INSTRUCTIONS FOR
RECHARGEABLE 360° 7 SMD + 3W LED
INSPECTION LAMP LITHIUM-ION
MODEL NO’S: LED3602 SERIES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
Ensure the lamp is fully charged before initial use.
DO NOT charge in damp conditions.
DO NOT turn the lamp on when it is being charged.
DO NOT shine directly into your, another person’s or an animal’s eyes.
DO NOT allow children to use the lamp.
DO NOT handle or move the lamp whilst it is being charged.
DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
DO NOT attempt to open, disassemble, modify or service the battery pack.
DO NOT crush, puncture, short external contacts or dispose of in re or water.
DO NOT expose to temperatures above 60°C (140°).
Replace only with the battery pack designated for this product.
Recycle or dispose of used battery as stipulated by local regulation.
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Unique and innovative 360° swivel and tilt function enables the light source to be positioned in any direction. Exclusive patented design owned
and registered to Sealey. 7 Super bright SMD LEDs with magnied lens providing up to 300 lumen output with 120° spread of light, illuminating
the whole work area. Includes an additional high power 3W LED in the end for use as a directional torch. Features two swivel hooks and
three rubber covered magnets, two on the rear and one on the end, which allow hands free operation. High quality 2.2Ah Lithium-ion battery
for longer life, no memory effect and a much slower discharge than traditional Ni-MH batteries. Micro USB charging port. Supplied with high
quality braided USB cable.
3. SPECIFICATION
Model no: ..................................................... LED3602 Series
Includes: LED3602.V2, LED3602B.V2, LED3602G.V2, LED3602R.V2, LED3602Y.V2, LED3602CAMO.V2, LED3602BA.V2,
LED3602CF.V2, LED3602WE.
Battery: .....................................................3.7V - 2.2Ah Li-ion
LED quantity: ................................................ 7 SMD + 1 LED
Lumen output side(high/low)/top: ................. (350/200)/120lm
Operating time side(high/low)/top:..........................(3.5/7)/8hr
Charging time:.............................................................. 3.5hrs
IP rating:..........................................................................IP54
Minimum length:......................................................... 255mm
Maximum length:........................................................ 270mm
IMPORTANT WARRANTY INFORMATION
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish.
Under these circumstances we will not replace the battery regardless of whether the battery less than one year old.
Refer to
Instruction
Manual
LED3602 SERIES | Issue 1 04/04/17
Original Language Version
© Jack Sealey Limited

4. OPERATION
4.1. Connect the USB lead to the socket on the rear of the lamp. Plug into USB power supply and turn on, the
charging LED (g.2.) on the lamp will light RED to show that charging has commenced.
4.2. When the battery has fully charged the LED will turn GREEN.
4.3. Direct the lens away from your eyes before switching on.
4.4. Toggle the lamp between the end light and side light using the ON/OFF switch, (g.1). First press = end light on,
second press = side light on full power, third press = side light on low power.
4.5. The lamp may be suspended by the hooks or attached to any ferrous surface by using the magnets.
4.6. When the light is hanging from the hook it can be rotated through 360° for more precise positioning.
4.7. Separate the top and bottom sections by pulling apart. When attached to a ferrous surface, using the base magnet, the lamp can
be rotated to shine in any direction.
g.1 g.2
Battery Removal
Remove the 6 screws on the back of the lamp. Remove the back casing and disconnect the wiring from the circuit
board. Remove the battery. Dispose of according to local government guidelines.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential
 purchasersofproductscontainingbatteries(asdenedwithintheseregulations),thattheyareregisteredwithValpak’s
 registeredcompliancescheme.JackSealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal
dispose according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
WasteElectricalandElectronicEquipment(WEEE).Whentheproductisnolongerrequired,itmustbedisposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Web
Hooks
LED3602 SERIES| Issue 1 04/04/17
Original Language Version
© Jack Sealey Limited

EC DECLARATION
OF CONFORMITY
Description and Function:........................................................................................................................................................................
Model/Type:.............................................................................................................................................................................................
Manufacturing Date/Serial Number (optional): ........................................................................................................................................
Manufacturer’s authorised representative within the EC: Jack Sealey Ltd, Kempson Way, Suffolk Business Park, Bury St
Edmunds, Suffolk. IP32 7AR
Conforms to the requirements of the Directives, as indicated.
And the following harmonised standard(s)
Technical le compiled by: Jack Sealey Ltd
Being the responsible person appointed by the manufacturer.
Signed...................................................................................
Date.......................................................................................
Name .....................................................................................
Position.................................................................................
Place: Bury St Edmunds
Rechargeable 360° Inspection Lamp 7 SMD
LED3602 v2 Series
2006/42/EC Machinery Directive
2014/35/EU Low Voltage Directive
:2014/30/EU EMC Directive
2009/125/EC Ecodesign Requirements
2009/142/EC Gas Appliance Directive
2014/29/EU Simple Pressure Vessels Directive
2000/14/EC Noise Emission in the Environment Directive
:2012/19/EU WEEE Directive
:2011/65/EU RoHS Directive
2014/68/EU Pressure Equipment Directive
89/686/EEC PPE Directive
 2014/53/EU RTTE Directive
24 May 2017
Steve Buckle.
Marketing Director.
EN 55015:2013.............................................................................
EN 61547:2009.............................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
......................................................................................................
