SCHUNK RM 50 - 310 User instructions

Translation of the original operating manual
Rotary module
RM 50 - 310
Assembly and Operating Manual
Superior Clamping and Gripping
www.comoso.com

Imprint
2 05.00|RM 50 - 310 |en
Imprint
Copyright:
This manual remains the copyrighted property of SCHUNK GmbH & Co. KG. It is solely
supplied to our customers and operators of our products and forms part of the product.
This documentation may not be duplicated or made accessible to third parties, in particu-
lar competitive companies,
without our prior permission.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 0389388
Edition: 05.00 |25/07/2013|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear customer,
congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for
the highest precision, top quality and best service.
You are going to increase the process reliability of your production and achieve best
machining results – to the customer's complete satisfaction.
SCHUNK products are inspiring.
Our detailed assembly and operation manual will support you.
Do you have further questions? You may contact us at any time – even after purchase.
Kindest Regards
Yours SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
www.schunk.com
www.comoso.com

Table of contents
05.00|RM 50 - 310 |en
3
Table of contents
1 About this manual .................................................................................................... 5
1.1 Warnings................................................................................................................... 5
1.1.1 Key words...................................................................................................... 5
1.1.2 Symbols ......................................................................................................... 5
1.2 Applicable documents .............................................................................................. 5
2 Basic safety notes .................................................................................................... 6
2.1 Intended use............................................................................................................. 6
2.2 Not intended use ...................................................................................................... 6
2.3 Environmental and operating conditions................................................................. 6
2.4 Product safety........................................................................................................... 7
2.4.1 Protective equipment ................................................................................... 7
2.4.2 Constructional changes, attachments, or modifications.............................. 7
2.5 Personnel qualification............................................................................................. 7
2.6 Using personal protective equipment...................................................................... 7
2.7 Notes on particular risks........................................................................................... 8
3 Warranty.................................................................................................................. 9
4 Scope of delivery ...................................................................................................... 9
5 Accessories.............................................................................................................. 10
5.1 Sensors.................................................................................................................... 10
6 Technical data ......................................................................................................... 11
7 Assembly and settings ............................................................................................. 12
7.1 Mechanical connection .......................................................................................... 12
7.2 Air connections....................................................................................................... 13
7.3 Adjusting the end positions.................................................................................... 14
7.3.1 Angle of rotation fine adjustment .............................................................. 15
7.3.2 Dampening adjustment .............................................................................. 15
7.4 End position monitoring......................................................................................... 16
8 Start-up................................................................................................................... 17
9 Troubleshooting ...................................................................................................... 18
9.1 Modul does not move? .......................................................................................... 18
9.2 Does the module not travel through the rotating angle?...................................... 18
9.3 End position signal not present?............................................................................ 18
9.4 Is torque dropping? ................................................................................................ 19
9.5 Does the module rotate abruptly?......................................................................... 19
9.6 Does the module move hard against the end positions? ...................................... 19
www.comoso.com

Table of contents
4 05.00|RM 50 - 310 |en
10 Maintenance and care ............................................................................................. 20
10.1 Shock absorber ....................................................................................................... 20
10.2 Maintenance and lubrication intervals .................................................................. 20
10.3 Lubricants/Lubrication points (basic lubrication) ................................................. 21
10.4 Dismantling the module ......................................................................................... 21
10.5 Assembling the module.......................................................................................... 22
11 Spare parts.............................................................................................................. 22
11.1 Sealing kit................................................................................................................ 22
12 Assembly drawing ................................................................................................... 23
13 Translation of original declaration of incorporation................................................. 24
www.comoso.com

About this manual
05.00|RM 50 - 310 |en
5
About this manual
This instruction is an integral part of the product and contains impor-
tant information for a safe and proper assembly, commissioning, op-
eration, maintenance and help for easier trouble shooting.
Before using the product, read and note the instructions, especial-
ly the chapter "Basic safety notes".
Warnings
The following key words and symbols are used to highlight dangers.
Key words
DANGER Dangers for persons.
Non-compliance will inevitably cause irreversible injury or death.
WARNING Dangers for persons.
Non-compliance may cause irreversible injury or death.
CAUTION Dangers for persons.
Non-observance may cause minor injuries.
NOTICE Information about avoiding material damage
Symbols
Warning about a danger point
Warning about hot surfaces
Warning about hand injuries
General mandatory sign to prevent material damage
Applicable documents
•General terms of business
•SCHUNK catalog Modular Assembly Automation
•Assembly and Operating Manuals of the accessories
•"Gemotec Toolbox Rotation" program
The documents listed up here, can be download on our homepage
www.schunk.com
1
1.1
1.1.1
1.1.2
1.2
www.comoso.com

Basic safety notes
6 05.00|RM 50 - 310 |en
Basic safety notes
Intended use
The module was designed to swivel permissible attachments or
workpieces.
The module is intended for installation in a machine/system. The
requirements of the applicable guidelines must be observed and
complied with.
The module may be used only in the context of its defined applica-
tion parameters (6, Page 11).
To use this unit as intended, it is also essential to observe the
technical data and installation and operation notes in this manual
and to comply with the maintenance intervals.
Not intended use
It is not an intended use if the module is used, for example, as a
pressing tool, stamping tool, lifting gear, guide for tools, cutting
tool, clamping device or a drilling tool.
Environmental and operating conditions
•The module may be used only within its defined application pa-
rameters.
•Ensure that the environment is clean. Observe the lubrication
intervals (10.2, Page 20).
•Ensure that the environment is free of splashing water and va-
pors, and also of abrasive dust and process dust. This does not
apply to modules designed especially for unclean environ-
ments.
•Do not subject the module to excessive vibrations and/or me-
chanical shocks.
•Strong magnetic fields can impair the function of the module. If
the product is to be used in strong magnetic fields, contact your
SCHUNK partner.
2
2.1
2.2
2.3
www.comoso.com

Basic sa
fety notes
05.00|RM 50 - 310 |en
7
Product safety
Dangers arise from the module, if:
•the module is not used in accordance with its intended purpose.
•the module is not installed or maintained properly.
•the safety and installation notes are not observed.
Avoid any manner of working that may interfere with the function
and operational safety of the module.
Wear protective equipment.
NOTE
More information are contained in the relevant chapters.
Protective equipment
Provide protective equipment per EC Machinery Directive.
Constructional changes, attachments, or modifications
Additional drill holes, threads, or attachments that are not offered
as accessories by SCHUNK may be attached only with permission
of SCHUNK.
Personnel qualification
The assembly, initial commissioning, maintenance, and repair of
the module may be performed only by trained specialist person-
nel. Every person called upon by the operator to work on the
module must have read and understood the complete assembly
and operating manual, especially the chapter "Basic safety notes"
(2, Page 6). This applies particularly to personnel only used oc-
casionally, such as maintenance personnel.
Using personal protective equipment
When using this product, observe the relevant industrial safety
regulations and use the personal protective equipment (PPE) re-
quired!
•Use protective gloves, safety shoes and safety goggles.
•Observe safe distances.
•Minimal safety requirements for the use of equipment.
2.4
2.4.1
2.4.2
2.5
2.6
www.comoso.com

Basic safety notes
8 05.00|RM 50 - 310 |en
Notes on particular risks
Generally valid:
•Remove the energy supplies before installation, modification,
maintenance, or adjustment work.
•Make sure, that no residual energy remains in the system.
•Do not move parts by hand when the energy supply is con-
nected.
•Do not reach into the open mechanism or the movement area
of the module.
•Perform maintenance, modifications, and additions outside the
danger zone.
•For all work, secure the unit against accidental operation.
•Take a precautionary approach by maintenance and disassem-
bly.
•Only specially trained staff should disassemble the module.
WARNING
Risk of injury from objects falling and being ejected
•The danger zone must be surrounded by a safety fence during
operation.
WARNING
Risk of injury due to rotating components!
Avoidance: The danger zone must be surrounded by a safety
fence during operation.
2.7
www.comoso.com

Scope of delivery
05.00|RM 50 - 310 |en
9
Warranty
The warranty is valid for 24 months from the delivery date to the
production facility under the following conditions:
•Intended use in 1-shift operation
•Observe the mandatory maintenance and lubrication intervals
•Observe the environmental and operating conditions
Parts touching the work piece and wear parts are not part of the
warranty.
Scope of delivery
The scope of delivery includes:
•Rotary Actuator RM in the ordered model.
•Exhaust air throttles
•Accessory pack
3
4
www.comoso.com

Accessories
10 05.00|RM 50 - 310 |en
Accessories
The following accessories that are required for the module must
be ordered seperately:
•End-position monitoring
•Sensors
For information about which accessories can be used with the ap-
propriate product version ☞catalog.
Sensors
Overview of the compatible sensors
Designation Type
Inductive proximity switches NI
Monitoring set RMNS...
•Exact type designation of the compatible sensors see ☞catalog
•If you require further information on sensor operation, contact
your SCHUNK contact person or download information from
our homepage.
5
5.1
www.comoso.com

Technical data
05.00|RM 50 - 310 |en
11
Technical data
Module type RM50-310 W90 RM50-310 W180
Standard angle of rotation [°] * 90 180
End position adjustability [°] ± 5
Ambient temperature [°C] 5 - 60
IP rating 40
Noise emission [dB(A)] ≤ 70
Pressure medium Compressed air, standard for quality of
the compressed air according to ISO 8573-
1: 6 4 4
Min. pressure [bar] 3
Max. pressure [bar] 8
Nominal working pressure [bar] 6
* All other angles of rotation between 5 and 180 degrees can be
selected – specify when ordering – ☞catalog.
Further technical data can be found in the catalog data sheet.
The most recent version applies.
6
www.comoso.com

Assembly and settings
12 05.00|RM 50 - 310 |en
Assembly and settings
NOTICE
Assembly measures
•When mounting loads, do not allow impermissible forces and
moments to be exerted (see catalog data).
•Select the suitable screw tightening torque when assembling
the module or loads at the module in accordance with the
generally accepted guidelines for screw connections.
•Secure all screws using a suitable chemical screw lock.
Mechanical connection
The values relate to the entire bolting surface.
Requirements for levelness of the bolting surface (Dimensions in mm)
Diameter Permissible unevenness
< 100 < 0.02
> 100 < 0.05
The connection geometries are above, below and at the side of the
rotary module.
Dimensions for the position and size of the connection geometries,
☞Catalog data sheet.
NOTE
•When mounting the module from the rear or on the side,
mount the module using the fixing bores provided.
•Mount the modules using the fixing bores provided.
7
7.1
Check the evenness
of the bolting surface
Mounting
www.comoso.com

Assembly and settings
05.00|RM 50 - 310 |en
13
Air connections
NOTICE
Pressure medium:
The unit must not under any circumstances be operated with
oiled air before operation with unoiled air (washing out of factory
lubrication).
NOTICE
Observe the requirements for the air supply.
(6, Page 11)"Technical Data"
Use connecting wires with the same or a larger cross-section as
the connection thread.
See the catalog for precise information about the position and size
of the connection geometries.
7.2
www.comoso.com

Assembly and settings
14 05.00|RM 50 - 310 |en
Adjusting the end positions
The parts listed below are included within the scope of delivery of
every rotary module for angle of rotation fine adjustment and ad-
justment of the end position dampening to the mass moment of
inertia occurring in operation.
•Counter nut (10)
•Stop coupling (13)
•Rod (14)
•Shock absorber (22)
•Counter nut (23)
Fig. 1 Adjusting the end positions
7.3
www.comoso.com

Assembly and settings
05.00|RM 50 - 310 |en
15
Angle of rotation fine adjustment
1 Release counter nut (10).
2 By twisting the stop coupling (13) with the rod (14) and shock
absorber (22) that are integrated in it, the angle of rotation in
both end positions can be set by ±5° from the nominal angle
of rotation. The nominal rotation angle has to be specified for
the order and can be selected without steps between 5° and
180°. Standard angles are 90° and 180°.
3 Tighten the stop coupling again with the counter nut.
Dampening adjustment
NOTICE
Use the shock absorber!
Operation without the shock absorber included within the scope
of delivery is not permitted.
•Observe the maximum mass moment of inertia (☞catalog da-
ta).
•Adjust the dampening at the mass moment of inertia.
The desired angle of rotation has been set (7.3.1, Page 15).
1 Release counter nut (23).
2 By turning the shock absorber (22) in and out, the stroke of
the shock absorber (and therefore the shock absorber charac-
teristic curve) can be adjusted to the mass moment of inertia
occurring in operation. The previously adjusted angle of rota-
tion is not influenced by this.
3 Tighten the absorber again with the counter nut.
7.3.1
7.3.2
www.comoso.com

Assembly and settings
16 05.00|RM 50 - 310 |en
End position monitoring
To monitor the end positions, standardized monitoring sets for di-
rect installation are available.
The stop level that is integrated in the rotary module is directly
monitored.
Proximity switch monitoring: GMNS-...
Scope of delivery of the monitoring set:
•1 x retaining plate
•1 x Proximity switch
•1 x connection cable
Fig. 2 Position of the proximity switches
1 Proximity switch (GMNS-... installation on both sides)
1 Undo the attachment screw.
2 Set the sensor via the retainer plate.
3 Fix the sensor via the attachment screw.
7.4
Setting the
monitoring
www.comoso.com

Start-up
05.00|RM 50 - 310 |en
17
Start-up
•Check the technical specifications (6, Page 11).
•Check the permissible loading specifications (see catalog).
•Do not use the module until trouble-free operation has been
checked taking all permissible operating parameters into ac-
count.
•Set the speed of the movement in such a way that the permit-
ted swiveling time is not exceeded. Use the "Gemotec Toolbox"
program for calculation (www.schunk.com).
•The movement speed is ideally regulated via throttle check
valves (7.2, Page 13). The speed is always set so that it starts
at a low speed and increases to a higher speed until the desired
operating speed has been reached.
•Operate the device in such a way that the permissible cycle
number per minute is not exceeded. Use the "Gemotec Tool-
box" program for calculation (www.schunk.com).
8
www.comoso.com

Troubleshooting
18 05.00|RM 50 - 310 |en
Troubleshooting
Modul does not move?
Possible cause Corrective action
Pressure drops below minimum. Check the air supply.
(
7.2, Page 13)
Compressed air lines switched Check compressed air lines.
Proximity switch defective or set incorrect. Repair the proximity switch.
Unused air connections not closed. Close the unused air connections.
Choke valve closed. Open the choke valve.
Does the module not travel through the rotating angle?
Possible cause Corrective action
The end positions are incorrectly adjusted Readjust the end positions
(
7.3, Page 14)
Pressure drops below minimum. Check the air supply.
(7.2, Page 13)
Mounting surface is not even enough Check the levelness of the bolting surface.
(
7.1, Page 12)
Component is broken, e.g. through over-
loading
Send the module to SCHUNK with a repair
order or disassemble module
Shock absorber defective Check or, if need be, replace the shock ab-
sorber
(
7.3, Page 14)
End position signal not present?
Possible cause Corrective action
Precisely adjust the sensor for the stop Readjust the sensor
(
7.4, Page 16)
Proximity switch defective or set incorrect. Repair the proximity switch.
Cable breakage Replacing the sensor cable
9
9.1
9.2
9.3
www.comoso.com

Troubleshooting
05.00|RM 50 - 310 |en
19
Is torque dropping?
Possible cause Corrective action
Seals of the drive piston defective Send the module to SCHUNK with a repair
order (recommended).
Replace the seals of the drive piston.
Positioning of the swivel table defective Send the module to SCHUNK with a repair
order.
Compressed air lines are blocked Check the compressed air lines for pinching
or damage.
Pressure drops below minimum. Check the air supply.
(
7.2, Page 13).
Does the module rotate abruptly?
Possible cause Corrective action
Seals of the drive piston defective Send the module to SCHUNK with a repair
order (recommended).
Replace the seals of the drive piston.
Positioning of the swivel table defective Send the module to SCHUNK with a repair
order.
Compressed air lines are blocked Check the compressed air lines for pinching
or damage.
Does the module move hard against the end positions?
Possible cause Corrective action
Fine adjustment of the absorber stroke is
faulty
Readjust absorber stroke
(
7.3, Page 14).
Absorber defective Replace and readjust absorbers, (7.3,
Page 14).
The exhaust air throttle is defective Replace the exhaust air throttle.
Speed of rotation too high Setting the exhaust air throttle (8,
Page 17).
9.4
9.5
9.6
www.comoso.com

Maintenance and care
20 05.00|RM 50 - 310 |en
Maintenance and care
Shock absorber
NOTICE
Serious mechanical damage due to failure of the shock absor-
bers.
The shock absorbers have a limited service life span. A shock ab-
sorber failure can lead to serious mechanical damage; for this
reason, they must be checked regularly for proper function. The
shock absorber is working correctly if the device reaches its end
position swiftly without any mechanical impact.
Overloading of the unit or exceeding the permitted swivel speed
can lead to drastic reduction of the service life.
•Determine the swiveling times and the permitted stroke fre-
quency with "Gemotec Toolbox".
•Regularly check the shock absorber.
•Observe the recommended maintenance intervals.
Maintenance and lubrication intervals
NOTICE
At ambient tempertature above 60°C the lubricans
cure out faster
•Interval decrease accordingly.
Size 50 - 310
Interval [Mio. cycles] 2
10
10.1
10.2
www.comoso.com
