Seagate Medalist Pro 4520 User manual

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .
Medalist Pro 9140
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .
Medalist Pro 6530
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .
Medalist Pro 4520
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .
Ultra ATA Interface Drives
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Manual
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .
Medalist Pro 9140 (ST39140A)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .
Medalist Pro 6530 (ST36530A)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .
Medalist Pro 4520 (ST34520A)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .
Ultra ATA Interface Drives
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Manual
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

© 1998 Seagate Technology, Inc. All rights reserved
Publication Number: 32659-001, Rev. B, April 1998
Seagate, Seagate Technology, the Seagate logo, Medalist and the
Medalist logo are registered trademarks of Seagate Technology, Inc.
Other product names are trademarks or registered trademarks of their
owners.
Seagate reserves the right to change, without notice, product offerings
or specifications. No part of this publication may be reproduced in any
form without written permission from Seagate Technology, Inc.

Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specification summary table . . . . . . . . . . . . . . . . . . . . 3
1.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . 5
1.1.1 Standard configuration . . . . . . . . . . . . . . . . . . 5
1.2 Physical organization . . . . . . . . . . . . . . . . . . . . . 6
1.3 Functional specifications . . . . . . . . . . . . . . . . . . . . 6
1.4 Physical dimensions . . . . . . . . . . . . . . . . . . . . . . 7
1.5 Seek time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6 Multisegmented cache buffer . . . . . . . . . . . . . . . . . 7
1.7 Start and stop times . . . . . . . . . . . . . . . . . . . . . . 8
1.8 Typical power-up and power-down sequence . . . . . . . . . 8
1.9 Power-up sequence . . . . . . . . . . . . . . . . . . . . . 9
1.9.1 Power-down sequence . . . . . . . . . . . . . . . . . . 9
1.10 Auto-park . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.11 Power specifications . . . . . . . . . . . . . . . . . . . . . 9
1.11.1 Power management . . . . . . . . . . . . . . . . . . . 9
1.11.2 Power consumption . . . . . . . . . . . . . . . . . . 11
1.12 Input noise . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.13 Environmental specifications . . . . . . . . . . . . . . . . 12
1.13.1 Ambient temperature . . . . . . . . . . . . . . . . . . 12
1.13.2 Temperature gradient . . . . . . . . . . . . . . . . . 12
1.13.3 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.13.4 Relative humidity . . . . . . . . . . . . . . . . . . . . 12
1.14 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.14.1 Operating shock . . . . . . . . . . . . . . . . . . . . 12
1.14.2 Nonoperating shock . . . . . . . . . . . . . . . . . . 13
1.14.3 Operating vibration . . . . . . . . . . . . . . . . . . . 13
1.14.4 Nonoperating vibration . . . . . . . . . . . . . . . . . 13
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B iii

1.14.5 Acoustics . . . . . . . . . . . . . . . . . . . . . . . 13
1.15 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.16 Agency listings . . . . . . . . . . . . . . . . . . . . . . . 14
1.17 Electromagnetic Compliance for the European Union . . . 14
1.18 FCC verification . . . . . . . . . . . . . . . . . . . . . . . 15
2.0 Configuring and mounting the drive . . . . . . . . . . . . . 17
2.1 Handling and static-discharge precautions . . . . . . . . . 17
2.2 I/O cable and connector. . . . . . . . . . . . . . . . . . . . 18
2.3 Power connector . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 Options jumper block . . . . . . . . . . . . . . . . . . . . 19
2.4.1 Master/slave configuration . . . . . . . . . . . . . . . 20
2.4.2 Alternate capacity jumper . . . . . . . . . . . . . . . . 21
2.4.3 Cable-select option . . . . . . . . . . . . . . . . . . . 21
2.4.4 Remote LED . . . . . . . . . . . . . . . . . . . . . . 21
2.5 Mounting the drive . . . . . . . . . . . . . . . . . . . . . . 22
3.0 ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.1 ATA Interface connector pin assignments . . . . . . . . . . 25
3.2 Command set . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2.1 Identify Drive command (ECH) . . . . . . . . . . . . . 29
3.2.2 Set Features command (EFH) . . . . . . . . . . . . . . 32
3.2.3 Standby timer timeout period . . . . . . . . . . . . . . 34
3.2.4 Automatic Reallocation . . . . . . . . . . . . . . . . . 34
3.2.5 S.M.A.R.T. command (B0H) . . . . . . . . . . . . . . . 35
3.3 Synchronous DMA Transfer . . . . . . . . . . . . . . . . . 36
3.3.1 Signal Line Definitions . . . . . . . . . . . . . . . . . . . 36
3.3.2 Protocol Rules . . . . . . . . . . . . . . . . . . . . . . 36
3.3.3 Error Register . . . . . . . . . . . . . . . . . . . . . . 37
Appendix. Timing diagrams . . . . . . . . . . . . . . . . . . 39
iv Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

Figures
Figure 1. Typical startup current profile . . . . . . . . . . . . . . . . 8
Figure 2. ATA interface connector . . . . . . . . . . . . . . . . . 18
Figure 3. Connectors . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 4. Configuration settings . . . . . . . . . . . . . . . . . . . 20
Figure 5. Connecting cable-selected drives . . . . . . . . . . . . . 22
Figure 6. Mounting dimensions . . . . . . . . . . . . . . . . . . . 23
Figure 7. ATA interface connector pin assignments . . . . . . . . 26
Figure 8. Programmed I/O timing without IORDY . . . . . . . . . . 39
Figure 9. Programmed I/O timing with IORDY . . . . . . . . . . . 40
Figure 10. Multiword DMA timing . . . . . . . . . . . . . . . . . . 41
Figure 11. Sustained synchronous DMA burst . . . . . . . . . . . 42
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B v

vi Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

Introduction
This manual describes the functional, mechanical and interface specifi-
cations for the Medalist®Pro 9140, the Medalist Pro 6530 and the
Medalist Pro 4520 hard disc drives. The drives are referred to throughout
this manual by their model numbers, ST39140A for the Medalist Pro
9140, ST36530A for the Medalist Pro 6530, and ST34520A for the
Medalist Pro 4520.
Seagate®desktopproductstakeastepintothefuturewiththeST39140A,
ST36530A and ST34520A. These drives feature MR heads and EPRML
recording technology, Ultra ATA performance, 7,200-RPM technology,
segmented cache, embedded servo technology, low noise and power
management.
Ultra ATA performance means that the drive supports PIO mode 4,
multiword DMA mode 2 transfer modes and synchronous DMA mode.
When the host chooses Ultra DMA mode 2, the drive provides burst
transfer rates of up to 33.3 Mbytes per second. The multiple block
read/write feature allows the drive to store several blocks of data in its
512-Kbyte segmented cache and transfer the blocks in a single burst.
The Medalist Pro drives have other features that ensure fast data
throughput.Embeddedservotechnologyallowsthedrives topositionthe
heads for data retrieval efficiently and accurately while eliminating the
periodic thermal recalibration that can interrupt data transfers. An intel-
ligent controller provides data streaming: direct data transfers between
the drive and the host without microprocessor intervention. These fea-
tures allow for a sustained data-transfer rate that facilitates video play-
back and other multimedia operations.
ThedrivessupportActive,IdleandStandbypower-managementmodes.
Power-saving modes can be controlled by the host computer. Standby
mode reduces power consumption to 3.0 watts (typical) while retaining
drive accessibility.
Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T.) is
available on these drives. This feature is discussed on page 35. To use
the feature, you must have a BIOS, a software driver or application
software that supports S.M.A.R.T.
The ATA commands with specific applications for these drives and the
Seagate-unique commands the drives use are discussed in Section 3.0
onpage25.Acompletelistofthecommandsthedrivessupportarefound
in the table on page 27.
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 1

The following is a summary of the drives’ features:
Capacity
•9.1, 6.5 and 4.5 Gbytes formatted
•LBA translation support
•Available software driver that surpasses the 528-Mbyte barrier and
4,092-cylinder barrier limited by some system BIOSs
•Available software driver that provides expanded 32-bit disk access
support for Windows 3.
x
Performance
•Ultra ATA (Burst transfer rates up to 33.3 Mbytes per second)
•Supports multiword DMA mode 2, Ultra DMA mode 2, PIO mode 4
and multiple block read/write.
•512-Kbyte segmented buffer
•9.5-msec average read seek time
•10.5-msec average write seek time
•Data streaming
Energy-efficiency
•Active, Idle and Standby power-management modes
•3.0 watt typical power dissipation rating in Standby mode
2 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

Specification summary table
The following table serves as a quick reference for the drives’ perform-
ance specifications. These and other specifications are discussed in
“Specifications” on page 5.
Drive specification ST39140A ST36530A ST34520A
Guaranteed capacity (Gbytes)
(×109bytes) 9.11 6.55 4.55
Guaranteed sectors 17,803,440 12,715,920 8,890,560
Bytes per sector 512
Sectors per track 63
Logical read/write heads 16 15 15
Logical cylinders 16,383 13,456 9,408
Physical cylinders 9,006 9,006 9,006
Physical read/write heads 8 6 4
Discs 4 3 2
Areal density (Mbits per
square inch) 1,715.2
Data zones 19
Recording density (Kbits per
inch) 179.2
Track density (tracks per inch) 9,570
Spindle speed (RPM) 7,200
Track-to-track seek time (msec
typical) 2.0
Average read seek time (msec
typical) 9.5
Average write seek time (msec
typical) 10.5
Full-stroke seek time (msec
typical) 21
continued
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 3

Drive specification ST39140A ST36530A ST34520A
Average latency (msec) 4.16
Internal minimum data-transfer
rate (Mbits per sec max) 193.88
External transfer rate (Mbytes
per sec max) 33.3
Cache buffer (Kbytes) 512
ECC on-the-fly (bits) 65
Height (inches max) 1.027
Width (inches max) 4.023
Depth (inches max) 5.787
Typical weight (lb) 1.5
Spinup current (max) 2.5A
Seek power (typical) 13.0W
Read/Write power (typical) 11.0W
Idle total power (typical) 11.0W
Standby/Sleep total power
(typical) 3.0W
Voltage tolerance (including
noise): +5V ± 5%
Voltage tolerance (including
noise): +12V ± 5%
Operating temperature (°C) 5° to 55°C
continued from previouspage
4 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

1.0 Specifications
1.1 Formatted Capacity
These drives support cylinder-head-sector (CHS) and logical-block ad-
dressing (LBA) translation modes. You can use the Identify drive (ECH)
command to verify the address modes the drives support, the number of
cylinders,sectorspertrack,totalnumberofsectors,headsandotherparame-
ters. The Identify drive parameters are listed in Section 3.2.1 on page 29.
Notes:
1. DOS and FAT 16 cannot access more than 2.147 Gbytes per parti-
tion. You must create multiple partitions to access the drive’s full ca-
pacity.
2. One Mbyte equals one million bytes.
3. If the system BIOS does not support more than 4,092 cylin-
ders, it may cause the computer to hang during startup, or it
may truncate or wrap the cylinders. To resolve this issue, the
system BIOS needs to be modified: the cylinder register or
variable must be increased from 12 bits to 16 bits to accommo-
date more than 4,092 cylinders.
1.1.1 Standard Configuration
CHS Mode ST39140A ST36530A ST34520A
Cylinders 16,383 13,456 9,408
Heads 16 15 15
Sectors 63 63 63
Guaranteed sectors 17,803,440 12,715,920 8,890,560
Guaranteed capacity
(Gbytes) 9.11 6.55 4.55
LBA Mode
When addressing either drive in LBA mode, all blocks (sectors) are
consecutively numbered from 0 to
n–
1
.
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 5

1.2 Physical organization
ST39140A ST36530A ST34520A
Read/write heads 8 6 4
Discs 4 3 2
1.3 Functional specifications
Interface Ultra ATA
Recording method EPRML (16/17 )
External data burst transfer rate:
DMA mode 2 (Mbytes per sec)
PIO mode 4 (Mbytes per sec)
Synchronous DMA mode 2
16.6
16.6
33.3
Internal minimum data-transfer rate
(Mbits per sec) 193.88
Spindle speed (RPM) 7,200 ± 0.5%
Cache size (Kbytes) 512
Bytes per sector 512
Areal density (Mbits/sq. in) 1,715.2
Data zones 19
Recording density, max (Kbits) 179.2
Track density (TPI) 9,570
Note. See Figure 8 on page 39 and Figure 9 on page 40 for PIO timing
specifications. See Figure 10 on page 41 and Figure 11 on page
42 for DMA timing specifications.
6 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

1.4 Physical dimensions
The mounting dimensions are shown in Figure 6 on page 23.
Height, max 1.027 inch (26.1 mm)
Width, max 4.010 inches (101.9 mm)
Depth, max 5.787 inches (146.1 mm)
Weight 1.5 lb (0.68 Kg)
1.5 Seek time
Seek value is the interval between the time the actuator begins to move
and the time the head has settled over the target track. Seek time is a
true statistical average of at least 10,000 measurements of seek time.
All measurements are taken under nominal conditions of temperature
and voltage with the drive mounted horizontally. The specifications in the
table below are defined as follows:
•Track-to-track seek time is the average of all possible single-track
seeks in both directions.
•Average seek time is measured by executing seeks in both directions
between random cylinders.
•Full-stroke seek time is half the time needed to seek from track 0 to
the maximum track and back to track 0.
Track-to-track
seek time (typ) Average/typical seek time Full-stroke seek time (typ) Average latency
2.0 msec seek
2.5 msec read
3.5 msec write
9.5 msec read
10.5 msec write 21.0 msec seek 22.0 msec read
23.5 msec write
4.16 msec
Note. Host overhead varies between systems and cannot be specified.
Drive internal overhead is measured by issuing a no-motion seek.
Overhead is typically less than 0.5 msec.
1.6 Multisegmented cache buffer
The Medalist Pro ST39140A, ST36530A, and ST34520A drives are
available with a 512-Kbyte, multisegmented cache buffer that improves
performance by reducing access times.
Read look-ahead. The drive uses the read segments to store additional
logical sectors, after the last requested sector, into a buffer before the
computer requests the additional sectors. The cache buffer stores data
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 7

from the start of a read until the buffer segment is full or until another
command is received.
Write immediate. The drive uses the write segment to store write
commands and data. After the drive receives all of the data for the
command, it issues a write complete. Then, the drive writes the data to
the disc.
Write merging. The drive accepts contiguous write commands and
executes them as one command.
1.7 Start and stop times
Within 20 seconds after power is applied, the drive is ready. Within 15
seconds after power is removed, the drive spindle stops rotating.
1.8 Typical power-up and power-down sequence
This section describes typical power-up and power-down sequences to
assist you in evaluating the drive’s performance. They are not perform-
ance specifications. A typical startup current profile is shown in Figure 1.
Startup current profiles are unique for each drive.
2.5
2.0
1.5
1.0
0.5
0024 6
81012
14 16
Current (Amps)
Time (seconds)
Figure 1. Typical startup current profile
8 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

1.9 Power-up sequence
1. Power is applied to the drive.
2. The spindle motor reaches operating speed in about 4 seconds.
3. The airvane actuator-lock releases the actuator.
4. The drive synchronizes to servo pattern.
5. Calibration routines are performed.
5.6. The heads move back to track 0 and the drive is ready.
1.9.1 Power-down sequence
Caution. Do not move the drive until the motor has come to a complete
stop.
1. The power is turned off.
2. The read/write heads automatically move to the landing zone, which
is inside the maximum data cylinder.
3. The airvane actuator-lock mechanism locks the arm. This completes
the power-down sequence.
4. Within 15 seconds, the drive stops rotating.
1.10 Auto-park
During power-down, the read/write heads automatically move to the
landing zone. The heads park inside the maximum data cylinder and the
airvane actuator-lock engages. When power is applied, the heads recali-
brate to track 0.
1.11 Power specifications
1.11.1 Power management
ThedrivesupportsActive, IdleandStandbypower-managementmodes.
The power-management commands the drive supports are listed in the
table on page 27. Thetable on page11showstheaveragetypical power
consumption rates for each power-management mode. The test criteria
for each mode is defined on the following page. The Idle and Standby
timers are disabled at the factory.
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 9

All measurements were taken at the drive power connector. A true RMS
meter is used to measure all modes except Standby. A DMM is used for
Standby measurements.
1.11.1.1 Active mode
During the Active mode, the drive is involved in spinup, seeking or
read/write activities. The table on page 11 shows the typical power-con-
sumption rates for these activities.
•Spinup. The drive enters the Spinup mode from the Standby mode
and brings the spindle and discs up to operating speed. Power in this
mode is defined as the peak power after starting spinup.
•Seek. The drive enters the Seek mode from the Idle mode. The
read/write heads are moved to a specific location on the disc surface
in preparation for reading from or writing to the disc. Read/write
electronicsarepowereddownbutservoelectronicsareactive.Typical
power is defined as the power average of executing random seeks
with a 2-revolution (22.2 msec) dwell between Seek commands.
•Read/write. Read/write mode is entered from Idle mode. Read/write
electronics are activated and the servo is on track. The drive reads
from or writes to the disc.
1.11.1.2 Idle mode
The Idle mode is entered 1 minute after the last disc I/O activity. The
motor is up to speed and the actuator is repositioned once every minute.
The drive enters Idle mode from either Active or Standby mode, when
the host issues an Idle command only.
1.11.1.3 Standby mode
The spindle is stopped, the heads are parked in the landing zone, the
actuator is latched and some of the drive electronics are powered down.
Note. When recovering from Standby or Sleep mode, you must allow
the drive to post ready before reporting a timeout. The drive can
take up to 20 seconds to post ready. In a master and slave
configuration, the master can wait up to 31 seconds for the slave
to complete diagnostics before posting ready.
10 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B

1.11.1.4 Sleep Mode
The sleep mode implementation is the same as in Standby mode.
1.11.2 Power consumption
Inthetablebelow,thevaluesapplyatthedrivepowerconnector.Current
was measured with an RMS DC ammeter.
Spinup Seek Read/
write Idle Standby
Current at +12V
Amps max 2.5 — — — —
RMS amps typ — 0.93 0.78 0.76 0.11
Watts typ — 11.12 9.33 9.09 1.38
Current at +5V
RMS amps typ — 0.38 0.33 0.38 0.32
Watts typ — 1.88 1.67 1.91 1.62
Power
Total watts typ — 13.0 11.0 11.0 3.0
1.12 Input noise
+5V +12V
Voltage tolerance (including noise) ±5% ±5%
Input noise frequency (max) 25 MHz 25 MHz
Input noise (max, peak-to-peak) 100 mV 240 mV
Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B 11

1.13 Environmental specifications
1.13.1 Ambient temperature
Operating 5°to 55°C(41°to 131°F)
Nonoperating –40°to 70°C (–40°to 158°F)
Note. The system must provide sufficient airflow to maintain a
surface temperature of the aluminum base below 60°C.
1.13.2 Temperature gradient
Operating 20°C per hour (36°F per hour)
Nonoperating 30°C per hour (54°F per hour)
1.13.3 Altitude
Operating –1,000 ft. to 10,000 ft. (–305 m to 3,048 m)
Nonoperating –1,000 ft. to 40,000 ft. (–305 m to 12,192 m)
1.13.4 Relative humidity
Operating 8% to 90% noncondensing
Maximum wet bulb 29.4°C (85°F)
Maximum operating
gradient 30% per hour
Nonoperating 5% to 95% noncondensing
Maximum wet bulb 40°C (95°F)
1.14 Shock
All shock and vibration specifications assume that the drive is mounted
securely with input shock applied at the drive mounting screws. Shock
and vibration may be applied in the X,Y or Z axis.
1.14.1 Operating shock
These drives comply with the performance levels specified in this docu-
ment when subjected to maximum operating shock of 10.0 Gs (based on
12 Medalist Pro 9140, 6530 and 4520 Product Manual, Rev. B
