INSTRUCTION MANUAL FOR:
DROP SPREADER 80kg TOW
BEHIND
MODEL No: SPD80T
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
3. SPECIFICATION & CONTENTS
2. INTRODUCTION
4.1. Check contents against fig.1 above, if anything is missing or
damaged contact your local Sealey dealer.
4.2. Refering to fig.2, remove the two lock nuts at the front base
of the hopper (1).
4.3. Align the two holes at the end of the hitch tongue (2) with the
protruding bolts at the front base of the hopper (1) and attach
the hitch tongue (2) using the two lock nuts previously removed in
4.2.
4. ASSEMBLY
Model No. ......................................SPD80T
Capacity (Weight)....................................80kg
Capacity (Volume) ...................................80ltr
Spread .........................................1070mm
Weight ............................................19kg
Dimensions (W x D x H)..................1350 x 910 x 550mm
 Ensure that the spreader is in sound condition and good working
order before use.
Ensure that the operator is fully trained and competent to operate
the prime mover before attaching and using the spreader.
 Ensure that all chemical safety instructions are adhered to when
handling products for use in the spreader. A full range of personal
safety equipment is available from your Sealey dealer.
 Always distribute the load evenly.
 Ensure all non essential personnel keep a safe distance when the
spreader is in use.
 Replace or repair damaged parts. Use only recommended parts.
Unauthorised parts may be dangerous and will invalidate the
warranty.
 Keep hands and feet away from moving parts.
DO NOT overload the spreader - see Specification.
DO NOT leave unattended, especially when loaded, unless the
wheels are chocked or the spreader is otherwise secured.
DO NOT allow others to ride on the spreader.
DO NOT allow untrained personnel to use the spreader.
DO NOT use the spreader for purposes other than for which it is
designed.
DO NOT operate the spreader when you are tired or under the
influence of alcohol, drugs or intoxicating medicines.
When loaded,DO NOT operate the spreader over edges, rough
surfaces etc. where the spreader is at risk of overturning.
WARNING! Failure to comply with these instructions may result
in damage to spreader or other property and/or personal injury.
Manufactured with a strong tubular steel frame and polypropylene
dispensing hopper. Pin hitch design attaches to ride-on lawnmowers,
can be converted to ball hitch using Model No. TB36. Fitted with
pneumatic tyres and adjustable feed system. Designed to spread in a
continuous line providing a more accurate application. Suitable for a
variety of horticultural agents, including grit, seed, salt, fertiliser and
weed killer.
Original Language Version SPD80T Issue: 1 - 21/06/11
fig.1
fig.2

4.7. Remove the hex bolt and nut securing the hitch bracket to the
hitch tongue (2). Align the loose end of the flow control handle
over the hole and attach to the hitch tongue (2) using the hitch
bracket hex bolt and lock nut as shown in figure 4.
4.8. Adjust the position of the flow control handle until it is aligned
with the hitch tongue and the hopper, then fully tighten all the
nuts and bolts used to secure the flow control handle.
4.9. Noting its position on the connecting rod (5), remove one of
thethreadedconnectors,asshowningure5.
4.10. Feed the connecting rod (5) through the hole in the control
armontheowcontrolhandle(6)asshowningure6,until
the connecting rod is central in the control arm.
4.11. Reattach the threaded connector removed in 4.9. back into its
original position on the connecting rod (5) .
4.12. Attach the threaded connectors to the dodge gate brackets on
thehopper(1)usinglocknutM6(9)asshowningure7.
Donotovertightenthenutstoallowmovementoftheow
control handle mechanism and dodge gate. The position and
range of movement of the dodge gate can be altered by
equally adjusting the threaded connectors up or down the
threaded portions on the connecting rod (5).
Original Language Version SPD80T Issue: 1 - 21/06/11
4.4. Remove the top lock nut from the front of the hopper (1) as
shown in figure 3.
4.5. Align the top left hand hole of the flow control handle (6) with
the protruding bolt and loosely reattach the lock nut
previously removed in 4.4.
4.6 Attach the right hand hole of the flow control valve (6) to the
hopper (1) using hex bolt M6x16 (7), big flat washer Ø6 (10)
and lock nut M6 (9). Do not fully tighten the nuts and bolts at
this stage.
fig.3
fig.5
fig.6
fig.7
fig.4

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our catalogue and latest promotions call us on 01284 757525 and leave your full name, address and postcode.
5. OPERATION
4.13. Remove the lock nut from the bottom bracket of the
hopper as shown in figure 8.
4.14. Attach a brace (3) to the bottom bracket of the hopper (1)
using the lock nut removed in 4.13 and hex bolt M6x16
(7) and lock nut M6 (9) as shown in figure 8. Do not fully
tighten the nuts and bolts at this stage.
4.15. Attach the other end of the brace to the hitch tongue using
hex bolt M6x16 (7) and lock nut M6 (9) as shown in
figure 9. Do not fully tighten the nuts and bolts at this
stage.
4.16. Repeat the procedure for the opposite side, again not fully
tightening the nuts and bolts.
4.17. Adjust the position of the hitch tongue so that it is
perpendicular to the hopper and fully tighten all the
relevant nuts and bolts.
4.18. Place a flat washer Ø20 (11) onto the axle tube followed by
a spacer (12) and then another flat washer Ø20 (11), as
shown in figure 10.
4.19. Attach the pneumatic wheel (4) with the valve facing
outwards. Align the hole in the wheel hub with the hole in
the axle and secure using hex bolt M6x50 (8) and lock
nut M6 (9), as shown in figure 11. Repeat the procedure
for the opposite side.
4.20. The spreader is now fully assembled and ready for use.
Original Language Version
5.1. Read the Safety Instructions in Section 1 before operating the
spreader.
5.2. Secure the spreader onto the prime mover using the towing
pin on the hitch tongue. Secure the towing pin with the R-pin
provided. The spreader can be converted to use a ball hitch
by fitting a Sealey Ø50mm Towing Hitch, Model No. TB36,
available from your Sealey dealer.
5.3. Load the product into the hopper, ensuring that it is evenly
distributed and the maximum capacity of the spreader is not
exceeded. When handling hazardous products it is important
to first read the safety data sheet and take necessary safety
precautions. A full range of personal safety equipment is
available from your Sealey dealer.
5.4. The towing speed will affect the rate of flow from the
spreader. It is advisable to operate the spreader at lower
speeds for a more effective flow of the product.
5.5. The adjustable feed system is controlled by movement of the
handle on the hitch tongue. Operate the spreader at the
desired speed and adjust the handle either forwards or
backwards until a satisfactory rate of flow is achieved. A
locking device is provided on the gauge to allow the optimum
flow required to be maintained.
5.6. Clean the spreader thoroughly after use, paying particular
attention to the area around the adjustable flow control
system and the agitator blade.
fig.8
fig.9
fig.10
fig.11
6. MAINTENANCE
6.1 After each use clean material out of hopper.
6.1.1 Rinse/dry inside and outside of spreader after each use.
6.1.2 Before operating make sure that the tyres are inflated to the
correct pressure.
6.1.3 Periodically check all fastenings are tight.
6.1.4 Annually clean and lightly lubricate parts.
6.1.5 Touch up all scratched or worn painted metal surfaces.
6.1.6 To avoid damaging the spreader never exceed the rated load
capacity of 80kg.
6.2 STORAGE.
6.2.1 Before storing ensure that the spreader is clean and dry.
6.2.2 Store indoors or in a protected area during severe weather and
in the winter months.
6.2.3 Never allow material to stay in the hopper for extended periods
of time.
