Scotsman Eclipse Series Installation guide

Technical Training
Technical Training
30 Inch Wide Eclipse
Modular Cubers

•Ice Making Head
– CME1386
– CME1686
•Compressor Package
– CP1316
– CP2086
•Condenser
– ERC1086
– ERC2086
Eclipse 1300
Eclipse 1300 - -2000 2000

The Eclipse System
The Eclipse System
•The remote system is made up of three parts:
– Ice Making Section or Head Unit - 115 volt
– Compressor Package - 208-230 volt
– AC Condenser - 208-230 volt
•Flexible Modular System
– CME1386 or CME1686 can connect to CP1316
– ERC1086 can be used on 1000, 1300 or 1600 systems
– All are R-404A systems

Ice Making Section
Ice Making Section
•30” Wide Head Units
•CME1386 or
CME1686 or
CME2086
– Remote Low Side
–CM
3technology
•Water and Control
Systems
•Rotomolded freezing
compartment

Ice Making Section
Ice Making Section
•Refrigerant
Line
Connections
– Vapor
– Liquid
–Suction
Vapor
Liquid
Suction

Ice Making Section
Ice Making Section
•Ice making
compartment
•Five or Six
evaporators
– CME1386 has 5
– CME1686 and
CME2086 have 6

Vapor Inlet Valve
Vapor Inlet Valve
•Purpose: Opens
during harvest to
allow vapor to enter
the evaporators
•24 volt coil

One TXV
One TXV
•Single externally
equalized valve
– Meters refrigerant
through a
distributor
TXV

Water Pump
Water Pump
•115 volt pump
•Same for all three
•Pedestal type
•Pump motor
separated from
reservoir
– Keeps motor drier
– Motor cap keeps
condensation off
motor

Controller
Controller
•AutoIQplus
•Uses sensors for
– ice harvest,
– bin full indications
– water reservoir
temperature
– water level
•Controls freeze and
harvest cycles
™

CME Electrical Box
CME Electrical Box
•Transformer 115
to 24, 85 VA
•Purge valve timer
•Control wire
connection
nearby
– Wire routes to
compressor
package
– Controls
contactor and
solenoid valves Box purposely mounted at an angle

Evaporator Covers
Evaporator Covers

Freezing Compartment
Freezing Compartment
Water Trough
Cube Deflector
Front Ice Sensor

Liquid Line
Temperature Sensors
Temperature Sensors
•Two sensors
– Water
•In pump discharge hose
•Used to check water temp for anti-slush and
refrigeration system operation
– Liquid
•Used to determine which pre-set time for first harvest
cycle
– Lower temperatures = longer first harvest cycle

Inlet Water Valve
Inlet Water Valve
•Opens to add water
and fill reservoir
– Adds water during
harvest
– Fills at beginning of
freeze
– Refills once more
during freeze

Purge Valve
Purge Valve
•Opens to drain the
reservoir during
harvest
•Controlled by purge
valve timer

Ice Sensors
Ice Sensors
•Infrared sensors
– Located at the ice
outlet port
– Create a light curtain
– Harvesting ice triggers
the sensor

Bin Thermostat
Bin Thermostat
•CME1386, CME1686
and CME2086 are all
equipped with a bin
thermostat.
•Thermostat routes
through hole in base.

Bin Thermostat
Bin Thermostat
•Thermostat bulb must
be mounted to the
bracket
•The bracket mounts
to the bottom of the
ice machine

Compressor Package
Compressor Package
•Two models
– CP1316
•Reciprocating compressor
– CP2086
•Scroll compressor
