PLC-XM150/XM100 IR Command List
□ Transmission format of LCD projector operation key
: NEC Format (single command / command pipelining mode)
□ Transmission format of PC mouse operation button (mouse cursor button) / L / R key
: SMK Mouse Code Format (Includes 3 bit of ID)
□ Custom Code + Custom Code
: 8 patterns as below
33h+00h(Default; code1), 33h+11h(code2), 33h+22h(code3), 33h+33h(code4),
33h+44h(code5), 33h+55h(code6), 33h+66h(code7), 33h+77h(code8)
Key
No.
Data Code
(HEX) Function
S1 *1 L-CLICK ※ Back-side Click Trigger Key
S2 11 ON
S3 10 STAND-BY
S4 05 INPUT
S5 89 AUTO PC
S6 16 INFO
S7 1C MENU
S8 82 SCREEN
S9 8B SHUTTER
S10 8C CURSOR UP
S11 1E CURSOR LEFT / VOLUME -
S12 1D CURSOR RIGHT / VOLUME +
S13 8D CURSOR DOWN / MUTE
S14 38 INPUT 1
S15 84 POINTER
S16 *1 R-CLICK
S17 39 INPUT2 (Number 1)
S18 88 D.ZOOM (Number 2)
S19 8A P-TIMER (Number 3)
S20 06 INPUT3 (Number 4)
S21 5B KEYSTONE (Number 5)
S22 43 FREEZE (Number 6)
S23 47 ZOOM + (Number 7)
S24 4A FOCUS + (Number 8)
S25 40 LENS SHIFT (Number 9)
S26 46 ZOOM -
S27 4B FOCUS - (Number 0)
S28 1A FILTER
S29 OF / *1 SELECT / Mouse Cursor button
*1･･･ Transmit code for Mouse
