Satec PM174 Series User manual

Powermeter and Power Quality Analyzer
PM174
DNP3 Communications Protocol
Reference Guide
BG0413 Rev. A3

2
Every effort has been made to ensure that the material herein is complete and accurate.
However, the manufacturer is not responsible for any mistakes in printing or faulty
instructions contained in this book. Notification of any errors or misprints will be received
with appreciation.
For further information regarding a particular installation, operation or maintenance of
equipment, contact the manufacturer or your local representative or distributor.
REVISION HISTORY
A2 March 2008 F/W Version 24.1.04 or later
Added individual harmonic distortion and analog input points
A3 July 2009 F/W Version 24.2.04 or later
Added four-quadrant kvarh and imported/exported kVAh energy counters

3
Table of Contents
1GENERAL ..........................................................................................................5
2DNP 3.0 PROTOCOL IMPLEMENTATION........................................................6
2.1 DEVIATIONS FROM STANDARD ..................................................................................................6
2.2 DNP IMPLEMENTATION ............................................................................................................6
2.2.1 CLASS 0 RESPONSE ................................................................................................6
2.2.2 EVENT OBJECTS.....................................................................................................7
2.2.3 DEVICE ADDRESS...................................................................................................7
2.2.4 TRANSACTION TIMING..............................................................................................8
2.2.5 SCALING 16-BIT ANALOG INPUTS.................................................................................8
2.2.6 SCALING 16-BIT BINARY COUNTERS..............................................................................8
2.3 PASSWORD PROTECTION .........................................................................................................9
3DNP POINT MAP..............................................................................................10
3.1 ANALOG INPUTS - BASIC SET .................................................................................................10
3.2 BINARY INPUTS - BASIC SET...................................................................................................11
3.3 BINARY COUNTERS - BASIC SET.............................................................................................11
3.4 FROZEN BINARY COUNTERS...................................................................................................12
Total Energies – Basic Set....................................................................................12
Counters – Extended Set ..................................................................................... 12
Total Energies - Extended Set...............................................................................12
Phase Energies - Extended Set .............................................................................13
3.5 ANALOG INPUTS, BINARY INPUTS AND COUNTERS – EXTENDED SET ........................................14
Digital Inputs DI1-DI4.........................................................................................14
Relay Outputs RO1-RO4.......................................................................................14
Counters ...........................................................................................................14
1-Cycle Phase Values ..........................................................................................14
1-Cycle Total Values............................................................................................15
1-Cycle Auxiliary Values ......................................................................................15
1-Second Phase Values........................................................................................15
1-Second Total Values.........................................................................................16
1-Second Auxiliary Values....................................................................................16
Present Volt, Ampere and Power Demands .............................................................16
Total Energies ....................................................................................................17
Phase Energies...................................................................................................18
V1/V12 Harmonic Distortion.................................................................................18
V2/V23 Harmonic Distortion.................................................................................18
V3/V31 Harmonic Distortion.................................................................................18
I1 Harmonic Distortion ........................................................................................18
I2 Harmonic Distortion ........................................................................................18
I3 Harmonic Distortion ........................................................................................19
Fundamental Phase Values...................................................................................19
Fundamental Total Values....................................................................................19
Minimum 1-Cycle Phase Values.............................................................................19
Minimum 1-Cycle Total Values..............................................................................20
Minimum 1-Cycle Auxiliary Values.........................................................................20
Maximum 1-Cycle Phase Values............................................................................20
Maximum 1-Cycle Total Values .............................................................................21
Maximum 1-Cycle Auxiliary Values........................................................................21
Maximum Demands ............................................................................................21
Scaled Analog Inputs...........................................................................................21
Raw Analog Inputs..............................................................................................21

4
3.6 FACTORY DEVICE SETTINGS AND IDENTIFICATION....................................................................22
Device Identification............................................................................................22
Factory Device Settings .......................................................................................22
Device Identification (alias)..................................................................................22
Port Identification ...............................................................................................22
3.7 DEVICE CONTROL..................................................................................................................23
Device Authorization Register...............................................................................23
Device Reset/Clear..............................................................................................23
Alarm Notification...............................................................................................23
Remote Relay Control..........................................................................................24
3.8 DEVICE SETUP.......................................................................................................................26
Basic Setup........................................................................................................26
Communication Ports Setup .................................................................................26
Device Options Setup ..........................................................................................27
3.9 DNP PROTOCOL SETUP ........................................................................................................29
DNP Options Setup .............................................................................................29
DNP Events Setup...............................................................................................30
DNP Class 0 Point Assignments.............................................................................30
4DATA SCALES AND UNITS............................................................................32
Data Scales .......................................................................................................32
Data Units .........................................................................................................32
5DATA FORMATS .............................................................................................33
Wiring Mode.......................................................................................................33
Instrument Options.............................................................................................33
DNP Object Variations .........................................................................................33
DNP Class 0 Objects............................................................................................34
APPENDIX A DNP APPLICATION MESSAGES ................................................35
APPENDIX B DNP DEVICE PROFILE................................................................37

5
1 General
This document specifies a subset of the DNP3 communications protocol used to transfer data
between a master computer station and the PM174. The document provides the complete
information necessary to develop third-party communications software capable of
communication with the Series PM174 instruments.
For additional information concerning communications operation, configuring the
communications parameters, and communications connections see the PM174 Installation and
Operation Manual.

6
2 DNP 3.0 Protocol Implementation
DNP3 (Distributed Network Protocol) is an open standard designed by Harris Control
Division. DNP defines a command-response method of communicating digital information
between a master and slave device. Detailed information regarding DNP3 is available in the
“Basic 4 Document Set” which can be obtained from the DNP User Group.
2.1 Deviations from Standard
The PM174 implements Level 2 of the DNP3 communication protocol. The device does not
support unsolicited requests or hardware collision avoidance.
The data link layer differs from the Basic 4 specifications because of the master-slave
relationship between devices. When the device receives a request, no further requests can
be sent until after the device makes the appropriate response.
2.2 DNP Implementation
The PM174, like most devices, allows retrieving regular analog and binary data from the
device by executing directed (non-broadcast) Read requests.
Binary-Output-Status objects and Analog-Output-Status objects are sent with flags that
always indicate ONLINE.
A Binary-Output-Status object that indicates the current state of a control digital point
(relay) uses remote forced data as well as local forced data bits. The value of a state bit
indicates the current state of the digital output point.
The PM174 executes the parameter clear function and demands resets using the Direct-
Operate, SBO/Operate or Direct-Operate-No-Acknowledge command to specified points of
the Control-Relay-Output-Block object.
Issuing the Direct-Operate, SBO/Operate or Direct-Operate-No-Acknowledge command to
appropriative points of the Analog-Output-Block object can change the setup parameters.
The device also supports the DNP functions Write, Cold-Restart and Delay Measurement.
Refer to Appendix A for specific requests and responses. Appendix B contains the standard
DNP Device Profile Document.
The device attempts to respond with the same object variation and qualifier as those in the
request. Exceptions to this rule include changing variation 0 to a specific variation and
changing qualifier code 6 to 1.
If the device receives an invalid request, it sets the internal indication to the error code. The
following internal indication bits are supported:
Octet
Position Bit Position Description
0 0 Set when a request received with a broadcast destination address. Cleared after next response.
0 7 Device restart - set when the device powers up or after executing Cold Restart, cleared by
writing zero to object 80.
0 4 Time-synchronization required from the master. Cleared when master sets the time.
0 5 Set when the device is in the Local state. Cleared when the device in the Remote state.
1 5 Set when the current configuration in the device is corrupted. May also be set as a result of the
legal changes in the setup configuration whenever another setup is affected by the changes
made. Cleared by writing zero to points 64-75 using object 12.
2.2.1 Class 0 Response
The PM174 DNP implementation supports a wide variety of messages. The most common
method of getting static object information from the meter via DNP is to issue a read Class
0 request.
The PM174 allows you to configure the Class 0 response by assigning ranges of points to be
polled via Class 0 requests (see Section 3.9, DNP Protocol setup).

7
2.2.2 Event Objects
The PM174 allows you to assign any static object point to a predefined object change event
point for Class 1, Class 2 or Class 3 event polling. A total of 64 change event points are
available. You can assign any of the Analog Input, Binary Input or Binary Counter static
points to the corresponding change event point through the DNP Event setup (see Section
3.9). You can also link any point to Class 1, Class 2 or Class 3 object polling.
By default, a change event point index is the same as for the corresponding static object
point. The PM174 gives you an option to re-map a static point index for the corresponding
event point starting with index 0, separately for each object type - Analog Input, Binary
Input or Binary Counter change events. For example, if the re-mapping option is active and
you first assign static point AI:23 (1-sec frequency) to an event Class 1 point, the
corresponding Analog Input change event point will be identified as point 0 in the Class 1
poll response.
Each point assigned to an event class can be separately enabled or disabled for scanning.
Each point can also be linked to the common device Event log so that each change would be
recorded to the Event log under common Setpoint #17.
The conditions for Analog Input change events can be specified by either an operating
threshold, or a deadband, using one of the following three relations:
Delta – a new event is generated when the absolute value of the difference between
the last reported value of the point and its current value exceeds the specified
deadband value;
More than (Over) - a new event is generated when the point value rises over the
specified threshold, and then when the point value returns below the threshold taking
into consideration a predefined hysteresis;
Less than (Under) - a new event is generated when the point value drops below the
specified threshold, and then when the point value returns above the threshold taking
into consideration a predefined hysteresis.
For Binary Counter and Binary Input change events, a Delta relation is only applicable.
The number of event points for each object type (Analog Input, Binary Input or Binary
Counter) is limited through the DNP Options setup (see Section 3.9). Every time you
change the number of points for any of the objects, the device clears all event buffers and
links the default set of static points to each event object type.
The scan time rates for polling events of different types are as follows:
- 1 cycle for Binary Input points
- 200 ms for Binary Counter and Analog Input points
The memory consumption for keeping events depends on the event objects variation, or
DNP object size. For each event object type and event class, the device uses a separate
buffer. The maximum buffer size per DNP event object/event class is 512 bytes. The
maximum number of events per class that the device can hold can be calculated as follows:
Maximum number of events = 512/(DNP Event Object Size + 1)
For example, the device can hold up to 512/12=40 measures of the 32-bit Analog change
event with Time objects, or up to 512/8=64 measures of the 8-bit Binary change event with
Time objects.
To disable change event objects, set to 0 all registers that define the number of the Analog
Input, Binary Input and Binary Counter objects to generate events. In this case, the device
will support only static objects.
2.2.3 Device Address
Each device on a DNP link must have a unique address. The PM174 allows a device address
in the range of 0 to 65532 to be selected. The DNP master can use addresses 65533 to
65535 for broadcast requests. A broadcast request never generates a DNP response.

8
2.2.4 Transaction Timing
The PM174 response time to master requests is indicated in Table 2-1.
Table 2-1 Response Time
Response Time, msBaud Rate, bps Min Max Typical
9600 13 15 13
19200 11 12 11
57600 9 10 9
115200 9 10 9
The Direct-Operate, SBO/Operate or Direct-Operate-No-Acknowledge requests for
reset/clear registers and setpoint changing are immediately confirmed.
2.2.5 Scaling 16-bit Analog Inputs
Any of the variations 1 through 4 can be used with the Analog Input objects. Variations
specified in Sections 3.1 and 3.5 show those that can be used to read a full-range value
without a possible over-range error when no scaling is used to accommodate the value to
the requested object size.
When over-range occurs, a positive value is reported as 32767 and a negative value as
-32768, with the over-range bit in the flag octet being set to 1 if a variation 2 is requested.
To avoid over-range errors when a variation 2 or 4 is required, a liner scaling may be used
to scale 32-bit analog readings to 16-bit Analog Input objects (see Section 3.9, DNP Options
setup). Scaling is enabled in the device by default.
When scaling is enabled, either analog input requested with variation 2 or 4 will be scaled to
the range of -32768 to 32767 for bi-directional parameters (such as power and power
factor), and to the range of 0 to 32767 for single-ended positive parameters (voltage,
current, frequency, etc.). To get a true reading, the reverse conversion should be done
using the following formula:
Y = ((X – DNP_LO) ×(HI - LO)) /(DNP_HI – DNP_LO) + LO
where:
Y- True reading in engineering units
X- Raw input data in the range of DNP_LO – DNP_HI
LO, HI - Data low and high scales in engineering units (for device data scales, see
Section 4)
DNP_LO - DNP low conversion scale: DNP_LO = -32768 for a point with a negative LO
scale
DNP_LO = 0 for a point with a zero or positive LO scale
DNP_HI - DNP high conversion scale: DNP_HI = 32767
EXAMPLE
If you have read a value of 201 for point AI:3 that shows the I1 current (see Section 3.1)
and the CT primary current is 200A (the high current scale is 2×200 = 400A), then the
current reading in engineering units is as follows:
(201 - 0) ×(400 - 0)/(32767 - 0) + 0 = 2.45A
2.2.6 Scaling 16-bit Binary Counters
Binary counters are stored in the device in 32-bit integer format. Using 16-bit Binary
Counter objects can cause over-range errors if the counter value exceeds 32767.
Scaling binary counters (see DNP Options setup in Section 3.9) allows changing a binary
counter unit from 1 to 1000 in powers of 10 to accommodate a 32-bit counter value to 16-
bit object format.

9
If the scaling unit is greater than 1, the counter value is reported being divided by the
scaling unit. To get the actual value, multiply the counter reading by the selected scaling
unit.
2.3 Password Protection
The PM174 has a password protection option allowing you to protect your setups,
cumulative registers and logs from being changed or cleared through communications. You
can disable or enable password protection through communications or via the front display.
For details, refer to your instrument Installation and Operation Manual.
When password protection is enabled, the user password you set in your instrument should
be written into the device authorization register (point AO:192) before another write
request is issued. If the correct password is not supplied while password protection is
enabled, the instrument will respond to all write requests with the exception response
“Control operation not supported for this point”. It is recommended to clear the password
register after you have completed your changes in order to activate password protection.

10
3 DNP Point Map
3.1 Analog Inputs - Basic Set
Object : Var. Object : Point Description Options/Range2Units2Type R/W Notes
30:3 AI:0 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:1 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:2 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:3 I1 Current 0-Imax U2 UINT32 R
30:3 AI:4 I2 Current 0-Imax U2 UINT32 R
30:3 AI:5 I3 Current 0-Imax U2 UINT32 R
30:3 AI:6 kW L1 -Pmax-Pmax U3 INT32 R
30:3 AI:7 kW L2 -Pmax-Pmax U3 INT32 R
30:3 AI:8 kW L3 -Pmax-Pmax U3 INT32 R
30:3 AI:9 kvar L1 -Pmax-Pmax U3 INT32 R
30:3 AI:10 kvar L2 -Pmax-Pmax U3 INT32 R
30:3 AI:11 kvar L3 -Pmax-Pmax U3 INT32 R
30:3 AI:12 kVA L1 0-Pmax U3 UINT32 R
30:3 AI:13 kVA L2 0-Pmax U3 UINT32 R
30:3 AI:14 kVA L3 0-Pmax U3 UINT32 R
30:4 AI:15 Power factor L1 -1000-1000 ×0.001 INT16 R
30:4 AI:16 Power factor L2 -1000-1000 ×0.001 INT16 R
30:4 AI:17 Power factor L3 -1000-1000 ×0.001 INT16 R
30:4 AI:18 Total PF -1000-1000 ×0.001 INT16 R
30:3 AI:19 Total kW -Pmax-Pmax U3 INT32 R
30:3 AI:20 Total kvar -Pmax-Pmax U3 INT32 R
30:3 AI:21 Total kVA 0-Pmax U3 UINT32 R
30:3 AI:22 In (neutral) Current 0-Imax U2 UINT32 R
30:4 AI:23 Frequency 0-Fmax ×0.01Hz UINT16 R
30:3 AI:24 Maximum kW import sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:25 kW import accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:26 Maximum kVA sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:27 kVA accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:28 I1 Maximum ampere demand 0-Imax U2 UINT32 R
30:3 AI:29 I2 Maximum ampere demand 0-Imax U2 UINT32 R
30:3 AI:30 I3 Maximum ampere demand 0-Imax U2 UINT32 R
30:3 AI:31 Present kW import sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:32 Present kVA sliding window demand 0-Pmax U3 UINT32 R
30:4 AI:33 PF (import) at Max. kVA sliding window demand 0-1000 ×0.001 UINT16 R
30:4 AI:34 V1/V12 Voltage THD 0-9999 ×0.1% UINT16 R 1 3-sec value
30:4 AI:35 V2/V23 Voltage THD 0-9999 ×0.1% UINT16 R 1 3-sec value
30:4 AI:36 V3/V31 Voltage THD 0-9999 ×0.1% UINT16 R 1 3-sec value

11
Object : Var. Object : Point Description Options/Range2Units2Type R/W Notes
30:4 AI:37 I1 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:38 I2 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:39 I3 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:40 I1 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
30:4 AI:41 I2 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
30:4 AI:42 I3 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
NOTES:
1 When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line voltages.
2All analog input points except of harmonics are 1-second average values. For volts, amps and power scales and units, refer to Section 4 ”Data Scales and Units”. For analog input scaling
formulas and examples, see Section 2.2.5, “ Scaling Analog Input Objects”.
3.2 Binary Inputs - Basic Set
Object : Var. Object : Point Description Range Units Type R/W Notes
01:1 BI:0 Relay #1 status 0-1 R
01:1 BI:1 Relay #2 status 0-1 R
01:1 BI:2 Relay #3 status 0-1 R
01:1 BI:3 Relay #4 status 0-1 R
01:1 BI:16 Status input #1 0-1 R
01:1 BI:17 Status input #2 0-1 R
01:1 BI:18 Status input #3 0-1 R
01:1 BI:19 Status input #4 0-1 R
01:1 BI:48 Battery status 0-1 R
3.3 Binary Counters - Basic Set
Object : Var. Object : Point Description Range Units Type R/W Notes
20:5 BC:0 kWh import 0-999,999,999 kWh UINT32 R
20:5 BC:1 kWh export 0-999,999,999 kWh UINT32 R
20:5 BC:2 kvarh net 0-999,999,999 kvarh UINT32 R
20:5 BC:3 kVAh total 0-999,999,999 kVAh UINT32 R
20:5 BC:4 kvarh import 0-999,999,999 kvarh UINT32 R
20:5 BC:5 kvarh export 0-999,999,999 kvarh UINT32 R
20:5 BC:6 kVAh import 0-999,999,999 kVAh UINT32 R
20:5 BC:7 kVAh export 0-999,999,999 kVAh UINT32 R
20:5 BC:8 kvarh Q1 0-999,999,999 kvarh UINT32 R
20:5 BC:9 kvarh Q2 0-999,999,999 kvarh UINT32 R
20:5 BC:10 kvarh Q3 0-999,999,999 kvarh UINT32 R
20:5 BC:11 kvarh Q4 0-999,999,999 kvarh UINT32 R

12
3.4 Frozen Binary Counters
Object : Var. 1 Object : Point Description Range Units Type R/W Notes
Total Energies – Basic Set
21:var FBC:0 kWh import 0-999,999,999 kWh UINT32 R
21:var FBC:1 kWh export 0-999,999,999 kWh UINT32 R
21:var FBC:2 kvarh net 0-999,999,999 kvarh UINT32 R
21:var FBC:3 kVAh total 0-999,999,999 kVAh UINT32 R
21:var FBC:4 kvarh import 0-999,999,999 kvarh UINT32 R
21:var FBC:5 kvarh export 0-999,999,999 kvarh UINT32 R
21:var FBC:6 kVAh import 0-999,999,999 kVAh UINT32 R
21:var FBC:7 kVAh export 0-999,999,999 kVAh UINT32 R
21:var FBC:8 kvarh Q1 0-999,999,999 kvarh UINT32 R
21:var FBC:9 kvarh Q2 0-999,999,999 kvarh UINT32 R
21:var FBC:10 kvarh Q3 0-999,999,999 kvarh UINT32 R
21:var FBC:11 kvarh Q4 0-999,999,999 kvarh UINT32 R
Counters – Extended Set
21:var FBC:35328 Counter #1 0-999,999 UINT32 R
21:var FBC:35329 Counter #2 0-999,999 UINT32 R
21:var FBC:35330 Counter #3 0-999,999 UINT32 R
21:var FBC:35331 Counter #4 0-999,999 UINT32 R
Total Energies - Extended Set
21:var FBC:38656
kWh import 0-999,999,999 kWh UINT32 R
21:var FBC:38657 kWh export 0-999,999,999 kWh UINT32 R
21:var FBC:38658 Not used UINT32 R
21:var FBC:38659 Not used UINT32 R
21:var FBC:38660 kvarh import 0-999,999,999 kvarh UINT32 R
21:var FBC:38661 kvarh export 0-999,999,999 kvarh UINT32 R
21:var FBC:38662 Not used UINT32 R
21:var FBC:38663 Not used UINT32 R
21:var FBC:38664 kVAh total 0-999,999,999 kVAh UINT32 R
21:var FBC:38665 Not used UINT32 R
21:var FBC:38666 Not used UINT32 R
21:var FBC:38667 kVAh import 0-999,999,999 kVAh UINT32 R
21:var FBC:38668 kVAh export 0-999,999,999 kVAh UINT32 R
21:var FBC:38669 Not used UINT32 R
21:var FBC:38670 Not used UINT32 R
21:var FBC:38671 Not used UINT32 R
21:var FBC:38672 Not used UINT32 R
21:var FBC:38673 Not used UINT32 R
21:var FBC:38674 kvarh Q1 0-999,999,999 kvarh UINT32 R
21:var FBC:38675 kvarh Q2 0-999,999,999 kvarh UINT32 R
21:var FBC:38676 kvarh Q3 0-999,999,999 kvarh UINT32 R
21:var FBC:38677 kvarh Q4 0-999,999,999 kvarh UINT32 R

13
Object : Var. 1 Object : Point Description Range Units Type R/W Notes
Phase Energies - Extended Set
21:var FBC:38912
kWh import L1 0-999,999,999 kWh UINT32 R
21:var FBC:38913
kWh import L2 0-999,999,999 kWh UINT32 R
21:var FBC:38914
kWh import L3 0-999,999,999 kWh UINT32 R
21:var FBC:38915 kvarh import L1 0-999,999,999 kvarh UINT32 R
21:var FBC:38916 kvarh import L2 0-999,999,999 kvarh UINT32 R
21:var FBC:38917 kvarh import L3 0-999,999,999 kvarh UINT32 R
21:var FBC:38918 kVAh total L1 0-999,999,999 kVAh UINT32 R
21:var FBC:38919 kVAh total L2 0-999,999,999 kVAh UINT32 R
21:var FBC:38920 kVAh total L3 0-999,999,999 kVAh UINT32 R
NOTE
1 For object variation, see DNP Options setup (see Section 3.9).

14
3.5 Analog Inputs, Binary Inputs and Counters – Extended Set
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:4 AI:32768 None 0 UINT16 R
Digital Inputs DI1-DI4 R
01:1 BI:34304 DI1 0-1 R
01:1 BI:34305 DI2 0-1 R
01:1 BI:34306 DI3 0-1 R
01:1 BI:34307 DI4 0-1 R
Relay Outputs RO1-RO4 R
01:1 BI:34816 Relay #1 0-1 R
01:1 BI:34817 Relay #2 0-1 R
01:1 BI:34818 Relay #3 0-1 R
01:1 BI:34819 Relay #4 0-1 R
Counters
20:5 BC:35328 Counter #1 0-999,999 UINT32 R
20:5 BC:35329 Counter #2 0-999,999 UINT32 R
20:5 BC:35330 Counter #3 0-999,999 UINT32 R
20:5 BC:35331 Counter #4 0-999,999 UINT32 R
1-Cycle Phase Values
30:3 AI:35840 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:35841 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:35842 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:35843 I1 Current 0-Imax U2 UINT32 R
30:3 AI:35844 I2 Current 0-Imax U2 UINT32 R
30:3 AI:35845 I3 Current 0-Imax U2 UINT32 R
30:3 AI:35846 kW L1 -Pmax-Pmax U3 INT32 R
30:3 AI:35847 kW L2 -Pmax-Pmax U3 INT32 R
30:3 AI:35848 kW L3 -Pmax-Pmax U3 INT32 R
30:3 AI:35849 kvar L1 -Pmax-Pmax U3 INT32 R
30:3 AI:35850 kvar L2 -Pmax-Pmax U3 INT32 R
30:3 AI:35851 kvar L3 -Pmax-Pmax U3 INT32 R
30:3 AI:35852 kVA L1 0-Pmax U3 UINT32 R
30:3 AI:35853 kVA L2 0-Pmax U3 UINT32 R
30:3 AI:35854 kVA L3 0-Pmax U3 UINT32 R
30:4 AI:35855 Power factor L1 -1000-1000 ×0.001 INT16 R
30:4 AI:35856 Power factor L2 -1000-1000 ×0.001 INT16 R
30:4 AI:35857 Power factor L3 -1000-1000 ×0.001 INT16 R
30:4 AI:35858 V1/V12 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:35859 V2/V23 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:35860 V3/V31 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:35861 I1 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value

15
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:4 AI:35862 I2 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:35863 I3 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:35864 I1 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:35865 I2 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:35866 I3 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:35867 I1 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:35868 I2 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:35869 I3 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:3 AI:35870 V12 Voltage 0-Vmax U1 UINT32 R
30:3 AI:35871 V23 Voltage 0-Vmax U1 UINT32 R
30:3 AI:35872 V31 Voltage 0-Vmax U1 UINT32 R
1-Cycle Total Values
30:3 AI:36608 Total kW -Pmax-Pmax U3 INT32 R
30:3 AI:36609 Total kvar -Pmax-Pmax U3 INT32 R
30:3 AI:36610 Total kVA 0-Pmax U3 UINT32 R
30:4 AI:36611 Total PF -1000-1000 ×0.001 INT16 R
30:4 AI:36612 Total PF lag 0-1000 ×0.001 UINT16 R
30:4 AI:36613 Total PF lead 0-1000 ×0.001 UINT16 R
30:3 AI:36614 Total kW import 0-Pmax U3 UINT32 R
30:3 AI:36615 Total kW export 0-Pmax U3 UINT32 R
30:3 AI:36616 Total kvar import 0-Pmax U3 UINT32 R
30:3 AI:36617 Total kvar export 0-Pmax U3 UINT32 R
30:3 AI:36618 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R 1
30:3 AI:36619 3-phase average L-L voltage 0-Vmax U1 UINT32 R
30:3 AI:36620 3-phase average current 0-Imax U2 UINT32 R
1-Cycle Auxiliary Values
30:3 AI:36864 Not used UINT32 R
30:3 AI:36865 In (neutral) Current 0-Imax U2 UINT32 R
30:4 AI:36866 Frequency 0-Fmax ×0.01Hz UINT16 R
30:4 AI:36867 Voltage unbalance 0-3000 ×0.1% UINT16 R
30:4 AI:36868 Current unbalance 0-3000 ×0.1% UINT16 R
1-Second Phase Values
30:3 AI:37120 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:37121 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:37122 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
30:3 AI:37123 I1 Current 0-Imax U2 UINT32 R
30:3 AI:37124 I2 Current 0-Imax U2 UINT32 R
30:3 AI:37125 I3 Current 0-Imax U2 UINT32 R
30:3 AI:37126 kW L1 -Pmax-Pmax U3 INT32 R
30:3 AI:37127 kW L2 -Pmax-Pmax U3 INT32 R
30:3 AI:37128 kW L3 -Pmax-Pmax U3 INT32 R
30:3 AI:37129 kvar L1 -Pmax-Pmax U3 INT32 R
30:3 AI:37130 kvar L2 -Pmax-Pmax U3 INT32 R

16
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:3 AI:37131 kvar L3 -Pmax-Pmax U3 INT32 R
30:3 AI:37132 kVA L1 0-Pmax U3 UINT32 R
30:3 AI:37133 kVA L2 0-Pmax U3 UINT32 R
30:3 AI:37134 kVA L3 0-Pmax U3 UINT32 R
30:4 AI:37135 Power factor L1 -1000-1000 ×0.001 INT16 R
30:4 AI:37136 Power factor L2 -1000-1000 ×0.001 INT16 R
30:4 AI:37137 Power factor L3 -1000-1000 ×0.001 INT16 R
30:4 AI:37138 V1/V12 Voltage THD 0-9999 ×0.1% UINT16 R 2 3-sec value
30:4 AI:37139 V2/V23 Voltage THD 0-9999 ×0.1% UINT16 R 2 3-sec value
30:4 AI:37140 V3/V31 Voltage THD 0-9999 ×0.1% UINT16 R 2 3-sec value
30:4 AI:37141 I1 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:37142 I2 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:37143 I3 Current THD 0-9999 ×0.1% UINT16 R 3-sec value
30:4 AI:37144 I1 K-Factor 10-9999 ×0.1 UINT16 R 3-sec value
30:4 AI:37145 I2 K-Factor 10-9999 ×0.1 UINT16 R 3-sec value
30:4 AI:37146 I3 K-Factor 10-9999 ×0.1 UINT16 R 3-sec value
30:4 AI:37147 I1 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
30:4 AI:37148 I2 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
30:4 AI:37149 I3 Current TDD 0-1000 ×0.1% UINT16 R 3-sec value
30:3 AI:37150 V12 Voltage 0-Vmax U1 UINT32 R
30:3 AI:37151 V23 Voltage 0-Vmax U1 UINT32 R
30:3 AI:37152 V31 Voltage 0-Vmax U1 UINT32 R
1-Second Total Values
30:3 AI:37888 Total kW -Pmax-Pmax U3 INT32 R
30:3 AI:37889 Total kvar -Pmax-Pmax U3 INT32 R
30:3 AI:37890 Total kVA 0-Pmax U3 UINT32 R
30:4 AI:37891 Total PF -1000-1000 ×0.001 INT16 R
30:4 AI:37892 Total PF lag 0-1000 ×0.001 UINT16 R
30:4 AI:37893 Total PF lead 0-1000 ×0.001 UINT16 R
30:3 AI:37894 Total kW import 0-Pmax U3 UINT32 R
30:3 AI:37895 Total kW export 0-Pmax U3 UINT32 R
30:3 AI:37896 Total kvar import 0-Pmax U3 UINT32 R
30:3 AI:37897 Total kvar export 0-Pmax U3 UINT32 R
30:3 AI:37898 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R 1
30:3 AI:37899 3-phase average L-L voltage 0-Vmax U1 UINT32 R
30:3 AI:37900 3-phase average current 0-Imax U2 UINT32 R
1-Second Auxiliary Values
30:3 AI:38144 Not used UINT32 R
30:3 AI:38145 In (neutral) Current 0-Imax U2 UINT32 R
30:4 AI:38146 Frequency 0-Fmax ×0.01Hz UINT16 R
30:4 AI:38147 Voltage unbalance 0-3000 ×0.1% UINT16 R
30:4 AI:38148 Current unbalance 0-3000 ×0.1% UINT16 R
Present Volt, Ampere and Power Demands

17
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:3 AI:38400 V1/V12 Volt demand 0-Vmax U1 UINT32 R 2
30:3 AI:38401 V2/V23 Volt demand 0-Vmax U1 UINT32 R 2
30:3 AI:38402 V3/V31 Volt demand 0-Vmax U1 UINT32 R 2
30:3 AI:38403 I1 Ampere demand 0-Imax U2 UINT32 R
30:3 AI:38404 I2 Ampere demand 0-Imax U2 UINT32 R
30:3 AI:38405 I3 Ampere demand 0-Imax U2 UINT32 R
30:3 AI:38406 kW import block demand 0-Pmax U3 UINT32 R
30:3 AI:38407 kvar import block demand 0-Pmax U3 UINT32 R
30:3 AI:38408 kVA block demand 0-Pmax U3 UINT32 R
30:3 AI:38409 kW import sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38410 kvar import sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38411 kVA sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38412 Not used UINT32 R
30:3 AI:38413 Not used UINT32 R
30:3 AI:38414 Not used UINT32 R
30:3 AI:38415 kW import accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:38416 kvar import accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:38417 kVA accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:38418 kW import predicted sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38419 kvar import predicted sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38420 kVA predicted sliding window demand 0-Pmax U3 UINT32 R
30:4 AI:38421 PF (import) at Max. kVA sliding window demand 0-1000 ×0.001 UINT16 R
30:3 AI:38422 kW export block demand 0-Pmax U3 UINT32 R
30:3 AI:38423 kvar export block demand 0-Pmax U3 UINT32 R
30:3 AI:38424 kW export sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38425 kvar export sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38426 kW export accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:38427 kvar export accumulated demand 0-Pmax U3 UINT32 R
30:3 AI:38428 kW export predicted sliding window demand 0-Pmax U3 UINT32 R
30:3 AI:38429 kvar export predicted sliding window demand 0-Pmax U3 UINT32 R
Total Energies
20:5 BC:38656
kWh import 0-999,999,999 kWh UINT32 R
20:5 BC:38657 kWh export 0-999,999,999 kWh UINT32 R
20:5 BC:38658 Not used UINT32 R
20:5 BC:38659 Not used UINT32 R
20:5 BC:38660 kvarh import 0-999,999,999 kvarh UINT32 R
20:5 BC:38661 kvarh export 0-999,999,999 kvarh UINT32 R
20:5 BC:38662 Not used UINT32 R
20:5 BC:38663 Not used UINT32 R
20:5 BC:38664 kVAh total 0-999,999,999 kVAh UINT32 R
20:5 BC:38665 Not used UINT32 R
20:5 BC:38666 Not used UINT32 R
20:5 BC:38667 kVAh import 0-999,999,999 kVAh UINT32 R

18
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
20:5 BC:38668 kVAh export 0-999,999,999 kVAh UINT32 R
20:5 BC:38669 Not used UINT32 R
20:5 BC:38670 Not used UINT32 R
20:5 BC:38671 Not used UINT32 R
20:5 BC:38672 Not used UINT32 R
20:5 BC:38673 Not used UINT32 R
20:5 BC:38674 kvarh Q1 0-999,999,999 kvarh UINT32 R
20:5 BC:38675 kvarh Q2 0-999,999,999 kvarh UINT32 R
20:5 BC:38676 kvarh Q3 0-999,999,999 kvarh UINT32 R
20:5 BC:38677 kvarh Q4 0-999,999,999 kvarh UINT32 R
Phase Energies
20:5 BC:38912
kWh import L1 0-999,999,999 kWh UINT32 R
20:5 BC:38913
kWh import L2 0-999,999,999 kWh UINT32 R
20:5 BC:38914
kWh import L3 0-999,999,999 kWh UINT32 R
20:5 BC:38915 kvarh import L1 0-999,999,999 kvarh UINT32 R
20:5 BC:38916 kvarh import L2 0-999,999,999 kvarh UINT32 R
20:5 BC:38917 kvarh import L3 0-999,999,999 kvarh UINT32 R
20:5 BC:38918 kVAh total L1 0-999,999,999 kVAh UINT32 R
20:5 BC:38919 kVAh total L2 0-999,999,999 kVAh UINT32 R
20:5 BC:38920 kVAh total L3 0-999,999,999 kVAh UINT32 R
V1/V12 Harmonic Distortion
2
30:4 AI:39168
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:39169
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:39217
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
V2/V23 Harmonic Distortion
2
30:4 AI:39424
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:39425
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:39473
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
V3/V31 Harmonic Distortion
2
30:4 AI:39680
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:39681
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:39729
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
I1 Harmonic Distortion
30:4 AI:39936
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:39937
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:39985
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
I2 Harmonic Distortion

19
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:4 AI:40192
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:40193
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:40241
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
I3 Harmonic Distortion
30:4 AI:40448
H01 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 AI:40449
H02 Harmonic distortion 0-100.00 0.01% UINT16 R
30:4 ...
30:4 AI:40497
H50 Harmonic distortion 0-100.00 0.01% UINT16 R
Fundamental Phase Values 0.2-sec values
30:3 AI:43264 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:43265 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:43266 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:43267 I1 Current 0-Imax U2 UINT32 R
30:3 AI:43268 I2 Current 0-Imax U2 UINT32 R
30:3 AI:43269 I3 Current 0-Imax U2 UINT32 R
30:3 AI:43270 kW L1 -Pmax-Pmax U3 INT32 R
30:3 AI:43271 kW L2 -Pmax-Pmax U3 INT32 R
30:3 AI:43272 kW L3 -Pmax-Pmax U3 INT32 R
30:3 AI:43273 kvar L1 -Pmax-Pmax U3 INT32 R
30:3 AI:43274 kvar L2 -Pmax-Pmax U3 INT32 R
30:3 AI:43275 kvar L3 -Pmax-Pmax U3 INT32 R
30:3 AI:43276 kVA L1 0-Pmax U3 UINT32 R
30:3 AI:43277 kVA L2 0-Pmax U3 UINT32 R
30:3 AI:43278 kVA L3 0-Pmax U3 UINT32 R
30:4 AI:43279 Power factor L1 -1000-1000 ×0.001 INT16 R
30:4 AI:43280 Power factor L2 -1000-1000 ×0.001 INT16 R
30:4 AI:43281 Power factor L3 -1000-1000 ×0.001 INT16 R
Fundamental Total Values 0.2-sec values
30:3 AI:43520 Total fundamental kW -Pmax-Pmax U3 INT32 R
30:3 AI:43521 Total fundamental kvar -Pmax-Pmax U3 INT32 R
30:3 AI:43522 Total fundamental kVA 0-Pmax U3 UINT32 R
30:4 AI:43523 Total fundamental PF -1000-1000 ×0.001 INT16 R
Minimum 1-Cycle Phase Values
30:3 AI:44032 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:44033 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:44034 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:44035 I1 Current 0-Imax U2 UINT32 R
30:3 AI:44036 I2 Current 0-Imax U2 UINT32 R
30:3 AI:44037 I3 Current 0-Imax U2 UINT32 R
30:3 AI:44038-
AI:44049 Not used 0 INT32 R

20
Object : Var. Object : Point Description Options/Range3Units3Type R/W Notes
30:4 AI:44050 V1/V12 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:44051 V2/V23 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:44052 V3/V31 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:44053 I1 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:44054 I2 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:44055 I3 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:44056 I1 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:44057 I2 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:44058 I3 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:44059 I1 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:44060 I2 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:44061 I3 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
Minimum 1-Cycle Total Values
30:3 AI:44288 Total kW -Pmax-Pmax U3 INT32 R
30:3 AI:44289 Total kvar -Pmax-Pmax U3 INT32 R
30:3 AI:44290 Total kVA 0-Pmax U3 UINT32 R
30:4 AI:44291 Total PF 0-1000 ×0.001 UINT16 R Absolute value
Minimum 1-Cycle Auxiliary Values
30:3 AI:44544 Not used UINT32 R
30:3 AI:44545 In Current 0-Imax U2 UINT32 R
30:4 AI:44546 Frequency 0-Fmax ×0.01Hz UINT16 R
Maximum 1-Cycle Phase Values
30:3 AI:46080 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:46081 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:46082 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
30:3 AI:46083 I1 Current 0-Imax U2 UINT32 R
30:3 AI:46084 I2 Current 0-Imax U2 UINT32 R
30:3 AI:46085 I3 Current 0-Imax U2 UINT32 R
30:3 AI:46086-
AI:46097 Not used 0 INT32 R
30:4 AI:46098 V1/V12 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:46099 V2/V23 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:46100 V3/V31 Voltage THD 0-9999 ×0.1% UINT16 R 2 0.2-sec value
30:4 AI:46101 I1 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:46102 I2 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:46103 I3 Current THD 0-9999 ×0.1% UINT16 R 0.2-sec value
30:4 AI:46104 I1 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:46105 I2 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:46106 I3 K-Factor 10-9999 ×0.1 UINT16 R 0.2-sec value
30:4 AI:46107 I1 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:46108 I2 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
30:4 AI:46109 I3 Current TDD 0-1000 ×0.1% UINT16 R 0.2-sec value
