Saramonic Blink100 User manual

User Manual
Blink100
用户手册
2.4GHz迷你双通道无线麦克风系统
Ultracompact 2.4GHz Dual-Channel
Wireless Microphone System

Statement
Please read this manual carefully before using and strictly operate
and store it in accordance with the instructions. Please save the
manual for your future reference.
If you need further assistance than the user manual, please consult
your retailer for help or email us: [email protected]
Cautions
1. Disintegration of this device by non-professionals is strictly
prohibited.
2. Please keep it away from heat sources such as heaters or ovens.
3. Do not remove the battery without professionals’ help.
4. Please clean the device with only a soft, dry cloth.
5. When using and storing, please pay attention to dust and moisture.
6. For the best pick-up pattern, do not hold your hand against the
microphone capsule cover.
01

Available Kits
In the box
Blink100 TX×1
Blink100 RX×1
Blink100 TX×2
Blink100 RX×1
Model
Blink100 B1
Blink100 B2
02

General Introduction
Wireless Transmitter Blink100 TX
①
⑤
⑥
②
④
③
03
Saramonic Blink100 is an ultracompact and portable 2.4GHz wireless
microphone system, compatible with smartphones, tablets, DSLR
cameras, and camcorders. It features automatic pairing and
selectable noise cancellation, delivering broadcast-quality sound.
Blink100 is ideal for live streaming, vlogging, mobile journalism and
more.
Product Structure

① Status indicator
Note: Please charge the transmitter in time when in a low battery
status, or it will auto shut off within 10 mins.
Status
Power ON/ Unpaired/ Pairing
Power OFF
Paired Successfully
Mute ON
Mute OFF
Noise Cancellation ON
Noise Cancellation OFF
Low Battery
Charging
Charging as Using
Fully Charged
Indicator
Blinks blue quickly
Red light steady for 1s then off
Static blue light
Blinks red slowly (per second)
Red light off
Static green light
Green light off
Blinks red quickly
Static red light
Static red & blue light
Red light off
② Power/Mute button
Function
Power ON/ OFF
Mute ON/ OFF
Operation
Press and hold for 2s
Short press
04

③ + -/NR button
·Press +/- button to adjust mic gain. (The setting is retained even
after the power is turned off.)
·Press and hold or continuously press "+"/ "-" to adjust mic gain to
maximum/ minimum, the indicator flashes blue twice (flashes green
twice in noise cancellation mode).
·Press the NR button (press both “+” and “-” buttons at the same
time) to turn on/off noise cancellation. (Default setting is off.)
④ Belt clip
⑤ Built-in microphone
⑥ USB-C charging port (DC 5V)
Use the supplied USB-C charging cable to charge the unit.
Wireless Receiver Blink100 RX
①
③
④
⑤
②
05

① Status indicator
Note: Please charge the receiver in time when in a low battery status,
or it will auto shut off within 10 mins.
Status
Power ON/ Unpaired/ Pairing
Power OFF
Paired Successfully
Low Battery
Charging
Charging as Using
Fully Charged
Indicator
Blinks blue quickly
Red light steady for 1s then off
Static blue light
Blinks red quickly
Static red light
Static red & blue light
Red light off
② Power button
Press and hold the power button for 2s to turn it on/ off.
③ LINE OUT jack
Connect the Blink100 RX to a smartphone, tablet, camera, recorder
or mixer with the supplied output cables.
④ USB-C charging port (DC 5V)
Use the supplied USB-C charging cable to charge the unit.
⑤ Belt clip
06

How to use
For the Blink100 B1/B2 kit
1. Press and hold the power button for 2 seconds to turn on the
transmitter/receiver.
2. Transmitter and receiver will be successfully paired within 10s.
3. You are ready to record.
Note: Due to 2.4GHz wireless frequency, signal can be easily
attenuated. Please try to avoid obstacles, such as walls and buildings,
and avoid close proximity to devices with 2.4GHz signal, such as high-
power Wi-Fi antennas, radios, etc.
09

Specifications
Transmission Type
Polar Pattern
Frequency Response
SNR
Sensitivity
Transmission Range
TX’s Battery Life
Battery Capacity
Charging Port
Dimensions
Weight
2.4GHz
Omnidirectional
20Hz-16kHz
76dB
-39±2dB
50m (without obstacles)
Approx. 10 hours
90mAh
USB-C
TX/RX: 39×35×14mm
TX/RX: 0.58oz (16.5g)
10

Packing list
11
Blink100 B1
Blink100 TX Transmitter ×1
Blink100 RX Receiver ×1
3.5mm TRS to TRS Output Cable for Cameras ×1
3.5mm TRS to TRRS Output Cable for Smartphones ×1
USB-C Charging Cable ×2
Fur Windshield ×1
Blink100 B2
Blink100 TX Transmitter ×2
Blink100 RX Receiver ×1
3.5mm TRS to TRS Output Cable for Cameras ×1
3.5mm TRS to TRRS Output Cable for Smartphones ×1
USB-C Charging Cable ×3
Fur Windshield ×2

声明
请在使用前仔细阅读本手册，并严格按照说明进行操作和存储。请妥善保
存好说明书以供将来参考。如果用户手册不能帮助您解决某些问题，请向
零售商寻求帮助或给我们发送电子邮件：[email protected]。
注意事项
1. 请勿在水下使用本机，不要将其暴露在雨中。请存放在阴凉干燥处。
2. 请在常温下使用并保存。请勿经常在冷热交替状态下使用设备，并远离
加热器和烤箱等热源。
3. 使用和存放时，请注意防尘和防潮。
4. 避免剧烈碰撞。
5. 为避免声音反馈，请勿将麦克风靠近扬声器。
6. 为获得最佳拾音模式，请勿将手放在麦克风咪头上。
12

可选套装组合
套装内容
Blink100 TX×2
Blink100 RX×1
型号
Blink100 B2
13
Blink100 TX×1
Blink100 RX×1
Blink100 B1

概述
无线发射器Blink100 TX
14
枫笛Blink100是一款迷你便携的2.4GHz无线麦克风系统，兼容智能手机、
平板电脑、单反相机和摄像机。产品具有自动配对和可选择的降噪功能,可
提供出色的广播级音质，适用于直播、视频内容创作、移动新闻等场景。
产品结构
①
⑤
⑥
②
④
③

① 状态指示灯
注意：发射器处于低电量时请及时充电，否则发射器会在10分钟内关机。
状态
开机/未联机/对码中
关机
联机成功
静音开启时
静音关闭时
降噪开启时
降噪关闭时
低电量
充电中
边充电边使用
充满电
指示灯
蓝灯快闪
红灯常亮1秒后熄灭
蓝灯常亮
红灯慢闪 (每秒1次)
红灯熄灭
绿灯常亮
绿灯熄灭
红灯快闪
红灯常亮
红蓝灯常亮
红灯熄灭
② 电源/静音键
功能
开/关机
静音开启/关闭
操作
长按2秒
短按
15

③ +- / NR键
·按+或-键调节麦克风增益（即使在电源关闭后，该参数设定仍然保留）。
·长按或连续按“+”/“-”可将麦克风增益调节到最大/最小，指示灯呈蓝
灯闪烁两次（在降噪模式下呈绿灯闪烁两次）。
·长按NR键（+-键同时按）开启/关闭降噪功能。（默认降噪功能为关闭状
态）
④ 背夹
⑤ 内置麦克风
⑥ USB-C充电口（直流电5V）
使用随附的USB-C充电线进行充电。
无线接收器Blink100 RX
①
③
④
⑤
②
16

① 状态指示灯
注意：接收器处于低电量时请及时充电，否则接收器会在10分钟内关机。
状态
开机/未联机/对码中
关机
联机成功
低电量
充电中
边充电边使用
充满电
指示灯
蓝灯快闪
红灯常亮1秒后熄灭
蓝灯常亮
红灯快闪
红灯常亮
红蓝灯常亮
红灯熄灭
② 电源键
长按电源键2秒即可开机/关机。
③ LINE OUT线性输出孔
使用随附输出线，将Blink100 RX连接至手机、平板电脑、相机、录音笔或混
音器等设备。
④ USB-C充电口（直流电5V）
使用随附的USB-C充电线进行充电。
⑤ 背夹
17

Blink100 B1/B2套装
1. 长按电源键2秒，将发射器、接收器开机；
2. 发射器和接收器将在10秒内完成配对；
3. 开始录音。
注意：由于在2.4GHz频谱下，信号很容易受干扰，请尽量避开墙壁和建筑
物等障碍物，避免接近2.4GHz频率的设备，如大功率WiFi天线、收音机等。
使用方法
20

信号传输
指向性
频率响应
信噪比
灵敏度
传输距离
TX续航
电池容量
充电接口
尺寸
重量
2.4GHz
全向
20Hz-16kHz
76dB
-39±2dB
无障碍50米
约10小时
90mAh
USB-C
TX/RX: 39×35×14mm
TX/RX: 16.5g
参数
21

包装清单
22
Blink100 B1
Blink100 TX发射器 ×1
Blink100 RX接收器 ×1
3.5mm TRS转TRS相机输出线 ×1
3.5mm TRS转TRRS手机输出线 ×1
USB-C充电线 ×2
防风毛套 ×1
Blink100 B2
Blink100 TX发射器 ×2
Blink100 RX接收器 ×1
3.5mm TRS转TRS相机输出线 ×1
3.5mm TRS转TRRS手机输出线 ×1
USB-C充电线 ×3
防风毛套 ×2

SmartRecorder is recommended.
为获得更好的录制体验，推荐使用枫笛 Saramonic
自主研发应用软件 SmartRecorder。
For better recording experience, the application
Shenzhen Jiayz Photo Industrial., Ltd
深圳市长丰影像器材有限公司
A16 Building, Intelligent Terminal Industrial Park of Silicon Valley
Power, Guanlan, Longhua District, Shenzhen, China
深圳市龙华区观澜街道大富工业区硅谷动力智能终端产业园A16栋
400-613-1096 www.saramonic.com
Scan the QR code and follow us！
[email protected]
