Schumacher DSR Industrial INC-14825A User manual

00-99-000992/0909
Model / Modelo / Modèle: INC-4825A
Automatic Battery Charger / Cargador de batería automático /
Chargeur de batterie automatique
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.• FAILURE TO DO SO CAN RESULT IN SERIOUS INJURY OR DEATH.
LEA EL MANUAL COMPLETO ANTES DE UTILIZAR ESTE PRODUCTO.• CUALQUIER FALLA PODRÍA RESULTAR EN SERIAS LESIONES O PODRÍA
SER MORTAL.
LIRE ENTIÈREMENT LE GUIDE AVANTD’UTILISER CE PRODUIT.• L’ÉCHEC DE FAIRE AINSI PEUT S’ENSUIVRE DANS LA BLESSURE
SÉRIEUSE OU LA MORT.
OWNER’S MANUAL•
MANUAL DEL USUARIO•
GUIDE D’UTILISATION•
Voltage / Tensión / Tension: 48
Amperage / Amperaje / Ampérage: 15<>25 Cycling

TABLE OF CONTENTS
SECTION PAGE
IMPORTANT SAFETY INSTRUCTIONS 2
PERSONAL PRECAUTIONS 3
PREPARING TO CHARGE 3
CHARGER LOCATION 4
DC CONNECTION PRECAUTIONS 4
FOLLOW THESE PRECAUTIONS WHEN CONNECTING THE BATTERY. 5
BATTERY CHARGING – AC CONNECTIONS 5
FEATURES 6
OPERATING INSTRUCTIONS 6
CALCULATING CHARGE TIME 8
MAINTENANCE INSTRUCTIONS 9
STORAGE INSTRUCTIONS 9
TROUBLESHOOTING 9
BEFORE RETURNING FOR REPAIRS 10
SPECIFICATIONS 10
LIMITED WARRANTY 11
ÍNDICE
SECCIÓN PÀGINA
INSTRUCCIONES IMPORTANTES DE SEGURIDAD 13
PRECAUCIONES PERSONALES 14
PREPARACIÓN PARA LA CARGA 14
UBICACIÓN DEL CARGADOR 15
PRECAUCIONES DE CONEXIÓN EN CC 16
SIGA ESTAS INDICACIONES CUANDO CONECTE LA BATERIA. 16
CARGA DE BATERÍA, CONEXIONES DE CA 16
CARACTERÍSTICAS 17
INSTRUCCIONES DE OPERACIÓN 17
CÁLCULO DE TIEMPO DE CARGA 19

INSTRUCCIONES DE MANTENIMIENTO 20
INSTRUCCIONES DE ALMACENAJE 20
LOCALIZACIÓN Y SOLUCIÓN DE PROBLEMAS 21
ANTES DE DEVOLVER A REPARACIONES 22
ESPECIFICACIONES 22
GARANTÍA LIMITADA 22
TABLE DES MATIÈRES
PARTIE PAGE
CONSIGNES DE SÉCURITÉ IMPORTANTES 25
PRÉCAUTIONS PERSONNELLES 26
PRÉPARATION POUR LE CHARGEMENT 26
EMPLACEMENT DU CHARGEUR 27
PRÉCAUTIONS SUR LA CONNEXION C.C. 28
SUIVRE CES PRÉCAUTIONS EN RACCORDANT LA BATTERIE 28
CHARGEMENT D’UNE BATTERIE – RACCORDEMENTS C.A. 28
CARACTÉRISTIQUES 29
CONSIGNES D’UTILISATION 29
CALCUL DU TEMPS DE CHARGEMENT 31
CONSIGNES D’ENTRETIEN 32
DIRECTIVES D’ENTREPOSAGE 32
TABLEAU DE DÉPANNAGE 33
AVANT DE L’ENVOYER POUR RÉPARATION 33
CARACTÉRISTIQUES 34
GARANTIE LIMITÉE 34

•1 •
IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL.
SAVE THESE INSTRUCTIONS – The INC-4825A offers a wide range
of features to accommodate your needs. This manual will show you how
to use your charger safely and effectively. Please read, understand and
follow these instructions and precautions carefully, as this manual contains
important safety and operating instructions. The safety messages used
throughout this manual contain a signal word, a message and an icon.
The signal word indicates the level of the hazard in a situation.
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury to the operator or
bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury to the operator or
bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in moderate or minor injury to the operator or
bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in damage to the equipment or vehicle or property
damage.
Safety messages in this manual contain two different type styles.
Unnumbered type states the hazard.•
Numbered type states how to avoid the hazard.•
The icon gives a graphical description of the potential hazard.
Pursuant to California Proposition 65, this product contains
chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm.

•2 •
IMPORTANT SAFETY INSTRUCTIONS1.
Riskofelectricshockorre.
Do not expose the charger to rain or snow.1.1
Use only recommended attachments. Use of an attachment not1.2
recommended or sold by Schumacher® Electric Corporation may result in
ariskofre,electricshockorinjurytopersonsordamagetoproperty.
To reduce the risk of damage to the electric plug or cord, pull by the plug1.3
rather than the cord when disconnecting the charger.
An extension cord should not be used unless absolutely necessary. Use of1.4
animproperextensioncordcouldresultinariskofreandelectricshock.
If an extension cord must be used, make sure:
That the pins on the plug of the extension cord are the same number,•
size and shape as those of the plug on the charger.
That the extension cord is properly wired and in good electrical•
condition.
That the wire size is large enough for the AC ampere rating of the•
chargerasspeciedinSection7.
To reduce the risk of electric shock, unplug the charger from the outlet1.5
before attempting any maintenance or cleaning. Simply turning off the
controls will not reduce this risk.
Remove personal metal items such as rings, bracelets, necklaces and1.6
watches when working with a lead-acid battery. A lead-acid battery can
produce a short-circuit current high enough to weld a ring or the like to
metal, causing a severe burn.
Do not operate the charger with a damaged cord or plug; take it to a1.7
qualiedserviceperson.(Callcustomerserviceat:1-800-621-5485.)
Do not operate the charger if it has received a sharp blow, been dropped1.8
orotherwisedamagedinanyway;takeittoaqualiedserviceperson.
(Callcustomerserviceat:1-800-621-5485.)
Donotdisassemblethecharger;takeittoaqualiedservicepersonwhen1.9
service or repair is required. Incorrect reassembly may result in a risk of
reorelectricshock.(Callcustomerserviceat:1-800-621-5485.)

•3 •
PERSONAL PRECAUTIONS2.
Risk of explosive gases.
Working in the vicinity of a lead-acid battery is dangerous. Batteries2.1
generate explosive gases during normal battery operation. For this
reason, it is of utmost importance that you follow the instructions each
time you use the charger.
To reduce the risk of a battery explosion, follow these instructions and2.2
those published by the battery manufacturer and the manufacturer of
any equipment you intend to use in the vicinity of the battery. Review the
cautionary markings on these products and on the engine.
This charger employs parts, such as switches and circuit breakers, that2.3
tend to produce arcs and sparks. If used in a garage, locate this charger
18inchesormoreaboveoorlevel.
NEVERsmokeorallowasparkorameinthevicinityofabatteryor2.4
engine.
Be extra cautious to reduce the risk of dropping a metal tool onto the2.5
battery. It might spark or short-circuit the battery or other electrical part
that may cause an explosion.
Use this charger for charging LEAD-ACID batteries only. It is not intended2.6
to supply power to a low voltage electrical system other than in a starter-
motor application. Do not use this battery charger for charging dry-cell
batteries that are commonly used with home appliances. These batteries
may burst and cause injury to persons and damage to property.
NEVER charge a frozen battery.2.7
NEVER overcharge a battery.2.8
PREPARING TO CHARGE3.
Risk of contact with battery acid. Battery acid
is a highly corrosive sulfuric acid.
Consider having someone close enough by to come to your aid when you3.1
work near a lead-acid battery.
Have plenty of fresh water and soap nearby in case battery acid contacts3.2
your skin, clothing or eyes.
Wear complete eye and body protection, including safety goggles and3.3
protective clothing. Avoid touching your eyes while working near the
battery.
If battery acid contacts your skin or clothing, immediately wash the area3.4
withsoapandwater.Ifacidentersyoureye,immediatelyoodtheeye
with cold running water for at least 10 minutes and get medical attention
right away.

•4 •
If it is necessary to remove the battery from the vehicle to charge3.5
it,alwaysremovethegroundedterminalrst.Makesureallofthe
accessories in the vehicle are off to prevent arcing.
Be sure the area around the battery is well ventilated while the battery is3.6
being charged.
Add distilled water to each cell until the battery acid reaches the level3.7
speciedbythebatterymanufacturer.Donotoverll.Forabatterywithout
removablecellcaps,suchasvalveregulatedleadacidbatteries(VRLA),
carefully follow the manufacturer’s recharging instructions.
Read, understand and follow all instructions for the charger, battery,3.8
vehicle and any equipment used near the battery and charger. Study all
ofthebatterymanufacturer’sspecicprecautionswhilechargingand
recommended rates of charge.
Determine the voltage of the battery by referring to the vehicle owner’s3.9
manual and make sure that the output voltage is correct.
Make sure that the charger cable connector makes tight connections.3.10
CHARGER LOCATION4.
Risk of explosion and contact
with battery acid.
Locate the charger as far away from the battery as the DC cables permit.4.1
Never place the charger directly above the battery being charged; gases4.2
from the battery will corrode and damage the charger.
Do not set the battery on top of the charger.4.3
Never allow battery acid to drip onto the charger when reading the4.4
electrolytespecicgravityorllingthebattery.
Do not operate the charger in a closed-in area or restrict the ventilation in4.5
any way.
DC CONNECTION PRECAUTIONS5.
Connect and disconnect the DC output cables only after setting the5.1
charger switch to the “off” position and removing the AC plug from the
electrical outlet.

•5 •
FOLLOW THESE PRECAUTIONS WHEN CONNECTING THE6.
BATTERY.
A spark near the battery may
cause a battery explosion. To
reduce the risk of a spark near
the battery:
Position the AC and DC cables to reduce the risk of damage by the hood,6.1
door and moving or hot engine parts. NOTE: If it is necessary to close the
hood during the charging process, ensure that the hood does not touch
the metal part of the battery clips or cut the insulation of the cables.
Stay clear of fan blades, belts, pulleys and other parts that can cause6.2
injury.
When disconnecting the charger, turn the switch to off, disconnect the AC6.3
cord and then disconnect the charger from the battery.
See CALCULATING CHARGE TIME for length of charge information.6.4
Donotfacethebatterywhenmakingthenalconnection.6.5
When disconnecting the charger, always do so in the reverse order of the6.6
connectingprocedureandbreaktherstconnectionwhileasfaraway
from the battery as practical.
BATTERY CHARGING – AC CONNECTIONS7.
Riskofelectricshockorre.
This battery charger is for use on a nominal 120-volt7.1
circuit and has a grounded plug that looks like the
plug illustrated. The charger must be grounded to
reduce the risk of electric shock. The plug must be
plugged into an outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.Theplugpinsmusttthereceptacle
(outlet).Donotusewithanungroundedsystem.
NOTE: The INC-4825A intermittently draws more than 15 amps of current.
We recommend that you either install a 20 amp circuit or do not run
anything else on the same circuit as the INC-4825A or you may trip the
breaker supplying the AC power.
NeveraltertheACcordorplugprovided–ifitdoesnotttheoutlet,have7.2
apropergroundedoutletinstalledbyaqualiedelectrician.Animproper
connection can result in a risk of an electric shock or electrocution.
NOTE: The use of an adapter plug is not recommended.

•6 •
Recommended minimum AWG size for extension cord:7.3
25 feet long or less - use a 12 gauge extension cord.•
25 feet to 50 feet long - use a 10 gauge extension cord.•
Over 50 feet long - not recommended.•
FEATURES8.
ON/OFF Switch1.
Charging/Charged LED2.
Quick-Connect Connector3.
1
3
2
OPERATING INSTRUCTIONS9.
Automatic Temperature Compensation
The charger adjusts the maximum charge voltage and maximum maintain
voltage based on the ambient air temperature. This permits optimum
charging and safety.
Thermal Runaway
The charger automatically reduces the current if it detects the battery may
be getting too hot. This is a safety precaution.
Charging
Ensure that all of the charger components are in place and in good1.
working condition.
Connect the battery to the charger by connecting the quick-connect2.
connector on the charger output cable to the quick-connect connector
on the battery.
Connect the AC power following the precautions listed in Section 7.3.
Switch the power switch to the ON position to turn the charger on.4.

•7 •
Automatic Charging Mode
When an Automatic Charge is performed, the charger switches to the
MaintainMode(seebelow)automaticallyafterthebatteryischarged.
Aborted Charge
If charging can not be completed normally, charging will abort. When
charging aborts, the charger’s output is shut off, and the CHARGING
(yellow)LEDwillblink.Toresetafteranabortedcharge,eitherdisconnect
the battery or turn off the charger.
Desulfation Mode
If the battery is left discharged for an extended period of time, it could
become sulfated and not accept a normal charge. If the charger detects
a sulfated battery, the charger will switch to a special mode of operation
designed for such batteries. If successful, normal charging will resume
after the battery is desulfated. Desulfation could take 8 to 10 hours. If
desulfationfails,chargingwillabortandtheCHARGING(yellow)LEDwill
blink.
Completion of Charge
ChargecompletionisindicatedbytheCHARGED(green)LED.Whenlit,
the charger has switched to the Maintain Mode of operation.
Maintain Mode (Float-Mode Monitoring)
WhentheCHARGED(green)LEDislit,thechargerhasstartedMaintain
Mode. In this mode, the charger keeps the battery fully charged by
delivering a small current when necessary. If the battery voltage drops
below a preset level, the charger will go back into Charge Mode until the
battery voltage returns to the full charge level, at which point the charger
will return to Maintain Mode.
NOTE: The charger automatically switches between Charge Mode and
MaintainModeasnecessary.TheCHARGED(green)LEDwillcycleon
when the battery is at full charge and off when the voltage drops below
a preset level and the charger goes into Charge Mode. This cycle will
continue,andtheCHARGED(green)LEDwillstayonforlongerperiods
of time as the battery becomes more fully charged.
Power Saving Mode
The charger has an internal relay that switches the power transformer on
and off automatically. This means, that the charger uses very little power
when in standby mode or maintain mode.
General Charging Notes
Fan:Thechargerisdesignedtocontrolitscoolingfanforefcient
operation. Consequentially, it is normal for the fan to start and stop when
maintaining a fully charged battery. Keep the area near the charger clear
ofobstructionstoallowthefantooperateefciently.

•8 •
CALCULATING CHARGE TIME10.
The Hydrometer or Electronic Method
Tondthetimeneededtofullychargeyourbattery,determinethe
battery’s charge level with a hydrometer or electronic Percent-of-Charge
Tester. The following table will help you convert hydrometer readings to
percent of charge values.
SPECIFIC GRAVITY PERCENT OF CHARGE PERCENT OF CHARGE
NEEDED
1.265 100% 0%
1.225 75% 25%
1.155 25% 75%
1.120 0% 100%
WhenyouknowthepercentofchargeandtheAmpHour(AH)ratingof
your battery, you can calculate the approximate time needed to bring your
battery to a full charge.
To convert Reserve Capacity to Amp Hours, divide Reserve Capacity by 2,
and add 16:
Example:
Amp Hour Rating = Reserve Capacity + 16
2
NOTE: The Reserve Capacity can be obtained from the battery
specicationsheetortheowner’smanual.
To calculate the time needed for a charge:
Findthepercentofchargeneeded.(Abatteryat50percentchargethat1.
willbechargedto100percentneedsanother50percent(.50)).
MultiplytheAmpHourRatingbythechargeneeded(.50)anddivideby2.
thechargersetting(17ampsaverage).
Multiply the results by 1.25 and you will have the total time needed, in3.
hours, to bring the battery to full charge.
Add an additional hour for a deep-cycle battery.4.
Example:
Amp Hour Rating x % of charge needed x 1.25 = hours of charge
Charger Setting
100(AHRating)x.50(chargeneeded) x 1.25 = 3.676 hours
17(ChargerSetting)
100 x .50 x 1.25 = 3.676
17
You would need to charge your 100-Ampere Hour Battery for a little more
than 3 hours using the above example.

•9 •
MAINTENANCE INSTRUCTIONS11.
After use and before performing maintenance, turn off, unplug and11.1
disconnectthebatterycharger(seeSections6and7).
Use a dry cloth to wipe all battery corrosion and other dirt or oil from the11.2
terminals, cords, and the charger case.
Ensure that all of the charger components are in place and in good11.3
working condition.
Servicing does not require opening the unit, as there are no user-11.4
serviceable parts.
STORAGE INSTRUCTIONS12.
Store the charger unplugged, in an upright position. The cord will still12.1
conduct electricity until it is unplugged from the outlet.
Storeinside,inacool,dryplace(unlessyou’reusinganon-boardMarine12.2
Charger).
Do not store the clips on the handle, clipped together, on or around metal,12.3
or clipped to cables.
TROUBLESHOOTING13.
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
The charger is making an
audible clicking sound. Battery is defective.
Shorted battery cables or
connector
Power Saving or Maintain
Mode
Have the battery checked.
Circuit breaker cycles when
current draw is too high.
Check for shorted cables
or connector and replace if
necessary.
No problem, this is a normal
condition.
Charger makes a loud
buzz or hum. Transformer laminations vibrate(buzz).
Shorted Diode Assembly or
OutputRectierAssembly
(hum).
No problem, this is a normal
condition.
Have charger checked by a
qualiedtechnician.
CHARGING(yellow)LED
is blinking. Indicates the charger is in abort mode. See “Aborted Charge” in the OPERATING
INSTRUCTIONS Section.
Charger will not turn on
when properly connected. AC outlet is dead.
Poor electrical connection.
Check for open fuse or
circuit breaker supplying AC
outlet.
Check power cord and
extension cord for loose
ttingplug.
The battery is connected
and the charger is on, but
is not charging.
Connector is not making a
good connection. Check for poor connection at battery connector. Make
sure connecting points are
clean.

•10 •
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
The measured current is
much lower than what was
selected.
The charger reached the
maximum voltage and is
reducing the current.
No problem, this is a normal
condition.
BEFORE RETURNING FOR REPAIRS14.
When a charging problem arises, make certain that the battery is capable14.1
of accepting a normal charge. Use a good battery to double check all
connections and the AC outlet for a full 120-volts.
When an UNKNOWN OPERATING PROBLEM arises, please read the14.2
complete manual and call the customer service number for information
that will usually eliminate the need for return.
If the above solutions do not eliminate the problem or for information about troubleshooting
or replacement parts, call toll-free from anywhere in the U.S.A.
1-800-621-5485
7:00 am to 5:00 pm Central Time Monday thru Friday
SPECIFICATIONS15.
Electrical
NominalOperatingVoltage(VAC) 120
InputVoltageRange(VAC) 120 ± 10%
InputCurrent(Amax) 15 A
OutputPower(W) 1200
OutputCurrent(Amax) 25
OutputVoltage(VDCmax./maintain) 61.6 / 52.8
Mechanical
Case Steel with Baked Enamel Finish
Dimensions(inches) 11 L x 9½ W x 10 ¼ H
Weight 40 lbs
Connections
AC Power Input Cable 14 Gauge 9’ with NEMA 5.15 Plug
DC Power Output Adapters 8 Gauge 6’ with Polarized 50 Amp Quick
Connect Connector

•11 •
LIMITED WARRANTY16.
SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS CENTER
DRIVE, MOUNT PROSPECT, IL 60056-2179, MAKES THIS LIMITED
WARRANTY TO THE ORIGINAL RETAIL PURCHASER OF THIS
PRODUCT. THIS LIMITED WARRANTY IS NOT TRANSFERABLE OR
ASSIGNABLE.
SchumacherElectricCorporation(the“Manufacturer”)warrantsthis
battery charger for 1 year from the date of purchase at retail against
defective material or workmanship that may occur under normal use
and care. If your unit is not free from defective material or workmanship,
Manufacturer’s obligation under this warranty is solely to repair or
replace your product with a new or reconditioned unit at the option of
the Manufacturer. It is the obligation of the purchaser to forward the unit,
along with mailing charges prepaid to the Manufacturer or its authorized
representatives in order for repair or replacement to occur.
Manufacturer does not provide any warranty for any accessories used
with this product that are not manufactured by Schumacher Electric
Corporation and approved for use with this product. This Limited Warranty
is void if the product is misused, subjected to careless handling, repaired,
ormodiedbyanyoneotherthanManufacturerorifthisunitisresold
through an unauthorized retailer.
Manufacturer makes no other warranties, including, but not limited to,
express, implied or statutory warranties, including without limitation,
anyimpliedwarrantyofmerchantabilityorimpliedwarrantyoftness
for a particular purpose. Further, Manufacturer shall not be liable for
any incidental, special or consequential damage claims incurred by
purchasers, users or others associated with this product, including, but not
limitedto,lostprots,revenues,anticipatedsales,businessopportunities,
goodwill, business interruption and any other injury or damage. Any and
all such warranties, other than the limited warranty included herein, are
hereby expressly disclaimed and excluded. Some states do not allow the
exclusion or limitation of incidental or consequential damages or length
of implied warranty, so the above limitations or exclusions may not apply
toyou.Thiswarrantygivesyouspeciclegalrightsanditispossibleyou
may have other rights which vary from this warranty.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS LIMITED
WARRANTY AND THE MANUFACTURER NEITHER ASSUMES
OR AUTHORIZES ANYONE TO ASSUME OR MAKE ANY OTHER
OBLIGATION TOWARDS THE PRODUCT OTHER THAN THIS
WARRANTY.
Schumacher Electric Corporation Customer Service
1-800-621-5485
Monday – Friday 7:00 a.m. to 5:00 p.m. CST
Schumacher and the Schumacher Logo are registered trademarks of
Schumacher Electric Corporation

•12 •
IMPORTANTE: LEA Y GUARDE ESTE MANUAL DE INSTRUCCIONES Y
SEGURIDAD.
GUARDE ESTAS INSTRUCCIONES: El INC-4825A ofrece una amplia
gama de características para satisfacer sus necesidades. Este manual
le mostrará cómo utilizar su cargador en forma segura y efectiva.
Por favor, lea, comprenda y siga estas instrucciones y precauciones
cuidadosamente, ya que este manual contiene instrucciones operativas y
de seguridad de importancia. Los mensajes de seguridad representados
enestemanualcontienenpalabrasguía,unmensajeyunagura.
La palabra guía indica el nivel de peligro en determinada situación.
Indica una inminente situación de riesgo que, si no se evita,
resultaría mortal o de serios perjuicios al operador o personas
alrededor.
Indica una situación potencialmente riesgoso que, si no se
evita, podría resultar o de serios perjuicios al operador o
personas alrededor.
Indica una situación potencialmente peligrosa que, de no
evitarse, podría resultar en menores o serio daños al usuario y
terceras personas.
Indica una situación potencialmente peligrosa que, de
no evitarse, podría causar daño al equipo, al vehículo y
propiedades alrededor.
Los mensajes estipulados en este manual se describen dos tipos de
estilo.
Los que aparecen sin número indican el riesgo.•
Aquellos que aparecen numerados, indican cómo evitar los riesgos.•
Laguramuestraunadescripcióngrácadelpotencialderiesgo.
Conforme a la propuesta 65 de California, este producto
contiene químicos de los cuales en el Estado de California se
tiene conocimiento que provocan cáncer y malformaciones
congénitas u otras lesiones reproductivas.
PELIGRO
ADVERTENCIA
ATENCIÓN
IMPORTANTE
ADVERTENCIA

•13 •
INSTRUCCIONES IMPORTANTES DE SEGURIDAD1.
El riesgo de descarga eléctrica o incendio
No exponga el cargador a la lluvia o a la nieve.1.1
Utilice solamente accesorios recomendados. El uso de un accesorio no1.2
recomendado o suministrado por Schumacher® Electric Corporation
puede provocar riesgo de incendio, descarga eléctrica o lesiones a
personas o daño a la propiedad.
Para reducir el riesgo de daños al enchufe o cable eléctrico, jale del1.3
enchufe en lugar de jalar del cable al desconectar el cargador.
No se debe utilizar un alargador a menos que resulte absolutamente1.4
necesario. El uso de un alargador inadecuado puede provocar riesgo
de incendio o descarga eléctrica. En caso de que deba utilizarse un
alargador, asegúrese de que:
Los pasadores en el enchufe del alargador posean el mismo número,•
tamaño y forma que aquellos presentes en el enchufe del cargador.
El alargador se encuentre correctamente conectado y en buenas•
condiciones eléctricas.
Eltamañodelcablesealosucientementeextensoparaelamperaje•
enCAdelcargadorcomoseespecicaenlaSección7.
Para reducir el riesgo de descarga eléctrica, desenchufe el cargador1.5
del tomacorriente antes de intentar llevar a cabo cualquier actividad de
mantenimiento o limpieza. El simple apagado de los controles no reducirá
este riesgo.
No utilice elementos personales de metal tales como anillos, pulseras,1.6
collares y relojes al trabajar con una batería de plomo-ácido. Una
batería de plomo-ácido puede producir una corriente de cortocircuito lo
sucientementeelevadacomoparasoldarunanillooprovocarefectos
similares sobre el metal, causando una quemadura de gravedad.
No utilice el cargador si el mismo posee un enchufe o cable dañado;1.7
hágalo revisar por una persona capacitada que efectúe reparaciones.
(Comuníqueseconelservicioalclienteal:1-800-621-5485.)
No utilice el cargador si el mismo recibió un golpe fuerte, si se cayó o1.8
si sufrió daños de cualquier otra forma; hágalo revisar por una persona
capacitadaqueefectúereparaciones.(Comuníqueseconelservicioal
clienteal:1-800-621-5485.)
No desarme el cargador; hágalo revisar por una persona capacitada que1.9
efectúe reparaciones cuando necesite servicio de mantenimiento o una
reparación. Volver a ensamblar el cargador en forma incorrecta puede
provocarriesgodeincendioodescargaeléctrica.(Comuníqueseconel
servicioalclienteal:1-800-621-5485.)

•14 •
PRECAUCIONES PERSONALES2.
Riesgo de gases explosivos.
Resulta peligroso trabajar en forma cercana a una batería de plomo. Las2.1
baterías generan gases explosivos durante su normal funcionamiento. Por
este motivo, resulta de suma importancia que siga las instrucciones cada
vez que utiliza el cargador.
Para reducir el riesgo de explosión de una batería, siga estas2.2
instrucciones y aquellas publicadas por el fabricante de la batería y por el
fabricante de cualquier equipo que intente utilizar en la proximidad de la
batería. Revise las pautas de precaución en estos productos y en el
motor.
Este cargador está equipado con partes, tales como, interruptores y2.3
cortacircuitos, que tienden a originar chispas y cortos. Si se utiliza en la
cochera, utilice el cargador 18 pulgadas o más del nivel del suelo.
NUNCA fume o permita la presencia de chispas o llamas en la proximidad2.4
de una batería o motor.
Tenga especial cuidado para reducir el riesgo de dejar caer una2.5
herramienta de metal sobre la batería. Esto podría provocar chispas o un
cortocircuito en la batería o en cualquier otra pieza eléctrica que podría
provocar una explosión.
Utilice este cargador solamente para cargar baterías de PLOMO-ÁCIDO.2.6
Este cargador no está destinado a suministrar energía a sistemas
eléctricos de baja tensión más que en una aplicación de un motor de
arranque. No utilice este cargador de batería para cargar baterías de
pila seca que por lo general se utilizan con artefactos domésticos. Estas
baterías podrían explotar y provocar lesiones a personas o daño a la
propiedad.
NUNCA cargue una batería congelada.2.7
NUNCA sobrecargue una batería.2.8
PREPARACIÓN PARA LA CARGA3.
Riesgo de contacto con el ácido de la batería.
El ácido de la batería es un ácido sulfúrico
altamente corrosivo.
Considere la idea de que alguna persona se encuentre cerca suyo para3.1
poder ayudarlo cuando trabaje en forma cercana a una batería de plomo-
ácido.
Cuente con una gran cantidad de agua potable y jabón a mano en caso3.2
de que el ácido de la batería tenga contacto con su piel, ropa u ojos.

•15 •
Utilice protección visual y corporal completa, incluyendo gafas de3.3
seguridad y prendas de protección. Evite tocar sus ojos mientras trabaje
en forma cercana a la batería.
Si el ácido de la batería tiene contacto con su piel o su ropa, lave de3.4
inmediato el área afectada con agua y jabón. En caso de que ingrese
ácido en un ojo, sumerja el mismo de inmediato bajo agua potable
corriente por al menos 10 minutos y obtenga atención médica en forma
inmediata.
Si resulta necesario extraer la batería del vehículo para cargarla, siempre3.5
retire el terminal con descarga a tierra en primer lugar. Asegúrese de que
todos los accesorios en el vehículo se encuentren apagados para evitar la
formación de arcos eléctricos.
Asegúrese de que el área que rodea a la batería se encuentre bien3.6
ventilada mientras se carga la batería.
Agregue agua destilada a cada pila hasta que el ácido de la batería3.7
alcanceelnivelespecicadoporelfabricantedelabatería.Noprovoque
derrames. En lo que concierne a baterías que no cuentan con tapas
extraíbles para pilas, tales como baterías de plomo-ácido reguladas
porválvulas(VRLA,porsussiglaseninglés),sigacuidadosamentelas
instrucciones de recarga del fabricante.
Lea, comprenda y siga todas las instrucciones para el cargador, la3.8
batería, el vehículo y cualquier equipo que se utilice cerca de la batería
yelcargador.Controletodaslasprecaucionesespecícasestablecidas
por el fabricante de la batería al realizar la carga, así también como los
índices de carga recomendados.
Determine la tensión de la batería al consultar el manual del usuario del3.9
vehículo y asegúrese de que la tensión de salida se correcta.
Asegúrese de que el conector del cable del cargador se encuentré3.10
fuertemente conectados.
UBICACIÓN DEL CARGADOR4.
Riesgo de contacto con el ácido
de la batería.
Ubique el cargador a la mayor distancia posible de la batería como lo4.1
permitan los cables de CC.
Nunca ubique el cargador directamente por encima de la batería que se4.2
carga; los gases de la batería corroerán y dañarán el cargador.
No ubique la batería encima del cargador.4.3
Nunca permita que el ácido de la batería gotee sobre el cargador al leer el4.4
pesoespecícodelelectrolitooalcargarlabatería.
No utilice el cargador en un área cerrada o restrinja la ventilación en4.5
cualquier forma.

•16 •
PRECAUCIONES DE CONEXIÓN EN CC5.
Antes de Conectar y desconectar los cables de salida de CC, el selector5.1
delcargadordebeestarenlaposiciónOff(apagado)ylaconexióndeCA,
desconetada de la toma de corriente.
SIGA ESTAS INDICACIONES CUANDO CONECTE LA BATERIA.6.
Una chispa provocada cerca
de la batería puede causar la
explosión de la batería. Para
reducir el riesgo de provocar
chispas cerca de la batería:
Ubique los cables de CA y CC para reducir el riesgo de daños a la6.1
cubierta, a la puerta y a las piezas móviles o calientes del motor. NOTA:
Si es necesario cerrar el cofre durante el proceso de carga, asegúrese
que el cofre no toque parte metálica de la batería o pele los cables.
Manténgase alejado de las paletas del ventilador, correas, poleas y otras6.2
piezas que podrían provocar lesiones.
Cuando desconecte el cargador, sitúe el selector a la posición OFF6.3
(apagado),desconecteelcabledeCAyentoncesdesconecteelcargador
de la batería.
Ver la sección CÁLCULO DEL TIEMPO DE CARGA por la información6.4
sobre la duración de carga.
Noseubiqueenposiciónfrontalalabateríaalrealizarlaconexiónnal.6.5
Al desconectar el cargador, siempre hágalo en forma inversa al6.6
procedimiento de conexión y realice la primera conexión tan lejos de la
batería como sea posible.
CARGA DE BATERÍA, CONEXIONES DE CA7.
El riesgo de descarga eléctrica o incendio
Este cargador de batería está destinado a un uso7.1
en un circuito con tensión nominal de 120 V y
posee un enchufe con descarga a tierra que luce
como el enchufe ilustrado. El cargador debe poseer
una descarga a tierra para reducir el riesgo de
descargas eléctricas. El enchufe se debe conectar
a un tomacorriente adecuadamente instalado y que
cuente con descarga a tierra de acuerdo con todas
las ordenanzas y códigos. Los pasadores del enchufe
debenadaptarsealreceptáculo(tomacorriente).No
utilizar con un sistema que no posea descarga a tierra.
