sauter EY-RU Series User manual

PDS 94.170 EY-RU241...246
ecoUnit241…246: Комнатное рабочее устройство для комнатной станции автоматизации
Как повышается энергетическая эффективность
Индивидуальное регулирование времени присутствия иотсутствия, также корректировка комнатных
уставок ирегулирование освещения изатемнения для оптимизации комнатного потребления энергии.
Область применения
Рабочее устройство для регулирования игарантии максимального комфорта вкомнате. Измерение и
регулировка температуры вкомнатах сразными типами оборудования благодаря интеллектуальному
унитарному контроллеру EY-modulo 2 ecos скоммуникативными возможностями.
Характеристики
•Часть серии систем SAUTER EY-modulo 2
•Комнатное рабочее устройство сразличными вариантами функциональности, конструкции ицвета
•Отображает различные функциональные символы
•Устройство спрозрачной передней крышкой монтируется врамку профиля 55 x 55 мм
•Рамки должны быть заказаны как аксессуары
•Внутренний климат может быть отрегулирован индивидуально
•Режим работы устанавливается сучетом присутствия людей вкомнате ирегулируется
трехступенчатым вентилятором
Техническое описание
•Питание от ecos 2
•3 (4) –жильное подключение, кабельный вход сзади, вставные клеммы для проводов от 0.12 до 0.5 мм²
(диаметромот 0.4 до 0.8 мм)
Продукт
Тип Описание
EY-RU241F001 ecos2 комнатная панель, LCD, NTC датчик, задатчик уставки dXs, без рамки, 2 кнопки
EY-RU244F001 ecos2 комнатная панель, LCD, NTC датчик, задатчик уставки dXs, 4 кнопки
EY-RU246F001 ecos2 комнатная панель, LCD, NTC датчик, задатчик уставки dXs, 6 кнопок
Технические данные
Электропитание Установка
Питание от ecos 2 Установка водинарной или двойной рамке
Размеры Дx Вx Ш(мм) 59.5 x 59.5 x 25
Версия Вес (кг) 0.1
Датчик
Диапазон измерений 0…40 °C Стандарты, нормативы идирективы
Разрешение 0.1 K Степень защиты IP 30 (EN 60529)
Временная постоянная 12 мин Класс защиты III (EN 60730-1)
Функциональные Окружающий класс 3K3 (IEC 60721)
Уставка дисплея (LCD) 0…10 V = 16…25.5 °C CE соответствие
(через терминал 4) Директива EMC 2004/108/EC EN 61000-6-1
Разрешение 0.1 K EN 61000-6-2 1)
Коррекция уставки настраиваемая EN 61000-6-3
Присутствие (занятость комнаты)3режима, LCD дисплей EN 61000-6-4
Скорость вентилятора 5 функций, LCD дисплей
Порт Дополнительная информация
Кабель 3 (4) –жильный, витой Инструкция по монтажу; P100002722
Длина ≤100 мДекларация материалов MD 94.170
Допустимые окружающие условия Размерный чертеж M10501
Рабочая температура 0…45 °C Монтажная схема A10528
Температура хранения и
транспортировки
-25…70 °C
Влажность 10…85% rh
без конденсации
1) При обязательном требовании выполнения промышленного стандарта (EN 61000-6-2), максимальная длина кабелей подключения не должна превышать 30 м.
