Savaria Eclipse User manual

(To Be Retained by Owner After Installation by Authorized Savaria Dealer)
©Savaria Corporation
Part No. 000626 (Rev. 28-m09-2010)
Eclipse
Residential Elevator
OWNER’S MANUAL

2 of 14
Installing Dealer:
FOR OWNER’S RECORDS
Customer Name:
Installing Dealer:
Dealer’s Telephone Number:
Date Installed:
Serial/Job Number:
IMPORTANT
Ensure that only an authorized Savaria dealer installs, services, and maintains
the Eclipse Residential Elevator. Under no circumstances is anyone other than
a dealer with Savaria training and authorization to install, adjust, service or
modify any mechanical or electrical device on this lift. Failure to follow this
warning can result in safety systems compromises or defeat; this can result in
serious injury or death. Savaria accepts no liability for property damage, war-
ranty claims or personal injury, including death, in this circumstance.
Lift and elevator passenger safety is the result of countless details in the
equipment’s design, manufacture, and installation. After installation, reliable
operation and continual safe operation requires regular service and inspec-
tion at least twice per year, or more frequently where usage, environment,
or local jurisdiction require. As the owner, you are responsible to ensure that
regular service and inspections occur in a timely manner.
Refer to this manual for operating instructions, precautions, and usage of the
Eclipse Residential Elevator.
Upon completion of installation, the dealer must provide the owner with the
information below and ensure it is recorded in this manual. In addition, either
the dealer or the owner must keep any service and/or maintenance records in
the Maintenance Record section of this manual.
WARRANTY
Ensure your authorized Savaria Dealer provides you with a copy of the manu-
facturer’s limited parts warranty and documentation relating to any Dealer
labour warranty.

3 of 14
ECLIPSE
RESIDENTIAL ELEVATOR
OWNER’S MANUAL
TABLE OF CONTENTS
1. GENERAL SPECIFICATIONS 4
2. STANDARD FEATURES 6
3. OPTIONAL FEATURES 8
4. OPERATING THE ELEVATOR
FROM THE LANDING CONTROLS 9
5. OPERATING THE ELEVATOR
FROM THE CAB CONTROLS 10
6. POWER FAILURE AND EMERGENCY LOWERING 11
7. EMERGENCY LIGHT 11
8. MANUAL LOWERING 12
9. MAINTENANCE AND INSPECTION CHECKS 13
10. MAINTENANCE RECORD 14

4 of 14
ECLIPSE RESIDENTIAL ELEVATOR
Load capacity 750 lbs. (340 kg), 950 lbs. (431 kg), 1000 lbs. (454 kg)
Rated speed 40 feet per minute (0.20 mps) (standard)
Power supply
(circuit supplied by others)
208 volt - 230 volt, single phase, 60 Hz, 20 amps, North America
220 volt - single phase, 50 Hz, International
Lighting supply
(circuit supplied by others) 120 volt, 60 cycle, 15 amps
Drive system Automatic 2HP-geared motor roller chain variable frequency drive, complete
with counterweight
Temperature operating
range - 10 °C to + 40 °C / 14 °F to 104 °F
Cab sizes
W36” x L48” x H80” (914 mm x 1219 mm x 2032 mm), Type 1, 2, 3, 4, 5
W36” x L54” x H80” (914 mm x 1371 mm x 2032 mm), Type 1, 2, 3, 4, 5
W36” x L60” xH80” (914 mm x 1524 mm x 2032 mm), Type 1, 2, 3, 4, 5
W40” x L54” x H80” (1067 mm x 1371 mm x 2032 mm), Type 1, 2, 3, 4, 5
Cab panel and nish
Solid melamine or MDF panels - standard; unnished veneer panels - optional;
nished recessed veneer panels - optional; solid hardwood raised panels -
optional
Maximum travel 50 feet (12.24 m), 60 feet (18.29 m) available where code is not applicable
Control system Relay logic controller complete with diagnostic LEDs
Levels and openings Up to 4 stops / up to 2 cab openings
Pit depth requirement 6” (152 mm), 11” (279 mm) minimum with buer springs
Minimum overhead
clearance 96”(2438 mm) for standard 80”cab, 114” (2896 mm) for 96” cab
Hall station and control
panel nish
Clear bronze anodized aluminum (standard), or stainless steel (optional), or
brass (optional)
Rectangular (standard) or oval (optional) hall stations, keyless (standard) or
keyed (optional)
Standard features
Automatic cab on/o lighting
Recessed gate pocket
Digital display in cab operating panel
Clear or bronze anodized aluminum cab entrance trim and handrail
Data plates, capacity tags
Proximity oor selection, stopping and two-way levelling
Home landing feature
Presentation drawings
Modular rail sections
Unnished plywood sub-oor
White ceiling with four incandescent pot lights
1. GENERAL SPECIFICATIONS

5 of 14
ECLIPSE RESIDENTIAL ELEVATOR
Safety features
Cab gate safety switch
Main controller cab wall access safety switches
Pit run/stop switch and car top run/stop switch
Emergency stop and alarm buttons
Uninterruptible power supply (UPS)/battery backup system for
lowering, automatic gate operation (if equipped), and electrical
interlock operation and lighting in the event of a power failure
Upper and lower terminal limits
Motor access door (locked and switched)
Handcrank
Emergency lights
Final limit switch
Mechanical rail shoring blocks
Sling: factory pre-assembled speedy sling, counterweight, preset slack
chain safety brake, and switch
Options
96” high cab
Rated speed - (50 fpm (0.250 mps) available where code permits)
Accordion car gate (choice of style)
Automatic gate operator (accordian gates only)
Automatic gate swing landing door operator
Buer springs (11”pit depth minimum)
Laminate ooring in nished oak, maple, or cherry
Interlocks for doors by others (PORTA, Kwiklock ,or EMI)
Keyed on/o hall stations
Oval hall call design
Cab interior in unnished oak, birch, cherry, or maple veneer
Recessed cab panels in cherry, oak, or maple veneer
Raised cab panels in solid cherry, oak, or maple veneer
Telephone cabinet to match car operating panel
Custom cab size
Ceiling panel to match walls

6 of 14
2. STANDARD FEATURES
1) Cab Key Switch (Figure 1-A)
The key switch turns the cab controls ON and
OFF. It limits the use of the elevator to authorized
persons only.
2) Cab Operating Panel Buttons (Figure 1-B)
Automatic Control
The Automatic Control Panel buttons facilitate
the UP/DOWN movement of the cab between
landings. After pressing a landing button, the cab
automatically moves to the landing.
The cab stops once it arrives at the selected
landing.
3) Door Open Button (Figure 1-C)
The elevator door/gate closes automatically after
a pre-set adjustable duration from 1 - 30 seconds.
Press the Door Open button to open the door/gate
once the cab is at a landing, if equipped.
4) Alarm Button (Figure 1-D)
Press the Alarm button to sound the alarm in case
of an emergency.
5) Emergency Stop Button (Figure 1-E)
Press the Emergency Stop button to Stop the cab
and activate the alarm buzzer at any time. Figure 1 Cab Operating Panel

7 of 14
6) Handrail
A single handrail is on the Cab Operating Panel side of the cab.
7) Emergency Light
The cab emergency light remains ON in the event of a main power
failure. The emergency light uses a Battery Back-Up system and
includes an automatic recharger.
8) Landing Hall Call Station Controls
Hall Call Stations at all landings initiate the
movement of the cab to the landing. An
optional key switch limits the elevator’s use
to authorized persons only.
9) Landing Door and/or Gate Interlock
The Landing Door/Gate lock prevents cab
movement unless the door/gate is in the shut
position with the lock in place. If the door/
gate is not completely shut, the cab does not
move.
10) Emergency Battery Operation
In the event of a building power failure, the door/gate system includes
a temporary power back-up system to allow the elevator to run
down to the next available landing, or to the 1st floor landing. The
lift cannot run up on battery power. Upon resuming normal building
power, the back-up system turns OFF and automatically recharges.
Figure 2 Hall Call Station

8 of 14
3. OPTIONAL FEATURES
Outside Entrance Automatic Door Opener - Landing Door
a) Press the Landing Hall Call button to call the elevator. The outside
landing door opens automatically once the elevator stops at the
landing.
b) Press the Remote Control (if equipped) to open the landing door
once the elevator stops at the landing.
c) The Push ’n’ Go system on the automatic door opener allows the
landing door to open automatically with a slight push to the door
itself. The door timer is inoperative when this feature is active.
Inside Entrance Automatic Gate Opener - Cab Gate
a) Press the Landing Hall Call button to call the elevator. The
outside landing door opens automatically if equipped with an
automatic door opener. The inside gate opens automatically
if equipped with an automatic gate opener once the
elevator stops at the landing and the outside landing door is
fully open.
NOTE
If the cab is equipped with a gate, the gate must be closed
after exiting the cab. If the gate is left open, all controls remain
inoperable.

9 of 14
NOTE
When using the landing controls, the cab can only be moved
(called) to the level from which you are calling. When using the
control buttons in the cab, the cab can be moved to any level.
WHEELCHAIR WHEELS MUST BE LOCKED AT ALL
TIMES WHEN THE ELEVATOR IS MOVING
4. OPERATING THE ELEVATOR FROM THE LANDING CONTROLS
Automatic Operation
1) Insert the key (if equipped) into the switch on the Hall Call
Station and turn the key to the ON position.
2) Press the Hall Call button once and release. The elevator
automatically comes to your landing.
4) If equipped with a manual landing door, turn the door handle
and pull the door open.
5) If equipped with a manual cab gate, slide the gate open and
enter the cab while closing the landing door behind you.
6) Once inside the cab, close the gate, insert the key (if equipped)
into the key switch, turn the key to the ON position, and press
the desired floor button.

10 of 14
NOTE
If the cab is equipped with a gate, the gate must be closed
after exiting the cab. If the gate is left open, all controls remain
inoperable.
5. OPERATING THE ELEVATOR FROM THE CAB CONTROLS
Automatic Operation
1) Insert the key (if equipped) into the switch in the Cab Operating
Panel. Turn the key to the ON position.
2) Press a Floor Landing button once and release. The elevator
automatically travels to and stops at the Floor Landing.
3) Turn the key (if equipped) to the OFF position and remove the key.
NOTE
The outside landing door must be closed after exiting or
entering the cab. If the outside landing door is left open, all
controls remain inoperable.

11 of 14
6. POWER FAILURE AND EMERGENCY LOWERING
In the event of a power failure, the elevator includes a Battery Back-Up
system that allows the user to lower the elevator from inside the cab.
This device operates on batteries and activates only if a main power
supply failure occurs. The following steps describe this operational
sequence:
1) For elevators with automatic operation, press any Floor
Landing button below the floor where the elevator currently
rests.
2) Upon arrival at the floor, the landing door automatically
unlocks.
3) If the door includes an automatic gate, the gate opens.
4) Remove the key, open the manual gate, (if equipped) and exit
the cab.
7. EMERGENCY LIGHT
In the event of a main power failure, the emergency cab lights
automatically illuminate.

12 of 14
8. MANUAL LOWERING
In the event of a power failure, batteries lower the cab to the next
level and open the doors. Should the batteries fail, use the telephone
to call for help, if equipped. A technician can use the Manual Hand
Crank to lower the elevator.
1) Instruct the person(s) in the elevator to remain calm and to stay
well back from the door of the elevator. Ease their concern by
telling them your intentions.
2) Turn the Main Disconnect Switch to the “OFF” position.
3) Locate the Motor Access Door, insert the Manual Hand Crank
onto the motor shaft, and crank the elevator to the next lowest
level.
4) Use the Emergency Key to open the elevator door.
5) To exit the cab, open the landing door and assist the
passenger(s).

13 of 14
9. MAINTENANCE AND INSPECTION CHECKS
Regular maintenance keeps the Eclipse in proper operating condition.
Please remember, as the owner of this elevator, you are responsible
to ensure that maintenance and upkeep occurs on a consistent and
regular basis. To ensure the continual proper operating condition
of your unit, have a technician inspect the following items and, if
necessary, service the elevator every six months. The elevator may
require additional inspections, depending on usage.
1) Tighten all rail and cab fastening bolts.
2) Lubricate the door hinges and adjust the door closure, if
required.
3) Lubricate the rails with light grease, such as white lithium.
4) Inspect the travelling cable for wear. Replace if any cuts or
damage to the jacket are evident.
5) Replace the batteries inside the control panel as indicated on
the battery label.
To perform maintenance to the PORTA- Kwik-, or EMI-lock, (if equipped),
call your Authorized Savaria Dealer.

14 of 14
10. MAINTENANCE RECORD
Date Time Reason for Call Comments Dealer
We recommend that the Owner updates the Maintenance Record after each
service call.

Eclipse Residential Elevator
OWNER’S MANUAL
Part No. 000626
Copyright © 2007 - 2010
Savaria Corporation
Elevators and Lifts
www.savaria.com
Sales
2 Walker Drive
Brampton, Ontario, L6T 5E1, Canada
Tel: [phone]
Fax: [phone]
Toll free: 1-800-661-5112
