USER MANUAL
UNINTERRUPTIBLE POWER SUPPLY
Series AVARA Multi Power
USMPX 15/25 kW –500kW
3 phase input / 3 phase output
On Line / Double Conversion (VFI) Technology

2
INTRODUCTION
This manual provides detailed instructions for use and installation of the product.
For information about using and to get the maximum performance from your UPS, this manual should be carefully kept
near the UPS and READ BEFORE ANY OPERATIONS ARE PERFORMED UPON IT.
NOTE: Some of the images in this document are provided as a guideline only, and they may not accurately reproduce the
depicted product components.
SAFETY PRECAUTIONS
Read the safety manual provided before carrying out any operations on the Modular UPS System.
This manual describes how to use the product; for its installation and configuration please refer to the specific manuals.
ENVIRONMENTAL PROTECTION
While developing its products, the company spends great efforts in analysing environmental issues. All our products seek the
objectives defined by the policies of the environmental management system, developed by the company according to the current
legislation.
No harmful material such as CFC, HCFC or asbestos can be found in this product.
The packaging is made of recyclable material. Please dispose of the individual elements according to the current legislation in
force in the country where the product is to be employed. Please refer to the following table for identifying the materials:
DESCRIPTION
MATERIAL
Pallet
Wood
(FOR)
Packaging box
Corrugated cardboard
(PAP)
Protective bag
High Density
Polyethylene (PE-HD)
Adhesive buffers
Low Density Polyethylene
(PE-LD)
Bubble Cushioning Wrap
DISPOSAL OF THE PRODUCT
The UPS contains materials which (in case of decommissioning/disposal) are considered TOXIC and DANGEROUS WASTE, for
example circuit boards and batteries. Treat such material according to the current legislation by using licensed centres. Their
correct disposal helps to protect the environment and human health.
If some of the components are to be stored before being disposed of, make sure to store them in secure areas protected from
weather conditions, in order to avoid soil and groundwater contamination (especially with materials such as lead or the battery
electrolyte).
©The reproduction of any part of this manual, even if partial, is forbidden unless authorised by the manufacturer.
The manufacturer reserves the right to change the product described at any time without prior notice for improvement purposes.

3
CONTENTS
PRESENTATION 6
AVARA MULTI POWER USMPX 15/25KWUP TO 500KW 6
MODULAR UPS POWER CABINET 130X (PWC 130X) 7
MODULAR COMBO CABINET (CBC 130X) 11
PWC 130X USER INTERFACE 15
CBC 100X USER INTERFACE 16
OPERATING MODE 17
MODULAR UPS SYSTEM 17
NORMAL MODE 17
BATTERY MODE 17
AUTOMATIC STATIC BYPASS MODE 17
ECO MODE 17
FREQUENCY CONVERTER MODE 17
EFFICIENCY CONTROL MODE 17
MANUAL BYPASS MODE 18
MODULAR UPS POWER CABINET 18
MODULAR BATTERY CABINET BTC 170 20
MODULAR UPS COMBO CABINET CBC 100X 21
INSTALLING THE CABINET 23
MODULES AND UNITS INSTALLATION 23
POWER MODULE (PM) 23
INTERFACE PANEL 24
INSERTION/EXTRACTION PROCEDURE 25
BYPASS MODULE (BM) 26
INTERFACE PANEL 27
INSERTION/EXTRACTION PROCEDURE 28
MONITORING UNIT (MU) [CBC 100X; BTC 170] 29
INTERFACE PANEL 29
INSERTION/EXTRACTION PROCEDURE 29
POWER SUPPLY UNIT (PSU) 30
INTERFACE PANEL 30
INSERTION/EXTRACTION PROCEDURE 30
MAIN COMMUNICATION UNIT (MCU) [CBC 100X] 31

4
INSERTION/EXTRACTION PROCEDURE 31
CONNECTIVITY PANEL (CP) [PWC 130X] 31
INTERFACE PANEL 31
INSERTION/EXTRACTION PROCEDURE 32
BATTERY UNIT (BU) 32
INSERTION/EXTRACTION PROCEDURE 32
BATTERY MAINTENANCE 34
DISPLAY 35
OVERVIEW 35
STATUS BAR 35
ICONS AND SYMBOLS 36
LOAD LEVEL AND REDUNDANCY SYSTEM STATUS 38
ACTIVE TEXT AREAS 39
NAVIGATION 39
SLIDING SWITCH STATUS 40
SYSTEM STATUS DISPLAY 40
“SYSTEM”HOME PAGE 41
SYSTEM MEASUREMENTS 44
“SYSTEM STATUS”PAGE 46
GLOBAL SYSTEM INFORMATION 48
“CABINET”PAGE 50
“POWER MODULE”PAGE 51
“BYPASS MODULE”PAGE 52
“MONITORING UNIT”PAGE 53
“BATTERY UNIT ARRAY”PAGE 56
ACCESS LEVEL SELECTION 56
COMMANDS 57
ACCESS TO THE COMMAND PANEL 57
SYSTEM OFF/ON COMMAND 57
“COLD START”COMMAND 58
BATTERY TEST COMMANDS 59
MODULE OFF/ON COMMAND 59
COMMANDS FOR DISPLAYING AND EXPORTING DATA 60
EMERGENCY OFF COMMAND 61
MAIN SETUP PAGE 62
LANGUAGE CONFIGURATION 63
SYSTEM CLOCK SETTING 63
CLOCK SYNCHRONIZATION SETTINGS 63
PLANNED OPERATIONS CONFIGURATION 64

5
BATTERY TEST SCHEDULING 64
E-MAIL CONFIGURATION 65
SMTP CLIENT CONFIGURATION 65
E-MAIL ADDRESS CONFIGURATION 65
CONFIGURATION OF THE DETAILS OF THE E-MAIL MESSAGE 66
NETWORK SETTINGS 66
GENERAL SYSTEM SETTINGS 67
SYSTEM LABEL 67
PASSWORD SETTING AND CHANGE 67
DISPLAY SETTINGS 68
BUZZER 68
ANOMALOUS SITUATION SCREENS 69
OPTIONS 71
REMOTE COMMUNICATION 72
OPERATIVE PROCEDURES 76
SYSTEM ON 76
SWITCHING THE SYSTEM TO MANUAL BYPASS 78
SWITCHING THE SYSTEM TO INVERTER AFTER MANUAL BYPASS 78
PM REPLACEMENT 79
BM REPLACEMENT 80
REPLACING MU, MCU, CP AND PSU 80
BU REPLACEMENT 80
STATUS MESSAGES / ALARM CODES 81
USMPX SYSTEM 81
POWER MODULE 82
BYPASS MODULE 86
MONITORING UNIT 87
TECHNICAL DATA TABLE 89

6
PRESENTATION
AVARA MULTI POWER USMPX 15/25KWUP TO 500KW
The USMPX modular UPS has been designed using the latest state of the art technology to ensure maximum resilience and
performance; additionally, the use of three level Neutral Point Clamped (NPC) inverter and Power Factor Corrected (PFC) input
control ensures the highest levels of performance such as:
▪OUTSTANDING EFFICIENCY; High system efficiency whilst operating in on-line double-conversion mode.
▪ULTIMATE SCALABILITY; with 15/25kVA unity power factor (PF) power modules ensures the highest power density
with ultimate scalability.
▪UTMOST AVAILABILITY; designed to have a redundant power module in each power rack to provide reliability in terms
of resilience and the availability of the UPS system.
▪EASY CONTROL; using the latest colour touch screen technology the connectivity module provides easily navigable
menus using icons to see the full status of the USMPX UPS without having a single point of failure.

7
MODULAR UPS POWER CABINET 130X (PWC 130X)
Front view
Rear view
①
Display
⑤
Relay Slot
②
Door
⑥
ASB Panel
③
Lock
⑦
CIB Panel
④
Back Panel

8
①
Display
③
Wheels
②
Bottom cable entry
④
Fastening stands
Top view
Bottom view

9
Front view –door open
Power Modules inserted
Front view –door open
Power Modules extracted and respective blanking
plates removed
①
Power Module 15/25kW (PM15X/PM25X)
④
Connectivity Panel (CP)
②
Bypass Module (BM)
⑤
Backplane: Power and communications interface
connections between the PM and the cabinet
③
Manual Bypass switch (SWMB)

10
Rear view
Without the signal board panels
Rear view
without the connections cover
①
Auxiliary Signal Board (ASB)
④
Connections cover
②
Relay Slot
⑤
Power connections area
③
Cabinet interface Board (CIB)
(Option)

11
MODULAR COMBO CABINET (CBC 130X)
Front view
Rear view
①
Display
③
Handle with lock
②
Door
④
Back Panel

12
①
Top cable entry
③
Swivel castors for positioning
②
Bottom cable entry
④
Fastening stands
Top view
Bottom view

13
Front view - open door
Power Modules inserted
Front view - open door
Power Modules extracted and respective blanking
plates removed
①
Power Module (PM)
⑤
Battery Unit
②
Bypass Module (BM)
⑥
Connectivity Panel (CP)
③
Manual Bypass switch (SWMB)
⑦
Backplane: power and communications interface
connections for the PM
④
Battery Switch (SWBATT)

14
①
Auxiliary Signal Board (ASB)
③
Connections cover
②
Relay Slot
④
Power connections area
Rear view
without rear panel
Rear view
without connections cover

15
PWC 130X USER INTERFACE
①
Connectivity Panel (CP)
④
Communication Slots for housing the expansion
cards
②
Power Supply Unit 1 (PSU 1)
⑤
Cold Start [optional]
③
Power Supply Unit 2 (PSU 2) [optional]
The Connectivity Panel is provided with a network
connection to enable the remote operation of the
system.
The right side of the display is equipped with connection
ports (SA ports) that are reserved for trained service
personnel only. Do not connect to the SA ports without
specific instructions.
NOTE: For further information refer to the chapter “Remote Communication and accessories”

16
CBC 100X USER INTERFACE
①
Main Communication Unit (MCU)
③
Monitoring Unit (MU)
②
Power Supply Units (PSU 1 & 2)
④
Communication Slots for housing the
expansion cards
⑤
Cold Start [optional]
A network connection port is located on one side of the
display to enable the remote operation of the system.
The right side of the display is equipped with
connection ports (SA ports) that are reserved for
trained service personnel only. Do not connect to
the SA ports without specific instructions.
NOTE: For further information refer to the chapter “Remote Communication and accessories”
Unscrew the fastening knobs and remove the protection
cover to access the components within the Connectivity
Panel (CP).

17
OPERATING MODE
MODULAR UPS SYSTEM
A Modular UPS System is intended to ensure a perfect supply voltage for the equipment connected to it, both with and without a
power supply network. Once connected and powered, the system generates an alternating sinusoidal voltage, with stable
amplitude and frequency, regardless of surges and/or variations affecting the electrical supply.
With no mains power, the system will power the load by taking energy from the batteries. When the batteries run out, the system
will switch off. When the mains power is restored, the load will be automatically powered according to the AUTORESTART setting.
The Modular UPS System features three types of cabinets: Modular UPS Power Cabinet, Modular UPS Combo Cabinet and
Modular Battery Cabinet, whose main functions and features will be highlighted within this manual.
The Modular UPS System can operate with different modes:
NORMAL MODE
During the NORMAL MODE, the system operates in On Line double conversion. This mode provides the maximum protection
level for the load, the energy coming from the supply network (AC), is converted in order to provide a clean and stable output. The
voltage supplied to the load is a perfect sine wave, with the frequency and voltage independent of the incoming mains supply (VFI
technology). During this mode, the batteries are constantly maintained in a charged condition.
BATTERY MODE
When the AC power network falls outside the pre-set tolerances, for example, in case of a blackout or voltage or frequency
fluctuation, the system automatically switches to the BATTERY MODE and takes power from the batteries to support the load.
When the AC network is again clean and stable, the system returns back to the NORMAL MODE operation.
The Power Walk-In function can be activated through the configuration software. This function allows, upon reconnection to the
network (following a supply failure), a progressive absorption of power from the incoming supply, in order to avoid stressing (due
to the inrush current) a generator which is installed upstream (if fitted). The duration of the transition mode can be set between 1
to 125 seconds. The default value is 10 seconds (when the function is enabled). During the transition mode the required power is
partially collected from the batteries and partially from the network whilst maintaining a sinusoidal take-up. The battery charger is
switched on again when the transition mode ends.
AUTOMATIC STATIC BYPASS MODE
During this operation mode, the load is directly powered by the AC supply, therefore, any input disturbances will directly affect the
connected load.
ECO MODE
In order to optimise efficiency, in ECO (1) mode, the load is normally powered via bypass (any disturbances that occur within the
supply network can affect the connected load). In the event of a mains power supply failure or if the power supply is not within the
pre-set tolerances, the UPS will switch to normal ON LINE operation with double conversion. Approximately five minutes after the
power supply returns within tolerance, the load is switched back to bypass.
FREQUENCY CONVERTER MODE
The system can be configured in this mode to generate a fixed output frequency different from the input frequency. In this
configuration the bypass line will be automatically disabled.
EFFICIENCY CONTROL MODE
The EFFICIENCY CONTROL mode(1) improves the system overall efficiency, particularly at low loads, while preserving the ON
LINE mode and the configured redundancy level. The PMs that are not required to support the applied load are placed in a low
consumption state. In the event of a mains power supply failure or if the power supply is not within the specified conditions, all of
the PMs switch to normal ON LINE operation with double conversion. If there are any sudden and/or high load increases, the
system continuity is guaranteed with a possible temporary transfer to bypass.
NOTE: The Home Page always displays the active operating mode.
(1) These operating modes can only be selected via the “Expert” user profile (see “Access level selection”)

18
MANUAL BYPASS MODE
Transferring the Modular UPS system into the MANUAL BYPASS MODE must be performed as follows to ensure that power to
the connected load is not lost.
Caution: if the system is in battery mode, operation of the Manual Bypass may disrupt the power to the connected load.
1. Close the Manual Bypass SWMB disconnection switch located behind the door: at this point the input is directly
connected to the output.
2. During this mode of operation, any disturbances or blackouts within the power supply line will impact the connected load
(the Modular UPS Cabinet is no longer active, and the load is directly connected to the mains supply network).
3. The display will show that the system has now been transferred to Manual Bypass.
Transferring the Modular UPS Cabinet from the MANUAL BYPASS MODE to NORMAL MODE must be performed as follows to
ensure that power to the connected load is not lost (perform this only if no anomalies or malfunctions are present and if the system
is operational):
1. Ensure that the Bypass Module (see the “Modules and Units” chapter) is present and switched on.
2. Open the SWMB disconnection switch by rotating the handle anti-clockwise.
3. The Bypass Module will activate and then the entire Modular UPS Cabinet will be switched on.
MODULAR UPS POWER CABINET
The Modular UPS Power Cabinet PWC 130X may contain up to 5 Power Modules (PM15X or PM25X) and one Bypass Module
(BM126X).
PMs are UPSs connected in parallel in order to increase reliability in the supply of power to the connected load and to increase
the power available at the output (ref. to the "Modules and Units" chapters)
The load that can be applied to a Modular UPS Cabinet can be higher than the load that can be sustained by each unit thanks to
automatic power-sharing. Increased reliability is only achieved on condition that the total system power, with one or more PMs
deactivated, remains higher than the demand. This condition is always achieved by adding at least one redundant PM to the
minimum number of elements required to power the load, so that after the automatic exclusion of a faulty PM, the power supply
can continue as required.
Each PM is equipped with a smart control unit, connected through a data bus with the other PMs within the system, achieving a
high reliability distributed logic.
Note: the redundancy level required by the PMs may be set-up during the initial configuration.
The Bypass Module (BM) operates as the central AUTOMATIC BYPASS for the whole Modular UPS Cabinet (ref. to chapter
“Modules and Units”).
In order to further increase the power of the system, multiple Modular UPS Power Cabinets can be connected in parallel, up to 4.
The maximum configuration will therefore be 20 PMs connected in parallel.
WARNING: The SWMB disconnection switch installed within the Modular UPS Cabinet is not a maintenance
bypass switch, therefore, there are dangerous voltages within the Cabinet, even if this disconnection switch
is closed.
CAUTION: Contact a service centre should any malfunctions be detected. Maintenance can be carried out
only by skilled staff authorised by the manufacturer.
CAUTION: dangerous voltages can be present inside the device, even if the input, bypass, output and
battery switches are open.
The removal of any panels from the Modular UPS Cabinet by non-skilled personnel is a source of danger
and may cause damage to the operator, to the equipment and to the load connected to it.

19
A wring diagram of the Modular UPS Power Cabinet is provided below.

20
MODULAR BATTERY CABINET BTC 170
The Modular Battery Cabinet consists of 9 shelves, each of which may contain 4 Battery Units (BU). The BU contains 10 x 12V
batteries (refer to “Modules and Units” chapter).
The Modular Battery Cabinet has an electronic supervision system which, through voltage and current sampling, is able to
measure the condition and any anomaly within each of the Battery Units. The collected data is sent to the system through a data
bus and shown on the display of the Modular UPS Cabinet.
In addition, within the Modular Battery Cabinet there is an SWBATT disconnection switch which enables the BUs to be
disconnected from the Modular UPS Cabinet. The cabinet also features an opto-isolated input which enables the SWBATT switch
to be opened remotely.
CAUTION: each shelf of the Modular Battery Cabinet can be filled (with the 4 BUs) based on the autonomy requirements
of the system (up to a maximum of 9 shelves). The minimum number of fully populated battery shelves must follow the
rules set out in the table below:
Number of non redundant PMs
PM15X
Minimum number of battery shelves
PM25X
Minimum number of battery shelves
1
1
2
2
2
3
3
3
5
4
4
8
..
…
…
N
Nx1
Nx2
Multiple Modular Battery Cabinets, up to 10, can be present within the Modular UPS System.
The wiring diagram of the Modular Battery Cabinet is provided below.
