Sea-doo SEASCOOTER PRO User manual

English Version
CAUTION
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 16 years of age. As with all
electrical products, precautions should be observed during handling
to reduce the risk of electric shock.
User Manual
SDP15870
Distributors in the United States and Canada provide a standard Limited
Warranty for 6 months from the date of purchase for new products. If
you're not located in the United States or Canada, please contact your
Local Distributor for warranty arrangements in your territory. Please
visit www.seadooseascooter.com for Distributor / Service Center details.
Distributors ONLY warrant Stallion products purchased from an
authorized dealer.
Ask your Local Distributor for the warranty period in your region by calling their
Service Center. Any part of the product supplied by the Distributor and found in the
reasonable judgment of the Distributor to be defective in material or workmanship
will be repaired or replaced by the Distributor without charge for parts or labor. The
product including any defective part must be sent to the Distributor within the
warranty period. The customer will pay for the expense of delivering the product to
the Distributor. The Distributor will pay for the expense of returning the product to
the customer.
ALWAYS ACTIVATE YOUR WARRANTY IMMEDIATELY ON
http://www.seadooseascooter.com/warranty.html
www.seadooseascooter.com
WARRANTY & CUSTOMER SERVICE
INFORMATION
Distributors ONLY warrant products with an active
Warranty Registration
SEE NEXT PAGE
Model no. SD5540
SEA-DOO®SEASCOOTER™ GTI
Model no. SD6545 X
SEA-DOO®SEASCOOTER™ VS SUPERCHARGED X
Model no. SD25001
SEA-DOO®SEASCOOTER™ GTS
Model no. SD75001
SEA-DOO®SEASCOOTER™ PRO
GTI
VS SUPERCHARGED PLUS
PRO
GTS

Contents Introduction
Introduction 1
Parts diagram 2
Warnings 4
Getting started 6
Battery use 11
Charging the battery 15
Care & maintenance 21
Trouble shooting 23
Technical specifications 28
Thank you for having chosen the SEA-DOO®SEASCOOTER™
PRO / GTI / VS SUPERCHARGED PLUS / GTS - with the
SEASCOOTER™swimming, snorkeling and diving is effortless
and fun.(Only use the seascooter for scuba diving if you are
a qualified diver)
Use appropriate equipment such as wetsuit, buoyancy
control device, fins, mask & snorkel, surface signaling
device, regulator(s) approved life jacket etc. when
operating the seascooter.
Only operate the Seascooter in water.
- SEASCOOTER™ PRO -
• Speed up to 2.0 mph / 3.2 km/h
• Run up to 1 hour with normal use
• Rated to 65 ft / 20 m
• Weight just 13 lb / 6 kg including battery
- SEASCOOTER™ GTI -
• Speed up to 2.5 mph / 4 km/h
• Run up to 2 hours with normal use
• Rated to100 ft / 30 m
• Weight just 18 lb / 8.2 kg including battery
- SEASCOOTER™ VS SUPERCHARGED PLUS -
• Speed up to 3 mph / 4.8 km/h
- SEASCOOTER™ GTS -
• Speed up to 2.8 mph / 4.5 km/h
• Run up to 1.5 hours with normal use
• Rated to100 ft / 30 m
• Weight just 18 lb / 8.2 kg including battery
There are many features incorporated in this sophisticated
design, please take time to study the manual to learn about
them all to get the most out of your SEASCOOTER™.
1
Discarded electrical appliances are
recyclable and should not be discarded
in the domestic waste! Please actively
support us in conserving resources and
protecting the environment by returning
this appliance to the collection centers
(if available).
• The seascooter is designed for 1 person use
• The seascooter is not a life saving device. Do not use it as
a buoyancy aid
WARNING
The Seascooter is designed for use in seawater. It will
have less buoyancy in fresh water, lake or pool and
may sink in such waters.

Parts Diagram
-SEASCOOTER GTI / VS SUPERCHARGED PLUS / GTS-
1
2a
2b
3
11 10
12
13
14
15
7
6
8
9
5
4
16 17 18
Fig.2
3
Parts Diagram
-SEASCOOTER PRO-
2
1
23
11 10
12
13
14
7
6
8
9
5
4
15 16 17
Fig.1
1 Latch
2a Nose Cone (GTI and
VS SUPERCHARGED PLUS)
2b Nose Cone (GTS)
3 Inner Nose Cone
4 Vent Plug
5 Trigger
6 Handle
7 Nozzle
8 Propeller
9 Protective Grilles
10 Battery Housing
11 Master Switch
1 Latch
2 Nose Cone
3 Inner Nose Cone
4 Vent Plug
5 Trigger
6 Handle
7 Nozzle
8 Propeller
9 Protective Grilles
10 Battery Housing
11 Master Switch
12 Battery
13 Vent Hole
14 Buoyancy Control
Chamber
15 Silicone Ring
16 Pump
17 Lubricant
18 Charger
19 Charger Jack
21
(For VS Supercharged Plus only)
12 Battery Leads
13 Battery
14 Vent Hole
15 Buoyancy Control
Chamber
16 Silicone Ring
17 Pump
18 Lubricant
19 Charger
20 Charger Jack
21 Nose Cone Protector
18
19
19
20

• Never remove the grilles except for maintenance.
•
Always charge battery to its maximum before using the
SEASCOOTER™. After charging is complete the battery
will continue to emit gas. Wait at least 30 minutes after
charging before removing the battery from the charger or
placing the battery into the battery housing. Failure to do
so could result in an explosion.
•
Ensure sufficient battery charge remains for return to
shore or surface.
• The Seascooter™ is not a personal floatation device -
always wear a Approved Personal Flotation Device /
Approved Life-Preserver when using the Seascooter™ for
snorkeling.
•
Be aware of appropriate water levels, tidal changes,
dangerous currents, weather changes and strong offshore
winds. Always scout unfamiliar water.
54
Warnings
14 +
14 +
16 +
•Read the user's manual carefully before use.
•Always follow this age recommendation: a
child under 16 years old should never operate
this SEA-DOO®SEASCOOTER™.
•Crushing / Cutting Hazard
•Be careful when you are transporting the
Seascooter and setting it down to avoid
crushing hazard on hands, foot or toes.
•This is not a life saving device.
•Never stick body parts, clothing or other
objects in the vicinity of the Propeller. Do not
wear loose or flowing clothing or equipment
that could be drawn into the propeller.
•Particular care should be exercised when
using the SEASCOOTER™ near anybody
with long hair. Users with long hair should tie
it up or wear a swimming cap when using the
SEASCOOTER™.
•Always inspect the swimming area to ensure
it is free of hazards or obstacles such as
boats and swimmers before using the
SEASCOOTER™.
• ALWAYS wear a life vest (personal floatation
device - PFD) approved by your local
authorities for Snorkeling: (U.S. Coast Guard
Type III vest in the US or Canadian Coast
Guard approved life vest in Canada or SAI
Approval PFD in Australia or CE / ISO
Approved PFD in Europe).

Getting Started
• Do not use alcohol or drugs prior to using this product.
• ALWAYS keep the SEA-DOO®SEASCOOTER™out of
direct sunlight when not in use. HEAT KILLS BATTERIES
AND IT MAY EXPLODE OR LEAK.
• When using the SEA-DOO®SEASCOOTER™for
SCUBA-DIVING, ascents and descents should be made in
accordance with recognized diving practices.
• The SEA-DOO®SEASCOOTER™should only be used for
SCUBA-DIVING by qualified divers.
• Never open the Cover of the SEA-DOO®SEASCOOTER™
in the water.
• When not in use, always turn the Master Switch to the off
position.
•
Do not use the SEASCOOTER™PRO below the
recommended maximum depth of 20m/65ft.
•
Do not use the SEASCOOTER™GTI / VS SUPERCHARGED
PLUS / GTS
below the recommended maximum depth of
30m/100ft.
• ALWAYS remove the battery from the unit when not in use.
• DO NOT store the battery in the unit
CAUTION:
• In different waters (seawater, lake, pool) and conditions
such as currents, temperature and pressure can affect the
buoyancy of the unit which may cause the unit to sink if
accidentally released.
• DO NOT release or leave the Seascooter in the water.
Always take the unit out of water when not in use.
When you buy the
SEA-DOO®SEASCOOTER™ the battery
is disconnected and needs to be charged. Follow the
Battery Instruction on pages 12 to 15 and charging
instructions on pages 16 to 19.
Using the SEASCOOTER™for swimming and snorkeling.
When swimming or snorkeling the SEA-DOO®
SEASCOOTER™
should be kept positively buoyant - this is
done by simply making sure the Buoyancy Chamber is
empty and fitted inside the Nose Cone.
To use the SEASCOOTER™for swimming or snorkeling
follow these instructions.
1.Charge the battery and install just before use.
2.Make sure that Vent Plug is closed.
3.Replace the Buoyancy Control Chamber.
4.Place the SEA-DOO®SEASCOOTER™ into the water so
the Handle, Outer Nose Cone and Nozzle fill with water.
CRUSHING HAZARD:
The following action during assembly, disassembly, and
transportation of the seascooter may incur crushing hazards
to your fingers or toes:
-Closing the nose cone latches
-Putting on the nose cone housing
-Placing the battery into the seascooter
-Accidental dropping of the seascooter or battery.
6 7

5.When ready to set off, turn the Master Switch to the
On position shown in figure 3.
6. Pull and hold both Triggers to start the Propeller.
(There is a short delay before the Propeller begins
to rotate).
7. To stop the Propeller, simply release the Triggers.
8.Always turn the Master Switch off when out of the water.
9.
Proper posture when using the SEA-DOO®
SEASCOOTER™ is important to achieve the maximum
speed - see figure 4 for the correct position of the
SEA-DOO®SEASCOOTER™when using it.
Fig.3
SEASCOOTER GTI / VS SUPERCHARGED PLUS
Shown in "ON" position
Rotate to turn "OFF"
CAUTION
Do not dive deeper than you would normally when snorkeling,
to ensure you can get back to the surface safely.
Important Notice: This machine is not to use to mix
or to work with sand, concrete and material with
similar physical characteristics. This machine is
only to use for diving in water.
98
SEASCOOTER PRO
Shown in "ON"
position Rotate to turn
"OFF"
Fig.4
PRO
GTI
VS SUPERCHARGED PLUS
GTS

Using the SEA-DOO®SEASCOOTER™
for diving - adjusting the buoyancy.
Your SEASCOOTER™ PRO can be used for diving up to
20m/65ft but will need to be adjusted for neutral buoyancy.
Your SEASCOOTER™ GTI / VS SUPERCHARGED PLUS /
GTS can be used for diving up to 30m/100ft but will need to be
adjusted for neutral buoyancy.
The SEASCOOTER™must never be adjusted for negative
buoyancy to avoid it sinking if accidentally released.
To adjust for neutral buoyancy follow these instructions
1.
Make sure the SEA-DOO®SEASCOOTER™ is in the Off
position.
2. Remove the SEASCOOTER™from the water, give a half
turn to the Latches, remove them (see figure 5) and
remove the Buoyancy Control Chamber.
3. Open the Buoyancy Chamber and add a small amount of
rocks or a lead weight (see figure 6).
4.
Cover the Buoyancy Chamber with the Nose Cone then
secure the latches and place the SEASCOOTER™ in the
water. If the SEASCOOTER™ is neutrally buoyant it will
neither float nor sink.
5. If the SEASCOOTER™ sinks, remove the weight until it is
neutrally buoyant.
If the SEASCOOTER™ is still positively buoyant repeat
step 3, until it is neutrally buoyant.
Rotate 180oand remove to open
Fig.5
1110
Fig.6
CAUTION
If the SEASCOOTER™is later used for swimming or
snorkeling be sure to remove the weight from the
Buoyancy Chamber so the SEA-DOO®SEASCOOTER™
has positive buoyancy.
PRO
GTI
VS SUPERCHARGED PLUS GTS

Battery UseBattery Use
1312
RE-CHARGE THE BATTERY
3
3
AT LEAST
MONTHS
EVERY
MONTHS
WARNING
BATTERY SAFETY
• Must remove and store the
battery separately from the unit
when not in use!
• Must re-charge the battery after
use WITHIN 24 HOURS.
• Must re-charge the battery at
least EVERY THREE MONTHS
when not in use.
User Manual must be read and
understood before use.
Please read and follow the
Battery Safety Instruction.
Incorrect battery maintenance
may reduce the battery life and
influence its function.
www.seadooseascooter.com
CAUTION
• Your SEA-DOO®SEASCOOTER™is supplied with a
battery that needs to be treated carefully as it will
release potentially explosive gases during its normal
cycle of use (off-gassing). Failure to do so can result
in an explosion occurring. Please read the entire
manual thoroughly and follow all instructions.
• Always remove the battery from your SEA-DOO®
SEASCOOTER™when it is not in use. Store
separately in a well ventilated area where it is out of
the reach of children and away from heat and ignition
sources.
• Do not attach the battery in your SEA-DOO®
SEASCOOTER™ until prior to using it.
• Before disconnecting/connecting any cables, open the
nose cone and allow two minutes for any explosive
gases to dissipate.
• Do not use/store/charge the battery in temperatures
above 40ºC (104ºF) as excessive off-gassing may
occur. Keep the battery and SEA-DOO®
SEASCOOTER™in the shade when not in use.
• Always ensure the unit is dried thoroughly before
opening the Nose Cone.
• Only use the charger supplied with the SEA-DOO®
SEASCOOTER™.

Battery UseBattery Use
1514
CAUTION
• The battery supplied with your SEA-DOO®
SEASCOOTER™releases a potentially explosive gas
during charging. Charging should only take place in a
well ventilated area, away from children and open
flames or other ignition sources (cigarettes, sparks).
Never charge the battery while still in the SEA-DOO®
SEASCOOTER™.
• Charge the battery as soon as possible after use within
24 hours.
• Always charge the battery to the fullest before using
the SEA-DOO®SEASCOOTER™.
• Always remove the battery from the battery housing
before charging.
• Always connect charger jack to the battery first and
then plug charger into the electrical socket/plug.
• After charging, disconnect from the electrical
socket/plug first and then disconnect the battery from
the charger.
• After charging is complete the battery will continue to
emit gas. Wait at least 30 minutes after charging before
removing the battery from the charger or placing the
battery into the battery housing. Failure to do so could
result in an explosion.
•
Remove battery from charger once fully charged.
CAUTION
• Never charge the battery in sealed container.
• Never charge the battery near water.
• Never short circuit the battery or battery connectors.
• Always ensure the charger is dry before use.
• The charger gets quite warm in use - this is normal.
• If in doubt of the state of the battery, recharge it until
the indicator on the battery charger indicates a full charge.
• If the battery is not to be used for an extended period,
store it in a well ventilated area away from children,
heat, and ignition sources. Recharge it every three
months to maintain charge and avoid excess
off-gassing. DO NOT store the battery inside the
SEA-DOO®SEASCOOTER™.
• If the battery appears damaged or will not fully charge,
the battery must be replaced. If battery life is noticeably
reduced, the battery should be replaced.
• The battery supplied with your SEA-DOO®
SEASCOOTER™ should last about 200 cycles or two
years before it should be replaced. Please contact your
local customer service center/distributors. Using a
battery in excess of these recommendations can result
in excessive off-gassing of explosive gases.

Charging the battery
For battery charging follow these instructions.
1. Always ensure that the Master Switch is Off -
see figure 3.
2. Always ensure that the SEA-DOO®SEASCOOTER™
is out of the water, dry and placed in a dry area.
3. Give a half turn to the Latches and remove them from
the Nose Cone as shown in figure 5.
4. Remove the Outer Nose Cone and Buoyancy Control
Chamber.
5. Open the Vent by unscrewing the Vent Plug.
6. Remove the Inner Nose Cone. To do this, first feed the
silicone ring (provided with this manual) through the
latch holes in the Inner Nose Cone and pull over the
hooks on the Battery Housing (see figure 7). Then
screw the Pump Nozzle onto the Vent Hole and pump
air into the Battery Chamber until the Inner Nose Cone
pops off and then remove the silicone ring.
7. Allow two minutes for any gases to dissipate.
8. Disconnect the battery cable from the housing cable (if
not already disconnected - the cable will be
disconnected when you buy your SEASCOOTER™) by
pressing the locking feature, as shown in figure 8.
9. Remove the battery and place on a level surface.
10.Connect the battery cable to the charger cable.
11. Plug charger into mains, and turn on the supply.
12.SEASCOOTER PRO - Charging will take 4 to 6 hours
for a fully discharged battery.
SEASCOOTER GTI / VS SUPERCHARGED PLUS /
GTS - Charging will take 6 to 8 hours for a fully
discharged battery.
When the battery is charging the red LED is lit, when
the battery is charged the green LED is lit.
13.Disconnect the charger from the electrical plug/socket.
14.Allow battery to stand for 30 minutes before using it.
Important Notice: Keep the silicone ring permanently (Refer
to Page 2 and 3, Parts Diagram).Removing the inner nose
cone without the silicone ring is dangerous
1716
Fig.7
Press here to release and pull to disconnect
Fig.8
Warning!
Replace the battery immediately if it is damaged.
