SCHUNK SKE Series User instructions

Translation of the original manual
Assembly- and Operating Manual
SKE
Swivel Unit

Imprint
2
04.00 | SKE | Assembly- and Operating Manual | en | 389407
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved. Any reproduction, processing, distribution (making available to third parties),
translation or other usage - even excerpts - of the manual is especially prohibited and
requires our written approval.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389407
Version: 04.00|24/09/2019|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
schunk.com

Table of Contents
04.00 | SKE | Assembly- and Operating Manual | en | 389407
3
Table of Contents
1 General.................................................................................................................... 4
1.1 About this manual ................................................................................................ 4
1.1.1 Presentation of Warning Labels ...............................................................4
1.1.2 Applicable documents ..............................................................................5
1.2 Warranty .............................................................................................................. 5
1.3 Scope of delivery .................................................................................................. 5
1.4 Accessories ........................................................................................................... 5
1.4.1 Sensors .....................................................................................................5
2 Basic safety notes ................................................................................................... 6
2.1 Intended use......................................................................................................... 6
2.2 Not intended use.................................................................................................. 6
2.3 Constructional changes ........................................................................................ 6
2.4 Spare parts ........................................................................................................... 6
2.5 Ambient conditions and operating conditions .....................................................7
2.6 Personnel qualification......................................................................................... 7
2.7 Personal protective equipment............................................................................ 8
2.8 Notes on safe operation ....................................................................................... 8
2.9 Transport .............................................................................................................. 8
2.10 Malfunctions......................................................................................................... 9
2.11 Disposal ................................................................................................................ 9
2.12 Fundamental dangers........................................................................................... 9
2.12.1 Protection during handling and assembly ..............................................10
2.12.2 Protection during commissioning and operation ...................................10
2.12.3 Protection against dangerous movements.............................................11
2.12.4 Protection against electric shock............................................................11
2.13 Notes on particular risks..................................................................................... 12
3 Technical Data .......................................................................................................13
4 Assembly ................................................................................................................14
4.1 Connections........................................................................................................ 14
4.1.1 Mechanical connection...........................................................................14
4.1.2 Pneumatic connection............................................................................15
4.2 Gripper assembly................................................................................................ 17
4.3 Other grippers .................................................................................................... 17
4.4 Mounting the sensor .......................................................................................... 19
4.4.1 Inductive proximity switch IN 40 ............................................................20
4.4.2 Inductive proximity switch IN 80 ............................................................22
5 Maintenance and care ............................................................................................25
6 Translation of original declaration of incorporation ................................................26
6.1 Annex to Declaration of Incorporation............................................................... 27

General
4
04.00 | SKE | Assembly- and Operating Manual | en | 389407
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working is
the observance of all safety instructions in this manual.
Illustrations in this manual are provided for basic understanding
and may differ from the actual product design.
In addition to these instructions, the documents listed under
Applicable documents [}5] are applicable.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.

General
04.00 | SKE | Assembly- and Operating Manual | en | 389407
5
1.1.2 Applicable documents
• General terms of business *
• Catalog data sheet of the purchased product *
• Assembly and operating manuals of the accessories *
The documents marked with an asterisk (*) can be downloaded on
our homepage schunk.com
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
• Observe the specified maintenance and lubrication intervals
• Observe the ambient conditions and operating conditions
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
• Swivel Unit SKE in the version ordered
• 2 One-way restrictors
• Brackets for proximity switches
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
1.4.1 Sensors
Overview of the compatible sensors
Designation Type
Inductive proximity switches IN
• Exact type designation of the compatible sensors see catalog.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.

Basic safety notes
6
04.00 | SKE | Assembly- and Operating Manual | en | 389407
2 Basic safety notes
2.1 Intended use
The product may only be used for swiveling permissible
attachment parts or workpieces.
• The product may only be used within the scope of its technical
data, Technical Data [}13].
• When implementing and operating components in safety-
related parts of the control systems, the basic safety principles
in accordance with DIN EN ISO 13849-2 apply. The proven safety
principles in accordance with DIN EN ISO 13849-2 also apply to
categories 1, 2, 3 and 4.
• The product is intended for installation in a machine/system.
The applicable guidelines must be observed and complied with.
• The product is intended for industrial and industry-oriented use.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Not intended use
It is not intended use if the product is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
• Any utilization that exceeds or differs from the appropriate use
is regarded as misuse.
2.3 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of the
product or damage it.
• Structural changes should only be made with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Use only original spare parts or spares authorized by SCHUNK.

Basic safety notes
04.00 | SKE | Assembly- and Operating Manual | en | 389407
7
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction to the product's life span.
• Make sure that the product is used only in the context of its
defined application parameters, Technical Data [}13].
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
• All work may only be performed by qualified personnel.
• Before working with the product, the personnel must have read
and understood the complete assembly and operating manual.
• Observe the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the various
activities related to the product:
Trained electrician Due to their technical training, knowledge and experience, trained
electricians are able to work on electrical systems, recognize and
avoid possible dangers and know the relevant standards and
regulations.
Qualified personnel Due to its technical training, knowledge and experience, qualified
personnel is able to perform the delegated tasks, recognize and
avoid possible dangers and knows the relevant standards and
regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.

Basic safety notes
8
04.00 | SKE | Assembly- and Operating Manual | en | 389407
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners or rough surfaces.
• Wear heat-resistant protective gloves when handling hot
surfaces.
• Wear protective gloves and safety goggles when handling
hazardous substances.
• Wear close-fitting protective clothing and also wear long hair in
a hairnet when dealing with moving components.
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
• Eliminate any malfunction immediately.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• Secure the product against falling during transportation and
handling.
• Stand clear of suspended loads.

Basic safety notes
04.00 | SKE | Assembly- and Operating Manual | en | 389407
9
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and no increased risks have arisen.
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's safety
and cause serious injuries as well as considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety devices.
• Before commissioning the product, take appropriate protective
measures to secure the danger zone.
• Disconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
• If the energy supply is connected, do not move any parts by
hand.
• Do not reach into the open mechanism or movement area of
the product during operation.

Basic safety notes
10
04.00 | SKE | Assembly- and Operating Manual | en | 389407
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
• Have all work carried out by appropriately qualified personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention rules.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
• Stand clear of suspended loads and do not step into their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious injuries
and even death.
• Take appropriate protective measures to secure the danger
zone.
• Never step into the danger zone during operation.

Basic safety notes
04.00 | SKE | Assembly- and Operating Manual | en | 389407
11
2.12.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
• Switch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
• Never rely solely on the response of the monitoring function to
avert danger. Until the installed monitors become effective, it
must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
• To avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum possible
movement energy. EMERGENCY STOP switches must be easily
and quickly accessible. Before starting up the machine or
automated system, check that the EMERGENCY STOP system is
working. Prevent operation of the machine if this protective
equipment does not function correctly.
2.12.4 Protection against electric shock
Possible electrostatic energy
Components or assembly groups may become electrostatically
charged. When the electrostatic charge is touched, the discharge
may trigger a shock reaction leading to injuries.
• The operator must ensure that all components and assembly
groups are included in the local potential equalisation in
accordance with the applicable regulations.
• While paying attention to the actual conditions of the working
environment, the potential equalisation must be implemented
by a specialist electrician according to the applicable
regulations.
• The effectiveness of the potential equalisation must be verified
by executing regular safety measurements.

Basic safety notes
12
04.00 | SKE | Assembly- and Operating Manual | en | 389407
2.13 Notes on particular risks
DANGER
Risk of fatal injury from suspended loads!
Falling loads can cause serious injuries and even death.
•Stand clear of suspended loads and do not step within their
swiveling range.
•Never move loads without supervision.
•Do not leave suspended loads unattended.
•Wear suitable protective equipment.
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
•Take appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
•Before starting any work on the product: Switch off the power
supply and secure against restarting.
•Make sure, that no residual energy remains in the system.
WARNING
Risk of injury from sharp edges and corners!
Sharp edges and corners can cause cuts.
•Use suitable protective equipment.

Technical Data
04.00 | SKE | Assembly- and Operating Manual | en | 389407
13
3 Technical Data
SKE 18 SKE 22 SKE 40 SKE 55
Torque [Nm] 0.4 0.75 5.0 9.0
Angle of rotation [°] 90.0
End position adjustability[°] 5.0
IP rating 30
Weight [kg] 0.13 0.2 0.92 1.95
Cycle time (1 x nominal angle of
rotation)
without attached load [s]
0.5 0.8 1.0 1.5
Air consumption per cycle
(2 x nominal angle) [cm3]
10.0 20.0 100.0 160.0
Nominal working pressure [bar] 4.0
Min. pressure [bar] 1.0
Max. pressure [bar] 6.0
Diameter hose connection [mm] 4.0
Min. ambient temperature [°C] 5.0
Max. ambient temperature [°C] 50.0
Repeatability [mm] 0.03
Noise emission [dB(A)] ≤ 70
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Assembly
14
04.00 | SKE | Assembly- and Operating Manual | en | 389407
4 Assembly
4.1 Connections
4.1.1 Mechanical connection
Connections on the
housing
ØFasten the product with the aid of the threads (3) on the
bottom.
ØCenter the product on the central fitting bore (2).
ØUse off-center fitting bore (1) for positioning.
Assembly options (principle drawing)
Mounting material (provided by the customer)
Item Mounting SKE 18 SKE 22 SKE 40 SKE 55
1 Positioning Ø 5 +0.03
5 deep
Ø 5+0.03
6 deep
Ø 5 +0.03
8 deep
Ø 6 +0.03
6 deep
2 Centering bore Ø 7
1.8 deep
Ø 20
3.0 deep
Ø 20
3.0 deep
Ø 20
3.0 deep
3 Mounting
thread
M3 / 4 deep
( 6x)
M4 / 7 deep
( 4x)
M5 / 6 deep
( 4x)
M6 / 8 deep
( 2x)
M6 / 20 deep
( 4x)
M8 / 15 deep
( 2x)
M8 / 15 deep
( 6x)

Assembly
04.00 | SKE | Assembly- and Operating Manual | en | 389407
15
4.1.2 Pneumatic connection
WARNING
Risk of injury due to moving parts!
Rotating components and/or components moving linearly may
cause severe injuries.
•Do not interfere with moving parts during operation.
•Wear protective equipment.
NOTE
• Observe the requirements for the compressed air supply,
Technical Data [}13].
• In case of compressed air loss (cutting off the energy line), the
components lose their dynamic effects and do not remain in a
secure position. However, the use of a SDV-P pressure
maintenance valve is recommended in this case in order to
maintain the dynamic effect for some time. Product variants
are also offered with mechanical gripping force via springs,
which also ensure a minimum clamping force in the event of a
pressure drop.
NOTE
The air connections are equipped with one-way flow control
valves.
The optimal swiveling speed is achieved by adjusting the swiveling
time on the exhaust air throttles.
Fine adjustment must be carried out on the fully assembled
system. Never operate the swivel unit without the one-way flow
control valves mounted. Do not go below the specified swiveling
time.
CAUTION
Material damage due to too high swiveling speed!
If the swiveling speed is too high, the assembly will be
decelerated abruptly by the shock absorber and will continue to
oscillate until reaching the end position. This will overload the
shock absorber and may cause damage to it.
•Adjust the swiveling speed in a way, that the movement
decelerate smoothly in the end position.

Assembly
16
04.00 | SKE | Assembly- and Operating Manual | en | 389407
Pneumatic connections
1 Throttle A
2 Throttle B
• Open only the air connections that are needed.
• Close unused main air connections using the screw plugs from
the enclosed pack.
• For a hose-free direction connection, use the O-rings from the
enclosed pack.
• Turn the set screws of the one-way flow control valves to center
position.
• Connect the hoses with dimension Ø4 / 6 mm.

Assembly
04.00 | SKE | Assembly- and Operating Manual | en | 389407
17
4.2 Gripper assembly
One or two grippers can be mounted on the swivel unit.
The adapter plates can be removed to facilitate assembly.
CAUTION
Make sure that the screw heads do not protrude.
Grippers and size of fixing screws (DIN EN ISO 4762) for use with standard adapter plates:
Type Gripper type/fixing screw dimension
SKE 18 RHL 0 / M3 RH 901 / M3 RH 901 ST 10 /
M3
SKE 22 RH 801 / M3 RH 905 / M4 RH 907 / M4
SKE 40 RH 806 KP / M4 RH 925 / M5 -
SKE 55 RH 940 / M6 - -
The grippers can be mounted centrally on the adapter plate either
parallel or vertical to the swivel axis.
Observe the tightening torque.
Type Fixing screw dimension
DIN EN ISO 4762, 10.9
Tightening torque [Nm]
SKE 18 M2.5 0.9
SKE 22 M3 1.6
SKE 40 M4 3.8
SKE 55 M5 7.5
4.3 Other grippers
When using special adapter plates, further grippers can be used.
For fastening of the gripper, please use 4 screws as per DIN EN ISO
4762. 2 fitting bores and a lateral groove guarantee the
positioning.
Main dimensions of the adapter plates:

Assembly
18
04.00 | SKE | Assembly- and Operating Manual | en | 389407
Type L B l1l2l3l4b1d1d2d3t
SKE
18
42 16 8 30 4 0.5 10 3 F7 2.8 5.0 2.8
SKE
22
54 20 46 38 6 1.0 13 5 F7 3.3 6.0 3.4
SKE
40
74 30 64 54 8 1.0 20 5 F7 4.4 7.6 4.6
SKE
55
106 40 91 76 10 1.0 28 5 F7 5.4 9.0 5.5

Assembly
04.00 | SKE | Assembly- and Operating Manual | en | 389407
19
4.4 Mounting the sensor
NOTE
Observe the assembly and operating manual of the sensor for
mounting and connecting.
The product is equipped for the use of sensors.
• For the exact type designations of suitable sensors, please see
the catalog data sheet.
• For technical data for the suitable sensors, see Assembly and
Operating Manual and catalog data sheet.
– The Assembly and Operating Manual and catalog data sheet
are included in the scope of delivery for the sensors and are
available at schunk.com.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.

Assembly
20
04.00 | SKE | Assembly- and Operating Manual | en | 389407
4.4.1 Inductive proximity switch IN 40
4
25
brown
black
blue
load closer
Types that can be ordered (☞ catalog):
The inductive proximity switches used are equipped with reverse
polarity protection and are short-circuit-proof.
Make sure that you handle the proximity switches properly:
• Do not pull on the cable.
• Do not allow the sensor to dangle from the cable.
• Do not overtighten the mounting screw or mounting clip.
• Please adhere to a permitted bend radius of the cable (☞ catalog).
• Avoid contact of the proximity switches with hard objects and
with chemicals, in particular nitric acid, chromic acid and
sulphuric acid.
The inductive proximity switches are electronic components,
which can react sensitively to high-frequency interference or
electromagnetic fields.
• Check to make sure that the cable is fastened and installed
correctly. Provide for sufficient clearance to sources of high-
frequency interference and their supply cables.
• Parallel switching of several sensor outputs of the same type
(npn, pnp) is permissible, but does not increase the permissible
load current.
• Note that the leakage current of the individual sensors (approx.
2 mA) is cumulative.
Pressurize connection A with compressed air.
Plug in the proximity switch 1 into the bracket of the contact plate
until the distance between them is 1.5 mm and fix it with an
attachment screw.
Do the same for connection B and proximity switch 2.
