Sealey SPB37W User manual

INSTRUCTIONS FOR:
BROADCAST SPREADER 37kg
WALK BEHIND
MODEL No: SPB37W
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
2. SPECIFICATION
3. INTRODUCTION & CONTENTS
Model No. .....................................SPB37W
Capacity (Weight)....................................37kg
Capacity (Volume) ...................................29ltr
Spread .........................................3-3.6mtr
Weight ..........................................10.4kg
Dimensions (W x D x H)...................535 x 940 x 820mm
Manufactured with a strong tubular steel frame and polypropylene
dispensing hopper. Fitted with nylon gear, rain cover, pneumatic tyres
and adjustable feed system. Includes hopper screen to ease spreader
flow and filter out unwanted contaminants. Sprays in 360° motion to
cover a large area. Suitable for a variety of horticultural agents
including grit, seed, salt, fertiliser and weed killer.
Original Language Version SPB37W Issue: 1 - 21/06/11
Before each use, check that there is no damage to the spreader
and that all fixings are tight.
 Replace or repair damaged parts. Use only recommended parts.
Unauthorised parts may be dangerous and will invalidate the
warranty.
Ensure that the operator is fully trained and competent to operate
the spreader.
 Ensure that all chemical safety instructions are adhered to when
handling products for use in the spreader. A full range of personal
safety equipment is available from your Sealey dealer.
 Always distribute the load evenly.
 Ensure all non essential personnel keep a safe distance when
the spreader is in use.
Keep hands and feet away from moving parts.
DO NOT overload the spreader - see Specification.
DO NOT leave unattended, especially when loaded.
DO NOT allow anybody to sit, stand, or ride on the spreader.
DO NOT allow untrained personnel to use the spreader.
DO NOT allow children to play in or climb onto the spreader.
DO NOT use on windy days when spreading seeds or herbicides.
DO NOT tow this spreader with a motorized vehicle of any sort.
DO NOT use the spreader for purposes other than for which it is
designed.
DO NOT operate the spreader when you are tired or under the
influence of alcohol, drugs or intoxicating medicines.
When loaded, DO NOT operate the spreader over edges, rough
surfaces etc. where the spreader is at risk of overturning.
 WARNING! Failure to comply with these instructions may result
in damage to spreader or other property and/or personal injury.

4.2 Refer to fig.2.
4.2.1 Slide the wheel frames (15) over the axle, ensure the bush
housing is facing inwards.
4.2.2 Secure with support rod (19) and M6x40 hex bolts (2).
4.3 Refer to fig.3.
4.3.1 Take the hopper (13) and lay it upside down, lower the gearbox
and frame onto the hopper, inserting the vertical axle through
the hopper.
4.3.2 On top of the wheel frame lay the support leg (16), secure
together with hex bolts M6x70 (1) with large washer (6),
Inserting from inside the hopper securing with lock nuts (7) on
the outside.
fig.2
fig.3
fig.4
4.4 Refer to fig.4.
4.4.1 Slide the inner axle bushes (11) over the axle and push into the
frame. Ensure a tight fit.
4.4.2 Put on the wheels (18). Secure the right hand wheel using hex
bolt M5x45 (3) and a lock nut (8).
4.4.3 After the wheel place a flat washer (5) over the end of the axle
and then the axle caps (9). Use a soft faced mallet to ensure
the axle are seated correctly.
fig.4
Original Language Version SPB37W Issue: 1 - 21/06/11
Note! Before assembly ensure there are no missing parts or fixtures.
4.1 Refer to fig.1.
4.1.1 Slide the Impeller (14) over the vertical axle on the gearbox (12).
4.1.2 Secure the Impeller to the axle with a round head bolt M4x20 (4).
Ensure the impeller is secured to the lower hole on the axle.
fig.1
4. ASSEMBLY

5. OPERATION
5.1 The spreader is designed to be pushed at three miles an hour,
which is a brisk walking pace. Slower or faster speeds will
change the spread pattern. Wet fertiliser will also change the
spread pattern.
5.2 Use the Stop bolt on the gauge to ensure the same amount of
distribution.
5.3 See figs.7 & 8 for suggested walking patterns depending on
the level of coverage you require.
5.4 Always start walking prior to opening the flow control plate.
5.5 Every time you are ready to stop, or turn to make a new pass,
close the flow control plate to stop dispensing the material and
continue one more stride. This reduces waste and avoids
damaging a lawn with over saturated product coverage.
5.6 To ensure consistent coverage, make sure each broadcast
pattern slightly overlaps the previous one.
5.7 Make sure that any broadcast material does not come into
contact with trees, shrubs and flowers that could be harmed by
the material.
5.8 Clean the spreader thoroughly after each use
paying particular attention to the shut off plate and the bottom
of the hopper.
fig.8
fig.5
fig.7
4.5 Refer to fig.5.
4.5.1 Turn the spreader onto its wheels and slide the handle
assembly (17) around the frame, secure with 4 M6x40 hex bolts
(2) and lock nuts (7).
fig.6
4.6 Refer to fig.6.
4.6.1 Insert the bent end of the control cable into the small hole in
the lever assembly.
4.6.2 Remove the hex bolts from cable clamp then insert the control
cable into the clamp (A,B).
4.6.3 Re-insert hex bolts to clamp control cable in place.
4.6.4 Move the lever (D) down to open the spreader slot in the
bottom of the hopper. If the hole is not fully exposed, loosen
the cable clamp (C) and adjust the cable.
4.6.5 Insert R-pin (10) through top of the vertical axle.
Original Language Version SPB37W Issue: 1 - 21/06/11

6. MAINTENANCE
(CHART 'A') SQUARE FOOT COVERAGE PER BAG (LBS/1000SQ.FT)
WEIGHT OF BAG (LBS) 5000 SQ.FT COVERAGE 10000 SQ.FT COVERAGE 15000 SQ.FT COVERAGE
5 1.0lb 0.5lb 0.3lb
10 2.0lb 1.0lb 0.7lb
15 3.0lb 1.5lb 1.0lb
20 4.0lb 2.0lb 1.3lb
25 5.0lb 2.5lb 1.7lb
30 6.0lb 3.0lb 2.0lb
35 7.0lb 3.5lb 2.3lb
40 8.0lb 4.0lb 2.3lb
45 9.0lb 4.5lb 3.0lb
50 10.0lb 5.0lb 3.3lb
55 11.0lb 5.5lb 3.7lb
(CHART 'B') SPREADER SETTINGS/SPREADER WIDTHS
MATERIALS TO BE
USED
LBS/1000
SQ.FT
SPREADER
SETTING
SMALL PARTICLE
SPREAD
MEDIUM PARTICLE
SPREAD
LARGE PARTICLE
SPREAD
GRIT
SEED
FERTILISER
WEED
KILLER
E.T.C.
1 5 5-6 ft 6-9 ft 9-12 ft
2 8 5-6 ft 6-9 ft 9-12 ft
3 10 5-6 ft 6-9 ft 9-12 ft
4 13 5-6 ft 6-9 ft 9-12 ft
5 15 5-6 ft 6-9 ft 9-12 ft
6 18 5-6 ft 6-9 ft 9-12 ft
7 20 5-6 ft 6-9 ft 9-12 ft
8 23 5-6 ft 6-9 ft 9-12 ft
9 25 5-6 ft 6-9 ft 9-12 ft
10 28 5-6 ft 6-9 ft 9-12 ft
11 30 5-6 ft 6-9 ft 9-12 ft
6.1 After each use clean material out of hopper.
6.1.1 Rinse/dry inside and outside of spreader after each use.
6.1.2 Before operating make sure that the tyres are inflated to the
correct pressure i.e. 30psi.
6.1.3 Periodically check all fastenings are tight.
6.1.4 Annually clean and lightly lubricate parts.
6.1.5 Touch up all scratched or worn painted metal surfaces.
6.1.6 To avoid damaging the spreader never exceed the rated load
capacity of 37kg.
6.2 STORAGE.
6.2.1 Before storing ensure that the spreader is clean and dry.
6.2.2 Store indoors or in a protected area during severe weather and
in the winter months.
6.2.3 Never allow material to stay in the hopper for extended periods
of time.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
Original Language Version SPB37W Issue: 1 - 21/06/11
5.9 CALCULATING THE AMOUNT OF MATERIAL NEEDED.
(refer to Charts 'A' & 'B')
To calculate the amount of material needed e.g lawn fertiliser,
divide the coverage stated on the packaging by the weight of
the fertiliser bag. For example, a 10lb bag of fertiliser with a
coverage of 10,0000 sq. ft. will distribute 1lb of fertiliser every
1,000 sq.ft. at full rate or 1/2lb. of fertiliser every 1,000 sq. ft. at
half rate.
5.10 For pre-calculated rates see Chart 'A' (Example: A 25lb bag
with a 15,000 sq. ft. coverage requires 1.7lb of fertiliser per
1,000 sq.ft.
5.11 Use Chart 'B' to find the closest spreader setting. For example,
1.7lb per 1000 sq.ft. = spreader setting 8)
