SK-7000 User Manual

CONTENTS
1 GUIDE ...................................................................................................1
1.1 Important Safety Instructions.........................................1
1.2 Unpacking ...............................................................................2
1.3 PRODUCT OVERVIEW & ILLUSTRATION ..................2
1.4 INSTALLATION OF METER ..............................................5
2 OUTLINE .............................................................................................5
3. THE MENU OSD INSTRUCTION................................................6
3.1 Channel Find ..........................................................................6
3.1.1 Country Setting .............................................................7
3.1.2 Channel No ......................................................................7
3.1.3Frequency .........................................................................7
3.1.4Bandwidth .........................................................................7
3.1.5Mode ...................................................................................7
3.1.6 Beep Tone ........................................................................7
3.1.7 Antenna Setting .............................................................7
3.1.8Antenna Setting ..............................................................7
3.1.0.1 QuickSearch ................................................................7
3.2 Program Info ..........................................................................9
3.3 Channel .................................................................................10
3.3.1 TV List ............................................................................ 10
3.3.2 Radio List ...................................................................... 10
3.3.3 EPG ..................................................................................12
3.4 Spectrum...............................................................................13
3.5 Multimedia ........................................................................... 14

3.6 System Setting ....................................................................16
5.Technical Specication ...............................................................19
6.Trouble Shooting ..........................................................................21

Digital DVBT Meter
1
1 GUIDE
1.1 Important Safety Instructions
Thank you for choosing our product. Before installation,
we would like to remind you some notes, which is very
important for operating safely and properly, as follows:
gBe sure to read this user manual, before starting your
operation.
gYou must install the dish with correct direction and
angle. If the dish is not working properly, contact your
local dealer.
gWhen the unit is suddenly moved to a hot area from a
cold area, it may cause some problems. In that case, turn
o󱐯 the power, and turn on again after 1-2 hours.
gKeep meter placed in clean space with su󱐰cient
ventilation.
gDo not cover the meter with or place it on a unit that
emits heat.
gClean the case by a soft cloth with a little washing liquid.
gDo not remove the cover.
gDo not let the unit exposed to extreme heat, cold or
humid conditions.
gNo liquids or any other materials to come inside of the
unit.

Digital DVBT Meter
2
1.2 Unpacking
Open the package and make sure it includes all below
items, if any missing, please contact the reseller for
replacement.
1.Digital SatelliteMeter
2.User’s manual
3.AV cable
4.Car charger cable
5.Power Adaptor
6.Strap of carrying case
7. DC 12V connect line
1.3 PRODUCT OVERVIEW&ILLUSTRATION

Digital DVBT Meter
3
NO Description FUNCTION
1 LNB IN Connect to satellite antenna cable
2 DC 12V OUTPUT DC 12V output for extern equipment
3 AV OUT Connect to AV port for TV
4 AV IN Connect to AV port for meter
5 HDMI Use HDMI cable to connect for TV
6 Power witch Turn on/o󱐯 meter
7 USB Port Connect to USB memory
8 DC Slot Connect to Adaptor Input
9 Torch LED Night lighting
10 Speaker Speaker Integrated
11 Power Power indicator light

Digital DVBT Meter
4
12 5V ANT 5V indicator light
13 12V/17v ANT 12V/17V indicator light
14 LOCK Signal lock indicator light
15 Charger (Note1) Charger indicator light
16 Red & TTXT Red KEY &Teletextinterface
17 Green & SUBT Green key & Subtitle interface
18 Orange &TV/R Orange key & TV and radio switch
19 BLUE &AUDIO Blue key & Audio interface
20 AV-S If we connect AV IN; switch AV in/out
for LCD and speaker
21 INFO INFO key
22 MUTE MUTE
23 MENU Show the main menu on the screen or
jump back to previous menu in sub-
menu setting conditions
24 EXIT Escape from present menu and save
the settings
25 NEVIGATION KEY Volume Control or move cursor, channel
or change, conrm etc
26 0-9 Number key to select channels or enter
programming
27 SCAN ‘Quick Search’menu shortcut key
28 F1 Auxiliary function key
29 F2 Auxiliary function key
30 F3 Auxiliary function key
31 F4 Auxiliary function key
32 LCD TFT LCD Screen
31 (Note 4) When power on the meter ,displays the
battery level
Note1:When the adapter insert dc slot, Charge indicator is
often bright, when the batteries charged su󱐰cient, the charge
indicator is go out.

Digital DVBT Meter
5
1.4 INSTALLATION OFMETER
2.OUTLINE
d4.3 Inch High Denition TFT LCD Screen
dFully DVB-T/DVB-T2, MPEG-2/MPEG-4 compliant
dMPEG-2 / H.264 Hardware decoding
dDigital meter for signal strength and quality
dSupports scan of Auto,Manual
dSound and Light Alarm for Locking Signal
dSpeaker Integrated
dSupport both AV out and AV in
dANT short protect
d7.4V/3000mAh Li-Ion Battery Included

Digital DVBT Meter
6
dDC12V output for monitor
dSoftware upgrade via USB port
dEasy to carry
3. THE MENU OSD INSTRUCTION
If you have installed and connected the cables of the meter,
pressing MENU key to display the Main Menu.
gChannel Find
gProgram Info
gChannel
gSpectrum
gMultimedia
gSystem Setting
Press the keys of ▲▼◄► to move the cursor up or down in
the menu interface, then use OK key to conrm a selection.
3.1 Channel Find

Digital DVBT Meter
7
3.1.1 Country Setting
Press ◄►key to change the defaultcountry.
3.1.2 Channel No
Press ◄►key to change the channel number.
3.1.3 Frequency
Frequency of the current channel, Input the value by using
the numeric keys.
3.1.4 Bandwidth
Press ◄►key to change the bandwidth, we can select 5,
6, 7 or 8M.
3.1.5 Mode
Press ◄►key to change the DVB standard, we have there
types including T/T2/T+T2, you can select one you want.
3.1.6 Beep Tone
Press ◄►key to switch beep tone. If we open the beep
tone, when we enter into the search screen, the beep of lock
alarm will open.
3.1.7 Antenna Setting
Press ◄► key to change the antenna power, we have there
types including 5v/12V/17v, you can select one you want.
3.1.8 Antenna Setting
Press ◄►key to power on or o󱐯the antenna
3.1.0.1 Quick Search
In the Channel Find interface,pressOK key will enter into

Digital DVBT Meter
8
Quick Search
gCh Scan: Press OK/F1 key to search current channel.
gAuto Scan : Press F2 key to auto blind search the current
channel.
gBeep :Press F3 key to open beep tone.
g Zoom : Press F4 key toenlarge showing of the signal
strength and quality.

Digital DVBT Meter
9
3.2 Program Info
When we receive signal, we can scan some relative parameter
information in this interface.

Digital DVBT Meter
10
3.3 Channel
We have there options in this menu.
3.3.1&3.3.2TV List & Radio List
When we enter into the TV List, we can edit TV Program.
In the Radio List we have the same operation.

Digital DVBT Meter
11
gSort : Press F1keyinto the sort list. Use ▲▼ key to move
the cursor, then press OK key to select the sort type of we
want; then press ok key to conrm or move the cursor to
“x” press ok key to cancel
gLock:Press ▲▼ key to the program that we want lock or
unlock, then press F2 key to lock or unlock the program.
When we deal with all the program need to be processed,
press menu key to then press ok key to conrm the
operation or select “x”; press ok key to cancel.

Digital DVBT Meter
12
g Del : Press F3 key to select“Delete Select” or “DeleteALL”.
Press ▲▼ key to select the program that we wantto
delete, then press F3 key to label. When we deal with all
the program need to be processed, press menu key to then
press ok key to conrm the operation or select “x”; press
ok key to cancel.
g Top : Press F4 key to place a TV or Radio program you
want on top.
3.3.3 EPG
Press ▲▼key to change program. If the current program
has EPG information, it will appear on the right side of
the window.Press ◄►key to change the day of the EPG
information.

Digital DVBT Meter
13
3.4 Spectrum
When we enter into this interface, we can press ◄◄ key
to scan some information about spectrum in di󱐯erent
frequency point.
gFull/Ch : Press F1 key to make all the frequency points
we can see on the window or to make some frequency
points on it.
gZoom : Press F2 key to enlarge showing the point you
current select, and press again it will be back

Digital DVBT Meter
14
gLocked : Press F3 key to lock all the current frequency
points, and remain unchanged unless you press again
gScan : When the frequency points have been locked, you
can press F4 key to receive signal on a point.
3.5 Multimedia
Will need to play the les in the USB stick and insert it into
the machine.

Digital DVBT Meter
15
○ Movie
Press red key to option the mode of play les and text
encode; then press menu key return.
Press green key to Change the folder File view to detailed
list.
Press orange key to change mode to big Icon browsing.
Press the arrow keys to move the cursor, then press ok key
to enter the le.
In the pay interface:
F1 Key: normal play.

Digital DVBT Meter
16
F2 Key: pause.
F3 Key: fast backward; press F1 key return.
F4 Key: fast forward; press F1 key return.
○ Music /Photo
Please refer to the Movie operating.
3.6 System Setting

Digital DVBT Meter
17
○ Country Setting
Press ◄► key to change the country
○ OSD Language
Press ◄► key to change the OSD Language.
○ TV Format
Press ◄► key to change the TV Format.
○ Video Output
If we connect HDMI interface, we can press ◄► key.
○ TV Resolution
On the basis of the Video Output choice, we can press ◄►
key to change the TV resolution.
○ Digital Audio Output
Press ◄► key to change the LPCM or RAW format.
○ Time Zone
Press ◄► key to change the Time Zone.
○ PWR Unit
Press ◄► key to change the PWR unit.
○ Flashlight
Press ◄► key to switch Flashlight on/o󱐯.
○ 12V
Press ◄► key to switch 12V on/o󱐯.
○ KB-BackLight
Press ◄► key to switch delay time of back light.
○Upgrade & Backup
