SCHUNK ELM Series User instructions

Translation of the original manual
Assembly and operating manual
ELM
Linear axis

Imprint
2
02.00 | ELM | Assembly and operating manual | en | 389058
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389058
Version: 02.00|24/06/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of contents
02.00 | ELM | Assembly and operating manual | en | 389058
3
Table of contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Presentation of Warning Labels ...............................................................5
1.1.2 Applicable documents ..............................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Scope of delivery .................................................................................................. 6
1.4 Accessories ........................................................................................................... 6
1.4.1 Cable set ...................................................................................................6
1.4.2 Drive controller.........................................................................................7
1.4.3 Power supply unit.....................................................................................7
1.4.4 Position measuring systems .....................................................................7
1.4.5 Weight compensation ..............................................................................7
1.4.6 Hydraulic shock absorbers........................................................................7
1.4.7 Anti-fall device..........................................................................................8
1.4.8 Fan cooling................................................................................................8
1.4.9 Cover.........................................................................................................8
2 Basic safety notes ................................................................................................... 9
2.1 Intended use......................................................................................................... 9
2.2 Not intended use.................................................................................................. 9
2.3 Constructional changes ........................................................................................ 9
2.4 Spare parts ........................................................................................................... 9
2.5 Ambient conditions and operating conditions .....................................................9
2.6 Personnel qualification....................................................................................... 10
2.7 Personal protective equipment.......................................................................... 10
2.8 Notes on safe operation .....................................................................................11
2.9 Transport ............................................................................................................ 11
2.10 Malfunctions....................................................................................................... 11
2.11 Disposal .............................................................................................................. 12
2.12 Fundamental dangers......................................................................................... 12
2.12.1 Protection during handling and assembly ..............................................12
2.12.2 Protection during commissioning and operation ...................................13
2.12.3 Protection against dangerous movements.............................................13
2.13 Notes on particular risks..................................................................................... 14
3 Technical data.........................................................................................................16
3.1 Basic version....................................................................................................... 16
3.2 Option with anti-fall device (deviating data)...................................................... 17
3.3 Fan cooling ......................................................................................................... 17
3.4 Weight compensation ........................................................................................ 17

Table of contents
4
02.00 | ELM | Assembly and operating manual | en | 389058
4 Assembly ................................................................................................................18
4.1 Connections........................................................................................................ 18
4.1.1 Mechanical connection...........................................................................18
4.1.2 Air connections.......................................................................................20
4.1.3 Electrical connection ..............................................................................20
4.2 Assembly of position measuring system WSM................................................... 21
4.3 Mounting of weight compensation GA .............................................................. 22
4.3.1 Weight compensation GA 23..................................................................22
4.3.2 Weight compensation GA 37..................................................................23
4.4 Mounting of shock absorbers SD........................................................................ 24
4.5 Mounting of anti-fall device ASP ........................................................................ 25
4.6 Mounting of fan cooling MK............................................................................... 27
4.7 Mounting of cover MA ....................................................................................... 28
5 Troubleshooting .....................................................................................................29
5.1 Modul bewegt sich nicht? .................................................................................. 29
5.2 The module does not travel through the entire stroke? .................................... 29
5.3 Electric signals are not transmitted? .................................................................29
5.4 Motor temperature too high? ............................................................................ 29
5.5 Required speed is not reached? ......................................................................... 30
5.6 Required precision is not reached...................................................................... 30
6 Maintenance and care ............................................................................................31
6.1 Maintenance and lubrication intervals............................................................... 31
6.2 Lubricants / lubrication points (basic lubrication).............................................. 32
6.3 Removing and cleaning rotor ............................................................................. 33
6.4 Dismantling the module ..................................................................................... 34
6.5 Assembly drawings ............................................................................................. 35
6.5.1 Assembly of ELM 23................................................................................35
6.5.2 Assembly of ELM 37................................................................................36
7 Translation of original declaration of incorporation ................................................37
7.1 Annex to Declaration of Incorporation............................................................... 38

General
02.00 | ELM | Assembly and operating manual | en | 389058
5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}6] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
NOTICE
Material damage!
Information about avoiding material damage.

General
6
02.00 | ELM | Assembly and operating manual | en | 389058
1.1.2 Applicable documents
• General terms of business*
• Catalog data sheet of the purchased product *
• Assembly and operating manuals of the accessories *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the specified maintenance and lubrication intervals
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• Linear axis ELM in the version ordered
• Assembly and Operating Manual
• Accessory pack
1.4 Accessories
The following accessories are required for the module:
• Cable set Cable set [}6]
• Drive controllerDrive controller [}7]
• Power supply unit Power supply unit [}7]
Order accessories separately.
For further accessories
• Position measuring systems Position measuring systems [}7]
• Weight compensation Weight compensation [}7]
• Hydraulic shock absorbers Hydraulic shock absorbers [}7]
• Anti-fall device Anti-fall device [}8]
• Fan cooling Fan cooling [}8]
• Cover Cover [}8]
1.4.1 Cable set
Cables must be designed for the module and the drive controller
used.
For design, exact type designations and order numbers, consult
your SCHUNK contact person

General
02.00 | ELM | Assembly and operating manual | en | 389058
7
1.4.2 Drive controller
The drive controller must be designed for the module and the
application
For design, exact type designations and order numbers, consult
your SCHUNK contact person
1.4.3 Power supply unit
The power supply unit must be designed for the module and the
application.
For design, exact type designations and order numbers, consult
your SCHUNK contact person
1.4.4 Position measuring systems
To increase positioning accuracy
Designation Type / ID
Position measuring system for
ELM 23-70
WSM 23-070 / 0314112
Position measuring system for
ELM 37-160
WSM 37-160 / 0314113
Position measuring system for
ELM 37-260
WSM 37-260 / 0314114
1.4.5 Weight compensation
For compensation of the slide weight and additional load in case of
vertical use.
Designation Type / ID
Weight compensation for ELM 23-70 GA 23-70 / 0314235
Weight compensation for ELM 37-160 GA 37-160 / 0314236
Weight compensation for ELM 37-260 GA 37-260 / 0314237
1.4.6 Hydraulic shock absorbers
To prevent damage in case of malfunctions.
Designation Type / ID
Hydraulic shock absorbers for ELM 23 SD 23 / 0314262
Hydraulic shock absorbers for ELM 37 SD 37 / 0314263

General
8
02.00 | ELM | Assembly and operating manual | en | 389058
1.4.7 Anti-fall device
NOTICE
Damage to the rod lock due to incorrect actuation / overload!
•The rod lock may only be triggered and unlocked when the
product has been shut down.
•See the data on static holding force in the catalog. The forces
occurring in a clamped condition must not exceed the holding
force.
•In the event of a dynamic load or overload (e.g. drop in
pressure during movement), the clamping cartridge must be
checked and replaced if necessary.
WARNING
The rod lock is not a safety component for personal protection
in the sense of the Machine Directive.
The module is optionally available with a rod lock to prevent
mechanical damage in the event of malfunctions.
Description Type / ID
Rod lock for ELM 23-70 ASP-E 23-070 / 0314350
Rod lock for ELM 37-160 ASP-E 37-160 / 0314351
Rod lock for ELM 37-260 ASP-E 37 -260 / 0314352
1.4.8 Fan cooling
To increase the constant force in case of higher power con-
sumption.
Alternatively, cooling by means of compressed air is possi-ble, via
the connection provided. Air connections [}20]
Designation Typ / ID
Fan cooling for ELM 23 MK 23 / 0314241
Fan cooling for ELM 37 MK 37 / 0314242
1.4.9 Cover
For routing of electric wires and pneumatic hoses
Designation Typ / ID
Cover for ELM 23-70 MA 23-70 / 0314238
Cover for ELM 37-160 MA 37-160 / 0314239
Cover for ELM 37-260 MA 37-260 / 0314240

Basic safety notes
02.00 | ELM | Assembly and operating manual | en | 389058
9
2 Basic safety notes
2.1 Intended use
The product is exclusively designed for linear movement of useful
loads into any desired position.
• The product may only be used within the scope of its technical
data, Technical data [}16].
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
It is not intended use if the product is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
• Make sure that the product is used only in the context of its
defined application parameters, Technical data [}16].

Basic safety notes
10
02.00 | ELM | Assembly and operating manual | en | 389058
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.

Basic safety notes
02.00 | ELM | Assembly and operating manual | en | 389058
11
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.

Basic safety notes
12
02.00 | ELM | Assembly and operating manual | en | 389058
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.

Basic safety notes
02.00 | ELM | Assembly and operating manual | en | 389058
13
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.
2.12.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
• The faulty actuation of conected drives may cause dangerous
movements.
• Operating mistakes, faulty parameterization during
commissioning or software errors may trigger dangerous
movements.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum possible
movement energy. EMERGENCY STOP switches must be easily
and quickly accessible. Before starting up the machine or
automated system, check that the EMERGENCY STOP system is
working. Prevent operation of the machine if this protective
equipment does not function correctly.

Basic safety notes
14
02.00 | ELM | Assembly and operating manual | en | 389058
2.13 Notes on particular risks
DANGER
Danger to life due to strong magnetic fields even in a shut-down
state.
The integrated high performance permanent magnets can
represent a risk to persons with an active or passive implant. The
following persons are not allowed to remain in the vicinity of the
magnetic field:
•Persons with pacemakers
•Persons with metal or electronic prostheses
•Persons with insulin pumps
•Persons with muscular stimulation systems.
•Persons with deaf-aids
•Pregnant women.
•The above mentioned persons must always keep a safe
distance of at least 2 m from the product.
DANGER
Danger from electric voltage!
Touching live parts may result in death.
•Switch off the power supply before any assembly, adjustment
or maintenance work and secure against being switched on
again.
•Only qualified electricians may perform electrical installations.
•Check if de-energized, ground it and hot-wire.
•Cover live parts.
DANGER
Risk of fatal injury from suspended loads!
Falling loads can cause serious injuries and even death.
•Stand clear of suspended loads and do not step within their
swiveling range.
•Never move loads without supervision.
•Do not leave suspended loads unattended.
•Wear suitable protective equipment.

Basic safety notes
02.00 | ELM | Assembly and operating manual | en | 389058
15
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
•Take appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
•Before starting any work on the product: Switch off the power
supply and secure against restarting.
•Make sure, that no residual energy remains in the system.
WARNING
Risk of injury from sharp edges and corners!
Sharp edges and corners can cause cuts.
•Use suitable protective equipment.
WARNING
Risk of burns through contact with hot surfaces!
The product can heat up considerably during operation. Touching
hot surfaces can cause burns.
•Do not touch hot surfaces.
•Let them cool down before working on the product.
•Wear appropriate safety equipment.
WARNING
Risk of injury from objects falling during energy supply failure!
Electronic devices are not fail-safe. In case of an energy supply
failure, the gripping force decreases. As a consequence, it cannot
be guaranteed that the workpiece is held safely.
•In case of an energy supply failure, it is the user's
responsibility to revert the drive into a safe state.

Technical data
16
02.00 | ELM | Assembly and operating manual | en | 389058
3 Technical data
More technical data is included in the catalog data sheet.
Whichever is the latest version.
3.1 Basic version
ELM 23-
H70
ELM 37-
H160
ELM 37-
H260
Mechanical operating data
Weight [kg] 1,5 4,95 5,5
Max. payload (horizontal
installation) [kg]
386
Max. stator temperature [°C] 65 65 65
Max. driving force [N] 60 160 160
Max. rated/constant force
(with us of fan cooling) [N]
31 100 100
Repeat accuracy (more exact
positioning through accessory
position measuring system)
[mm]
±0.05 ±0.05 ±0.05
Max. speed [m/s] 1,5 1,4 1,4
Max. acceleration [m/s2] 43 35 35
Max. useful stroke [mm] 70 160 260
IP rating 40 40 40
Electrical operating data
Nominal voltage [VDC] 72 72 72
Max. current [A] 2,8 5 5
Operating data for compressed air connection
Pressure medium Compressed air, compressed air
quality according to ISO 8573-1:7
4 4

Technical data
02.00 | ELM | Assembly and operating manual | en | 389058
17
3.2 Option with anti-fall device (deviating data)
ELM 23-H70-
ASP
ELM 37-H160-
ASP
ELM 37-H260-
ASP
Weight [kg] 1,61 5,25 5,83
Minimum release pressure [bar] 3 3 3
Static holding force [N] 180 350 350
Max. axial play of clamp [mm] 0,2 0,25 0,25
3.3 Fan cooling
MK 23 MK 37
Nominal voltage
[VDC]
24 24
3.4 Weight compensation
GA 23-70 GA 37-160 GA 37-260
Feeding force [N/bar] 2,6 6,7 6,7
Module slide weight [kg] 0,7 2,6 3,15

Assembly
18
02.00 | ELM | Assembly and operating manual | en | 389058
4 Assembly
4.1 Connections
4.1.1 Mechanical connection
WARNING
Danger of injury due to unexpected movements of the
machine/system!
•Switch off energy supply.
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
Mounting Connection geometries are on the base body, on the slide and on
the end plate:
Connection geometries for ELM 23

Assembly
02.00 | ELM | Assembly and operating manual | en | 389058
19
Connection geometries for ELM 37
ELM 23 ELM 37
A M5 / 7 M5 / 10
B [mm] Ø5F7 / 7 Ø5F7 / 3
C [mm] Ø3F7 Ø5F7
D Km4 DIN974-1 Km5 DIN974-1
E [mm] - Ø5F7 / 5
F - M5 / 9
G [mm] - 12.05 / 1.2

Assembly
20
02.00 | ELM | Assembly and operating manual | en | 389058
4.1.2 Air connections
The module has a compressed air connection for cooling of the
drive.
Luftanschlüsse
ELM 23 ELM 37
A M5 M5
4.1.3 Electrical connection
WARNING
Danger from electric voltage!
Touching live parts can result in death.
•Switch off the power supply before any assembly, adjustment
or maintenance work and secure against being switched back
on again.
•Only qualified electricians should perform electrical
installations.
•Cover up live parts.
•Check if de-energized, ground it and hot wire.
Use the specified cable sets and controllers. Consult your SCHUNK
contact person if necessary
