The Savant HDMI Over CAT5/6 Extender (HCX-1010) Quick Reference Guide provides the
steps necessary to install the HCX-1010.
Note: Savant does not support IR functionality for this extender.
Box Contents
(1) HDMI over CAT5/6 Solution Set (HCX-1010-xx) includes the following:
•(1) Transmitter Unit
•(1) Receiver Unit
•(2) 5V DC Power Supply with locking power connector
(1) Quick Reference Guide
Unpack the Components
To unpack and install the components listed above, do the following:
1. Open the component box and remove the packing.
2. Remove the component and supplied items from the box.
3. Place the components in a location that provides for adequate cooling and ventilation,
and access to connectors in order to route the source power cables and other required
cables.
Specifications
Environmental
Temperature
32° to 95° F (0° to 35°C)
Humidity
10% to 905 RH (non-condensing)
Dimensions and Weight
Dimensions (H x W x D)
1.25 in x 3.25 in x 3.4 in (3.2 cm x 8.2 cm x 8.6 cm)
Weight
1.5 lb (0.68 kg)
Power
Power Supply
120V AC, 50/60 Hz to 5V DC
Maximum Power
10 Watts per unit
Signal/Data Transmission
Video Amplifier Bandwidth
225 MHz
Input Video Signal
1.2 Volts p-p
Input DDC Signal
5 Volts p-p (TTL)
Maximum Ethernet Data
Transmission Rate
100 Mbps
Ethernet Packet
Transmission Mode
(Duplex)
Full
Resolution
Maximum Video
Resolution Supported
1080p60/1920 x 1200@60 Hz
HDMI
Supports all HDMI 1.3 specifications
Supports 3D resolutions for HDMI 1.4 specifications
Compliance
Safety and Emissions
FCC Part 15 | CE Mark | C-Tick
RoHS
Compliant
ELECTRICAL DISCONNECT: The 5V DC power adaptor connected to the HCX-1010
should be easily accessible in the event of an electrical malfunction.
SURGE PROTECTION: Use a surge-protected circuit for all components requiring 120V
AC, 50/60 Hz source power.
ELECTRICAL DISCONNECT: Remove power before working on the HCX-1010.
Transmitter Front and Rear Panels
Front Panel
Connectors
5V DC
Locking power supply input. Provides
5V DC input power to transmitter
HDMI In
Provides HDMI signal input to
Transmitter
Indicator
Power LED
Red indicates the Transmitter is
receiving 5V DC power.
Off indicates the Transmitter is not
receiving 5V DC power.
Rear Panel
Connectors
Link
RJ-45 Shielded
Ethernet
CAT5/6 Ethernet Connector
IR Blaster
Reserved for future use.
Receiver Front and Rear Panels
Front Panel
Connectors
5V DC
Locking power supply input. Provides 5V DC input
power to Receiver
HDMI Out
Type A 19-Pin Female; Outputs HDMI signal input
to Display
IR
Reserved for future use.
Indicator
Power LED
Red indicates the Receiver is receiving 5V DC
power.
Off indicates the Receiver is not receiving 5V DC
power.
5V DC Power
Supply Input
Power LED
Indicator
HDMI Input from
A/V Source
Not
Supported
CAT 5/6
Ethernet
Connector
CAT 5/6 Link
Connector to
Receiver
Not
Supported
HDMI Output
to Display
Power LED
Indicator
5V DC Power
Supply Input

HDMI Over CAT5/6 Extender
(HCX-1010)
Quick Reference Guide
009-0306-04
HCX-1010-00
Copyright © 2012 Savant Systems LLC, SAVANT and RacePoint Blueprint are trademarks of Savant Systems, LLC.
All brand names, product names and trademarks are the property of their respective owners.
Savant Systems, LLC reserves the right to change product specifications without notice.
Savant Confidential and Proprietary
052912
45 Perseverance Way, Hyannis, MA 02601 Phone [phone] Fax [phone] www.SavantSystems.com
Rear Panel
Connectors
Link
RJ-45 Shielded
Ethernet
CAT5/6 Ethernet Connector
Ext IR
Reserved for future use.
Interconnect the Units
To interconnect the units, do the following:
1. Connect the Savant Extra Long Range Extender Over one CAT5/6 cable to the A/V
and Ethernet source devices such as infrastructure, routers and switches using short
HDMI and CAT5/6 cables.
2. Do the same operation between the Extender receiver and the extended HD display
and any network devices that are to be connected.
3. When the Extender Transmitter and Receiver units have been connected to sources,
displays and network equipment, connect a single CAT5/6 extension cable between
the Transmitter and Receiver. The Transmitter and Receiver units may be up to 330
feet apart.
Details for Connecting the Transmitter and Receiver
1. Connect an HDMI source to the Transmitter unit. Also connect an Ethernet source to
the Transmitter unit.
2. Connect the Receiver unit to a suitable display using an HDMI cable. Connect a
CAT5/6 cable to the Display.
3. Connect the Transmitter unit to the Receiver unit using the CAT5/6 Ethernet cable.
4. Apply power to all connected units. Plug the AC power adaptors between the power
strip and the 5V DC input connectors on the Transmitter and Receiver.
Important: Savant recommends the use of a CAT6 solid core cable for optimum
performance. Also, a single continuous run from the transmitter to the receiver is
recommended. Use of patch panels or wall plates may interfere with the signal.
Wiring Diagram for the HCX-1010 - HDMI over CAT5/6 Extender
Additional Documentation
For more documentation, go to http://www.SavantSystems.com and navigate as follows:
>Dealer Login > Knowledge Base >
•Click link: RacePoint Blueprint™
Not
Supported
CAT 5/6
Ethernet
Connector
CAT 5/6 Link
Connector
to Sender
