SCS IR-2000TS User manual

Features:
Through Beam Photoelectric Beam Sensor
IR-2000TS
INSTALLATION MANUAL
1
Sensing Range: 20 meters
IP-66 Water Proof
N.C. / N.O. /Common Relay Output
Terminal Block WiringConnection
Mounting Hardware Included
Tamper Switch Included
AC / DC 12 24 Input Voltage
Gate or Garage Door
Overhead Doors
Conveyer
Door Entrance
Parking Lot
Alarm System
Warehouse
Included:
Screw Hole
Screw Hole
Lens
Beam Alignmnet
Indicator
Relay
Power Led
Indicator
Terminal Block
Wiring Connection
Hole
Power Terminal
Block
Tamper Switch
Terminal Block
Tamper Switch
Part Account:
Specifications:
IR-2000TS SCREWS
Detection Method
Sensing Range
Input Voltage
Response Time
Emitting Element
Operation Indicator
Dimensions
Output Method
Current Consumption
Contact Current
Illumination
Connection Method
Noise Resistance
Surge Resistance
Vibration Resistance
Housing Material
Operating Temp.
Water Proof
Safety Standard
Through Beam
20 meters
AC / DC 12 24V
100 ms
IR LED
Red LED(Rx): ON(when beamis broken) Green (Tx): ON
46(w) 95(h) 34(t) mm
Relay Output
Tx: 25mA / Rx:25 mA (when beamalignment properly)
Tx: 25mA / Rx:15 mA (when beamis broken)
1A / 120VAC
Lamplight < 10,000 Lux; Sunlight < 30,000Lux
Terminal Block
1500Vp-P / 1us
2KV / 1uS
10-55Hz / 1.5mm, 2Hour In X.Y.Z.Phase
Casing: Nylon Cover: PCresin
-20 60
IP-66
CE
Application:

TX RX
2
INSTALLATION MANUAL
Wiring Connection:
RECEIVER TRANSMITTER
1122
33
44
567
Tamper Switch
Tamper Switch
Terminal Block
COM
N.C.
N.O.
AC/DC 12 24V
(Non-polarity)
AC/DC 12 24V
(Non-polarity)
Sensing Range:
Note:
20 meters
Dimensions:
34
25
73
95
28
46
UNIT: mm
(O) (X)
Wiring Connection
When installation, Please make sure that
the hole for cable should be on the down side.
