Introduction
Sealevel Systems ROUTE 56 Page 1
Introduction
Overview
The ROUTE 56 adapter provides the PC with a single channel high-speed
multi-protocol serial interface suitable for the most popular communication
protocols. This sync/async card provides an ideal solution for high-speed
applications including LAN/WAN connectivity. Utilizing the Z16C32
(IUSC™) on chip DMA controller eliminates bus bandwidth constraints that
are placed on typical PC interface adapters, allowing data rates to reach 10M
bps in burst mode. By utilizing the Z16C32's 32 byte FIFO buffer coupled with
256K of on board memory, higher data rates are achieved without increasing
processor overhead.
What’s Included
The ROUTE 56 is shipped with the following items. If any of these items are
missing or damaged, contact the supplier.
•ROUTE 56 Adapter card
•ROUTE 56 Developers Toolkit Software
•ROUTE 56 User manual
Factory Default Settings
The ROUTE 56 factory default settings are as follows:
Base Address Default Electrical Interface
300 RS-530/422
To install the ROUTE 56 using factory default settings, refer to Installation on
page 4.
For your reference, record installed ROUTE 56 settings below:
Base Address Default Electrical Interface

Card Setup
Sealevel Systems ROUTE 56 Page 2
Card Setup
The ROUTE 56 contains several jumper straps for each port, which must be set
for proper operation.
Address Selection
The ROUTE 56 adapter occupies a total of four consecutive I/O locations. A
DIP-switch is used to set the base address for these locations. Be careful when
selecting the base address as some selections conflict with existing PC ports.
The following table shows several examples that usually do not cause a
conflict.
Address Binary Switch Settings
Hex A9 A8 A0 1234567
238-23B 10001110XX On On On Off Off Off On
300-303 11000000XX Off On On On On On On
304-307 11000001XX Off On On On On On Off
310-313 11000100XX Off On On On Off On On
314-317 11000101XX Off On On On Off On Off
320-323 11001000XX Off On On Off On On On
3A0-3A3 11101000XX Off Off On Off On On On
Figure 1-Address Selection Table
The following illustration shows the correlation between the DIP-switch
setting and the address bits used to determine the base address. Assume 300
Hex to 303 Hex is the desired base address. 300 Hex = (1) 1 0000 0X in
Binary.
1 2
3
4
5
6
7
ON
OFF
A8 A2
Figure 2-DIP-Switch Illustration
Note:Setting the switch “On” or “Closed” corresponds to a “0” in the address,
while leaving it “Off” or “Open” corresponds to a “1”.

Card Setup
Sealevel Systems ROUTE 56 Page 3
Interface Selection
Headers E2, E3 and E4 must be set prior to installing the ROUTE 56 in your
computer chassis. These headers choose the electrical/mechanical interface
options for the ROUTE 56 (i.e. RS-232, RS-530, V.35). Refer to the
illustration below for guidance in configuring the ROUTE 56.
RS-232
V.35
RS-530*
E4
E3
E2
A B A B A B
Figure 3-Header E2,E3 & E4 Interface Selection Headers.
* Factory Default
Note: The Electrical Interface must be set in the IUSC’s Port Control Register
(PCR) prior to the interface being active. Refer to the ROUTE 56 Developers
Toolkit Diskette for detailed instructions and examples in setting the PCR.

Installation
Sealevel Systems ROUTE 56 Page 4
Installation
The ROUTE 56 can be installed in any of the 16-bit expansion slots. The
ROUTE 56 contains several jumper straps for each port, which must be set for
proper operation.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available slot and remove the blank metal slot cover.
4. Gently insert the ROUTE 56 into the slot. Make sure the adapter is seated
properly.
5. Replace the screw.
6. Replace the cover.
7. Connect the power cord.
Installation is complete.
The ROUTE 56 has a number of cabling options available. These options
include:
•CA-103 -This cable provides a high quality shielded cable with the V.35
mechanical specification met on one end and a DB-25S (female) on the
other end. V.35 has a mechanical specification that is impossible to place
on a PC bracket and requires this adapter cable.
•CA-104 -This cable provides a 6’ extension for use with RS-232,
RS-530/422 and MIL-188.
•CA-107 -RS-530 (DB-25P) to RS-449 (DB-37P) cabling adapter. RS-530
is replacing RS-449 in Telecom applications, but there is still a very large
base of installed equipment that uses the RS-449 pin-out. Both standards
use RS-422 to define the electrical specifications and are interchangeable
via this adapter cable.

Technical Description
Sealevel Systems ROUTE 56 Page 5
Technical Description
The Sealevel Systems ROUTE 56 adapter was designed for seamless
integration into any ISA based system. The ROUTE 56 adapter requires a
80286 or higher CPU, one IRQ, a 4 byte block of I/O address and a 16K block
of memory address. The memory range of this adapter can be configured to
reside in the lower 1 Megabyte of memory and appear to the system as a bank
switched 16K window or the on-board memory can be used by the system as a
256K linear address block in the upper 4 Megabytes of memory. When using
either address configuration, the ROUTE 56 adapter's memory range can be
disabled allowing multiple adapters to share the same block of memory.
Features
•Single channel high speed sync/async wide area network (WAN)
interface
•RS-232, RS-422/449, EIA-530, V.35 and X.21 serial interface
capability with versatile cabling options
•Multiple protocols supported including: PPP (point-to-point
protocol), Frame Relay, X.25, high-speed Async, Bisync, Mono-Sync,
HDLC, SDLC and MIL-188
•Ideal for Fractional T1, T1, E1, and ISDN applications
•On-board Z16C32 (IUSC™) with built in DMA controller and 32 byte
FIFO buffer
•Up to 10 Mbps burst mode
•256K of on-board RAM
•Link list DMA supported
•16-bit data path
•Off loads communication processing

Technical Description
Sealevel Systems ROUTE 56 Page 6
IUSC™
The ROUTE 56 adapter is based on a single Zilog Z16C32 IUSC (Integrated
Universal Serial Controller). Application and driver software access the IUSC
registers through the first 256 bytes of on-board RAM. Register access to the
IUSC can be disabled via I/O registers allowing the first 256 bytes of RAM to
be used for buffer storage. The IUSC has a built-in DMA controller that allows
high-speed data transfers directly to and from the 256K block of on-board
memory. The IUSCs built-in DMA controller supports 4 different modes of
DMA transfer: Single Buffer, Pipelined, Array, and Link List. An on-board
16MHz oscillator clocks the IUSC.
RAM
The ROUTE 56 has 256K of on-board SRAM, which can be configured, as
“low” or “high” addressing. When in low addressing mode, the 256K bytes of
SRAM appear to the host processor in the 2nd 512K bytes of the host’s
memory address range, (Segment 8000 to F000). In addition, the 256K of
SRAM appears to the host in a 16K bank-switched window. The address of the
16K window and the page is software selectable. When in high addressing
mode, the entire 256K bytes of SRAM are accessible to the host processor
simultaneously in the Linear Address Range C00000 to FFFFFF. The IUSC
always views the 256K of SRAM as linear memory. The SRAM can be
selectively disabled through software. The SRAM must be addressed in a
section that does not conflict with system DRAM.
1MB
8MB
LowAddressMode
Selected
512K(80000)
16MB(FFFFFF)
12MB(C00000)
HighAddressMode
Selected
1MB(FFFFF)
16KAddressWindow
forBankSwitching
(D0000-D4000)
256KLinear
AddressWindow
(D00000-D40000)

Technical Description
Sealevel Systems ROUTE 56 Page 7
Control / Status Registers
The control / status registers occupy 4 consecutive bytes in the AT I/O range. The following tables provide a functional description
of the bit positions.
Address D7 D6 D5 D4 D3 D2 D1 D0
Base+0 RD/WR MEMEN IUSCEN XXP17 P16 P15 P14
Base+1 WR INT2 INT1 INT0 MA21/18 MA20/17 MA19/16 MA18/15 MA14
Base+2 WR HIAD WSEN EN16 IRQMODE XXXX
Base+3RD XXINTPEND RESTAT 16BIT XXX
Base+3 WR Reset for entire board
Field Description
MEMEN 1 = Host access to RAM enabled; 0 = Host access to RAM disabled.
IUSCEN 1 = Disable Host access to IUSC; 0 = Enable Host access to IUSC.
P17-P14 Page selector / Valid in “LOW” addressing mode only.
INT2-INT0 Interrupt: 000 = None; 001 = IRQ3; 010 = IRQ4; 011 = IRQ9; 100 = IRQ10; 101 = IRQ11; 110 = IRQ12; 111 = IRQ15.
MA21/18-
MA18/15 For “HIGH” addressing mode: These bits select the base memory address of the 256K of SRAM. For “LOW” addressing mode: These
bits and MA14 select the base memory address of the 16K bank-switched window of SRAM.
MA14 In “LOW” addressing mode this bit and MA21/18-MA18/15 select the base memory address of the 16K bank-switched window of
SRAM. In “HIGH” addressing mode this bit is not used.
HIAD “HIGH” addressing mode enable: 1 = “HIGH” addressing mode enable;0 = “LOW” addressing mode enable.
WSEN Wait State Enable: 1 = disable wait states(Zero wait states); 0 = enable wait states.
EN16 Enable 16-bit operations with the IUSC and SRAM: 1 = enable 16-bit operations; 0 = disable 16-bit operations.
IRQMODE IRQ mode: 1 = ISA IRQ mode; 0 = EISA IRQ mode.(wire OR low level)
INTPEND IUSC interrupt status: 1 = No interrupt pending on IUSC; 0 = Interrupt pending on IUSC.
RESTAT Reset status: 1 = On-board reset inactive; 0 = On-board reset active.
16BIT 1 = Card resides in 16-Bit slot; 0 = Card resides in 8-Bit slot.

Technical Description
Sealevel Systems ROUTE 56 Page 8
25 Pin Connector Signal Layouts
RS-232 Signals
Signal Name Pin # Mode
GND Ground 7
RD Receive Data 3Input
CTS Clear To Send 5Input
DSR Data Set Ready 6 Input
DCD Data Carrier Detect 8 Input
TM Test Mode 25 Input
RI Ring Indicator 18 Input
TXC Transmit Clock 15 Input
RXC Receive Clock 17 Input
TSET Transmit Signal Element Timing 24 Output
DTR Data Terminal Ready 20 Output
TD Transmit Data 2Output
RTS Request To Send 4Output
V.35 Signals
Signal Name DB-25 V.35 Mode
GND Ground 7B
RDB RX+ Receive Positive 16 T Input
RDA RX-Receive Negative 3RInput
TXCB TXC+ Transmit Clock Positive 12 AA Input
TXCA TXC-Transmit Clock Negative 15 YInput
RXCB RXC+ Receive Clock Positive 9XInput
RXCA RXC-Receive Clock Negative 17 VInput
TDB TX+ Transmit Positive 14 SOutput
TDA TX-Transmit Negative 2POutput
TSETB TSET+ Transmit Signal Element Timing + 11 WOutput
TSETA TSET-Transmit Signal Element Timing -24 UOutput
CTS Clear To Send 5DInput *
DSR Data Set Ready 6EInput *
DCD Data Carrier Detect 8FInput *
RI Ring Indicator 18 JInput *
DTR Data Terminal Ready 20 HOutput *
RTS Request To Send 4COutput *
* Note:All modem control signals are single ended (un-balanced) with RS-232
signal levels.

Technical Description
Sealevel Systems ROUTE 56 Page 9
EIA-530, RS-422 and MIL 188 Signals
Signal Name Pin # Mode
GND Ground 7
RDB RX+ Receive Positive 16 Input
RDA RX-Receive Negative 3Input
CTSB CTS+ Clear To Send Positive 13 Input
CTSA CTS-Clear To Send Negative 5Input
DSRB DSR+ Data Set Ready Positive 22 Input
DSRA DSR-Data Set Ready Negative 6Input
DCDB DCD+ Data Carrier Detect Positive 10 Input
DCDA DCD-Data Carrier Detect Negative 8Input
TXCB TXC+ Transmit Clock Positive 12 Input
TXCA TXC-Transmit Clock Negative 15 Input
RXCB RXC+ Receive Clock Positive 9Input
RXCA RXC-Receive Clock Negative 17 Input
RI-Ring Indicator 18 Input
TM Test Mode 25 Input
TDB TX+ Transmit Positive 14 Output
TDA TX-Transmit Negative 2Output
RTSB RTS+ Request To Send Positive 19 Output
RTSA RTS-Request To Send Negative 4Output
DTRB DTR+ Data Terminal Ready Positive 23 Output
DTRA DTR-Data Terminal Ready Negative 20 Output
TSETB TSET+ Transmit Signal Element Timing Positive 11 Output
TSETA TSET-Transmit Signal Element Timing Negative 24 Output

Specifications
Sealevel Systems ROUTE 56 Page 10
Specifications
Environmental Specifications
Specification Operating Storage
Temperature Range 0 to 50 º C
(32 to 122 º F) -20 to 70 º C (-4 to 158 ºF)
Humidity Range 10 -90% R.H.
NonCondensing 10 -90% R.H. NonCondensing
Power Consumption
Supply line -5VDC +5 VDC
Rating 2.1A
Mean Time Between Failures (MTBF)
Greater than 150,000 hours. (Calculated)
Physical Dimensions
Board length 8.25 inches (20.955 cm.)
Board Height including Goldfingers 4.80 inches (12.192 cm.)
Board Height excluding Goldfingers 4.50 inches (11.430 cm.)

Appendix A -Troubleshooting
Sealevel Systems ROUTE 56 Page 11
Appendix A -Troubleshooting
A Developers Toolkit Diskette is supplied with the Sealevel Systems adapter
and will be used in the troubleshooting procedures. By using this diskette and
following these simple steps, most common problems can be eliminated
without the need to call Technical Support.
1. Identify all I/O adapters currently installed in your system. This includes
your on-board serial ports, controller cards, sound cards etc. The I/O
addresses used by these adapters, as well as the IRQ (if any) should be
identified.
2. Configure your Sealevel Systems adapter so that there is no conflict with
currently installed adapters. No two adapters can occupy the same I/O
address.
3. Make sure the Sealevel Systems adapter is using a unique IRQ. While the
Sealevel Systems adapter does allow the sharing of IRQ’s, many other
adapters (i.e. SCSI adapters and on-board serial ports) do not. The IRQ is
typically selected via an on-board header block. Refer to the section on
Card Setup and the Control/Status port for help in choosing an I/O address
and IRQ.
4. Make sure the Sealevel Systems adapter is securely installed in a 16-bit
slot.
5. Use the supplied diskette and User Manual to verify that the Sealevel
Systems adapter is configured correctly. The supplied diskette contains a
diagnostic program “SSDR56” that will verify if an adapter is configured
properly. This diagnostic program is written with the user in mind and is
easy to use. Refer to the “README.txt” file on the supplied diskette for
detailed instructions on using “SSDR56”.
6. The following are known I/O conflicts:
•The 278 and 378 settings may conflict with your printer I/O
adapter.
•3B0 cannot be used if a Monochrome adapter is installed.
•3F8-3FF is typically reserved for COM1:
•2F8-2FF is typically reserved for COM2:
•3E8-3EF is typically reserved for COM3:
•2E8-2EF is typically reserved for COM4:

Appendix B -How To Get Assistance
Sealevel Systems ROUTE 56 Page 12
Appendix B -How To Get Assistance
Please refer to Appendix A -Troubleshooting prior to calling Technical
Support.
1. Read this manual thoroughly before attempting to install the
adapter in your system.
2. When calling for technical assistance, please have your user
manual and current adapter settings. If possible, please have the
adapter installed in a computer ready to run diagnostics.
3. Technical support is available Monday to Friday from 8:00 a.m. to
5:00 p.m. Eastern time. Technical support can be reached at
[phone].
RETURN AUTHORIZATION MUST BE OBTAINED FROM SEALEVEL
SYSTEMS BEFORE RETURNED MERCHANDISE WILL BE ACCEPTED.
AUTHORIZATION CAN BE OBTAINED BY CALLING SEALEVEL
SYSTEMS AND REQUESTING A RETURN MERCHANDISE
AUTHORIZATION (RMA) NUMBER.

Appendix C -Electrical Interface
Sealevel Systems ROUTE 56 Page 13
Appendix C -Electrical Interface
RS-232
Quite possibly the most widely used communication standard is RS-232. This
implementation has been defined and revised several times and is often
referred to as RS-232 or EIA/TIA-232. It is defined by the EIA as the Interface
between Data Terminal Equipment and Data Circuit-Terminating
Equipment Employing Serial Binary Data Interchange. The mechanical
implementation of RS-232 is on a 25 pin D sub connector. RS-232 is capable
of operating at data rates up to 20 Kbps at distances less than 50 ft. The
absolute maximum data rate may vary due to line conditions and cable lengths.
RS-232 often operates at 38.4 Kbps over very short distances. The voltage
levels defined by RS-232 range from -12 to +12 volts. RS-232 is a single
ended or unbalanced interface, meaning that a single electrical signal is
compared to a common signal (ground) to determine binary logic states. A
voltage of +12 volts (usually +3 to +10 volts) represents a binary 0 (space) and
-12 volts (-3to -10 volts) denotes a binary 1 (mark). The RS-232 and the
EIA/TIA-574 specification defines two type of interface circuits, Data
Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE).
The Sealevel Systems adapter is a DTE interface.
RS-422
The RS-422 specification defines the electrical characteristics of balanced
voltage digital interface circuits. RS-422 is a differential interface that defines
voltage levels and driver/receiver electrical specifications. On a differential
interface, logic levels are defined by the difference in voltage between a pair of
outputs or inputs. In contrast, a single ended interface, for example RS-232,
defines the logic levels as the difference in voltage between a single signal and
a common ground connection. Differential interfaces are typically more
immune to noise or voltage spikes that may occur on the communication lines.
Differential interfaces also have greater drive capabilities that allow for longer
cable lengths. RS-422 is rated up to 10 Megabits per second and can have
cabling 4000 feet long. RS-422 also defines driver and receiver electrical
characteristics that will allow 1 driver and up to 32 receivers on the line at
once. RS-422 signal levels range from 0 to +5 volts. RS-422 does not define a
physical connector.

Appendix C -Electrical Interface
Sealevel Systems ROUTE 56 Page 14
RS-530
RS-530 (a.k.a. EIA-530) compatibility means that RS-422 signal levels are
met, and the pin-out for the DB-25 connector is specified. The EIA (Electronic
Industry Association) created the RS-530 specification to detail the pin-out,
and define a full set of modem control signals that can be used for regulating
flow control and line status. The RS-530 specification defines two types of
interface circuits, Data Terminal Equipment (DTE) and Data Circuit-
Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE
interface.
V.35
V.35 is a standard defined by ITU (formerly CCITT) that specifies an electrical,
mechanical, and physical interface that is used extensively by high-speed digital
carriers such as AT&T Dataphone Digital Service (DDS). ITU V.35 is an
international standard that is often refereed to as Data Transmission at 48
Kbps Using 60 -108 KHz Group-Band Circuits. ITU V.35 electrical
characteristics are a combination of unbalanced voltage and balanced current
mode signals. Data and clock signals are balanced current mode circuits. These
circuits typically have voltage levels from 0.5 Volts to -0.5 Volts (1 Volt
differential). The modem control signals are unbalanced signals and are
compatible with RS-232. The physical connector is a 34 pin connector that
supports 24 data, clock and control signals. The physical connector is defined
in the ISO-2593 standard. ITU V.35 specification defines two type of interface
circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating
Equipment (DCE). The Sealevel Systems adapter is a DTE interface.
MIL-188
This communications standard comes is two varieties, MIL-188/C and
MIL-188/114. Both of these interfaces are military standards that are defined
by the US Department of Defense. MIL-188/114 is a differential interface and
MIL-188/C is a unbalanced or single ended interface. Both MIL-188 interfaces
are implemented on a RS-530 connector. MIL-188/C and MIL-188/114 have
signal levels from +6 volts to -6 volts and are ideal for long distances at high
speeds.

Appendix D -Silk-Screen
Sealevel Systems ROUTE 56 Page 15
Appendix D -Silk-Screen
4.5"
8.25"
4.8"

Appendix E –Compliance Notices
Sealevel Systems ROUTE 56 Page 16
Appendix E -Compliance Notices
Federal Communications Commission Statement
FCC -This equipment has been tested and found to comply with the limits for
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in such case the user will be required to
correct the interference at his own expense.
EMC Directive Statement
Products bearing the CE Label fulfill the requirements of the
EMC directive (89/336/EEC) and of the low-voltage directive
(73/23/EEC) issued by the European Commission.
To obey these directives, the following European standards must be met:
•EN55022 Class A-“Limits and methods of measurement of radio
interference characteristics of information technology equipment”
•EN50082-1-“Electromagnetic compatibility -Generic immunity
standard” Part 1 : Residential, commercial and light industry
•EN60950 (IEC950) -“Safety of information technology
equipment, including electrical business equipment”
Warning
This is a Class A Product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Always use cabling provided with this product if possible. If no cable is
provided or if an alternate cable is required, use high quality shielded cabling to
maintain compliance with FCC/EMC directives.

Warranty
Sealevel Systems ROUTE 56 Page 17
Warranty
Sealevel Systems, Inc. warrants this product to be in good working order for a
period of one year from the date of purchase. Should this product fail to be in
good working order at any time during this period, Sealevel Systems will, at it's
option, replace or repair it at no additional charge except as set forth in the
following terms. This warranty does not apply to products damaged by misuse,
modifications, accident or disaster.
Sealevel Systems assumes no liability for any damages, lost profits, lost
savings or any other incidental or consequential damage resulting from the use,
misuse of, or inability to use this product. Sealevel Systems will not be liable
for any claim made by any other related party.
RETURN AUTHORIZATION MUST BE OBTAINED FROM SEALEVEL
SYSTEMS BEFORE RETURNED MERCHANDISE WILL BE ACCEPTED.
AUTHORIZATION CAN BE OBTAINED BY CALLING SEALEVEL
SYSTEMS AND REQUESTING A RETURN MERCHANDISE
AUTHORIZATION (RMA) NUMBER.
Sealevel Systems, Incorporated
155 Technology Place
P.O. Box 830
Liberty, SC 29657 USA
[phone] FAX: [phone]
www.sealevel.com
Technical Support is available from 8 a.m. to 5 p.m. Eastern time.
Monday -Friday
Trademarks
Sealevel Systems, Incorporated acknowledges that all trademarks referenced in
this manual are the service mark, trademark, or registered trademark of the
respective company.
ROUTE 56 is a trademark of Sealevel Systems, Incorporated.
