Introduction
The HUB4SSBA is a SuperSpeed 4-Port USB 3.1 Gen 1 hub. Supported in all USB aware operating systems,
the HUB4SSBA requires no separate software drivers and is easy to install.
The HUB4SSBA integrates SeaLATCH™ USB 3.1 Gen 1 ports, which are fully compatible with standard USB
cables. When used with the optional USB cable with a SeaLATCH type B USB connector, the metal
thumbscrew provides a secure metal-to-metal connection to the hub and prevents accidental cable
disconnection. The hub’s four SeaLATCH type A USB connectors can secure USB peripherals to the hub in
the same way.
Features
•Increases the number of SuperSpeed USB ports from a single computer port
•SeaLATCH USB 3.1 Gen 1 connectors provide locking connection
•Status LEDs indicate when a downstream USB connection to the host is established
oGreen LED when a USB 3.1 Gen 1 connection is established
oYellow LED when USB 2.0/1.1 connection is established
•USB 3.1 Gen 1 compliant with transfer rates up to 5 Gbps
•Backwards compatible with USB 2.0/1.1/1.0 devices
•Plug-and-Play; no drivers required for Linux or Windows XP/7/8/10/11™ operating systems
•Includes 4 USB downstream ports that enable concurrent data transfer and charging at up to
1500mA available per port (2400mA available on port 4)
•Dedicated charging configuration (no host computer)
•Individual overcurrent detection and protection for each port
•ESD protection on SuperSpeed data lines to ±15 kV
•ESD protection on High-Speed data lines to ±8kV
•Automatic link and speed detection
•Rugged all-metal enclosure designed for use in industrial applications

6
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Before You Get Started
What’s Included
The HUB4SSBA is shipped with the following items. If any of these items are missing or damaged, please
contact Sealevel for replacement.
•HUB4SSBA – SuperSpeed 4-Port USB 3.1 Gen 1 Hub with SeaLATCH USB Ports
•CA783 – USB 3.1 Gen 1 Type A to USB 3.1 Gen 1 Type B Cable, 2 meters in Length
•9723K88 (x4) - PVC Flat Top Bumper 1/2" diameter (Rubber Feet)
•104456 – Pluggable, Locking Screw Terminal (2-pos; 5.08mm)
Advisory Conventions
Warning
The highest level of importance used to stress a condition where damage could result to the
product, or the user could suffer serious injury.
Important
The middle level of importance used to highlight information that might not seem obvious or a
situation that could cause the product to fail.
Note
The lowest level of importance used to provide background information, additional tips, or other
non-critical facts that will not affect the use of the product.

7
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Optional Items
Depending upon your application, you are likely to find one or more of the following items useful for
interfacing the HUB4SSBA to real-world signals. All items can be purchased from our website
(www.sealevel.com) or by calling [phone].
100-240 VAC to 24 VDC @ 2.71A, Desktop Power Supply w/ Tinned Leads (Item# TR152)
The TR152 is a desktop power supply rated for
universal 100-240 VAC input and 24 VDC output
at 2.7 amps (65 watts). The TR152 conforms to
DoE requirements for Level VI Energy Efficiency,
features over voltage, short circuit, and over
current protection, and operates over a 0 to +40C
temperature range. The DC output wire is
approximately 6 feet in length; the positive lead
is marked with red shrink tubing and both leads
are stripped and tinned.
SeaLATCH USB 3.1 Type A and SeaLATCH USB 3.1 Type B Device Cable, 78” (Item# CA746)
The
CA746 is a USB 3.1 device cable with
SeaLATCH USB type A and SeaLATCH type B
connectors. The metal thumbscrew on each
connector provides a secure metal-to-metal
connection to devices with SeaLATCH USB
ports.
SeaLATCH USB 3.1 Type A and USB 3.1 Type B Device Cable, 78” (Item# CA747)
The CA747 is a USB 3.1
device cable with
SeaLATCH USB type A and standard type B
connectors. The metal thumbscrew on the
SeaLATCH connector provides a secure metal-
to-metal connection to devices with SeaLATCH
USB ports.
USB 3.1 Type A and SeaLATCH USB 3.1 Type B Device Cable, 78” (Item# CA748)
The CA748 is a USB device cable with standard
USB type A and SeaLATCH type B connectors.
The metal thumbscrew on the SeaLATCH
connector provides a secure metal-to-metal
connection to devices with SeaLATCH USB
ports.

8
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
DIN Rail Mounting
The HUB4SSBA is available with an optional
factory-installed DIN-
rail mounting clip.
Alternatively, DIN-
rail mounting clips can be
ordered as a field upgrade kit (Item# DR106). The
bracket with clip is easily attached using two
included #4-40 Phillips head machine screws.

9
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Legacy Accessories:
SeaLATCH USB Type A and SeaLATCH Type B Device Cable, 72” (Item# CA332)
The CA332 is a USB device cable with SeaLATCH USB type A and type B
connectors. The metal thumbscrew on each connector provides a secure metal-
to-metal connection to devices with SeaLATCH USB ports.
SeaLATCH USB Type A to USB Type B Device Cable, 72” (Item# CA355)
The CA355 is a USB device cable with a SeaLATCH USB type A connector and
standard type B connector. This cable secures the HUB7M to legacy USB
peripheral devices.
USB Type A to SeaLATCH Type B Device Cable, 72” (Item# CA356)
The CA356 is a USB device cable with a SeaLATCH USB type B connector and
standard type A connector. This cable is included with all Sealevel USB products
with an integrated SeaLATCH type B USB port.
USB Type A to USB Type A, 3 Meter Extension Cable (Item# CA214)
The CA214 is a fully rated USB extension cable that adds three meters to any
existing USB cable (maximum 5 meters). The CA214 has a type A male connector
on one end and a type A female connector on the other end.
USB Type A to USB Type B, 72” Device Cable (Item# CA179)
The CA179 is a 72" USB device cable that connects USB peripherals with a Type
B connector to the Type A connector on a host computer. The CA179 is USB 2.0
compliant and is compatible with USB 1.1 and 1.0 devices.
USB Type A to USB Type B, 5 Meter Device Cable (Item# CA215)
The CA215 is a fully rated 5 meter device cable that connects USB peripherals
with a type B connector to the type A connector on a host PC. This cable provides
the maximum 5 meters (16 feet) for a USB connection.

10
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Installation
Windows XP/7/8/10/11™ Operating Systems
Installing and Powering-Up the HUB4SSBA as an Externally Powered Hub
1. The HUB4SSBA is fully supported as a generic USB 3.1 Gen 1 hub device in Windows
8/10/11™ operating systems and requires no separate drivers.
2. The HUB4SSBA is supported as a generic USB hub device in Windows XP/7™ and other USB-
aware operating systems and requires no separate drivers.
3. Simply connect the power supply to the HUB4SSBA and connect to an AC outlet.
4. Using the included USB device cable (CA783), plug the HUB4SSBA’s Upstream Host Port into
an available USB 3.1 Gen 1 port on your host system.
5. The ‘Found New Hardware’ screen will appear, and the hub will be automatically recognized
as both a Generic USB 2.1 Hub device and a Generic SuperSpeed USB Hub device.
6. The hub is ready to use when you see the screen ‘Your USB hub is installed and ready to use.’
Installing and Powering-Up the HUB4SSBA as a Bus Powered Hub
1. Using the included USB device cable (CA783), plug the HUB4SSBA’s Upstream Host Port into
an available USB 3.1 Gen 1 port on your host system.
2. The ‘Found New Hardware’ screen will appear, and the hub will be automatically recognized
as both a Generic USB 2.1 Hub device and a Generic SuperSpeed USB Hub device.
3. The hub is ready to use when you see the screen ‘Your USB hub is installed and ready to use.’
Windows NT is not USB aware and thus cannot support this device.

11
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Hardware Description
USB Ports
The HUB4SSBA integrates SeaLATCH USB 3.1 Gen 1 ports, which are fully compatible with standard USB
cables. When used with the optional USB cable with a SeaLATCH USB 3.1 Gen 1 type B connector
(CA746/CA748), the metal thumbscrew provides a secure metal-to-metal connection to the hub and
prevents accidental cable disconnection.
The SeaLATCH USB 3.1 Gen 1 type B locking connector and standard USB 3.1 Gen 1 type B port is shown
below:
The HUB4SSBA’s four SeaLATCH USB 3.1 Gen 1 type A locking USB connectors can secure USB peripherals
to the hub in the same way. Two of the SeaLATCH USB 3.1 Gen 1 type A ports are shown below. Each of
the four downstream type A USB ports provides up to 1500mA to USB peripherals with port four providing
up to 2400mA.
Each downstream port of the HUB4SSBA has its own transaction translator to provide the best USB
performance no matter what class of USB device is connected to it.
1500mA Ports:
Each HUB4SSBA has three CDP ports that can supply up to 1500mA. When there is no upstream host
connection, these ports are dedicated charging ports, supporting vendor specific charging (RapidCharge;
Apple® 2.0A).
2400mA Port:
Each HUB4SSBA has a single, high-power port that can supply up to 2400mA. When there is no upstream
host connection, the high-power port is a dedicated charging port, supporting vendor specific charging
(RapidCharge; Apple® 2.4A).

12
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Status LEDs
Each downstream port has a status LED that is visible from the front of the HUB4SSBA module to indicate
the following information:
•USB 2.0/1.1/1.0 Connection with Host (Yellow) – Lights when a USB 2.0, 1.1, or 1.0 connection
is established with the upstream host.
•USB 3.1 Gen 1 Connection with Host (Green) – Lights when a USB 3.1 Gen 1 connection is
established with the upstream host.
Hub Power Modes
External Power
The HUB4SSBA can be ordered with a desktop power supply (Item# TR152) that outputs 24VDC @
2.71A, providing up to 1500mA to each downstream USB port and up to 2400mA to downstream port
4. Power is input via a 5mm 2-position removable screw terminal block (shown below). To prevent
accidental disruption of power, the terminal block includes captive mounting screws for securing the
hub. The HUB4SSBA accepts a wide input voltage range from 9VDC to 30VDC for use with alternative
power supplies.
When the HUB4SSBA is powered via external power, the hub is configured as a self-powered device
that consumes less than 1 mA of upstream VBUS current. In this self-powered mode, each downstream
port is configured as a Charging Downstream Port (CDP) capable of delivering up to 1500mA with port
4 capable of delivering up to 2400mA.
When external power is used to supply the hub, the HUB4SSBA will automatically reset and
switch to a bus-powered configuration if the external power supply drops below 9VDC (8.75v
typical) or if it rises above 30VDC (33v typical). If either of these two power supply conditions
occur, the HUB4SSBA will perform a reset and re-enumerate as a bus-powered device. When
the external power supply returns to a nominal voltage, the HUB4SSBA will reset back into
external-powered mode.

13
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Bus Power
The HUB4SSBA can also be powered via the upstream USB connection to the host. In this mode, the
HUB4SSBA draws all its power from the host computer's USB interface. It does not need a separate
power connection.
When the HUB4SSBA is powered via bus power, the hub is configured as a bus-powered device. In this
mode, each downstream port has its current limit reduced and is configured as a Standard Downstream
Port (SDP). After configuration, the bus-powered hub must consume no more than 900mA of the
upstream VBUS current (500mA if the hub is connected to the host through a legacy USB 2.0/1.1 port).
Many devices may require more power than the bus-powered hub can provide and may not work while
the hub is in the bus-powered mode. This is especially true of USB 3.0/3.1/3.2 devices. If a device fails
to enumerate in bus-powered mode, it may be attempting to draw too much current out of the upstream
USB connection. If this happens, remove the device, apply external power, and reconnect the device.
The bus-powered mode is ideal for situations where external power cannot be applied, (or is
inconvenient to do so).
To configure the HUB4SSBA as a bus-powered device, the upstream host must be connected
to the host port of the HUB4SSBA.

14
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
SeaLATCH® USB 3.1 Gen 1
The HUB4SSBA integrates SeaLATCH USB 3.1 Gen 1 ports, which are fully compatible with standard USB
cables. When used with the optional USB cable (Item# CA748) with a SeaLATCH USB 3.1 Gen 1 type B
connector, the metal thumbscrew provides a secure metal-to-metal connection to the hub and prevents
accidental cable disconnection.
The hub’s four SeaLATCH type A USB 3.1 Gen 1 connectors can secure USB peripherals to the hub in the
same way. Sealevel incorporates SeaLATCH locking USB ports on many USB I/O devices. Accidental cable
disconnection is the most common point of failure with USB industrial I/O devices and SeaLATCH cables
and connectors prevents that while being fully compatible with standard USB cables.
Examples of the HUB4SSBA with SeaLATCH equipped Sealevel I/O devices are shown below:

15
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
SeaLATCH Locking USB 3.1 Gen 1 Cables
SeaLATCH locking USB 3.1 Gen 1 cables integrate a small thumbscrew into each USB connector.
SeaLATCH USB 3.1 Gen 1 cables are fully interchangeable with standard USB cables. The thumbscrew
provides a secure metal-to-metal connection preventing accidental disconnection. SeaLATCH USB 3.1 Gen
1 cables are available in three configurations.

16
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Technical Specifications
Power Requirements
Supply line 9-30 VDC
Rating 65W
Physical Dimensions
Part Length Width Height
Enclosure 5.600 inches (14.23 cm) 5.060 inches (12.85 cm) 1.500 inches (3.81 cm)
PCB 5.300 inches (13.46 cm) 4.860 inches (12.34 cm) 0.675 inches (1.71 cm)
(See Appendices D and E for additional dimensions.)
Weight
0.8 lbs / 0.36 kg
Environmental Specifications
Specification Operating Storage
Temperature Range -40º to 85º C (-40º to 185º F) -40º to 85º C (-40º to 185º F)
Humidity Range 10 to 90% R.H. Non-Condensing 10 to 90% R.H. Non-Condensing
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested.
These printed circuit boards are solder mask over bare copper or solder mask over tin nickel.

17
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Appendix A – Troubleshooting
The HUB4SSBA is a generic SuperSpeed USB hub and should provide years of trouble-free service. Should
the device appear to not be functioning correctly, the following tips can eliminate most common problems
without the need to call Technical Support.
1. Make sure the power supply is connected to the hub and to a live AC power outlet.
2. Make sure the hub is connected to a USB port using the included USB cable or quality replacement
USB cable.
3. The hub is fully supported as a USB 3.1 hub device in any operating system that supports
SuperSpeed USB hub devices, including Windows 8, Windows 10 and Windows 11.
4. The hub is supported as a USB 2.0 hub device in any USB-aware operating system including
Windows XP/7, Linux (kernel v2.4 or better), Apple (Apple OS X 10.4+), and other USB-aware
operating systems. Check to make sure that USB support is enabled in the System BIOS and it is
functioning properly in the operating system. This can be done by using Device Manager in
Windows.
5. When a portable device (PD) is connected to a downstream port of the HUB7SSBA, the PD
enumerates with either a SuperSpeed connection or a legacy USB connection (High-Speed, Full-
Speed, or Low-Speed).
a. If a SuperSpeed USB connection is established, the corresponding LED for that port will
illuminate green.
b. If a non-SuperSpeed USB connection is established, the corresponding LED for that port
will illuminate yellow.
c. The LEDs should remain unlit until a USB connection is detected.
6. When a downstream USB peripheral pulls more than 1500mA of power from ports 1,2,3,4,5, or 6,
the overcurrent protection will shut down the port until the problem is resolved.
7. When a downstream USB peripheral pulls more than 2400mA of power from port 7, the overcurrent
protection will shut down the port until the problem is removed.
8. On Windows 10 and Windows 11, if the problem device is not removed from the HUB7SSBA within
3 seconds, the overcurrent event will be reported to the host as shown below:

18
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
9. Click on the “Power surge on the USB port” notification to open the prompt shown below:
10. The LED associated with the downstream port will turn off when in overcurrent shutdown; use the
state of the LEDs to determine which port incurred the overcurrent shutdown. Disconnect your USB
peripheral attached to the port in overcurrent shutdown. If the port remains unpowered, reset the
HUB7SSBA by disconnecting the upstream host & external power and then reconnect them. Inspect
the problem USB peripheral and replace, if necessary. Try connecting a different USB peripheral to
the problem port. If the port remains unpowered after following the steps above, contact technical
support for further assistance.
If these steps do not solve your problem, please call Sealevel’s Technical Support at [phone]. Our
technical support is free and available from 8:00 AM to 5:00 PM Eastern Time Monday through Friday. For
email support, contact [e-mail].

19
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Appendix B – How To Get Assistance
Begin by reading through the Troubleshooting Guide in Appendix A. If assistance is still needed, please see
below.
When calling for technical assistance, please have your user manual and current adapter settings. If
possible, please have the adapter installed in a computer ready to run diagnostics.
Sealevel Systems provides an FAQ section on its web site. Please refer to this to answer many common
questions. This section can be found at http://www.sealevel.com/faq.asp.
Sealevel Systems maintains a web page on the Internet. Our home page address is www.sealevel.com. The
latest software updates, and newest manuals are available via our web site.
Technical support is available Monday to Friday from 8:00 AM to 5:00 PM, Eastern Time. Technical support
can be reached at [phone]. For email support contact [e-mail].
RETURN AUTHORIZATION MUST BE OBTAINED FROM SEALEVEL SYSTEMS BEFORE RETURNED
MERCHANDISE WILL BE ACCEPTED. AUTHORIZATION CAN BE OBTAINED BY CALLING SEALEVEL
SYSTEMS AND REQUESTING A RETURN MERCHANDISE AUTHORIZATION (RMA) NUMBER.

20
© Sealevel Systems, Inc. HUB4SSBA Manual | SL9184 10/2023
Appendix C – Silk Screen – HUB4SSBA PCB
