Schwaiger DSR 6050 HD User manual

Keys on the remote control
1. Mute
2. Information key (INFO)
3. Teletext key (TTX)
4. SCART input key (DTV/VCR)
5. Subtitles key (SUBTITLE)
6. EXIT key
7. Confirm (OK)
8. Volume+ key / navigation right
9. Toggle between TV and radio (TV/RADIO)
10. Previous channel key (RECALL)
11. Search key (GOTO)
12. Previous file key ((|<<)
13. Next file key ((|<<)
14. REPEAT key
15. STOP key
16. STANDBY key
17. EPG key
18. Audio key
19. Channel+ key / navigation up
20. Settings menu key (MENU)
21. Favourites key (FAVOURITE)
22. Numerical key (0… 9)
23. Fast forward during playback ((>>)
24. Fast rewind during playback (<<)
25. Playback key (PLAY/ >)
26. Pause key
27. Function keys (red, green, yellow, blue)
28. RECORD key
29. Recording list (LIST)
Notes:
The functions of the PVR keys are optional.
The function of the colour keys green, red, yellow and blue
varies with the different modes of operation. These
functions will always be explained in the relevant sections.

Digital HD Satellite Receiver
'65 HD
Operating manual
Modifications and errors reserved.
We do not assume any liability for printing errors.
Version 1.0 DE, 16.03.10
Dear customer,
Having in mind an environmentally friendly behaviour we
ask you to switch off your receiver after usage by
operating the mains switch at the rear side of the device.
With this, you contribute to the protection of the
environment and save money.

Preface
This operating manual will help you in the
•appropriate
•safe and
•favourable
use of the digital HD satellite receiver, in short, the
“receiver”.
We assume that the user of the receiver has overall
knowledge regarding the handling of audio and video
equipment.
Each person who
•installs,
•connects,
•operates,
•cleans
•disposes of
this receiver must be familiar with the entire content of
this operating manual. Always keep this operating
manual in the proximity of the receiver.
Style features
Specific style features have been given in different
sections of the operating manual. Thus, you can easily
differentiate whether it concerns:
normal text,
•enumerations
or
actions
3

4
CONTENTS
Preface ............................................................................................... 3
Style features .................................................................................... 3
Safety instructions ........................................................................... 6
Basic safety instructions ..................................................6
Explanation of safety instructions ..................................10
Appropriate use .............................................................10
Scope of supply ..............................................................................11
Description ......................................................................................12
Connecting the receiver.................................................................16
LNB cable installation ....................................................17
SCART cable connection...............................................20
Connection with the HDMI cable....................................22
Connection with the Cinch cable....................................24
Connection of an audio digital receiver..........................26
Connection and rough direction of the antenna .............28
Getting started ................................................................................34
Remote control ..............................................................34
The receiver...................................................................36
Operation.........................................................................................37
Screen display messages when switching channels .....37
User interface on the TV screen ....................................39
Menu structure...............................................................39
Menu navigation ............................................................42
Channel list (symbol: TV I).............................................43
Video settings (symbol: TV II) ........................................47
Installation (symbol: Magnifier) ......................................48
Time (symbol: clock and earth)......................................52
Options (symbol: gears).................................................54
System (symbol: tool) ....................................................55
USB (symbol: USB stick) (optional) ...............................56
PVRready function from normal mode (optional) .......................61

7
Ask a qualified person to check the equipment before
reuse.
•Else, there is a risk of electric shock.
•Ensure that the power source (socket) is easily
accessible.
•Do not bend or crimp the mains cable.
•If the mains cable is damaged, the receiver must be
repaired by an expert before reusing it. Otherwise,
there is a risk of electric shock.
•Never allow children to operate the receiver or to play
with the antenna unit unless supervised.
•Refer all maintenance to qualified personnel.
Otherwise, you will put yourself and others at risk.
•Disconnect the receiver from the power source in case
of operational disruptions.
•Spare parts must be ordered directly from the
manufacturer
•Modifications of the device lead to an extinction of the
manufacturer’s liability.
•Remove the protection films.
Caution
Information on separation from power source. The
Standby key of this device will not separate the device
completely from the power source. In addition, the
device will draw current. To separate the device
completely from the power source, the mains plug
must be pulled out of the socket.

6
Safety instructions
Please read the safety instructions carefully before
operating the receiver.
Please follow all warnings and instructions indicated on
the equipment and in the operating manual.
Basic safety instructions
Electrical connection
•Disconnect the receiver from the power source in case
of operational disruptions. Please note: The receiver
will remain live, even if it is turned off with the mains
switch on the rear side.
•Do not expose the receiver to rain or any kind of
humidity to avoid risk of fire and electric shock.
•Do not open the receiver. It could cause electric shock.
•Connect the receiver only to a professionally installed
mains socket of 220 V –240 V ~, 50 Hz –60 Hz.
•The total current at the antenna connection of the
receiver ‘LNB IN’ must not exceed 300 mA.
•Pull out the mains plug from the socket if the
equipment is not in use for a longer period of time.
Only pull at the mains plug, not at the cable.
•In case of storms pull out the mains plug of the
receiver from the socket.
•In case of a storm, loosen the LNB cable from the
receiver.
•If foreign bodies or fluids enter the receiver,
immediately pull out the mains plug from the socket.

Digital HD Satellite Receiver
'650 HD
Operating manual
Modifications and errors reserved.
We do not assume any liability for printing errors.
Version 1.0 DE, 16.03.10
Dear customer,
Having in mind an environmentally friendly behaviour we
ask you to switch off your receiver after usage by
operating the mains switch at the rear side of the device.
With this, you contribute to the protection of the
environment and save money.

8
Suitable location
•Place the receiver on a firm and flat surface.
•Avoid proximity to:
-heat sources, such as e. g. heaters,
-naked flames, such as e. g. candles,
-devices with strong magnetic fields, like e.g.
loudspeakers.
-Never place receptacles filled with liquid (e. g.
vases) on the receiver
•Avoid direct sunlight and places with an extremely high
amount of dust.
•Never cover the ventilation slots. Ensure adequate
ventilation of the receiver.
•Do not place any heavy objects on the receiver.
•Moisture may condense in the receiver when it is
brought from a cold into a hot environment. In this
case, wait for about an hour before operating the
equipment.
•Arrange the mains and antenna cables in such a
manner that nobody can step or trip over them.
Correct battery handling
•Batteries may contain toxic agents. Ensure that
batteries are not within the reach of children. Children
may eat and swallow batteries. Should a battery be
swallowed, seek medical attention immediately.

9
•Leaking batteries may damage the remote control.
When the receiver is not in use for a longer period of
time, remove the batteries from the remote control.
•Batteries may contain toxic agents. Discard the
batteries in an ecologically accepted manner and in
accordance with the relevant statutory regulations.
Never discard the batteries with normal household
waste.
•Never expose the batteries to open fire or strong heat,
as otherwise there is a danger of explosion.
•Replace the batteries always by batteries of the same
type.

10
Explanation of safety instructions
The following categories of safety instructions are
included in the operating manual:
Danger!
Instructions with the word DANGER give a warning
against possible personal injuries.
Caution
Instructions with the word CAUTION give a warning
against possible material or environmental damages.

These instructions contain special information for
commercial usage of the receiver.
Appropriate use
The receiver is designed for receiving digital unencrypted
satellite channels (free-to-air) for private use. It is
exclusively meant for this purpose and should only be
used for the same. This also includes paying attention to
all information contained in these operating instructions,
especially the safety instructions.
Any other use is considered to be improper and may lead
to material damages and even personal injuries.
Moreover, it will result in the immediate loss of guarantee.
The manufacturer does not bear any liability for damages
caused due to improper usage.

11
Scope of supply
Check the scope of supply after purchase. The scope of
supply may vary according to the type of the receiver.
Please follow the information on the packaging.
No.
Pieces
Description
1
1
Receiver
2
1
Remote control
3
2
Batteries type AAA/1.5V
-
1
Operating ma
nual (not shown above

12
Description
With this receiver you are able to receive unencrypted
(free-to-air) digital satellite channels for private use or via
satellite antenna.
It is not necessary to programme the receiver at this
stage.
The most important broadcasting stations and
satellites have been pre-programmed.
The satellite antenna has to be directed towards the
desired satellite.
The receiver will scan for further new broadcasting
stations as soon as you initiate the automatic scanning of
broadcasting stations for this satellite. Satellites not
preset may be added.
All receiver settings can be made easily using the user
interface (menu) on the TV screen.
The multilingual user interface supports the following
languages:
•German
•Italian
•Spanish
•Portuguese
•Czech
•Danish
•Swedish
•English
•French

13
The following satellites have been preset by the
company:
•ASTRA1 19.2°E
•Hotbird 13.0°E
•Türksat 42°E
•ASTRA1 28.2°E
•Sirius2 5.0°E
•Amos/Atlantic 4-5°W
•Eutel W2 16°E
•HellasSat 39°E
•ASTRA 23.5°E
•Eurobird 9.0°E
Other features of the equipment:
•HDTV & SDTV
•Upscaling of SDTV channels
•Software update via satellite ASTRA1 19.2°E
(optional) or via USB interface.
•Saves the channel last watched (Last Station Memory)
•LNB control logic (sound 0/22 kHz), max. current
delivery for LNB 300 mA
•Symbol rate 1-35 MS/s and 950-2150 MHz input
frequency
•2 keys at the frontage
•plug & play
•The power draw in standby mode is approx. 1W.
•Mains connection 220 V –240 V ~, 50/60 Hz
•5.000 channel storage locations
•Child lock (preset password: 000000)

14
•4 favourites lists
•Automatic scanning of broadcasting stations
•Broadcasting station -List editor
•Analogue sound output through Cinch connector
(stereo), volume adjustment possible via remote
control
•RCA video Cinch output
•AC3 coaxial digital audio output
•2 Euro-SCART connections for TV and video set (TV &
VCR)
•TV SCART output with CVBS and RGB assignment
•HDMI output
•Super fast videotext with a memory of 800 pages
•Digital radio reception, background image for radio
(background display)
•Additional channel information is displayed when the
channel is changed.
•DiSEqC 1.0, 1.2, USALS is supported if an appropriate
antenna unit is connected
•SWAP function (via Recall key)
•Screen aspect ratios can be set to 4:3, 16:9, and
automatically (letterbox)
•20x multi-functional timer linked with EPG, sleep timer
•Electronic Programme Guide EPG (up to 7 days in
advance, channel-dependent)
•SCPC/MCPC reception standard C/Ku-band satellites
•Automatic selection of the TV standard with video
converter

15
•Digital satellite finder (Sat-Finder) for an optical
orientation of the paraboloidal-type reflector
In addition, a suitable channel editor can be
obtained through our hotline. Then you will be
able to edit the channel lists of the receiver using
your computer. Please read the information on
our website www.VFKZDLJHU.de.

16
Connecting the receiver
The receiver is connected with your satellite antenna by
means of a coaxial cable. If necessary, you will have to
prepare a coaxial cable before connecting the receiver.

The coaxial cable is not included in the scope of
supply.
Caution
Connect the receiver to the mains supply only after you
have connected it to all equipment and the antenna
properly. Otherwise, the receiver can suffer damages.
Caution
Information on separation from power source. The
Standby key of this device will not separate the device
completely from the power source. In addition, the
device will draw current. To separate the device
completely from the power source, the mains plug
must be pulled out o
f the socket.
The wire netting and the inner core of the coaxial cable
carry current during operation.
Danger!
Connect the receiver to the mains supply only after you
have connected it to all equipment and the antenna
properly. Otherwise, there is a risk of electric shock
that can be a threat to life or physical condition.

17
LNB cable installation
(See installation diagram on the following page)
For the installation of the F connectors on the coaxial
cable you will need a knife (ideally a wire stripper) and
side cutting pliers.

When stripping the isolation, neither the inner
core or the foil nor the wire netting must be
damaged.
Cut 8 mm of the coaxial cable at each end up to the
inner core.
Carefully cut 10 mm of the outer insulation so that the
wire netting is exposed.
Turn the wire netting backwards and wind it over the
outer insulation in such a manner that it does not touch
the inner core.
Remove the inner insulation together with the foil
placed over it up to 2mm before reaching the wire
netting.
Caution
The wire netting and the foil must not touch the inner
core. The foil must enclose the inner insulation and
must not be damaged.
Rotate the F connector onto the turned-back wire
netting until the connector touches the inner insulation.

The wire netting must not protrude from the back
of the connector.

18
Cut the inner core with a cable cutter in such a manner
that it projects maximum 1 mm from the connector.

19
Installation diagram
Fasten the F connector of the coaxial cable onto the
“LNB IN” antenna connection of the receiver. Fasten
the other end of the coaxial cable on the LNB.

20
SCART cable connection
Plug the SCART cable in the SCART socket “TV” of
the receiver.
Connect the SCART cable to the TV set. Follow the
instructions in the operating manual of the TV set.
Plug the SCART cable in the SCART socket “VCR” of
the receiver if you want to connect a video set.
Connect the SCART cable to the video set. Follow the
operating manual of the video set.
Insert the Cinch connector of the Cinch cable in the
“AUDIO-R” and “AUDIO-L” sockets of the receiver if
you want to connect a stereo system.

The Scart cable is not included in the scope of
supply.
