Specifications
POWER RATING . . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
178 W (AVG.)
ANTENNA INPUT IMPEDANCE. . . . . . . . . . . . . . . . . 75Ω
UHF/VHF/CATV
DIGITAL
RECEIVING CHANNEL . . . . . . . . . . . . . . . . . 2 - 13 (VHF),
14 - 69 (UHF),
01, 14-94, 95-135 (CATV)
1-135 (DIGITAL)
REMOTE READY. . . . . . . . . 48 KEY REMOTE CONTROL
SOUND OUTPUT. . . . . . . . . . . . . . . . . . . . . . . 10.0 W/CH
INTERMEDIATE FREQUENCY
PICTURE IF CARRIER . . . . . . . . . . . . . . . . . . 45.75MHz
SOUND IF CARRIER . . . . . . . . . . . . . . . . . . . 41.25MHz
COLOR SUB CARRIER . . . . . . . . . . . . . . . . . 42.17MHz
CABINET DIMENSIONS
WIDTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1012mm
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 704mm
DEPTH INCLUDING BASE . . . . . . . . . . . . . . . . 307mm
REFERENCE No. SM780171
DP42840, N7AL, PRODUCT CODE 113018210
FILE NO.
SERVICE MANUAL Remote Control Digital
Color Television DP42840 (U.S.A.)
(CANADA)
ORIGINAL VERSION
Chassis No. P42840-00
NOTE: Match the Chassis No. on
the unit’s back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit’s, additional Service
Literature is required. You
must refer to “Notices” to the
Original Service Manual
prior to servicing the unit.
Servicing should be performed by only trained and qualified service personnel.
Contents
SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . 2
SERVICE ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . 3
ON-SCREEN SERVICE MENU . . . . . . . . . . . . . . . . . . . . . 4
POWER FAILURE CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . 5
MECHANICAL DISASSEMBLY . . . . . . . . . . . . . . . . . . . . 6
CHASSIS ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . 8
COMPONENT AND TESTPOINT LOCATIONS . . . . . . 21
BLOCK DIAGRAM POWER LINES. . . . . . . . . . . . . . . . . 27
BLOCK DIAGRAM SIGNAL LINES . . . . . . . . . . . . . . . . 28
IC BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . 29
TROUBLESHOOTING FLOW CHARTS . . . . . . . . . . . . . 35
CONTROL PORT FUNCTIONS. . . . . . . . . . . . . . . . . . . . 38
MAIN SHEET BLOCK DIAGRAM & PERIPHERICALS. . 40
SCHEMATIC NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
IC, DIODE, AND TRANSISTOR PIN LAYOUTS. . . . . . . 42
PC BOARD CONNECTIONS AND LOCATIONS . . . . . . 43
CAPACITOR AND RESISTOR CODE CHART . . . . . . . . 44
SCHEMATIC DIAGRAMS. . . . . . . . . . . . . . . . . . . . . . . . 45
© Sanyo Manufacturing Corporation 2010

– 2 –
SAFETY PRECAUTIONS
WARNING: The chassis of this receiver has a floating
ground with the potential of one half the AC line voltage in
respect to earth ground. Service should not be attempted by
anyone not familiar with the precautions necessary when
working on this type of equipment.
The following precautions must be observed:
1. An isolation transformer must be connected in the power
line between the receiver and the AC line before any ser-
vice is performed on the receiver.
2. Comply with all caution and safety-related notes provid-
ed inside the cabinet, on the chassis, and on the back.
3. When replacing a chassis in the cabinet, always be certain
that all the protective devices are installed properly, such
as control knobs, adjustment covers, shields and barriers.
4. Before replacing the back cover of the set, thoroughly
inspect the inside of the cabinet to see that no stray parts
or tools have been left inside.
Before returning any television to the customer, the
service technician must perform the following safety
checks to be sure that the unit is completely safe to
operate without danger of electrical shock.
ANTENNA COLD CHECK
Remove AC plug from the 120 VAC outlet and place a
jumper across the two blades. Connect one lead of an ohm-
meter to the jumpered AC plug, and touch the other lead to
each exposed antenna terminal (UHF and VHF antenna ter-
minals). The resistance must measure between 1M ohm and
5.2M ohm. Any resistance value below or above this range
indicates an abnormality which requires corrective action.
LEAKAGE CURRENT CHECK
Plug the AC line cord directly into a 120 VAC outlet. (Do not
use an isolation transformer for this check.) Use an AC volt-
meter, that has 5000 ohms per volt or more sensitivity.
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 μF
150 VAC capacitor, between a known good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of the
cabinet (antennas, handle bracket, metal cabinet, screw
heads, metal overlays, control shafts, etc.). Measure the AC
voltage across the 1500 ohm resistor. The AC voltage
should not exceed 750 mV. A reading exceeding 750 mV
indicates that a dangerous potential exists. The fault must
be located and corrected. Repeat the above test with the
receiver power plug reversed.
NEVER RETURN A RECEIVER TO THE CUSTOMER
WITHOUT TAKING THE NECESSARY CORRECTIVE ACTION.
PRODUCT SAFETY NOTICE
When replacing components in a receiver, always keep in
mind the necessary product safety precautions. Pay special
attention to the replacement of components marked with a
in the parts list and in the schematic diagrams. To ensure
safe product operation, it is necessary to replace those com-
ponents with the exact same PARTS.
SERVICING ELECTROSTATICALLY SENSITIVE DEVICES
Semiconductors (solid-state devices) that can be damaged
by static electricity are referred to as Electrostatically
Sensitive (ES) devices. Examples of typical ES devices are:
Integrated Circuits (IC), Field-Effect Transistors (FET), and
“chip” components. The following techniques should be
observed strictly, to reduce the occurrence of semiconduc-
tor damage due to electrostatic discharge.
1. Immediately prior to handling any semiconductor com-
ponent or an assembly containing a semiconductor
device or devices, discharge the electrostatic buildup on
your body by touching a known earth ground. You may
also obtain and wear a commercially available discharg-
ing wrist strap device.
CAUTION: Be sure to remove the wrist strap before
applying power to any unit being serviced.
2. After removing an ES equipped assembly, place it on a
conductive surface, such as, aluminum foil, to prevent
buildup or exposure to static electricity.
3. Use only grounded-tip soldering irons to solder or unsol-
der ES devices.
4. Use only anti-static solder removal devices. Some suc-
tion-type devices can generate static electricity adequate
to damage ES devices.
5. A replacement ES device will come packaged in protective
material (conductive foam, aluminum foil, or some compa-
rable conductive material). Do Not remove an ES device
from its protective packaging unless you are prepared to
install it immediately.
6. Precisely prior to removing an ES device from its protective
packaging, touch the protective packaging to the chassis or
assembly in which the device will be installed.
CAUTION: Be sure that no power is applied to the chassis
or circuit assembly.
7. Incidental body movements, such as, lifting a foot from
a carpeted floor or the rubbing of fabric together can
generate static electricity sufficient to damage ES devices.
Therefore, minimize all body movements while handling
exposed (unpackaged) ES devices.
SAFETY INSTRUCTIONS

– 3 –
SERVICE ADJUSTMENTS
GENERAL
This set has an On-screen Service Menu system included in
the CPU that allows remote operation for most of the
service adjustments.
ON-SCREEN SERVICE MENU SYSTEM
1. Enter the Service Menu:
•Turn off the receiver and disconnect the AC power
supply.
•While pressing the Volume (––) button on the televi-
sion, reconnect the AC power supply. The Service
Menu will now appear. The remote can now be used
to make adjustments. See Figure 1 below.
2. Service Adjustments:
•Press the Cursor  and key to select the desired
service menu item you want to adjust. See page 4 for
the On-screen Service Menu.
•Use the Cursor or key to adjust the data.
The or key will increase or decrease the data
sequentially.
3. Exit from the Service Menu:
•Press the MENU key to turn off the Service Menu
display.
Figure 1. Service Menu Display
HEX DATA
ITEM NO. TITLE
POWER
INPUT
ENTER
MENU
VOL
CH
POWER
INPUT
ENTER
MENU
VOL
CH
Volume – :Enter Service Menu
DYN VOL
INFO
PIX SHAPE
Menu:
Exit Service Menu Cursor :
Select Item
Cursor :
Adjust the data

– 4 –
ON-SCREEN SERVICE MENU
Table 1. ON-SCREEN SERVICE MENU
When IC801 (EEPROM) is replaced, check the bus data to confirm they are the same as below. See page 3 for
On-Screen Service Menu access and adjustments.
PROGRAM CODES
The microprocessor used in this model is a multi-purpose type and is used in several different models. To ensure
proper operation and the correct features for your particular model, the program codes must be correct.
Note 1. Option Data 1 (NO. 087 OP1) should be hexadecimal
00. See 087 above. If this program code is wrong the TV will
not operate properly.
Note 2. Option Data 2 (NO. 088 OP2) should be hexadecimal
08. See 088 above. If this program code is wrong the TV will
not operate properly.
No. Title Initial Data Note
1A0 MUTE A0h Audio mute at Power ON
086 VOL 30h Volume setup inspection
087 OP1 00h Option 1 Data (HDMI)
088 OP2 08h Option 2 Data (Display Panel)
101 1R00 00h ROM Correction Data
102 1R01 00h ROM Correction Data
↓↓ ↓ ↓
197 2R47 00h ROM Correction Data
198 2R48 00h ROM Correction Data
• All data except in gray box area is fixed. Do not change for correct operating.
• Data in gray box is initial and can be set according to adjusment information.

– 5 –
POWER FAILURE CIRCUIT
Check the following if the unit is turned off by the power
failure detector.
1. Disconnect the AC power cord (120V AC line) for a short
time.
2. Connect a DC Voltmeter to the circuits shown below.
3. Press the Power key and check for the proper voltage
supplies.
4. If any of these voltages is low, the power failure detec-
tor should turn the unit off within three seconds.
5. Check all circuits shown below.
Note: If power failure is detected 3 times in 15 minutes,
the set will enter the standby mode and cannot be
switched On.To reset the operating programs of the
CPU it is necessary to disconnect the AC cord for a
short time.
CPU (IC800) is programmed so the set will go to standby
mode when there is circuit failure as described below.
(Refer to“Block Diagram Power Lines”.)
This unit is equipped with a Power Failure Detector function
included in the CPU which checks for an abnormal condi-
tion in the chassis power supplies.
If, while the power is on, a failure is caused by any of the
following that results in a low voltage supply, the CPU will
turn the unit off in 1.5 seconds to prevent further damage:
•Failure within the power supply circuits.
•A short circuit in the load side from the supply.
Power Failure: Detected voltage failure for circuit.
(Connected to IC800 pin 48 and pin 23.)
(Normal: High; Failure: Low)
If, while the power is off, the power is switched on and any
of these failures remains uncorrected, the CPU will shut off
the power within three seconds.
48
18
IC800 (SUB-CPU)
4,2
3
23
Power Fail 1
Power On
Power Fail 2
1
Power Board
Inverter
Main
D1671
K8B
D1660
D1681
Audio_Pow
13V
IC1660
9V
12V
5V
STAND BY
D1621
3
D1620 IC1630
3.3V

– 6 –
STAND REMOVAL
Note: Position TV face down on a padded or cushioned
surface to protect the screen and finish.
Remove 4 screws (B: 6x12) to take the stand off.
MECHANICAL DISASSEMBLY
A
Back Lid
CAUTION:
This LCD TV uses several different kinds of screws. Using
the correct screw is necessary to prevent damage. Lead
wires must be redressed to their previous locations after
servicing. The Earth sheet and gasket are provided to pre-
vent interference to other radio and television receivers.
The Earth sheet and gasket should be returned to its previ-
ous position after servicing.
MAIN BOARD REMOVAL
Remove 5 screws (C: 3X14, 4pcs; A3X6, 1pc) to take the
Main Board off.
POWER UNIT REMOVAL
Remove 6 screws (C: 3X14) to take the Power Unit off.
BACK LID REMOVAL
Remove 2 screws (A: 3x6) to take the Back Lid off.
BB
Main BoardPower Unit
CC
C
C
C
A
C
CC
C
C

– 7 –
BACK CABINET REMOVAL
Remove 17 screws to take the back cabinet off.
(C: 3x14, 13pcs; D: 4x8, 4 pcs)
RC LED BOARD REMOVAL
Remove 1 screw (C: 3x14) to take the RC LED board off.
KEY SW BOARD REMOVAL
Remove 1 screw (C:3x14) to take the KEY SW board off.
ELECTROSTATICALLY SENSITIVE DEVICES
Many solid-state devices (especially Integrated
Circuits) are Electrostatically Sensitive, and, therefore,
require special handling techniques as described
under “Servicing Electrostatically Sensitive Devices,”
on page two in this service literature.
LCD PANEL REMOVAL
Lift up the LCD panel from front cabinet.
SPEAKER REMOVAL
Remove 2 screws (E: 3x14) to take off each speaker.
C
C
D
D
C
D
CC
CC
CC
C
D
C
C
C
CC
Speaker
Speaker Holder
RC LED Board
C
KEY SW Board C

– 8 –
CHASSIS ELECTRICAL PARTS LIST
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS
and PRODUCT SAFETY NOTICE on Page 2.
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACE-
MENT DESIGNATED BY A . NO DEVIATIONS FROM RESISTANCE, WATTAGE, AND VOLTAGE RATINGS MAY
BE MADE FOR REPLACEMENT ITEMS DESIGNATED BY A .
Schematic
Location Part No. Description Schematic
Location Part No. Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
CAPACITORS RESISTORS

– 9 –
Schematic
Location Part No. Description
CAPACITORS
C001 CK1H102KLZBNG CERAMIC 1000P K 50V
C002 CK1H102KLZBNG CERAMIC 1000P K 50V
C003 CK1E105KGMBNG CERAMIC 1U K 25V
C004 CK1E105KGMBNG CERAMIC 1U K 25V
C005 CK1H102KLZBNG CERAMIC 1000P K 50V
C006 CK1H102KLZBNG CERAMIC 1000P K 50V
C007 CK1H102KLZBNG CERAMIC 1000P K 50V
C008 CK1H102KLZBNG CERAMIC 1000P K 50V
C009 CK1H104KLZBNG CERAMIC 0.1U K 50V
C010 CK1H104KLZBNG CERAMIC 0.1U K 50V
C011 CK1H104KLZBNG CERAMIC 0.1U K 50V
C012 CK1H104KLZBNG CERAMIC 0.1U K 50V
C013 CK1H104KLZBNG CERAMIC 0.1U K 50V
C014 CK1H104KLZBNG CERAMIC 0.1U K 50V
C015 CK1H104KLZBNG CERAMIC 0.1U K 50V
C016 CK1H104KLZBNG CERAMIC 0.1U K 50V
C017 CEXLB1E102VEN ELECT 1000U M 25V
C018 CC1H331JLZCNG CERAMIC 330P J 50V
C019 CC1H331JLZCNG CERAMIC 330P J 50V
C020 CK1E105KGMBNG CERAMIC 1U K 25V
C021 CK1H104KLZBNG CERAMIC 0.1U K 50V
C022 CK1H104KLZBNG CERAMIC 0.1U K 50V
C023 CK1E105KGMBNG CERAMIC 1U K 25V
C024 CK1H104KLZBNG CERAMIC 0.1U K 50V
C025 CK1H104KLZBNG CERAMIC 0.1U K 50V
C026 CK1H104KLZBNG CERAMIC 0.1U K 50V
C027 CK1H104KLZBNG CERAMIC 0.1U K 50V
C028 CC1H150JLZCNG CERAMIC 15P J 50V
C029 CC1H150JLZCNG CERAMIC 15P J 50V
C030 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C031 CC1H681JLZCNG CERAMIC 680P J 50V
C032 CC1H101JLZCNG CERAMIC 100P J 50V
C033 CK1H472KLZBNG CERAMIC 4700P K 50V
C034 CK1H104KLZBNG CERAMIC 0.1U K 50V
C035 CK1H104KLZBNG CERAMIC 0.1U K 50V
C036 CK1E105KGMBNG CERAMIC 1U K 25V
C037 CK1E105KGMBNG CERAMIC 1U K 25V
C038 CK1H103KLZBNG CERAMIC 0.01U K 50V
C040 CK1H104KLZBNG CERAMIC 0.1U K 50V
C041 CK1H104KLZBNG CERAMIC 0.1U K 50V
C042 CK1H104KLZBNG CERAMIC 0.1U K 50V
C800 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C801 CK1H104KLZBNG CERAMIC 0.1U K 50V
C802 CK1A105KLZBNG CERAMIC 1U K 10V
C803 CK1H104KLZBNG CERAMIC 0.1U K 50V
C806 CEXLB0J221VDN ELECT 220U M 6.3V
C808 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C809 CK1A105KLZBNG CERAMIC 1U K 10V
C813 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C820 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C821 CC1H180JLZCNG CERAMIC 18P J 50V
C822 CC1H220JLZCNG CERAMIC 22P J 50V
C1002 CK1A105KLZBNG CERAMIC 1U K 10V
C1004 CK1A105KLZBNG CERAMIC 1U K 10V
C1006 CK1A105KLZBNG CERAMIC 1U K 10V
C1009 CK1A105KLZBNG CERAMIC 1U K 10V
C1010 CK1A105KLZBNG CERAMIC 1U K 10V
C1012 CK1A105KLZBNG CERAMIC 1U K 10V
C1014 CK1A105KLZBNG CERAMIC 1U K 10V
C1016 CK1A105KLZBNG CERAMIC 1U K 10V
C1025 CC1H471JLZCNG CERAMIC 470P J 50V
C1201 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1600 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1601 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1602 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1603 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1610 CEXLB1V471VDN ELECT 470U M 35V
C1611 CK1E224KLZBNG CERAMIC 0.22U K 25V
C1612 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1613 CK1E105KGMBNG CERAMIC 1U K 25V
C1615 CK1H222KLZBNG CERAMIC 2200P K 50V
C1616 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1617 CEXLB0J102VDN ELECT 1000U M 6.3V
C1630 CEXLB1V471VDN ELECT 470U M 35V
C1631 CK1E224KLZBNG CERAMIC 0.22U K 25V
C1632 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1633 CK1E105KGMBNG CERAMIC 1U K 25V
C1635 CK1H472KLZBNG CERAMIC 4700P K 50V
C1636 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1637 CEXLB0J102VDN ELECT 1000U M 6.3V
C1640 CEXLB0J221VDN ELECT 220U M 6.3V
C1641 CK1A105KLZBNG CERAMIC 1U K 10V
C1643 CK1A105KLZBNG CERAMIC 1U K 10V
C1644 CK1A105KLZBNG CERAMIC 1U K 10V
C1645 CEXLB0J102VDN ELECT 1000U M 6.3V
C1651 CEXLB0J102VDN ELECT 1000U M 6.3V
C1660 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1661 CK1E105KGMBNG CERAMIC 1U K 25V
C1662 CEXLB1C101VDN ELECT 100U M 16V
C1663 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1664 CEXLB1C101VDN ELECT 100U M 16V
C1671 CEXLB1V471VEN ELECT 470U M 35V
C1672 CK1E105KGMBNG CERAMIC 1U K 25V
C1673 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1674 CK1H105KGNBNG CERAMIC 1U K 50V
C1676 CK1H472KLZBNG CERAMIC 4700P K 50V
C1677 CK1E105KGMBNG CERAMIC 1U K 25V
C1678 CEXLB1E102VEN ELECT 1000U M 25V
C1681 CK1E105KGMBNG CERAMIC 1U K 25V
C1700 CEXLB1V471VDN ELECT 470U M 35V
C1701 CK1E474KLZBNG CERAMIC 0.47U K 25V
C1702 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1703 CK1H105KGNBNG CERAMIC 1U K 50V
C1705 CK1H472KLZBNG CERAMIC 4700P K 50V
C1706 CK1E475KGNBNG CERAMIC 4.7U K 25V
C1707 CEXLB1E102VDN ELECT 1000U M 25V
C1801 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1807 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1816 CK0J106KGMBNG CERAMIC 10U K 6.3V
C2403 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2404 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
Schematic
Location Part No. Description

– 10 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C2405 CK1A105KLZBNG CERAMIC 1U K 10V
C2407 CK1A105KLZBNG CERAMIC 1U K 10V
C2409 CC1H101JLZCNG CERAMIC 100P J 50V
C2410 CC1H101JLZCNG CERAMIC 100P J 50V
C2416 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2417 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2418 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2440 CC1H470JLZCNG CERAMIC 47P J 50V
C2441 CC1H470JLZCNG CERAMIC 47P J 50V
C5500 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5501 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5502 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5503 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5504 CK1A105KLZBNG CERAMIC 1U K 10V
C5505 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5506 CK1A105KLZBNG CERAMIC 1U K 10V
C5507 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5508 CK1A105KLZBNG CERAMIC 1U K 10V
C5509 CK1A105KLZBNG CERAMIC 1U K 10V
C5510 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5511 CK1A105KLZBNG CERAMIC 1U K 10V
C5512 CK1A105KLZBNG CERAMIC 1U K 10V
C5514 CK1A105KLZBNG CERAMIC 1U K 10V
C5515 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5516 CK1A105KLZBNG CERAMIC 1U K 10V
C5517 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5518 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5519 CK1A105KLZBNG CERAMIC 1U K 10V
C5520 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5521 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5522 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5523 CK1A105KLZBNG CERAMIC 1U K 10V
C5524 CC1H101JLZCNG CERAMIC 100P J 50V
C5525 CK1A105KLZBNG CERAMIC 1U K 10V
C5526 CK1A105KLZBNG CERAMIC 1U K 10V
C5527 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5528 CK1A105KLZBNG CERAMIC 1U K 10V
C5529 CK1A105KLZBNG CERAMIC 1U K 10V
C5530 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5531 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5532 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5533 CK1A105KLZBNG CERAMIC 1U K 10V
C5534 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5535 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5536 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5537 CK1A105KLZBNG CERAMIC 1U K 10V
C5538 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5539 CK1A105KLZBNG CERAMIC 1U K 10V
C5540 CK1A105KLZBNG CERAMIC 1U K 10V
C5541 CK1A105KLZBNG CERAMIC 1U K 10V
C5542 CK1A105KLZBNG CERAMIC 1U K 10V
C5544 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5545 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5547 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5548 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5549 CK1A105KLZBNG CERAMIC 1U K 10V
C5550 CK1A105KLZBNG CERAMIC 1U K 10V
C5551 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5552 CK1A105KLZBNG CERAMIC 1U K 10V
C5553 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5554 CK1A105KLZBNG CERAMIC 1U K 10V
C5555 CK1A105KLZBNG CERAMIC 1U K 10V
C5556 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5557 CK1A105KLZBNG CERAMIC 1U K 10V
C5559 CC1H7R0DLZCNG CERAMIC 7P D 50V
C5560 CK1A105KLZBNG CERAMIC 1U K 10V
C5561 CC1H7R0DLZCNG CERAMIC 7P D 50V
C5562 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5564 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5565 CK1A105KLZBNG CERAMIC 1U K 10V
C5566 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5567 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5568 CK1A105KLZBNG CERAMIC 1U K 10V
C5569 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5570 CK1A105KLZBNG CERAMIC 1U K 10V
C5571 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5572 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5573 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5574 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5575 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5576 CK1A105KLZBNG CERAMIC 1U K 10V
C5577 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5578 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5579 CK1A105KLZBNG CERAMIC 1U K 10V
C5580 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5581 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5582 CK1A105KLZBNG CERAMIC 1U K 10V
C5583 CK1A105KLZBNG CERAMIC 1U K 10V
C5584 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5585 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5586 CK1A105KLZBNG CERAMIC 1U K 10V
C5587 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5588 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5589 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5590 CK1A105KLZBNG CERAMIC 1U K 10V
C5591 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5592 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5593 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5594 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5595 CK1A105KLZBNG CERAMIC 1U K 10V
C5596 CK1A105KLZBNG CERAMIC 1U K 10V
C5597 CK1A105KLZBNG CERAMIC 1U K 10V
C5598 CC1H4R0CLZCNG CERAMIC 4P C 50V
C5599 CC1H4R0CLZCNG CERAMIC 4P C 50V
C5602 CK1A105KLZBNG CERAMIC 1U K 10V
C5603 CK1A105KLZBNG CERAMIC 1U K 10V
C5604 CK1A105KLZBNG CERAMIC 1U K 10V
C5605 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5606 CK1A105KLZBNG CERAMIC 1U K 10V
C5607 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V

– 11 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C5609 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5610 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5611 CK1A105KLZBNG CERAMIC 1U K 10V
C5612 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5613 CK1A105KLZBNG CERAMIC 1U K 10V
C5614 CK1A105KLZBNG CERAMIC 1U K 10V
C5615 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5616 CK1A105KLZBNG CERAMIC 1U K 10V
C5617 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5618 CK1A105KLZBNG CERAMIC 1U K 10V
C5619 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5620 CK1A105KLZBNG CERAMIC 1U K 10V
C5621 CK1A105KLZBNG CERAMIC 1U K 10V
C5622 CEXLB0J221VDN ELECT 220U M 6.3V
C5623 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5624 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5625 CEXLB1H4R7VDN ELECT 4.7U M 50V
C5630 CK1A105KLZBNG CERAMIC 1U K 10V
C5631 CEXLB1V470VDN ELECT 47U M 35V
C5650 CC1H470JLZCNG CERAMIC 47P J 50V
C5651 CC1H470JLZCNG CERAMIC 47P J 50V
C5652 CC1H470JLZCNG CERAMIC 47P J 50V
C5653 CC1H470JLZCNG CERAMIC 47P J 50V
C5654 CC1H470JLZCNG CERAMIC 47P J 50V
C5655 CC1H470JLZCNG CERAMIC 47P J 50V
C5656 CC1H470JLZCNG CERAMIC 47P J 50V
C5657 CC1H470JLZCNG CERAMIC 47P J 50V
C5658 CC1H470JLZCNG CERAMIC 47P J 50V
C5659 CC1H470JLZCNG CERAMIC 47P J 50V
C5660 CC1H470JLZCNG CERAMIC 47P J 50V
C5661 CC1H470JLZCNG CERAMIC 47P J 50V
C5662 CC1H470JLZCNG CERAMIC 47P J 50V
C5663 CC1H470JLZCNG CERAMIC 47P J 50V
C5664 CC1H470JLZCNG CERAMIC 47P J 50V
C5665 CC1H470JLZCNG CERAMIC 47P J 50V
C5666 CC1H470JLZCNG CERAMIC 47P J 50V
C5667 CC1H470JLZCNG CERAMIC 47P J 50V
C5702 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5703 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5704 CK1A105KLZBNG CERAMIC 1U K 10V
C5705 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5706 CK1A105KLZBNG CERAMIC 1U K 10V
C5707 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5709 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5710 CK1A105KLZBNG CERAMIC 1U K 10V
C5711 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5712 CK1A105KLZBNG CERAMIC 1U K 10V
C5713 CK1A105KLZBNG CERAMIC 1U K 10V
C5714 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5715 CK1A105KLZBNG CERAMIC 1U K 10V
C5716 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5717 CK1H103KLZBNG CERAMIC 0.01U K 50V
C5730 CEXLB0J221VEN ELECT 220U M 6.3V
C5731 CEXLB0J221VDN ELECT 220U M 6.3V
C5732 CK1A105KLZBNG CERAMIC 1U K 10V
C5737 CEXLB0J102VEN ELECT 1000U M 6.3V
C5750 CK1A105KLZBNG CERAMIC 1U K 10V
C5901 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5902 CK1E224KLZBNG CERAMIC 0.22U K 25V
C6101 CK1H103KLZBNG CERAMIC 0.01U K 50V
C6102 CK1H103KLZBNG CERAMIC 0.01U K 50V
C6105 CC1H470JLZCNG CERAMIC 47P J 50V
C6106 CC1H470JLZCNG CERAMIC 47P J 50V
C6110 CEXLB0J102VDN ELECT 1000U M 6.3V
C6111 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6112 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6130 CK1H102KLZBNG CERAMIC 1000P K 50V
C6131 CK1H102KLZBNG CERAMIC 1000P K 50V
C6133 CC1H120JLZCNG CERAMIC 12P J 50V
C6134 CC1H120JLZCNG CERAMIC 12P J 50V
C6135 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C6136 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C6200 CK1A105KLZBNG CERAMIC 1U K 10V
C6201 CK1A105KLZBNG CERAMIC 1U K 10V
C6204 CC1H471JLZCNG CERAMIC 470P J 50V
C6205 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6206 CC1H680JLZCNG CERAMIC 68P J 50V
C6207 CC1H680JLZCNG CERAMIC 68P J 50V
C6208 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6209 CEXLB1H100VDN ELECT 10U M 50V
C6210 CC1H680JLZCNG CERAMIC 68P J 50V
C6211 CC1H680JLZCNG CERAMIC 68P J 50V
C6212 CC1H471JLZCNG CERAMIC 470P J 50V
C6213 CK1A105KLZBNG CERAMIC 1U K 10V
C6214 CK1A105KLZBNG CERAMIC 1U K 10V
C6330 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6332 CEXLB1C101VDN ELECT 100U M 16V
C6510 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6533 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6563 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6600 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6602 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6603 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6604 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6605 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6606 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6607 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6609 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6610 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6611 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6612 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6613 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6614 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6615 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6616 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6617 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6618 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6630 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6631 CK1E105KGMBNG CERAMIC 1U K 25V
C6632 CEXLB0J221VDN ELECT 220U M 6.3V

– 12 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C6633 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6634 CEXLB0J221VDN ELECT 220U M 6.3V
C6650 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6651 CK1E105KGMBNG CERAMIC 1U K 25V
C6652 CEXLB1V470VDN ELECT 47U M 35V
C6653 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6654 CEXLB1V470VDN ELECT 47U M 35V
C6655 CEXLB1V470VDN ELECT 47U M 35V
C8501 CK1A105KLZBNG CERAMIC 1U K 10V
C8503 CK1H103KLZBNG CERAMIC 0.01U K 50V
C8504 CEXLB0J221VDN ELECT 220U M 6.3V
DIODES
D002 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D003 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D007 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D008 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D800 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D801 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D8500 DDDF2S6.8UFSG DIODE DF2S6.8UFS
D8501 DDDF2S6.8UFSG DIODE DF2S6.8UFS
D1000 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1001 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1610 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1620 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1621 DZ02DZ3.0Y—G ZENER DIODE 02DZ3.0Y(TPH3
DZUDZS3.0B—G ZENER DIODE UDZS3.0B-TE-1
DZXLBXB3.0B-G ZENER DIODE MM3Z3V0B
D1630 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1651 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1660 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1670 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1671 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1681 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1700 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D2402 DDRB551V-30-G DIODE RB551V-30-TE-17
D2403 DDRB551V-30-G DIODE RB551V-30-TE-17
D6501 DDRB551V-30-G DIODE RB551V-30-TE-17
D6502 DDRB551V-30-G DIODE RB551V-30-TE-17
D6503 DDRB551V-30-G DIODE RB551V-30-TE-17
INTEGRATED CIRCUITS
IC001 QSTA333W13TRP IC STA333W13TR
QTC7SET08FU-P IC TC7SET08FU-(TE85L)
QXXAVC924—-P IC 74AHCT1G08GW
IC800 QXXAAJQ1239— IC LC87F2932AVU-Y10LCD
IC800A QXXGA0500125M IC LC87F2932AVU-QIP-E
IC800C 1AA6P4P2084— LABEL-LC87F2932AVU-Y10LCD
IC801 QLE24C023M-EP IC LE24C023M-TLM-E
QXXAVC837—-P IC AT24C02BN-10SU-1.8
IC801 QXXAVC986—-P IC CAT24C02WI-GT3
IC804 QTC7SET14FU-P “IC TC7SET14FU-(TE85L,F”
QXXAVD177—-P “IC 74AHCT1G14GW,125”
IC1200 QCD4052BNSR-P IC CD4052BNSR
QTC4052BF—-P IC TC4052BF(EL)
IC1610 QLV5803M-E—P IC LV5803M-TE-L-E
IC1630 QLV5803M-E—P IC LV5803M-TE-L-E
IC1640 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC1660 QLM1117S-ADJP IC LM1117S-ADJ
IC1670 QXXGA0500165P IC LV5806MX-TLM-H
IC1700 QLV5803M-E—P IC LV5803M-TE-L-E
IC1801 QTC7SET08FU-P IC TC7SET08FU-(TE85L)
QXXAVC924—-P IC 74AHCT1G08GW
IC2401 QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2402 QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2404 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2405 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC5500 QXXAVD166—-M IC BCM35143KQLEG
IC5600 QLE24C023M-EP IC LE24C023M-TLM-E
QXXAVC837—-P IC AT24C02BN-10SU-1.8
QXXAVC986—-P IC CAT24C02WI-GT3
IC5623 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC5624 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC5700 QXXAVD153—-M IC A3R12E4JFF-G8E
IC5730 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC5750 QXXAAJQ1157— IC W25Q128BVFIG
IC5750A QXXAVD195—-P IC W25Q128BVFIG
IC5750C 1AA6P4P2088— LABEL-W25Q128BVFIG

– 13 –
Schematic
Location Part No. Description Schematic Location Part No. Description
IC5900 QXXAVD046—-P IC XC6108N28AMR
IC6200 QBA4558RF-E2P IC BA4558RF-E2
QNJM4558M—-P IC NJM4558M-TE2
IC6600 QTDA9996——M IC TDA9996
IC6630 QLM1117S-ADJP IC LM1117S-ADJ
IC6650 QLM1117S-ADJP IC LM1117S-ADJ
IC8500 QRT9711CGB—P IC RT9711CGB
COILS
L001 1LB4L26B1630G “INDUCTOR ,22UH”
L002 1LB4L26B1630G “INDUCTOR ,22UH”
L003 1LB4L26B1630G “INDUCTOR ,22UH”
L009 1LB4L26B0700G “INDUCTOR , 120 OHM”
L011 1LB4L26B0740G “INDUCTOR , 220 OHM”
L012 1LB4L26B0740G “INDUCTOR , 220 OHM”
L013 1LB4L26B1630G “INDUCTOR ,22UH”
L017 1LB4L26B0700G “INDUCTOR , 120 OHM”
L800 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L801 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1000 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1200 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1602 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1604 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1605 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1606 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1607 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1608 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1609 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1610 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1613 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1614 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1615 1LB4L26B1180G INDUCTOR 10U M
L1616 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1630 1LB4L26B1180G INDUCTOR 10U M
L1631 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1644 1LB4L26B1180G INDUCTOR 10U M
L1660 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1670 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1672 1LB4L26B1180G INDUCTOR 10U M
L1675 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1676 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1677 1LB4L26B0740G “INDUCTOR, 220 OHM”
L1680 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1683 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1684 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1716 1LB4L26B1180G INDUCTOR 10U M
L2401 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L5500 1LB4L26B0740G “INDUCTOR, 220 OHM”
L5501 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5502 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5503 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5504 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5505 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5506 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5507 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5508 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5509 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5511 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5512 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5513 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5514 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5515 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5516 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5517 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5518 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5519 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5520 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5521 1LB4L26B0700G “INDUCTOR, 120 OHM”
L5555 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
L5650 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5651 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5652 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5653 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5654 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5655 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5660 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5661 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5662 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5701 1LB4L26B0740G “INDUCTOR , 220 OHM”
L5730 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6100 RGF1200JTCANL MT-GLAZE 120 JA 1/10W
L6101 RGF1200JTCANL MT-GLAZE 120 JA 1/10W
L6104 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6105 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L6117 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6131 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L6132 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L6200 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6301 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6302 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6303 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6304 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6305 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6306 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6307 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6308 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6351 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6600 1LB4L26B0700G “INDUCTOR, 120 OHM”
L6630 1LB4L26B0740G “INDUCTOR, 220 OHM”
L6651 1LB4L26B0700G “INDUCTOR, 120 OHM”
L6670 1LB4L26B0700G “INDUCTOR, 120 OHM”
L6671 1LB4L26B0700G “INDUCTOR, 120 OHM”
L8500 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
TRANSISTORS
Q800 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q801 TISA1235AC1EP TR ISA1235AC1E
TISA1235AC1FP TR ISA1235AC1F
TXXLBB005—-P TR MMBTSA1235F
Q806 TISA1235AC1EP TR ISA1235AC1E

– 14 –
Schematic
Location Part No. Description Schematic Location Part No. Description
TISA1235AC1FP TR ISA1235AC1F
TXXLBB005—-P TR MMBTSA1235F
Q808 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1001 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1002 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1200 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1201 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1202 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1203 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1610 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1620 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1621 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1623 T2SC2411K-Q-P TR 2SC2411K-T146-Q
Q1670 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1700 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1801 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1802 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1805 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1806 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q2401 TUM6K1N——-P TR UM6K1N-TN
Q5580 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q6329 TMCH6331-S-EG TR MCH6331-S-TL-E
Q6330 T2SC2411K-Q-P TR 2SC2411K-T146-Q
Q6331 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q6332 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q6530 T3LN01C-E—-P TR 3LN01C-TB-E
Q8500 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
RESISTORS
R001 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R002 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R003 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R004 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R005 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R006 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R007 1LB4L26B0700G INDUCTOR“, 120 OHM”
R008 1LB4L26B0700G INDUCTOR“, 120 OHM”
R009 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R010 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R012 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R013 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R015 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R016 RGF1201JTCANL MT-GLAZE 1.2K JA 1/10W
R019 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R021 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R022 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R023 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R800 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R802 RGF2702JTCANL MT-GLAZE 27K JA 1/10W
R803 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R805 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R806 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R807 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R810 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R811 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R813 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R820 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R826 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R827 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R828 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R829 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R830 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R833 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R835 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R836 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R839 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R840 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R841 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R845 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R848 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R852 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R853 RGF1002JTCANL MT-GLAZE 10K JA 1/10W

– 15 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R854 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R857 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R858 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R859 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R860 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R861 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R862 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R865 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R871 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R873 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R875 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R876 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R877 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R879 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R883 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R884 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R885 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R886 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R887 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R888 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R890 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R891 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R892 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R893 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R894 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R897 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R899 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R901 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R902 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1005 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1012 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1014 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1015 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1016 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1018 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1019 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1020 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1021 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1022 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1036 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R1037 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1038 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1040 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R1041 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1042 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1043 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1044 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1045 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1046 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1047 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1048 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1049 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1050 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1051 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1052 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1053 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1054 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1055 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1056 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1057 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1058 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1077 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1096 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1098 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1100 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1102 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1104 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1106 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1108 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1110 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1200 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1201 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1202 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1203 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1205 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1207 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1208 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1209 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1600 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1607 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1610 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1612 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1613 RGF4701FTCANL MT-GLAZE 4.7K FA 1/10W
R1614 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1616 RGF1201FTCANL MT-GLAZE 1.2K FA 1/10W
R1618 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1622 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1623 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1624 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1625 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1628 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1630 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1631 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1632 RGF1501FTCANL MT-GLAZE 1.5K FA 1/10W
R1633 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1635 RGF4701FTCANL MT-GLAZE 4.7K FA 1/10W
R1637 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1638 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
R1640 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
R1641 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1643 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1644 RGF4700FTCANL MT-GLAZE 470 FA 1/10W
R1645 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1647 RGF68R0JTCANL MT-GLAZE 68 JA 1/10W
R1648 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1656 RG147R0JTEANL MT-GLAZE 47 JA 1W
R1657 RG122R0JTEANL MT-GLAZE 22 JA 1W
R1664 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R1665 RGF12R0JTCANL MT-GLAZE 12 JA 1/10W
R1666 RGF8200FTCANL MT-GLAZE 820 FA 1/10W
R1671 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1672 RGF2202JTCANL MT-GLAZE 22K JA 1/10W

– 16 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R1673 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1674 RGF1201FTCANL MT-GLAZE 1.2K FA 1/10W
R1675 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1677 RGF1802FTCANL MT-GLAZE 18K FA 1/10W
R1679 RGF1201FTCANL MT-GLAZE 1.2K FA 1/10W
R1682 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1684 RG14700JTEANL MT-GLAZE 470 JA 1W
R1685 RG1R470JTEANL MT-GLAZE 0.47 JA 1W
R1701 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1702 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1703 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1704 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1705 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1707 RGF4701FTCANL MT-GLAZE 4.7K FA 1/10W
R1709 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1800 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1801 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1802 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1805 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1806 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1807 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1808 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1810 RGF3300JTCANL MT-GLAZE 330 JA 1/10W
R1811 RGF3300JTCANL MT-GLAZE 330 JA 1/10W
R1812 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1813 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1826 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1827 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1829 1LB4L26B0700G INDUCTOR“, 120 OHM”
R1830 1LB4L26B0700G INDUCTOR“, 120 OHM”
R1833 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1835 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1842 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1843 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1844 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1847 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1848 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1850 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1851 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1852 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1853 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1854 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1856 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1858 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1869 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2404 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2405 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2406 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R2407 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R2408 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R2409 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R2410 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2411 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2412 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2414 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R2415 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R2419 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2420 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2421 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2422 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2426 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2427 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2428 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2429 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2430 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2434 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2435 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2436 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R2437 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R2438 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2445 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2446 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2448 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2449 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2455 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2457 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2458 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2460 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5500 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5501 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5502 RGF1501JTCANL MT-GLAZE 1.5K JA 1/10W
R5503 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5504 RGF1501JTCANL MT-GLAZE 1.5K JA 1/10W
R5505 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5506 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5507 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5508 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5509 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5510 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5511 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5512 RGF1201FTCANL MT-GLAZE 1.2K FA 1/10W
R5513 RGF1801FTCANL MT-GLAZE 1.8K FA 1/10W
R5514 RGF1004JTCANL MT-GLAZE 1M JA 1/10W
R5515 RGF1500JTCANL MT-GLAZE 150 JA 1/10W
R5516 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5517 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5518 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5519 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5520 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5521 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5522 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5523 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5524 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5525 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5526 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5527 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5528 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5529 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5530 RGF3901FTCANL MT-GLAZE 3.9K FA 1/10W
R5531 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5532 RGF1004JTCANL MT-GLAZE 1M JA 1/10W
R5533 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W

– 17 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R5534 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5535 RGF82R0JTCANL MT-GLAZE 82 JA 1/10W
R5536 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5540 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5541 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5542 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5545 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5547 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5548 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5549 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5550 RGF82R0JTCANL MT-GLAZE 82 JA 1/10W
R5559 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5561 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5562 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5563 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5565 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5566 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5568 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5569 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5571 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5572 1LB4L26B0700G INDUCTOR“, 120 OHM”
R5573 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5574 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5575 1LB4L26B0700G INDUCTOR“, 120 OHM”
R5578 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5581 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5585 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5586 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5587 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5588 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5591 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5594 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5596 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5600 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5601 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5623 1LB4L26B0700G INDUCTOR“, 120 OHM”
R5624 1LB4L26B0700G INDUCTOR“, 120 OHM”
R5700 RGF1000FTCANL MT-GLAZE 100 FA 1/10W
R5701 RGF1000FTCANL MT-GLAZE 100 FA 1/10W
R5702 RGF56R0FTCANL MT-GLAZE 56 FA 1/10W
R5703 RGF56R0FTCANL MT-GLAZE 56 FA 1/10W
R5730 RG1R470JTEANL MT-GLAZE 0.47 JA 1W
R5731 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5733 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
R5736 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5737 RGF4700FTCANL MT-GLAZE 470 FA 1/10W
R5738 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R5740 RGF68R0JTCANL MT-GLAZE 68 JA 1/10W
R5751 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5753 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5900 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5901 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5902 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5949 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5950 RGF22R0JTCANL MT-GLAZE 22 JA 1/10W
R5954 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5955 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5956 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5957 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5959 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R6100 RGF8201JTCANL MT-GLAZE 8.2K JA 1/10W
R6101 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6104 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6105 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6107 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6109 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6110 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6116 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6130 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R6200 RGF2201FTCANL MT-GLAZE 2.2K FA 1/10W
R6201 RGF2201FTCANL MT-GLAZE 2.2K FA 1/10W
R6202 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R6203 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R6204 RGF6802FTCANL MT-GLAZE 68K FA 1/10W
R6205 RGF6802FTCANL MT-GLAZE 68K FA 1/10W
R6206 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6207 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6208 RGF6802FTCANL MT-GLAZE 68K FA 1/10W
R6209 RGF6802FTCANL MT-GLAZE 68K FA 1/10W
R6210 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R6211 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R6212 RGF2201FTCANL MT-GLAZE 2.2K FA 1/10W
R6213 RGF2201FTCANL MT-GLAZE 2.2K FA 1/10W
R6318 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6319 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6321 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6322 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6330 RG11500JTEANL MT-GLAZE 150 JA 1W
R6331 RG11500JTEANL MT-GLAZE 150 JA 1W
R6332 RG11500JTEANL MT-GLAZE 150 JA 1W
R6337 RGF1504JTCANL MT-GLAZE 1.5M JA 1/10W
R6339 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6340 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6341 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6342 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R6344 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R6346 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R6348 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R6350 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R6372 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6376 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6377 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R6509 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6510 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6511 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6512 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6513 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6514 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6515 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6516 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W

– 18 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R6517 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6518 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6519 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6520 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6531 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R6532 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6539 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6540 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6541 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6542 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6543 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6544 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6545 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6546 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6547 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6548 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6549 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6550 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6569 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6570 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6571 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6572 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6573 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6575 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6576 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6577 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6578 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6579 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6580 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6581 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6600 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6601 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6604 RGF1202FTCANL MT-GLAZE 12K FA 1/10W
R6630 RGF2200FTCANL MT-GLAZE 220 FA 1/10W
R6631 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6632 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R6650 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R6651 RGF12R0JTCANL MT-GLAZE 12 JA 1/10W
R6652 RGF2200FTCANL MT-GLAZE 220 FA 1/10W
R8502 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8504 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R8506 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R8507 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R8508 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8509 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
R8510 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R8511 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
CRYSTAL / FILTERS
X800 1AV4V11B1771G “OSC,CERAMIC 8.00MHZ”
X801 1AV4V10B0560N “OSC,CRYSTAL 32.768KHZ”
X5500 1AV4V10B9220G “OSC,CRYSTAL 54.1MHZ”
X5501 1AV4V10B9280G “OSC,CRYSTAL 24MHZ”

– 19 –
Schematic
Location Part No. Description Schematic Location Part No. Description
MISCELLANEOUS
A100 1AA0B10N28100 “ASSY,PWB,MAIN_B-N7AL”
A200 1AA0B10N284A0 “ASSY,PWB,KEY_SW N7AL”
A300 1AA0B10N28800 “ASSY,PWB,RC_LED B N7AL”
A400 1AA0B10N29000 “ASSY,PWB,POWER N7AL”
A6100 1AV4F1BAZ0120 “TUNER,U/V”
EL901 1AV4T40C18400 LCD(T420HW06 V2)
K1003 1LB4J31B01101 “TERMINAL, BOARD”
K1004 1LB4J12B11700 “JACK,RCA-9”
K1005 1LB4J12B11600 “JACK,RCA-6”
K2401 1LB4J12B11900 “JACK,PHONE D3.6”
K2402 1LB4J11B0630N “SOCKET,D-SUB 15P”
K5LVDS 1AV4J10XE400G “PLUG,40P”
K6501 1AV4J11B9810G “SOCKET,IF(HDMI) 19P”
K6502 1AV4J11B9810G “SOCKET,IF(HDMI) 19P”
K6503 1AV4J11B9810G “SOCKET,IF(HDMI) 19P”
K802 1AV4J10EA053N “PLUG,5P”
K803 1AV4J10EA073N “PLUG,7P”
K8B 1AV4J10FT140N “PLUG,PWB 14P”
K8CTR 1AV4J10AU085N “PLUG,8P”
K8L 1AV4J10AU055N “PLUG,5P”
KSP 1AV4J10EA043N “PLUG,4P”
KUSB 1LB4J11B0550N “SOCKET,USB 4P”
PB5500 1LG4B10Y04600 “PWB,MAIN, N7AL”
SPL 1LB4A10B08700 “SPEAKER,8”
SPR 1LB4A10B08700 “SPEAKER,8”
W901 1AV4W10B17904 “CORD,POWER-2.0MK-VTR-02”
WK5LV-PN 1AA4W30B62700 “CORD 42INCH,40P-51P(LVDS)”
PPOOWWEERRBBOOAARRDDPPAARRTTSSLLIISSTT
CAPACITORS
C605 CGXAV27224ABC MT-POLYEST 0.22U M 275V
CGXAV27224BBC MT-POLYEST 0.22U K 275V
C606 CGXAV27224ABC MT-POLYEST 0.22U M 275V
CGXAV27224BBC MT-POLYEST 0.22U K 275V
C607 CKXAV2E101AAC CERAMIC 100P M 250V
C608 CEXAVB03000-N ELECT 470U M 250V
C609 CGXAV27224ABC MT-POLYEST 0.22U M 275V
CGXAV27224BBC MT-POLYEST 0.22U K 275V
C610 CK3A102KANHAN CERAMIC 1000P K 1K
C611 CK3A102KANHAN CERAMIC 1000P K 1K
C612 CK3A102KANHAN CERAMIC 1000P K 1K
C613 CK3A102KANHAN CERAMIC 1000P K 1K
C614 CEXAVB03000-N ELECT 470U M 250V
C615 CK1E474KLZBNG CERAMIC 0.47U K 25V
C616 CC3D220JAHGEN CERAMIC 22P J 2K
C617 CG2J123KAPAQN MT-POLYEST 0.012U K 630V
C619 CE1V560MMVANN ELECT 56U M 35V
CE1V560MNRANN ELECT 56U M 35V
C620 CK1H104KLZBNG CERAMIC 0.1U K 50V
C621 CK1H104KLZBNG CERAMIC 0.1U K 50V
C624 CK1H473KLZBNG CERAMIC 0.047U K 50V
C625 CK1H104KLZBNG CERAMIC 0.1U K 50V
C626 CE1H100MMVANN ELECT 10U M 50V
CE1H100MNRANN ELECT 10U M 50V
C627 CK1H105KGNBNG CERAMIC 1U K 50V
C628 CC1H681JLZCNG CERAMIC 680P J 50V
C629 CC1H101JLZCNG CERAMIC 100P J 50V
C630 CM2J823JAWAQN MT-POLYPRO 0.082U J 630V
C631 CK3D101KANHAN CERAMIC 100P K 2K
CK3D101KCRDAN CERAMIC 100P K 2K
C632 CK3D471KANHAN CERAMIC 470P K 2K
CK3D471KCRDAN CERAMIC 470P K 2K
C633 CK3D150JTDANG CERAMIC 15P J 2K
C634 CK3D150JTDANG CERAMIC 15P J 2K
C635 CK1E474KLZBNG CERAMIC 0.47U K 25V
C638 CKXAV2E471AAC CERAMIC 470P M 250V
C639 CK1H102KLZBNG CERAMIC 1000P K 50V
C640 CE1H220MMVANN ELECT 22U M 50V
CE1H220MNRANN ELECT 22U M 50V
C641 CK1H104KLZBNG CERAMIC 0.1U K 50V
C642 CK1H104KLZBNG CERAMIC 0.1U K 50V
C643 CK1H104KLZBNG CERAMIC 0.1U K 50V
C645 CM2J823JAWAQN MT-POLYPRO 0.082U J 630V
C646 CKXAV2E101AAC CERAMIC 100P M 250V
C647 CKXAV2E101AAC CERAMIC 100P M 250V
C649 CK1H102KLZBNG CERAMIC 1000P K 50V
C650 CKXAV2E102AAC CERAMIC 1000P M 250V
C653 CKXAV2E102AAC CERAMIC 1000P M 250V
C701 CK3A102KANHAN CERAMIC 1000P K 1K
CK3A102KCRDAN CERAMIC 1000P K 1K
C702 CK3A102KANHAN CERAMIC 1000P K 1K
CK3A102KCRDAN CERAMIC 1000P K 1K
C703 CE1V681M2FANN ELECT 680U M 35V

– 20 –
Schematic
Location Part No. Description Schematic Location Part No. Description
CE1V681M6QANN ELECT 680U M 35V
C704 CE1V681M2FANN ELECT 680U M 35V
CE1V681M6QANN ELECT 680U M 35V
C705 CE1V471M2FANN ELECT 470U M 35V
CE1V471M6QANN ELECT 470U M 35V
C706 CK3A102KANHAN CERAMIC 1000P K 1K
CK3A102KCRDAN CERAMIC 1000P K 1K
C707 CK3A102KANHAN CERAMIC 1000P K 1K
CK3A102KCRDAN CERAMIC 1000P K 1K
C708 CE1E102M2FANN ELECT 1000U M 25V
CE1E102M6QANN ELECT 1000U M 25V
C710 CK1H104KLZBNG CERAMIC 0.1U K 50V
C711 CK1E475KGNBNG CERAMIC 4.7U K 25V
C712 CK3A102KANHAN CERAMIC 1000P K 1K
CK3A102KCRDAN CERAMIC 1000P K 1K
C713 CE1C272M2FANN ELECT 2700U M 16V
CE1C272M6QANN ELECT 2700U M 16V
C714 CE1C102M6RANN ELECT 1000U M 16V
CE1C102MMYANN ELECT 1000U M 16V
C715 CK1H104KLZBNG CERAMIC 0.1U K 50V
C717 CE1H220MMVANN ELECT 22U M 50V
CE1H220MNRANN ELECT 22U M 50V
C718 CK1H105KGNBNG CERAMIC 1U K 50V
C719 CK1H105KGNBNG CERAMIC 1U K 50V
C720 CK1H104KLZBNG CERAMIC 0.1U K 50V
C721 CK1H104KLZBNG CERAMIC 0.1U K 50V
C722 CK1H104KLZBNG CERAMIC 0.1U K 50V
C723 CK1H104KLZBNG CERAMIC 0.1U K 50V
C724 CK1H104KLZBNG CERAMIC 0.1U K 50V
C725 CK1H102KLZBNG CERAMIC 1000P K 50V
C726 CK1H104KLZBNG CERAMIC 0.1U K 50V
C727 CK1H104KLZBNG CERAMIC 0.1U K 50V
C729 CK1H104KLZBNG CERAMIC 0.1U K 50V
C730 CK1H104KLZBNG CERAMIC 0.1U K 50V
C732 CK1E474KLZBNG CERAMIC 0.47U K 25V
C733 CE1V471M2FANN ELECT 470U M 35V
CE1V471M6QANN ELECT 470U M 35V
C734 CK1H104KLZBNG CERAMIC 0.1U K 50V
C735 CE1E102M2FANN ELECT 1000U M 25V
CE1E102M6QANN ELECT 1000U M 25V
DIODES
D601 DDXLBB092—-N DIODE D15XB60 7101
D602 DDEG01C——-N DIODE EG01C
DDXLBB011—-N DIODE EG01C
D603 DDEU1———-N DIODE EU1
DDXLBB017—-N DIODE EU1
D605 DCBPC-817MC-N PHOTO COUPLE BPC-817MC
DCPC123X5YFZN PHOTO COUPLE PC123X5YFZ0F
D606 DCBPC-817MC-N PHOTO COUPLE BPC-817MC
DCPC123X5YFZN PHOTO COUPLE PC123X5YFZ0F
D607 DCBPC-817MC-N PHOTO COUPLE BPC-817MC
DCPC123X5YFZN PHOTO COUPLE PC123X5YFZ0F
D608 DCBPC-817MC-N PHOTO COUPLE BPC-817MC
DCPC123X5YFZN PHOTO COUPLE PC123X5YFZ0F
D609 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D611 DDAG01A——-N DIODE AG01A
D612 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D613 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D614 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D616 DDEU1———-N DIODE EU1
DDXLBB017—-N DIODE EU1
D617 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D618 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D619 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D620 DZ02DZ18Y—-G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS18B—-G ZENER DIODE UDZS18B-TE-17
DZXLBXB18B—G ZENER DIODE MM3Z 18B
D621 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D622 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D623 DZMTZJ27B—-N ZENER DIODE MTZJ27B
D624 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D625 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D626 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D627 DZMTZJ13B—-N ZENER DIODE MTZJ13B
D628 DDXLBB088—-N DIODE STPS20LCD100C
DDXLBB090—-N DIODE SBR200-10JS
D629 DDXLBB088—-N DIODE STPS20LCD100C
DDXLBB090—-N DIODE SBR200-10JS
D630 DDSBT80-06JSN DIODE SBT80-06JS
DDXLBB086—-N DIODE STPS10LCD60C
D631 DDSBT80-06JSN DIODE SBT80-06JS
DDXLBB086—-N DIODE STPS10LCD60C
D632 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D633 DZPTZ13B——G ZENER DIODE PTZ13B-TE25
D636 DD1SS352——G DIODE 1SS352-(TPH3)
