Sciener M101 User manual

Installation manualM101 Bluetooth Smart Lock - 170113

Find more information and help for your product at the following

Ocial website: http://www.sciener.co

Please read this manual carefully before installation

Anti-theft door lock

Product Installation and Parts List

Note: The door lock frame is greater than 110mm, and the door thickness can

be installed in the range of 35mm ~ 50mm.

●

Key x 2

Lock body x 1

55mm lock screw x 4

thumbturn spindle

Front panel Back panel Front & Back

rubber gasket

40mm screw sleeve

Wood screws x 5

Strike plate

Strike box

Spindle x 2

Standard electronic lock body

Please contact us at +6016-8220059 for assistance with installation,

commission-ing, etc. that have not been listed in the user's installation manual.

The performance of this product is under continuous improvement, subject to

change without notice.

●

Package list:

Model

Dimensions

Material

Weight

Communication Methods

Supporting systems

Stand-by current

Operating current

Power supply

Unlock time

M101

W76mm x H310mm x T30mm

Shell stainless steel / lock body iron

2.4KG (with lock body)

Bluetooth 4.0ble

Android 4.3 / iOS 7.0 above

≈20µA

≈200 mA

4 AA Alkaline 1.5V Batteries (LR6) (6V)

≈1.5 second

Precautions before installing and adjusting the door lock

Set up the lock function before installing

Add & delete password or Bluetooth administrator

Before installing the lock, please check that all the accessories are present. If your

door needs to drill holes across, please seek professional help in order to avoid

unnecessary property damage.

Before installation, connect the front panel of the lock to the back panel, bind the

lock with the app, and then install the lock to the door after setting up.

How to connect front and back panels

Remove the front panel power cord ①. Plug in ﬁgure ②position. Connect the

ﬁgure ③lock body connector to the battery case for testing.

●

Unlock key

Battery compartment

Pair with app using bluetooth

After power is on, while the front panel touchscreen backlight is o:

　1. Tap the touch screen to active

　2. Open the app

　3. Tap "proﬁle picture"- "+add lock" on the top left corner, select door lock.

　4. Select the lock device name that is found. After adding successfully,

　　 the page will jump to the lock list;

If not successful, repeat the above steps or long press the back panel

adapter and try again.

Important Note

Power

connector

Power

connector

Battery case

Front panel

Lock body

Install lock body and lock cylinder

If your door lock and panel mounting holes do not match with our products. You

need to ask for the professionals to refer to our products.

For attachments in the [drilling] hole, non-professionals should not arbitrarily open

holes to avoid causing property damage!

●

Cylinder ①position installation instructions

Restore lock tongue in place. Put the cylinder tongue through the door hole into

the lock body. If you encountered blocking, please shake the lock and try again.

Important Note

25mm wood screws

Lock cylinder

步骤(1)

Installation instructions

Front panel : After installing the lock body, connect the two connecting wires of the lock body. Connect the large plug the door to connect the front panel.

Then connect the small plug to the rear panel as shown in Figure ①②. Insert the square bar into the handle hole of the front panel and pad the rubber pad.

Back panel : Connect the lock connector. Insert the square bar of the rear panel of ﬁgure ③. Insert reverse locking square bar of ﬁgure ⑤and pad the rubber

pad. Screw in four 55mm screws. The installation is complete.

Install the front & back panel

后面板

Front Panel

55mm cylinder screw x2

Rubber

gasket

Rubber

gasket

Front panel spindle Back panel spindle

Back panel connector

Rear panel connector
