Schleibinger CDF User manual

Schleibinger CDF/CIF - Freeze-Thaw Testing Equipment
User manual
Schleibinger Geräte
Teubert u. Greim GmbH
Gewerbestraße 4
84428 Buchbach
Tel. [phone]
Fax. [phone]
www.schleibinger.com
[e-mail]
October 11, 2021
Version 3.0

Contents 2
Contents
1 Introduction 4
2 Safety Information 4
2.1 Important Safety Information . . . . . . . . . . . . . . . . 5
2.2 Protection Switches . . . . . . . . . . . . . . . . . . . . . 5
2.3 Personal Safety and First Aid . . . . . . . . . . . . . . . . 5
2.4 Safety Instructions for the Refrigerant . . . . . . . . . . . 6
3 Intended Use 7
4 Reasonably Foreseeable Misuse or Foreseeable Incorrect Use 7
5 Declaration of Conformity 7
6 Description of the Appliance 8
6.1 Testing Bath with Machine Lid . . . . . . . . . . . . . . . . 9
6.2 Refrigerant Equipment . . . . . . . . . . . . . . . . . . . . 9
6.3 ControllerUnit ........................ 9
6.4 Display ............................ 9
6.5 SafetySwitch......................... 10
6.6 LevelIndicator ........................ 10
6.7 USBPort ........................... 10
6.8 KeySwitch .......................... 10
6.9 MainSwitch.......................... 10
6.10 Notices and Stickers . . . . . . . . . . . . . . . . . . . . . 11
6.11 Network Connection . . . . . . . . . . . . . . . . . . . . . 11
6.12 Important Information about the Machine . . . . . . . . . 12
7 Delivery and Installation 13
7.1 Delivery and Packaging . . . . . . . . . . . . . . . . . . . 13
7.2 Spatial Requirements . . . . . . . . . . . . . . . . . . . . 14
7.3 Transportation ........................ 14
7.4 Turn on the Equipment . . . . . . . . . . . . . . . . . . . . 15
7.5 Filling the Equipment . . . . . . . . . . . . . . . . . . . . . 16
7.6 Cooling Water Connection for the Combined Air-Water-
Cooling (optional) . . . . . . . . . . . . . . . . . . . . . . . 17
7.7 Cube Test and ASTM C666 Procedure A (optional) . . . . 18

Contents 3
8 Operation of the CDF Machine 19
8.1 StartandStop ........................ 20
8.2 Status............................. 21
8.3 CycleTime .......................... 22
8.4 USB.............................. 23
8.5 Setup ............................. 24
8.5.1 Target Value . . . . . . . . . . . . . . . . . . . . . 24
8.5.2 Profile input . . . . . . . . . . . . . . . . . . . . . . 24
8.5.3 Display ........................ 28
8.5.4 Clock ......................... 28
8.5.5 System Menu . . . . . . . . . . . . . . . . . . . . . 28
9 Software Handling from Web Browser 32
9.1 Configuration of the Network access . . . . . . . . . . . . 32
9.1.1 receive IP address automatically . . . . . . . . . . 32
9.1.2 use of static IP address . . . . . . . . . . . . . . . 33
9.2 Measured Values . . . . . . . . . . . . . . . . . . . . . . . 35
9.3 Data.............................. 37
9.3.1 Display of Temperature Data . . . . . . . . . . . . 37
9.3.2 Logfile and Error Codes . . . . . . . . . . . . . . . 38
9.3.3 Deletedata...................... 38
9.4 Profiles ............................ 39
9.5 SystemandHelp....................... 40
10 Service Hints 41
10.1 Repair and Maintenance . . . . . . . . . . . . . . . . . . . 41
10.2 Cleaning of the CDF Machine . . . . . . . . . . . . . . . . 42
10.3 Adjusting the Heat Transfer Fluid . . . . . . . . . . . . . . 42
10.4 Removing the Panels . . . . . . . . . . . . . . . . . . . . 43
10.5 Emptying the Heat Transfer Fluid . . . . . . . . . . . . . . 43
10.6BatteryChange........................ 44
10.7 Help in the Event of a Malfunction . . . . . . . . . . . . . 44
11 Decommissioning and Disposal 46
11.1 Decommissioning . . . . . . . . . . . . . . . . . . . . . . 46
11.2 Disposal of the Heat Transfer Fluid . . . . . . . . . . . . . 46
11.3 Disposal of the Machine . . . . . . . . . . . . . . . . . . . 46

1 Introduction 4
1 Introduction
In this user manual the product „CDF/CIF - Freeze-Thaw Testing Equip-
ment“ (hereafter CDF machine) is described.
This user manual contain information on the safe, trouble-free and eco-
nomical use of the CDF machine.
These informations are intended for people who carry out tasks with or
in connection with the CDF machine.
Keep this user manual or relevant parts of it ready to hand in the imme-
diate vicinity of the CDF machine.
When handing over the machine to another person, the operator passes
this user manual on to this person.
The other applicable documents are supplied with this user manual and
can be found under „CDF Service Dokumente“.
2 Safety Information
Read and follow the instructions.
This manual contain Warning and Caution statements. This information
is important for safe and efficient installation and operation. The follow-
ing signal words and symbols are used in this user manual:
Warning indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Caution indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
Indicates a dangerous situation which, if not obviated, may result in dam-
age to property.
Hazardous voltage. Danger of electrical shock or burn.
Warning of the risk of crushing and injury to the hand.
Warning of the risk of crushing the hand.
Wear protective gloves when using equipment.
Wear safety glasses when using equipment.
Wash hands before breaks and
immediately after handling the product.
When using do not eat, drink or smoke.

2 Safety Information 5
2.1 Important Safety Information
Make sure that the input voltage and frequency correspond to the device
specification. This information is printed on the type label and can be
found on the machine in the area of the connection cable.
Disconnect the power supply before servicing. To reduce the risk of fire,
electric shock, or personal injury, installation work and electrical wiring
must be done by a qualified electrician in accordance with all applicable
regulations and standards, including fire-rated construction.
The CDF machine is operating with a refrigerant and requires a careful
handling with it. Service and repair jobs at the cooling machine are al-
lowed only for well trained and special educated persons. Please contact
Schleibinger for further questions.
2.2 Protection Switches
The CDF machine is equipped with the following safety and security
components, which are adjusted by manufacturer.
• electromagnetic lock for the lid. The lock is active, when the tem-
perature is below 0°C or the testing machine is switched off.
• Over-temperature protection for the heating unit.
• Level indicator for the testing bath and the buffer.
• Safety switching device for limiting the high pressure of the com-
pressor.
• Safety switching device for limiting the low pressure of the com-
pressor
• safety switch to monitor for overshoot and undershoot of the com-
pressor current
• safety switch to monitor for compressor over-temperature
• safety switch over-temperature bath, user adjustable.
Changing the set-up of the security devices is prohibited! Any ma-
nipulation will lead to a total loss of the warranty!
2.3 Personal Safety and First Aid
• In the event of defects that endanger safety, do not use the ma-
chine and inform responsible.
• Do not swallow the heat transfer fluid and antifreeze concentrate
(glycol)!
•Avoid skin contact!
• Avoid eye contact!
• Do not use reactive substances.
• Do not eat, drink or smoke.
During hanging and removal of the sample containers:
• Wear protective gloves!
• Wear safety glasses!

2 Safety Information 6
• Avoid splashing when refilling.
• Avoid splashing when taking sample container.
• In case of contact with eyes, rinse immediately with plenty of water
and seek medical advice.
• In case of contact with clothes and skin, take off immediately all
contaminated clothing and wash the skin immediately with plenty
of water for a minimum of 10 minutes.
• Absorb leaked liquid with absorbent material and dispose of ac-
cording to the local regulations.
•In case of fire: use fire extinguisher. Do not use water in the full
jet! Do not breath fumes!
•When closing the machine, do not put your hands under the cover.
There is a risk of crushing
•When closing the machine, do not place your hands in the area of
the safety switch. There is a risk of crushing and injury.
2.4 Safety Instructions for the Refrigerant
Work on the refrigerant-related parts of the testing equipment is only
permitted for educated and trained technicians in accordance with all
applicable regulations and standards.
The refrigerant R448a is classified in safety class A1 according to ISO/
ASHRAE. It is not flammable and has no significant harmful effects on
humans. R448a has a global warming potential of GWP = 1387.
Do not change safety, protection and control devices!
In case of fire, switch off the refrigeration system. Containers and system
parts that are filled with refrigerant can burst violently. When extinguish-
ing, cool the container and system parts with water spray.

3 Intended Use 7
3 Intended Use
The CDF machine is designed for the storage of mineral building mate-
rials at changing temperatures in a range of - 20 °C to + 20 °C and is
intended for use in closed rooms. Use the system only for its intended
purpose.
4 Reasonably Foreseeable Misuse or Foreseeable Incorrect Use
Do not use the machine for the following applications:
• Storage and cooling of products that are not mineral building ma-
terials.
• Storage of mineral materials that tend to form gas during storage.
• Storage of mineral materials that create a flammable atmosphere
during storage.
• Applications that create a risk of explosion.
• Use in potentially explosive areas.
• Use outdoors or in damp and splash water areas.
5 Declaration of Conformity
The declaration of conformity is supplied with the user manual and can
be found in the additional applicable documents under „CDF Service
Dokumente“.

6 Description of the Appliance 8
6 Description of the Appliance
The CDF/CIF-Freeze-Thaw testing equipment (CDF machine) is a high-
quality testing device for carrying out freeze-thaw resistance tests on
building materials. CDF machine is equipped with a microprocessor
controller including internet interface. All relevant safety regulations for
refrigeration and electrics have taken into account.
The CDF freeze-thaw testing device enables the implementation of the
freeze-thaw resistance test according to RILEM Recommendation (Ma-
terials and Structures (1996) Vol. 29 (193), pp 523-528), according to
RILEM CIF test and according to CEN/TS 12390-9. The advantage of
these test methods lies in the very good reproducibility of the measure-
ment results.
These test methods describe the periodic freezing of building materials
through indirect contact with a heat transfer fluid. This arrangement en-
ables an optimal temperature distribution, a fast temperature adjustment
and a temperature gradient perpendicular to the tested surface. Due
to the optimal thermal contact, the temperature can be maintained very
accurately over the entire temperature curve.
The CDF machine is cooled by means of air cooling. Optionally, the ma-
chine can be equipped with a combined air-water cooling „Additional
Feature Air and Water Cooling for CDF equipment“.
With a appropriate system upgrade, the cube test (VDZ cube method) in
accordance with CEN/TS 12390-9 and the ASTM test in accordance with
ASTM C666 procedure A can be carried out („Additional Feature Cube
Test and ASTM C666 Procedure A“). In contrast to air conditioning
cabinets, the freeze-thaw cycle can be run through in 12 hours instead
of 24 hours due to an efficient heat transfer from the heat-transfer fluid
to the sample. Hence, testing time and costs will be minimized.
The technology of the system is easily accessible from all sides due
to removable panels. A thick, carefully executed pipe insulation and a
cross ventilation of the device parts reliable prevent condensation. All
components fits well due to the use of CNC punching and CNC bending
presses. Robust surfaces result from powder coating of all sheet metal
parts.
The CDF machine is supplied as a plug-in compact device in chest form.
It consists of three main parts: testing bath, refrigerant equipment and
controller unit (fig. 1).

6 Description of the Appliance 9
1 machine lid
2 testing bath
3 refrigerant equipment
4 controller unit
5 display
6 safety switch
7 level indicator
8 USB port
9 key switch
10 main switch
Figure 1: Structure of the CDF machine.
6.1 Testing Bath with Machine Lid
The tub of the testing bath is thermally insulated and is made of high
quality stainless steel. For the uniform temperature distribution in the
testing bath, the cooling liquid is kept flowing. The sample containers
are made of stainless steel and are placed in the cooling bath. The
concrete samples are placed in the sample containers. The buffer with
the heat transfer fluid is placed directly under the testing bath.
6.2 Refrigerant Equipment
The unit part, which contains the refrigerant equipment and the assem-
blies for circulation and temperature control, is located below the testing
bath (fig. 1, (3)).
The temperature bath is circulated with a pump and thus enabling rapid
temperature control. If the temperature bath is to be heated up, the
heating is switched on. If the temperature bath is to be cooled, pre-
cooled heat transfer fluid is taken from the storage bath and fed into the
main circuit.
The temperature in the storage bath is always kept well below the target
temperature of the testing bath so that a sufficient amount of cold is
available.
6.3 Controller Unit
The controller unit contains the regulation and switches of the machine
and is attached to the right of the machine (fig. 1, (4)). Disconnect the
power supply before maintenance work. All installation and maintenance
work on the electrics and electronics may only be carried out by qualified
specialist in accordance with all applicable regulations and standards.
6.4 Display
The machine is operated via the operatind and control unit (display) (fig.
1, (5)). Up to 7 different temperature profiles can be entered and se-
lected on the screen. A test program can only be started and stopped
on the display.

6 Description of the Appliance 10
6.5 Safety Switch
Opening the lid of the cooling bath is only permitted, if the bath tem-
perature is close to room temperature. The lid of the CDF machine is
equipped with the safety switch (fig. 2). The lock is active, when the
temperature is below 0 °C or the testing machine is switched off.
The lock is deactivated, when the power is on and the temperature inside
is above 0 °C.
Do not place hands in the area of the safety switch when closing the lid.
There is a risk of crushing and injury!
Figure 2: Lid lock on the left side of the machine: closed position (left) and open
position (right).
6.6 Level Indicator
The level indicator shows the level of the heat transfer fluid in the storage
bath (fig. 1, (7)). The level should be set in the area of the optimum and
must not be below the minimum mark or above the maximum mark.
6.7 USB Port
USB port for the supplied USB stick is available below the display (fig.
1, (8)). Use the supplied USB stick only!
6.8 Key Switch
During the operation, the equipment can be protected against unautho-
rized users with a key switch (fig. 1, (9)). The display can be blocked so
that the operation from the display is no longer possible.
To lock the machine, insert the key into the lock and turn it in the direction
0. The key can then be withdrawn. To unlock, turn the key to the I
position.
When the machine is locked with the key switch, it is possible to access
the system via the network.
6.9 Main Switch
The main switch is located in the lower area of the controller unit (fig. 1,
(10)).

6 Description of the Appliance 11
6.10 Notices and Stickers
Notices and stickers are attached on the system. These must be re-
newed in the event of loss or illegibility.
Mandatory signs can be found on the lid of the CDF machine (fig. 3, 1):
Wear protective gloves.
Wear safety glasses.
The CDF machine contains fluorinated greenhouse gases. The marking
is mandatory as a result of the Kyoto protocol. The information on the
refrigerant used can be found on the sticker under the screen (fig. 3, 2).
The type label is located on the back of the machine in the area of the
connection cable (fig. 3, 4 und 5). The information on the type label can
be found in the applicable documents „CDF Service Dokumente“.
6.11 Network Connection
The Network socket is located on the rear of the machine (fig. 3, 3).
Figure 3: Stickers and rear connections of the CDF machine:
1 mandatory signs
2 information on the refrigerant used
3 network socket
4 type label
5 power cable

6 Description of the Appliance 12
6.12 Important Information about the Machine
General
dimension (w x d x h) 225 x 95 x 120 cm
weight without cooling liquid approx. 560 kg
protection IP20
temperature range -20 °C ... +20 °C
(-40 °C at evaporator)
temperate deviation < ±0,5 °C, except freezing point of
the test fluid
temperature control indirectly via heat transfer fluid
heat transfer fluid approx. 50 % ethylene glycol
approx. 50 % water
adjusted to -45 °C
volume heat transfer fluid approx. 100 liters
Environmental conditions
temperature range +5 °C ... +28 °C
humidity max. 65 %
Testing bath
inner dimensions (l x w x d) 170 x 51 x 20 cm
material stainless steel 1.4301
Power supply
mains 400 V
3PH+N+PE, 50 Hz (optional 60 Hz)
power consumption 4.5 ... 8.5 kW
supply fuse 32 A
Values for the safety switches
Refrigerator:
overpressure switch: 25 bar
under-pressure switch: -0.3 bar
Heater:
over-temperature switch: 70 °C, max. 85 °C
over-temperature bath sensor: 30 °C

7 Delivery and Installation 13
7 Delivery and Installation
7.1 Delivery and Packaging
• The testing equipment is delivered on a pallet in a wooden box.
• Check the packaging for damage before accepting the goods. Dam-
ages caused by transportation must be reported immediately.
• The wooden box is fastened with wood screws. First unscrew the
lid (fig. 4, (1)) and then the side parts of the wooden box (fig. 4,
(2)).
• The CDF machine stands on a pallet (fig. 4, (3)). It can be lifted off
the pallet with a forklift. Pay attention to the maximum permissible
load capacity of the forklift! The empty weight of the CDF machine
is approx. 560 kg.
• If the equipment is to be lifted with the straps, fold them about the
entire body of the machine. Never lift the machine by the lid or the
controller unit!
Figure 4: Packaging of the CDF machine.
The packaging is designed to protect the equipment during moving and
is made of wood. The box is heat-treated according to the regulations
ISPM15/IPPC.
When the packaging is no longer needed, dispose of it according to local
regulations.

7 Delivery and Installation 14
7.2 Spatial Requirements
The CDF machine is designed for operation in closed rooms. The envi-
ronmental conditions should be at minimum +5 °C to maximum +28 °C
and relative humidity of maximum 65 %. At higher humidity, more con-
densation may occur on some parts of the machines. For the tempera-
tures above 28 °C additional water cooling system is required.
The CDF machine is engineered in accordance with DIN EN 378-1 class
A. This means it is allowed to operate the CDF machine in a room where
people are sleeping, disabled persons are working, or a lot of not in-
structed people are present. So there are no special requirements in the
training of the people working with, or nearby the machine.
The floor should be designed for a load of at least 300 kg/m2. For a
purely air-cooled system, the room size should be at least 200 m3and
be well ventilated to dissipate the waste heat. For the set up of the CDF
machine, please ensure free air circulation around the equipment.
The installation area required for the CDF machine is shown in fig. 5.
Figure 5: Required area for the installation of the CDF machine.
7.3 Transportation
For the transportation of the CDF machine, remove sample containers
and the cooling liquid from the bath and the storage tank (buffer) when
filled (see also chapter 10.5).
Only attach the system to the frame of the chest and avoid exerting
any force on the side (trim panels) of the chest or the controller unit.
The trim panels should be additionally secured or transported extra.
The dimensions and the balance point of the equipment as well as the
points of support for the forklift are shown in the figure 6.
If no frost-proof transportation is to be expected, the residual water from
the water-cooled systems must be drained from the plate heat exchanger

7 Delivery and Installation 15
(evaporator) to prevent frost damage. Contact appropriately trained tech-
nician to perform this work.
Figure 6: Dimensions (in cm) and balance point of the CDF machine.
7.4 Turn on the Equipment
Make sure incoming voltage and frequency are the same as the equip-
ment rating. This information is printed on the type label and can be
found on the CDF machine in the area of the power cable.
The CDF machine requires a 5-pin Euro power socket and 400 V three-
phase power network with a rating of 3x32A CEE32A (3x25A charac-
teristic B) and an appropriate circuit protection. Direction of rotation is
right.
Connect the power supply by a red 3PH+N+PE plug and turn on the
equipment. The display is on.
The main switch of the system should be switched on preferably 12
hours before starting testing. The compressor heater is then activated.
The warming up prevents overpressure failure of the compressor after a
long standstill.

7 Delivery and Installation 16
7.5 Filling the Equipment
Set the CDF machine in level before filling the bath. Check this by a level
at the testing bath (7). If necessary, the device can be levelled with four
adjustable feet. It should be adjusted to ±1 mm/m exactly.
Figure 7: Level check.
Insert the filter through the drainage openings in the testing bath (fig. 8,
left).
Fill the heat transfer fluid (water-glycol mixture) into the testing bath.
The filling quantity of the equipment in approx. 100 litres and depends
on the number of sample containers in the testing bath. Hang up the
required number of sample containers in the testing bath and fill up the
heat transfer fluid to the optimum level (fig. 8, right).
Turn on the pump „PU 1“ for the testing bath and pump „PU 2“ for the
buffer from the menu Setup →System Menu →Manual (see chapter
8.5.5). If need, turn the pumps on and off several times until the circuit
remains stable. For pumping the heat transfer fluid from the buffer into
the testing bath activate „Y-K1“ from the menu „manual“.
Never run the pumps for long time without fluid. Always make sure that
the pumps are not sucking in air.
Figure 8: Inserting the filter (left) and optimum filling quantity of the heat transfer
fluid of the machine (right).

7 Delivery and Installation 17
7.6 Cooling Water Connection for the Combined Air-Water-Cooling (optional)
If the CDF machine is equipped for the combined air-water cooling, it
can be supplied with cooling water via 1/2“hoses. When connecting,
pay attention to the flow direction (fig. 9). The hoses can then be passed
under the machine.
On-site installation of manometers in the water inlet and water outlet, a
water meter and a water filter with a mesh size of 0.1 mm are recom-
mended.
The water inlet pressure should be between 1 and 10 bar.
The regulation for the cooling of the CDF machine is set via pressure of
the condenser. For the pressure of the condenser between 15 and 16
bar air cooling takes place. Higher temperatures due to the environment
or inefficient ventilation and heat dissipation cause higher pressure of
the condenser. If the pressure of the condenser rises to 16 bar and
higher, the water cooling switches on additionally.
All changes to the settings must be carried out by a qualified technicians.
Contact your customer service or Schleibinger for questions.
Figure 9: Water connectors for cooling water.

7 Delivery and Installation 18
7.7 Cube Test and ASTM C666 Procedure A (optional)
The equipment may optionally be used for the cube testing method ac-
cording CEN/TS 12390-9 or for the testing method according to ASTM
C666 procedure A. Both methods require a higher filling level of cooling
liquid and a higher heat output. For the conversion, proceed as follows:
• Remove the filter and screw on additional sequence pieces includ-
ing the sealing of the drain in the testing bath to reach a level of
100 mm. Put the filter back in.
• Place the majority of the sample containers in the testing bad and
add heat transfer fluid until the optimum fluid level is reached.
• Check from the menu Setup →System menu →Misc. additional
sensor Ad. Sensor is activated.
• Choose the suitable profile in set-up menu: profile for cube test
method (VDZ12 or VDZ24) or profile ASTM 666 for test profile ac-
cording ASTM C666 procedure A.
This option is characterized by a higher heating output. The heating pa-
rameters can be changed using the controller parameters. Select from
the display Setup →System Menu →Controller →Bath →VDZkr.
The number means the temperature difference between the current tem-
perature and the set temperature and should be between 1 and 5. For
the input number of 5, the heating switches on when the difference be-
tween the current and set temperature reaches 5 °C. For carry out the
freeze-thaw test according to ASTM C666 Procedure A or Cube Test ac-
cording to CEN/TS 12390-9 usage of the temperature difference of 2 °C
is recommended (fig. 10).
The CDF machine equipped with this option is factory set. No changes
are required for heating operation.
Figure 10: Parameter setting for higher heating power.

8 Operation of the CDF Machine 19
8 Operation of the CDF Machine
This part of the user manual describes all the functions that can be set
by the user from the display of the CDF controller. The controller itself is
located in the controller unit at the top left.
An overview of the menu structure is shown in the fig 11 schematically.
Depending on the position within the menu, the following options are
possible by selecting a menu item:
• selecting this menu item, which is marked accordingly,
• forwarding to the next menu or
• you will be asked to provide specification.
By selecting the menu item Return or Back you return to the previous
menu.
Figure 11: Menu structure of the CDF machine (excerpt).

8 Operation of the CDF Machine 20
8.1 Start and Stop
The main switch of the system should be turn on preferably 12 hours
before starting testing. The compressor heater is then activated. The
warming up prevents overpressure failure of the compressor after a long
standstill.
Turn the red main switch below the USB port to turn on the system. After
starting up the main menu appears on the display (fig. 12, left). When
choosing Start a hint appears on the display (fig. 12, right). If you are
sure the device is already warm, you can skip the hint with Continue.
The main menu appears on display again (fig. 12, left).
By selecting Start, the system starts at the specified cycle time. This
time is retained even after turning off and can be changed in the menu
cycle time (see chapter 8.3). For the CDF test 28 cycles of 12 hours
each will be executed. The corresponding number of cycles will expire, if
another profile is activated. At the end of the last cycle, the temperature
is kept constant at +20 °C until the cycle time is reset and the profile is
restarted. This means in case of a new test the cycle time has to be
reset.
To stop the CDF controller when running, press anywhere on the display
and select stop.
Figure 12: Main menu on display (left) and hints for warming up of the system
(right).
