Sealey MPS1.V2 User manual
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
2.1. Ideal for use with off-road/trials bikes. Easily lifts the bike when performing maintenance/services or cleaning. Simple, one foot, step
and lift mechanism means the bike can be instantly raised in one motion.
2. INTRODUCTION & SPECIFICATION
DO NOT sit on the motorcycle on the stand.
DO NOT start the motorcycle on the stand.
DO NOT mount the stand on tarmacadam, as the surface may be unstable.
DO NOT use the stand for a purpose it is not designed to perform.
DO NOT operate the stand if it is damaged.
DO NOT use the stand when you are tired or under the influence of alcohol, drugs or intoxicating medication.
DO NOT allow untrained persons to operate the stand.
DO NOT make any modifications to the stand.
DO NOT operate the stand if parts are missing or damaged.
DO NOT exceed the maximum capacity.
Maintain the stand in a good clean condition for the best and safest performance.
Locate the stand and motorcycle in a suitable area. Keep area clean, tidy and free from unrelated materials and ensure that there is
adequate lighting. Also ensure that the floor/ground is level and strong enough (preferably concrete) to take the weight of the stand
and the motorcycle.
Maintain correct balance and footing whilst positioning the motorcycle on the stand, DO NOT over reach.
Ensure that the floor is not slippery, wear non-slip footwear. Also essential for safe operation of the foot pedal.
Keep children and unauthorised persons away from the work area.
Before removing a motorcycle from the stand, ensure that there are no obstructions or persons around the motorcycle.
Always support motorcycle to prevent falling.
If using as a front stand, always use in conjunction with another suitable rear stand to ensure full stability.
When not in use, store in a safe, dry, childproof location.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2.2. Specification.
Model No: ................................................................. MPS1.V2
Minimum Height:............................................................300mm
Maximum Height:...........................................................400mm
Maximum Capacity: .........................................................150kg
3. ASSEMBLY INSTRUCTIONS
INSTRUCTIONS FOR:
QUICK LIFT STAND FOR OFF-ROAD/TRIALS
BIKES 150kg
MODEL No: MPS1.V2
The stand consists of three main items. Item [A] base frame, [B] platform frame and [C] foot pedal assembly. Ancilliary items
includeaplasticroller,twocirclips,an18mmwasher,splitpinandasetofM6xings.Someitemsin3.1.-3.3.mayalreadybetted.
3.1. Withtherollerandtwocirclipstted,slidethefootpedal[C]spindle(g.1)throughtheverticalpillarbossofthebaseframe[A],
retain with washer and split pin.
3.2. Offer the platform tubular pillars over the base tubular pillars; the foot pedal roller aligned with platform roller guides.
3.3. Fit the foot pedal extension with the M6 screw, washer and stiff nut.
Original Language Version MPS1.V2 Issue: 1 - 27/12/13
©Jack Sealey Limited 2013
330
Over centre
locked position
Extension removed and retained.2.5:1 (approx.) initial mechanical advantage
(effort diminishes to zero as platform raises)
Stand fully elevated and locked.
Retained
xings
g.1
g.2
300
min
400
max
Circlip (inner)
Washer and split pin
Roller and
circlip
[A]
[B]
[C]
150kg max
Rubber
tread
Rubber pad
Roller guides
NOTE: The stand needs to be used in conjunction with suitable external motorcycle support to ensure full stability.
Although the support stand can be operated by one person, we advise seeking the assistance of a second person. A concrete
deck working area is recommended (tarmacadum may become unstable).
4.1. Support stand placement (fig.3).
4.1.1. With the platform at minimum height (fig.2), slide the stand beneath the point to be lifted. Choose a point with mechanical integrity.
4.1.2. Check the load bearing support platform will not crush or deform cables, pipes, exhaust or panels.
4.1.3. With external support options available, slowly raise the motorcycle wheels off the concrete deck using the foot pedal (fig.2). If stiction
occurs in the linkage at the start of the lift, additional force may be required. This force will greatly diminish as the load rises to full
height (fig.2).
IMPORTANT! Ensure that the foot pedal travels full stroke, to obtain the "over centre" locking. This is a safety feature which
mechanically locks the lift at full height preventing accidental descent.
4.1.4. Check that the motorcycle is stable on the stand and suitably supported before servicing or leaving it.
4.1.5. Remove the pedal lever extension (tripping hazard) and retain in the holder (fig.2). Replace when lowering and removing the stand.
4.2. Removing the stand.
4.2.1. Continuing to support the motorcycle, lift the pedal slightly to release the "over centre" mechanical lock, once this occurs the weight of
the motorcycle will be enough to lower to the concrete deck. Control the lowering speed with your foot on the lever pedal.
4.2.2. When descent is complete slide the stand away from beneath the motorcycle.
5.1. When the stand is not in use, store it in a safe, dry, childproof location.
5.2. Keep the stand clean and wipe off any oil or grease.
5.3. Before each use, check all parts. If any part of the stand is damaged or defective, remove it from service and take the necessary action
to remedy the problem.
5. MAINTENANCE
4. OPERATING INSTRUCTIONS
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
sales@sealey.co.uk
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version MPS1.V2 Issue: 1 - 27/12/13
©Jack Sealey Limited 2013
fig.3
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
g.3
