Screen Innovations Nano Roll 375 Series User manual

Screen Innovations
9715-B Burnet Rd, Suite 400 Austin, TX 78758
512.832.6939
www.screeninnovations.com
Version 1.0
INSTALLERS: Please leave this manual with the owner.
120 VAC - RTS
PART NO. 400031
Nano Roll
Installation Instructions

Wall Brackets (375 / 475) + End Caps
PARTS LIST - NANO ROLL - 120 VAC - RTS
Parts list - Nano Roll - 120 VAC - RTS Pg 1
Motor Side Idler Side
Shades
375 Roll
475 Roll
Spacer Blocks (optional)
Screws included
(3 per bracket)
Note: For more information about these tools and their use, please call Tech Support at
512.832.6939 Opt. 1
PARTS LIST - NANO ROLL - 120 VAC - RTS
Parts list - Nano Roll - 120 VAC - RTS Pg 2
Leveling Shims (optional)
Set Screw Hex Tool
(1/8”)
5/16” Magnetic Driver
ADDITIONAL ACCESSORIES - NANO ROLL - 120 VAC - RTS

SPACER BLOCKS AND LEVELING SHIMS (OPTIONAL)
Spacer Blocks - used to clear an obstruction in the fabric path.
Leveling Shims - used if the window frame is out of level.
Connect to shade brackets before installation
Note: do not use more than 2 leveling shims per bracket.
Connect spacer blocks to shade brackets before installation
Note: Do not use more than 4 Spacer blocks per bracket.
Spacer Blocks and Leveling Shims (Optional) Pg 3 Pg 4
INSTALLATION - 120 VAC - RTS (375 / 475 SERIES)
Installation - Nano Roll - 120 VAC - RTS - 375 / 475
2. Install wall bracket/end cap assembly with the supplied screws
1. If mounting to a wall, remove the ceiling ange from motor and idler brackets
Before installing the shades, verify whether the shade was ordered as standard roll or reverse roll. Though
illustrations in this manual show standard roll shades, the installation for reverse roll shades is the same.
Motor Side Motor Side
for Ceiling Mount
Motor side Idler side
for Wall
Mount

INSTALLATION - 120 VAC - RTS (375 / 475 SERIES)
4. Remove both end caps
3. Measure bracket to bracket width and verify it matches the ordered width. Adjust accordingly.
Motor End cap
1/8” hex tool
Idler End cap
Pg 5
Installation - Nano Roll - 120 VAC - RTS - 375 / 475
Brackets must be level before the
shade is installed!
5. Push power cable into pre-wire hole
6. Align and fasten motor side.
Pg 6
INSTALLATION - 120 VAC - RTS (375 / 475 SERIES)
Installation - Nano Roll - 120 VAC - RTS - 375 / 475
There will be an audible click.
Note:
Motor cable is not plenum
rated. Terminate accordingly.

Installation - Nano Roll - 120 VAC - RTS - 375 / 475 Pg 7
INSTALLATION - 120 VAC - RTS (375 / 475 SERIES)
Click!
7. Then put idler end cap over idler and snap into place. 8. Replace and fasten motor end cap
Pg 8
Installation - Nano Roll - 120 VAC - RTS - 375 / 475
1/8” Hex tool
INSTALLATION - 120 VAC - RTS (375 / 475 SERIES)
