Schmitz arco-matic 200 M User manual

Instructions for use
Examination and
treatment chair
arco-matic 200 M / 300 M
arco-matic 114.9600.0
arco-matic 114.9700.0

2Instructions for use arco-matic 200 M / 300 M -
V
ersion 2018-05-08 GBR ID no. 2038823A
Table of contents
These instructions for use ......................................................................................................................4
General.............................................................................................................................................................. 4
Warnings ........................................................................................................................................................... 4
Text symbols...................................................................................................................................................... 4
Important safety information .................................................................................................................. 5
Regulatory .............................................................................................................................................6
Product classification ........................................................................................................................................ 6
Intended use...................................................................................................................................................... 6
Approved accessories ....................................................................................................................................... 7
Device description..................................................................................................................................9
Diagram ............................................................................................................................................................. 9
Features.............................................................................................................................................................11
Control units.....................................................................................................................................................12
Delivery ................................................................................................................................................13
Storing the product ..........................................................................................................................................13
Transport to destination ...................................................................................................................................14
Unpacking.........................................................................................................................................................14
Transport at destination ...................................................................................................................................15
Setup ................................................................................................................................................................16
Preparation for operation.......................................................................................................................17
Levelling ........................................................................................................................................................... 17
Setting up a hardwired connection (optional) ..................................................................................................18
Fitting the back foot section cover ................................................................................................................. 20
Connecting the foot control unit..................................................................................................................... 23
Fitting the front foot section cover.................................................................................................................. 24
Connecting the hand control unit ................................................................................................................... 25
Connecting .......................................................................................................................................... 26
Mains connection ............................................................................................................................................ 26
Potential equalisation (optional, 101.0481.0).................................................................................................... 26
Sockets on the device (optional, 101.0482.0) ................................................................................................. 27
Positioning patients .............................................................................................................................. 29
Operation ............................................................................................................................................30
Safety information...........................................................................................................................................30
Switching on /
off ............................................................................................................................................. 31
Hand control unit ........................................................................................................................................... 32
Foot control unit ............................................................................................................................................. 37
Standard accessories............................................................................................................................ 39
Back pad ......................................................................................................................................................... 39
Seat pad ..........................................................................................................................................................40
Head pad ..........................................................................................................................................................41
Rinsing basin.................................................................................................................................................... 42
Cradle of the hand control unit ...................................................................................................................... 43
Side rail accessories .............................................................................................................................44
Arm rest (101.0019.0) ......................................................................................................................................44
Göpel leg support (101.0459.0), attachment clamp (101.1670.0) .................................................................. 45
Other optional accessories ................................................................................................................... 49
Foot supports (101.0492.0) ............................................................................................................................49
Protective cover for foot supports (101.0475.0) ..............................................................................................50
Göpel leg support (101.0493.0) .......................................................................................................................51
Head cushion (101.0472.0) .............................................................................................................................. 53
Mobility (101.0466.0) ...................................................................................................................................... 54
Foot rest for the doctor (right: 01.0468.0, left: 101.0469.0) ........................................................................... 56
Leg plate (101.0471.0) ..................................................................................................................................... 57
Paper roll (101.0489.0) .................................................................................................................................... 58
Rinsing basin with convenient holder (101.0495.0) ......................................................................................... 59
Colposcope support (101.0467.0) ...................................................................................................................60
Potential equalisation (101.0481.0) ...................................................................................................................61
Cleaning and disinfecting ..................................................................................................................... 62
Pads ................................................................................................................................................................. 63
Stainless steel parts.........................................................................................................................................64
Rinsing basin....................................................................................................................................................64

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 3
Replacing fuses .................................................................................................................................... 65
Technical Service ................................................................................................................................. 66
Wear parts....................................................................................................................................................... 67
Visual and functional checks........................................................................................................................... 67
Disposal...............................................................................................................................................69
Product identication........................................................................................................................... 70
Identication plate .......................................................................................................................................... 70
Symbols used ................................................................................................................................................... 71
Technical data...................................................................................................................................... 73
Connection dimensions ........................................................................................................................ 76
EMC declaration .................................................................................................................................. 77
EC Declaration of Conformity (including accessories) ............................................................................ 79
Glossary .............................................................................................................................................. 82
Index ...................................................................................................................................................84
Contact information ............................................................................................................................. 88

4 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
These instructions for use
General
These instructions for use reect the state of knowl-
edge at the time of printing and make no claim to
completeness. The information provided in these
instructions for use may be outdated due to the
ongoing technical development of our products.
However, all information is regularly updated in
revisions.
Illustrations in these instructions for use are not
necessarily to scale.
Keep these instructions for use at the place of use of
the product.
These instructions for use must be read and
observed by all persons who use, operate or clean
the product.
To be able to use the described product safely, the
provisions of these instructions for use must be
observed. Please observe in particular warnings,
ambient conditions, installation instructions, oper-
ating instructions, inspection and maintenance
regulations, as well as the standards listed in these
instructions for use.
Warnings
A risk assessment pursuant to ISO 14971:2007+
amendment:2009 (Risk management for medical
devices) was performed for this device. The signal
words, symbols and colours of the warnings were
selected in accordance with ANSI 535.6.
The warnings were scaled in accordance with the
following denitions for risk assessment.
DANGER!
“DANGER” refers to a hazardous situation which
could result in serious injury or death if it is not
avoided. Serious injuries are irreversible injuries
requiring permanent and regular medical care.
WARNING!
“WARNING” refers to a hazardous situation which
could result in moderate to serious injury if it is not
avoided. This includes reversible injuries requiring
care or examination by a medical professional.
CAUTION!
“CAUTION” refers to a hazardous situation which
could result in slight to moderate injury if it is
not avoided. This includes reversible injuries not
requiring medical care.
NOTE
“NOTE” refers to information not relating to personal
injury, e.g. information relating to damage to prop-
erty.
RECOMMENDATION
Recommendations are information that helps readers
use the product better, longer and more safely.
Text symbols
A triangle before the text means:
Execute this work step.
Execute this partial work step.
A square before the text means:
This is the result of the previous action.
A bullet point before the text means:
•This is part of an itemisation.

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 5
Important safety information
Use of the product
This product is state-of-the-art and was built
according to recognised safety rules. Nevertheless,
risks to the life and limb of users or third parties
may occur, or this product and other assets may be
adversely aected by the use of this product. This
product must only be used in sound condition and
for its intended use.
Suitability for use in oxygenated atmosphere
The examination chair must not be operated in an
oxygenated atmosphere.
Technical changes
It is not permitted to modify the examination and
treatment chair without the consent of the manufac-
turer.
Attaching accessories
When mounting accessories, always check the
condition of the accessory, and make sure that it is
attached securely.
Replacement parts
Replacement parts have to meet the requirements
established by SCHMITZ u. Söhne. Using original
replacement parts guarantees at all times that the
parts comply with requirements.
Non-slip setup
Before and during use of the product, it must be
ensured that the product has sucient oor adhe-
sion and that there is good slip resistance for both
product and user.
Mandatory training
This product may only be operated by persons
instructed in its proper use.
Patient positioning
The user must be familiar with and must comply with
the applicable organisational and national rules and
regulations for the proper positioning of patients.
The nursing sta are responsible for ensuring that
the patients are positioned in such a way that no
threats are posed to respiration, the nervous system
or the circulatory system. This applies in particular to
anaesthetised or unconscious patients.
HF devices
Combination with HF or debrillator devices is
possible. Please note that the patient must be insu-
lated from the examination and treatment chair. Use
electrically insulated underlays between the patient
and the examination and treatment chair. To this end,
the instructions for use issued by the device manu-
facturer must be complied with.
Checklist
Perform a visual and functional check regularly
according to the device-specic checklist provided
in these instructions for use.

6 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Regulatory
Product classication
In combination with the accessories listed in “Tab.
1” on page 8, the product is a Class I medical
device according to Annex IX of the Medical Device
Directive 93/42/EEC. Harmonised standards were
used to assess compliance. The product meets the
fundamental requirements according to Annex I of
Directive 93/42/EEC, as well as of amending Council
Directive 2007/47/EC regarding medical devices
(Medical Device Directive).
Intended use
Only uses that are listed in this “Intended use”
chapter are intended for the purposes of IEC 60601-
1:2005 + amendment: 2006 + amendment: 2007 +
supplement1:2012.Any other use will result in an
exclusion of liability.
The examination and treatment chair arco-matic is
intended for use in human medicine only.
The examination and treatment chair may be used
for the following purposes:
•for the short-term positioning of patients for
urological examinations and treatment of
non-anaesthetised or sedated persons. A person
placed under the care of a guardian may only be
positioned on the examination chairs under super-
vision. Under these same conditions, the exami-
nation chair can also be used in gynaecology and
proctology.
The examination and treatment chair may not be
used:
•as an operating table,
•for transporting patients.
The safe working load of the examination and
treatment chair as per IEC 60601-1:2005 + amend-
ment:2006 + amendment:2007 + supplement 1:2012
is 250 kg less the weight of the attached accessories.
It may only be used in Group 0 and Group 1 medical
rooms according to and/or IEC 60364-7-710:2002-11.
Permissible user groups for the product are:
•Trained medical personnel (doctor/nurse)
•Trained cleaning sta
•Hospital technicians

Instructions for use arco-matic 200 M / 300 M -
V
ersion 2018-05-08 GBR ID no. 2038823A 7
Approved accessories
Accessories from SCHMITZ u. Söhne were devel-
oped for and tailored to this product (for a list of
accessories, see the table below). Third-party acces-
sories must be inspected and used with reference to
their instructions for use.
(*) The corresponding weight of the patient is indi-
cated in brackets.
Example: a safe working load of ‘‘60 (250) kg’’ means
that the accessory can support a weight of up to 60
kg. The part of the body that weighs 60 kg indicates
a total body weight of 250 kg.
Fig. 1
Notes regarding the following table (sample values)
Article no. Description Safe working load
as per IEC 60601-
1:2005, (*) in kg:
Net
weight
per unit in kg :
101.0492.0 Foot supports for positioning the patient’s legs. 25 4
101.0464.0 Side rails for seat section (pair), 150 mm long, used to
attach side rail accessories
101.0466.0 Integrated double castor (set) for the examination and
treatment chair (‘‘mobility’’). Serves to transport the
examination and treatment chair without a patient.
101.0472.0 Magnetic head cushion for positioning the patient’s
head.
101.0474.0 Leatherette cover (pair) to improve the grip on the
Göpel leg support
101.0475.0 Protective covers (pair), to protect the foot supports
when used with shoes.
101.0482.0 2 sockets as power supply for accessories attached to
the examination and treatment chair, such as colpo-
scopes or examination lights
25 0.3
250 5
/ 0.51
/ 0.2
/ 0.1
/ /
101.0487.0 LED illumination / /
101.0493.0 Göpel leg support with integrated handle, for posi-
tioning the patient’s legs during examination and treat-
ment.
25 6
101.0471.0 Extensible leg plate to position the patient’s legs 50 3
101.0467.0 Colposcope support (attachable on both sides) for
mounting colposcopes.
101.0473.0 Leatherette cover (pair) to improve the grip on the foot
support
101.0478.0 Foot supports, short (version), for positioning the
patient’s legs during examination and treatment
101.0481.0 Potential equalisation to reduce the patient leakage
current
101.0483.0 2 sockets for the Swiss market as power supply for
accessories attached to the examination and treatment
chair, such as colposcopes or examination lights
25 7
/ 0.2
25 4
/ /
/ /
101.0489.0 Paper roll, 500 mm wide, as hygienic cover for the pads. / 1.5
101.0019.0 Arm rest, serves to stabilise the patient’s arm 20 6.8
101.1670.0 Attachment clamp (piece) for mounting approved
accessories on the side rails.
25 0.7
101.0459.0 Göpel leg support for positioning the patient’s legs
during examination and treatment
see ‘‘Safe working 4
load’’ on page 45

8 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Article no. Description Safe working load
as per IEC 60601-
1:2005, (*) in kg:
Net weight
per unit:
101.0463.0 Side rails for seat section (pair), 290mm long, for
mounting side rail accessories
25 0.6
101.0468.0 Foot rest for the doctor, to support the doctor’s feet
during the examination (right-sided version).
25 1.5
101.0469.0 Foot rest for the doctor, to support the doctor’s feet
during the examination (left-sided version).
25 1.5
101.0476.0 Protective cover for seat pad to protect the seat pad / 0.2
101.0465.0 Side rails for the back section for mounting accessories
on the back section
20 1
Tab. 1
Approved accessories from SCHMITZ u. Söhne GmbH & Co. KG

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 9
Device description
Diagram
Fig. 2
Examination and treatment chair arco-matic 200 M / 300 M
Head pad Head cushion (optional,
101.0472.0) Back pad
Leatherette cladding Seat pad Lifting arm
Rear foot section cladding F o o t s u p p o r t s Rinsing basin
Foot control unit (e.g. arco
200 M) Hand control unit Front foot section cladding
Tab. 2
Position numbers of the above illustration

10 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Fig. 3
Examination and treatment chair arco-matic 200 M / 300 M (back)
Locking pedal (optional) On/o switch Fine-wire fuses of the inte-
grated sockets
Attachment screws for the
rear foot section cladding
Screw thread for the attach-
ment screws Cable brackets
Integrated socket (optional,
101.0482.0) Mains connection Potential equalisation (optional, 101.0481.0)
Tab. 3
Position numbers of the above illustration

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 11
Features
arco-matic 200 M / 300 M is an adjustable examina-
tion and treatment chair for use in gynaecology.
Operation
The examination and treatment chair can be adjusted
with a foot control or hand control. Four memory
buttons are available for this purpose, with which the
positions of all available adjustment features can be
saved.
For version-specic features, see Tab. 4.
Accessories
The integrated double castors (article number
101.0466.0, optional) can be locked or set to a drive
mode for “quick forward drive/rotation on its axis” or
“easy mobility in all directions”.
The head cushion (article number 101.0472.0,
optional) is xed to the head pad magnetically. It can
be adjusted by 560mm in a longitudinal direction
and 250mm in a transverse direction.
During the adjustment of the examination and treat-
ment chair, the rinsing basin remains in a horizontal
position automatically. It measures 325 mm × 175 mm
(depth: 65 mm) and can be removed.
Paper rolls with a width of 400mm and 500mm can
be inserted. The diameter of these paper rolls may
not exceed 140mm. The mount for the paper roll is
enclosed on all sides and thus protected against dirt.
Some models feature LED lighting. This LED lighting
comes on as soon as the examination and treatment
chair is connected to the mains and switched on. If
the LED lighting is not required, it can be switched
o by a maintenance engineer.
Feature arco-matic 200 M arco-matic 300 M
Seat height adjustment present present
Back section adjustment present present
Foot support adjustment not present present
Number of storable memory positions 4 4
Tab. 4
Version-related features of the examination and treatment chair

12 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Control units
The examination and treatment chair is operated
using a hand control unit or a foot control unit.
The control unit of the examination and treatment
chair is equipped with a memory for four adjustable
chair positions (“memory function”). Adjustment
functions operated by electric motors are activated
by a foot control unit or hand control unit.
For more information on the hand control unit, please
see chapter “Hand control unit” on page 32.
For more information on the foot control unit, please
see chapter “Foot control unit” on page 37.
Fig. 4
Control units of the arco-matic 200 M
Fig. 5
Control units of the arco-matic 300 M

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 13
Delivery
The product is generally stored prior to the shipping
and transport of the product to the end user, and the
unpacking of the delivered product at the end user’s
premises, by SCHMITZ u. Söhne and/or its distribu-
tion partners.
This chapter is intended for those people who handle
the storage of the product prior to the shipping, the
transport of the product at the end user’s premises
and the unpacking of the supplied product at the end
user’s premises.
Storing the product
NOTE
If ambient conditions deviate from the range of
values stated in Tab. 5, the electronic control unit
may be damaged irreparably during storage or
transport.
Hence, the examination and treatment chair must
not be exposed to conditions other than those
indicated during transport and storage.
During transport to the place of destination and
during storage, specic requirements apply for
the ambient conditions. These requirements may
deviate from the ambient conditions required during
operation. The admissible ambient conditions during
transport to the destination and during storage are
indicated by symbols on the packaging.
For the ambient conditions permitted for storage and transportation, please see Tab. 5.
Parameter Ambient temperature Relative humidity Air pressure
Range of values -10°C – +50°C 20% – 95% at 30°C -
non-condensing 700 – 1,060 hPa
Symbol on the packaging
Tab. 5
Ambient conditions permitted during storage and transport

14 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Transport to destination
The products from SCHMITZ u. Söhne are prepared
for transportation when they leave the plant.
After delivery, transport the product to its place
of use in its original packaging!
Unpacking
NOTE
The pads of the examination and treatment chair can
easily be slit when cutting open the packaging lm.
The product must be unpacked at its place of use.
Inspect the product during unpacking. Any
damage incurred during transportation must be
reported immediately to the applicable partner or
SCHMITZ u. Söhne.

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 15
Transport at destination
To lift the examination and treatment chair, e.g. from
a pallet, the cladding must rst be removed from
both foot sections. The chair must be lifted with
carry straps (included in the delivery).
The following steps must be followed even if, at a
later stage (e.g. after nal use), the examination and
treatment chair is to be moved and the chair is not
equipped with a mobility function.
Attaching the carry straps
The examination and treatment chair comes with
foot supports, which are tted as shown in Fig. 6.
The foot supports are tted the other way round
for delivery: the right foot support is on the left side
and vice versa. The foot supports must be removed
before the examination and treatment chair is trans-
ported at the destination.
Remove the attached foot supports.
Keep the right and left foot supports separately.
Each is to be tted on the other side respectively
once the examination and treatment chair has
been set up (see “Setup” on page 16).
Fig. 6
Foot support, before assembly
1) Foot support
Attach two carry straps each on the left and right
side as shown in Fig. 7 or in Fig. 8.
Lower the examination and treatment chair from
the pallet. This must be done by four people.
NOTE
The examination and treatment chair will be
damaged if it is lifted by the back pad and seat pad.
The examination and treatment chair must therefore
always be lifted by the foot section.
Moving at the destination
Models with a mobility function can also be trans-
ported at the destination by moving the examination
and treatment chair along to the desired location.
Please refer to the instructions in chapter “Mobility
(101.0466.0)” on page 54.
Fig. 7
Attaching carry straps (for non-mobile models)
1) Carry strap
Fig. 8
Attaching carry straps (for mobile models)

16 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Carrying
WARNING!
Components such as the foot rest or colposcopes
are not designed as carrying or lifting handles. When
subjected to such a load, the component will detach
from the examination chair. Serious injury may occur
when the examination chair falls as a result.
Components such as the foot rest or colposcopes
are not designed as carrying or lifting handles!
To carry the product after unpacking or nal use,
it must be brought into the transport position.
The transport position is the position in which the
product was delivered:
•disconnected from the power supply,
•no mounted accessories,
•product moved down (height adjustment set to
lowest level).
Bring the product into the transport position.
Disconnect the mains connection (disconnect
the mains plug).
Detach mounted accessories.
Move the product to its lowest position.
During transportation, ensure that the unit does
not collide with persons or objects.
Setup
NOTE
The examination and treatment chair requires some
time to acclimatise. If the acclimatisation period is
too short, the examination and treatment chair may
be damaged.
For this reason, please let the examination and
treatment chair acclimate for at least 12 hours after
every transport.
NOTE
The power cord and supply cable for the foot control
unit may be damaged if the levelling screws touch
down on them.
For this reason, always make sure that none of
the electric cables are pinched under the levelling
screws or under the foot section.
Set up the unit so as to ensure that
•the product can be used and operated without
any obstruction,
•the mains plug is easily accessible,
•the displays can be read easily, and
•that existing switches can be operated easily
(e.g. the on/o switch at the rear must be
easily accessible).
Fit the removed foot supports (see “Attaching the
carry straps” on page 15) to the opposite side
to which they were previously tted.

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 17
Preparation for operation
Final mechanical works on the product are generally
performed by SCHMITZ u. Söhne or its distribution
partners. In so doing, the examination and treatment
chair must be levelled out, the foot section cladding
must be attached and the cradle of the hand control
unit must be mounted.
This chapter is intended for people who deal with the
nal mechanical works on the products.
The nal mechanical works may be performed only
by personnel trained and authorised by SCHMITZ u.
Söhne or its distribution partners.
Performing the works described in this chapter
requires a spirit level, an M3 hexagon spanner, a
Phillips screwdriver, an M2.5 hexagon spanner and a
bar.
Levelling
The levelling feet serve to compensate for uneven
oors and to ensure that the examination and treat-
ment chair is placed in a horizontal position.
Lift the examination and treatment chair on one
side.
Secure the examination and treatment chair by
placing a bar under the foot section.
Turn the levelling foot in or out.
Remove the bar and lower the examination and
treatment chair.
Check to see if the examination and treatment
chair stands properly.
Repeat until the examination and treatment chair
stands properly.
NOTE
The power cord and supply cable for the foot control
unit may be damaged if the levelling screws touch
down on them.
For this reason, always make sure that none of
the electric cables are pinched under the levelling
screws or under the foot section.
Fig. 9
Lifting the examination and treatment chair
1) Front levelling foot (octagonal)
Fig. 10
Lifting the examination and treatment chair
1) Rear levelling foot

18 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Setting up a hardwired connection (optional)
The examination and treatment chair can, if neces-
sary, be hardwired on-site instead of connected to
the mains supply via the mains cable. This requires
some adjustments to be made in the control unit
housing.
DANGER!
Risk of electric shock!
Improper electrical work to the examination and
treatment chair puts patients, medical personnel and
those carrying out the work at risk!
The modications listed in this chapter must,
therefore, only be carried out by qualied specialist
personnel! The examination and treatment chair
must be completely disconnected from the mains
supply during such work!
If setting up an electrical hardwired connection for
the examination and treatment chair, a wall switch
must be installed, which can switch the examination
and treatment chair o.
Disconnect the mains plug of the examination
chair.
Undo and remove the attachment screws on the
cover of the control unit housing as shown in Fig.
11.
Remove the cover of the control unit housing as
shown in Fig. 12.
Undo the screw from the mains socket.
Undo the conductors of the mains cable on the
mains adapter.
Undo the mains cable attachment screw (Fig. 13,
Pos. 5).
Fig. 11
Remove the cover of the control unit housing
Fig. 12
Remove the cover
Fig. 13
Inside of the mains socket
1) Green and yellow protective earth conductor 2)
Brown conductor 3) Blue conductor 4) Cable attach-
ment screws 5) Mains cable attachment screw

Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A 19
Disconnect the mains cable from the control unit
housing.
Fig. 14
Disconnect the mains plug
1) Screw connection 2) Mains plug
Feed the mains cable of the on-site electrical
connection through the opening in the control
unit housing as shown in Fig. 15.
Connect the conductors of the new mains cable
to the mains socket as shown in Fig. 13.
Put the cover back on the mains socket and screw
on.
Replace the cover of the control unit housing.
Secure the cover of the control unit housing again
with attachment screws.
Fig. 15
Feed the mains cable through the opening
1) Mains socket 2) Mains cable

20 Instructions for use arco-matic 200 M / 300 M - Version 2018-05-08 GBR ID no. 2038823A
Fitting the back foot section cover
If the product is equipped with mounted double
castors, the rear foot section cladding is already
mounted.
If the product is not equipped with double
castors:
Place the rear foot section cladding in the
correct position as shown in Fig. 16. The power
cord must be guided through the recess in the
rear foot section cladding.
Fig. 16
Mounting the rear foot section cladding
1) Rear foot section cladding 2) Recess 3) Power cord
Insert two attachment screws for the rear
foot section cladding into the bores for the
attachment screws and tighten them with the
supplied 2.5 mm hexagon spanner.
Fig. 17
Mounting the attachment screws
1) Attachment screw (Allen screw, M2.5)
Position the splash protection for the on/o
switch and press down rmly.
Insert the socket cladding and fuses and press
down rmly.
Fig. 18
Fitting the splash protection of the on/o switch
1) Splash protection of the on/o switch 2) On/o
switch
