Sealey SSB37W User manual

Model No. .....................................SSB37W
Capacity (Weight)....................................37kg
Capacity (Volume) ...................................29ltr
Spread ......................................... 3-3.6mtr
Weight .........................................10.44kg
Dimensions (W x D x H)...................550 x 940 x 860mm
Manufactured with a strong tubular stainless steel frame and polypropylene dispensing hopper.Features corrosion resistant stainless steel
feed system ideal for spreading salt and grit.Fitted with nylon gear and adjustable feed system.Sprays in 360° motion to cover a large area.
Suitable for a variety of horticultural agents including grit, seed, salt, fertiliser and weed killer.
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
üBefore each use, check that there is no damage to the spreader and that all fixings are tight.
üReplace or repair damaged parts. Use only recommended parts.Unauthorised parts may be dangerous and will invalidate the warranty.
üEnsure that the operator is fully trained and competent to operate the spreader.
üEnsure that all chemical safety instructions are adhered to when handling products for use in the spreader.A full range of personal
safety equipment is available from your Sealey dealer.
üEnsure all non essential personnel keep a safe distance when the spreader is in use.
DO NOT place hands inside the hopper during spreading.
DO NOT over inflate the tyres, 25psi (1.7bar) maximum.
DO NOT overload the spreader - see Specification.
DO NOT leave unattended, especially when loaded.
DO NOT allow anybody to sit, stand, or ride on the spreader.
DO NOT allow untrained personnel to use the spreader.
DO NOT allow children to play in or climb onto the spreader.
DO NOT use on windy days when spreading seeds or herbicides.
DO NOT tow this spreader with a motorized vehicle of any sort.
DO NOT use the spreader for purposes other than for which it is designed.
DO NOT operate the spreader when you are tired or under the influence of alcohol, drugs or intoxicating medicines.
DO NOT operate the spreader over edges, rough surfaces etc., where the spreader is at risk of overturning.
WARNING! Failure to comply with these instructions may result in damage to spreader or other property and/or personal injury.
WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be applied by the operator.
NOTE: This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities or
lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a
person responsible for their safety.Children should be supervised to ensure that they do not play with the appliance.
INSTRUCTIONS FOR:
STAINLESS STEEL BROADCAST SALT
SPREADER 37KG WALK BEHIND
MODEL NO: SSB37W
1. SAFETY
2. INTRODUCTION
3. SPECIFICATION
© Jack Sealey Limited
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTLYAND WITHCARE FOR THE PURPOSE FOR WHICHIT IS INTENDED. FAILURE TO DO SO MAYCAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL
INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
Refer to
instruction
manual

4. CONTENTS
(7)
(35)
(2)
(30)
(12)
(31)
(32)
(1)
(52)
(21)
(25) (28)
(40)
(41)
(33)
(9)
(17)
(39) (14)
(20)
(24)
(36)
(60)
(50)
(59)
(51) (13)
(10)
(44)
Fixings/Bushes
(23)
34 11 19
27 26 42
47 49 48
18
29
Main Items
(15)
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

Item Description Qty Item Description Qty
1 Carriage Bolt M6x25 1 31 Axle End Cover 2
2 External Serrated Washer Ø8 1 32 Inner Axle Bushing 2
3 Gauge and Level Sub Assembly 1 33 Outer Axle Bushing 2
4 Adjuster Lever 1 34 Gearbox and Axle Sub Assembly 1
5 Split Handle 1 35 Screw M4x20 1
6 Split Handle 1 36 Hex Bolt M6x60 1
7 Round Head Screw M4x18 2 37 Clamp Plate 2
8 Handle Grip 1 38 Hopper Control Cable 1
9 Plastic Spacer 5 39 Hex Screw M5x10 2
10 Plastic Clamp Knob 1 40 Nylon Washer 1
11 Hopper 1 41 Large Flat Washer Ø6 5
12 "R" Pin Ø2.5x80 (Agitator) 1 42 Handle Bar 1
13 Centre Hub (Plastic) 1 43 Throat Plate 1
14 Hex Bolt M6x70 4 44 Single Coil Spring Washer Ø6 1
15 Pop Rivet Ø5x13 4 45 Large Plug 1
16 Guide Plate 1 46 Small Plug 2
17 Hex Screw M5x12 4 47 Support Rod 1
18 Frame Fork (Left) 1 48 Rain Cover (not shown in diagram) 1
19 Impeller 1 49 Hopper Grille Screen 1
20 Hex Bolt M6x35 5 50 Flat Washer Ø5 4
21 Hex Theadlock Nut M5 4 51 Wing Nut M6 6
22 Anchor Bracket 1 52 Carriage Bolt M6x20 10
23 TubeEndCap    4 53 LeftDeector    1
24 Hex Bolt M6x40 6 54 Boom Rail 1
25 HexThreadlockNutM6  23 55 FrontDeector    1
26 SupportLeg    1 56 RightDeector    1
27 Frame Fork (Right) 1 57 Clamp Bracket 4
28 ThinPlasticWasher   1 58 RearDeector    1
29 Pneumatic Wheel 2 59 Flat Washer Ø6 4
30 Flat Washer Ø16 2 60 Hex Bolt M6x30 4
PARTS LIST
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

4
39
37
25
38
21
22
49
COMPOSITE EXPLODED PARTS DIAGRAM
Seeg.12
39 Seeg.9and
view bottom right
Seeg.5
Seeg.4&g.6
Seeg.1
Seeg.9
Seeg.2
Seeg.3
Seeg.7
38
37
41
60
59
37
50
43
47
36
58
53
51 54
55
56
25 957
52
44
42
40 41
35
A
B
A
B
C
C
Seeg.9
45
46
46
20
20
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

5. ASSEMBLY
5.3. Refer to fig.3 for support leg and gearbox fitting.
5.3.1. Take the hopper (11) and lay it upside down, lower the gearbox and frame onto the hopper, inserting the vertical axle through the
hopper and centre hub (13).
5.3.2. On top of the wheel frame, lay the support leg (26), secure together with hex bolts M6x70 (14) and large washer (41),
Inserting from inside the hopper securing with lock nuts (25) on the outside.
5.4. Refer to fig.4 for undercarriage and rear deflector fitting.
5.4.1. Slide the outer axle bushes (33) over the axle and push into the frame with location lobe innermost, see also fig.6.
5.4.2. Insert the inner axle bush (32) into the outer axle bush.
5.4.3. Fit the wheels (29).Secure the right hand wheel using hex bolt M6x60 (36) and a lock nut (25); see fig.4 and fig.6 for clarity.
5.4.4. Place a flat washer (30) over the end of the axle and then the axle caps (31). Use a soft faced mallet to ensure the axle caps are seated
correctly.
5.4.5. Attach the rear deflector (58) to the support leg; fasten with M6x40 hex bolts (24) and M6 lock nuts (25).
fig.2
fig.3
fig.4
fig.4
Note! Before assembly ensure there are no missing parts or fixtures.
5.1. Refer to fig.1 for fitting the impeller.
5.1.1. Slide the Impeller (19), with vanes uppermost over the vertical axle on the gearbox (34).Align the hole in the impeller boss with the
lower pre-drilled hole in the spindle.
5.1.2. Secure the Impeller to the axle with a round head screw M4x20 (35).Ensure the impeller is secured to the lower hole on the vertical axle.
5.2. Refer to fig.2 for fitting the wheel frames (forks).
5.2.1. Slide the wheel frames (27) and (18) over the axle, ensure the bush housing (33) is facing inwards as in fig.5 and fig.6.
5.2.2. Secure with support rod (47) and M6x35 hex bolts (20).
fig.1
Flange of outer axle
bushing outermost with
the keyed lug innermost.
Inner axle bushing
and wheel spacer
outermost.
(19)
(35)
(34)
(20)
(47)
(20)
(27)
(18)
(33)
(33)
(34) (26)
(25)
(14)
(41)
(11)
(38)
(31)
(30)
(29) (32)
(36&25)
(24)
(25)
(33)
(32)
(58)
[Seealsog.6
forttingbushes]
(28)
Impeller
xing
point
Hex Bolt
M6x35
Hex Bolt
M6x35
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

5.5. Refer to fig.7 for handle fitting.
5.5.1. Turn the spreader onto its wheels and slide the handle assembly (42) around the frame, secure with 4 M6x40 hex bolts (24) and lock
nuts (25).
5.6. Refer to fig.8 for control lever and cable fitting.
5.6.1. Insert the bent end of the control cable (38) into the small hole in the lever assembly.
5.6.2. Remove the hex screws (17) from the cable clamp, then insert the control cable into the clamp (A,B).
5.6.3. Re-insert hex screws to clamp control cable in place.
5.6.4. Move the flow control lever (C) down to open the spreader slot in the bottom of the hopper.If the hole (fig.13) is not fully exposed or fully
closed, loosen the cable clamp (B) and adjust the cable.
5.6.5. Insert R-pin (12) through top of the vertical axle.
fig.8
(35,25) Pinned hub this side
FRONT
(32)
fig.9
fig.7
5.7. Refer to fig.9 for fitting front and side deflectors.
5.7.1. Offer the 4-M6 X 30 screws (60) from inside the hopper and fit 4 brackets (57) to underside of hopper with spacers (9) between.
5.7.2. Slide the boom rail (54) through the 1st clip in items (57) and (60), then brackets (57), finally the 2nd clip as indicated.
5.7.3. Clamp all 3 deflectors with wing nuts (51) and carriage bolts (52).
Hopper
(9), (21), (59), (60)
(57)
(52)
(54)
(51)
(53, 56 opposite)
(55)
1st 2nd
55
(33)
Impeller (19)
Hopper (11)
(16)
(43)
(37),(17),(21)
Cable (38)
fig.6
fig.5
(42)
(24)
(25) (39)
(37)&(38)
(4)&(5)&(6)
(12)
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

6.1. Prior to filling the hopper with salt/grit, ensure the hopper screen (49) is insitu.This will grade the salt/grit passing through to the
throat plate and help prevent possible clogging.
6.2. Use the stop on the gauge to ensure the same amount of distribution (fig.12).
6.3. Seefigs.10&11forsuggestedwalkingpatternsdependingonthelevelofcoverageyourequire.
6.4. Always start walking prior to opening the flow control lever.
6.5. Every time you are ready to stop, or turn to make a new pass, close the flow control lever to stop dispensing the material and continue
one more stride.This reduces waste with over saturated product coverage. Ensure the stop bolt continues to register the spreader
setting from table "B". Remember to start walking prior to opening the flow control lever.
6.6. To ensure consistent coverage, make sure each broadcast pattern slightly overlaps the previous one.
6.7. Make sure that any broadcast material does not come into contact with trees, shrubs and flowers that could be harmed by the material.
6.8. Clean the spreader thoroughly after each use paying particular attention to the throat plate and the bottom of the hopper.
fig.11
fig.10
6. OPERATION
(CHART 'A') SQUARE FOOT COVERAGE PER BAG (LBS/1000SQ.FT)
WEIGHT OF BAG (LBS) 5000 SQ.FT COVERAGE 10000 SQ.FT COVERAGE 15000 SQ.FT COVERAGE
5 1.0lb 0.5lb 0.3lb
10 2.0lb 1.0lb 0.7lb
15 3.0lb 1.5lb 1.0lb
20 4.0lb 2.0lb 1.3lb
25 5.0lb 2.5lb 1.7lb
30 6.0lb 3.0lb 2.0lb
35 7.0lb 3.5lb 2.3lb
40 8.0lb 4.0lb 2.3lb
45 9.0lb 4.5lb 3.0lb
50 10.0lb 5.0lb 3.3lb
55 11.0lb 5.5lb 3.7lb
fig.12
"Use the stop on the gauge to ensure
the same amount of distribution"
Fullow
Setow
Adjustable Throat plate
Spinning agitator
fig.13
(10),(9),(1),(2)
(4)
(43)
(12)
(20),(40),(41),(25)
(13)
(15)
(5),(6),(7)
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited

7.1. After each use clean material out of hopper.
7.1.1. Rinse/dry inside and outside of spreader after each use.
7.1.2. Before operating make sure that the tyres are inflated to the correct pressure i.e. 25psi maximum.
7.1.3. Periodically check all fastenings are tight.
7.1.4. Check the condition of the "media agitator" (12) "R" pin, after continued use.Replace if required.
7.1.5. Annually clean and lightly lubricate cable.
7.1.6. To avoid damaging the spreader never exceed the rated load capacity of 37kg.
7.1.7. Use the rain cover (48) when necessary.Avoid using the spreader when raining, unless essential.
7.2. STORAGE.
7.2.1. Before storing ensure that the spreader is clean and dry; fit the rain cover.
7.2.2. Store indoors or in a protected area during severe weather and in the winter months.
7.2.3. DO NOT allow material to stay in the hopper for extended periods of time.
6.9. CALCULATING THE AMOUNT OFMATERIAL NEEDED. (refer to Charts 'A' & 'B')
The spreader is designed to be pushed at three miles an hour, which is a brisk walking pace.Slower or faster speeds will change the
spread pattern.Wet salt/grit will also change the spread pattern.See fig.13 for media agitator; promoting flow.
To calculate the amount of salt/grit needed, divide the coverage stated on the packaging by the weight of the bag.
For example, a 10lb bag of salt/grit with a coverage of 10,000 sq.ft. will distribute 1lb of salt/grit every 1,000 sq.ft. at full rate or 1/2lb.of
salt/grit every 1,000 sq.ft. at half rate.
6.10. For pre-calculated rates see Chart 'A' (Example: A 25lb bag with a 15,000 sq.ft. coverage requires 1.7lb of media per 1,000 sq.ft.
6.11. Use Chart 'B' to find the closest spreader setting.For example, 1.7lb per 1000 sq.ft. = spreader setting 6)
6.12. Use both charts as a guide only; experience will replace necessity to use the charts but they will be a good reference point.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St.Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
7. MAINTENANCE
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
(CHART 'B') SPREADER SETTINGS/SPREADER WIDTHS
MATERIALS TO BE
USED LBS/1000 SQ.FT G/M² SPREADER SETTING SMALL PARTICLE SPREAD MEDIUM PARTICLE SPREAD LARGE PARTICLE SPREAD
GRIT
SEED
FERTILISER
WEED
KILLER
E.T.C.
1 5 5 5-6 ft 6-9 ft 9-12 ft
2 10 8 5-6 ft 6-9 ft 9-12 ft
3 15 10 5-6 ft 6-9 ft 9-12 ft
4 20 13 5-6 ft 6-9 ft 9-12 ft
5 25 15 5-6 ft 6-9 ft 9-12 ft
6 30 18 5-6 ft 6-9 ft 9-12 ft
7 35 20 5-6 ft 6-9 ft 9-12 ft
8 40 23 5-6 ft 6-9 ft 9-12 ft
9 45 25 5-6 ft 6-9 ft 9-12 ft
10 50 28 5-6 ft 6-9 ft 9-12 ft
11 55 30 5-6 ft 6-9 ft 9-12 ft
Original Language Version SSB37W Issue: 3 (SP) - 11/09/15
© Jack Sealey Limited
