Saswell SAS6000UTK-7 User manual

1
SAS6000UTK-7
OPERATING
INSTRUCTION

1
This manual apply for SAS6000UTK-7,used with Single Stage,Multi-Stage,Heat pump
SPECIFICATION
Power Supply ……………………… Dual Power 24VAC (18-30VAC,50/60Hz) or Battery Powered
Terminal Load…………………………1.0 Aper terminal, 2.0A maximum total load
Set point Temperature Range………….41℉to 95℉(5℃to 35℃)
Operating Ambient…………………….32℉to 122℉(0℃to 50℃)
Operating Humidity…………………...90% non-condensing max
Shipping Temperature Range………….14℉to +140℉(-10℃to 60℃)
Dimensions……………………………. 5.9 inch×4.5 inch×1.2inch(150mm×115mm ×32mm)
Color……………………………………White
FEATURE
Apply with various kind of heating and cooling system. Including Single stage, Multi-stage
And Heat Pump (Up to 3-stage heat, 2-stage cool, with Aux. Or Emergency heat)
Large LCD display with backlight, continuous backlight option
Menu Driven Programming

2
The screen displays the set temperature, the room temperature and current time simultaneously
Fan switch with on and auto
Auto change over
Permanent user setting retention during power loss, no batteries are required,
Optional7 day programming and non-programmable
Optionaltemperature display of Celsius or Fahrenheit scale
Both Vacation mold and hold duration mode available for comfort and energy saving
Air filter change indicator
UV light change indicator
IMPORTANT SAFETY INFORMATION
Always turn off power at the main power source by unscrewing fuse or switching circuit breaker to the off
position before installing, removing, cleaning, or servicing this thermostat.
Read all of the information in this manual before installing this thermostat.
Only a professional contractor should install this thermostat.
All wiring must conform to local and national building and electricalcodes and ordinances.
Use this thermostat only as described in this manual.

3
KEYBOARD, DISPLAY AND SWITCH DESCRIOPTION
Touch Screen Thermostat
Figure 1

4
Home Screen Description
Figure 2
Time of the day
System Switch
Fan Swtich
Menu key for entering
different modes
Date of Week Set Temperature
Room
Temperature
Temperature
Up/Down
used for modifying
set point
Low Battery
Indication
Keypad lockout
Indication

5
Figure 3
(1)
(2)
(14)
(13) (15) (16)
(17)
(18) (19)
(20)
(24)(23) (22) (21)
(5) (6)
(7) (8) (9)
(10)
(11)
(3)
(4)
(12)

6
(1) Press day(s) to set program schedule
(2) “Hold Until” indicates the time when a temporary hold period will end
(3) Press to select system type
(4) Press to select fan operation
(5) Press “MENU” to display first function menu of button (6) (7) (8) (9) (10)
Press “DONE” to confirm current setting
(6) Press “SET TIME” to set current time clock
Press “INFO” to check outside temperature or inquiry for count back time for changing filter or inquiry for UV
light duration hours.
(7) Press “RUN SCHED” to resume program operation
Press “RESET” to current program setting or current configuration setting to factory default value
Press “CONFIG” to set configuration menu item
(8) Press “HOLD” to permanent hold current set point
Press “CLEAN DISPLAY” for entering 30 second count back time for cleaning the display
Press “PREVIOUS STEP” for going back to last configuration menu item
(9) Press “SET SCHED” for setting schedule foreach days of the week
Press “NEXT STEP” for going forward to next configuration menu item or next day of week when setting
schedule.
(10) Press “OTHER” for entering the second function menu of (5) (7) (8) (10)
Press “CANCEL” to disregard current setting andgo back to last operation
(11) Press “WAKE” “LEAVE” “RETURN” “SLEEP” to choose the 4 setting period of each day when setting program

7
schedule
(12) Press UP and DOWN for modifying set point
(13) “Days” displays during steps in setting vacation duration daysor count backdays of vacation duration days
“Am” indicate current time clock is in the morning. “Pm” indicates current time clock is in the afternoon
(14) Press UP and DOWN for setting current time clock or setting time in programming or changing
selections in configuration menu or setting the time when a temporary hold period will end
(15) “Emergency” flashes when system mode is set “EMER”
“ Using Schedule” displays when thermostat is operating under presetting schedule
“ Permanent Hold” displays when thermostat is in permanent hold setting temperature period
“ Temporary Hold” displays when thermostat is in temporary hole setting temperature period
(16) displays when first stage cooling activate
displayswhen both first stage cooling and second stage cooling activate
(17) displays when first stage heating activate
displayswhen both first stage heating and second heating activate
(18) displays whenAuxiliary heating or Emergency heating activate
(19) displays when circulating fan activate

8
(20) “TECHNICIAN SET UP: USE UP AND DOWN FOR SURRENT SELECTION AND NEXT STEP PREVIOUS
STEP KEY TO THE NEXT PREVIOUS STEP” displays to help technician how to operate in configuration mode
(21) Indicate current status of the thermostat
(22) “Chg Filter” displays indicate changing filter count back has expired
(23) “Comp Dly” displays when compressor delay lock out activate
(24) “Chg UV” displays when changing UV duration days has expired
INSTALLATION
1. Pull the thermostat body off the thermostat base.Forcing or prying on the thermostat will cause damage to the
unit.
2. Place base over hole in wall and mark mounting hole locations on wall using base as a template
3. Move base out of the way. Drill mounting holes. If you are using existing mounting holes and the holes drilled
are too large and do not allow you to tighten base snugly, use plastic screw anchors to secure the base.
4. Fasten base snugly to wallusing mounting holes shown in Figure 3 and two mounting screws. Leveling is for
appearance only and will not affectthermostat operation.
5. Connect wires to terminal block on base using appropriate wiring schematic (See Figure 5、Figure 6)
6. Carefully line the thermostat up with the base and snap into place.
Battery Location
Batteries are optional (to provide backup power) if your thermostat was wired to run onAC power when installed.

9
Battery replacement
Install fresh batteries immediatelywhen the Low Batt warning beginsflashing. The warningflashes about 60 days
before batteries are depleted. Even if the warning does not appear, you should replacebatteries once a year, or before
leaving homefor more than 1 month
To replace batteries, set system to OFF, remove thermostat from wall and install the batteries in therear along the
top of the thermostat. (See figure 4)
Figure 4
Front Panel 2 AA Batteries
Base

10
WIRING DIAGRAM
Figure 5
Wiring guide

11
1H/1C System (1 transformer) 1H/1C System (2 transformer)
2H/2C System (1 transformer)
RC
Power 【1】
RH (RH+RC joined by jumper)
W
Heat Relay
Y Compressor contactor
G
Fan relay
C/S1
24VAC common/remote sensor 【3,4】
S2
Remote sensor
RC
Power (cooling transformer) 【1,2】
RH Power (heating transformer) 【1,2】
W Heat relay
Y Compressor contactor
G Fan relay
C/S1
24VAC common/remote sensor 【3,4】
S2
Remote sensor
RC
Power (cooling transformer) 【1,2】
RH （RH+RCjoined by jumper）【1,2】
W
Heat relay 1
Y Cool relay 1
W2
Heat relay 2
Y2 Cool relay 2
G
Fan relay
C/S1
24VAC common/remote sensor 【3,4】
S2
Remote sensor
RC Power 【1】
RH
(RH+RC joined by jumper)
W Heat relay 1
Y
Cool relay 1
W2 Heat relay 2
Y2
Cool relay 2
G Fan relay
C/S1
24VAC common/remote sensor 【3】
S2 Remote sensor
2H/2C System (2 transformer)

12
1H/1C Heat Pump (no auxiliary heat)2H/2C Heat Pump (no auxiliary heat)
RC Power 【1】
RH
(RH+RC joined by jumper)
Y Compressor relay
O
Changeover valve energized in heating
B Changeover valve energized in cooling
G
Fan relay
C/S1
24VAC common/remote sensor 【3】
S2
Remote sensor
RC Power (cooling transformer) 【1,2】
RH （RH+RCjoined by jumper）【1,2】
Y Cool relay 1
O Changeover valve energized in heating
B Changeover valve energized in cooling
Y2
Compressor relay 2
G Fan relay
C/S1
24VAC common/remote sensor 【3】
S2 Remote sensor

13
2H/1C Heat Pump (with auxiliary heat) 3H/2C Heat Pump (with auxiliary heat
【1】Power supply
【2】Remove jumper for 2-transformer system
【3】Optional 24VAC common connection
【4】Common connection must come fromcooling transformer
【5】If L terminal is used, 24VAC common (terminal C) must be connected
【6】Install field jumper between Aux and E terminals if there is no emergency heat relay
L Equipment monitor 【5】
RC Power 【1】
RH
(RH+RC joined by jumper)
Y Compressor relay
E
Emergency heat replay 【6】
Aux
Auxiliary heat repay (Heat 2) 【6】
O Changeover valve energized in heating
B Changeover valve energized in cooling
G Fan relay
C/S1
24VAC common/remote sensor 【3】
S2 Remote sensor
L Equipment monitor 【5】
RC Power 【1】
RH
(RH+RC joined by jumper)
Y Compressor relay 1
E
Emergency heat replay 【6】
Aux
Auxiliary heat repay (Heat 2) 【6】
O Changeover valve energized in heating
B Changeover valve energized in cooling
Y2 Compressor relay 2
G Fan relay
C/S1
24VAC common/remote sensor 【3】
S2 Remote sensor

14
CONFIGURATION MENU
The configuration menu allows you to set certain thermostat operating characteristics to your system or personal
requirements.
To enter the configuration menu, switch off the thermostat
Press system
until OFF blink
Press DONE
to save changes

15
1) Press MENU for displaying main menu button, Press OTHER for display other menu button
2) Press CONFIG for entering configuration menu, change setting according to following figure.
For resume factory default setting, press RESET and then confirm by pressing DONE.
Press MENU
for displaying main
menu button
Press OTHER
for displaying other
menu button
Press DOWN
to confirm and
exit Press CONFIG
for entering
configuration menu
Press CANCEL
to exit to main
home screen

16
Press NEXT
STEP changing to
next menu item
Display menu item
Press UP and DOWN
for change setting
Press DOWN
to confirm and
exit
Press RESET
for resume to
factory default
setting
Press PREVIOUS
STEP changing to
previous menu
item
Press CANCEL
to exit to main
home screen

17
1 H 2H HP1 HP2 Press
Display
factory
default
Press Up and
DOWN
To select Comments
1 NEXT
STEP SYSTEM
(2H) 1H,2H,HP1,HP2 Select control system
2 NEXT
STEP BLowER
(HA) HA,HE
HA: Gasheating, Furnance
controls blower
HE: Electric heating.
Thermostat controls blower
NA NA 3 NEXT
STEP AxMOdE HA,HE HA: Fossil fuel backup heat
HE: Electric backup heat
4 NEXT
STEP CHANGE (0) 0,1 0: Manual changeover 1: Auto changeover
5 NEXT
STEP DbaNd(3) 2,3,4,5,6,7,8,9 Auto changeover dead band
6 NEXT
STEP RECVRY (OFF) OFF/ON Intelligent Recovery operation
7 NEXT
STEP HCYCLE (FA) FA, SL First heating cycle rate

18
8 NEXT
STEP CCYCLE (FA) FA, SL First cooling cycle rate
NA NA 9 NEXT
STEP EMER (FA) FA, SL Emergency heating rate
10 NEXT
STEP DELAy
(5) 0,5 Select compressor lockout
delay
11 NEXT
STEP LIGHT (2) 1,2, 3 Select backlight display
12 NEXT
STEP CALIbR
(0) +4 TO -4 Select Temperature
Calibration
13 NEXT
STEP F OR C (F) F or C Select ºF or ºC Readout
14 NEXT
STEP PRGM (7) 0,7 7: 7-day program
0: non-program
NA 15 NEXT
STEP H2SP
(FA) FA, SL Select second stage heating
rate
NA NA 16 NEXT
STEP C2SP
(FA) FA,SL Select second stage cooling
rate

19
17 NEXT
STEP FILTER
(00) 00 – 12 Select filter replacement run
time
18 NEXT
STEP UVLAMP (UF) UO or UF Select UV lamp replacement
run time
19 NEXT
STEP CLOCK (24) 24,12 Selection of time scale
20 NEXT
STEP SENSOR (0) 0,1,2,3 Remote sensor option
NA NA 21 NEXT
STEP HPLOCK (0) 0,15,20,25,30,35,4 0℉Heat pump compressor lockout option
NA NA 22 NEXT
STEP AxLOCK (0) 0,40,45,50,55,60 ℉Heat pump auxiliary lockout option
23 NEXT
STEP VOICE (yES) YES,No Select audible beeper On/off
24 NEXT
STEP LOCK (unL) PAL,unL,FUL Select keypad lockout option
