and stored by a user)
“CUSTOM2” ----- Image2 (the value set and stored by a user)
“CUSTOM3” ----- Image3 (the value set and stored by a user)
“CUSTOM4” ----- Image4 (the value set and stored by a user)
Details
Select Image Mode
Parameter “CUSTOM1” to “CUSTOM4” is the same as “Image1” to “Image4”
displayed when selecting Image onOSD menu.
The value set by this command is stored in EEPROM and its setting is effective
even after ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]
8.4.12 CF_IMAGEADJ Command
Command
“CF_IMAGE
ADJ_%1”[CR]
%1
“RST”
-------
Reset Image adjustment
“STR1” ----- Store current Image adjustment to Image 1
“STR2” ----- Store current Image adjustment to Image 2
“STR3” ----- Store current Image adjustment to Image 3
“STR4” ----- Store current Image adjustment to Image 4
Details
Reset / store Image adjustment.
Parameter “STR1” to “STR4” is the same as “Image1” to “Image4” displayed when
adjusting Image onOSD menu and selecting “Store”
The value stored to “Image1-4” is saved and its setting is effective even after ALL
is OFF.
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“Error Code”[CR]

PLC
-
XC56
Expand Serial Command
Functional Specifications
                                       
19 / 65
8.5 PC Adjust Control Command
8.5.1 CF_FSYNC Command
Command
“CF_FSYNC_%1”[CR]
%1
“0000~0031”
---------------
Directly se
lect Fine Sync setting value
“UP” -------------------------- Current Fine Sync setting value + 1
“DN” -------------------------- Current Fine Sync setting value - 1
Details
Set Fine Sync value of PC signal
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“101”[CR]
---
when Input for Video is selected
8.5.2 CF_TDOTS Command
Command
“CF_TDOTS_%1”[CR]
%1
“
mmmm~nnnn
”
---
Directly select Total Dots setting value
“mmmm” shows minimum value, it is current Display Dots Horizontal value +
Position value.
“nnnn” shows maximum value, which is not over 140MHz.
“UP” -------------- Current Total Dots setting value + 1
“DN” -------------- Current Total Dots setting value - 1
Details
Set Total Dots
of PC signal
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“101”[CR]
----
when Input for Video is selected
8.5.3 CF_CLAMP Command
Command
“CF_CLAMP_%1”[CR]
%1
“mmmm~nnnn”
----
Directly select Clamp s
etting value
“mmmm” shows minimum value, fixed-value “0001”.
“nnnn” shows maximum value: it depends on input signal.
“UP” ------------------ Current Clamp setting value + 1
“DN” ------------------ Current Clamp setting value – 1
Details
Set Clamp value
of PC signal
Projector does not save the value set with this command so that it returns its
original when projector turning into Stanby mode or ALL is OFF.
This command is available in normal Power ON status.
Response
Acceptable
“000”[CR]
Unacceptable
“101”[CR]
----
when Input for Video is selected
