Schreder INDU BAY GEN3 User manual

INDU BAY GEN3_EM BOX_IS_09-2018
INDU BAY GEN3
Emergency Box
Supplementary Installation Instructions
8
1. Batteries should be stored within the specified temperature range in low humidity conditions.
Optimal storage conditions are: Temperature: -20°C to +35°C Humidity: 45% - 85%
2. Avoid atmosphere with corrosive gas.
3. It is recommended to disconnect the battery before storage or delivery.
4. Battery should be charged once in three months in order to keeping it in initial performance.
5.This product should be installed by a full certified electrician in accordance with local building and electrial codes.
WARNING
IP66 08
220~240 V AC 50/60 Hz
0°C ~ +50°C
5 W
180min
IP66
Operating voltage
Working temperature
3000 mAhBattery capacity
Emergency power
Emergency time
IP rating
1 2
"Click"
Activation
(battery connection)
3
5
Permanent unswitched
AC INPUT
5
PH2
6
Suitable Wire
diameter:
φ5~φ11mm
27
X8
a
b
a
b
N L
N PE Lem
X8
b
a

INDU BAY GEN3_EM BOX_IS_09-2018
8
Moun�ng
LAMP
Pendant installa�on Suspension chain moun�ng
b
15 ± 0.5 Nm
4
a
b
b
Permanent
unswitched
AC INPUT
cd
Switched
AC INPUT
Permanent
unswitched
AC INPUT
Switched
AC INPUT
a
b
c
Test Swich
Test Swich
*EM box electrified state
EM StatusTest Swich
EM OFFDon’t Press
EM ONPress Charging
Battery
Status
Discharging
(Emergency mode)
Green
Light
Indicator LED
Status
OFF
