SCHUNK AGE-F-XY Series User instructions

Original Operating Manual
Assembly and Operating Manual
AGE-F-XY
Compensation unit with spring return

Imprint
2
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389002
Version: 03.00|24/06/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of contents
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
3
Table of contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Applicable documents ..............................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
1.4 Accessories ........................................................................................................... 6
1.4.1 Sensors .....................................................................................................6
2 Basic safety notes ................................................................................................... 7
2.1 Intended use......................................................................................................... 7
2.2 Not intended use.................................................................................................. 7
2.3 Constructional changes ........................................................................................ 7
2.4 Spare parts ........................................................................................................... 7
2.5 Ambient conditions and operating conditions .....................................................8
2.6 Personnel qualification......................................................................................... 8
2.7 Personal protective equipment............................................................................ 9
2.8 Notes on safe operation ....................................................................................... 9
2.9 Transport .............................................................................................................. 9
2.10 Malfunctions....................................................................................................... 10
2.11 Disposal .............................................................................................................. 10
2.12 Fundamental dangers......................................................................................... 10
2.12.1 Protection during commissioning and operation ...................................11
2.12.2 Protection during handling and assembly ..............................................11
3 Technical data.........................................................................................................12
4 Assembly and settings ............................................................................................13
4.1 Assembly example.............................................................................................. 13
4.2 Mechanical connection ...................................................................................... 14
4.3 Setting the stop in order to limit stroke ............................................................. 15
4.4 Adjusting, removing and replacing the return spring for units built before June
2016.................................................................................................................... 16
4.5 Adjusting, removing and replacing the return spring for units built in or after
June 2016 ........................................................................................................... 18
4.6 Programmable magnetic switch (MMS-P).......................................................... 19
5 Troubleshooting .....................................................................................................21
5.1 Module does not move?..................................................................................... 21
5.2 Magnetic switch (MMS) does not work / cannot be adjusted ........................... 21

Table of contents
4
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
6 Maintenance ..........................................................................................................22
6.1 Maintenance interval ......................................................................................... 22
6.2 Lubricants/Lubrication points (basic lubrication) .............................................. 22
6.3 Disassemble the module .................................................................................... 22
6.4 Maintaining and assembling the module ........................................................... 23
6.5 Assembly drawing............................................................................................... 24

General
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}6] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.

General
6
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
1.1.2 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• Assembly and operating manuals of the accessories *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the specified maintenance and lubrication intervals
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• Compensation unit AGE-F-XY in the version ordered
• Assembly and Operating Manual
• Accessory pack
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Sensors
Overview of the compatible sensors
Designation Type
Programmable magnetic switch MMS22
• Exact type designation of the compatible sensors see catalog.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.

Basic safety notes
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
7
2 Basic safety notes
2.1 Intended use
The product is designed for the mechanical setting and saving of a
positioning point for workpieces and other devices .
• The product may only be used within the scope of its technical
data, Technical data [}12].
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.

Basic safety notes
8
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
• Make sure that the product is used only in the context of its
defined application parameters, Technical data [}12].
• Make sure that the product is a sufficient size for the
application.
• Make sure that the environment is free from splash water and
vapors as well as from abrasion or processing dust. Exceptions
are products that are designed especially for contaminated
environments.
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.

Basic safety notes
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
9
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.

Basic safety notes
10
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.
• The operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
• While paying attention to the actual conditions of the working
environment, the potential equalisation must be implemented
by a specialist electrician according to the applicable
regulations.
• The effectiveness of the potential equalisation must be verified
by executing regular safety measurements.

Basic safety notes
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
11
WARNING
Risk of injury due to uncontrolled movements!
Due to faulty control the product can move uncontrolled and
cause serious injuries.
•Do not reach into the movement range of the product during
commissioning, conversion and adjustment work.
•Observe the direction of rotation of the product when
designing the control.
2.12.1 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
2.12.2 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.

Technical data
12
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
3 Technical data
Size 31 40 63 80
Recommended workpiece weight [kg] 1.5 4.0 12.5 32.3
Max. payload / load capacity F pull [N] 100 200 300 2800
Max. payload / load capacity F pressure
[N]
200 500 3000 12000
Weight [kg] 0.123 0.23 0.78 3.13
Max. reset force [N]
Version - 1
Version - 2
Version - 3
3.5
5.5
7.0
5.0
7.0
9.0
25.0
38.0
55.0
70.0
130.0
150.0
Ambient temperature [°C]
Min.
Max.
5
80
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Assembly and settings
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
13
4 Assembly and settings
4.1 Assembly example
Assembly on the robot arm
1 Robot arm 3 Mounting screws for adapter
plate
2 Adapter plate with interface
according to DIN 9409
(optionally to be provided by
SCHUNK or by the customer)
4 AGE-F-XY compensation
element
5 Handling device, e.g. gripper
6 Mounting screws for gripper
• An interface plate with a hole pattern for locating holes is
optionally available.
• The adapter plate is screwed with the robot and AGE-F-XY (see
catalog for mounting data).
• The handling device is fastened directly to the AGE-F-XY.
• The pneumatic connection and electric cables are fastened,
bundled, and mounted with strain relief so that the greatest
possible freedom of movement is available during use.

Assembly and settings
14
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
4.2 Mechanical connection
WARNING
Breakage due to faulty assembly possible!
Observe max. screw-in depth on robot-side and on tool-side.
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
Mounting
Possibilities of assembly
Mounting material
Item Mounting
AGE-F-XY
31 40 63 80
Y Thread diameter and
max. screw-in depth Y tool-side [mm]
M2,5x7 M3x8 M4x8 M5/
M6x10
X Thread diameter and
max. screw-in depth X tool-side [mm]
M3x5 M3x5 M5/M6x9 M8x12/2
0
Z Max. srew-in depth Z, robot-side [mm] 6 6 9 13
31 DIN 4762 cylindrical screw
Tightening torque [Nm]
M2,5
0,75
M3
1,27
M5
5,9
M8
24,6
Diameter of the cylindrical pins
for mounting the module [mm]
Ø2 Ø3 Ø4 Ø6
ØUse two cylindrical pins to fasten the module via the provided
fixing holes.
ØTighten the mounting screws (31) using an Allen key.

Assembly and settings
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
15
4.3 Setting the stop in order to limit stroke
Set-screw (52) to limit stroke for type AGE-F-XY-40
Set-screw (52) to limit stroke for types AGE-F-XY-63/80
Dimensions of set-screw (52)
Item Designation
AGE-F-XY
40 63 80
52 Thread diameter M3 M4 M4
Minimum length [mm] 12 12 18

Assembly and settings
16
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
Insert set-screw or
screw
NOTICE
The set-screw can fall into the housing if it is screwed in too far.
The compensation unit can jam.
•Observe the minimum length of the set-screw!
ØRemove the set-screw (52) using a hexagon socket wrench.
NOTE
There is no stroke limitation with AGE-F-XY 31.
4.4 Adjusting, removing and replacing the return spring for units
built before June 2016
The unit contains
4 compression springs for the return position function. The units
are set ex-works in accordance with the catalog values.
Adjustment These force values can be slightly changed on the unit by adjusting
the set-screws (50).
NOTE
If the set-screws are screwed in too far, this will cause the unit to
jam (springs on block). This can be determined if the unit can no
longer perform the complete stroke or no longer moves
Setting dimension X
see table
Setting dimension for the set-screw

Assembly and settings
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
17
The units are delivered ex-works with the following setting
dimensions for the set-screws:
Size 31 40 63 80
Setting dimension for
Version 1 [mm]
10+0.2 13.5+0.2 17.7+0.2 18.5+0.2
Setting dimension for
Version 2 [mm]
10+0.2 12.5+0.2 17.2+0.2 18.5+0.2
Setting dimension for
Version 3 [mm]
9.3+0.2 12.5+0.2 15.2+0.2 18.5+0.2
The catalog values have been ascertained in this basic setting.
Removing / Replacing Position of the item numbers Assembly drawing [}24]:
ØRemove the set-screws (50).
ØRemove the spring sleeve (4) and take out the springs (15).
As standard, three springs are available for each size. Special
springs on request.
The new springs are assembled in the reverse order.
Ensure lubrication is correct Lubricants/Lubrication points (basic
lubrication) [}22].

Assembly and settings
18
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
4.5 Adjusting, removing and replacing the return spring for units
built in or after June 2016
The unit contains 4compression springs for the return position
function.
The force values on the unit can not be changed anymore (applies
to units delivered since June 2016).
Replacing springs
Removing / Replacing Position of the item numbers Assembly drawing [}24]:
ØRemove the set-screws (50).
ØRemove the spring sleeve (4) and take out the springs (15).
As standard, three springs are available for each size. Special
springs on request.
The new springs are assembled in the reverse order.
Ensure lubrication is correct. Lubricants/Lubrication points (basic
lubrication) [}22]

Assembly and settings
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
19
4.6 Programmable magnetic switch (MMS-P)
Magnetic switch MMS 22
brown
black
blue
load closer
Connection diagram
NOTICE
Risk of damage to the sensor during assembly.
•Observe a maximum tightening torque of 10 Ncm for the set-
screws.
NOTE
Ferromagnetic material changes the switching positions of the
sensor. For example: Adapter plate made of ordinary steel.
At ferromagnetic adapter plates:
• First mount the product on the adapter plate.
• Then set the position of the magnetic switch.
NOTE
• Do not use the sensor as a safety component.
• Do not pull on the cable of the sensor.
• Secure the cable and connection plug so that they are not
taught and cannot move during operation.
• Do not exceed the permitted bending radius of the cable.
• Do not allow the sensor to come into contact with hard objects
and chemicals (e.g., nitric acid, chromic acid and sulfuric acid).

Assembly and settings
20
03.00 | AGE-F-XY | Assembly and Operating Manual | en | 389002
Position of the magnetic switch MMS - stop position (A)
The magnetic switches MMS are mounted and adjusted equally for
each axis movement:
Assembly steps
ØScrew in the sensor
OR
insert the sensor axially into the groove until the required signal
is present.
ØLock sensor into place using an Allen key.
