Schenker MODULAR 60 User manual

COD: 60M12/24.A.2018
Installation, use and maintenance manual
Model.: Modular 60
Matriculation number: 60M12/24A
Year of construction: 2000
Schenker Italia
Via Delle Repubbliche Marinare, 67
80147 Naples Italy
Tel. [phone]
Fax. [phone]
E-mail: i[email protected]t
WWW.schenkerwatermakers.com
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
MODULAR 60
Analogic 12/24 V dc

COD: 60M12/24.A.2018
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
INDEX
1. MANUAL CONSULTING ...................................................................................................................................4
1.1 STRUCTURE OF THE MANUAL ............................................................................................................................4
1.2 DESCRIPTION OF THE PICTOGRAMS.................................................................................................................4
2. GENERAL WARNINGS AND INFORMATION TO THE RECIPIENT .....................................................5
2.1 IMPORTANT INFORMATION ................................................................................................................................5
2.2 SAFETY WARNINGS ............................................................................................................................................5
2.3 START-UP...........................................................................................................................................................6
2.4 WARRANTY..........................................................................................................................................................6
2.5 IDENTIFICATION OF THE UNIT ..........................................................................................................................7
2.6 NORMATIVE REQUIREMENTS .............................................................................................................................7
2.6.1 DIRECTIVES AND STANDARDS CONCERNING MACHINE SAFETY.................................................................7
2.6.2 RESPECT FOR THE ENVIRONMENT –REQUIREMENTS FOR DEMOLITION AND DISPOSAL .........................7
3. PRODUCT PRESENTATION ............................................................................................................................9
3.1 TRANSPORT AND MATERIAL HANDLING ...........................................................................................................9
3.2 STOCK ...............................................................................................................................................................10
3.3 PACKAGING.......................................................................................................................................................10
3.3.1 PACKAGING CONTENTS.................................................................................................................................10
3.4 ATTACHED DOCUMENTS ..................................................................................................................................11
3.5 TECHNICAL DATA .............................................................................................................................................11
3.6 CHARACTERISTIC OF THE PRODUCT...............................................................................................................12
3.7 ADVANTAGES OF THE ENERGY RECOVERY SYSTEM ......................................................................................13
3.8 COMPOSITION OF THE MACHINE ....................................................................................................................14
3.8.1 PUMP GROUP ..................................................................................................................................................14
3.8.2 WATERMAKER GROUP....................................................................................................................................15
3.8.3 ACCESSORIES ................................................................................................................................................18
4. MOUNTING AND INSTALLATION...............................................................................................................19
4.1 GENERAL CRITERIA ..........................................................................................................................................19
4.2 COMPONENTS MOUNTINGS .............................................................................................................................20
4.2.1 PUMP GROUP..................................................................................................................................................20
4.2.2 WATERMAKER GROUP ...................................................................................................................................20
4.2.3 ACCESSORIES................................................................................................................................................20
4.3 INSTALLATION ..................................................................................................................................................20
4.3.1 WATER INTAKES AND DISCHARGES ............................................................................................................20
4.3.2 SEAWATER INTAKE........................................................................................................................................21
4.3.3 FRESH WATER INTAKE FOR WASHING.........................................................................................................22
4.3.4 BRINE DISCHARGE ........................................................................................................................................22
4.4 HYDRAULIC CONNECTIONS .............................................................................................................................23
4.5 ELECTRIC CONNECTION...................................................................................................................................26
4.5.1 REMOTE CONTROL PANEL MOUNTING .........................................................................................................26
4.5.2 ELECTRIC CONNECTIONS:WIRES (MODULAR 60 12/24V DC).............................................................27
4.5.3 ELECTRIC LAYOUT SCHEME (12/24V DC)................................................................................................29
5. FUNCTIONING AND USE..............................................................................................................................31
5.1 COMMAND DESCRIPTION.................................................................................................................................31
5.2 INTRODUCTION –BY PASS MODE...................................................................................................................32
5.3 FIRST START UP PROCEDURE ..........................................................................................................................32
5.3.1 MANUAL MODE ACTIVATION THROUGH THE BYPASS SELECTOR SWITCH ................................................33

COD: 60M12/24.A.2018
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
5.3.2 PRELIMINARY CHECKS BEFORE PROCEEDING WITH THE STARTUP PROCEDURE .....................................33
5.3.3 START UP .......................................................................................................................................................34
5.4 NORMAL OPERATING PROCEDURE ..................................................................................................................36
5.4.1 NORMAL OPERATING PROCEDURE WITH AUTOMATIC WASHING ON (ADVISABLE PROCEDURE)...........37
5.4.2 NORMAL OPERATING PROCEDURE WITH AUTOMATIC WASHING OFF (NOT ADVISABLE PROCEDURE)..37
5.5 MANUAL WASHING PROCEDURE .....................................................................................................................38
5.6 RESET PROCEDURE ..........................................................................................................................................39
6. MAINTENANCE (ROUTINE AND EXTRAORDINARY) ...........................................................................41
6.1 CONTROL OF FILTER CLEANING CONDITION .................................................................................................41
6.2 CHECK THE PLANT WORKING PRESSURE .......................................................................................................42
6.3 CHECK FOR ABSENCE OF LEAKS .....................................................................................................................42
6.4 CHECK FOR MEMBRANES REPLACEMENT ........................................................................................................42
6.5 SHUTDOWN PROCEDURE .................................................................................................................................42
6.5.1 NECESSARY EQUIPMENT ..............................................................................................................................43
6.5.2 SHUTDOWN OPERATING PROCEDURE..........................................................................................................44
6.6 ANTIFREEZE PROCEDURE (WINTERIZING PROCEDURE IN COLD CLIMATE -UNDER 5°C).......................47
6.7 PERIODIC MAINTENANCE.................................................................................................................................48
6.7.1MEMBRANE REPLACEMENT............................................................................................................................48
6.8 ADJUSTMENTS ..................................................................................................................................................48
7. TROUBLESHOOTING......................................................................................................................................49
7.1 FAILURE CHART ................................................................................................................................................49
7.2 ELECTRONIC ISSUES AND THEIR SOLUTION..................................................................................................50
8. SUGGESTED SPARE PARTS.........................................................................................................................51
8.1 SHORT TERM CRUISING...................................................................................................................................51
8.2 LONG TERM CRUISING .....................................................................................................................................51
8.3 ERS SPARE PARTS ...........................................................................................................................................52
8.4 ADDITIONAL SPARES .......................................................................................................................................53

1 –MANUAL CONSULTING COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
4
1. MANUAL CONSULTING
1.1 Structure of the manual
The manual is divided into chapters, which gather all the information necessary to use the system without any
risk.
Within each chapter there is a subdivision in paragraphs to focus on essential points; each paragraph can be
pointed out with a subtitle and a description.
At the top of each page the heading section is reported in order to remind the reader the field of the page.
Within the chapter, for example chapter 1, we will have:
1 Chapter title
1.1 Paragraph title
1.1.1 Subtitle
1.1.1.1 Further subtitles
The numbering of the pages, figures and tables, is reset to each chapter; therefore, we will find the prefix
indicating the chapter and the page number, figure or table in progressive that starts from number 1 at the
beginning of each chapter.
1.2 Description of the pictograms
The following symbols will be used in the manual to highlight particularly important indications and warnings:
ATTENTION:
This symbol indicates accident prevention regulations for the operator and / or for any exposed
persons.
CAUTION:
This symbol indicates that there is the possibility of damaging the system and / or its components.
NOTE:
This symbol indicates useful information.

2 - GENERAL WARNINGS & INFORMATION TO THE RECIPIENT COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
5
2. GENERAL WARNINGS AND INFORMATION TO THE RECIPIENT
2.1 Important information
To safeguard the operator's safety and to avoid possible damage to the machine, before carrying out any
operation on the machine, it is essential to read carefully all the instructions manual.
This manual must be complete and legible in its entirety, every operator involved in the use of the machine, or
responsible for maintenance or adjustment operations, must know its location and must have the possibility to
consult it at any time.
All rights of reproduction of this manual are reserved to SCHENKER ITALIA. This manual cannot be transferred
to third parties without the written authorization of SCHENKER ITALIA.
The text cannot be used in other printed matter without the written permission of SCHENKER ITALIA.
The descriptions and illustrations provided in this publication are not binding.
SCHENKER ITALIA reserves the right to make any modifications it deems appropriate.
© SCHENKER ITALIA
THIS MANUAL IS PROPERTY OF SCHENKER ITALIA, ANY REPRODUCTION, EVEN PARTIAL, IS
PROHIBITED.
This manual was drafted according to the requirements of the 2006/42 / EC Machinery Directive.
2.2 Safety warnings
•Wear protective equipment suitable for service operation.
•Clothing must be tight to the body, and resistant to the products used for cleaning.
•Do not remove safety devices or accident prevention protections.
•Check if the plant is correctly installed eventually contacting a Schenker service point.
•Verify that the electric and hydraulic connections are in keeping with the indicated specifications.
•The water produced by a Schenker plant, starting from picking clean seawater, is potentially potable, but
the drinkable cannot be guaranteed because a bacterium may be present in some points of the plant,
especially in case of non-observance of shutdown and cleaning procedures. So, avoid drinking the water
produced by the plant if a sterilizer system has not been installed.
•Avoid using the plant if the sea water is polluted.
•Children and inexperienced people shall not touch or operate the plant.
•Check periodically that no leakage is present. Avoid installing the plant where an eventual leakage may
cause damages and jeopardize the safety.
•Unqualified and non-Schenker personnel shall not perform any maintenance work.

2 - GENERAL WARNINGS & INFORMATION TO THE RECIPIENT COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
6
ATTENTION
Any technical changes or operating conditions indicated that affect the correct operation or
safety of the machine must only be carried out by the manufacturer's technical staff or by
technicians formally authorized by the manufacturer. Otherwise, SCHENKER ITALIA declines
any responsibility for changes or damages that may result from it.
2.3 Start-Up
The system MODULAR 60 test and validation takes place at the end of the assembly at Schenker Italia
production site.
2.4 Warranty
The equipment and the relevant accessories are guaranteed 12 months from delivery. The guaran-tee does
not include consumable items (filters, carbon filters, membranes, etc.). The “ERS” pressure amplification
device is guaranteed 36 months, provided that the annual maintenance is per-formed at a Schenker service
point.
The guarantee covers faults, defect of materials and parts. It is limited to the replacement or re-pair of faulty
parts. The expense for the disconnecting and reinstalling on the vessel and transport of the equipment from or
to our Service Point, or our factory will be at the customers own expense.
The under guarantee delivered parts transport, will be at customer’s own risk.
In case of repairs under guarantee performed by our technicians on the customer vessel, the faulty parts
replacement cost will be at Schenker's expense, while manpower and travel expenses will be charged to the
customer. The guarantee does not include faults caused by negligence in operating, maintenance and
installation of the device (if not carried out by an authorised Schenker Service point).
Dismantling by non-authorized personnel will render void all guarantees. Schenker Italia cannot be held liable
for any direct or indirect damage caused by the malfunctioning equipment, limiting its responsibility to the repair
and replacement of faulty parts.
ATTENTION
SCHENKER ITALIA declines any responsibility for improper use of the machine, for damages
caused as a result of operations not covered by this manual or unreasonable use.

2 - GENERAL WARNINGS & INFORMATION TO THE RECIPIENT COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
7
2.5 Identification of the unit
All the watermakers manufactured by Schenker Italia can be identified trough a serial number printed on a
laberl which is pasted upon the aluminum frame near the manometer. The same serial number is also recorded
on the central black block of the energy recovery system (ERS).
Serial number
Fig. 2-1
2.6 Normative requirements
2.6.1 Directives and standards concerning machine safety
•Machinery Directive 2006/42 / EC, in force since December 29, 2009;
•Low Voltage Directive 73/23 / EEC and subsequent amendments and additions: 93/68 / CEE
implemented by the Law of 18 October 1997 n. 791.
•Electromagnetic Compatibility Directive 89/336 / EEC and subsequent amendments and additions:
93/31 / CEE implemented with D.L. December 4, 1992 n. 476.
•Standards UNI EN 292/1 and 292/2 (safety of machinery);
2.6.2 Respect for the environment –requirements for demolition and disposal
ATTENTION
Evacuate and dispose of materials, as result of the demolition of the machine, must be
performed in accordance with the regulations in force, for the safeguard and protection of the
environment.
With regard to demolition and disposal, it should be noted that the materials of which the machine is made of
are not of a dangerous nature and consist essentially of:
- Stainless Steel;
- Aluminium;
- Plastic;
- Carbon fibre;
- Motors, cables and consumable electrical materials;
- Rubber and polyurethane seals;

2 - GENERAL WARNINGS & INFORMATION TO THE RECIPIENT COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
8
After dismantling the machine, the various materials must be segregated according to the regulations of the
country in which the machine has been removed.
The machine does not contain dangerous components or substances that require special removal procedures.
ATTENTION
Different legislations are in force in the different countries, therefore the prescriptions imposed
by the laws and by the agencies designated by the Countries must be observed.

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
9
3. PRODUCT PRESENTATION
ATTENTION
Be sure to follow general safety instructions.
•Wear protective equipment suitable for the transport and handling operations.
•Lift the machines with equipment appropriate to the weight and size of the box, taking the utmost care
and following carefully the instructions on the present use and maintenance manual (attachment points
for loading devices, etc.).
•Make sure that the lifting equipment used is in good condition and correctly maintained.
•Do not stand or pass under the groups to be moved during lifting or transport operation.
3.1 Transport and material handling
The watermaker unit is transported in a carton box. In the following table dimension and weight are indicated.
MATERIALS HANDLING
fig. 3-1
Packaging dimensions and weight
tab.3-1
Model
L cm.
W cm.
H cm.
Weight Kg.
Manual
120
47
47
52
Electron
120
47
47
52

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
10
3.2 Stock
ATTENTION
To avoid undesirable damages to the system be aware to stock the unit in a dry place with
temperature between 5 and 40 °C. Coldest temperature could led to a freeze of the fluid inside
the system with the consequence of a permanent fault of the system.
3.3 Packaging
3.3.1 Packaging contents
PACKAGING
FIG. 3-2
Modular 60
Watermaker
Pump group
Active carbon filter with electrovalve
White filter key
Net filter
Non-return valve with Tee fitting
Remote panel with electric box
10 mt extension cable for remote panel
Intallation kit
Small metal goods
6x8 hose for production
Pipe fittings

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
11
3.4 Attached documents
The packaging contains the technical documentation (use and maintenance manual, electric and hydraulic
scheme, warnings and instructions).
ATTENTION
•Lift the system only using the aluminium
structure and not trough the Inox SS fittings.
•Read carefully the use and maintenance
manual before installing the system.
•Use only recommended material for the
installation (especially pipes, fittings and
seals) in accordance with the present
manual.
•Do not stock the unit under temperature of
5°.
DOCUMENTS INCLUDED IN THE PACKAGING
FIG. 3-3
3.5 Technical data
NOTE:
The following technical data refers to the watermaker Modular 60 12/24V Analog version
WATERMAKER GROUP
Dimensions
Length: 67 cm
Width: 30 cm
Hight: 30 cm
Weight: 28 Kg
Hydraulic Connection
Seawater inlet: ¾’’ fitting, 16mm internal diameter rinforced hose.
Exhaust: ½’’ fitting, 16mm internal diameter rinforced hose.
Fresh water: ¼’’ fitting, 6x8mm hose.
PUMP GROUP
Dimensions
Length: 34 cm
Width: 19 cm
Hight: 35 cm
Weight: 10 Kg

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
12
Hydraulic Connection
Water inlet: ¾’’ fitting, 16mm internal diameter rinforced hose.
Water outlet: ¾’’ fitting, 16mm internal diameter rinforced hose.
Feed pump type: Shurflo diaphragm pump
Filters: n. 1 Cartridge filter 5 microns 2.32" x 9 ¾’’
n. 1 Active carbon filter 2.32" x 9 ¾’’
Power supply: 12 VDC +/- 15% (60M12 version)
. 24 VDC +/- 15% (60M24 version)
Average electric consumption: 250 Watt/h average
Peak electric consumption: 400 Watt
Nominal fresh water production: 60 Lit/h +/- 20% @ seawater 25 °C salinity 35.000 ppm
Fresh water quality: Under 500 ppm TDS average
CEE conformity: In compliance with directives 89/392 CEE sect.1 (general safety machines
requirements), 89/336 CEE (electromagnetic compatibility), 73/23 CEE
(electric safety requirements)
3.6 Characteristic of the product
The machine uses sea water to produce fresh water.
The water produced by the Schenker plant, starting from clean sea water, is potentially drinkable. The requisite
of potable water cannot be guaranteed, however, because in some parts of the system there may be a bacterial
charge, especially in the event of non-observance of the cleaning and storage procedures. Therefore, it is
suggested to avoid drinking the fresh water produced by the plant, if a UV sterilizer is not installed.
ATTENTION
Do not drink fresh water produced by the watermaker if a UV sterilizer system is not installed.

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
13
3.7 Advantages of the Energy recovery system
Introduction
Thank you for choosing a Schenker Watermaker.
As all the equipment, the knowledge of operating and maintenance procedures allows to use the system in the
best way, and to guarantee a perfect functioning throughout the years. We invite you to read carefully this
manual and to keep it for a quick reference.
Functioning principles
The Schenker watermakers, as alternative to the high-pressure pumps of traditional systems, utilizes the
ENERGY RECOVERY SYSTEM patented device, which amplifies the pressure of common low-pressure
pumps, and recoup all the hydraulic energy back from the membranes, allowing an high energy efficiency.
The lack of high-pressure pumps makes the system silent and vibrations free, and enormously simplify the
use because no adjustment is necessary for its operating.
FUNCTIONING SCHEME
FIG. 3-4

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
14
3.8 Composition of the machine
The machine is composed by the following parts:
1. PUMP GROUP
2. WATERMAKER GROUP
3.8.1 Pump group
This pump has the duty of picking the sea water up and send it to the watermaker group, through the pre filter.
The pump group is composed by the following components:
•5 micron cartridge filter
•Diaphragm pump
•High pressure switch
•Pump box
•Pulsation dampener
PUMP GROUP AND FILTER 12-24 V DC
FIG. 3-5
5 micron cartridge filter
Pump box with relays
Diaphragm pump
High pressure switch

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
15
3.8.2 Watermaker group
WATERMAKER GROUP
FIG. 3-6
Manometer
Reverse osmosis membranes
Flowmeter
Electric connection box
WATERMAKER GROUP (LATERAL VIEW)
FIG. 3-7
Reset valve
Remote panel IN
Depressurization valve
Positioner knob
Fresh water discharge
7

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
16
WATERMAKER GROUP (BACK VIEW)
FIG. 3-8
Microcomputer
Signal pressure switch
CONCENTRATE OUTLET (OUT) AND SEAWATER INLET (IN)
FIG. 3-9
The watermaker group is composed by the following components:
•Reverse osmosis membranes
•Energy Recovery System
•Manometer
•Flowmeter
•Depressurization valve
•Positioner
•Reset valve
•Probe (pressure switch)
•Electric box
Reverse osmosis membranes, are installed inside the glass fibre high-pressure housing. Membranes are
n.3 x SW2521 type. Their purpose is to separate the intake high-pressure seawater in two flows: one for the
salt-water drain and one for the fresh water production.

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
17
Energy Recovery System It is the black, carbon fibre unit. It has the function to amplify the pressure supplied
by the pumps and to recoup the hydraulic energy back from the membranes. The ERS device makes periodic
cycling by a hydraulically controlled automatic valve. The cycles are noticeable through a ”beat” issued
periodically by the watermaker unit. The unit is based on cylinders and a central body containing the hydraulic
valve necessary for the system functioning.
Manometers. It is located on the front panel of the watermaker, and it measures the working pressure of the
watermaker.
Flowmeter. It is located on the front panel, and it measures the fresh water instantaneous capacity sent to the
tank. The device accuracy is +/- 20%.
Pulsation dampener is a black plastic cylinder, installed in the watermaker. Its function is to reduce and
stabilize the pressure peaks during the watermaker functioning. The device has to be pre-charged with air
through the specific valve. The air pressure precharge is about 4 Bar. The pressure dimmer is charged in
factory at the right pressure.
Depressurization valve. It is used for the air bleeding of the unit. It is recognizable by a blue lever and it is
located on the right fitting of the third membrane. Its function is to depressurize the system and to allow the
bleeding of air. The valve must be closed during normal working conditions (vertical position), and it is opened
during the air bleeding operations (horizontal position).
Positioner. It is a stainless steel threaded arm, with a black knob, located on the right side of the watermaker.
Its function is to reset the unit in case of hydraulic block.
Reset valve. It is installed next to the watermaker right front corner and it is recognizable by the little blue
plastic lever. The valve must be closed during normal functioning (lever perpendicular to the valve). Such valve
has the function to allow the reset of the ERS in case of a system block. It must be opened before acting on
the valve positioner.
High pressure switch. It Is hydraulically connected with the pump group. It stops the system if the pump
pressure exceeds 9,5 bar. In this case a high-pressure alarm is activated on the control panel.
Probe (pressure switch). It is a device, hydraulically connected to the left side on the main valve of the Energy
Recovery System. Its function is check that the cycling of the machine is correct. It is set at 2 bar.
Electric box. It contains all the electric and electronic devices necessary for the functioning of the system and
the protection of the components.
It is connected to a remote control panel that allow to control the whole function of the watermaker.

3 –PRODUCT PRESENTATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
18
3.8.3 Accessories
The main accessories of the watermaker are the followings:
•Active carbon filter
•Electrovalve
•Non-return valve
•Net filter (strainer)
ACCESSORIES
FIG. 3-10
Non-return valve
Active carbon filter
Net filter (strainer)
Elettrovalve
Active carbon filter. This filter is connected between the fresh water pressurized system of the boat and the
electro valve on the filter holder. On the filter inlet is positioned a manual valve that allows to replace the
cartridge without depressurize the fresh water system of the boat.
Electrovalve. It has the function of switching from seawater intake to fresh water tank when washing the
watermaker.
Non-return valve. It avoids the emptying of the inlet pipes. It must be installed horizontally. It avoids also the
leak of fresh water from the seacock while washing procedure.
Net filter: The machine is equipped with a strainer to protect the pump from macro sediments. It is placed
between the seacock and pre-pump.

4 –MOUNTING AND INSTALLATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
19
4. MOUNTING AND INSTALLATION
4.1 General criteria
Before starting with the installation, it is important to carefully plan all the activities, by evaluating all the possible
solution to be adopted. The main points to focus on are the following:
•Individuate the seawater inlet
•Positioning of the main units (pump group, watermaker group, active carbon filter).
•Positioning of the magnetothermic switch.
•Passage of the pipes and electric cables.
CAUTION
For a correct installation of the watermaker, in order to avoid issues along the different ways
of operating condition, please follow carefully the general instruction below:
•Consider to install the through-hull fitting in a central and deep position, in the way that no air
could be aspirated.
•The non-return valve has to be installed under the seawater level and as close as possible to
the through-hull fitting, in vertical position.
•The pump must be installed as low as possible respect to the seawater level and as close as
possible to the seawater intake (through-hull fitting).
•The watermaker unit must be horizontally positioned, and arranged on an adequate support
which is able to sustain the weight (about 50 Kg).
•Provide to leave a space of about 20cm on the left side of the watermaker unit in order to allow
the passage of inlet and outlet (discharge) pipes.
CAUTION
The pump group must be installed in a ventilated place, in order to facilitate the cooling. In
addition to this, a place not exposed to condensation and dripping should be adopted.
ATTENTION
The external surface of motor and pump can reach high temperature; therefore, it is
recommended to avoid any contact with inflammable liquids and materials.
NOTE
Once individuate the correct installation solution, it is recommended to first make a schematic
draft of the hydraulic and electric connection, and attach them to the present manual for future
needs as first reference.

4 –MOUNTING AND INSTALLATION COD.60M12/24.A.2018
EN
THE PRESENT MANUAL BELONGS TO - Schenker Italia -ALL RIGHTS RESERVED
20
4.2 Components mountings
4.2.1 Pump group
The diaphragm pumps are a self-priming type, so the pump group may be installed relatively above the
seawater level. Anyway, it is suggested to install the pump group as low as possible respect to the seawater
level and as close as possible to the water inlet; furthermore, the pump cannot run dry. Therefore, it is very
important avoiding to start the system if the intake valve is closed or if inlet filters are clogged.
The pump group should be installed in an adequately ventilated room, with the purpose to facilitate the cooling
of the motor, and not subject to condenses or drippings. The max permitted room temperature must not
exceed 45°C.
Avoid the contact or the proximity with inflammable material or liquid, since the motor surfaces can reach
elevated temperatures. Avoid locating the pump wherever a possible loss of water can involve damages or
jeopardize its safety. The pump must be installed on a base sufficiently horizontal, suitable to sustain the
weight of the group. The pump is normally fixed on the support structure by passing bolts.
4.2.2 Watermaker group
Concerning the watermaker unit installation there are not height limits respect to the seawater level. Anyway,
it should be installed above both pumps.
Avoid to install the system wherever any possible leak may cause damages to the boat or jeopardize its safety,
since possible leaks due to accidental causes (pipe bursting, hose clamp loosening, equipment failure, etc.)
may cause water losses.
The hydraulic intake and outlet connections are positioned on the left of the unit. Therefore, it is necessary to
foresee a minimum distance of 20 cm. to allow the pipes laying. The watermaker unit must be installed on a
base sufficiently horizontal, suitable to sustain the weight of the group. The max allowed room temperature
must not exceed 40°C. It is advisable to install the unit in such position to make the instrumentation easily
visible, and make the valves (located on the right of the unit) easily accessible. The watermaker is normally
fixed on the support structure by passing bolts.
4.2.3 Accessories
The non-return valve has to be installed vertically as close as possible to the seawater intake, following the
direction of the arrow.
The active carbon filter (and the attached electrovalve) has to be placed next to the pump group, if possible,
on a vertical side easily accessible.
4.3 Installation
4.3.1 Water intakes and discharges
For a correct installation of the watermaker it is necessary to arrange the following water intake and discharge
out of the board:
•Seawater intake.
•Fresh water intake for washing.
•Brine disharge.
