SC&T DKM01T User manual

DVI KVM with USB/RS232/Analog Audio CAT5e Extender
ITEM NO: DKM01 DVI & USB/RS232/Analog Audio CAT5e Extender
The DKM01 DVI & USB with Analog audio, RS232 CAT5e/6 extender design for extend all
signals over one CAT5e/6 up to 140 meters, transmitter unit with local DVI monitor output. It
provides superior video quality up to 1920x1200 resolutions, and using cost effective CAT5e
cable, instead of DVI, RS232 cables, for an easy, neater and reliable installation. It is
optimized for applications at industrial control, hospital, education, security and system
control over RS232 and USB.
Features:
Extend DVI, USB, RS232, and Audio signals over one CAT5e/CAT6 cable.
Transmission range up to 140M over CAT6, 120M over CAT5e.
DVI video resolution up to 1920 x 1200@ 60Hz.
HDCP 1.4 Compliant.
DKM01T transmitter unit built in DVI local loop output.
Support USB 2.0 and compatible with 1.1, 1.0
Built in Bi-directional analog audio extender function.
Support Bi-directional RS232.
Built in EDID copy.
Receiver unit with 4 ports USB 2.0 devices, to extend USB 2.0 peripheral devices, such as
flash drive, hard drive, mass storage device, keyboard, mouse, etc.
Optional model:
SR01 signal repeater for longer distance application.
IR-CR01: IR receiver cable.
Perfect for control remote machines and security monitoring systems, digital signage
application.
Installation View:
Optional Model: SR01 Signal Repeater (order separately)
Extend data signal for an additional 120meters.
Application for DKM01 signals for extra-long range transmission.
Ability to cascade connection with multiple SR01 for long range transmission
Built in LED status indication.
External power required.
Plug and play for easy installation.
Work with DKM01 CAT5e Extender:

2
Panel View:
DKM01T DKM01R
LED Indication Status:
Position
LED Color
Instruction
Front Panel
Green
Power on/off
Front Panel
Blue
Link on/off
RJ45
Green
RJ45 linking Indication
RJ45
Yellow
RJ45 Transmisison Indication (ACT)
Bottom Switch & Button:
DKM01T
SWITCH/BUTTON
FUNCTION
↑OFF
↓ON
1
Group
0
1
2
RS232
Default
Reserve
3
Default
Reserve
4
EDID Management
4 5
↑↑= Select Default 1080p EDID
↓↑= Select Receiver Monitor EDID
↑↓= Select Transmitter loop out Monitor EDID
↓↓= Reserve
5
6
Reserve
Default
Reserve
Button
Copy EDID
Based on SWITCH 4 & 5 setting to do EDID Copy
DKM01R
SWITCH/BUTTON
FUNCTION
↑OFF
↓ON
1
Group
0
1
2
RS232
Default
Reserve
Button 1
MENU
MAC, IP, Baudrate, Updated EDID
Button 2
Select
115200, 57600, 38400, 19200, 14400, 9600, 4800, 2400,
1200

3
Rotary Switch:
DKM01 built in rotary switch for pairing devices and the rotary switch can be used to switch
0-F channel pairing with group setting of switch 1. The channel number and group setting of
the transmitter and receiver must be same to be connected each other, total up to 32 (16 for
each group) pairs could be setup at one switch.
After setting the pairing and group, it must reset the power to make it work.
RJ45 Pin Define:
Link Cable (use TIA/EIA-568-B)
1. Orange-white Data 1 +
2. Orange Data 1 -
3. Green-white Data 2 +
4. Blue Data 3 +
5. Blue-white Data 3 -
6. Green Data 2 -
7. Brown-white Data 4 +
8. Brown Data 4 –
Cable:
Link cable recommend use high quality CAT5e,CAT6 UTP/STP/FTP cable. The max working distance is
140M (Max) over CAT6. Poor quality cable or network connection or improper construction will
cause unstable connection, video or sound disruptions, picture noise appears.
For longer distance application could be use model no: SR01 for extend longer distance or add a Gigabit
Switch.
RS232 Baud Rate Setting:
RS232 Default Baud rate is 115200bps. If need to change data rate, press menu button at the receiver
unit to select Baud rate menu, then press select button to select the data rate and press menu button
again to confirm and completed the Baud rate setting.
RS232 Define:
DB9 (M)/3.5mm STEREO PHONE JACK Cable (Optional Order)
DB9 F)/3.5mm STEREO PHONE JACK DB9 (M)/3.5mm STEREO PHONE JACK
RS232
3.5 mm Phone Jack
RS232
3.5 mm Phone Jack
Footprint
Define
Footprint
Define
Footprint
Define
Footprint
Define
Pin 2
TX
Pin 1
RX
Pin 2
RX
Pin 1
RX
Pin 3
RX
Pin 2
TX
Pin 3
TX
Pin 2
TX
Pin 5
GND
Pin 3
GND
Pin 5
GND
Pin 3
GND

4
Trouble Shooting:
1. DKM01 transmission data rate up to 850Mbps Max.
2. Do not recommend to connect general LAN to avoid large video data transmission slow down other
LAN devices. 。
3. Default transmitter EDID is 1080p, you could copy remote/loop out monitor EDID from TX.
4. RX analog audio input (MIC IN) is mono for microphone use only, not stereo audio (Line in)
5. RX USB port each max power output is 500mA, 4 port USB total output up to 1500mA.
Package Include:
DKM01T Transmitter x 1
DKM01R Receiver x 1
USB A to B cable x 1
DB9 male to 3.5mm phone jack cable x 1
DB9 female to 3.5mm phone jack cable x 1
DC 5V 2Amp power adapter x 2
Specification:
ITEM NO.
DKM01T
DKM01R
Support Resolution
Up to 1920 x1200@60Hz (Reduced Blanking)
Transmission Distance
CAT5e：120M / CAT6：140M (Max)
HDCP Compliant
HDCP 1.4
DVI Connector
DVI-I (only support Digital Signal) x2
DVI-I (only support Digital Signal) x2
USB Connector
USB 2.0 Type B x 1
USB Type A x 4
RS232 Connector
3.5mm Phone Jack x 1
3.5mm Phone Jack x 1
RS232 not support hardware handshake
Link Connector
RJ45 x 1
Analog Audio connector
Input: Line In, 3.5mm Stereo Phone
Jack
Output: 3.5mm Stereo Phone Jack
Input: Mic In, 3.5mm Mono Phone
Jack Output: 3.5mm
Stereo Phone Jack
Power Supply
DC 5V 2A
Power Consumption
1000mA (Max)
400mA (Max, No USB Device)
Temperature
Operation:-20 to 60℃, Storage: -20 TO 85℃, Humidity: up to 95%
Dimensions mm
125 x 140 x 30
Weight g
400
385
Rev.A
