Saris Bones EX 803 User manual
28749A BonesEX.indd 2 2/7/2020 2:38:34 PM
LONG FOR THE RIDE
Just as no garage is complete without a bicycle, at Saris, we believe no car is
complete without a bike rack.
Since setting off on this journey nearly 30 years ago, Saris racks
have freed millions of bike-lovers to explore new territory and terrain,
take part in group rides, bike pool to races, and commute to and
from work.
And we continue to do so in style.
As the all-time #1 best-selling bike rack, Saris Bones® continues to set the
standard for excellence in design. Today all Saris bicycle racks are intuitive to
load and secure, and guaranteed for life.
Built by cyclists for cyclists in Madison, Wisconsin,
we strive to create the world’s best bike racks.
Because cycling is what we live for.
MADE IN USA
3-bike shown
28749A BonesEX.indd 3 2/7/2020 2:38:37 PM
Specifications: Bones EX
Max = 35 lbs/16kg
Máx.= 16kg (35 libras)
Max = 35lb/16kg
Max = 105 lbs/48kg
Máx.= 48kg (105 libras)
Max = 105lb/48kg
3
BIKE
Fit
Guide
Max = 35 lbs/16kg
Máx.= 16kg (35 libras)
Max = 35lb/16kg
2
BIKE
Max = 70 lbs | 32 kg
Máx.= 32kg (70 libras)
Max = 70 lbs | 32 kg
28749A BonesEX.indd 4 2/7/2020 2:38:38 PM
Optional Accessories:
#3037, 3040
Bike Beam
#3035
Hatch Huggers
#3033
Wheel Straps
#3050
Trunk Rack Lock
*The Bike Beam is recommended if bike wheels are not paralell to the ground or if wheels are less than 12” from the ground.
*
28749A BonesEX.indd 5 2/7/2020 2:38:38 PM
RACK ORIENTATION
Bones EX can be confi gured for different vehicle types, as shown.
28749A BonesEX.indd 6 2/7/2020 2:38:38 PM
1
OPENING RACK
Turn knob on rack arm counterclockwise to loosen rack arm. Slide arm to center of aluminum tube and open arms as shown, slide arm back over aluminum tube
spline. Tighten knob by turning clockwise.
x 2
28749A BonesEX.indd 7 2/7/2020 2:38:38 PM
2
Turn knob counterclockwise on outer leg knob to loosen leg as shown. Remove leg from spline and reinstall on spline at desired position. Refer to page 6 to
determine optimal rack orientation. Tighten knob.
SETTING LEG POSITION
x 2
2
2
2
2
2
2
28749A BonesEX.indd 8 2/7/2020 2:38:39 PM
3
Place lower rack feet on bumper. Some vehicles require the feet to be on the trunk lid, refer to website fi t guide for proper feet placement on your vehicle. Place upper feet
in center of trunk lid or center of rear window. Raise rack arms as shown. Note: bike cradles furthest from vehicle should be highest from the ground.
POSITIONING ON VEHICLE
28749A BonesEX.indd 9 2/7/2020 2:38:39 PM
4
Install rack hooks in locations as shown. Hooks are labeled upper, side and lower. Upper hook straps can route through channels in upper legs. Reference
fit guide on website for recommended upper leg strap position. Tie off all straps as shown once thoroughly tightened.
ATTACHING STRAPS
x 6
A
C
B
AA
B
C
C
B
x 2
x 2
x 2
28749A BonesEX.indd 10 2/7/2020 2:38:39 PM
C
5
Install bike in rack cradles as shown. Lower anti-sway strap on arm should be positioned at the rear of the bike. Close straps and pull tight. Heaviest bikes should be
installed closest to vehicle. Note: be aware of bicycle tire position in relation to vehicle exhaust. Be sure bike tires are at least 12” from ground. Do not open trunk or hatch
with rack and/or bikes installed.
INSTALLING BIKES
28749A BonesEX.indd 11 2/7/2020 2:38:39 PM
6
PRECAUTIONS
>12”
>30.5 cm
Do not open vehicle trunk or gate when
rack is installed.
28749A BonesEX.indd 12 2/7/2020 2:38:39 PM
Technical Specifications 3-Bike
Bike carrier weight: 12lbs/5kg
Permitted load capacity: max 105lbs/48 kg
Max bike weight: 35 lbs/16 kg
CAUTIONS:
• All requirements for compatability/fit as stated in the current Saris vehicle/carrier compatability guide must be followed.
• Read and follow instructions carefully. Save owner’s manual for future reference or parts information. Ensure that any other users of the bicycle carrier are familiar with
their content.
• Drive slowly over speed bumps, 5 to 10 mph max speed.
• It’s the end users responsibility to ensure that use of this product meets all local and state laws.
• When cleaning vehicle and rack, use only water soluble cleaners. Do not take rack through car wash.
• Make sure bike tires are not directly behind exhaust pipe.
• Do not mount to any type of trailer or RV including Class B vehicles.
• Prior to usage on the road, remove all loose parts from bicycle, including (but not limited to) child seat, basket, lock, light, pump, etc.
• This carrier is not recommended for off-road use or for use at speed exceeding 70 mph (113 km/h).
• The handling characteristics of a vehicle will change when a rear bicycles carrier is fitted and especially when it is loaded (in particular crosswind sensitivity, handling on
bends and braking). Driving techniques should be altered to allow for these changes, reduce speed, especially on bends and allowing for longer braking distances.
• The vehicle’s total length increases when the bike carrier is attached. The bikes themselves may increase the vehicle’s total width and height. Take care when reversing
and/or entering garages or ferries, etc.
• Remove carrier from vehicle when not in use.
• This carrier is constructed to carry standard-bike-frames. It is not intended for use with tandem or recumbent bicycles.
• Replace any mounting strap at the first sign of wear.
Technical Specifications 2-Bike
Bike carrier weight: 12lbs/5kg
Permitted load capacity: max 70lbs/32 kg
Max bike weight: 35 lbs/16 kg
28749A BonesEX.indd 13 2/7/2020 2:38:39 PM
• Tighten straps regularly during the journey.
• Do not exceed maximum load capacity of carrier (105 lbs max or 35 lbs max per bike!) Secure properly and adjust for even load distribution, loading the heaviest/biggest
bike first and closest to the vehicle.
• The Bike Beam (3037/3040) is recommended if bike wheels are not paralell to the ground or if wheels are less than 12” from the ground.
• Saris absolves itself of responsibility for any personal injuries or consequential damage to property or wealth caused by incorrect fitting or use.
Warning and Disclaimer:
This carrier has been designed to carry bicycles on specific vehicles. Before installation, user must read and follow current Saris Fit Guide (available through Saris dealer)
recommen-dations and enclosed instructions. Fit recommendations are based on vehicle’s standard features; optional features may affect the fit recommendations. User must
attach carrier correctly to the vehicle, check its attachment before each use, and inspect carrier parts for wear. Carrier’s attachment to the vehicle is critical and beyond the control
of the manufac-turer. Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or loss, whether direct, indirect, or incidental, resulting
from the incorrect attachment, improper use, inadequate maintenance, or neglect of this carrier.
28749A BonesEX.indd 14 2/7/2020 2:38:40 PM
LIMITATIONS
The foregoing warranties are in lieu of and exclude all other warranties not expressly set forth herein, whether expressed or implied by operation of law or otherwise. Other than as
set forth above, SCG makes no warranty, whether express, implied or statutory, with respect to any product, including, but not limited to, warranties of reliability, merchantability
fitness for a particular purpose, or those arising from any course of performance, dealing, usage or trade. SCG shall not be liable for incidental or consequential losses, damages or
expenses in connection with its products. SCG’s liability hereunder is expressly limited to the replacement of goods not complying with this warranty or, at SCG’s election, to the
repayment of an amount of the purchase price of the product in question. Some states do not permit the exclusion or limitation of implied warranties or incidental or consequential
damages, so the preceding limitations and exclusions may not apply to you.
EXCLUSIONS
• If consumer does not heed cautions listed in Instruction Manual, damage is not covered under warranty
• Impact/collision damage is not covered under warranty
• Cradles and strap damage due to improper arm placement are not covered under warranty
• Carrying anything other than a bicycle is not covered under warranty
• Rust is wear and tear and is preventable with rack maintenance
• Weather impact (UV, salt air/water)
RECOMMENDED RACK MAINTENANCE
Each use:
• Wipe down trunk rack feet
• Check straps for signs of wear
• Check bike cradles and wheel scoops
• Check for loose bolts
Every 90 days actions
• Clean with water and mild soap
• Lubricate locks if applicable (use wet, oil based lubricant; NO WD-40)
• Grease hitch bolt threads
• Check for scratches in paint
28749A BonesEX.indd 15 2/7/2020 2:38:40 PM
