Sargent POWERGLIDE Series Instruction Manual

1
1
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.
MODEL 351 POWERGLIDE SERIES
INSTRUCTIONS FOR INSTALLING SARGENT DOOR
CLOSERS WITH "H" HOLDER ARMS
351 SERIES NON SIZED ADJUS ABLE SIZES 1 HRU 6
CAU ION: FAILURE O INS ALL OR ADJUS PROPERLY MAY RESUL IN INJURY OR DAMAGE.
FOR ASSIS ANCE, CALL SARGEN A 1-800-727-5477.
LEFT
HAND DOOR
RIGHT
HAND DOOR
PULL
HINGE SIDE
PULL
HINGE SIDE
STOP (PUSH) SIDE STOP (PUSH) SIDE
NOTE: FOR H8 ARM MOUNTING
SEE DATA SHEETS ENCLOSED
STANDARD APPLICATION
(TYPE 25-H ARM) NUMBER OF TURNS OF SPRING POWER ADJUSTING SCREW
FROM FACTORY SETTING (USE CHART AS GUIDE ONLY)
DOOR WIDTH
(INCHES)
24
30
32
36
40
42
44
46
48
OVER 48
EXTERIOR DOORS
FACTORY SET
1-4 CW
4-7 CW
7-10 CW
10-12 CW
UP TO 18 CW AS REQ.
INTERIOR DOORS
1-5 CCW
FACTORY SET
1-5 CW
5 CW AND UP AS REQ.
APPROXIMATE
DOOR WEIGHT (POUNDS)
80
110
115
130
150
155
165
170
180
NUMBER OF TURNS OF SPRING POWER ADJUSTING NUT
FROM FACTORY SETTING (USE CHART AS GUIDE ONLY)
DOOR WIDTH
(INCHES)
24
30
32
36
40
42
44
46
48
OVER 48
EXTERIOR DOORS
2-6 CW
6-8 CW
8-11 CW
11-13 CW
UP TO 18 CW AS REQ.
INTERIOR DOORS
1-5 CCW
FACTORY SET
1-7 CW
8 CW AND UP AS REQ.
APPROXIMATE
DOOR WEIGHT (POUNDS)
80
110
115
130
150
155
165
170
180
ADJUST SPRING POWER ACCORDING TO CHART*
ADJUST SPRING POWER ACCORDING TO CHART*
INCREASE
POWER
CLOCKWISE
(CW)
DECREASE
POWER
COUNTER CLOCKWISE
(CCW)
+-
*IF INTERIOR DOORS DO NOT HAVE TO COMPLY WITH ADA REQUIREMENTS, EXTERIOR DOOR SETTINGS
ARE RECOMMENDED. WHERE STRONG DRAFTS EXIST, INCREASE SPRING POWER AS NEEDED BY TURNING
SPRING ADJUSTMENT SCREW CLOCKWISE. IF NECESSARY, REDUCE SPRING POWER BY TURNING SCREW
COUNTERCLOCKWISE.
5/8" SPRING POWER
ADJUSTMENT NUT
USE
PAGE 2
USE
PAGE 3
USE
PAGE 4
PARALLEL ARM
APPLICATION
(TYPE 25-PH9)
CLOSER MOUNTED ON
STOP SIDE OF DOOR
TOP JAMB
APPLICATION
(TYPE 25-H, 25-HZ, 25-HZA)
CLOSER MOUNTED ON FRAME
ON STOP SIDE OF DOOR
CLOSER MOUNTED ON
HINGE SIDE OF DOOR
STANDARD & TOP JAMB APPLICATIONS
PARALLEL APPLICATION ONLY

2
351 STANDARD APPLICATION INSTRUCTIONS
INSTALL DOOR CLOSER TO DOOR WITH
SPRING ADJUSTMENT NUT AWAY FROM HINGE.
NOTE: 351 CLOSER BODIES ARE NON HANDED.
IT IS IMPORTANT THAT THE CLOSER BODY BE
MARKED WITH “RH” SYMBOL AT TOP, FOR RIGHT
HAND DOORS. “LH” SYMBOL AT TOP FOR LEFT
HAND DOORS.
ATTACH ARM WITH INDEX MARK ON SPINDLE ALIGNED AS SHOWN. SECURE WITH SCREW AND
WASHER. INSERT ROD END INTO SWIVEL ARM AND TIGHTEN ARM SCREW AS SHOWN BELOW.
ATTACH FOOT TO FRAME AS SHOWN
WITH NUT UP FOR RH DOOR OR
DOWN FOR LH DOOR.
RIGHT HAND
DOOR SHOWN
DIM. "B"
DIM. "A"
RH
ALTERNATE
STANDARD 91/2"
61/2"
12 3/4"
93/4"
MOUNTING
110
DIM.
B
DIM.
A
MAX. DOOR
OPENING
IMPORTANT: USE ALTERNATE MOUNTING IF DOOR CAN
OPEN BEYOND LIMITS SHOWN FOR STANDARD MOUNTING
IF BUTT, FRAME AND WALL CONDITIONS PERMIT DOOR WILL
OPEN 180°
160
ARM
TYPE
“H”
HOLDER
ARM
RIGHT HAND DOOR SHOWN. LEFT HAND
DOOR OPPOSITE.
1
2THIS DIMENSION IS TAKEN FROM HINGE
EDGE OF DOOR FOR INVISIBLE HINGES.
COF HINGE PIVOT:
BUTTS, OFFSET PIVOTS,
SWING CLEAR, CENTER HUNG
OR INVISIBLE HINGES
#12 x 3 WOOD
SCREWS OR
#12-24 X 2 1/4
FLAT HEAD
MACHINE SCREWS
L
1
2
3
4
5
INDEX MARK
ON SPINDLE
MAIN ARM
DRILL & TAP AND USE SCREWS PROVIDED OR USE MORTISE
NUTS WHEN REQUIRED. SEE PAGE 6 FOR MORTISE NUTS.
9"
2 1/2"
9/16"
1 1/8"
TOP OF DOOR
21/2"
RIGHT HAND DOOR
POSITION OF
MAIN ARM WHEN
ASSEMBLING
TO SPINDLE ROD
ARM
SCREW
HOLD OPEN
ARM
90°
NUT FACES DOWN
LEFT
HAND
DOOR
NUT FACES UP
RIGHT
HAND
DOOR
A
B C
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.

INSTALL DOOR CLOSER TO FRAME/MOUNTING PLATE
WITH SPRING ADJUSTMENT NUT AWAY FROM HINGE.
INSTALL MAIN ARM TO SPINDLE AND SECURE WITH SCREW AND WASHER AS SHOWN.
INSERT ROD END INTO MAIN ARM AND TIGHTEN ARM SCREW.
ATTACH FOOT TO DOOR WITH
NUT UP FOR LH, DOWN FOR RH
RIGHT HAND
DOOR SHOWN
NOTE: 351 CLOSER BODIES ARE NON HANDED.
IT IS IMPORTANT THAT THE CLOSER BODY BE
MARKED WITH “RH” SYMBOL AT TOP, FOR LEFT
HAND DOORS. “LH” SYMBOL AT TOP FOR RIGHT
HAND DOORS.
351-A MOUNTING PLATE REQUIRED FOR
DOUBLE RABBETED DOOR.
RIGHT HAND DOOR SHOWN, LEFT
HAND DOOR OPPOSITE.
THIS DIMENSION IS TAKEN FROM HINGE
EDGE OF DOOR FOR INVISIBLE HINGES.
21/8" TO 5"
0" TO 2"
REVEAL
DEPTH
ARM
TYPE
140
DOOR
OPENING
140
“HZ” ARM
“H” ARM
51/8" TO 8" 140
“HZA” ARM
DRILL & TAP AND USE SCREWS PROVIDED OR USE MORTISE NUTS WHEN
REQUIRED. SEE PAGE 6 FOR MORTISE NUTS.
1
DOOR OPENING TO 180 IS POSSIBLE IF
DEPTH OF REVEAL IS NOT GREATER THAN 2"
3
4
LEFT HAND DOOR
POSITION OF
MAIN ARM WHEN
ASSEMBLING
TO SPINDLE
ROD
ARM
SCREW
HOLD OPEN
ARM
MAIN ARM
90°
INDEX MARK
ON SPINDLE
VIEW LOOKING UP
WHEN ASSEMBLING
ARM TO SPINDLE
RIGHT HAND DOOR
POSITION OF
MAIN ARM WHEN
ASSEMBLING
TO SPINDLE
ROD
ARM
SCREW
HOLD OPEN
ARM
90°
ARMS ARE HANDED AND MUST
BE THE SAME HAND AS DOOR.
1
3
2
4
5
TOP OF DOOR
FRAME
33/8"
3 3/8"
DEPTH OF REVEAL
SINGLE RABBETED FRAME
DEPTH OF REVEAL
COF PLATE
MOUNTING
SCREWS
L
1"
#12 X 1 1/2"
WOOD SCREWS OR
#12-24 X 5/8"
FLAT HEAD
MACHINE SCREW
53/8"
1 1/2" 6"
9"
1"
351-A
7/16"
C OF PIVOT HINGE
L
8 7/8"
2 1/2"
NUT FACES DOWN
RIGHT
HAND
DOOR
13/16"
2 1/8"
2 5/16"
21/2"
1"
1"
7/16"
1 3/4"
MIN.
DOOR
DOUBLE RABBETED FRAME WITH REQUIRED 351-A MOUNTING PLATE
MOUNTING PLATE
RIGHT HAND
DOOR
NUT FACES UP
LH
3
351 TOP JAMB APPLICATION INSTRUCTIONS
AB
C
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.

4
351 PARALLEL ARM APPLICATION INSTRUCTIONS
AB
C
INSTALL DOOR CLOSER TO DOOR WITH SPRING ADJUSTMENT
NUT AWAY FROM HINGE.
7"
97/8" 10 1/4"
73/8"
120
DIM.
B
DIM.
A
MAX. DOOR
OPENING
180
TOP OF
DOOR
STOP
C OF HINGE PIVOT
DIM. A
L
TOP VIEW
11/4"
21/2"
5/16"
7/8"
1/2"
DOOR
C OF HINGE PIVOT
(BUTT HINGE SHOWN)
DIM. B
2 3/8"
2 1/2"
#12 WOOD SCREWS
OR #12-24 x 5/8 FLAT HEAD
MACHINE SCREWS
RIGHT HAND
DOOR SHOWN
USING WRENCH ON BOTTOM END OF SPINDLE, ROTATE SPINDLE 45 AND ASSEMBLE MAIN
ARM TO CLOSER AS SHOWN, AND THEN INSERT ROD END INTO SWIVEL ARM AND TIGHTEN
ARM SCREW POSITIONING ARM 1/2" AWAY FROM DOOR.
#12 x 3 WOOD SCREWS OR
#12-24 X 2 1/4" MACHINE
SCREW
9"
RH
CAUTION: DOOR CLOSER
WILL NOT OPERATE
PROPERLY IF ARM IS NOT
INDEXED CORRECTLY.
INDEX MARK
ON SPINDLE
MAIN ARM
LEFT HAND VIEW OF INDEX
PRELOAD
APPROX. 45°
POSITION OF MAIN ARM
WHEN ASSEMBLING
TO SPINDLE
FOOT BRACKET
ARM SCREW
SWIVEL ARM
1/2"
INDEX MARK
ON SPINDLE
RIGHT HAND VIEW OF INDEX
45°
45°
MAIN
ARM
MAIN ARM
ATTACH FOOT BRACKET TO FRAME STOP AND
MOUNT HOLD OPEN ARM TO BRACKET WITH
ADJUSTING NUT FACING DOWN FOR LEFT
HAND, FACING UP FOR RIGHT HAND DOOR.
OPTIONAL FOOT BRACKET FLUSH TRANSOMS.
SEE DATA SHEET ENCLOSED.
PH4 BRACKET
LEFT HAND
DOOR SHOWN
NUT FACES UP
RIGHT HAND
DOOR SHOWN
NUT FACES DOWN
RIGHT HAND DOOR LEFT HAND OPPOSITE
HOLD OPEN ARM
L
1
2
3
4
5
1
2
3
4
5
LEFT HAND DOOR SHOWN. RIGHT HAND
DOOR OPPOSITE.
1
2DO NOT USE THIS MOUNTING FOR
“SWING CLEAR” HINGES.
3THIS DIMENSION IS TAKEN FROM HINGE
EDGE OF DOOR FOR INVISIBLE HINGES.
DRILL & TAP AND USE SCREWS PROVIDED OR USE
MORTISE NUTS WHEN REQUIRED. SEE PAGE 6 FOR
MORTISE NUTS.
NOTE: 351 CLOSER BODIES ARE NON HANDED.
IT IS IMPORTANT THAT THE CLOSER BODY BE
MARKED WITH “RH” SYMBOL AT TOP, FOR RIGHT
HAND DOORS. “LH” SYMBOL AT TOP FOR LEFT
HAND DOORS.
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.

5
FINAL ADJUSTMENT AND REGULATING PROCEDURE
A B
D
E
C
REGULATING DOOR SPEED AND LATCHING SPEED AS NEEDED.
USE HEX SOCKET (1/8" ALLEN) WRENCH AND TURN VALVES CLOCKWISE
TO SLOW DOWN OR COUNTER CLOCKWISE TO SPEED UP DOOR
MOVEMENT.
INSTALL COVER WITH TWO SCREWS AS SHOWN.
FOR MODELS WITH OPTIONAL DELAYED ACTION FEATURE
“DELAYED ACTION” PROVIDES SLOW DOOR CLOSING THROUGH
DELAYED ACTION RANGE
TURN VALVE CLOCKWISE TO SLOW DOWN OR COUNTER
CLOCKWISE TO SPEED UP DOOR MOVEMENT
REGULATING BACKCHECK
TO REGULATE THE INTENSITY OF BACKCHECK ACTION TURN VALVE
CLOCKWISE TO INCREASE OR COUNTER CLOCKWISE TO DECREASE
CHECKING.
CAUTION: SET VALVE FOR SLIGHT CUSHIONING EFFECT. IT IS
DAMAGING TO THE CLOSER IF THE CHECKING ACTION IS TOO ABRUPT.
NEVER USE BACKCHECK AS A DOOR STOP.
ALWAYS USE A DOOR STOP TO STOP THE DOOR.
DELAYED ACTION
RANGE
CLOSING SPEED
RANGE
LATCHING
SPEED RANGE
BACKCHECK
RANGE
BACKCHECK
VALVE
OPTIONAL DELAYED
ACTION VALVE
DOOR SPEED
VALVE
LATCHING
SPEED VALVE
INSERT IS REMOVABLE.
PLACE IN UNUSED OPENING.
FASTER
(+)
SLOWER
(–)
ADJUSTMENT OF HOLD OPEN ARM.
SLIGHT TIGHTENING OR LOOSENING OF HOLD OPEN
NUT CHANGES HOLDING POSITION OF DOOR.
NOTE: TO PROTECT WALL, TRIM AND CLOSER,
USE A DOOR STOP LOCATED
10 BEYOND HOLD OPEN
POSITIONS BUT NOT
BEYOND THE MAX.
DOOR OPENING SHOWN
ON INSTRUCTIONS.
HOLD
OPEN
NUT
USE 15/16"
WRENCH
TO ADJUST
NUT
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.

6
USING MORTISE NUTS WITH SARGENT DOOR CLOSER
FRAME
DOOR
COVER
SARGENT 1430
SERIES CLOSER
SHOWN. (OTHER
SERIES SIMILAR)
DOOR STOP
MORTISE NUT HEAD
DRILL 3/8" DIA.
HOLE FOR MORTISE
NUT BODY.
DRILL 1/4" DIA. HOLE
FOR MOUNTING SCREWS
1. SEE INSTRUCTIONS OR DATA SHEET PACKED WITH DOOR CLOSER FOR DIMENSIONS LOCATING THE
CLOSER BODY AND FOOT ON DOOR AND FRAME.
2. MORTISE NUT SHOWN IS DESIGNED FOR AN UNREINFORCED METAL DOOR.
4. FOR DOORS 2 1/4" THICK: MORTISE NUT SHOWN FOR 1 3/4" THICK DOORS WILL BE FURNISHED ALONG WITH APPORPRIATE LENGTH THRU-BOLTS.
DOOR CONSTRUCTION MUST PROVIDE A BRIDGE TYPE REINFORCEMENT TO PREVENT THE DOOR RAIL FROM COLLAPSING WHEN THRU-BOLTS
ARE TIGHTENED.
3. FOR TOP JAMB AND CORNER BRACKET APPLICATIONS: THE DOOR CLOSER FOOT WILL BE ATTACHED TO THE DOOR IN A MANNER SIMILAR TO
THAT SHOWN FOR MOUNTING THE CLOSER BODY.
FRAME
DOOR
1/8"
5/8" DIA. HOLE
SHORTEN MORTISE
NUT BODY TO
THIS LENGTH
1/4" DIA.
DRILLED HOLE
351 DOOR CLOSER SHOWN
(TRACK ASSEMBLY
MOUNTING IS SIMILAR)
3/8" DIA. HOLE
MORTISE NUT
HEAD
DOOR
STOP
9/16"
DIA.
7/64"
MORTISE NUT
1 11/16" FOR 1 3/4" THICK DOOR
1 5/16" FOR 1 3/8" THICK DOOR
(SEE NOTE #4 FOR 2 1/4" THICK DOORS)
#12-24 THREAD
SEE NOTE #1 BELOW FOR DIMENSION INFORMATION.
IF A DIMENSION LESS THAN 7/8" IS USED. THE DOOR
STOP MUST BE CUT TO CLEAR THE MORTISE NUT HEAD
OR THE MORTISE NUT HEAD MUST BE RECESSED.
(SEE ENLARGED VIEW "Y")
A7341A
Copy ight © 2007, 2008, Sa gent Manufactu ing Company, an ASSA ABLOY G oup company.
All ights ese ved. Rep oduction in whole o in pa t without the exp ess w itten pe mission of
Sa gent Manufactu ing Company is p ohibited.
