DCE33 Ice Machine

All manuals and user guides at all-guidesbox.com

all-guidesbox.com

DCE33

DCE33

•Gravity Drain or

•Drain Pump models

•Reversible Door

•Air in and out the front

All manuals and user guides at all-guidesbox.com

DCE33 Installation

DCE33 Installation

•Water

– 1/4” OD copper tubing

•Power

– 115/60/1 cord connected

•Drain

– Gravity or pump

•Space

– 15 & 1/4” wide

All manuals and user guides at all-guidesbox.com

Water

Connection

DCE33 Installation

DCE33 Installation

•Air Cooled

– Route drain tubing

– Route water supply

All manuals and user guides at all-guidesbox.com

DCE33 Gravity Drain

DCE33 Gravity Drain

•Gravity Drain installation is critical

– Connect internally to bin drain

– Route flexible tubing out the back

– Route with downward pitch to drain receptacle - no

dips, no upward slopes, no traps.

•Use rigid tubing if possible

•Vent the drain tubing

•Must have air-gap at end

All manuals and user guides at all-guidesbox.com

DCE33 Drain Pump

DCE33 Drain Pump

•Magnetic drive drain pump

•Tubing included

– Do NOT kink!

•Can pump up to one story

•Field convertible

All manuals and user guides at all-guidesbox.com

all-guidesbox.com

Water: It flows downhill!

Water: It flows downhill!

Water Cannot Collect in a Downward Sloping Straight Tube

Water CAN collect in a Downward Sloping Flexible Tube

Trapped water restricts

draining!

All manuals and user guides at all-guidesbox.com

Reversing Door

Reversing Door

•Remove door

•Switch hinges top to bottom, left to right

•Return door to cabinet

All manuals and user guides at all-guidesbox.com

DCE33 Initial Start Up

DCE33 Initial Start Up

•Check installation

•Remove control box cover

•Rotate timer CW to Harvest

•Rotate bin control to “Operating

Range”

•After second batch, check cube

size

– Adjust cube size if needed

Timer in

Harvest

Position

All manuals and user guides at all-guidesbox.com

DCE33

DCE33

Cubes too large or too small:

Adjust cube size control.

CW makes cubes larger

CCW makes cubes smaller

All manuals and user guides at all-guidesbox.com
