Sealey RD2500T User manual

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1.2. GENERAL SAFETY
 WARNING!Disconnect the heater from the mains power, before servicing or performing any maintenance, which must only be carried
out by an authorised service agent. Report any oil leakage immediately to an authorised service agent.
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Ensure that the heater is used in an area larger than 4m³. Allow a few centimetres of clearance from any surface, and ensure there is
good overhead clearance for heat circulation.
Only use the heater in an upright position.
WARNING! do not tamper with the wiring, heating element or oil. The system is a sealed unit.
The breaking of any seal may be dangerous, will damage the heater and will invalidate the warranty.
DO NOT use the heater for anything other than its intended purpose. It is designed for providing
heat in enclosed areas, no smaller than 4m³, such as offices, homes, workshops etc. It is not
suitable for drying clothes or laundry.
DO NOT place the heater close to a bath, wash basin, shower, swimming pool or any other
water-filled area or wet surface. DO NOT get the heater wet or use in areas of high condensation.
DO NOT place the heater up against any surface such as a wall, door, furniture etc.
DO NOT place the heater immediately below any electrical outlet.
DO NOT allow the power lead to touch the radiator surface.
DO NOT cover the radiator or use it to dry laundry.
DO NOT switch the heater on whilst the electrical lead is wrapped on the storage bracket.
DO NOT store the electrical lead until the radiator is cold.
DO NOT attempt to repair a damaged heater, contact an authorised service agent.
DO NOT stand on the heater.
DO NOT touch the heating elements when the heater is on as it becomes very hot.
 Operators must read this manual or receive adequate training before using the heater.
1.1. ELECTRICAL SAFETY
 WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also
recommend that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual
Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity at Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2.
and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that none is loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty
item repaired or replaced by a qualified electrician. When an ASTA/BS approved UK
3 pin plug is damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly
connected, that the cable outer insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10. Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure
that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket
with your electrician.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use
of 2.5mm² section cable.
1.1.12. DO NOT move the heater whilst it is ON, always disconnect from the supply and allow to cool first.
Original Language Version RD2500T Issue: 1 - 16/04/13
INSTRUCTIONS FOR:
OIL FILLED RADIATOR 2500W/230V
11 ELEMENT WITH TIMER
MODEL No: RD2500T
Fig.1
© Jack Sealey Limited 2013
Recommended fuse rating 13amp

ASSEMBLY (fig.2):
Invert the radiator after removal from packaging, oil should be heard flowing internally under gravity, this is expected and not a problem. Attach
the castor wheels by passing the stud through the underside of the wheel plate and securing with the supplied nut. Mount the castor wheel
plate between the first and second element of each end of the radiator. Tighten the wing nuts on the metal "U" bolts; return the radiator to the
upright position; oil should be heard flowing internally under gravity and your heater is ready to use when the flowing ceases. Check the unit is
the correct way up by observing carrier handle apertures are at the top and the cable tidy is at the bottom, also the thermostat "LOW" and
"HIGH" instruction is further confirmation.
SAFETY FEATURE-: The tilt safety switch will isolate supply if accidentally tipped over or if assembled upside down.
3.1 Heating settings fig.3
3.1.1 Unwrap the mains lead and plug it into the power supply.
3.1.2 Turn the thermostat control to the highest setting.
3.1.3 Choose the required heat output by selecting the appropriate switch, this switch will illumunate when pressed.
3.1.4 Low setting: ..... Select switch with the Roman Numeral "I".
Medium setting: .. Select switch with the Roman Numeral "II". Set switch with "I" to off.
High setting:..... Select both switches "I" and "II".
3.1.5 Once the required room temperature has been achieved, turn the thermostat down until the light on the selected
heat setting switch goes out. The heater will then keep the surrounding air at the set temperature by switching on
and off at intervals. You may reset the thermostat at any time.
3.1.6 To switch the unit off, turn the heat selecting switches off and unplug from the mains. Allow the unit to cool before
handling or storage.
3.1.7 Safety cut-out. The heater is fitted with a safety tilt switch and a thermostatic safety cut-out which will automatically
turn the heater off should it be placed in circumstances that cause overheating or malfunction. Should this happen,
switch the heater off and disconnect it from the mains. Allow the heater to cool before handling. Do not use the
heater again until the cause has been identified and remedied. If necessary return the heater to your Sealey
dealer for servicing.
3.1.8 When used for the first time, it is suggested that you set the heater to maximum power for a few minutes in a
well ventilated room to eliminate the newness smell, typical of this type of heater.
3.2 Timer settings fig.4
3.2.1 Set the 24 hour perimeter clock to the approximate actual time adjacent to the triangle symbol.
3.2.2 The switch in the slot, "I" symbol = on all the time, clock symbol = timed switching, "0" symbol = off all the time.
3.2.3 Each blue "flag" on the dial face represents 15 minutes approximately. Inner positions are bypassed, outer
positions switch the heater "on" then "off" at the approximate time settings made by the operator.
  WARNING!Disconnect the heater from the mains power, before servicing or performing any maintenance, which must only be carried
out by an authorised service agent with the exception of the following.
4.1. Dust the radiator (when cold) with a dry cloth.
4.2. Do not use a strong abrasive to clean the radiator.
4.3. When storing the heater, use the original shipping box and store in a safe, dry location.
Note: Report any oil leakage immediately to an authorised service agent.
3. INSTRUCTIONS FOR USE
4. MAINTENANCE
2. SPECIFICATION & ASSEMBLY
Oil-filled radiator suitable for office, home, showroom and workshop use. Manufactured to
rigorous safety standards and fitted with a 13Amp BS approved plug. Features full thermostatic
heat control that cuts power to the heater elements when pre-set temperature is attained and tilt
safety switch. Elements designed to maximise area of the heated surface in order to transfer
more heat to the atmosphere. Features built-in 24 hour timer allowing the user to programme the
time and duration the heater is operated. Fitted with castors for added mobility.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version RD2500T Issue: 1 - 16/04/13
Children should be supervised at all times when the heater is in use.
 Ensure that the heater is correctly turned off when not in use and store in a safe, dry area, out of reach of children.
Model No: RD2500T
Power: 2500W
Supply: 230V
Timer: Yes
Size (W x D x H): 480 x 240 x 624mm
Weight: 12.5kg
Fig.2
Fig.3
Fig.4
Thermostat
© Jack Sealey Limited 2013
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
WEEE Regulations.
Dispose of this product at the end of its working life in compliance
with the EU Directive on Waste Electrical and Electronic Equipment.
When the product is no longer required, it must be disposed of in an
environmentally protective way. Contact your local solid waste
authority for recycling information.
24 Hour Timer
