SC&T VE02DALS User manual

Smart Cabling & Transmission Corp. V1.0
VGA Extender
User Manual
Model : VE02DALS
VGA & Stereo Audio/Digital Audio CAT5e Receiver with Skew
Corrector and Chainable output

1
User Manual
VE02DALS
Introduction
VE02DALS is a receiver unit for the VGA extender designed for long-distance transmission over a
cost-effective CAT5 and an audio cable and has a built-in RGB skew adjustment for the optimum video
performance under a long cable run.
Features
Extends and split a VGA into 2 ones.
Resolution up to 1920x1200@60Hz.
Signal extension up to 300M.
Must work with VE01PT, VE02T, VE05T, VE02ALT, or VE05ALT.
Support analog stereo audio.
Built in equalization, gain adjustment.
Built-in RGB skew adjustment for the optimum video performance under a long cable run.
Daisy chainable for another VE02DALS for working distance and multiple VGA displays.
Installation View

2
User Manual
VE02DALS
Panel View
VE02DALS
Adjustment
EQ:
Cable length EQ adjustment for picture sharpness, clockwise turning to
enhance signal, counter-clockwise to lower signal.
Gain:
Video signal gain adjustment for picture brightness, clockwise turning to
enhance signal, counter-clockwise to lower signal.
Skew Select ←→:
Press ←→2 buttons together to start the Skew adjustment mode. Under
skew adjustment mode, Press ←→2 buttons together again to switch the
color (RGB) you want to adjust.
Skew Select ←:
reduce delay time (color move to left side)
Skew Select →:
increase delay time (color move to right side)
Note
1. Under Skew adjustment mode without any setting in 30 seconds, it will be auto off skew
adjustment mode.
2. EQ, Gain, Skew adjustment also influence the picture quality of Loop Out.
LED Indication
Blue LED:
Power on/off
Vertical 3 x LED:
Under skew adjustment mode, to indicate the color you adjust
R = Red, G = Green, B = Blue.
Link Cable Connector
Green LED:
Audio signal lock (LED on)

3
User Manual
VE02DALS
Caution
The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, radio
equipment, high voltage lines.
Specification
ITEM NO.
VE02DALS
Support
Compliance
TTL
Max. Video Resolution
1920x1200@60Hz
Max. Transmission Distance
300M
Video Bandwidth
122MHz, -3dB
Audio Bandwidth
20 to 20KHz (-3dB)
Frequency
Horizontal at 30 to 95 KHz, Vertical at 50 to 180Hz
Skew Adjustment
0 to 62ns
Ports & Interfaces
Video Input
1 x RJ45
Video Output
1 x DB15 (75Ω, 0.7Vp-p)
Video Loop-out
Analog Audio Interface
1 x 3.5mm Stereo Phone Jack (10KΩ, 3Vp-p)
Digital Audio Interface
1 x Coaxial RCA (75Ω), 1 x Optical
Power
Power Supply
DC 5V 2A
Power Consumption
1A (Max)
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
125 x 95 x 30mm
Weight
285g
