Savaria Infinity User manual

OWNER’S MANUAL
(To Be Retained by Owner After Installation
by Authorized Savaria Dealer)
Part No. 000784
10-m01-2011
Infinity & Infinity HD
Residential Elevators

2
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
IMPORTANT
Ensure that only an Authorized Savaria Dealer installs and services the Savaria™
Infinity & Infinity HD Residential Elevators. Under no circumstances is anyone
other than a dealer with Savaria training and authorization to install, adjust,
service or modify any mechanical or electrical device on this equipment. Failure
to follow this warning can result in safety system compromises or defeat; this
can result in serious injury or death. Savaria accepts no liability for property
damage, warranty claims or personal injury, including death, in this
circumstance.
Passenger safety is the result of countless details in the equipment’s design,
manufacture, and installation. After installation, reliable operation and
continual safe operation requires regular service and inspection at least twice
per year, or more frequently where usage, environment, or local jurisdiction
requires. As the Owner, you are responsible for ensuring that regular service
and inspections occur in a timely manner.
Refer to this manual for specifications, operating instructions and maintenance
of the Infinity & Infinity HD Residential Elevatorss.
Upon completion of installation, the dealer must provide you with the
following information and ensure it is recorded in this manual. In addition,
either the dealer or you must keep any service and/or maintenance records in
the Maintenance Record section of this manual.
WARRANTY
Ensure your Authorized Savaria Dealer provides you with a copy of the
manufacturer’s limited parts warranty and documentation relating to any
Dealer labour warranty.
-------------------------------------------------------------------------------------------------
FOR OWNER’S RECORDS
Customer Name: _________________________________________
Installing Dealer: _________________________________________
Dealer’s Telephone Number: _______________________________
Date Installed: ___________________________________________
Serial/Job Number: _______________________________________

3
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
Table of Contents
TO ENSURE SAFE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2. FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4. OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operating from the Landing Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operating from the Cab Operating Panel (COP) Controls . . . . . . . . . .10
5. POWER FAILURE AND EMERGENCY LOWERING . . . . . . . . . . . . . . . . . . . . . . . . . .11
6. EMERGENCY LIGHTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
7. MANUAL LOWERING DEVICE (MACHINE ROOM) . . . . . . . . . . . . . . . . . . . . . . . . .12
8. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Maintenance Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

4
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
TO ENSURE SAFE OPERATION
To ensure safe operation of this equipment, pay careful attention to the
important notes below.
• Read this manual carefully before using your Infinity or Infinity HD
Residential Elevator.
• To prevent accidents, adhere strictly to the instructions and keep clear
of moving parts at all times.
• Follow instructions on all equipment labels at all times. Replace any
damaged labels immediately.
• Ensure that only qualified personnel perform maintenance.

5
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
1. SPECIFICATIONS
Infinity/Infinity HD Specifications
Load capacity Infinity: 750 lb (341 kg) or 1000 lb (454 kg)
Infinity HD: 1400 lb (635 kg)
Rated speed 36 ft/min (0.18 m/s) nominal
Power supply 208 volt, three phase, 30 amps or
230 volt, single phase, 40 amps
Drive system 1:2 cable hydraulic
Cab sizes
Infinity Type 1L/R, 2, 3, 4 and 5:
• 36” x 48” (914 mm x 1219 mm)
• 36” x 54” (914 mm x 1372 mm)
• 36” x 60” (914 mm x 1524 mm)
• 40” x 54” (1016 mm x 1372 mm)
Infinity HD Type 1L/R, 2, 3, 4 and 5:
• 48” x 60” (1219 mm x 1524 mm)
Maximum travel 50 ft (15.24 m) or per local code
Maximum # of stops 6 stops
Pit depth required Infinity: 8” (203 mm) minimum
Infinity HD: 12” (305 mm) minimum
Minimum overhead
clearance
92” (2337 mm) for standard 80” cab; 96” (2438 mm) for 84” cab, 108”
(2743 mm) for 96” cab
Control system Constant pressure or automatic push button
Floor selection Magnetic selector
Flooring material Plywood (standard) or hardwood (optional)
Control panel finish Clear or bronze anodized aluminum (standard)
Stainless steel or brass (optional)
Hall station finish Clear or bronze anodized aluminum (standard)
Stainless steel or brass (optional)
Motor Infinity: 3 HP (2.24 kW)
Infinity HD: 5 HP (3.73 kW)
Cab panel finish Solid melamine or MDF panels (standard)
Unfinished oak veneer or raised solid hardwood (optional)
Lighting supply 115 volts, 60 Hz, 15 amps
Standard features
Automatic on/off cab lighting
“Car in use” illuminated hall call buttons
Digital floor indicator in cab
Emergency battery powered lowering and lighting with automatic
recharging
Emergency stop button in cab
Emergency alarm button in cab
Solid ceiling with four stainless steel pot lights
Vertical keyed stainless steel control panel

6
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
2. FEATURES
1 Cab Key Switch (Optional) (Figure 1-A)
The optional key switch turns the cab controls
ON and OFF. It is provided to limit the use of the
elevator to authorized persons only.
Figure 1: 2 Stop COP
A
B
C
D
E
2 Cab Operating Panel Buttons (Figure 1-B)
Automatic Control
Automatic control panel buttons facilitate the
UP/DOWN movement of the cab between
landings. Once the selected landing button is
pressed, the cab will automatically move to the
landing. The cab will stop when the selected
landing is reached.
Constant Pressure Control
Constant pressure control panel buttons
facilitate the UP/DOWN movement of the cab
between landings. The selected landing button
must be pressed and held until the cab moves
to the landing. The cab will stop when the
button is released or when the selected landing
is reached.
3 Door Open Button (Figure 1-C)
The elevator door/gate will close automatically
after a pre-set adjustable time of 8 seconds. This
button can be pressed to open the door/gate
when the cab is at a landing.
4 Alarm Button (Figure 1-D)
This button can be pressed at any time to sound
the alarm in case of an emergency.
5 Emergency Stop Button (Figure 1-E)
This button can be pressed at any time to stop
the cab and activate the alarm buzzer.
6 Handrail
A single handrail is mounted on the Cab Operating Panel side of the cab.

7
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
7 Landing Hall Call Station Controls (Figure 2) Figure 2: Hall Call
Hall Call buttons are installed at all landings to move
the cab to the landing from which it is being called. An
optional key switch limits the use of the elevator to
authorized persons only.
8 Landing Door and/or Gate Interlock
The Landing Door/Gate lock prevents the movement of
the cab unless the door/gate is in the closed and locked
position. If the door/gate is not completely closed, the
cab will not move.
9 Emergency Battery Operation
In the event of a building power failure, the door system is provided with a
temporary power back-up system to continue the opening operation for a
number of times. On resuming normal building power, the back-up system will
turn OFF and begin automatic recharging.

8
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
3. OPTIONS
Automatic Door Opener
1Press the Landing Hall Call button to call the elevator. The entrance door will
open automatically once the elevator stops at the landing.
2Press the Remote Control (if equipped) to open the entrance door once the
elevator stops at the landing.
3Push ’n’ Go allows the entrance door to open automatically with a slight
push to the door itself. The door timer is inoperative when this feature is
activated.
Automatic Gate Opener
1Press the Landing Hall Call button to call the elevator. The gate will open
automatically once the elevator stops at the landing and the entrance door
is fully open.
2Manually open the entrance door; the gate will open automatically once
the entrance door is fully open.
NOTE
If the cab is equipped with a gate, the gate must be closed after
exiting the cab. If the gate is left open, all controls will remain
inoperable.
An “entry” and “exit” timer allows approximately 9 seconds
before the Hall Call buttons become operational. This delay
allows time for a person to enter/exit the cab.

9
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
4. OPERATION
Operating from the Landing Controls
Automatic Operation
1If equipped with a key switch, insert the key into the key switch on the Hall
Call station and turn the key to the ON position.
2Press the Hall Call button once and release. The elevator will automatically
come to your landing.
3Turn the key (if equipped) to the OFF position and remove the key.
4If required, turn the door handle and pull the door open.
5If the cab has a manual gate, slide the gate open and enter the cab.
6Once inside the cab, close the gate, insert the key (if equipped) into the key
switch, and turn the key to the ON position.
NOTE
WARNING
When using the landing controls, the cab can only be moved
(called) to the level from which you are calling. When using the
control buttons in the cab, the cab can be moved to any level.
Wheelchair wheels must be locked at all times when
the elevator is moving.
Constant Pressure Operation
1If equipped with a key switch, insert the key into the key switch on the Hall
Call station and turn the key to the ON position.
2Press and hold the Hall Call button until the cab stops at your landing. To
stop the cab at any point simply release the Hall Call button.
3Turn the key (if equipped) to the OFF position and remove the key.
4If required, turn the door handle and pull the door open.
5If the cab has a manual gate, slide the gate open and enter the cab.
6Once inside the cab, close the gate, insert the key (if equipped) into the key
switch, and turn the key to the ON position.

10
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
Operating from the Cab Operating Panel (COP) Controls
Automatic Operation
1If equipped with a key switch, insert the key into the key switch on the Cab
Operating Panel and turn the key to the ON position.
2Press the selected Landing button once and release. The elevator will
automatically travel to and stop at the selected landing.
3Release the Landing button when the elevator arrives at the landing.
4Turn the key (if equipped) to the OFF position and remove the key.
5Unlock the wheelchair wheels (if applicable) and exit the cab.
Constant Pressure Operation
1If equipped with a key switch, insert the key into the key switch on the Cab
Operating Panel and turn the key to the ON position.
2Press and hold the selected Landing button to move the elevator. Maintain
constant pressure until the elevator automatically stops at the desired
landing. To stop the elevator at any point, simply release the Landing
button.
3Release the Landing button when the elevator arrives at the landing.
4Turn the key (if equipped) to the OFF position and remove the key.
5Unlock the wheelchair wheels (if applicable) and exit the cab.
NOTE
If the cab is equipped with a gate, the gate must be closed after
exiting the cab. If the gate is left open, all controls will remain
inoperable.
An “entry” and “exit” timer allows approximately 9 seconds
before the Hall Call buttons become operational. This delay
allows time for a person to enter/exit the cab.

11
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
5. POWER FAILURE AND EMERGENCY LOWERING
In the event of a power failure, the elevator is equipped with a Battery Back-Up
system that allows you to lower the elevator from the inside of the cab. This
device operates on batteries and is only activated if a main power supply failure
occurs. The operation is as follows:
1For elevators with automatic operation, press any Landing button below
the floor where the elevator is located.
2For elevators with constant pressure operation, press any Landing button
below the floor where the elevator is located and maintain constant
pressure until the cab is level with the lower landing.
3On arrival at the selected floor, the landing door will automatically unlock.
4If there is an automatic gate, the gate will open.
5Release the Landing button, remove the key, open the manual gate (if
equipped) and exit the cab.
6. EMERGENCY LIGHTING
In the event of a main power failure, the emergency cab light will turn on
automatically.

12
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
7. MANUAL LOWERING DEVICE (MACHINE ROOM)
In the event of a power failure, the cab can be moved to a lower level manually
by using the following procedure:
1Obtain the key to unlock the door to the machine room where the elevator
pump unit is located (if applicable).
2Instruct the passenger (s) in the elevator to remain calm and stay well back
from the door of the elevator. Ease their concern by telling them your
intentions.
3Switch the main disconnect switch for the main power supply to the
elevator pump unit to the “OFF” position.
4If equipped, use the owner’s key to
unlock the Controller Tank cover. The
EPV Valve is located inside.
Figure 3: EPV Valve
Manual release knob
(pull to lower cab)
5Locate the RED manual release knob
on the EPV Valve and pull the knob to
lower the cab (refer to Figure 3).
Maintain a constant pull on the knob
until the elevator reaches the lowest
landing and stops automatically.
(Although you may not be able to see
the elevator, this is readily detected,
as there will be no further noise as
the oil flows to the reservoir).
6To exit the cab, open the lower
landing door (using the special key)
and assist the passenger(s).
7After the passenger has exited the
cab, remove the cab key. Make sure the landing door is closed, reconnect
the disconnect switch in the machine room, and lock the door.

13
Part No. 000784, 10-m01-2011 Infinity & Infinity HD Owner’s Manual
8. MAINTENANCE
Regular maintenance (performed by your Authorized Savaria Dealer) will keep
your elevator in proper operating condition. Please remember, as the owner of
this elevator, you are responsible for making sure that maintenance and
upkeep are done on a regularly scheduled basis. To ensure proper operating
condition of your unit, the items listed below must be inspected and, if
necessary, serviced a minimum of twice per year. Additional inspections may
be required depending on usage.
1Tighten all rail and cab fastening bolts.
2Lubricate the door hinges and adjust the door closure if required.
3Lubricate the rails with light grease, such as white lithium.
4Inspect the travelling cable for wear. Replace the cable if any cuts or damage
to the jacket are evident.
5Check for any hose/pipe leaks. Replace and/or tighten the fittings to correct
any hydraulic leaks found.
6Check the fluid level of the pump reservoir (with the elevator at its lowest
landing), and fill as required. (Use Grade 32 Hydraulic Oil). There must be at
least 1” inch of oil on the dipstick.
7Tighten any hose connections or bleeder valves found loose. Check the
hydraulic cylinder (jack) for any leaks. If necessary, the packing seals may
have to be replaced.
8Replace the batteries inside the control panel as indicated on the battery
label.
9To perform the required maintenance to the door locks, contact your
Authorized Savaria Dealer.
10 Activate and test the safety mechanism.
WARNING
Under no circumstances should the pump controlsor
valve settings be adjusted except by an Authorized
Savaria Dealer.

14
Infinity & Infinity HD Owner’s Manual Part No. 000784, 10-m01-2011
Maintenance Record
Date Time Reason for Call Comments Dealer

Infinity & Infinity HD
Residential Elevators
OWNER’S MANUAL
Part No. 000784
Copyright © 2011
Savaria Corporation
Elevators and Lifts
www.savaria.com
Sales
107 Alfred Kuehne Blvd.
Brampton, Ontario, L6T 4K3, Canada
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-661-5112
