Sargent 1130 Series User manual

Top Jamb
Installation
See Page 5
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Right Hand Door - RH
Left Hand Reverse - LHR
Regular Arm
Installation
See Page 2
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand Door - LH
Right Hand Reverse - RHR
Top Jamb
Installation
See Page 5
Regular Arm
Installation
See Page 2
Parallel Arm
Installation
See Pages
3 & 4
Parallel Arm
Installation
See Pages
3 & 4
CAUTION
CAUTION
An Incorrectly installed or improperly adjusted
door closer can cause property damage or
personal injury. These installation instructions
should be followed to avoid the possibility of
misapplication or misadjustment.
Installation Instructions
80-9311-0011-021 Rev 2
Non Hold Open Models
Adjustable
(Sizes 1 thru 6)
1131
Non Handed Door Closer
1130 Series
Doors should be hung on ball bearing or
anti-friction hinges.
A separate door stop is recommended.
Door and frame must be properly
reinforced.
Adjust closing time speed between 3 and 7
seconds from 90° to 0°.
These door closers should NOT be
installed on the exposed side (weather
side) of exterior doors.
3/16"
#7
1/4-20
Spring Power Adjustment
Screw 1131 Series
"BC" Valve
Pinion Cap
Closer
Size
Stamp "L"Valve "S"Valve
Standard Components Optional Components
1-6
Closer Body
Cover
Sleeve Nut and Bolt
Drill 9/32 thru from Closer Side
3/8 Drill other side
(Optional)
Metal Wood
RU Soffit Plate
Used with Parallel
Arm Closers Only
Soffit Plate
Regular Arm/Top
Jamb Shoe Main Arm
Connecting Rod Forearm
Screw Arm Slide
Arm Assembly
Machine Screws
#7 Drill, 1/4-20 Tap
Self Drilling Screws
Wood and Metal
For Wood drill 3/16 hole
A7674C
Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company, All rights reserved. Reproduction
in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

3
2
7
1
3
4
Non Hold Open Door Closers — Regular Arm
5
Latch
Sweep
Parts
6
Backcheck
6
(152)
1-3/4
(44)
1-1/4
(32)
3/4
(19) 9-1/16
(230)
7/8
(22)
A
80-9311-0011-021 Rev 2
Opening
To 100°
101° to 120°
121° to 180°
*
7
(178)
6
(152)
3-1/2
(89)
Dimension "A"
Door/Wall/Hardware/Jamb
*
conditions permitting
Right Hand Shown
BC
LS
L
S
1131 Spring
Power Adjust
(If Necessary)
AB
F
90°
E
DInches
(mm)
— 2 —
P
A
(2)
or
G
Pinion Cap
or Optional Cover
Caution:
Don't completely
close valve
Optional
Cover
C
L
Y
S
Z
R
LS
Stronger
+
Weaker
-
Slower
-
Faster
+
Faster
+
Slower
-
Stronger
+
Weaker
-
1130 Series
A7674C

Parts
Right Hand Shown
2
1
Non Hold Open Door Closers — Parallel Arm
34
Door
Opening
To 100°
101° to 130°
131° to 180°
*
A
9-1/4
(235)
7-3/4
(197)
5-3/4
(146)
B
7-5/8
(194)
6-1/8
(156)
4-1/8
(105)
2-3/4
(70) 3/8
(10)
1/2
(13)
7/16
(11)
2
(50)
A
3-1/4
(83)
3/4
(19)
9-1/16
(230) C
L
B
Top of
Door
Door/Wall/Hardware/Jamb
*
conditions permitting
Inches
(mm)
5
— 3 —
S
L
Place Arm on
Spindle
R
o
t
a
t
e
Remove Arm
from Spindle
Close Valves
LS
Latch
Sweep
Optional
Cover
See Step 6 on Page 4
Frame
Slower
-
Slower
-
80-9311-0011-021 Rev 2
1130 Series
A7674C

13 14
12
Non Hold Open Door Closers — Parallel Arm
11
Latch
Sweep
Backcheck
68
7
910
Spring Power
Adjust 1131
(If necessary)
PA
BC
S
L
S
L
1-1/2
(38)
— 4 —
or
(2)
Assemble Arm
Arm Screw
Open Valves
Caution:
Don't completely
close valve
Pinion Cap
or Optional Cover
L
Y
S
Z
R
L
Y
S
Z
R
Left Hand
Door
Right Hand
Door
or
B
A
Flat
Flat
Slower
-
Faster
+
Weaker
-
Stronger
+
Stronger
+
Weaker
-
Slower
-
Faster
+
Caution:
Do Not Back
Valve Out
Completely
80-9311-0011-021 Rev 2
1130 Series
A7674C

(2)
6
1
3
2
7
5
4
Non Hold Open Door Closers — Top Jamb Arm
Latch
Sweep
Backcheck
9-1/16
(230) 3/4
(19)
1/2
(13)
6
(152)
1-1/2
(38)
1-3/4
(44)
C
L
A
Opening
To 100°
101° to 120°
121° to 180°
*
7-1/2
(191)
6
(152)
3-1/2
(89)
Dimension "A"
Door/Wall/Hardware/Jamb
*
conditions permitting
Right Hand Shown
BC
LS
L
S
1131 Spring
Power Adjust
(If Necessary)
90°
Top of
Door
Inches
(mm)
— 5 —
D
B
AE
F
P
A
G
Parts
Caution:
Don't completely
close valve
A longer connecting
rod is required
for reveals greater
than 3" (76)
or
Pinion Cap
or Optional Cover
Optional
Cover
Reveal
C
L
Y
S
Z
R
Stronger
+
Weaker
-
Slower
-
Faster
+
Faster
+
Slower
-
Stronger
+
Weaker
-
80-9311-0011-021 Rev 2
1130 Series
A7674C

Backcheck
BC
Sweep
LS
Latch
L
S
— 6 —
To identify your model: Arm Placement in Shoe
CLOSED
70°
10°
Spring Power
Adjust 1131
PA
Date
Code
or
or
7-1/2 % Stronger
7-1/2 % Weaker
(Use 3/16" Hex Wrench for this Adjustment)
(Use 1/8" Hex Wrench for these Adjustments)
Stronger
+
Weaker
-
Slower
-
Faster
+
Faster
+
Slower
-
Stronger
+
Weaker
-
1-6
BE
Size
Code
+
-
1130 Series Adjustments Page
80-9311-0011-021 Rev 2
For installation assistance, contact SARGENT at 800-810-WIRE (9473)
Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
1- 6=1131
A7674C
= 8 Turns As Shipped
Adjustment Chart
EXTERIOR
INTERIOR
Regular Arm
Top Jamb
Regular Arm
Top Jamb
Parallel Arm
Parallel Arm
FULL 360° TURNS OF
3/16 POWER
ADJUSTMENT WRENCH
1131
DOOR
TYPE
OF
INST. *34”
(0.85M)
36”
(0.90M)
40”
(1.00M)
44”
(1.10M)
48”
(1.20M)
24610 12
35811 14
35811 14
5811 16 19
30 FULL (360°) TURNS MAXIMUM AVAILABLE
*
MAXIMUM DOOR SIZE
Number of Turns Required
