SC&T TTP111HDP-LK User manual

Smart Cabling & Transmission Corp. V1.0
Twist Pair Passive
User Manual
Model : TTP111HDP-LK
HD-TVI/AHD/HDCVI/CVBS Video & Power Balun with Pigtail

1
User Manual
TTP111HDP-LK
Introduction
TTP111HDP-LK are video balun that can use a single cost-effective Ethernet cable to extend HD-TVI/ AHD/
HDCVI/ CVBS signal and power, with the transmission distance up to 300M and the resolution up to 4K
(8MP). The equipped power plug can also provide power from the local power supply for a remote CCTV
camera and the pigtail design allows you to have an easier, faster connection experience.
Besides, the balun has built-in ESD, EFT, and surge protection components, allowing the unit to have a
longer product lifespan.
Features
Resolution up to 4K (8MP)
Signal extension up to 300M over CAT5e (or greater) cable.
Built with DC jack for power transmission.
Male BNC to RJ45 connector with pigtail design.
Built-in ESD, EFT(impulse noise) and transient protection.
Installation View
Remote Power by DC24V/AC24V, please use our model no: PC500/PC1A power converter (AC to DC
for regulated DC12V ) at camera side to send regulated DC12V for camera use.
Transmission Distance
Video Transmission Distance
HD-TVI
AHD
HDCVI
CVBS
1080P 250M
5MP 200M
1080P 250M 4MP
200M
1080P 300M
4K 200M
400M
The distance may effected by the quality of cable, camera, DVR. This installation should be made by a
qualified service person and should conform to all local codes.

2
User Manual
TTP111HDP-LK
Power Transmission Distance
Voltage Drop According to Cable Length (24AWG)
Voltage
DC12V
Distance
50M
100M
300M
Camera Power Consumption
2 PAIRS
2PAIR
2 PAIR
50mA
11.8
11.5
10.8
100mA
11.5
10.9
9.6
150mA
11.2
10.4
8.4
200mA
11
9.9
7.2
250mA
10.7
9.4
5.9
300mA
10.4
8.9
4.7
350mA
10.2
8.4
3.5
400mA
9.9
7.9
2.3
450mA
9.6
7.5
1.1
500mA
9.3
7
1.2
1A
6.8
2.7
X
1.5A
4.1
X
X
Panel View
Front Rear
Recommend Cable
Use high quality CAT5e UTP or CAT6 UTP cable. The max working distance is 300M for AHD, CVI camera,
HD-TVI maximum distance is 250M. The distance may effected by the quality of cable, camera, DVR.
Caution
1. The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, mobile
phone, radio equipment, high voltage power cable.
2. Remote Power by DC24V/AC24V, please use our model no: PC500/PC1A power converter (AC to DC
for regulated DC12V) at camera side to send regulated DC12V for camera use.
Voltage
DC24V
Distance
50M
100M
300M
Camera Power Consumption
2 PAIR
2 PAIR
2 PAIR
50mA
23.6
23.3
22.8
100mA
23.3
22.7
21.6
150mA
23
22.3
20.4
200mA
22.8
21.8
19.1
250mA
22.5
21.3
17.9
300mA
22.2
20.8
16.7
350mA
21.9
20.3
15.5
400mA
21.7
19.8
14.2
450mA
21.4
19.4
13
500mA
21.1
18.9
11.8
1Amp
18.7
14.7
0.8
1.5Amp
16.1
10
X
RJ-45 Jack Pin Define

3
User Manual
TTP111HDP-LK
Specification
ITEM NO.
TTP111HDP-L
TTP111HDPJ-L
Support
Max. Video Resolution
8MP (4K)
Max. Transmission Distance
HD-TVI 100M at 1080p
AHD 150M at 8MP
HDCVI 100M at 8MP
CVBS 300M (NTSC/ PAL)
Signal Bandwidth
50Hz to 60MHz ( -3dB )
Ports & Interfaces
Video Input/ Output
1 x BNC (1 Vp-p, 75 Ohm)
Link Interface
1 x RJ45 (100 Ohm)
Power Interface
1 x DC Plug (ø2.1 x 5.5mm)
1 x DC Jack
Protection
ESD Protection
30kV(Air), 15kV (Contact), IEC 61000-4-2
EFT Protection
40A(5/50ns), IEC 61000-4-4
Lightning Protection
2A (8/20μs), IEC 61000-4-5
Response Time
< 1 ns
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
52.6 x 25 x 20.7mm & 120mm pigtail cable
Weight
45g
