SERVICE MANUAL LCD Television

FILE NO.

Original Version

Chassis Series: UH3-B

N5YV/N5ZV/N5ZW

Model No. LCD-32S10

LCD-42S10

LCD-42S10-HD

Give complete “SERVICE REF. NO.” for

parts order or servicing. It is shown on the

rating plate at the cabinet back of the unit.

This T.V. receiver will not work properly in

foreign countries where the television

transmission system and power source dif-

fer from the design specifications. Refer to

the specification table.

Product Code: 32S10: 1-130-131-16

42S10: 1-130-132-16

42S10-HD: 1-130-132-17

Contents

Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chassis Block Diagrams . . . . . . . . . . . . . . . . . . 4

CPU Block Diagrams . . . . . . . . . . . . . . . . . . . . . 5

On-screen Service Menu system . . . . . . . . . . . . 6

Service Adjustments . . . . . . . . . . . . . . . . . . . . . 7

Mechanical Disassembly . . . . . . . . . . . . . . . . . . 8-13

Chassis Electrical Parts List . . . . . . . . . . . . . . . 14-62

PCB Assemble . . . . . . . . . . . . . . . . . . . . . . . . . . 63-64

Printed Wiring Board . . . . . . . . . . . . . . . . . . . . . 65-70

Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . 71-73

REFERENCE NO. SM3010333

Service Ref. No. LCD-32S10-00

LCD-42S10-00

LCD-42S10-HD-00

(Whole Asia)

COVER-SM-LCD-S10 5/8/08 8:36 AM Page 1

Safety Notice

Safety Precautions

The following precautions must be observed.

1:Comply with all caution and safety-related notes provided on the cabinet back, cabinet bottom, inside the

cabinet or on the chassis.

2:When replacing a chassis in the cabinet, always be certain that all the protective devices are installed

properly, such as, control knobs, adjustment covers or shields, barriers, etc..

DO NOT OPERATE THIS TELEVISION WITHOUT THE PROTECTIVE SHIELD IN POSITION AND

PROPERLY SECURED

3:Before replacing the cabinet cover, thoroughly inspect the inside of the cabinet to see that no stray parts or

tools have been left inside.

Before returning any televison to the customer, the service personnel must be sure that it is completely safe

to operate without danger of electrical shock.

Product Safety Notice

Product safety should be considered when a component replacement is made in any area of a receiver.

Components indicated by mark in the parts list and the schematic diagram designate components in

which safety can be of special signicance.

It is particularly recommended that only parts designated on the parts list In this manual be used for

component replacement designated by mark .

No deviations from resistance Wattage or voltage ratings may be made for replacement items designated

by mark .

Specications

Model LCD-32S10/LCD-42S10/LCD-42S10-HD

Maximum Visible Range LCD-32S10: 80cm ; LCD-42S10/-HD: 107cm (Screen Diagonal Size)

Picture Resolution 1366(H) x 768(V)

Viewable Angle(L。

/3) L/R:+/- 89D, U/D:+/- 89D

Brightness 500cd/m²

Contrast LCD-32S10/LCD-42S10: 1200:1 LCD-42S10-HD: 1500:1

Definition RF Analog Signals: Horizontal≥350; Vertical≥400

Degree of Colour Coverage ≥30%

Mobile Trailer Time LCD-32S10/LCD-42S10: 8ms LCD-42S10-HD: 6.5ms

Voltage AC110-242V 50/60Hz

Power Consumption LCD-32S10: 144W ; LCD-42S10: 187W ; LCD-42S10-HD: 250W

Power Management VESA DPMS

Colour System PAL/NTSC/NTSC4.43/SECAM

Sound System D/K, I, M, B/G

Channel Coverage - VHF: E2-E12, R1-R12, K1-K9, J1-J12, A2-A13

- UHF: 21-69, A14-A69, J13-J62

- CATV: S1-S41, X, Y, Z, Z+1, Z+2

Aerial input impedance 75Ω

Speaker Size Mains: 4.5cm x 13cm x 2pcs Woofer: 8cm x 8cm x 1pcs

Sound speciality Maximum Output Power is 10W+10W+10W

Total Harmonic Distortion(THD)≤10%

Input terminals VGA Terminal : RGB X 1 HDMI terminal: x2

Audio: Mini stereo jack x 1 (Audio input of VGA)

Video: Composite video terminals x1 (1Vp-p, 75Ω)

S-VIDEO input: x 1 (DIN 4-pin, Y/C separate signal input)

DVD input: Component video input Y, CB/PB, CR/PRinput x 1

Audio input: (R/L) x 4 (400mVrms)

USB input (Just for LCD-42S10-HD): Different value input D+, D-

MINI USB input (Just for LCD-42S10-HD): Different value input D+, D-

Output terminals Video Monitor Output: x1 (1Vp-p, 75Ω)

Audio Monitor Output: R/L x 1（400mVrms, ≤1KΩ)

Headphone Jack : Mini stereo jack x1

Dimensions

(Width x Height x Depth) LCD-32S10: 790mm x 579mm x270mm (Including Stand)

LCD-42S10/-HD: 1012mm x 699mm x270mm (Including Stand)

Net Weight

(Including Stand) LCD-32S10: < 14.1 KG ; LCD-42S10/-HD: < 24.6 KG

Operating Environment

Operating Temperature 0ºC~40ºC（32ºF~104ºF）

Operating Humidity 20~80%

Storage Temperature -10ºC~50ºC（14ºF~122ºF）

Storage Humidity 20~80%

Chassis Block Diagrams

MST6E89DL

CPU Block Diagrams

LCD-CA10

07.12.21

丁

渊源

摇控器

On-screen Service Menu System

1) How to enter the Service Menu

1. Press MENU button on SIDE controls, MENU will display.

2. Press and hold MENU button on SIDE controls and press “1” button on remote controls. SERVICE

MENU will display.

General

This set has an On-screen Menu system included in the CPU that allows remote operation for most of the

service adjustments.

"1" button

Remote controls

Menu button

SIDE Controls

2) How to select the service section and service item and change data value:

To select service section: Press the Cursor ▲ or ▼ button on the remote control hand set, and press the

Cursor ◄ or ► button to enter the SUB menu.

To change data value: Select service item by pressing the Cursor ▲or ▼ button , and change data value by

pressing the Cursor ◄ or ► button.

3) Exit from the service menu

Press the MENU button repeatedly or turn off the TV set by pressing the POWER ON/OFF button.

How to adjust White Balance Adjustment

1. Input a white pattern(80%) to the composite input terminal.

2. Set the television to following conditions:

Picture mode: standard

Colour temperature: normal

Pre-heading time: more than 10 minutes

3. Enter the service menu, and select WHITE BALANCE with ▲ or ▼ key.

Press ◄► to enter the White Balance Adjustment , press corresponding number key to adjust R,G,B.

3. After adjustment, conrm white balance again by normal picture.

Service Adjustments

Important Notice:

Do not attempt to adjust service adjustments not listed below otherwise it may cause loss of performance

and for correct operation.

White Balance Adjustment

红色"+"

红色"-"

绿色"-"

蓝色"-"

绿色"+"

蓝色"+"

Red "+" Green "+" Blue "+"

Red "-" Green "-" Blue "-"

Mechanical Disassembly (LCD-42S10-HD)

(一) Cabinet Back Removal

1. Remove screws A，B.

2. Take the Cabinet Back off.

(A:16pcs，B:4pcs)

AAAA

POWER BOARD

LCD SCREEN

KEY&LED

BOARDS

MAIN

BOARD

USB

BOARD

Mechanical Disassembly(LCD-42S10-HD)

（二）Chassis and Terminal Board Removal

1. Remove screws C，D and G, take the terminal board off.

2. Remove Screw E，F take Power Board，Main Board，Usb Board and WOOFER off.

（C: 2pcs，D: 2pcs，E：15pcs，F: 4pcs，G: 2pcs)

Mechanical Disassembly (LCD-42S10)

(一) Cabinet Back Removal

1. Remove screws A，B.

2. Take the Cabinet Back off.

(A:16pcs，B:4pcs)

AAAA

POWER BOARD

LCD SCREEN

KEY&LED

BOARDS

MAIN

BOARD

Mechanical Disassembly(LCD-42S10)

（二）Chassis and Terminal Board Removal

1. Remove screws C，D and G, take the terminal board off.

2. Remove Screw E，F take Power Board，Main Board and WOOFER off.

（C: 2pcs，D: 2pcs，E：12pcs，F: 4pcs，G: 2pcs)

Mechanical Disassembly (LCD-32S10)

(一) Cabinet Back Removal

1. Remove screws A，B.

2. Take the Cabinet Back off.

(A:9pcs，B:4pcs)

AAA

POWER BOARD

LCD SCREEN

KEY&LED

BOARDS

MAIN

BOARD

Mechanical Disassembly(LCD-32S10)

（二）Chassis and Terminal Board Removal

1. Remove screws C，D and G, take the terminal board off.

2. Remove Screw E，F take Power Board，Main Board and WOOFER off.

（C: 2pcs，D: 2pcs，E：12pcs，F: 4pcs，G: 2pcs)

-14-

N5YV

OUT OF CIRCUIT BOARD

LCD PANEL

EL901 6450953774 LCD(T315XW02 VC01)

MISCELLANEOUS

SP901 6520025844 SPEAKER,8

SP902 6520025844 SPEAKER,8

W901 6450940354 CORD,POWER-2.23MK-VAR-2

6103394695 ASSY,PWB, POWER, N5YV

1AA0B10S2650A

TRANSISTOR

Q1603 4051814609 TR 2SK3264

Q1606 4050180606 TR 2SC3332-S

Q601 4052211308 TR STW25NM50N

Q602 4051789709 TR 2SK3505

Q604 4051789709 TR 2SK3505

Q6800 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q681 4060213004 TR CJD400-E

4050235009 TR 2SD400-E-MP

Q682 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q683 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q684 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q685 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

Chassis Electrical Parts List

Ref. No. Part No. Description Ref. No. Part No. Description

Product safety should be considered when a component replacement is made in any area of a receiver.

Components indicated by a mark in this parts list and the circuit diagram show components whose value have

special significance to product safety. It is particularly recommended that only parts specified on the following parts

list be used for components replacement pointed out by the mark.

Note: Parts order must contain Chassis No., Part No., and descriptions. The main PCB unit will be supplied without tuner and

flyback transformer. They should be ordered separately.

Read description in the Capacitor and Resistor as follows:

CAPACITOR

CERAMIC 100P K 50V

Rated Voltage

Tolerance Symbols:

Less than 10pF

A : Not specified B : ±0.1pF C : ±0.25pF

D : ±0.5pF F : ±1PF G : ±2pF

R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF

More than 10pF

A : Not specified B : ±0.1% C : ±0.25%

D : ±0.5% F : ±1% G : ±2%

H : ±3% J : ±5% K : ±10%

L : ±15% M : ±20% N : ±30%

P : +100-0% Q : +30-10% T : +50-10%

U : +75-10% V : +20-10% W : +100-10%

X : +40-20% Y : +150-10% Z : +80-20%

Rated value: P=pico farad, U=micro farad

Material:

CERAMIC........... Ceramic

MT-PAPER......... Metallized Paper

POLYESTER...... Polyester

MT-POLYEST.....Metallized Polyester

POLYPRO.......... Polypropylene

MT-POLYPRO....Metallized Polypropylene

COMPO FILM.....Composite film

MT-COMPO........Metallized Composite

STYRENE...........Styrene

TA-SOLID........... Tantalum Solid

AL-SOLID........... Aluminium Solid

ELECT................ Electrolytic

NP-ELECT..........Non-polarised Electrolytic

OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic

DL-ELECT.......... Double Layered Electrolytic

RESISTOR

CARBON 4.7K J A 1/4W

Rated Wattage

Performance Symbols:

A: General B: Non flammable Z: Low noise

Other: Temperature coefficient

Tolerance Symbols:

A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%

F: ±1% G: ±2% J: ±5% K: ±10%

M: ±20% P: +5-15%

Rated value, ohms:

K: 1,000, M: 1,000,000

Material:

CARBON........... Carbon

MT-FILM............ Metal Film

OXIDE-MT......... Oxide Metal Film

SOLID................ Composition

MT-GLAZE......... Metal Glaze

WIRE WOUND...Wire Wound

CERAMIC RES.. Ceramic

FUSIBLE RES....Fusible

NOTES:

P List-N5YV(UH3-B) 5/8/08 8:00 AM Page 14

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q690 4052203115 TR ISA1235AC1E

4052203016 TR ISA1235AC1F

4060214308 TR MMBTSA1235F

4051345925 TR 2SA1037AK-T146-R

4051472215 TR 2SA1037AK-S-T146

4051739615 TR 2SA1235A1E

4051739714 TR 2SA1235A1F

Q691 4060214407 TR MMBTSC3928R

4050144519 TR 2SC2412K T146 R

4050144618 TR 2SC2412K T146 S

4050158724 TR 2SC2812-L6-TB

4050158922 TR 2SC2812-L7-TB

4051631612 TR 2SC2812N-L6-TB0

4051739813 TR 2SC3928A1R

4051739912 TR 2SC3928A1S

Q692 4052203115 TR ISA1235AC1E

4052203016 TR ISA1235AC1F

4060214308 TR MMBTSA1235F

4051345925 TR 2SA1037AK-T146-R

4051472215 TR 2SA1037AK-S-T146

4051739615 TR 2SA1235A1E

4051739714 TR 2SA1235A1F

INTEGRATED CIRCUIT

IC1601 4096910512 IC FAN7602M

IC602 4096910215 IC UCC28019DR

IC604 4096915200 IC TL431ATA

4091802307 IC UPC1093J

IC610 4096915200 IC TL431ATA

4091802307 IC UPC1093J

IC633 4096867618 IC L6599DTR

IC670 4094991503 IC KIA78R05PI

CAPACITOR

C1601 4041098002 ELECT 47U M 35V

4034208708 ELECT 47U M 35V

C1602 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1603 4041046706 CERAMIC 0.047U K 50V

4040914501 CERAMIC 0.047U K 50V

C1604 4041084500 ELECT 47U M 25V

C1605 4041032402 CERAMIC 1000P K 50V

4040901105 CERAMIC 1000P K 50V

C1606 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1607 4041111701 ELECT 47U M 50V

C1608 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1609 4041032907 CERAMIC 0.01U K 50V

4040901204 CERAMIC 0.01U K 50V

C1610 4041111503 CERAMIC 2200P K 2K

4040861904 CERAMIC 2200P K 2K

C1655 4041112500 CERAMIC 470P K 2K

4040862109 CERAMIC 470P K 2K

4032454404 CERAMIC 470P K 2K

C1664 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1675 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1689 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C1693 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C601 4040888802 MT-POLYEST 0.22U M 275V

4040941804 MT-POLYEST 0.22U K 275V

C602 4040733904 CERAMIC 1000P K 250V

4041113903 CERAMIC 1000P M 400V

C6024 4032812412 CERAMIC 0.22U K 16V

4033645910 CERAMIC 0.22U K 16V

C603 4040733904 CERAMIC 1000P K 250V

4041113903 CERAMIC 1000P M 400V

C604 4040888802 MT-POLYEST 0.22U M 275V

4040941804 MT-POLYEST 0.22U K 275V

C605 4040888802 MT-POLYEST 0.22U M 275V

4040941804 MT-POLYEST 0.22U K 275V

C606 4040733706 CERAMIC 100P K 250V

4041144204 CERAMIC 100P K 400V

C607 4032601600 MT-POLYEST 1U J 400V

4034334516 MT-POLYEST 1U K 400V

C608 4032601600 MT-POLYEST 1U J 400V

4034334516 MT-POLYEST 1U K 400V

C611 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C612 4041102600 ELECT 10U M 16V

C613 4041045402 CERAMIC 1800P K 50V

4040913009 CERAMIC 1800P K 50V

4031577015 CERAMIC 1800P K 50V

C614 4041040308 CERAMIC 1000P J 50V

4040946502 CERAMIC 1000P J 50V

C615 4041167500 CERAMIC 1U K 16V

C616 4041045600 CERAMIC 220P K 50V

4040913207 CERAMIC 220P K 50V

4031576216 CERAMIC 220P K 50V

C617 4041150809 CERAMIC 0.22U K 50V

4040913405 CERAMIC 0.22U K 50V

C618 4033238815 CERAMIC 2.2U Z 16V

C619 4040888802 MT-POLYEST 0.22U M 275V

4040941804 MT-POLYEST 0.22U K 275V

C620 4034271811 MT-POLYEST 0.1U K 450V

C625 4034271811 MT-POLYEST 0.1U K 450V

C626 4034271811 MT-POLYEST 0.1U K 450V

C630 4041046508 CERAMIC 470P K 50V

4040914303 CERAMIC 470P K 50V

C631 4041045204 CERAMIC 1500P K 50V

4040901303 CERAMIC 1500P K 50V

C632 4041150809 CERAMIC 0.22U K 50V

4040913405 CERAMIC 0.22U K 50V

C633 4041032402 CERAMIC 1000P K 50V

4040901105 CERAMIC 1000P K 50V

C634 4041150809 CERAMIC 0.22U K 50V

4040913405 CERAMIC 0.22U K 50V

C635 4041112500 CERAMIC 470P K 2K

4040862109 CERAMIC 470P K 2K

4032454404 CERAMIC 470P K 2K

C636 4041149902 MT-POLYPRO 0.047U H 800V

4041109401 MT-POLYPRO 0.047U J 800V

C637 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C638 4041084500 ELECT 47U M 25V

C639 4041003105 POLYESTER 0.1U J 100

4032564826 MT-COMPO 0.1U J 100V

4032564836 MT-COMPO 0.1U J 100

4032564806 MT-COMPO 0.1U J 100V

C640 4041150809 CERAMIC 0.22U K 50V

4040913405 CERAMIC 0.22U K 50V

C647 4041166404 ELECT 220U M 450V

C652 4040735106 CERAMIC 470P K 250V

4041144303 CERAMIC 470P K 400V

C653 4040735106 CERAMIC 470P K 250V

-15-

N5YV

Ref. No. Part No. Description Ref. No. Part No. Description

P List-N5YV(UH3-B) 5/8/08 8:00 AM Page 15

-16-

N5YV

4041144303 CERAMIC 470P K 400V

C654 4040733706 CERAMIC 100P K 250V

4041144204 CERAMIC 100P K 400V

C655 4041112500 CERAMIC 470P K 2K

4040862109 CERAMIC 470P K 2K

4032454404 CERAMIC 470P K 2K

C661 4040912606 CERAMIC 0.1U K 50V

4033701517 CERAMIC 0.1U K 50V

C662 4041064700 ELECT 2200U M 35V

C663 4041064205 ELECT 1000U M 35V

4034315505 ELECT 1000U M 35V

C664 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C665 4041064205 ELECT 1000U M 35V

4034315505 ELECT 1000U M 35V

C666 4041078400 CERAMIC 1000P K 1K

4040846307 CERAMIC 1000P K 1K

4032221303 CERAMIC 1000P K 1K

4032719602 CERAMIC 1000P K 1K

C667 4041078400 CERAMIC 1000P K 1K

4040846307 CERAMIC 1000P K 1K

4032221303 CERAMIC 1000P K 1K

4032719602 CERAMIC 1000P K 1K

C670 4041063802 ELECT 1000U M 16V

C671 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C672 4041064304 ELECT 470U M 16V

C673 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C675 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C676 4041064205 ELECT 1000U M 35V

C677 4041064700 ELECT 2200U M 35V

C678 4041078400 CERAMIC 1000P K 1K

4040846307 CERAMIC 1000P K 1K

4032221303 CERAMIC 1000P K 1K

4032719602 CERAMIC 1000P K 1K

C679 4041078400 CERAMIC 1000P K 1K

4040846307 CERAMIC 1000P K 1K

4032221303 CERAMIC 1000P K 1K

4032719602 CERAMIC 1000P K 1K

C6800 4040912606 CERAMIC 0.1U K 50V

4033701517 CERAMIC 0.1U K 50V

C6803 4040912606 CERAMIC 0.1U K 50V

4033701517 CERAMIC 0.1U K 50V

C682 4041098408 ELECT 100U M 25V

4034275304 ELECT 100U M 25V

C683 4041063703 ELECT 2200U M 25V

4034311804 ELECT 2200U M 25V

C684 4041032907 CERAMIC 0.01U K 50V

4040901204 CERAMIC 0.01U K 50V

C689 4040912606 CERAMIC 0.1U K 50V

4032245715 CERAMIC 1000P K 50V

C690 4041063802 ELECT 1000U M 16V

C691 4041063703 ELECT 2200U M 25V

C692 4041063901 ELECT 1000U M 25V

4034309702 ELECT 1000U M 25V

C693 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C694 4040912606 CERAMIC 0.1U K 50V

4033701517 CERAMIC 0.1U K 50V

C695 4041078400 CERAMIC 1000P K 1K

4040846307 CERAMIC 1000P K 1K

4032221303 CERAMIC 1000P K 1K

4032719602 CERAMIC 1000P K 1K

C696 4040912606 CERAMIC 0.1U K 50V

4033701517 CERAMIC 0.1U K 50V

C698 4041044900 CERAMIC 0.1U K 50V

4040912606 CERAMIC 0.1U K 50V

C699 4041064304 ELECT 470U M 16V

RESISTOR

R1601 4012552710 MT-GLAZE 3.9M JA 1/4W

R1602 4012552710 MT-GLAZE 3.9M JA 1/4W

R1603 4011882818 MT-GLAZE 56K JA 1/4W

R1604 4011879214 MT-GLAZE 10 JA 1/4W

R1605 4011882610 MT-GLAZE 56 JA 1/4W

R1606 4011505915 MT-GLAZE 10K JA 1/10W

R1607 4011506219 MT-GLAZE 1K JA 1/10W

R1608 4021196308 OXIDE-MT 0.47 JA 1W

4020949509 OXIDE-MT 0.47 JA 1W

4021205000 OXIDE-MT 0.47 JA 1W

4010575216 OXIDE-MT 0.47 JA 1W

R1609 4012189213 MT-GLAZE 100 JA 1/3W

R1610 4011881217 MT-GLAZE 33 JA 1/4W

R1611 4012560210 MT-GLAZE 120K JA 1/10W

R1612 4012565314 MT-GLAZE 56K JA 1/10W

R1613 4012559214 MT-GLAZE 6.2K JA 1/10W

R1614 4011624111 MT-GLAZE 5.6K JA 1/10W

R1615 4011035610 MT-GLAZE 10K JA 1/4W

R1616 4011880517 MT-GLAZE 2.2K JA 1/4W

R1617 4011882818 MT-GLAZE 56K JA 1/4W

R1618 4021034501 OXIDE-MT 68K JA 2W

4020932709 OXIDE-MT 68K JA 2W

4010694511 OXIDE-MT 68K JA 2W

R1619 4011842010 MT-GLAZE 2.2 JA 1/2W

R1621 4012552710 MT-GLAZE 3.9M JA 1/4W

R1622 4012552710 MT-GLAZE 3.9M JA 1/4W

R1623 4012556114 MT-GLAZE 20K JA 1/10W

R1685 4012566014 MT-GLAZE 27K JA 1/10W

R6002 4012565611 MT-GLAZE 47 JA 1/10W

R6003 4012641919 MT-GLAZE 10K FA 1/10W

R6005 4012641810 MT-GLAZE 1K FA 1/10W

R6006 4012582618 MT-GLAZE 150 FA 1/10W

R6008 4011882313 MT-GLAZE 4.7K JA 1/4W

R6009 4011506110 MT-GLAZE 2.2K JA 1/10W

R601 4010104802 CARBON 470K JA 1/2W

4021038400 CARBON 470K JA 1/2W

4020925305 CARBON 470K JA 1/2W

R602 4010104802 CARBON 470K JA 1/2W

4021038400 CARBON 470K JA 1/2W

4020925305 CARBON 470K JA 1/2W

R604 4012552710 MT-GLAZE 3.9M JA 1/4W

R605 4012552710 MT-GLAZE 3.9M JA 1/4W

R606 4021102408 OXIDE-MT 0.27 JA 2W

4020934406 OXIDE-MT 0.27 JA 2W

4012280415 OXIDE-MT 0.27 JA 2W

R607 4021102408 OXIDE-MT 0.27 JA 2W

4020934406 OXIDE-MT 0.27 JA 2W

4012280415 OXIDE-MT 0.27 JA 2W

R608 4011880418 MT-GLAZE 220 JA 1/4W

R609 4011505816 MT-GLAZE 100K JA 1/10W

R615 4012567318 MT-GLAZE 6.8K JA 1/10W

R616 4012567615 MT-GLAZE 3.9K JA 1/10W

R618 4012543015 MT-GLAZE 33K JA 1/4W

R621 4011882016 MT-GLAZE 4.7 JA 1/4W

R624 4011881217 MT-GLAZE 33 JA 1/4W

R626 4011881910 MT-GLAZE 390K JA 1/4W

R627 4011881910 MT-GLAZE 390K JA 1/4W

R630 4021096400 OXIDE-MT 12K JA 1W

4021048409 OXIDE-MT 12K JA 1W

4010589817 OXIDE-MT 12K JA 1W

R636 4012566311 MT-GLAZE 47K JA 1/10W

R637 4012646518 MT-GLAZE 2.2K FA 1/10W

Ref. No. Part No. Description Ref. No. Part No. Description

P List-N5YV(UH3-B) 5/8/08 8:00 AM Page 16

R642 4011505915 MT-GLAZE 10K JA 1/10W

R643 4012563617 MT-GLAZE 15K JA 1/10W

R644 4012561415 MT-GLAZE 330K JA 1/10W

R645 4012555810 MT-GLAZE 2K JA 1/10W

R647 4011505915 MT-GLAZE 10K JA 1/10W

R648 4012566311 MT-GLAZE 47K JA 1/10W

R649 4011879214 MT-GLAZE 10 JA 1/4W

R650 4011879214 MT-GLAZE 10 JA 1/4W

R651 4012566311 MT-GLAZE 47K JA 1/10W

R652 4011879214 MT-GLAZE 10 JA 1/4W

R653 4012566212 MT-GLAZE 270 JA 1/10W

R654 4021036406 OXIDE-MT 0.68 JA 1W

4020949608 OXIDE-MT 0.68 JA 1W

4010576817 OXIDE-MT 0.68 JA 1W

R655 4011879214 MT-GLAZE 10 JA 1/4W

R656 4012560012 MT-GLAZE 120 JA 1/10W

R658 4021173200 SOLID 10M KA 1/2W

R659 4021173200 SOLID 10M KA 1/2W

R661 4021096103 OXIDE-MT 0.47 JA 2W

4020931405 OXIDE-MT 0.47 JA 2W

4010642106 OXIDE-MT 0.47 JA 2W

R664 4011836712 MT-GLAZE 3.3K JA 1/2W

R666 4011836712 MT-GLAZE 3.3K JA 1/2W

R667 4011506219 MT-GLAZE 1K JA 1/10W

R670 4021196308 OXIDE-MT 0.47 JA 1W

4020949509 OXIDE-MT 0.47 JA 1W

4010575216 OXIDE-MT 0.47 JA 1W

R671 4012566014 MT-GLAZE 27K JA 1/10W

R672 4011623718 MT-GLAZE 4.7K JA 1/10W

R6800 4011506219 MT-GLAZE 1K JA 1/10W

R6801 4011506110 MT-GLAZE 2.2K JA 1/10W

R6802 4012655718 MT-GLAZE 8.2K FA 1/10W

R6803 4012643715 MT-GLAZE 1.5K FA 1/10W

R6804 4012641919 MT-GLAZE 10K FA 1/10W

R6805 4011623619 MT-GLAZE 470 JA 1/10W

R6806 4012566014 MT-GLAZE 27K JA 1/10W

R6807 4011623718 MT-GLAZE 4.7K JA 1/10W

R6809 4011623015 MT-GLAZE 22K JA 1/10W

R6810 4011505915 MT-GLAZE 10K JA 1/10W

R6811 4011506219 MT-GLAZE 1K JA 1/10W

R6812 4011506219 MT-GLAZE 1K JA 1/10W

R6813 4011506219 MT-GLAZE 1K JA 1/10W

R6814 4011506219 MT-GLAZE 1K JA 1/10W

R684 4021196407 OXIDE-MT 10 JA 1W

4020926302 OXIDE-MT 10 JA 1W

4010581118 OXIDE-MT 10 JA 1W

R685 4012566014 MT-GLAZE 27K JA 1/10W

R686 4011603314 MT-GLAZE 1.5K JA 1/4W

R687 4011623718 MT-GLAZE 4.7K JA 1/10W

R688 4011623718 MT-GLAZE 4.7K JA 1/10W

R691 4011623619 MT-GLAZE 470 JA 1/10W

R692 4011880418 MT-GLAZE 220 JA 1/4W

R693 4011623718 MT-GLAZE 4.7K JA 1/10W

R694 4011623015 MT-GLAZE 22K JA 1/10W

R695 4011506219 MT-GLAZE 1K JA 1/10W

R696 4011506219 MT-GLAZE 1K JA 1/10W

R697 4011506110 MT-GLAZE 2.2K JA 1/10W

R698 4011624111 MT-GLAZE 5.6K JA 1/10W

R699 4011465110 MT-GLAZE 1K JA 1/4W

TRANSFORMER

T601 6520025189 TRANS,POWER,PULSE

T602 6520025165 TRANS,POWER,PULSE

COIL

L601 6520024755 LINE FILTER

L602 6520024106 LINE FILTER

L603 6520024106 LINE FILTER

L604 6520024106 LINE FILTER

L605 6520025196 INDUCTOR ,500UH

L660 6520024144 INDUCTOR,0.8UH

L661 6520024144 INDUCTOR,0.8UH

L662 6520001749 CORE,PIPE

L663 6520024144 INDUCTOR,0.8UH

L670 6520001749 CORE,PIPE

L671 6520001749 CORE,PIPE

DIODE

D1601 4080476205 ZENER DIODE MTZJ36A

D1602 4080585105 DIODE LL4148

D1604 4080584207 DIODE EU1

D1605 4080475307 ZENER DIODE MTZJ16A-52

D1606 4080584207 DIODE EU1

D1607 4080456603 DIODE EG01C

4080583804 DIODE EG01C

D601 4072494309 DIODE FMD-G26S

D602 4080614706 DIODE RL255

D603 4080643409 DIODE D10SB60

D604 4072187518 ZENER DIODE UDZS16B-TE-17

4080647506 ZENER DIODE MM3Z 16B

D610 4080585105 DIODE LL4148

D611 4080585105 DIODE LL4148

D612 4080585105 DIODE LL4148

D630 4080585105 DIODE LL4148

D631 4080585105 DIODE LL4148

D638 4080475307 ZENER DIODE MTZJ16A-52

D650 4072626700 PHOTO COUPLE BPC-817MC

4072348701 PHOTO COUPLE PC123X5YFZ

4072303908 PHOTO COUPLE PC123Y52

D651 4072626700 PHOTO COUPLE BPC-817MC

4072348701 PHOTO COUPLE PC123X5YFZ

4072303908 PHOTO COUPLE PC123Y52

D652 4072626700 PHOTO COUPLE BPC-817MC

4072348701 PHOTO COUPLE PC123X5YFZ

4072303908 PHOTO COUPLE PC123Y52

D661 4072538102 DIODE RB215T-90

D670 4080458508 DIODE RU3YX

4080651107 DIODE RU3YX

D673 4080660505 DIODE RN1Z

D674 4080584207 DIODE EU1

D6801 4080585105 DIODE LL4148

D6802 4080585105 DIODE LL4148

D6803 4080585105 DIODE LL4148

D6804 4080585105 DIODE LL4148

D6805 4072219615 ZENER DIODE UDZS27B-TE-17

4080641306 ZENER DIODE MM3Z 27B

D6806 4072219615 ZENER DIODE UDZS27B-TE-17

4080641306 ZENER DIODE MM3Z 27B

D6807 4072089713 ZD UDZS-TE-175.6B

4080629700 ZENER DIODE MM3Z5V6B

D6808 4072312217 ZENER DIODE UDZS13B-TE-17

4080646707 ZENER DIODE MM3Z13B

D682 4072217116 ZENER DIODE UDZS-TE-1712B

4080631802 ZENER DIODE MM3Z12B

D690 4072537501 DIODE RB085T-60

D691 4080585105 DIODE LL4148

MISCELLANEOUS

F601 4240067403 FUSE 250V 5A

R603 4080563707 THERMISTOR NTPAD5R1LDNB0

VA601 4072254309 VARISTOR ENE621D-14A

4072620609 VARISTOR MYG3-14K385

-17-

N5YV

Ref. No. Part No. Description Ref. No. Part No. Description

P List-N5YV(UH3-B) 5/8/08 8:00 AM Page 17

-18-

N5YV

6103395449 ASSY,PWB, KEY, N5YV

1AA0B10S2650B

CAPACITOR

C1900 4040949800 CERAMIC 0.1U Z 25V

4031640214 CERAMIC 0.1U Z 25V

RESISTOR

R1900 4012563617 MT-GLAZE 15K JA 1/10W

R1901 4012563617 MT-GLAZE 15K JA 1/10W

R1902 4012560418 MT-GLAZE 12K JA 1/10W

R1903 4012560111 MT-GLAZE 8.2K JA 1/10W

R1904 4012567219 MT-GLAZE 18K JA 1/10W

R1905 4012565314 MT-GLAZE 56K JA 1/10W

R1906 4012560418 MT-GLAZE 12K JA 1/10W

R1907 4012560111 MT-GLAZE 8.2K JA 1/10W

R1908 4012567219 MT-GLAZE 18K JA 1/10W

R1909 4011506011 MT-GLAZE 0.000 ZA 1/10W

R1910 4011506011 MT-GLAZE 0.000 ZA 1/10W

R1911 4011506011 MT-GLAZE 0.000 ZA 1/10W

R1912 4011506011 MT-GLAZE 0.000 ZA 1/10W

COIL

L1900 6450046650 INDUCTOR,600 OHM

DIODE

ZD1900 4072065618 ZENER DIODE UDZS-TE-1710B
