SPYKER P20-5010 Series User manual

1008198 Rev. B©2010 Spyker Spreaders/A Brinly-Hardy Co.
Spyker Spreaders
Contact Us at 800.972.6130
This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
IMPORTANT
Model P20-5010/P20-9010 Series
Operator's Manual

1008198 Rev. B 2
22
15
23
11
19
24
26
4
48
1
23
11
8
7
24
13
17
5
12
25
21
46
49
24
48
11
31
30
45
31
32
33
24
24
32
54
14
27 18
33
10
12
24
24
24
24
3
9
27
28
43
33
34
55
29
16
52
28
53
2
16
33
12
33
12
12 12
12
51
39
40
36
47
44
36
37
38
38
37
50
35
50
42
56
24
33
11
20
20
11
15
6
22
50
41
57
Handle/Frame
Explosion
Axle Explosion
Hopper Explosion

1008198 Rev. B3
Item Part # Qty Description
1 1007081 1 Handle spacer
2 F-577 1 E-Ring
3 1000213 1 Dial
4 1008028 1 Gauge Plate
5 1008156 1 Adjust handle
6 1007086 1 Adjust handle knob side 1
7 1007087 1 Adjust handle knob side 2
8 1007088 1 Screw, M4 x 18 SS
9 1001587 1 Dial Mount Plastic Hopper
1000211 1 Dial Mount Metal Hopper
10 1001590 1 Diffuser Plug (Plastic
Hopper)
11 1007091 7 Bolt, M6 x 45 SS
12 1007092 4 Nylon washer
13 1007093 1 Flat washer, M6, big SS
14 1008022 1 Screen For Plastic Hopper
15 1007095 2 Handle cover
16 1007892 1 Plastic Hopper Black
1000204 1 Metal Hopper
17 1008207 1 Lockwasher, M6 SS
18 F-574 1 Hopper bushing
19 1008196 1 Pivot and bracket assembly
20 1007100 2 Wheel frame tube
21 1008206 2 Nut, Nylon Lock M8 SS
22 1007102 2 End cover
23 1007103 2 Upper handle
24 1007104 14 Lock nut, M6 SS
25 1008013 1 Control rod A
26 1007106 1 Handle shaft
27 1000215 2 Pine Tree Clip
28 1001588 2 Rate Gate Guide Plastic
Hopper
1000202 2 Rate Gate Guide Metal
Hopper
Item Part # Qty Description
29 1000198 1 Felt Washer
30 1008011 1 Frame
31 1007111 2 Frame brace
32 1007112 2 Bolt, M6 x 60 SS
33 1007113 5 Bolt, M6 x 35 SS
34 1000223 1 Agitator
35 1005414 1 Rue Ring Locking Pin
36 1008027 2 Pneumatic wheel
37 1007117 2 Axle bushing
38 1007118 2 Axle bearing
39 1008010 1 Gearbox & axle assembly
40 1007120 1 Washer
41 1008031 1 Cotter Pin
42 1008209 1 Impeller
43 1000203 1 Bearing, Metal Hopper
44 1007124 1 Hex locknut, M5 SS
45 1007125 1 Cross brace
46 1008014 1 Adjust connect rod, B
47 1008208 1 Hex bolt, M5 x 40 SS
48 1007128 2 Flat washer, M6 SS
49 1008098 1 Cotter Pin, Small
50 1007531 3 Nylon Washer
51 1005993 1 Dial Mount Retainer
(Plastic Hopper)
52 1000210 1 Rate Gate
53 1000687-01 1 Rate Gate Link
54 1008110 1 Cover, Square Hopper
55 1008257 1 Bracket, Frame Clamp
56 1008258 1 Bar, Frame Clamp
57 1008276 1 Hex Bolt, M6 x 20 SS

1008198 Rev. B 4
1. Remove two M6 locknuts and M6 x 45mm
long bolts to remove pivot and bracket
assembly from wheel frame tubes. Set bolts
and nuts to the side. You will re-install them in
Step 2.
2. Insert arm assembly between frame tubes.
Re-install pivot and bracket assembly through
wheel frame tubes and arm assembly with two
M6 x 45mm bolts and M6 locknuts removed
in Step 1.
Figure 1
Figure 2

1008198 Rev. B5
3. Rotate control rod and insert into adjustment
handle, Figure 3. Remove one nut from end
of control rod. Insert control rod into pivot
and bracket assembly as shown, Figure 3.
Note orientation of bracket. Install second nut
finger tight only.
Ensure rate gate opens and closes fully. If so,
hold the upper control rod nut with wrench
and tighten the bottom nut only.
4. Tighten nuts and bolts on both sides of
spreader at locations shown.
Figure 3
Figure 4

1008198 Rev. B 6
READ BEFORE USING
OPERATE SAFELY
Keep bystanders away when you operate this machine.
Use this machine for intended purpose only.
Do not let children or an untrained person operate
machine.
Keep all parts in good condition and properly installed.
Fix damaged parts immediately. Replace worn or broken
parts.
Do not modify the machine or safety devices.
Unauthorized modifications to the machine may impair
its function and safety, and void the warranty.
Do not let anyone sit or ride on equipment during
operation. Keep riders off attachment.
Wear substantial footwear and long trousers. Do not
operate the equipment when barefoot or wearing open
sandals.
Do not wear loose fitting clothing that can get caught in
moving parts.
Always wear eye protection when operating the
equipment.
Stay alert for holes in the terrain and other hidden
hazards.
Watch out for traffic when crossing or near roadways.
Before you operate any feature of this machine, observe
your surroundings and look for bystanders.
Always wash hands after contact with fertilizers and
pesticides.
Keep all nuts, bolts and screws tight to be sure the
equipment is in safe working condition.

1008198 Rev. B7
READ BEFORE USING
Become Familiar With The Operation Of The Spreader Before
You Put Material In The Hopper
• Practice walking with the spreader, opening and
closing the rate gate at the appropriate times.
• Travel at a constant speed and operate the spreader
lever position. Remember: Open the rate gate after
the spreader is in motion at operating speed (about
3 mph, or at a brisk walking pace).
• Close the rate gate while spreader is still at
operational speed.
Dial Setting Information
The RATE DIAL has 9 numbers with 10 stops between
each number. This allows for accurate control of the
spreading rate. The dial is set with only a turn, it will
automatically lock into the set position. LINE UP THE
DIAL NUMBER WITH THE DIAL INDICATOR.
Rate Dial
• The spread width ranges from 4 - 12 ft. wide
depending on the volume/density, particle size of the
material, and rate of travel.
• The spread thins or feathers at the outer edges,
eliminating sharp, "Edge Of Spread" lines which
cause stripes and streaks. Extra coverage can be
given under trees and other heavy feeding areas
without showing "Edge Of Spread" lines.
• Gaps and double overlaps are less likely. Small
errors in travel are forgiven and do not show.
WARNING: When spreading products containing
herbicides, exercise extreme caution with respect to
careless spreading and to wind-drift.
Contact Of Some Products On
Some Plants Can Be Fatal
If a dial setting is not found, use the size and weight
comparison table found in this manual. Determine a
dial setting on the low side. If the setting proves to
be too low, cover the area more than one time. A
higher setting can be used when a proven dial setting is
established.
Remember: Published dial settings are
approximate only. The operation of the spreader, the
condition of the material (damp or dry or over-pulverized)
and weather conditions, are all contributing factors.
For these reasons, it is often a good idea to spread the
area 2 times - or one-half rate - in cross directions (SEE
INFORMATION ON ONE-HALF RATE DIAL SETTINGS).
One-half rate dial settings are highly recommended under
damp and humid conditions.
Rotary Agitator
Use the rotary agitator only if needed. Free-flowing,
lump-free materials will not require the agitator. The
rotary agitator is easily installed or removed. Note the
clockwise rotation and sweep. Place felt washer around
spinner shaft before inserting agitator.

1008198 Rev. B 8
READ BEFORE USING
Now You Are Ready To Put
Material In The Hopper
WARNING: Avoid Injury! Chemicals can be
dangerous. Avoid injury to operators or bystanders.
• Make sure the rate gate is in the closed position.
• Read chemical container label for handling
instructions. A Material Safety Data Sheet (MSDS)
should be supplied by the chemical dealer and
provides proper safety information.
• Wear proper clothing and safety equipment while
handling or applying chemicals.
• Prohibit all smoking, drinking, and eating around
chemicals.
• When spreading products containing herbicides,
exercise extreme caution with respect to careless
spreading and to wind-drift. Contact Of Some
Products On Some Plants Can Be Fatal.
• Fill the spreader on a flat, level surface only. Fill on
sidewalk, driveway, cardboard, etc. to avoid material
loss.
• When filling hopper with material, always use screen
to help break up clumps.
Now You Are Ready To Spread
• Keep spinner blade clean. Excess material build-up
can cause an uneven spread pattern.
• Keep the impeller level when spreading.
• DO NOT overload. Maximum capacity is 50 lbs.
• DO NOT use on windy days.
• Spread header strips at the ends of the area
OPPOSITE of the direction of spreading. This will
provide a "turn-around" area, an area to re-align the
spreader for the return spread.
• Example shown is for 6 ft. wide spread. Make the
first spread pass at one-half the spread width from
the edge of the spreading area or in this case,
approximately 3 feet (or one big step).
• Additional spreading passes will be at the full spread
width or approximately 6 ft. apart.
• TAKE A SIGHTING AT THE FAR END. Keep your eye
on the sighting as you spread. You will not need
to wonder where you are or where you have been.
Continue until spreading is completed.
• Left over fertilizer can be spread under trees and
other high feeding areas without showing "edge of
spread" lines.
Tip: When not spreading, and if pushing the spreader
some distance, tip the spreader so only the idle wheel is
on the ground.
Header
6’ 6’3’
Header
Cleaning The Spreader Is Part
Of The Spreading Job
Clean and oil spreader immediately after each use.
Method #1 - Wipe spreader thoroughly with an oily cloth.
Oil all bearings and bearing areas.
Method #2 - Wash, rinse, and dry the spreader. Note:
Drying takes time. Moisture trapped in bearing areas is
slow to go. Immediately after drying - oil all bearings and
moving parts. Make certain all operations are thorough.
NOTE: Good "Dry Cleaning" is preferable to poor "Wet
Cleaning".
• It is virtually impossible to have rust and corrosion on
a clean, dry, oiled surface.
• Again - just before using - oil all bearings and moving
parts.
• In storage, ideally the spreader should be hung by
the handle. In any case, do not pile weight on the
spreader, as excess weight over a period of time can
distort the tires.
Oil Bearings And All Moving
Parts
Make sure the spreader is running freely!

1008198 Rev. B9
Spreader does not sit flat The "feet" or the flattened
portion of the spreader hopper
support tubes are not bent
equally.
Using a hammer or pliers,
bend the feet to be equal with
each other.
Deflector shut off is binding
and will not open/close
properly
Shut off plate is jammed with
debris.
Thoroughly wash out hopper
and shut off plates with water.
Ensure debris is not stuck
between shut off plate and
rate gate plate.
TROUBLESHOOTING

1008198 Rev. B 10
Particle Size
NOTE: Dial Settings Are Approximate Only !
Lbs. per
1000 sq. ft.
Product
Fine Pellets
1
2
3
2
4
6
2
4
6
1
2
3
2
4
6
2
4
6
Dial Settings
Full Rate
Once Over
3.6
4.0
4.2
3.7
4.7
5.2
3
4.2
4.5
3.5
4.2
4.7
3.5
4.2
5.2
3.8
4.9
5.9
Dial Settings
Half Rate
Twice Over
3.1
3.5
3.7
3.2
4.1
4.5
2.2
3.7
4
3
3.7
4
3
3.8
4.5
3.3
4.1
4.9
Mixed Fine
Pellets
Small Pellets
Nitrogen Pellets
Medium Size
Medium Pellets
And Granuals
Large Heavy
Pellets
GRASS SEED SPREADING CHART
Product Bag
Weight
Sq. Ft.
Coverage
Dial Setting
Full Rate
Dial Setting
Half Rate
Spread
Width
Blue Grass or Red Top .5 lbs. 1,000 1.25 4
1 lbs. 1,000 2.0 4
2 lbs. 1,000 2.5 4
Park, Merion, Delta, or Kentucky Bluegrass .5 lbs. 1,000 2.5 4
1 lbs. 1,000 3.0 4
2 lbs. 1,000 3.5 4
Hulled Bermuda 2 lbs. 1,000 2.75 2.25 6
3 lbs. 1,000 3.0 2.5 6
4 lbs. 1,000 3.25 2.75 6
Mixtures Including Coarse Seeds 2 lbs. 1,000 6.0 6
4 lbs. 1,000 7.0 6
6 lbs. 1,000 7.0 6
Rye Grasses or Tall Fescue 2 lbs. 1,000 6.0 6
4 lbs. 1,000 7.0 6
6 lbs. 1,000 7.75 6
Dichondra 4 oz. 1,000 1.9 8
8 oz. 1,000 2.1 8
12 oz. 1,000 2.5 8
Pensacola Bahia 4 lbs. 1,000 4.5 3.75 7
5 lbs. 1,000 4.75 4.0 7
6 lbs. 1,000 5.0 4.25 7

1008198 Rev. B11
THIS PAGE INTENTIONALLY LEFT BLANK

1008198 Rev. B
1 YEAR LIMITED WARRANTY
This is warranted to the original purchaser only. Spyker will replace parts
with defects in materials and workmanship, for a period of one year from the
date of purchase.
For Spyker Spreaders–a Brinly-Hardy Company, products employing metal
gear systems, pinion and bevel, these metal gears, only, not inclusive of any
other parts or materials, are warranted for the life of the spreader, not to
be used for replacement or repair past original purchase.
Spyker Spreaders will not be liable for any loss, damage or expense including,
but not limited to, consequential or incidental damages, arising from the
operation, condition or use of the item. The sole and exclusive remedy
against Spyker Spreaders being the replacement of the defective parts. This
warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
This express warranty, which is applicable only to the original
purchase, is in lieu of and excludes all other warranties, whether
expressed or implied by operation of law or otherwise, including any
warranty of merchantability or fitness for particular purpose.
SPYKER SPREADERS
Jeffersonville, IN 47130 USA
Phone: [phone]
