Schiller BR-102 PLUS User manual

User Guide
Art. no.: 2.511076 Rev.: g *2.511076*
24/48 Hour Ambulatory Blood Pressure Recorder
BR-102 PLUS
BR-102 PLUS PWA

Address Headquarters
SCHILLER AG Tel: [phone]
Altgasse 68 Fax: [phone]
CH-6341 Baar [email protected]
Switzerland www.schiller.ch
Sales and Service Information
The SCHILLER sales and service centre network is world-wide. For the
address of your local distributor, contact your nearest SCHILLER
subsidiary. In case of difficulty a complete list of all distributors and
subsidiaries is provided on our internet site:
www.schiller.ch
Sales information can also be obtained from:
[email protected]h
BR-102 plus / BR-102 plus PWA bears the CE-0123 mark (Notified Body TÜV-SÜD Produkte Ser-
vice GmbH, Ridlerstr. 65, 80339 Munich, Germany), indicating its compliance with the essential re-
quirements of the Annex I of the Medical Device Directive 93/42/EE regarding safety, functionality
and labelling. The requirements apply to patients, users and third persons who come into contact
with this device within the scope of its intended use.
Article no: 2.511076 Rev.: g
Issue date: 13.12.21
Corresponds to: Original

Page 3
User Guide
Art. no.: 2.511076 Rev.: g
BR-102 plus / BR-102 plus PWA
Contents
1 Safety Notes .............................................. 7
1.1 User Profile................................................................... 7
1.2 Intended Use................................................................. 7
1.3 Contraindications......................................................... 8
1.4 Responsibility of the User........................................... 8
1.5 Organisational Measures ............................................ 8
1.6 Maintenance ................................................................. 9
1.7 Hygiene ......................................................................... 9
1.8 Safety Conscious Operation....................................... 9
1.9 Safety Facilities............................................................ 9
1.10 Operation with other Devices ................................... 10
1.11 Safety Symbols and Pictograms .............................. 11
1.11.1 Symbols used in this Document ........................................... 11
1.11.2 Symbols on the Device, Batteries, and Accessories ............ 11
2 Introduction ............................................ 13
2.1 BR-102 plus / BR-102 plus PWA ............................... 14
2.1.1 BR-102plus........................................................................... 14
2.1.2 BR-102 plus PWA................................................................. 14
2.2 The medilog®DARWIN2 Program ............................. 15
2.3 Inserting/Changing the Batteries.............................. 15
2.4 Connecting the Pressure Hose and Microphone.... 16
2.5 Main Components of the Device............................... 17
2.5.1 Operating and Display Elements .......................................... 18
2.5.2 Switching on ......................................................................... 18
2.5.3 Switching Off ........................................................................ 19
2.5.4 Battery Status for NiMH Rechargeable Batteries ................. 20
2.5.5 Battery Display for Energizer Ultimate Lithium Battery......... 21
2.5.6 Time Display......................................................................... 21
2.6 Menu Structure........................................................... 22
2.6.1 Menu Overview..................................................................... 23
3 BP recording ........................................... 26
3.1 Safety .......................................................................... 26
3.2 Applying the Cuff ....................................................... 28
3.2.1 Cuff Type with D-ring............................................................ 30
3.2.2 Cuff Type without D-ring....................................................... 30
3.2.3 Patient Comfort Sleeve......................................................... 31
3.2.4 Fixing the Microphone Directly on the Upper Arm................ 31
3.2.5 Securing the Cuff with the Fixation Pad ............................... 32
3.3 Single Measurement .................................................. 33
3.4 Long Term Recording................................................ 34
3.4.1 RECORD SETUP ................................................................. 35

Page 4
Art. no.: 2.511076 Rev.: g
BR-102 plus / BR-102 plus PWA
3.4.2 Program ................................................................................ 35
3.4.3 Starting a Recording ............................................................. 36
3.4.4 Changing the Batteries During a 48 Hr Recording ............... 38
3.4.5 Stopping the Recording ........................................................ 39
3.4.6 Displaying a Recording on the BR-102 plus ......................... 39
3.4.7 Uploading the Recording to the medilogDARWIN2 .............. 40
4 Patient Information .................................41
4.1 General ....................................................................... 42
4.2 Taking an Extra Measurement.................................. 42
4.3 Interrupting a measurement during the recording . 43
4.4 Extended 48-Hour Recording ................................... 43
4.5 BR-102 plus PWA Unit Measurements .................... 43
5 Cleaning ...................................................44
5.1 Important Information ............................................... 44
5.1.1 Non-admissible detergents ................................................... 44
5.1.2 Admissible detergents .......................................................... 45
5.1.3 Cleaning the Device.............................................................. 45
5.1.4 Cleaning the Pressure Hose/Microphone Cable Assembly .. 45
5.2 Cleaning the Cuff and Pouch.................................... 46
5.2.1 Cleaning the Cuff .................................................................. 46
5.2.2 Cuff Preparation.................................................................... 47
5.2.3 Cleaning the Pouch (as well as the Shoulder and Waist strap) 50
5.2.4 Disinfection ........................................................................... 51
5.2.5 Admissible Disinfectants for the Casing ............................... 52
5.2.6 Non-admissible disinfectants ................................................ 52
5.2.7 Sterilisation ........................................................................... 52
6 Maintenance ............................................53
6.1 Visual Inspection ....................................................... 53
6.2 Battery Maintenance.................................................. 54
6.2.1 Charging the Batteries .......................................................... 54
6.2.2 Battery Disposal.................................................................... 54
6.3 Calibration.................................................................. 55
6.4 Measurement Check.................................................. 55
6.4.1 Equipment Required ............................................................. 55
6.4.2 Setup .................................................................................... 55
6.4.3 Measurement accuracy ........................................................ 56
6.4.4 Overpressure Relieve Valve ................................................. 57
6.5 Error Messages.......................................................... 58
6.5.1 Error Message Table ............................................................ 58
7 Technical Data ........................................60
7.1 Preventing electromagnetic interferences .............. 62
8 Accessories .............................................63
8.1 Documentation........................................................... 63

Page 5
User Guide
Art. no.: 2.511076 Rev.: g
BR-102 plus / BR-102 plus PWA
8.2 General Accessories.................................................. 63
8.3 Cuff and Cuff Accessories ........................................ 64
9 BR-102 plus PWA ................................... 65
9.1 Overview ..................................................................... 65
9.2 Measurements............................................................ 65
9.3 Display of Pulse Wave Analysis ............................... 65
9.4 Method ........................................................................ 66
10 Patient Diary ........................................... 67
10.1 Patient Diary Example ............................................... 67
11 Index ........................................................ 71
12 Appendix - Symbols ............................... 73

Page 6
Art. no.: 2.511076 Rev.: g
BR-102 plus / BR-102 plus PWA

Page 7
Art. no.: 2.511076 Rev.: g
Safety Notes 1
User Guide User Profile 1.1
BR-102 plus / BR-102 plus PWA
1 Safety Notes
1.1 User Profile
Medical Personnel (Operator, User)
This blood pressure recorder as well as the analysis program are
provided for the exclusive use of qualified physicians or trained
medical personnel under their direct supervision.
Patient, Caregiver (for use in home environment)
After thorough instruction from the attending physician, the patient or
his/her caregiver may use the device on their own (see chapter 4
Patient Information and chapter 10 Patient Diary).
1.2 Intended Use
The BR-102 plus / BR-102 plus PWA is a non-invasive ambulatory
blood pressure recorder. It uses auscultatoric and oscillometric
signals, or purely oscillometric signals to measure the blood
pressure of human beings. Systolic, diastolic, mean arterial
pressure and heart rate are measured. The BR-102 plus / BR-102
plus PWA is intended as an aid to diagnosis and treatment when
it is necessary to measure an adult or adolescent patient’s blood
pressure over an extended period of time (up to 24 48 hours).
Further, with each measurement, the PWA data will be saved for
subsequent external assessments.
The BR-102 plus / BR-102 plus PWA can be used for adults and
children (3 years old onwards) of both sexes and all ethnic origins.
This blood pressure recorder can be used on pregnant patients or
patients suffering from pre-eclampsia.
Patients with special needs such as children, the elderly, the
disabled, or people lacking the capacity for judgement must be
accompanied by a caregiver who will supervise the actions as well
as monitor the recording.

1 Safety Notes
1.3 Contraindications
Page 8
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
1.3 Contraindications
1.4 Responsibility of the User
1.5 Organisational Measures
The BR-102 plus / BR-102 plus PWA has not been designed for,
and must not be used for the following patients:
– neonates and children under the age of 3.
– Patients who must undergo invasive blood pressure monitoring.
The numerical and graphical results as well as any interpretation
suggested by the device must be examined with respect to the
patient's overall clinical condition and the quality of the recorded
data.
The indications given by this equipment are not a substitute for
regular checking of vital functions.
The responsibilities of the personnel for the operation and
maintenance of the device must be specified.
Ensure that personnel have read and understood these operating
instructions. In particular this section safety notes, must be read
and understood.
Damaged or missing components must be replaced immediately.
The operator is responsible for compliance with all applicable
accident prevention regulations and safety regulations.
The safety, reliability and performance of the unit can only be
guaranteed when the maintenance intervals, as stated in the
Maintenance section of this user guide, are observed.
No modification of this equipment is allowed.
Before using the unit, ensure that an introduction regarding the
recording functions and the safety precautions has been provided
by a medical product representative.
Observe the operating instructions and maintenance instructions
and keep these operating instructions in an accessible place for
reference when required. Make sure that they are always
complete and legible.
These operating instructions do not override any statutory or local
regulations, or procedures for the prevention of accidents and
environmental protection.

Page 9
Art. no.: 2.511076 Rev.: g
Safety Notes 1
User Guide Maintenance 1.6
BR-102 plus / BR-102 plus PWA
1.6 Maintenance
1.7 Hygiene
1.8 Safety Conscious Operation
1.9 Safety Facilities
There are no serviceable parts inside. Refer servicing to qualified
technician authorised by SCHILLER only.
Do not use high temperature sterilisation processes (such as
autoclaving). Do not use E-beam or gamma radiation sterilisation.
Do not use solvent or abrasive cleaners on either the unit or cable
assemblies.
Do not, under any circumstances, immerse the device or cable
assemblies in liquid.
For cleaning and disinfection observe the legal requirements
applicable.
Only use cleaning agents and disinfectants recommended by
SCHILLER. Unsuitable agents can damage the device. Clean and
disinfect the device in accordance with the instructions given in
this book.
Make sure that the staff have read and understood the operating
instructions - particularly this Safety Notes section.
Immediately report any changes that impair safety (including
operating behaviour) to the person responsible.
Only use accessories and other parts recommended or supplied
by SCHILLER AG. Use of other than recommended or supplied
parts may result in injury, inaccurate information and/or damage to
the recorder.
Connecting the unit to a PC with defective cables may constitute a
danger to life. Therefore:
– Do not connect the BR-102 plus / BR-102 plus PWA to any PC if
the earth connection is suspect or if the mains lead is damaged
or suspected of being damaged.
– Damaged cable connections and connectors must be replaced
immediately.

1 Safety Notes
1.10 Operation with other Devices
Page 10
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
1.10 Operation with other Devices
Only use accessories and other parts recommended or supplied
by SCHILLER AG. The use of other than recommended or
supplied parts may result in injury, inaccurate information and/or
damage to the device.
Accessory equipment must be certified according to the respective
IEC standards (e.g. IEC/EN 60950 for data processing equipment
and IEC/EN 60601-1 for medical equipment). Furthermore, all
configurations shall comply with the valid version of the system
standard IEC/EN 60601-1. Everyone who connects additional
equipment to the signal input part or signal output part configures
a medical system, and is therefore responsible that the system
complies with the requirements of the valid version of the system
standard IEC/EN 60601-1. If in doubt, consult the technical service
department or your local representative.
The BR-102 plus / BR-102 plus PWA is safe during defibrillation.
However, as a safety precaution remove the cable assembly
between the recorder and the PC and when possible, remove the
BR-102 plus from the patient before defibrillation.
The BR-102 plus / BR-102 plus PWA complies with EMC
regulations for medical products which afford protection against
emissions and immunity. However, the possibility exists that high
frequency disturbance from other devices can affect the recorder's
operation.

Page 11
Art. no.: 2.511076 Rev.: g
Safety Notes 1
User Guide Safety Symbols and Pictograms 1.11
BR-102 plus / BR-102 plus PWA
1.11 Safety Symbols and Pictograms
1.11.1 Symbols used in this Document
The safety level is classified according ANSI Z535.4. The following
overview shows the safety symbols and pictograms used in this
manual.
1.11.2 Symbols on the Device, Batteries, and Accessories
For general symbols, see Appendix - Symbols, page 73
For a direct danger which could lead to severe personal injury or to
death.
For a possibly dangerous situation, which could lead to serious bodily
injury or to death.
For a possibly dangerous situation which could lead to personal injury.
This symbol is also used to indicate possible damage to property.
For general safety notes as listed in this chapter.
Note For possibly dangerous situations, which could lead to damages
to property or system failure. Important or helpful user information.
Reference to other guidelines.
Type BF equipment, safe for external applications.
Symbol for the recognition of electrical and electronic equipment.
Recycle the recorder and batteries separately from other waste.
Equipment/components and accessories no longer required must be
disposed of in a municipally approved collection point or recycling
centre. Alternatively, you can return the equipment to your supplier or
SCHILLER AG for disposal. Improper disposal can harm the
environment and human health.

1 Safety Notes
1.11 Safety Symbols and Pictograms
Page 12
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
BR-102 plus / BR-102 plus PWA battery type 2 x AA 1.2 V /
2700 mAh, NiMH. Use NiMH charger only.
Do not disassemble, mutilate, incinerate, or heat. Do not short circuit
a battery. May cause burns. At the end of a battery’s life, do not
dispose in household waste. Batteries must be disposed of in a
municipally approved collection point or recycling centre. To prevent
the possibility of battery leakage, always remove the batteries from
the device when not used for prolonged periods.
(with carrying pouch)
According DIN VDE 0470 PART 1 /EN 60529 / IEC 529
Protection against deposits of dust and protection against spray
water. (The first digit indicates the protection of the equipment against
ingress of solid foreign bodies and dust and the second digit indicates
the degree of protection of the equipment inside the enclosure from
ingress of water).
Read and follow the instructions in the accompanying documentation.
• Do not tumble dry
• Do not use bleach to clean the pouch.
• Do not iron
•DryClean
• Wash the pouch at a temperature of 30° C and the cuff at 40°C.
• Select gentle or delicate cycle.
NiMHNiMH
IP42

Page 13
Art. no.: 2.511076 Rev.: g
Introduction 2
User Guide Safety Symbols and Pictograms 1.11
BR-102 plus / BR-102 plus PWA
2Introduction
The SCHILLER BR-102 plus / BR-102 plus PWA is an Ambulatory
Blood Pressure Recorder used for single and long-term recordings.
The device can take up to 100 measurements over a 24 hour
recording period, and up to 200 measurements over a 48 hour
recording period. All recorded data is stored in an internal memory
and can be uploaded to the medilogDARWIN2 program. The recorder
has four recording programs that can be defined by the user with
individual time and interval settings for each program. This enables
long-term blood pressure measurements to be taken at pre-set
intervals for different patients and conditions.
Standard
• BR-102 plus Ambulatory Blood Pressure recorder Standard, or BR-
102 plus PWA (Pulse Wave Analysis)
• Four rechargeable AA NiMH batteries
• Battery charger unit
• Cuff size ‘M’ (medium) adult, and pressure hose with microphone
• Comfort Sleeve size ‘M’ (medium) adult
• Securing pouch with shoulder and waist-strap
• medilogDARWIN2 software
• USB cable
• BR-102 plus / BR-102 plus PWA user guide
Cuffs and Accessories
Cuffs are available in sizes ‘XS’ (extra small, Osc. only), ‘S’ (small), ‘M’
(medium), ‘L’ (large), and ‘XL’ (extra large). A list of these and other
accessories are given at the end of this book (see Accessories, page
63)

2Introduction
2.1 BR-102 plus / BR-102 plus PWA
Page 14
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
2.1 BR-102 plus / BR-102 plus PWA
The recorders are available as follows:
2.1.1 BR-102plus
The Standard BR-102 plus is identified by the black front casing.
There are two measurement methods available as follows:
• Option 1 employs the auscultatory (Riva-Rocci, Korotkoff) method
of measurement, with an oscillometric method as back-up. This
means that when a clear measurement cannot be obtained with the
auscultatory method, the oscillometric value is used. If a clear
measurement cannot be obtained with either method the BP meas-
urement is retaken. It is not possible to define oscillometric as the
primary measurement method.
• Option 2 employs the oscillometric method only. Note that with this
recorder no microphone is provided with the cuff.
2.1.2 BR-102 plus PWA
The BR-102 plus PWA (Pulse Wave Analysis) is identified by the
white front casing and takes measurements using the auscultatory
(Riva-Rocci, Korotkoff) method with oscillometric as back-up.
The setup and settings of the BR-102 plus PWA, measurement
interval, cuff application, and start and stop procedure are all identical
to the standard unit.
To obtain the extra data needed for PWA, the measurement cycle
differs from standard BP measurement. After every individual
measurement (and the SYS and DIA values recorded), the cuff is
again inflated to the diastolic pressure. This pressure is then held for
10 seconds while the PWA data is obtained. After 10 seconds the cuff
is again deflated and ready for the next programmed measurement.
An outline of PWA principal is given at the end of this book (see BR-
102 plus PWA, page 65).

Page 15
Art. no.: 2.511076 Rev.: g
Introduction 2
User Guide The medilog®DARWIN2 Program 2.2
BR-102 plus / BR-102 plus PWA
2.2 The medilog®DARWIN2 Program
The medilogDARWIN2 program supplied with the recorder is used to
display, save, edit, analyse and print recordings. In addition to blood
pressure recordings, the medilogDARWIN2 can upload and view
Holter ECG recordings and SpO2recordings. Details of the program
are given in the medilogDARWIN2 user guide (see Documentation,
page 63).
2.3 Inserting/Changing the Batteries
1. Open the battery compartment by pressing and sliding the battery
cover away from the recorder.
2. Use the battery removal ribbon to remove the two batteries.
3. Insert two fully charged batteries.
– Ensure that the battery removal ribbon is positioned under the
batteries so that the batteries can be removed from the recorder
when depleted.
– Ensure that the batteries are inserted with the correct polarity as
shown.
4. Position the battery cover in the cover slides and slide back in
place until it clicks to secure.
Use NiMH rechargeable batteries supplied or recommended by
SCHILLER. Full capacity of new NIMH batteries are only reached
after three charge/discharge cycles.
Eneloop Pro NiMH rechargeable batteries (Panasonic 2450 mA)
or Energizer Ultimate Lithium batteries (ENERGIZER L91-FR6)
can also be used.
Do not mix batteries. Only use two batteries of the same type.
Do not use any other type of battery. The capacity of other
battery types may not be sufficient for a 24-hour recording and the
battery capacity symbol may be incorrect.
Battery compartment
cover. Position in grooves and slide until clicked
positive
negative
Battery removal
ribbon

2Introduction
2.4 Connecting the Pressure Hose and Microphone
Page 16
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
2.4 Connecting the Pressure Hose and
Microphone
Two hoses are compatible with the BR-102 plus: see Cuff and Cuff
Accessories, page 64.
• The battery capacity indicator is detailed in the operating section
(see Battery Status for NiMH Rechargeable Batteries, page 20).
• Battery charging details, disposal, and safety relevant precautions
are detailed in the maintenance section (see Battery Maintenance,
page 54).
• Battery and battery charger part numbers are detailed at the end of
this book (see Accessories, page 63).
The hose / microphone assembly can only be inserted in one
direction. Take care when positioning the assembly not to damage
any connectors. Do not pull directly on the hose or microphone cable.
Position the pressure hose connector (a) and attach to the BR-102
plus / BR-102 plus PWA by gently pressing until the connector clicks
in place. If the version is with a microphone (c), the plug is combined
with the hose and the assembly is inserted into BR-102 plus / BR-102
plus PWA at the same time.
Removing the Pressure Hose
Gently press the securing catch (b) to release and remove the hose
connector (and microphone jack plug) from the BR-102 plus / BR-102
plus PWA.
a
b
c

Page 17
Art. no.: 2.511076 Rev.: g
Introduction 2
User Guide Main Components of the Device 2.5
BR-102 plus / BR-102 plus PWA
2.5 Main Components of the Device
(a) USB cable connection
(b) OLED display
(c) Loudspeaker
(d) Microphone connector jack plug and patient cuff connection re-
cess
(e) USB connector
(f) Battery recess (battery cover removed)
(g) Battery removal ribbon
(h) Micro SD card recess (under battery removal ribbon)
(i) Calibration label
(j) Programming function key
(k) Microphone for recording patient identification
(l) Programming function key and ON/OFF key
NEW RECORD
LAST RECORD
SINGLE MEAS.
SYSTEM
NEXT OK
05:16PM
SCHILLER
BR-102plus
cba
ljk
de
g fi h
The micro SD memory card is for service only and is used for software
updates or storage of raw data for test purposes.

2Introduction
2.5 Main Components of the Device
Page 18
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
2.5.1 Operating and Display Elements
Menu option selection and control of the BR-102 plus / BR-102 plus
PWA is with two function keys. The green and blue function
information boxes at the bottom of the screen indicate the function
that will be carried out when the green and blue function keys are
pressed:
2.5.2 Switching on
Press the green ON/OFF key. The display shows an introduction
screen and copyright message for a few seconds and then the main
menu is displayed. If an unformatted micro SD card is installed, you
are prompted to format the card when the recorder is switched on, and
again when a recording is started.
NEW RECORD
LAST RECORD
SINGLE MEAS.
SYSTEM
NEXT OK
05:16PM
SCHILLER
BR-102plus
Right Blue Key Functions:
OK: (confirm menu selection)
Change: (toggle through
options)
Yes: (confirm selection)
Meas: initiate a measurement
(during the recording)
Start: Starts the acoustic
record of the patient ID
Stop: Stops a recording in
progress
Left Green Key Functions:
ON/OFF: (Switch-Off from main
menu only)
Next: (next menu item)
No: (do not confirm selection)
Meas: initiate a measurement
(during the recording)
Holding the key stops the recording
Break: Halts an ongoing
measurement
Stop: Stops a recording in progress
Back: Back to last menu

Page 19
Art. no.: 2.511076 Rev.: g
Introduction 2
User Guide Main Components of the Device 2.5
BR-102 plus / BR-102 plus PWA
2.5.3 Switching Off
With the main menu displayed and the cursor at any position, press
and hold the Green control button for 4 seconds. When the button
is released, the device is switched off.
If a recording is running, first stop the recording by holding the Green
control button for 4 seconds and confirming that the recording will
be stopped (see Stopping the Recording, page 39). Then enter the
main menu and switch off as described above. Any recorded data is
saved when the recorder is switched off.
SCHILLER
15.12.2013
SCHILLER
BR-102plus
. . exit
NEW RECORD
LAST RECORD
SINGLE MEAS.
SYSTEM
NEXT OK
05:16PM
When no recording is running, the recorder switches off automatically
after 5 minutes if no keys are pressed.

2Introduction
2.5 Main Components of the Device
Page 20
BR-102 plus / BR-102 plus PWA
Art. no.: 2.511076 Rev.: g
2.5.4 Battery Status for NiMH Rechargeable Batteries
The battery status display is a guide to battery capacity when using
NiMH rechargeable batteries supplied or recommended by
SCHILLER. If Energizer Ultimate Lithium Batteries are used, a
different battery symbol is displayed (see next page).
Battery Condition
Batteries deteriorate over time and must be replaced. An indication of
battery condition is given when batteries are first placed in the
recorder after a full charge, as follows:
The battery symbol in the upper right of the screen, indicates the
battery status. When the battery is full, the symbol is filled and gives
an indication of current battery capacity as it reduces during the
recording. The empty symbol indicates that the capacity is limited and
that the batteries should be changed. If the batteries are not changed
during this period, a warning message is given that the batteries must
be changed. If the batteries are still not changed an error message is
displayed before the recorder switches off (see next page).
Full
80%
Half full
Low capacity (20%)
Empty
Battery low
Change battery
immediately
NO YES
WARNING
Battery low
Change battery
immediately
OK
ERROR
• An audible and visual indication is given during recording when bat-
tery capacity is limited. When the indication is given and the record-
ing is to be continued, we recommend that the batteries are re-
placed at the first opportunity.
• When recording is stopped because of low battery capacity, and the
batteries are replaced within 5 hours of the recorder switching off,
the recording will continue (see Changing the Batteries During a 48
Hr Recording, page 38)
Battery Indicator Battery Recording Capacity
Full (100%) 24-hour recording is possible.
80% 24-hour recording should be possible.
Half full (50%) Single measurements only will be possible.
The batteries should be replaced.
Low capacity or
empty
A 24-hour recording is not possible. Replace
batteries.
